THERMOROSSI Mon Amour Installation and operating instructions

Page
2
Installation, use and maintenance guide
Mon Amour
INDEX
1 - INTRODUCTION .................................................................................................................................. 7
1.1 GENERAL GUIDELINES..................................................................................................................................7
1.2 SAFETY GUIDELINES .....................................................................................................................................7
1.3 RECOMMENDATIONS.....................................................................................................................................7
1.4 GENERAL GUIDELINES..................................................................................................................................9
1.5 TRANSPORTATION AND STORAGE..............................................................................................................9
2 – TECHNICAL CHARACTERISTICS*...................................................................................................10
3 – GENERAL DESCRIPTION.................................................................................................................11
3.1 OPERATING TECHNOLOGY.........................................................................................................................11
3.2 THE PELLET...................................................................................................................................................11
3.3 THE FEEDBOX...............................................................................................................................................11
4 - INSTALLATION ..............................................................................................................................12
4.1 APPLIANCE LOCATION.................................................................................................................................12
4.2 MOUNTING THE CASING..............................................................................................................................13
5 – DESCRIPTION OF THE CONTROLS .........................................................................................14
5.1 DESCRIPTION OF THE CONTROL PANEL..................................................................................................14
5.2 DESCRIPTION OF THE POWER PANEL......................................................................................................15
5.3 DATE/TIME: SETTING THE DATE AND TIME ..............................................................................................16
5.4 CHRONO: ON/OFF PROGRAMMING............................................................................................................16
5.5 LEVEL: OPERATING LEVEL SETTING.........................................................................................................18
5.6 THERMOCOMFORT: ACTIVATING THE CONNECTION WITH THE HANDHELD RADIO CONTROL
(OPTIONAL)..................................................................................................................................................19
6 - OPERATION OF THE HANDHELD RADIO CONTROL THERMOCOMFORT (OPTIONAL) ..............20
6.1 INDICATORS OF THE HANDHELD RADIO CONTROL................................................................................20
6.2 USE OF THE HANDHELD RADIO CONTROL...............................................................................................21
7 – USE OF THE APPLIANCE.................................................................................................................25
7.1 DESCRIPTION OF THE OPERATING STAGES ...........................................................................................25
7.2 SWITCHING ON THE STOVE........................................................................................................................25
7.3 COMBUSTION AND VENTILATION ADJUSTMENTS...................................................................................25
7.4 INFRARED REMOTE CONTROL...................................................................................................................25
8 – ROOM TEMPERATURE THERMOSTAT / CHRONOTHERMOSTAT (not supplied)........................26
8.1 OPERATING WITH THE ADDITIONAL ROOM TEMPERATURE THERMOSTAT (NOT SUPPLIED) .........26
8.2 OPERATING WITH THE ADDITIONAL CHRONOTHERMOSTAT (NOT SUPPLIED)..................................26
9 CLEANING AND MAINTENANCE ........................................................................................................28
9.1 FOREWORD...................................................................................................................................................28
9.2 CLEANING AND MAINTENANCE..................................................................................................................28
9.3 REPLACING THE BATTERY OF THE REMOTE CONTROL........................................................................30
9.4 REPLACING THE BATTERY OF THE CONTROL PANEL............................................................................30
10 – SMOKE DISCHARGE TUBE AND VENTILATION OF THE ROOMS...............................................31
10.1 FOREWORD.................................................................................................................................................31
10.2 ROOM VENTILATION ..................................................................................................................................31
10.2.2 VENTILATION OF THE ADJOINING ROOMS ......................................................................................................................31

I
Page
3
installation, use and maintenance guide
Mon Amour
10.2.1 SINGLE OR MULTIPLE VENTILATION DUCTING...............................................................................................................31
10.3 SMOKE OUTLET.......................................................................................................................................... 31
10.3.1 FLUE OUTLET / FLUE SYSTEM COMPONENTS................................................................................................................ 32
10.3.3 CONTROLS PRIOR TO INSTALLING THE APPLIANCE...................................................................................................... 33
11 – ALARMS..........................................................................................................................................34
12 – ELECTRONIC BOARD LAYOUT.....................................................................................................35
13 - INFORMATION FOR THE SKILLED TECHNICIAN..........................................................................37
13.1 MAIN COMPONENTS AND THEIR POSITION ........................................................................................... 37
13.2 GUIDELINES FOR CORRECT INSTALLATION.......................................................................................... 37
13.3 TROUBLESHOOTING CAUSES-SOLUTION .............................................................................................. 38
14 – SPARE PARTS FOR MON AMOUR MODEL ..................................................................................40
14.1 MAIN COMPONENTS AND THEIR POSITION 1 ........................................................................................ 40
14.2 MAIN COMPONENTS AND THEIR POSITION 2/3 ..................................................................................... 41
14.3 MAIN COMPONENTS AND THEIR POSITION 3/3 ..................................................................................... 42
14.4 Key to figures................................................................................................................................................ 43

Page
4
Installation, use and maintenance guide
Mon Amour
DICHIARAZIONE DI CONFORMITA'
DECLARATION OF CONFORMITY
La THERMOROSSI S.P.A., VIA GRUMOLO N° 4 36011 ARSIERO (VI), sotto la sua esclusiva responsabilità
DICHIARA che l’apparecchiatura descritta in appresso:
DECLARES that the product:
Descrizione Stufa a pellet
Description Pellet stove
Marchio THERMOROSSI S.P.A.
Trademark
Modello MON AMOUR
Model
è conforme alle disposizioni legislative che traspongono le seguenti Direttive:
•2004/108/CE (Direttiva EMC)
•2006/95/CE (Direttiva Bassa Tensione)
•2011/65/EU (Direttiva RoHS 2)
is in accordance with the following Directives:
•2004/108/EC Directive (EMC Directive)
•2006/95/EC Directive (Low Voltage Directive)
•2011/65/EU Directive (RoHS 2)
e che sono state applicate tutte le norme e/o specifiche tecniche di seguito indicate
and that all the following standards have been applied
EN 55014-1 EN 60335-1 EN 50581
EN 55014-2 EN 60335-2-102
EN 61000-3-2 EN 62233
EN 6100-3-3
Ultime due cifre dell’anno in cui è affissa la marcatura CE 14
Last two figures of the year of the CE marking
Luogo Arsiero
Place
Data 24/06/2014
Date
Firma
Sign.

I
Page
5
installation, use and maintenance guide
Mon Amour
DICHIARAZIONE DI PRESTAZIONE
DECLARATION OF PERFORMANCE
Dichiarazione di prestazione in accordo con il Regolamento (UE) 305/2011
Declaration of performance according to Regulation (EU) 305/2011
N° 56
1
Codice di identificazione unico del prodotto-tipo:
Unique identification code of the product type:
MON AMOUR, apparecchio per il riscaldamento domestico, senza acqua, alimentato a pellet
di legno
MON AMOUR, residential space heating appliance without water fired by wood pellets
EN 14785:2006
2
Numero di tipo, lotto , serie o qualsiasi altro elemento che consenta l'identificazione del
prodotto da costruzione ai sensi dell'articolo 11, paragrafo 4:
Type, batch or serial number or any other element allowing identification of the construction
product as required under Article 11( 4):
MON AMOUR
3
Uso o usi previsti del prodotto da costruzione, conformemente alla relativa specifica tecnica
armonizzata, come previsto dal fabbricante:
Intended use or uses of the construction product, in accordance with the applicable harmonised
technical specification, as foreseen by the manufacturer:
Apparecchio per il riscaldamento domestico, senza acqua, alimentato a pellet di legno
Residential space heating appliance without water fired by wood pellets
4
Nome, denominazione commerciale registrata o marchio registrato e indirizzo del fabbricante ai
sensi dell'articolo 11, paragrafo 5:
Name, registered trade name or registered trade mark and contact address of the manufacturer
as required pursuant Article 11( 5):
THERMOROSSI S.P.A. Via Grumolo, n° 4 36011 Arsiero (VI)
5
Sistema o sistemi di valutazione e verifica della costanza della prestazione del prodotto da
costruzione di cui all'allegato V:
System or systems of assessment and verification of constancy of performance of the
construction product as set out in Annex V:
Sistema 3 e 4 / System 3 and 4

Page
6
Installation, use and maintenance guide
Mon Amour
6
Nel caso di una dichiarazione di prestazione relativa ad un prodotto da costruzione che rientra
nell'ambito di applicazione di una norma armonizzata:
In case of the declaration of performance concerning a construction product covered by a
harmonised standard:
L' organismo notificato TÜV Rheinland Energie und Umwelt GmbH N° 2456 ha determinato
il prodotto-tipo in base a prove di tipo secondo il sistema 3 ed ha rilasciato il rapporto di prova
K13532014Z1
The notified laboratory TÜV Rheinland Energie und Umwelt GmbH N° 2456 performed the
determination of the product type on the basis of type testing under system 3 and issued test
report K13532014Z1
7
Prestazione dichiarata / Declared performance
Specifica tecnica armonizzata:
Harmonized technical specification:
EN 14785:2006
Caratteristiche Essenziali
Essential characteristics Prestazione / Performance
Sicurezza antincendio / Fire safety
Reazione al fuoco / Reaction to fire A1
Distanza da materiali combustibili
Distance to combustible materials
Minime distanze / Minimum distances (mm):
posteriore / rear = 200
lati / sides = 200
frontale / front = 800
soffitto / ceiling = -
pavimento / floor = -
Rischio di fuoriuscita di braci incandescenti
Risk of burning fuel falling out Passa / Pass
Emissione di prodotti della combustione
Emission of combustion products
CO 106,8 mg/m3 Alla potenza termica nominale / Nominal heat
output
CO 553,2 mg/m3 Alla potenza termica ridotta / Reduced heat
output
Temperatura superficiale / Surface temperature Passa / Pass
Sicurezza elettrica / Electrical safety Passa / Pass
Pulizia / Cleanability Passa / Pass
Pressione massima di esercizio
Maximum operating pressure -- bar
Temperatura fumi a potenza termica nominale
Flue gas temperature at nominal heat output T 178 °C
Resistenza meccanica (per sopportare un
camino/una canna fumaria)
Mechanical resistance(to carry a chimney/flue) NPD {No Performance Determined}
Potenza termica nominale / Nominal heat output 6,74 kW
Potenza termica resa in ambiente / Room heating output 6,74 kW
Potenza termica ceduta all’acqua / Water heating output - - kW
Rendimento
Efficiency 87,63 % Alla potenza termica nominale / Nominal heat output
89,50 % Alla potenza termica ridotta / Reduced heat output
8
La prestazione del prodotto di cui ai punti 1 e 2 è conforme alla prestazione dichiarata di cui al
punto 7. Si rilascia la presente dichiarazione di prestazione sotto la responsabilità esclusiva del
fabbricante di cui al punto 4
The performance of the product identified in points 1 and 2 is in conformity with the declared
performance in point 7. This declaration of performance is issued under the sole responsibility
of the manufacturer identified in point 4

I
Page
7
installation, use and maintenance guide
Mon Amour
Firmato a nome e per conto del fabbricante da (nome e funzione)
Signed for and on behalf of the manufacturer (name and title)
Luogo/Place Data/Date
Arsiero 24/06/2014
1 - INTRODUCTION
1.1 GENERAL GUIDELINES
This installation, use and maintenance guide is an integral and essential part of the product and must be kept by the user. Before
commencing with the installation, use and maintenance of the product, carefully read this guide. All local, national and European
regulations regarding the installation and use of the appliance must be met. The Manufacturer recommends carrying out all the
maintenance operations described in this manual.
This appliance must only be used as intended by the manufacturer. Any other use is considered incorrect and therefore hazardous;
consequently, the user shall be totally liable for the product if used improperly. Installation, maintenance and repairs must be carried
out by professionally qualified personnel, certified according to Decree no. 37 of 22 January 2008 and in compliance with current
regulations. In case of repairs only original spare parts supplied by the manufacturer must be used. Incorrect installation or poor
maintenance can injure or damage people, animals or things; in this case the manufacturer shall be relieved of all responsibility.
Before beginning any cleaning or maintenance operation switch off the appliance by means of the 0/I switch located on the power
panel and disconnect the plug from the electrical power socket. The product must be installed in locations suitable for fire-fighting and
furnished with all the services which the appliance requires for a correct and safe operation. Any repairs or actions carried out on any
systems, components or internal parts of the appliance, or on any of the accessories supplied with it, that are not specifically
authorised by Thermorossi S.p.A, will automatically void the warranty and the manufacturer's responsibility, pursuant to D.P.R. 224
of 24/05/1988, art. 6/b.
It is recommended to keep this manual in a safe place that is easily accessible to all users; if the manual is lost or deteriorated contact
the authorized dealer for a replacement copy. If the appliance is sold or transferred to another user ensure that the manual is handed
over with it.
Thermorossi S.p.A. retains copyright on this manual. These instructions may not be reproduced or communicated to third parties or
used in any other way without the necessary authorisation.
1.2 SAFETY GUIDELINES
PERSONAL INJURY
This safety symbol identifies important messages throughout the manual. Read the information marked
by this symbol carefully as non-observance of this message can cause serious injury to persons using
the appliance.
DAMAGE TO PROPERTY
This safety symbol identifies messages or instructions that are fundamental for the generator to function
well. To avoid serious damage to the appliance adhere strictly to these instructions.
INFORMATION
This symbol indicates important instructions for good functioning of the generator. If this information
is not correctly observed, the performance of the appliance will not be satisfactory.
1.3 RECOMMENDATIONS

Page
8
Installation, use and maintenance guide
Mon Amour
Before using the appliance, carefully read every section of this installation, use and maintenance guide as knowledge
of the information and the regulations contained in it are essential for a correct use of the appliance.
The entire operation concerning the connection of the electric panel must be carried out by expert personnel; no
responsibility will be accepted for damages, even to third parties, if the instructions for installation, use and maintenance
of the appliance are not followed scrupulously. Modifications made to the appliance by the user or on his behalf, must
be considered to be under his complete responsibility. The user is responsible for all the operations required for the
maintenance of the appliance before and during its use.

I
Page
9
installation, use and maintenance guide
Mon Amour
1.4 GENERAL GUIDELINES
Caution: the appliance must be connected to a system provided with a PE conductor (in compliance with the
specifications of 2006/95/EC, concerning low voltage equipment). Before installing the appliance check the efficiency
of the earth circuit of the power supply system.
Caution: the power supply line must have a section which is suitable for the power of the equipment. The cable section must in any
case be no less than 1.5 mm². The appliance requires powering with a voltage of 230V and 50 Hz. Voltage variations greater than
10% of the nominal value can cause irregular operation or damage the electrical device.
Position the appliance so that the electric power outlet in the room is easily accessible. Ensure that a suitable differential switch is
installed upstream from the equipment.
Your appliance has obtained the CE marking and has been made to run for 1 hour to check that it functions correctly.
The product must not be used by children, by persons with physical or mental impairments, by persons who are not familiar with the
instructions for use and maintenance of the product (the instructions are found in this booklet).
CAUTION: Before every use make sure that the burner is clean and positioned correctly in its seat, and check that the ash pan is
clean, check that the firebox door is closed.
CAUTION: the door must always remain shut tight when the stove is operating. It is strictly forbidden to open the door while the
appliance is in operation. While the appliance is in operation the smoke exhaust pipes and some parts of the appliance itself can
reach extremely high temperatures: do not touch them! Do not expose your body to hot air for long, do not overheat the room in which
the appliance is installed, as these actions could cause health problems. Do not expose plants or animals directly to the hot air flow
as this could have noxious effects on them. It is strictly prohibited to use any type of fuel (liquid, solid...) to light up the appliance:
lighting must occur automatically as intended and described in this installation, use and maintenance booklet; consequently, it is also
strictly forbidden to feed pellets (or any other material) into the brazier. Do not place non-heat resistant or inflammable or combustible
objects in the vicinity of the appliance: keep them at a suitable distance. Do not place wet clothing to dry on the appliance. When
using a clothes horse, keep at a suitable distance. It is strictly prohibited to disconnect the appliance from the electrical mains during
any of the appliance’s operating stages.
Warning: do not wet the appliance and do not touch the electrical parts with wet hands. Never vacuum hot ash: this
could damage the vacuum device. All the cleaning operations described in this manual must be carried out when the
appliance is cold.
Caution! Warning for Swiss users
Refer to the local cantonal regulations imposed by the Fire Department (Mandatory signalling and safety distances )
and the Note concerning installation of heaters issued by the Association of Cantonal Fire Agencies (VKF - AEAI).
CAUTION: it is mandatory to earth the appliance. If this instruction is not observed serious damage, which is not
covered by warranty, will result to the body of the appliance. Have an electrician check the earthing. There must be no
electric potential (Volt) between the earth of the generator and the actual earth of the plant.
1.5 TRANSPORTATION AND STORAGE
TRANSPORTATION AND HANDLING
The appliance body must always be in a vertical position when handled and exclusively by means of trolleys. Take special care to
protect the electric panel, the glass, and all the fragile parts from mechanical impact which could damage them and their correct
functioning.
STORAGE
The appliance must be stored in a humid-free environment and sheltered from the weather; avoid placing the appliance directly on
the ground. The Company denies all responsibility for damage caused to wood floors or floors made from any other material.
It is inadvisable to store the product for long periods of time.

Page
10
Installation, use and maintenance guide
Mon Amour
972
418
968
426 8
241
418
487
487
O
80
2 – TECHNICAL CHARACTERISTICS*
* All the data are based on the appliance fuelled
with EN 14961 standard type-approved pellets.
** Important: take into consideration the fact
that the heatable volume is greatly influenced
by the insulation of the house, i.e. the energy
class of the building and by the position of the
appliance in the planimetry of the house. The
indicated values, therefore, can vary
considerably.
MON AMOUR
Height (mm) 972
Depth (mm) 487
Width (mm) 418
Weight (Kg) 99
Firebox power Min. / M x. (KW) 3.15 / 7.69
R ted power Min. / M x. (KW) 2.82 / 6.74
Min/M x consumption (Kg/h) 0.65 / 1.59
Ø smoke exh ust pipe (mm) 80
Min. dr ught t r ted power (P ) 10
Min. dr ught t reduced power (P ) 10
T nk c p city (Kg) 15
Aver ge smoke temper ture t r ted power (°C) 178
Aver ge smoke temper ture t reduced power (°C) 98.2
Smoke flow t r ted power (g/s) 6.0
Smoke flow t reduced power (g/s) 4.3
Efficiency t r ted power (%) 87.63
Efficiency t reduced power (%) 89.46
CO concentr tion with 13% O2 t r ted power (mg/m3) 106.8
CO concentr tion with 13% O2 t reduced power (mg/m3) 553.2
Power supply volt ge nd frequency 230V 50Hz
M x electric l consumption 1.18 - 271W
Min electric l consumption 0.29A - 66W
He t ble volume (m3) 189**

I
Page
11
installation, use and maintenance guide
Mon Amour
3 – GENERAL DESCRIPTION
3.1 OPERATING TECHNOLOGY
Your appliance has been built to fully satisfy all your heating and practical requirements. Top-grade components and functions
managed with microprocessor technology guarantee high reliability and optimal performance.
3.2 THE PELLET
The appliance is fuelled by pellets, that is, cylinders of compressed sawdust; it his allows you to fully enjoy the heat of the flame
without having to manually stoke the combustion.
The dimensions of the pellets are ø 6 and length from 10 to 20 mm. They have a max moisture content of 8%; a calorific value of
4000/4500 Kcal/kg and density of 620-630 kg/m³, less than 0.7% ash. The pellet must be approved according to UNI EN 14961-2 A1
A2.
It is strictly forbidden to use any pellet type other than that specified above. The use of fuel that does not comply with the
above specifications not only immediately invalidates the warranty for the appliance but can also create dangerous
situations. Do not use the appliance as an incinerator, at the risk of voiding the warranty.
3.3 THE FEEDBOX
The feedbox is situated in the top part of the appliance. The
load capacity specified in the technical data can vary
according to the specific weight of the pellets.
Take special care when loading the pellet tank as the screw
feeder located at the bottom ofthe hopper is in motion. Take
care when topping up with fuel as the loading area can get
very hot.
Only pellets that comply with the specifications listed above
must be fed into the tank; Never insert foreign objects into
the tank.
CAUTION: it is normal to find some pellets remaining in the
tank even if the stove shuts off because the pellets have run
out.
Attention: when loading the pellets into the tank take care
not to drop any in the inner parts of the appliance, as this
could cause live flames inside the appliance.
The manufacturer recommends emptying the tank and vacuuming the screw feeder zone once a month and during the
summer period; this operation must only be carried out when the stove is cold and with the electrical power supply
disconnected. The appliance is designed to run on pellet. Use of other combustible materials in the tank and/or
combustion chamber is strictly prohibited.
Only pellets complying with the above specifications are to be loaded into the tank; in no case whatsoever must foreign
substances or objects be introduced into the tank, the brazier or any part of the generator.

Page
12
Installation, use and maintenance guide
Mon Amour
4 - INSTALLATION
4.1 APPLIANCE LOCATION
Follow the general guidelines set out in paragraph 1.1 to
the letter. Above all keep in mind that the floor of the
installation site must be capable of bearing the weight of
the appliance added to the weight of the pellets in the tank.
CAUTION: The appliance must be installed in a room with
adequate ventilation. The appliance must be positioned at
a minimum safe distance from walls and furnishings. If
inflammable items are positioned near the appliance
(matchboarding, furniture, curtains, wall hangings, sofas,
etc...), this gap must be increased considerably. The
recommended minimum distances are illustrated in the
drawing below on the right. If the flooring is made of wood
or any other combustible material, it is recommended to
install a fireproof floor protector plate between the
appliance and the floor. Installation in the vicinity of heat-
sensitive materials is only permitted if suitable insulating
and fireproof protection is placed between the object and
the appliance (ref. Uni 10683). Failure to observe this instruction will immediately invalidate the warranty.
The installer must issue a certificate of conformity for the installation which includes the design plans and the following
documents:
a) Report containing the type of materials utilised.
b) Project as defined in Article 5 of Ministerial Decree n° 37 22 January 2008.
d) References to existing partial or previous declarations of conformity (e.g. electrical wiring).
e) Copy of the certificate of recognition of the professional technical qualifications.
These documents must, by law, be kept together with the use and maintenance booklet. The customer is responsible
for verifying, directly or indirectly, that the installation has been carried out to perfection in accordance with relevant
regulations in force. Do not install the appliance in unsuitable rooms such as bedrooms, bathrooms, garages and/or
lock-ups. It is forbidden to place the appliance in environments with an explosive atmosphere.
CAUTION, the stove is not simply a household appliance: if the instructions set out in this booklet are not followed and/or if
installation of the appliance is not executed perfectly and/or the provisions in force are not strictly complied with, dangerous
conditions could arise for both objects and persons. It is the user’s responsibility to verify the presence, in the room, of a vent
necessary for supplying oxygen to the generator.
The installer must provide the final user with verbal instructions on the correct use of the appliance when the appliance
is set at work for the first time.
Heat Insulating Material
Inspectable Tee
element
450 mm if the material is
combustible
800 mm if the material is combustible
200 mm if the material is combustible

I
Page
13
installation, use and maintenance guide
Mon Amour
4.2 MOUNTING THE CASING
ATTENTION: before proceeding to mount the casing and positioning the appliance, adjust the mounting feet to the
maximum height.
Legenda
Key
Dettaglio Detail
Attach the plates A to the left and right side panels with the supplied screws B. Position the left and right kickplates D on their
respective sides and fix with screws E.
Position the side panels F, previously assembled, on the stove body by matching up the slots Ywith the tabs Z on the base. Secure
the side panels with screws G and screws H.
AB
DDE
X
Dettaglio X
F
F
Y
DETTAGLIO Y
Z
DETTAGLIO Z
G
G
H
H

Page
14
Installation, use and maintenance guide
Mon Amour
5 – DESCRIPTION OF THE CONTROLS
The appliance, when operating, could be hot to the touch, particularly the door of the combustion chamber: take care
when handling the appliance components. Your appliance has obtained the CE marking and has been made to run for
at least one hour to check that it functions correctly. The product must not be used by children, by persons with physical
or mental impairments, by persons who are not familiar with the instructions for use and maintenance of the product (the
instructions are found in this use and maintenance booklet).
CAUTION: Before each use make sure that the brazier is clean and positioned correctly in its lodging.
CAUTION: the door must always remain shut tight when the stove is operating. It is strictly forbidden to open the door
while the appliance is in operation. While the appliance is in operation the smoke exhaust pipes can reach extremely
high temperatures: do not touch them! It is strictly prohibited to use any type of fuel (liquid, solid...) other than pallet to
light up the appliance: lighting must occur automatically as intended and described in this installation, use and
maintenance booklet; consequently, it is also strictly forbidden to feed pellets (or any other material) into the brazier. Do
not place non-heat resistant or inflammable or combustible objects in the vicinity of the appliance: keep them at a suitable
distance. Do not place wet clothing to dry on the appliance. When using a clothes horse, keep at a suitable distance. It
is strictly prohibited to disconnect the appliance from the electrical power mains during normal operation.
5.1 DESCRIPTION OF THE CONTROL PANEL
The control panel is managed by a microprocessor. The control buttons and the various displays are described below.
The control buttons are:
Clock button
Press this button to activate / deactivate the programming. (See para. 5.4),
Ventilation button
Press this button to set the desired level of ventilation: Six ventilation levels can be set on this stove. The fan starts
operating as soon as the temperature inside the stove body rises and the smoke thermocouple gives the signal. The
fan stops automatically when the stove body has cooled sufficiently. The fan cannot be disabled during operation.
Flame button
Pressing this button when the appliance is off activates the START sequence (See Para. 7), sets the combustion
power in the WORK mode (See Para. 7) or shuts off the appliance by activating the OFF sequence (See Para. 7).
Scroll buttons (only in the Menu)
Press MINUS key to lower the value. Press PLUS key to raise the preset value.
Menu button
Press this button to access the main menu. You can scroll the setting screens shown below, which will be described
in detail in the following paragraphs. To access the functions of each subwindow wait a few seconds.
DATE/TIME This button is used to set the day of the week, the hour and minutes. (See par. 5.3)
CHRONO This button is used to set the programmed on and off sequences. (See para. 5.4)

I
Page
15
installation, use and maintenance guide
Mon Amour
LEVEL Is used to change the rotation speed of the smoke suction unit. (See para. 5.5)
THERMOCOMFORT This button is used to activate the connection with the optional handheld radio control. (See para. 5.6)
Display
The following information can appear on the display:
Displays the preset combustion power, and consequently the pellet consumption, by the number of bars that are
lit up around the flame symbol, using this logic:
One bar lit up: Minimum combustion power (and therefore with minimum pellet consumption)
Two bars lit: Second combustion power
Three bars lit: Third combustion power
Four bars lit: Fourth combustion power
Five bars lit up: Maximum combustion power (and therefore with maximum pellet consumption)
No bars lit up: The appliance is OFF
Displays the preset ventilation power, and consequently the room fan speed, by the number of bars that are lit
up around the fan symbol, using this logic:
One bar lit: Minimum ventilation power
Two bars lit: Second ventilation power
Three bars lit: Third ventilation power
Four bars lit: Fourth ventilation power
Five bars lit: Fifth ventilation power
Six bars lit: Maximum ventilation power
Dashes appear along the top of the display, and each dash corresponds to one day of the week set by the user
(e.g. 1 corresponds to Monday, 2 corresponds to Tuesday… etc.).
The operating status of the appliance appears below these dashes, that is START, OFF or WORK. And the current
time set by the user appears below this word.
The presence in the display of the clock symbol indicates that the CHRONO programming has been enabled; if this
symbol does not appear it means that the CHRONO programming has been disabled. (See Par. 5.4)
5.2 DESCRIPTION OF THE POWER PANEL
The components of the power panel are described below:
1) Electrical power outlet 220V-240V 50Hz
2) Main switch 0/I.
3) Test light for pellet feed motor.
The light comes on simultaneously with the activation of the pellet feed
motor.
4) Cap for reset thermostat button.
If the reset thermostat overheats stop the pellet feeder. The appliance
must cool down before you can restart the appliance. After verifying
and eliminating the causes of the event, undo the protective cap and
press the button.
5) Safety fuse.
Legenda
Key
Riarmo Reset
Spia motoriduttore Ratio motor led
3
4
21
5

Page
16
Installation, use and maintenance guide
Mon Amour
5.3 DATE/TIME: SETTING THE DATE AND TIME
The appliance must be energised and the I/0 switch in position “I".
The current date and time can be set using the DATE/TIME function.
To set the current time and date proceed as follows:
1) Press the Menu Button once to view the following screen:
2) After a few seconds the following screen will appear on the display:
3) Now press the Scroll Buttons to change the day of the week; each number corresponds to one day of the week (e.g. 1
corresponds to Monday, 2 corresponds to Tuesday, etc...). To confirm the selection of the day of the week press the Flame
Button.
Once confirmed, the selector shifts to the hour section while the selected day of the week remains framed:
4) Press the Scroll Buttons to change the hour. Once you have set the hour confirm the value by pressing the Flame Button. Once
confirmed, the selector shifts to the minutes section. Press the Scroll Buttons to set the minutes. Press the Flame button to
confirm.
Once confirmed, the date and time setting screen closes automatically and the initial screen returns to the display.
If you confirm the wrong value simply press the Menu Button several times to exit the box until the initial screen will appear, and
repeat the procedure described above.
5.4 CHRONO: ON/OFF PROGRAMMING
The appliance must be energised and the I/0 switch in position “I".
The CHRONO function allows you to set the weekly program by setting up to 3 on-off cycles at different times for every day from
Monday through to Sunday.
To set a program follow the procedure described below:
1) Press the Menu Button twice quickly to view the following screen:
After a few seconds the following screen will appear on the display:
2) Press the Scroll Buttons to select the day of the week on which you want to set the program. Each number corresponds to one
day of the week (e.g. 1 corresponds to Monday, 2 corresponds to Tuesday, etc...). To confirm the day of the week selected for
the programming press the Flame Button. The following screen will appear:
3) Now press the Scroll Buttons to select the hour at which you wish the appliance to start up automatically (ON1). Once the hour
has been set, confirm the value by pressing the Flame Button. When scrolling the ON1 values the OFF1 values will scroll as well;
this is to avoid setting a shut off time that is earlier than the start up time.
Once confirmed, the selector shifts to the minute section of ON1. Press the Scroll Buttons to set the minutes for the first start
up. Confirm the value by pressing the Flame Button.
4) Now press the Scroll Buttons to select the hour at which you wish the appliance to shut off automatically (OFF1). Once the hour
has been set, confirm the value by pressing the Flame Button.
Once confirmed, the selector shifts to the minute section of OFF1. Press the Scroll Buttons to set the minutes for the first shut
off. Confirm the value by pressing the Flame Button.
At this point the first ON/OFF cycle for the selected day has been set.

I
Page
17
installation, use and maintenance guide
Mon Amour
The following screen will appear:
At this point if no further programming is required for that day go to point 5-A.
If, on the other hand, you wish to program a second ON/OFF cycle for that day go to point 5-B.
5-A) Press the Menu Button to exit the screen, in order to enable you to program the times for the ON/OFF cycles for the other
days of the week. In this case repeat the instructions from point 2 up to this paragraph.
5-B) Press the Scroll Buttons to select the hour at which you wish the appliance to start up automatically for the second time
(ON2). The start up time will be that set before OFF1; this is to avoid setting a second start up time that is earlier than the
preceeding shut off time. Once the hour has been set, confirm the value by pressing the Flame Button. When scrolling the
ON2 values the OFF2 values will scroll as well; this is to avoid setting a shut off time that is earlier than the start up time.
Once confirmed, the selector shifts to the minute section of ON2. Press the Scroll Buttons to set the minutes for the second
start up. Confirm the value by pressing the Flame Button.
Now press the Scroll Buttons to select the hour at which you wish the appliance to shut off automatically (OFF2). Once the
hour has been set, confirm the value by pressing the Flame Button.
Once confirmed, the selector shifts to the minute section of OFF2. Press the Scroll Buttons to set the minutes for the second
shut off. Confirm the value by pressing the Flame Button.
At this point the second ON/OFF cycle for the selected day has been set.
The following screen will appear:
At this point if no further programming is required for that day go to point 6-A.
If, on the other hand, you wish to program a third ON/OFF cycle for that day go to point 6-B.
6-A) Press the Menu Button to exit the screen, in order to enable you to program the times for the ON/OFF cycles for the other
days of the week. In this case repeat the instructions from point 2 up to this paragraph.
6-B) Press the Scroll Buttons to select the hour at which you wish the appliance to start up automatically for the third time (ON3).
The start up time will be that set before OFF2; this is to avoid setting a third start up time that is earlier than the preceeding
shut off time. Once you have set the hour confirm the value by pressing the Flame Button. When scrolling the ON3 values
the OFF3 values will scroll as well; this is to avoid setting a shut off time that is earlier than the start up time..
Once confirmed, the selector shifts to the minute section of ON3. Press the Scroll Buttons to set the minutes for the third
start up. Confirm the value by pressing the Flame Button.
Now press the Scroll Buttons to select the hour at which you wish the appliance to shut off automatically (OFF3). Once the
hour has been set, confirm the value by pressing the Flame Button. Once confirmed, the selector shifts to the minute section
of OFF3. Press the Scroll Buttons to set the minutes for the third shut off. Confirm the value by pressing the Flame Button.
At this point the third and final ON/OFF cycle for the selected day has been set.
Alternatively, if you wish to copy the exact same programming for the ON/OFF cycles set for a particular day to the next day simply
press the Ventilation button.
For example: if I want to copy all the programmed ON/OFF cycles set for Monday to Tuesday the following screen will appear:
I press the Ventilation button once again to copy all the cycles programmed for Tuesday to Wednesday. The following screen will
appear:
sing the same logic we can copy the programmed cycles to the other days.
7) To conclude the programming operations simply press the Menu Button several times to exit the box until the initial screen will
appear.
CAUTION: The appliance ignores any ON or OFF command programmed ith a value of 00:00. Consequently if
you do not wish to use an ON or OFF time setting simply set a value of 00:00. The appliance ignores any ON or OFF
command if the shut off time is set the same as or before the start up time.
ATTENTION:

Page
18
Installation, use and maintenance guide
Mon Amour
In the event of a programmed cycle on always ensure that the brazier is clean and in the correct position. Failure to
clean the brazier can reduce and/or affect the life of the spark plug as it would be subjected to high temperatures due
to poor cooling. It is recommended to set ON/OFF cycles times lasting no less than hours, in order to save energy
and for the proper operation of the appliance.
.
Enabling the programmed cycles:
Back in the initial screen, to enable the appliance to carry out the ON/OFF cycles as programmed it is necessary to press the Clock
Button.
The image of a clock will appear on the main screen:
The programmed cycles are now enabled.
When the programmed cycles are enabled (a clock symbol appears on the display) it will not be possible to use
an additional chronothermostat (see Para. 8.2).
Disabling the programmed cycles:
To disable the appliance from carrying out the programmed ON/OFF cycles press the Clock Button once again.
On the display the clock symbol will disappear. This operation disables the weekly program that has been set by the user but does
not delete or reset the times.
Resetting the programmed cycles:
Moreover, it is possible to reset, in other words delete, all the programmed cycles entered by the user by holding down the Clock
Button in the initial screen for approx. five seconds.
The words CL AR TIM RS will appear momentarily on the screen.
Do not release the button until the text CLEARED appears on the screen. Only the appearance of the words CLEARED
signal that the previously entered programmed cycles have been deleted. When the programmed cycles are active the
operating level at start up, that is the combustion power, will be the same level set before the last time the machine was
shut off: that is, only if it was a programmed shut off, not if the machine was shut off by means of a manual action. Manual
shut down can only be carried out with the programming disabled. If after a manual shut off the programmed cycle re-
enables, at the next programmed start up the appliance will be on the first combustion power level.
5.5 LEVEL: OPERATING LEVEL SETTING
The appliance must be energised and the I/0 switch in position “I".
Your appliance is delivered with an excellent program installed that favours combustion efficiency; the program is called LEVEL 1.
However, if you are using pellets with a higher than normal incidence of residues after combustion in the brazier, it is possible to
select alternative levels:
LEVEL 2 is an operating program that accelerates the speed of the smoke suction unit in proportion to all the combustion
power levels. This level must be set when the user notices a weak, high and very dark flame. Attention: this
modification does not authorise the use of below-standard pellets, or no vacuum in the flue outlet.
If using loosely compressed pellets, you could select:
LEVEL 0: is an operating program that decelerates the speed of the smoke suction unit when using loosely compressed
pellets and/or when the flue outlet has a very high vacuum, over 2 mm water column (20 Pascal).
The pellet consumption value remains unchanged regardless of the selected operating level. These variations will only change the
rotation of the smoke suction unit in the WORK stage, all the other stages will not undergo any changes.
Select the required Level by acting as follows:
1) Press the Menu Button three times quickly and the following box will appear:
After a few seconds the following screen will appear on the display:

I
Page
19
installation, use and maintenance guide
Mon Amour
2) To change the operating level, hold down a Scroll Button while simultaneously pressing the other Scroll Button.
To set the desired level simply press the Menu Button several times until the initial screen will appear on the display.
The level selection can be made with the appliance OFF or ON. If the change is made while the appliance is running
the difference in the flame will be apparent. It is mandatory to pay particular care when selecting the most appropriate
operating cycle for your installation. After the selection of the operating cycle a thorough cleaning of the brazier is
mandatory.
5.6 THERMOCOMFORT: ACTIVATING THE CONNECTION WITH THE HANDHELD RADIO CONTROL
(OPTIONAL)
The appliance must be energised and the I/0 switch in position “I".
This function enables you to activate the connection of the appliance with the optional THERMOCOMFORT handheld radio control
(See Para. 6).
The THERMOCOMFORT function can be activated by proceeding as follows:
1) Press the Menu Button five times quickly until the following screen appears:
After a few seconds the following screen will appear on the display:
2) Press one of the two Scroll Buttons and the following screen will appear (Select ON to activate).
ATTENTION: It will only be possible to activate the THERMOCOMFORT function and select ON in the previousscreen if the appliance
detects the radio control signal. It is therefore recommended to ensure that the radio control is energised and within close vicinity of
the appliance.
3) To confirm the activation of the THE MOCOMFO T function or to exit the screen simply press the Menu Button to return to the
initial screen.
The THERMOCOMFORT symbol will be present on the initial screen if the appliance is in the START or WORK stage:
The Thermocomfort function is automatically disabled when the appliance is OFF. It automatically reactivates at the next START up.
To disable the THERMOCOMFORT function simply repeat operations 1 and 2, but this time select the OFF command. The function
will be disabled immediately.

Page
20
Installation, use and maintenance guide
Mon Amour
6 - OPERATION OF THE HANDHELD RADIO CONTROL THERMOCOMFORT
(OPTIONAL)
The Thermocomfort handheld radio control is the instrument that allows you to optimise both consumption and functions.
If set in AUTO mode, the radio control detects the room temperature where it is located and automatically manages the modulation
of the combustion power and the ventilation power of the appliance according to the target temperature set by the user in the radio
control.
If set in MANUAL mode, the user can select both the ventilation power and the flame power .
6.1 INDICATORS OF THE HANDHELD RADIO CONTROL
1 Flame button
2 Ventilation button
3 DOWN key
4 UP key
5 Displays the room temperature detected by the radio control sensor
6 Ventilation power indicator
7 Combustion power indicator
8 Target room temperature indicator, use buttons 3 and 4 to change the value
9 Area of the display where the operating program is displayed
10 Battery charge level
11 Main switch 0-1 radio control power supply
12 Battery charger connection
13 Code selector and batteries compartment cover
