thermastor Santa-Fe Crawl Space Alert User manual

Crawl Space Alert Installation
For small usage:
4201 Lien Rd., Madison, WI 53704 •TOLL-FREE 1-800-533-7533 •www.thermastor.com •[e-mail]
TS-647 06/10
Functionality
Crawl Space Alert
The amber colored warning-lamp will glow when the crawl space humidity is out of control. The
homeowner must be instructed to check this lamp periodically and to give their contractor a call if this
lamp turns on.
Dehumidifier safety shutoff (connection and use of this feature are optional)
If water in the condensate pump reservoir rises to the point of triggering the top level overflow switch,
power to the dehumidifier will turn off. This can help avoid creating a large puddle of water if the
condensate pump motor fails or the discharge hose becomes blocked.
Installation
1. Mounting
Mount the Crawl Space Alert at least 24" above ground. Avoid mounting to an exterior wall. Exterior
walls are likely to interfere with the operation of the Crawl Space Alert due to the influence of outdoor
temperatures.
2. Enable overflow shutoff (connection and use of this feature are optional)
Route the gray 2-wire cable (8ft available) to the condensate pump. Connect one wire to one terminal of
the overflow switch and the remaining wire to the other terminal. Although one wire is red and the other
black, the two are interchangeable. This connection is typically accomplished using wire nuts. Plug the
dehumidifier (max of 12amps) and condensate pump into the outlets located on the side of your Crawl
Space Alert.
To confirm functionality of the overflow shutoff: While the dehumidifier is operating, lift up on the safety
float switch or turn the pump up side down. If everything is working properly, the dehumidifier will turn
off.
If the operation is backwards (dehumidifier turns on when the safety float switch trips), then the pump
switch terminals will need to be swapped. Most pump switches have three terminals yet only connect
wires to two. One of your wires was probably connected to the Normally Open terminal. You must
change it to the Normally Closed terminal. Check the functionality again.
3. Powering up
Plug the Crawl Space Alert power cord (8ft available) into a dedicated 15 amp GFCI outlet.
4. Warning lamp install
Consider who will check for warnings and locate it at a good viewing angle. Select the location for the
warning lamp (40ft of wire is available). The mounting plate provided can be flush mounted or bracket
mounted.
Flush mount: Flex the tab until it breaks away from the plate. Drill a 1/2"
diameter installation hole. Insert lamp through the hole. Slide mounting plate
over wires, centering the lamp in the plate. Fix the plate to the surface using
adhesive or a screw.
Bracket mount: Bend mounting tab to the desired angle for mounting with a
screw.
Anchor the wire along its length. Bundle and secure any extra wire, out of harms way.
5. Installation verification
Be sure to confirm that the installation is in good working condition and operates as desired.
To reduce the risk of electric shock, this product has a grounding type plug that has a third (grounding)
pin. This plug will only fit into a grounding type power outlet. If the plug does not fit into the outlet,
contact a qualified electrician to install the proper outlet. Do not change the plug in any way.

WARRANTOR:
Therma-Stor LLC
4201 Lien Rd
Madison, WI 53704
Telephone: [phone]
WHO IS COVERED: This warranty extends only to the
original residential end-user of the Santa Fe Crawl
Space Alert, and may not be assigned or transferred.
FIRST YEAR WARRANTY: Therma-Stor LLC warrants
that, for one (1) year the Santa Fe Crawl Space Alert
will operate free from any defects in materials and
workmanship, or Therma-Stor LLC will, at its option,
repair or replace the defective part(s), free of any
charge.
END-USER RESPONSIBILITIES: Warranty service must
be performed by a Servicer authorized by Therma-
Stor LLC. If the end-user is unable to locate or obtain
warranty service from an authorized Servicer, he should
call Therma-Stor LLC at the above number and ask for
the Therma-Stor LLC Service Department, which will
then arrange for covered warranty service. Warranty
service will be performed during normal working hours.
The End-user must present proof of purchase (lease)
upon request, by use of the warranty card or other
reasonable and reliable means. The end-user is
responsible for normal care. This warranty only applies
to residential applications and does not cover any
defect, malfunction, etc. resulting from misuse, abuse,
lack of normal care, corrosion, freezing, tampering,
modification, unauthorized or improper repair or
installation, accident, acts of nature or any other cause
beyond Therma-Stor LLC's reasonable control.
LIMITATIONS AND EXCLUSIONS: If any Santa Fe Crawl
Space Alert part is repaired or replaced, the new part
shall be warranted for only the remainder of the original
warranty period applicable thereto (but all warranty
periods will be extended by the period of time, if any,
that the Santa Fe Crawl Space Alert is out of service
while awaiting covered warranty service).
UPON THE EXPIRATION OF THE WRITTEN WARRANTY
APPLICABLE TO THE Santa Fe Crawl Space Alert OR
ANY PART THEREOF, ALL OTHER WARRANTIES IMPLIED
BY LAW, INCLUDING MERCHANTABILITY AND FITNESS
FOR A PARTICULAR PURPOSE, SHALL ALSO EXPIRE.
ALL WARRANTIES MADE BY THERMA-STOR LLC ARE
SET FORTH HEREIN, AND NO CLAIM MAY BE MADE
AGAINST THERMA-STOR LLC BASED ON ANY ORAL
WARRANTY. IN NO EVENT SHALL THERMA-STOR LLC,
IN CONNECTION WITH THE SALE, INSTALLATION, USE,
REPAIR OR REPLACEMENT OF ANY Santa Fe Crawl
Space Alert OR PART THEREOF BE LIABLE UNDER
ANY LEGAL THEORY FOR ANY SPECIAL, INDIRECT OR
CONSEQUENTIAL DAMAGES INCLUDING WITHOUT
LIMITATION WATER DAMAGE (THE END-USER SHOULD
TAKE PRECAUTIONS AGAINST SAME), LOST PROFITS,
DELAY, OR LOSS OF USE OR DAMAGE TO ANY REAL OR
PERSONAL PROPERTY.
Some states do not allow limitations on how long an
implied warranty lasts, and some do not allow the
exclusion or limitation of incidental or consequential
damages, so one or both of these limitation may not
apply to you.
LEGAL RIGHTS: This warranty gives you specific legal
rights, and you may also have other rights which vary
from state to state.
