Thermasol ThermaTouch TT7 Series User manual

Wellness Steam Package
OVER 60 YEARS OF STEAM SHOWER INNOVATION
Installation Manual
For Tutorials and Troubleshooting visit www.thermasol.com/solutions

22
ThermaTouch Control
7 Inch Screen
Installation Manual
For Tutorials and Troubleshooting visit www.thermasol.com/solutions
TT7X-XX
OVER 60 YEARS OF STEAM SHOWER INNOVATION

PLEASE REVIEW WARNINGS BELOW AND LEAVE THIS MANUAL WITH HOMEOWNER
DO NOT USE THIS PRODUCT UNLESS YOU HAVE CONSULTED WITH YOUR DOCTOR AND RECEIVED WRITTEN PERMISSION TO DO SO.
USE OF THIS PRODUCT MAY BE HAZARDOUS TO YOUR HEALTH.
PLEASE CONSULT YOUR PHYSICIAN BEFORE USING. IF YOU ARE PREGNANT, ELDERLY, HAVE HIGH BLOOD PRESSURE, DIABETES,
SUFFERING FROM HEART DISEASE, ARE INTOXICATED, OR NOT IN GOOD HEALTH, DO NOT USE THIS STEAM BATH.
STEAM IS HOT! DO NOT TOUCH OR GO NEAR THE STEAMHEAD FROM THE TIME THE UNIT IS “ON,” UP TO ONE HOUR AFTER IT HAS SHUT
OFF. SEVERE BURNS WILL OCCUR IF YOU COME IN CONTACT WITH THE STEAMHEAD OR STEAM EMITTING FROM THE STEAMHEAD.
NEVER ATTEMPT TO FILL AROMA RESERVOIR ON THE STEAMHEAD WHEN UNIT IS IN THE "ON" POSITION. SEVERE BURNS WILL OCCUR.
DO NOT USE THERMASOL AROMATHERAPY OILS, SKIN CARE PRODUCTS OR ANY PRODUCT ASSOCIATED WITH YOUR THERMASOL UNIT
WITHOUT CONSULTING WITH YOUR ALLERGIST OR DOCTOR BEFORE USE. THESE PRODUCTS MAY BE HAZARDOUS TO YOUR HEALTH.
DO NOT USE STEAM ROOM WHILE UNDER THE INFLUENCE OF ALCOHOL OR DRUGS, AS THIS CAN BE HAZARDOUS TO YOUR HEALTH.
YOUR SHOWER MAY BE A SLIP-AND-FALL HAZARD. CHECK WITH YOUR CONTRACTOR OR FLOORING MANUFACTURER REGARDING THE
SAFE USE OF YOUR FLOORING IN A STEAM APPLICATION. SLIPPING AND FALLING INTO THE STEAMHEAD ITSELF OR INTO THE STREAM
OF STEAM EMITTING FROM THE STEAMHEAD WILL CAUSE SERIOUS BURNS OR PHYSICAL INJURY.
IF YOU ARE FEELING UNCOMFORTABLE, DIZZY, FAINT, OR STARTING TO FALL ASLEEP, IMMEDIATELY EXIT THE STEAM ROOM.
DO NOT USE STEAM ROOM IF YOU ARE UNDER THE AGE OF 16 UNLESS SUPERVISED BY AN ADULT.
THERMASOL STEAM BATH GENERATORS ARE NOT DESIGNED TO BE USED FOR SPACE HEATING PURPOSES.
THERMASOL STEAM BATH GENERATORS ARE FOR INDOOR USE ONLY. THEY SHOULD NEVER BE LOCATED OUTSIDE THE HOME.
All products must be installed in accordance with installation instructions provided. Failure to do so may invalidate warranty at
manufacturer’s discretion. ©2019 ThermaSol.
The ThermaTouch Control must be installed
inside the shower. The ThermaTouch control
will only function on the current TFX, SSA and
PRO Series generators.
The control should be installed 60" from
the floor of the shower and away from
the steamhead.
The steamhead should be installed 24" from
the floor and 6" from any wall. Locate as far
as possible from the bathing seating area
or location of the users and not below
any fixtures.
IMPORTANT: When locating and installing the
ThermaTouch, it is required to not place the
control under any water-outlets, shower heads
or in the direct path of flowing water.
SEE DIAGRAM FOR LOCATION EXAMPLE.
1Important Information before You Install
THERMASOL.COM I800.776.0711 3
Wellness Steam Package

7.5" W by 5.5" opening for recessed mount TTMR-BK Mud Ring
3Mud Ring Application
PDM
Item 10-8147
Silicone Installation instructions, warranty,
static cling warning label
25-foot Yellow M12 Cable
Item 03-7149-25
Mud Ring
Item 04-8544
2Tools and Materials
Controller
Item TT7X-XX
Shower wallShower wall
Mud Ring goes
inside wall opening
Finished wall must be flush
with the mud ring.
Power Supply Brick
Item 03-7142
Materials needed:
o ThermaTouch control
oM12 cable
o Silicone
o Power Distribution Module (PDM)
o Mud Ring
o Ethernet Cable with RJ-45 Connector (not supplied)
o Other materials as required
Back of Control
REMINDER
in order to receive software updates the unit must be plugged into
the internet using an Ethernet Cable connected to a Router
(Router and Ethernet Cable not supplied).
Power/Data
M12 connection
Audio Out
Plug in network cable RJ-45
for updates over the internet
Bluetooth
Antenna
THERMASOL.COM I800.776.0711
Wellness Steam Package
44

THERMASOL.COM I800.776.0711
Shower wall Route the M12 cable through the finished wall
to the back side of the control. (The other end
of the cable runs to the PDM location.) NOTE:
It is recommended to run the cable through
electrical conduit. DO NOT STAPLE the cable!
Run the M12 cable so the 90-degree end
connection will connect to the ThermaTouch
control. Then connect the M12 Cable to
ThermaTouch control. Do not over tighten.
If the Serenity Light, Sound, Rain Head option is
not used then amplified speakers are required
for sound.
Connect the data cable to Power Distribution Module (PDM).
(The other end of the cable runs to the back of the control in the shower location.)
DO NOT pinch, nail, staple, wedge, or bind the
data cable.
DO NOT wrap the data cable around steam line
or route it in a manner so that the hot steam line
could melt
the cable.
Any damage to the control cable will result in
the control not working properly.
Carefully connect the data cable to the PDM
and control BEFORE turning power on to the
generator or PDM.
"ON"
Turn Clockwise
"OFF"
Turn Counter Clockwise
• Do not staple, strain or damage data cable
• Align pins to receptacle visually before tightening
• Do not force plug
• Hand tighten only
Connector
Detail
Contact
pins
TTC
SLS
Connect to PDM
PDM requires 110V power
Contact
pins
Cable
ends
3.5mm male audio cable
(not included unless Serenitiy Light,
Sound, Rain Head was purchased)
M12 Cable
Ethernet cable with RJ-45
(not included)
4Control Installation and Data Cable Connection
Wellness Steam Package
5

Side View of Surface
Mount Control
Back Side of Surface
Mount Control
M12 Cable
Ethernet
Audio
THERMASOL.COM I800.776.0711
THESE STEPS MUST BE TAKEN FOR CORRECT INSTALLATION OF THE CONTROL. REMOVE MUD RING
FROM WALL CUTOUT BEFORE MAKING FINAL CABLE CONNECTIONS TO THE THERMATOUCH CONTROL.
TEST THAT ALL CONNECTIONS ARE WORKING BEFORE SEALING THE CONTROL TO THE WALL.
(Power on the control and see that it lights up).
Coat the entire groove on the control back with supplied waterproof silicone to fully seal the control to the wall.
Completely seal the control to the wall so moisture does not collect behind it.
Place the control on the wall pressing firmly.
(You may need to tape the control into place until the silicone dries.)
Be careful not to harm the wall or control with the tape. Let dry for 24 hours before using steam bath.
A
5Sealing Control
A
66
Wellness Steam Package

TTC
SLS
TTC
SLS
110v
110v
M12 Cable
Audio Cable
M12 Cable
M8 Cable
M12 Cable
6a Connecting ThermaTouch to Generator
6b Connecting ThermaTouch to Serenity Light,
Sound, Rainhead
THERMASOL.COM I800.776.0711 7
Wellness Steam Package

6c Connecting ThermaTouch to Digital Shower
6b Connecting Total Wellness Package
THERMASOL.COM I800.776.0711
TTC
SLS
110v
M12 Cable
M12 Cable
Audio Cable
TTC
SLS
110v
M12 Cable
M12 Cable
Audio Cable
M8 Cable
88
Wellness Steam Package

Now you will need to decide on the steamhead placement in the shower so you can run the steam line from the generator to the
steamhead. There are a couple of things you need to know about the placement of the steamhead and steam line itself.
24"
6"
B
7Steam Line and Steamhead
A
C
Steam Line
Shown installed
in attic
DO NOT install any valve in the steam line. Flow of steam must
be unobstructed.
DO NOT plumb any traps in the steam line.
The steam outlet on the generator requires a 1/2" brass
union for easy installation (not included).
Use 1/2” brass pipe or copper tubing from unit to
steamhead rough-in fitting as permitted by code.
A
B
The steam line can run up and then down, once; or horizontal;
but never run down and then up. If it does, a steam trap will
be produced at the low point blocking the flow of steam.
Insulate the steam outlet piping if the piping run exceeds 10 feet or
is exposed to cold areas. Use steam rated insulation.
Pitch/angle steam lines back towards generator before any up or
down turns; pitch/angle towards steam room after any up or down
and avoid perfectly level plumbed lines.
THERMASOL.COM I800.776.0711 9
Wellness Steam Package

Steamhead Location
Steamhead rough-in fitting
to be installed flush and
sealed to finished wall
C
CInsert protective cap
into housing
Insert installation tool and
tighten housing into place
with a 1" socket and driver
DO NOT install the steamhead near the seating area or the user.
DO NOT forget to install the steamhead rough-in fitting!
Install the steamhead 24" from the floor or bathtub rim
and 6" from any corner.
Steamhead is to be mounted as far as possible from
typical bathing position (seated or standing) and installed
as far from the in-shower controller as possible.
For retrofit to existing finish wall:
Drill a 1-1/8" diameter hole in the shower wall or wall above
bathtub rim for the steam outlet rough-in fitting and install
to be flush with the finished wall. this housing must be
sealed to the wall to not allow vapor or water behind it.
(plumbing must be done from backside of
finshed space)
For new framing: Mount and install rough-in fitting to be
flush with finished wall.
Connect a 1/2" NPT brass pipe or copper tubing to
the steam outlet union (not included) on the generator
running the pipe to the steam head location in the wall
to connect with the steamhead rough-in fitting. It is very
important that the pipe is firmly secured to the wall, so
that when the steamhead is installed it doesn’t push the
rough-in fitting back into the wall. Install a 1/2” dropear
elbow on the end of the 1/2” pipe or tubing for the
rough-in fitting.
Use the installation tool to tighten the housing in place
with a 1" socket and driver. Then insert the protective cap
into the housing.
For all the connections, use solder for copper joints and
Teflon tape for pipe fittings and do not over tighten fittings.
DO NOT USE PVC CEMENT.
THERMASOL.COM I800.776.0711
1010
Wellness Steam Package

D
D
Remove protective
cap from housing
Insert steamhead
into housing
Use the supplied
silicone to adhere
the steamhead to
the wall
Turn ON the water supply to the generator. Check all the connections for leaks.
Plug in generator (unless hardwired model).
Turn ON the power source or breaker.
Verify control panel lights up and test operation. Note: Initial power-on phase takes several minutes for generator to
heat up steam.
Please direct the home owner to visit www.thermasol.com/solution and click on the “I’m the home owner” button to
learn about set-up and programing (in order to set up the clock and any other options if applicable).
8Final Pre-Check Before Operation
Upon final installation mount steamhead with facing up
to allow aromatherapy well to dispense steam.
For detailed installation instructions of the steamhead please
see Installation section in thermasol.com/customer-support
Apply a small amount of
supplied lubricant directly
on the o-rings.
Once the shower wall is complete and the housing
is sealed to the wall, remove the protective cap and
insert the steamhead into housing. Use the supplied
silicone to adherethe steamhead to the wall sealing
out any water from getting behind the head.
Use supplied o-ring lubricant to assist in steam head
installation. A very small amount is all that is need directly
on the o-rings.
Allow 24 hours for silicone to dry before use.
THERMASOL.COM I800.776.0711 11
Wellness Steam Package

OVER 60 YEARS OF STEAM SHOWER INNOVATION
Installation Manual
For Tutorials and Troubleshooting visit www.thermasol.com/solutions
HVLSRSQ-XX
HydroVive

PLEASE REVIEW WARNINGS BELOW AND LEAVE THIS MANUAL WITH HOMEOWNER
DO NOT USE THIS PRODUCT UNLESS YOU HAVE CONSULTED WITH YOUR DOCTOR AND RECEIVED WRITTEN PERMISSION TO DO SO. USE OF
THIS PRODUCT MAY BE HAZARDOUS TO YOUR HEALTH.
PLEASE CONSULT YOUR PHYSICIAN BEFORE USING. IF YOU ARE PREGNANT, ELDERLY, HAVE HIGH BLOOD PRESSURE, DIABETES, SUFFERING
FROM HEART DISEASE, ARE INTOXICATED, OR NOT IN GOOD HEALTH, DO NOT USE THIS STEAM BATH.
STEAM IS HOT! DO NOT TOUCH OR GO NEAR THE STEAMHEAD FROM THE TIME THE UNIT IS “ON,” UP TO ONE HOUR AFTER IT HAS SHUT OFF.
SEVERE BURNS WILL OCCUR IF YOU COME IN CONTACT WITH THE STEAMHEAD OR STEAM EMITTING FROM THE STEAMHEAD.
NEVER ATTEMPT TO FILL AROMA RESERVOIR ON THE STEAMHEAD WHEN UNIT IS IN THE "ON" POSITION. SEVERE BURNS WILL OCCUR.
DO NOT USE THERMASOL AROMATHERAPY OILS, SKIN CARE PRODUCTS OR ANY PRODUCT ASSOCIATED WITH YOUR THERMASOL UNIT
WITHOUT CONSULTING WITH YOUR ALLERGIST OR DOCTOR BEFORE USE. THESE PRODUCTS MAY BE HAZARDOUS TO YOUR HEALTH.
DO NOT USE STEAM ROOM WHILE UNDER THE INFLUENCE OF ALCOHOL OR DRUGS, AS THIS CAN BE HAZARDOUS TO YOUR HEALTH.
YOUR SHOWER MAY BE A SLIP-AND-FALL HAZARD. CHECK WITH YOUR CONTRACTOR OR FLOORING MANUFACTURER REGARDING THE SAFE
USE OF YOUR FLOORING IN A STEAM APPLICATION. SLIPPING AND FALLING INTO THE STEAMHEAD ITSELF OR INTO THE STREAM OF STEAM
EMITTING FROM THE STEAMHEAD WILL CAUSE SERIOUS BURNS OR PHYSICAL INJURY.
IF YOU ARE FEELING UNCOMFORTABLE, DIZZY, FAINT, OR STARTING TO FALL ASLEEP, IMMEDIATELY EXIT THE STEAM ROOM.
DO NOT USE STEAM ROOM IF YOU ARE UNDER THE AGE OF 16 UNLESS SUPERVISED BY AN ADULT.
THERMASOL STEAM BATH GENERATORS ARE NOT DESIGNED TO BE USED FOR SPACE HEATING PURPOSES.
THERMASOL STEAM BATH GENERATORS ARE FOR INDOOR USE ONLY. THEY SHOULD NEVER BE LOCATED OUTSIDE THE HOME.
ALL PRODUCTS MUST BE INSTALLED IN ACCORDANCE WITH INSTALLATION INSTRUCTIONS PROVIDED. FAILURE TO DO SO MAY INVALIDATE
WARRANTY AT MANUFACTURER’S DISCRETION. ©2021 THERMASOL.
Important Information Before You Install1
THERMASOL.COM I800.776.0711 13
Wellness Steam Package

Tools and Materials
2
Parts Enclosed:
Silicone 25' Yellow M12 Cable
Item 03-7149-25
Wood Screw
#10 x 3.5" x 4
Installation instructions
Materials needed:
oPDM (Item 10-8147)
oCompatible controller
oDrill
oTile Cutter
oPly Wood Backing Board
o36" long 3/8" Compression Flexible Water Line
oSeparate water volume control diverter
with shut off valve
(Fig. 1) Installation Profile View
Compatible Controls:
ThermaTouch 7" and 10"
HydroVive Light, Sound,
Rain Head fixture and hardware
Item HVLSRSQ-XX
Joist Mounting Bracket +
4x #4 Flat Head Screw
Plywood
Waterproof
Backing
Mortar
Finished
Shower Surface
RTV Silicone Sealant
#10 Flat Head Screw
O-Ring (-016)
Screw Cover
25' Audio Cable
Item 03-7140
THERMASOL.COM I800.776.0711
1414
Wellness Steam Package

Placement and Cutout3
Cut a 16.7" square out of your ceiling and frame it in.
Once framed in, you’ll want a minimum clearance of 14.45" x
14.25" for comfortable installation. Framing studs should be
on 16" Centers.
Put all your connections through the hole as the rest of the
installation will be completed from inside the shower.
NOTE: HydroVive weighs 37 lbs. It must be mounted to a framed
structure that can support its weight. 16.7"
16.7" 14.5"
14.25"14.25"
Cutout Sizing
PDM Sold and ships
with ThermaTouch control
ThermaTouch Control
sold separately
25'Yellow M12 Cable
Item 03-7149-25 ships
with ThermaTouch control
Digital Shower Valve
By adding the Digital Shower
Valve, you replace multiple
manual valves and can control
all shower functions through a
single ThermaTouch Control.
25'Audio Cable
Item 03-7140
25' Yellow M12 Cable
Item 03-7149-25
THERMASOL.COM I800.776.0711 15
Wellness Steam Package

Mounting Brackets4
Measure and locate the midpoints on each 14.25" side of the cutout.
The midpoints are where you’ll install the mounting brackets, each
mounting bracket will require 4–3/4" (included) wood screws.
WARNING: READ BEFORE PROCEEDING:
The HydroVive weighs 37 lbs. and overhead lifting is required to
continue installation. Please be cautious and practice ladder safety.
Connecting HydroVive5
NOTE: Make sure electrical power is off to all ThermaSol devices prior
to making any connections.
Align the notches at the top of the mounting guides with the mounting
brackets and slip them over to firmly secure the HydroVive in place
while the connections are made. With HydroVive secured on the
mounting brackets, angle the unit to gain access and connect all
cables.
Double check to ensure that all connections are correct before moving
forward.
Connect both the M12 power/data cable from the
rainhead and the M12 cable from ThermaTouch
to the PDM
Plug the PDM into a standard 110VAC outlet, test
at the control that all functions are working prior to
moving forward.
Need Assistance?: Contact us at 800.776.0711
Connecting to Power Distribution Module (PDM)
6
THERMASOL.COM I800.776.0711
1616
Wellness Steam Package

Complete Installation9
Install the Screw Covers with O-Rings by hand.
Allow the silicone to dry for 24 hours before use.
Move Into Place8
Guide the HydroVive into the ceiling and rest it on the highest
hook you can reach. Use the 3.5" included mounting screws, and
gradually insert them a little at a time to evenly lift the HydroVive into
position to create a seal with the previously applied silicone. DO
NOT OVERTIGHTEN! Once the HydroVive is in position and the
silicone seal is created, no further clamping force is necessary.
Sealing HydroVive7
Apply silicone along the groove on the back of HydroVive.
THERMASOL.COM I800.776.0711 17
Wellness Steam Package

ThermaSol Product Registration
Dear ThermaSol End User:
Please register your product at www.thermasol.com/warranty so we can assist you much quicker if you ever need to
contact our Technical Support Department.
In addition we’ll keep you informed about your product and time to time we’ll update you about new products and other
company announcements.
Thank you from all of us at ThermaSol and we wish you many relaxing and steamy days ahead.
We will not sell, rent or share your personal information.
1958 Steam Way
Round Rock, TX 78665
Wellness Steam Package
THERMASOL.COM I800.776.0711
1818

THERMASOL.COM I800.776.0711 19
THIS PAGE INTENTIONALLY LEFT BLANK

1958 STEAM WAY ROUND ROCK, TX 78665
PHONE: [phone] | FAX: [phone] | WWW.THERMASOL.COM 81240_NC
