European Home DV 52 User manual

For Your Safety:
Do not store or use gasoline or other ammable vapors and liquids in the vicinity of this or
any other appliance.
Safety Notice:
Glass doors on gas replaces are extremely hot while the replace is on and remain hot even after the
replace has been turned o. Safety screens are available and can reduce the risks of severe burns.
®
C US
Warning:
Improper installation, adjustment, alteration, service or maintenance can cause injury or
property damage. Refer to this manual. For assistance or additional information consult a
qualied installer, service agency or the gas supplier.
Warning:
What to do if you smell gas
• Do not try to light any appliance.
• Do not touch any electrical switch; do
not use any phone in your building.
• Immediately call your gas supplier
from a neighbor's phone. Follow the
gas supplier's instructions.
• If you cannot reach your gas supplier,
call the re department.
• Installer: Leave this manual with
the appliance.
• Consumer: Keep this manual for
future reference.
Installation,
Operation and
Maintenance
Manual
DV 52
Direct Vent
Gas Fireplace
Check local codes and read all
instructions prior to installation.

Page 2
DV52 Gas Fireplace
rev.101207
Warning:
Read this manual before installing, operating or troubleshooting this appliance.
Please retain this owner's manual for future reference.
Safety Alert Key:
• DANGER! Indicates a hazardous situation which, if not avoided will result in death or serious injury.
• WARNING! Indicates a hazardous situation which, if not avoided could result in death or serious injury.
• CAUTION! Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury.
• NOTICE: Used to address practices not related to personal injury.
• Important: Used to address practices not related to personal injury.
Congratulations
Safety Alert Key
Introduction ............................................................................................... 3
Installation ................................................................................................4
Installing and Framing the Fireplace .............................................. 4
Installing the Gas Line ....................................................................5
Vent Installation ............................................................................. 5
Installing the Nailing Flange Extension ..........................................7
Top Vent Runs .......................................................................... 7 - 11
Side Vent Runs .........................................................................7 - 12
About the Power Vent ................................................................... 13
Finishing Around the Fireplace ..................................................... 13
Mantels and Surrounds ................................................................. 14
Table Of Contents
Wiring ...................................................................................... 14
Removing and Installing the Door ................................................ 15
Operation ................................................................................................. 17
Maintenance ...........................................................................................19
Troubleshooting ........................................................................... 20
Spare Parts ................................................................................... 20
Warranty .................................................................................................. 21
Appendix
A. Termination Locations .............................................................. 22
B. State of Massachusetts ............................................................. 23
Congratulations
Congratulations on selecting a European Home gas replace, an elegant
and well designed gas replace built with you in mind. The gas replace
you have selected is designed to provide the utmost in safety and reli-
ability.
As the owner of this new replace, you'll want to read and carefully
follow all the instructions contained in this Installation, Operation and
Maintenance manual. Pay special attention to all cautions, warnings, and
important warnings.
This owner's manual should be retained for future reference. We suggest
that you keep it with all your other important documents and product
manuals.
The information contained in this owner's manual, unless noted other-
wise, applies to all models, and gas control systems.
Your new gas replace will give you years of reliable use. Welcome to the
European Home family of gas replace products.

Page 3
DV52 Gas Fireplace
rev.101207
Introduction
Thank you for choosing a European Home Gas Fireplace.
About this Fireplace:
The DV 52 is a gas replace with a linear burner. This replace can be converted to
both a top vent or rear vent application, and is currently available in the models below.
The DV 52 is rated for natural gas or propane at 40,000 BTU/hr. (11.73 Kilowatts) input.
• DV 52; millivolt pilot
• DV 52 E; electronic ignition
How to use this manual:
This manual covers installation, operation and maintenance. Lighting, operation
and care of this replace can be easily performed by the homeowner. However, all
installation and service work should be performed by a qualied or licensed installer,
plumber, or gastter who is qualied or licensed by the state, province, region, or
governing body in which the appliance is being installed.
This manual covers all models and unless otherwise specied, the designation DV 52
refers to all applicable models.
Warranty and Installation Information:
The European Home warranty will be voided by, and European Home disclaims any
responsibility for, the following actions:
• Modication of the replace and/or components including direct vent assembly or
glass doors.
• Use of any component part not manufactured or approved by European Home in
combination with this European Home replace system.
• Installation other than as instructed in this manual.
Consult your local gas inspection branch on installation requirements for factory-
built gas replaces. Installation and repairs should be done by a qualied contractor.
Installations in Canada must conform to the current CAN/CGA B-149.1 and .2
Gas Installation Code and local regulations. If the optional air-circulating fan kit is
installed, it must be electrically grounded in accordance with CSA C22.1 Canadian
Electrical Code Part 1 and/or Local Codes.
Installations in the USA must conform to local codes, or in the absence of local
codes to the National Fuel Gas Code, ANSI Z223.1-1988. If the optional air-circulating
fan is installed, it must be grounded in accordance with local codes or, in the absence
of local codes, with the National Electrical Code, ANSI/NFPA 70-1987. Within the
State of Massachusetts this replace must comply with NFPA-54 Chapter 10.
CAUTION!
Due to its high operating temperatures, the appliance should be
located out of trac and away from furniture and draperies.
 Children and adults should be alerted to the hazards of the
high surface temperature, which could cause burns or clothing
ignition.
 Young children should be carefully supervised when they are in
the same room as the appliance.
 Clothing or other ammable materials should not be placed on
or near the appliance.
WARNING!
When this appliance is installed directly on carpeting, tile or any combustible
material other than wood ooring, it must be installed on a metal or wood
panel extending the full width and depth of the appliance.
What is Combustible?
Materials that can catch re and burn are considered combustible. Any material that
is made of, or faced with, wood, wood pulp, paper, plastic or any other material that
can catch re and burn is considered combustible. Even though these materials may
have been 'ame-proofed', made 're-resistant' or are 're-rated' they are considered
combustible.
The combustibility of a material can be tested per "ASTM E136 Standard Test Method
for Behavior of Materials in a Vertical Tube Furnace at 750 Degrees C". Note that 're-
resistant' does NOT mean non-combustible.
Note: If a certain material has a core considered to be non-combustible (in accordance
with ASTM E136) but is faced with a combustible material then the material is
considered to be combustible.
When in doubt, ask for an ASTM E136 compliance statement.
What is Non-combustible?
A given material is said to be non-combustible when it cannot catch re and burn.
For example, materials made entirely, or in combinations, of, stone, brick, concrete,
tile, steel, plaster or glass are considered non-combustible.
For the purposes of the installations described in this Manual, those materials that
have passed the ASTM E136 tests are considered to be non-combustible.
As of this writing, the materials listed below are reported by their manufacturers to
be non-combustible (in accordance with ASTM E136):
• James Hardie Building Products, Inc.:
HardieBacker™ ¼” Cement Board
• U.S. Architectural Products, Inc.:
Versaroc® Cement Bonded Particle Board
Cem-Clad® Cement Panel

Page 4
DV52 Gas Fireplace
rev.101207
Installation
Installing and Framing the Fireplace
The replace may be installed in any location that maintains proper clearances to air
conditioning ducts, electrical wiring and plumbing. Safety, as well as eciency of
operation, must be considered when selecting the replace location. Try to select a
location that does not interfere with room trac, has adequate ventilation, and oers
an accessible pathway for direct vent installation. Refer to page 5 - Vent Installation
for more information.
The replace dimensions are shown below:
When installing a shelf over the top of the replace, the following must be
observed: For top vent applications, the minimum clearance is 24". (Minimum
clearances must still be maintained around the vent pipes.)
Figure 2. Framing dimensions.
Framing
* Clearance from the top of the replace to a combustible ceiling within the replace enclosure
** Refer to the 'Finishing Around the Fireplace' section of this manual.
Unprotected combustible walls which are perpendicular to the replace opening,
must not project beyond the shaded area shown in Figure 24.
For protection against freezing temperatures, it is recommended that outer walls of
the chase be insulated with a vapor barrier. This will reduce the possibility of a cold
air convection current on the replace.
Clearances
These clearances apply to all dimensions except the framed opening, where the
clearances to combustibles are 0". The DV 52 clearances to combustible materials are:
Top - Rear Vent * N/A
Top - Top Vent 24
Back 3"
Sides 2"
Floor 0"
Mantle** 4"
Top View
Front View Side View
WARNING!
When this appliance is installed directly on carpeting, tile or any combustible
material other than wood ooring, it must be installed on a metal or wood
panel extending the full width and depth of the appliance.
Rear Vent
7”
3”
Figure 3. Minimum corner framing dimensions, using a 45° elbow.
Figure 4. Framing for shelves over the replace using combustible materials.
Figure 3a. Top or rear vent with non-
combustible materials.
52"
47¼"
8"
52"
13½"
22½"
5"
1"
21¼"
33¼"
47" 2½"
2½"
2½"
5¼"
6¾"
22½"
33¼"
8"
5"
28"
Ceiling
39½"
25"*
52"
Niche above
replace
Non-combustible
materials only!
Header
Floor
1" min.
Top
vent
Rear
vent
52"
96½"
68¼"
0" clearance to
corners only!
Top Vent
24"
40" 39½"
Elbow
Shelf
39½"
10"
Shelf
Framing header,
supplied shield
See Fig. 23
Framing header,
supplied shield
* When bringing non-combustible wall
board to the replace opening the framing
depth is increased by ½".
See Planning Guide for overlay nishing.
Minimum
84"

Page 5
DV52 Gas Fireplace
rev.101207
Installation
• Use only certied European Home vent components. Use of other parts will void the
European Home warranty, and may impede the operation of the replace.
• All joints must be secured with a minimum of two screws per joint
• Vent terminations must not be recessed in walls or siding
• Horizontal runs must be supported by a minimum of two supports per horizontal run. A
minimum of one screw on each side of support is also required
• Flex vent sections may be stretched up to 50% of their total length (e.g. a 24" section
may be stretched to 36")
• Flex vent sections over 6 feet must fall within the limits set by the venting graph and must
have a minimum vertical rise of 3 inches per foot of ex.
• Solid vent sections may be cut less than half way from the female end
• Venting components can be used in any combination of solid/rigid pipe or ex pipe and
in any orientation, i.e. connectors can face in any direction.
Vent Terminations
Selecting A Termination Location
Choosing your vent termination location will help to determine whether you need to
use a top vent or rear vent replace. Figure 6a, below, shows typical replace locations
and the venting options they provide.
For a more detailed diagram of allowed termination locations, see Appendix A.
Figure 6a. Fireplace locations and vent terminations.
Installing The Gas Line
The gas line must be installed before nishing the DV 52 Gas Fireplace. Natural gas
requires a minimum inlet gas supply pressure of 5.5" w.c. and a manifold pressure
of 3.5" w.c. Propane gas requires a minimum inlet gas supply pressure of 11" w.c. and
a manifold pressure of 10" w.c. Provision must also be made for a ⁄" NPT plugged
tapping and be accessible for test gauge connection immediately upstream of the
gas supply controls to the appliance. The replace gas connection and the main
operating gas valve is located behind the removable trim at the bottom of the unit
and need only be attached to the gas line with an approved tting, as required by
the applicable installation codes.
• Only use gas shut-o valves approved for use by the state, province, region, or
governing body in which the appliance is being installed or as required by the
applicable installation codes.
• Flexible gas connectors must not exceed 3 feet in length, unless it is allowable within
applicable installation codes.
The appliance and its individual shut-o valve must be disconnected from the gas
supply piping system during any pressure testing of that system at test pressures in
excess of ½ psig (3.5 kPa).
Note: After gas line is connected, each appliance connection, valve and
valve train must be checked while under normal operating pressure
with either a liquid solution, or leak detection device, to locate any
source of leak. Tighten any areas where bubbling appears or leak is
detected until bubbling stops completely or leak is no longer detected.
DO NOT use a ame of any kind to test for leaks.
Figure 5a. Gas line access.
The appliance must be isolated from the gas supply piping system by closing its
individual manual shut-o valve during any pressure testing of the gas supply piping
system at test pressures equal to or less than ½ psig (3.5 kPa).
Vent Installation
This section covers the installation of direct venting and terminations.
Installation Requirements
• DV 52 fireplaces are certified for use with European Home standard
(5"/8") venting components.
• Minimum clearance to combustible construction around the vent pipe is 1" on
all sides, except on horizontal venting where the top of the pipe must have a clearance
of at least 2".
Cautions:
• Vent terminations can be very hot. If the termination is less than
7 feet above a public walkway, it should be tted with a certied
European Home Heat Guard. (Part no. PTKOG).
• Do not obstruct, or attempt to conceal, the vent termination.
These actions will aect the operation of the replace, and may
be hazardous.
• In heavy snow areas, take extra care to prevent snow buildup from
obstructing the vent termination.
• Use European Home VSS Vinyl Heat Shield when using on applications
with vinyl siding to guard against possible damage.
10" to center
Gas line access
⁄" diameter
2"

Page 6
DV52 Gas Fireplace
rev.101207
4.5”
Installation
Installing Terminations with Built-In Frames
Installing Terminations with MSR Frames
12
12
1. Frame the termination opening to 12" x 12".
2. Fasten the termination to the studs using a minimum of 4 screws.
11
11
1. Frame the termination opening to 11" x 11".
2. Fasten the termination to the studs using a minimum of 4 screws.
Installing Terminations with MOSR Frames
1212
12
MOSR
1. Frame the termination opening to 12" x 12".
2. Fasten the MOSR frame to the interior side of the studs using a minimum of 4
screws.
3. Insert the termination into the MOSR frame as shown here, and attach by
screwing through the four pilot holes in the termination.
MSR
PTO-4 (5"/8")
PTO-4F (5"/8")
PTO-4 (5"/8")
PTKOG (5"/8")
1. Ensure that the two long mounting brackets are facing the bottom of the
termination, see inset. This will provide more heat protection at the top of the
termination, where temperatures are highest.
2. Attach to the faceplate of the termination using four sheet metal screws.
3. If installing the termination over vinyl siding, Use the VSS Termination Shield.
Installing Heat Guards over Terminations
Installing The Standos
To avoid elevated mantel temperatures, all DV 52 gas
fireplaces are required to have the supplied standoffs installed.
The replace is supplied with two standos. Bend and install these standos on top
of the replace ensuring that the height of the stando maintains a 4½" clearance.
Figure 6b. Installing the standos.
Figure 6. Installing the VSS Vinyl Shield.
Figure 5a. Installing a PTO termination.
Figure 5b. Installing a PTO termination with the MSR frame.
Figure 5c. Installing a PTO termination with the MOSR frame.
Figure 5d. Installing a PTO termination heat guard.

Page 7
DV52 Gas Fireplace
rev.101207
Figure 6c. Installing the nailing ange extension.
Installation
Converting to Top Vent/Rear Vent
DV 52 Top Vent
Use the following instructions to convert to a DV 52 top vent.
1. Install the 5" inner ue cap on the rear ue outlet and secure the cap in place
with ve screws, as shown in Figure 7a.
2. Install the 8" outer ue cap on the rear ue outlet, and secure it with ve
screws, as shown in Figure 7a.
3. Install the ue gasket material and ue cover plate on the rear vent outlet .
Fasten the plate with four screws, as illustrated below.
4. Install the 5" inner ue collar and the 8" outer ue collar in place on the top
vent outlet using 5 screws, as illustrated below.
DV 52 Rear Vent
Use the following instructions to convert an DV 52 for rear vent use:
1. Install the 5" inner ue cap on the top ue outlet and secure the cap in place
with ve screws, as shown in Figure 8a.
2. Install the 8" outer ue cap on the top ue outlet, and secure it with ve
screws, as shown in Figure 8a.
3. Install the ue gasket material and ue cover plate on the top vent outlet.
Fasten the plate with four screws, as illustrated in Figure 8b.
4. Install the 5" inner ue collar and the 8" outer ue collar in place on the rear
vent outlet using 5 screws, as illustrated below.
5” Inner Flue Cap
8” Outer Flue Cap
Flue Gasket
Flue Cover Plate
8” Outer Flue Collar
5” Inner Flue Collar
5” Inner Flue Collar
8” Outer Flue Collar
Flue Gasket
Flue Cover Plate
5” Inner ue CapFl
Fl8” Outer ue Cap
Figure 7a. Flue cap installation, top vented DV 52 replace.
Figure 7b. Flue collar installation, top vented DV 52 replace.
Figure 8a. Flue cap installation, rear vented DV 52 replace.
Figure 8b. Flue collar installation, rear vented DV 52 replace.
Top Vented Runs
For a top-vented DV 52, there are two types of installations:
a) through-the-wall and b) through-the-roof
A) Through-The-Wall Installations
Before you install any venting, you must determine whether the venting run will be
acceptable. Unacceptable venting can aect the replace's combustion.
The Venting Graph
Measure the vertical height from the replace hearth to the center of the termination
and the horizontal run from the from the replace ue collar to the wall ange of the
termination. Plot on the Venting Graph (Fig. 9a) with an 'X'.
Installing the Nailing
Flange Extension
Once the replace is placed into the rough framed opening (see Figure 2), and the
supplied steel lintel (p/n L42087) is in place, the supplied nailing extension must
be placed along the top edge of the replace and securely fastened in place to the
metal lintel, and combustible wood framing. Note: The nailing ange extension
can be substituted with a piece of NON-COMBUSTIBLE material of the same size
and thermal characteristics, i.e. cement board or equivalent.

Page 8
DV52 Gas Fireplace
rev.101207
B
A
C
Power Vent models, LDVPV47
EDVRSPV58, and EDVWSPV58
to be used within the shaded area
of graph. See index of this guide
for applicable product page.
Installation
Figure 9a. DV 52 Top Vent Venting Graph
NOTES: All dimension lengths for vertical or horizontal runs are measured
from center of the vent pipe.
Venting runs must fall within the limits set by the venting graph
(see Figure 9a).
Example 1:
For our shortest venting conguration use components A and E (see Figure 9a).
Figure 10. Typical top vent installation. If the 90° elbow is installed directly on the
replace, for height to the center of the termination see chart on Page 3.
Important:
An inspection of the explosion relief appers and door must be made prior to
lighting the replace. This will ensure the door gasketing material will provide
an adequate seal during operation.
PEL
RHS101
Horizontal Venting
Figure 11. Typical top vent installation. The solid sections can be used in various
combinations to obtain the desired vent run. The vent run must fall
within the limits set by the venting graph.
90° Elbow
PEXT Section
Termination
If the 'X' falls on or above the top boundary of the shaded area, the installation is
acceptable.
Example A: (Acceptable Installation)
If the vertical dimension from the hearth is 84" and the horizontal run to the wall ange
of the vent termination is 36", the installation is acceptable.
Example B: (Acceptable Installation)
If the vertical dimension from the hearth is 108" and the horizontal run to the wall ange
of the vent termination is 120", the installation is acceptable.
Example C: (Unacceptable Installation)
If the vertical dimension from the oor of the replace is 48" and the horizontal run to
the wall ange of the vent termination is 108", the installation is NOT ALLOWED.
Available Top Vent Components
The following components are available for through-the-wall venting:
5" / 8" Venting
A - Termination PTO-4 (4" Length)
PTO-4F (4" Length)
B - Stucco Kits MSR (Stucco Frame)
MOSR (Stucco Can)
BSR ( Brick Can)
C - Flex Sections PFL-1 (12" Section)
PFL-2 (24" Section)
PFL-3 (36" Section)
PFL-4 (48" Section)
D - Rigid Sections PEXT-1 (12" m/f Section)
PEXT-2 (24" m/f Section)
PEXT-3 (36" m/f Section)
PEXT-4 (48" m/f Section)
E - Elbows PEL-90MM (m/m 90° Elbow)
PEL-90FF (f/f 90° Elbow)
PEL-90FM (f/m 90° Elbow)

Page 9
DV52 Gas Fireplace
rev.101207
Installation
Figure 12. Extended installation using a combination of solid and ex venting. Use
the vent graph to determine your allowable run, then select appropriate
components.
Example 2:
Rigid sections and an elbow used in conjunction with 3 ft. ex section (PFL-3) will,
when extended in a ve foot chase, allow for a maximum horizontal run of 12' 6"from
the center of the replace to outside wall and a minimum of 7'6" when retracted in
the opposite direction. See Figures 12 and 13.
"C" ex sections and "D" rigid sections may be used in conjunction with one another
to obtain dierent possible horizontal length installations. NOTE: Flex section with
no vertical rise must not exceed maximum horizontal length of 3 feet, see Figure 14.
Flex runs over 3 feet must fall within the limits set by the venting graph, and must
have a minimum vertical rise of 3" per foot of ex.
Figure 13. Retracted installation using a combination of solid and ex venting. Use
the vent graph to determine your allowable run, then select appropriate
components.
Figure 14. Horizontal ex installation with minimum vertical rise.
B. Vertical (Through-The-Roof) Installations
Vertical rise >12' can be reduced (on applicable models).
Vertical terminations must be installed:
• minimum 2' (two feet) above the highest point where
vent passes through the roof.
• minimum 6' (six feet) from a mechanical air inlet
• minimum 18" (1½ feet) from a parapet wall.
 Maximum vent height is:
• 32 feet above replace.
Note: Flame characteristics will change if the maximum vent height is used.
 2" minimum clearance between vent and all horizontal combustible materials
must be maintained.
A maximum of two osets (each oset has two 90° bends) may be made and
shall not exceed total length of 25% of the vertical vent height, when measured
center to center of piping.
Using this vent installation example:
• 20' vertical vent
• 2 - 2' osets required
Maximum oset allowed = 25% of 20'or 5'. This venting conguration meets
requirements.
5"/8" Venting
A - Termination PVTK-1
B - Flex Sections PFL-1 (12" Section)
PFL-2 (24" Section)
PFL-3 (36" Section)
PFL-4 (48" Section)
C - Rigid Sections PEXT-1 (12" m/f Section)
PEXT-2 (24" m/f Section)
PEXT-3 (36" m/f Section)
PEXT-4 (48" m/f Section)
D - Support Ring and
Plate
PSPXT-8
E - Firestop PS-8
F - Roof Flashing PRF-7 (1/12 - 7/12 pt.)
PRF-7 (7/12 - 12/12 pt.)
G - Adaptor/Vent
Reducer
PVA5487 (5"/8" to 4"/7")
4’ max. RHS 8,
4’ vent run or
less, use RHS101

Page 10
DV52 Gas Fireplace
rev.101207
Installation
Figure 15. Straight, vertical venting showing required PXT-10 adaptor (supplied
with the PVTK-1 termination).
* All venting: minimum 1" clearance to all vertical combustibles,
minimum 2" to all horizontal combustibles.
Figure 17. Vertical venting with 2 osets (1 oset= two 90° bends).
Figure 16. Vertical venting with 1 oset (1 oset= two 90° bends).
PEXT
PEXT
PXT-10
Figure 16a. RHS8 Installation. Install by sliding over vent pipe where it passes through
the combustible construction.
Figure 16b. RHS101 Installation. Install by sliding over vent pipe where it passes
through the combustible construction.
Framing
Drywall
RHS101 Heat Shield,
Inner Section.
Vent from fireplace
RHS101 Heat Shield,
Outer Section.
Termination
32’
RHS8
Heat Shield
1" min.
Both sides
typical
2" min.
1" min.

Page 11
DV52 Gas Fireplace
rev.101207
Installation
Important: Corner installation is available only for top vent
replaces.
Figure 20. Corner installation.
Figure 21. Flex installation.
2. 45° Corner Installation.
Attach an PEL-90 (90° elbow) directly onto the ue collar, and attach it to the
PEL-45 (45° elbow). Cut the PXT-18 to suit and insert it into the PEL-45. Slide the
replace into position, and then connect it to the exterior termination.
3. Corner Installation — 45° or less.
Use a PTO-4 termination and an PFL-1 or PFL-2 (12" or 24" compressed length)
and a frame, if appropriate. Flex may be turned to obtain desired degree of angle
required but must not exceed 45°.
IMPORTANT: For both rear vent installations your vent run must fall within the
limits set by the Figure 22c vent graph.
Before you install any venting, you must determine whether the venting run will be
acceptable. Unacceptable venting can aect the replace's combustion.
The Venting Graph
Measure the vertical height from the replace hearth to the center of the termination
and the horizontal run from the from the replace ue collar to the wall ange of the
termination. Plot on the Venting Graph (Figure 22c) with an 'X'.
If the 'X' falls on or above the top boundary of the shaded area, the installation is
acceptable.
B. Multi-Elbow Installations
For more dicult installation situations, a rear-vented DV 52 must be installed with
either one or two 90° elbows as described in a) or b), below:
a) One 90° elbow must be placed directly on the ue collar then place venting
vertically through the roof to the termination.
b) Two elbows as shown in Figure 23 using a minimum vertical lift of 50" (measured
from the hearth) as shown in Figure 23.
Figure 22c. Multi-elbow venting graph.
Power Vent models, LDVPV47
EDVRSPV58, and EDVWSPV58
to be used within the shaded area
of graph. See index of this guide
for applicable product page.
Termination
Flue Collar
PEL-45 Elbow
PXT-18
RHS101
Heat Shield
PEL-90 Elbow

Page 12
DV52 Gas Fireplace
rev.101207
Figure 23. Multi-elbow installation. Distance 'H' must be a minimum of 50".
The vent run must comply with Figure 22c.
NOTES: All dimension lengths for vertical or horizontal runs are measured
from center of the vent pipe.
IMPORTANT: Venting runs must fall within the limits set by the
venting graph (see Figure 22c).
Rear Vent Venting Runs
Note: Rear venting has only two congurations!
The DV 52 has only two possible installations in the rear vent conguration; using
one 90° elbow o the back and straight up through the roof of the structure or Figure
23 with two elbows.
Heat Shield
The heat shield (RHS101) must be used on all installations straight through the
wall, at the point where the vent pipe connects to the termination. With the heat
shield, proper vent clearances can be maintained. The heat shield is not included
with the replace.
To install the heat shield, slide one section over the vent pipe on the inside of the wall
opening, with the circular portion inside the wall cavity. Screw the shield in place over
the wall opening. Install the second section on the outside of the wall opening sliding
the circular portion into the wall opening. Refer to Figure 16b.
Installation of Rear Vent
The following components are available for through-the-wall venting:
Installation
5"/8" Venting
A - Termination PTO-4 (4" length)
PTO-4 (4" length)
B - Stucco Kits MSR (Stucco Frame)
BSR-4 (4" Brick Frame)
BSR-6 (6" Brick Frame)
MOSR (Stucco Can)
C - Flex Sections PFL-1 (12" Section)
PFL-2 (24" Section)
PFL-3 (36" Section)
PFL-4 (48" Section)
D - Rigid Sections PEXT-1 (12" m/f Section)
PEXT-2 (24" m/f Section)
PEXT-3 (36" m/f Section)
PEXT-4 (48" m/f Section)
PXT-1 (20" Section)
E - Elbows PEL-90MM (m/m 90° Elbow)
PEL-90FF (f/f 90° Elbow)
PEL-90FM (f/m 90° Elbow)
PEL-45FM (f/m 45° Elbow)

Page 13
DV52 Gas Fireplace
rev.101207
Installation
About the Power Vent
A power vent is required where the termination is located too far away from the
gas replace and/or if the vent run is beyond the scope of this document, or the
specications recommend vent augmentation. There are four 4/7 power vent models
available. These power vents oer superior venting, safe operation and years of
trouble free operation.
The available European Home power vent models are:
LDVPV47 (Linear, interior in-line power vent)
EDVPV47 (External power vent module)
EDVRSPV47 (Exterior vertical roof mount 4/7 stainless steel power vent system)
EDVWSPV47 (Exterior horizontal wall mount 4/7 stainless steel power vent system)
Contact European Home for more information.
WARNING!
When covering the upper metal portion of the replace, up to 6" (as shown,
Figures 24 and 25) with a non-combustible material. Please note that the
decorative facing materials may be subject to temperatures in excess of 250° F.
This should be considered when selecting facing materials.
Fireplace Facing
When selecting the nish material for your replace, it is important to remember
that THE OPENING MUST NOT BE OBSTRUCTED IN ANY WAY. Doing so restricts
the air supply for the control compartments and heat exchanger as well as prevents
access for servicing controls.
The face of the replace may be painted to match the room decor provided you use
a heat-resistant paint. Decorative facing must not extend past the replace opening
at all because it will interfere with the access to retainers for removal of glass door.
Finishing Around the Fireplace
Combustible mantels and moldings may be safely installed over the top and on the
front of the replace provided that they do not project beyond shaded area shown in
Figure 24. Side wall clearances are 3". Combustible surrounds may be installed with
3" clearance to the side of the replace as shown in Figure 25.
Figure 24. Combustible mantles and facings.
Horizontal Run (in)
Non-Combustible
Facing Material
WARNING!
We recommend careful consideration be given to the eects of elevated
mantel temperatures which may be in excess of product design, for example:
candles, plastic or pictures. This can cause melting, deformation, discoloration
or premature failure of T.V. and radio components.

Page 14
DV52 Gas Fireplace
rev.101207
Installation
Surround Heat Shield
Included with the DV 52 Gas replace is a heat shield fabricated from galvanized steel.
The kit comes with three (3) pieces as shown below. This shield is to protect all adjacent
combustible mantels and moldings from excessive heat radiated by the cabinet of the
replace. This shield must be installed as shown in Figure 24a.
1). Top shield fastened as shown. Wide ange face up, shallow ange toward inside
of room, nailed or screwed ush with framing.
2). Both side shields fastened as shown. Wide anges face out, shallow ange toward
inside of room, nailed or screwed ush with framing.
Painting:
Special care is recommended by the Master Painters and Decorators Association, when
painting the replace surrounds, to select and apply a quality alkyd sealer prior to the
application of latex paints. This helps to prevent leaching of water from evaporation
which can cause a brownish staining to paint overcoats.
Mantels and Surrounds
NOTE: National Canadian Gas Association mantel test requirements are for re hazard
prevention to combustible materials.
New technology, to meet consumer and government demands for the wise use of
energy, has prompted us to manufacture many models of replaces which are hot
and energy ecient.
Please be aware that temperatures over the mantel will rise above normal room
temperature and walls above replace may be hot to touch.
Figure 24a. Three piece combustible framing shield.
Fasteners
3-Per Shield
Framing
1/2
Side shield
Side shield
Top shield
Framing
1/2
Fasteners
3-Per Shield
4
Figure 25. Combustible surrounds.
Non-Combustible
Facing Material
Header
Drywall/Sheetrock
6”
3”
Wiring
DV 52
Gas Control Wiring
The DV 52 ships ready for manual operation. For remote control operation the
remote receiver must be connected.
• Cut the white splice cap o of the end of the thermostat wire, strip the ends and
connect them to the remote receiver as shown in Figure 26.
• Install the four AA batteries and set the switch to the 'REMOTE', or center, posi-
tion.
See information sheet packaged with remote system for complete instructions.
Note: Use only the included thermostat wire to connect the remote receiver.
Figure 26. Wiring the DV 52 remote receiver.
Thermostat Wire
(supplied)
to thermocouple
to thermopile

Page 15
DV52 Gas Fireplace
rev.101207
Installation
Wiring for the Optional Fan Kit
All DV 52 replaces may be equipped with optional fan kits for circulating heat into
the living space.
Installations in Canada which employ the fans must be electrically grounded
in accordance with CSA C22.1 Canadian Electrical Code Part 1 and/or Local Codes.
Installations in the USA which employ the fans must be grounded in accordance
with local codes or, in the absence of local codes, with the National Electrical Code,
ANSI/NFPA 70-1987.
For more information see the Fan Kit Installation Guide included with the fan kit.
NOTE: If any of the original wire supplied with the appliance is replaced, it must be
replaced with the same type, or its equivalent.
Figure 27. Wiring schematic for optional fans.
G
L2-WH
L1-BLK
p g
Quick Connect
lu to motor
5/1/60 Supply
G L1 L2
Removing and Installing the Door
The doors are removed in a few simple steps. Follow the steps below to remove the
horizontal access panel, unlatch the door buckles and remove the door. Replace in
reverse order.
Figure 28a. Locate the door buckles. (both sides typical)
Figure 28. Removing and installing the horizontal access panel
Locate the Door BucklesStep 2:
Step 1:
Remove the horizontal cover by
placing ngers in both nger holes,
then pushing away from you and
lifting out. Place it aside during
maintenance or cleaning.
Install in reverse order.
Finger Hole
Remove the Horizontal Access Panel
Door Latch Hook
Door Latch Slot
Hand-hold
Release the Door Buckles
Figure 28b. Door buckle tool
1
Step 4:
Firmly grasp hand-hold end
of door buckle tool and place
the machined end in the slot
under door frame as shown.
Figure 28c.
Step 3:
Horizontal
Access Panel

Page 16
DV52 Gas Fireplace
rev.101207
Installation
To install the door, hook the top edge of the door frame into place. Lower the door
into position and follow the previous steps shown in reverse order.
Installing the Door
2
Step 5:
Ensure the tool is rmly in the
lower end of the slot, as shown.
Then pull toward you.
Caution: Hold the tool securely.
3
Step 6:
Pull hard if necessary to release
the spring tension.
Caution: The latch springs
back with force. Hold the tool
securely.
4
Step 7:
Remove the tool from the latch
slot. Ensure the latches are hang-
ing freely and the hook end is
released from the bottom of the
door. Repeat all four steps for the
remaining latches.
Figure 28d.
Figure 28e.
Figure 28f.
Step 8:
Grasp the door on either side, usually midway, and lift the door carefully up
and away from the front of the replace. See Figure 28g. Place the door aside in
a safe place while maintenance and/or cleaning is being performed.
Figure 28g. Removing and installing the glass doors. (both sides typical)
Removing the Door

Page 17
DV52 Gas Fireplace
rev.101207
• If you cannot reach your gas supplier, call the Fire Department.
C. Use only your hand to push in or turn the gas control knob. Never use
tools. If the knob will not push in or turn by hand, don't try to repair it,
call a qualied service technician. Force or attempt to repair may result
in a re or explosion.
D. Do not use this appliance if any part has been under water. Immediately
call a qualied service technician to inspect the appliance and to replace
any part of the control system and any gas control which has been under
water.
A. This appliance has a pilot which must be lighted by hand. When lighting
the pilot, follow these instructions exactly.
B. BEFORE LIGHTING smell all around the appliance area for gas. Be sure
to smell next to the oor because some gas is heavier than air and will
settle on the oor.
What To Do If You Smell Gas:
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in your
building.
• Immediately call your gas supplier from a neighbor's phone. Follow
the gas supplier's instructions.
To Turn O Gas To Appliance:
Operation - Model DV 52
3. Push in gas control knob slightly and turn clockwise to "O". Do
not force.
4. Flip up the lower trim.
1. Turn o remote switch.
2. Flip down the lower trim.
1. STOP! Read the safety information above on this label.
2. Flip down the lower trims.
3. Push in gas control knob and turn clockwise to "OFF."
4. Wait ve (5) minutes to clear out any gas. Smell for gas, including near
the oor. If you then smell gas, STOP! Follow "B" in the safety information
above on this label. If you don't smell gas, go to the next step.
5. Locate pilot burner (See illustration at right.) and follow steps below.
6. Turn knob on gas control counter clockwise to "PILOT."
7. Push in gas control knob completely and hold. Light with Piezo Igniter
button. Continue to hold the control knob in for about (1) minute after the
pilot is lit. Release the knob and it will pop back up. Pilot should remain
lit. If it goes out repeat steps 3 through 8.
• If knob does not pop up when released. Stop and immediately call
your service technician or gas supplier.
• If the pilot will not stay lit after several tries, turn the gas control
knob to "OFF" and call your service technician or gas supplier.
8. Push in gas control knob and turn counter-clockwise to "ON."
9. Flip up the lower trim.
10. Turn on remote switch to ignite re.
Lighting Instructions:
with Continuous Pilot
For Your Safety - READ BEFORE LIGHTING:
NOTE: Gas control knob cannot be turned from
"PILOT" to "OFF" unless knob is pushed
in slightly. Do not force.
DV 52
WARNING: If you do not follow these instructions exactly, a re or explosion may result causing
property damage, personal injury or loss of life.

Page 18
DV52 Gas Fireplace
rev.101207
Operation - Model DV 52 E
DV 52 E
with Proame SIT Electronic Ignition
WARNING: If you do not follow these instructions exactly, a re or explosion may result causing
property damage, personal injury or loss of life.
To Turn O Gas To Appliance:
Lighting Instructions:
tools. If the knob will not push in or turn by hand, don't try to repair it,
call a qualied service technician. Force or attempt to repair may result
in a re or explosion.
D. Do not use this appliance if any part has been under water. Immedi-
ately call a qualied service technician to inspect the appliance and to
replace any part of the control system, and any gas control which has
been under water.
A. This appliance is equipped with an ignition system that lights the pilot
burner automatically. Do not attempt to light the pilot by hand.
B. BEFORE LIGHTING smell all around the appliance area for gas. Be sure
to smell next to the oor because some gas is heavier than air and will
settle on the oor.
What To Do If You Smell Gas:
 Do not try to light any appliance.
 Do not touch any electrical switch; do not use any phone in your
building.
 Immediately call your gas supplier from a neighbor's phone. Fol-
low the gas supplier's instructions.
 If you cannot reach your gas supplier, call the Fire Department.
C. Use only your hand to push in or turn the gas control knob. Never use
1. Turn o remote switch.
2. Remove the lower horizontal access panel.
3. Turn the incoming gas control valve to "O".
4. Replace the lower horizontal access panel.
1. STOP! Read the safety information above on this label.
2. Remove the lower horizontal access panel.
3. Turn Incoming gas valve to the ON" position.
4. Wait 5 minutes to clear out any gas. If you smell gas, STOP! Follow "B"
in the safety information above on this label. If you don't smell gas, go
to the next step.
5. Turn wall switch "ON".
6. If the Fireplace does not light, the system will cycle through two trials,
(one minute audible clicking, thirty seconds of silence, and then
another one minute of audible clicking). If the system locks out due to
inadequate gas ow, refer to "Troubleshooting Section".
7. After completion of the information in the Troubleshooting section,
Repeat step 5.
8. If the system will not function correctly, follow the instructions "To Turn
O Gas To Appliance" and call your service technician or gas supplier.
EV1 (pilot
burner)
EV2 (main
burner)
Pilot Adjustment Screw
Lockout Reset Key
Diagnostic Terminal
Power
Command
(wall switch)
Pilot Sensor
Igniter
Ground
EV1 (pilot burner)
EV2 (main burner)
Gas "Out"
Gas "In"
Incoming Gas
Line, Shut-o
Valve
To replace
main burner
For Your Safety - READ BEFORE LIGHTING:

Page 19
DV52 Gas Fireplace
rev.101207
Maintenance
General
• Have the replace and installation inspected yearly. The inspection must
include, but is not limited to, the following:
• A visual check of the entire vent system and termination.
• An inspection of the explosion relief appers and the door gasketing to
ensure a proper seal.
• An inspection of the burner, venturi, and primary air openings.
• An inspection of the gas valve, gas components, and pilot ame. For your
convenience a ⁄" manifold pressure tap is supplied on the gas valve for a
test gauge connection. See Figure 32.
• Inspection of all optional equipment; fans, thermostats, etc.
• For Natural Gas this appliance requires a minimum inlet pressure of 5.5" w.c.
and a manifold pressure of 3.5" w.c.
• For Propane Gas this appliance requires a minimum inlet pressure of 11" w.c.
and a manifold pressure of 10" w.c.
• Always keep the replace area clear and free of combustible materials, as well
as gasoline and other ammable vapors and liquids.
• Do not use this appliance if any part has been under water. Immediately call a
qualied service technician to inspect the appliance and to replace any part of
the control system and any gas control which has been under water.
Operation
Lighting Instructions
See pages 17 and 18.
Burner Adjustment
The DV 52 and DV 52 E are equipped with an adjustable burner, allowing you to raise
or lower the ames. To adjust the ames, locate the black knob marked 'Hi-Lo', in the
center of the gas control valve (See Figure 32). The front burners are not adjustable.
• To raise the ame height, turn the black knob (located behind the lower trim)
counter-clockwise.
• To lower the ame height, turn clockwise.
Figure 32. 'Hi-Lo' Adjustment on the DV 52 gas valve.
Cleaning
When the replace is rst activated, there may be some smoking and a visible lm
may be left on the glass. This is a normal condition, and is the result of burning of
protective coatings on new metal.
• Glass must be cleaned periodically to remove any lm (which is a normal
by-product of combustion) which may be visible. Film can easily be removed
after removing the door, as shown on page 15. Handle the door carefully, and
clean it with non-abrasive glass cleaners. We recommend Stove Bright® Gas
Appliance Glass Cleaner by Forrest Paint Co. Follow the instructions for use and
do not clean the glass when it is hot! If the glass becomes coated with deposits
which cannot be removed it must be replaced.
• Silicone seals on inner door during initial ring will "o gas", leaving a visual
deposit of a white substance on combustion chamber walls. This can easily be
removed using normal household products.
• Use a vacuum cleaner or whisk broom to keep the control compartment, burner,
and rebox free from dust and lint.
• Linear burners may be cleaned periodically with a vacuum to remove soot or
other contaminates.
'Hi-Lo' Adjustment Knob
CAUTION!
 Fireplace gas control must be in the “OFF” position and pilot and main
burners extinguished when cleaning appliance with a vacuum.
 Doors can get very hot. Handle only when cool.
WARNING!
Do not attempt to clean glass when hot.
Do not clean glass with abrasive materials as any glass etching may
cause premature glass failure.

Page 20
DV52 Gas Fireplace
rev.101207
Maintenance
Gas Control Valve
Manifold Pressure
Test Connection
Pilot Adjustment Screw
Inlet
Pressure
Power
Generator
Wall Switch
Figure 33. Sit Nova 820 gas valve.
Pilot Burner Adjustment
1. Locate Pilot Adjustment Screw. (See Figure 33.)
2. Adjust pilot screw to provide properly sized ame as shown in
Figure 34).
3. After installing or servicing, leak test with a soap solution with main burner
on. Coat pipe and tubing joints, gasket etc. with soap solution. Bubbles
indicate leaks. Tighten any areas where the bubbles appear until the bubbling
stops completely.
Figure 34. Pilot Burner.
Troubleshooting
The following is a troubleshooting chart of possible problems:
PROBLEM CORRECTIVE ACTION
Noisy Pilot Flame Locate pilot adjustment screw on
gas control valve. Flame is decreased by turn-
ing adjustment screw clockwise.
Pilot won’t ignite Disconnect remote wires and try to light
pilot. If pilot now works, remote connections
are faulty. Check Figure 33 wiring diagram.
Main burner will 1. Check wiring, see Figure 33.
not light 2. Check wall switch for proper connection.
All service and repairs should be performed by a qualied agency.
All spare parts, optional parts and accessories are available from your local dealer
or the manufacturer.
DV 52 E
DV 52
Troubleshooting
Follow this information to reset the SIT system:
1. Locate the lead to the battery backup, (remove)
(Refer to schematic, below)
2. Locate the AC/DC wall transformer, (Unplug connector)
(Refer to schematic, below)
If your replace still does not operate correctly, consult your dealer or the manu-
facturer.
1.
2.
DV 52 DV 52 E
NG Gas Valve RGC1006 RGC3033
NG Pilot RPA020 RPA052
NG Burner RBL5201 RBL5201
NG Orice ROR ROR
LP Gas Valve RGC1005 RGC3034
LP Pilot RPA021 RPA053
LP Burner RBL5202 RBL5202
LP Orice ROR1152 ROR1152
Door RDTL52 RDTL52
Base RLG554 RLG554
Spare Parts
