PRODUCT SPECIFICATIONS
See-Thru (LSTF36) Designer Vent Free Firebox
42 1/8
23 11/16
44 1/16
22 13/16
34 1/2
23 13/16
3 1/16
12 3/8
35 15/16
7/8
28
39 1/2
TOP VIEW
FRONT VIEW
RIGHT SIDE VIEW
LEFT SIDE VIEW
34 3/4
FRAMING
DIMENSION
42 3/8
FRAMING DIMENSION
22 5/16
FRAMING
DIMENSION
To avoid personal injury or property damage, the product described by this brochure must be installed, operated and maintained in strict compliance with the instructions packaged with the product and all applicable
building or fire codes.Contact local building or fire officials about restrictions and installation inspection requirements.All photographs and drawings on this brochure are for illustrative purposes only and are not intended
for, nor should they be used as a substitute for the instructions packaged with the unit.Appearance and specifications of the product are subject to change without notice.© 2007 Monessen Hearth Systems Co.
A Brand of Monessen Hearth Systems Co.
149 Cleveland Drive, Paris, Kentucky 40361
www.monessenhearth.com
INTERIOR DIMENSIONS
Front opening width: 35 15/16"
Front opening height: 28"
Firebox depth: 23 13/16"
TECHNICAL INFORMATION
Clearance to Fireplace: Zero
CSA Design Certified
FIELD INSTALLED ACCESSORIES
Variable Thermostat Controlled ForcedAir Blower (160cfm) - BLOT
Brass Hood
HPBA
Hearth, Patio & Barbecue Association
MADE IN U.S.A.
