Thetford SPINFLO S-FI24000 Specification sheet

BUILD IN APPLIANCES
FOR USE WITH LIQUIFIED PETROLEUM GAS (LPG) OR NATURAL GAS
CAUTION – ALL OUTER SURFACES WILL GET HOT WHEN IN USE
GAS FIRE MODELS
S~FI24000 (LPG)
S~FI24000NG (Natural Gas)
INS 1008 Issue 1
INSTALLATION, USE &
MAINTENANCE
SPINFLO LIMITED, Unit 19, Oakham Drive, Parkwood Industrial Estate
Rutland Road, Sheffield S3 9QX, ENGLAND.
TEL: + 44 (0) 114 273 8157 FAX: + 44 (0) 114 275 3094

2
MODEL S~FI24000 S~FI24000NG
Gas Type LPG
(G30 & G31) NATURAL GAS (G20)
Size, mm H x W x D H x W x D
Fire Front
602 x 498 x 89 602 x 498 x 89
R
ear Box
542 x 383 x 158 542 x 383 x 158
Total Input 3.8kW 3.8kW
Gas Rate 0.365m
3
/hr 0.365m
3
/hr
Efficiency Class 1 Class 1
Injector Size Ø1.0mm Ø1.4mm
Ignition INTEGRAL PIEZO INTEGRAL PIEZO
Voltage N/A N/A
Nox Rating @ 0% O
2
, 171.83 mg/kWh
Gas Category
CAT I
3 + (28-30/37)
CAT I
3 B/P (30)
CAT I
2 H(20)
Butane (G30) 28-30mbar BUTANE (G30) 30mbar Natural Gas
Propane (G31) 37mbar Propane (G31) 30mbar (G20) 20mbar
•Only use with LPG or Natural Gas as specified above
•Only use the gas pressures as specified above

3

4

5
This appliance must be installed in accordance with the local, national and European
regulations in force. Particular attention shall be given to the requirements regarding
ventilation. Read the instructions before installing or using the appliance. The
appliance MUST be installed by an approved competent person.
Failure to install the appliance correctly could invalidate any warranty or liability claims and
lead to prosecution. Please refer to the methods of installation within this handbook.
Our policy is one of continuous development and improvement. Specifications and
illustrations may change subsequent to publication.
PROVISION OF VENTILATION
The use of a gas appliance results in a production of heat and moisture in a room in which it
is installed. Ensure the room is well ventilated, keep natural ventilation holes open or install a
mechanical ventilation device, (mechanical extractor fan).
Prolonged intensive use of the appliance may call for additional ventilation, for example
opening a window, or more effective ventilation, for example increasing the level of
mechanical ventilation where present.
The room containing the fire should have an air supply in accordance with local and
national/European standards.
POSITION
This appliance must be positioned free from draughts, which may affect the combustion, and
in a manner that will prevent the accumulation of unburnt gas. When in use ensure that air
vents are not inadvertently blocked or shut off.
The burner on this appliance has fixed aeration and no adjustment is required. Depending on
the gas being used, the burners should flame as follows: -
Propane - The flames should burn quietly with a blue/green colour with no sign of yellow
tips.
Butane - Normally on initial lighting, a small amount of yellow tipping will occur and then
slightly increases as the burner heats up.
Natural gas - The flames should burn with a blue/green colour with no sign of yellow tips.
INTRODUCTION GB
LP
G
(
GAS
) APPLIANCES MUST
NOT BE INSTALLED BELOW
GROUND LEVEL. E.G. IN A BASEMENT.
OPERATION
THE APPLIANCE IS FITTED WITH AN OXYGEN DEPLETION SENSOR AS
STANDARD. THE SENSOR WILL EXTINGUISH THE FLAME IF
EVACUATION OF THE COMBUSTION PRODUCTS IS INTERRUPTED.
IF THE OXYGEN DEPLETION SENSOR OPERATES REPEATEDLY TURN
OFF THE GAS AND CONTACT YOUR DEALER.

6
Ensure the gas cylinder is turned on. In the event of a gas smell, turn off at the cylinder and
contact supplier.
IGNITION
(1) Press in the control knob. (2) Keeping the control knob pressed in rotate the knob anti-
clockwise, until the spark igniter clicks twice. (3) Ensure the pilot and main burner flames
are established, keep the knob pressed for approximately fifteen seconds then release.
(4) If burner ignition fails return the knob to ‘OFF’ position, wait one minute before repeating
above sequence holding the knob depressed for longer.
FLAME SETTINGS
(1) Light the fire following ignition sequence above. (2) After ignition the setting of the fire is
on LOW Flame. (3) To adjust to High Flame, rotate the knob fully anti-clockwise until it
comes to a stop. (4) To turn the fire off, rotate the knob fully anti-clockwise until the line on
the knob is adjacent to the ‘dimple’ on the fire grate.
DO'S AND DON'TS
DO read the user instructions carefully before using the appliance for the first time.
DO allow the fire to burn off for one hour to expel any smells or lubricants.
DO clean the appliance regularly with a damp cloth, only when the fire has cooled down.
DO check that controls are in the off position when finished.
DO have the appliance serviced at least once a year.
DO check periodically that the air vents and flue are clear from obstructions.
DO NOT allow children near the fire when in use.
DO NOT use abrasive cleaners or powders that will scratch the surfaces of the fire.
DO NOT during operation touch any parts of the fire other than the control knob.
LEAKS
If a smell of gas becomes apparent, the supply should be turned off at the cylinder
IMMEDIATELY. Extinguish naked lights including cigarettes and pipes. Do not operate
electrical switches. Open all doors and windows to disperse any gas escape.
Butane/Propane gas is heavier than air; any escaping gas will therefore collect at a low level.
The strong unpleasant smell of gas will enable the general area of the leak to be detected.
Check that the gas is not escaping from an unlit appliance
MAINTENANCE
This appliance needs little maintenance other than cleaning. All parts should be cleaned
using either a duster or a damp cloth. Do not use abrasive cleaners, steel wool or cleansing
powders. The control knob is a push fit and can be removed for cleaning.
OPERATION
•
IF FOR ANY REASON THE FLAME SHOULD GO OUT DO NOT
ATTEMPT TO RE-IGNITE THE BURNER FOR AT LEAST THREE
MINUTES.
•NEVER CHECK FOR LEAKS WITH A NAKED FLAME.
•NEVER USE SOAPY WATER FOR LEAK DETECTION, SALT AND
OTHER INGREDIENTS IN SOAP CAN SERIOUSLY DAMAGE THE
PRECISION COMPONENTS OF THE FIRE

7
Regulations and Standards
These installation and service instructions are intended for use by an approved competent
person only. If you are not competent then you must not attempt any of the following
procedures.
Before installation, ensure that the local distribution conditions (identification of type of gas
and pressure) and the adjustment of the appliance are compatible. All local and
National/European standards in force must be adhered to.
Failure to install the appliance correctly could invalidate any warranty or liability claims and
lead to prosecution. Particular attention shall be given to the requirements regarding
ventilation. Read the instructions before installing or using this appliance.
Location of Appliance
The appliance maybe installed in a lounge/lounge diner but NOT in a room containing a bath
or a shower. LPG (Gas) appliances must NOT be fitted below ground level. e.g. in a
basement.
Ventilation
This appliance is suitable for installation into Holiday Homes only. In all cases the national
standards with regard to ventilation for the particular vehicle into which the appliance is to be
installed must be adhered to.
The flue cavity MUST be ventilated, we recommend a flue terminal with integrated vent
(Please contact Spinflo by Thetford for details) or by a vent in the wall. The gas escape vent
should be positioned as detailed on the included installation drawings and MUST be baffled
to prevent direct draught to the fire.
The vents MUST comply to the following dimensions:-
High Level Vent Flue Terminal with integrated vent
OR
Wall vent (5000 sq mm Min - 6000 sq mm Max Size)
Gas Escape Vent 5000 sq mm (Minimum Size)
14400 sq mm (Maximum Size)
INSTALLATION
GB
•
THIS APPLIANCE MUST BE INSTALLED INTO A VENTILATED
ENCLOSURE WHICH MEETS THE SPECIFICATION DETAILED
WITHIN THIS HANDBOOK. HOLES FOR CABLES AND PIPES
MUST BE SIZED TO MINIMIZE AIR LEAKAGE BETWEEN
COMPARTMENTS.
•
THE GAS SUPPLY INPUT PRESSURE TO WHICH THIS APPLIANCE
IS CONNECTED, MUST NOT RISE OR FALL BY MORE THAN
2.5 MBAR (BUTANE/PROPANE)
1.0 MBAR (NATURAL GAS)
FROM NOMINAL, WHEN ALL CONNECTED APPLIANCES ARE
OPERATED SIMULTANEOUSLY.

8
POSITION
All models must be installed and positioned on a hearth with a minimum distance of 60mm
from the outside of the surround trim to the outside of the hearth. The hearth should also
extend a minimum of 60mm from the front of the grate – see Fig. 2.
If the fire is to be installed with a shelf/curtain above, the shelf/curtain must be a minimum of
100mm above the surround trim and not exceed 160mm in depth – see Fig. 2.
Fires produce high levels of heat during use. It is important the installer verifies the furniture
construction material is suitable for the application - i.e. Plastic materials used in the
construction may have a softening point lower than the maximum allowable temperature rise
specified in the relevant European Standards (EN13278)
This appliance must be positioned free from draughts, which may affect the combustion, and
in a manner that will prevent the accumulation of unburnt gas. When in use ensure that air
vents are not inadvertently blocked or shut off.
FIXINGS
The aperture for the appliance is 560mm high by 421mm wide, and the appliance is fixed as
shown in Fig. 5. The flue pipe must be fixed to the rear outlet of the appliance and to the flue
terminal by the use of the worm drive clips provided.
Where installations do not allow a vertical rise of the flue pipe directly behind the appliance
the flue pipe MUST be incline towards the flue terminal rising to vertical as soon as possible.
If the appliance cabinet is unusually deep then the flue pipe must rise with a minimum
gradient of 10º.
Fire surround must fit flush against fire front and provide rigid mounting for the fire securing
brackets.
GAS CONNECTION
The connection is made to an Ø8mm inlet pipe through the rear case of the fire. The fire
MUST be connected using metal pipe manufactured from either copper, seam welded steel,
seamless steel or stainless steel, which complies with the requirements detailed within
EN1949. Rubber tubing must NOT be used.
INSTALLATION
GB
•
INLET COMPRESSION JOINT – ASSEMBLE ONTO PIPE AND
TIGHTEN NUT BY HAND. WHILST HOLDING PIPE IN POSITION,
TIGHTEN NUT BY SPANNER 1 FULL TURN (6 FLATS). CHECK
FOR LEAKS. IF NECESSARY NUT CAN BE TURNED A FURTHER 2
FLATS TO ACHIEVE SEAL. MAX TURN = 8 FLATS
•IF JOINT CANNOT BE MADE GAS TIGHT, NUT, OLIVE AND PIPE
MUST BE REPLACED WITH NEW PARTS.
•FLUE PIPE SUPPLIED WITH FIRE IS THE ONLY PIPE THAT
SHOULD BE USED.
•FLUE TERMINAL SUPPLIED IS THE ONLY TYPE THAT CAN BE
USED WITH THE FIRE.

9
OPERATIONAL TESTS
1. Ensure the gas cylinder is turned on.
2. Check the ignition functions correctly and the pilot remains lit
3. Turn to high rate, check function correct.
4. Turn off, check flame extinguished and knob position correct
5. Test For Spillage
THIS TEST MUST BE CARRIED OUT BEFORE THE INSTALLATION
IS PASSED OVER TO THE CUSTOMER.
•Ensure all doors and windows to the room containing the fire are closed.
•Ignite the fire and turn on to full rate as previously described.
•After a period of between ten and fifteen minutes, a lighted smoke match
should be held adjacent to the fire outlet, central to the middle radiant,
halfway between the radiant and the front of the radiant housing canopy. Use
an extension tube to hold the match and ensure that smoke is drawn into the
fire outlet. Figs 3 & 4 show the correct and incorrect positions for the match.
•If smoke is drawn into the outlet then the flue assembly is working correctly, if
not then check the following points:-
- The flue pipe has been properly sealed.
- That there is not a blockage in either the flue pipe or terminal.
•The test should be repeated after an interval of at least a further fifteen
minutes and if still unsatisfactory advice should be sought from the supplier.
•If an extractor fan is fitted in the same or adjacent room as the fire, then the
test should be carried out with the fan switched on.
FINAL CHECKS
1. Ensure all removable panels are securely attached.
2. Clean off any marks or dust that may have occurred during installation.
3. Ensure installation and user instructions are available for the owner.
INSTALLATION GB
•
AFTER INSTALLATION THE APPLIANCE MUST BE TESTED
FOR GAS SOUNDNESS.
•DO NOT OVER TIGHTEN GAS JOINTS.
•IF THE FIRE IS REMOVED FOR SERVICING, REMAKE BY
HAND THE EXISTING INLET CONNECTION UNTIL THE NUT
IS TIGHT ON THE OLIVE. JOINT CAN THEN BE MADE GAS
TIGHT BY TURNING NO MORE THAN 2 FLATS USING A
SPANNER

10
ALL SERVICING MUST BE CARRIED OUT BY AN APPROVED COMPETENT PERSON
AFTER EACH SERVICE THE APPLIANCE MUST BE CHECKED FOR GAS SOUNDNESS
1. Remove front cover from appliance
Turn off gas supply. Remove the push fit control knob. Remove fixing screws
located below top deflector. Pull top of cover away from fire and lift off.
2. Remove appliance from housing
Perform step (1). Disconnect gas supply from fire. Remove four fixing screws from
fixing brackets (fig. 5). Pull fire out of opening until access to flue pipe is gained.
Loosen worm drive clip and pull flue pipe away from fire.
3. Control replacement
Perform step (1). Disconnect gas supply from fire. Unscrew burner pipe, pilot pipe
and thermocouple and remove from the control. Disconnect spark ignition lead
from spark electrode by pulling. Unscrew locknut from mounting bracket and
remove control. Replace control and repeat above operations in reverse.
4. Burner replacement
Perform step (1). Disconnect gas supply. Unscrew the screw that attaches the pilot
assembly to the burner. Remove the locknut from the injector assembly. Then
remove the two screws, which attach the burner to the radiant housing. Remove
the burner. Replace burner and repeat above operations in reverse.
5. Burner injector replacement
Perform step (1). Disconnect gas supply. Remove the locknut from the injector
assembly. Disconnect burner pipe from control tap and remove pipe/injector.
Replace pipe/injector and repeat above operations in reverse.
6. Thermocouple replacement
Perform step (1). Disconnect gas supply. Disconnect thermocouple from control
tap. Remove screw and retaining flange from pilot assembly. Remove
thermocouple. Replace thermocouple and repeat above operations in reverse.
7. ODS / pilot replacement
Perform step (1). Disconnect gas supply. Disconnect pilot pipe from control tap.
Remove screw and retaining flange from pilot assembly. Remove ODS / pilot.
Replace ODS and repeat above operations in reverse.
8. Radiant replacement
Perform step (1). Remove fixing screws from the radiant retainer – Fig 7, lift off
retainer. Remove and replace radiants, repeat above operations in reverse.
SERVICE GB
AT LEAST ONCE EVERY 12 MONTHS THE FIRE, FLUE & TERMINAL
SHOULD BE CHECKED FOR CORRECT OPERATION.
