Thinkware T700 User manual

This product records videos while the vehicle is operating.
Read and follow the instructions in this guide to properly use and maintain the product.
User Guide
T700

Before using the product
About the product
This product records videos while the vehicle is operating. Use this product only for reference when
investigating incidents or road accidents. This product is not guaranteed to record or process cloud data
for all events. The device may not record accidents with impacts that are too minor to activate the impact
sensor or accidents with massive impacts that cause the vehicle’s battery voltage to deviate.
Video recording does not begin until the product is completely turned on (booted up). To ensure that all
vehicle events are recorded, wait until the product is completely booted up after turning it on, and then
begin operating the vehicle.
THINKWARE is not responsible for any loss caused by an accident, nor is it responsible for providing any
support regarding the outcome of an accident.
Depending on the vehicle’s configuration or operating conditions, such as the installation of remote door
lock devices, ECU settings, or TPMS settings, some product features may not be supported, and different
firmware versions may influence the product’s performance or features.
About the user guide
The information provided in the guide may change when the manufacturer updates its service policy.
This user guide is intended for THINKWARE T700 models only, and it may contain technical errors, editorial
errors, or missing information.
Copyrights
All rights for the content and maps in this guide are reserved by THINKWARE and are protected under
copyright laws. All unauthorized duplication, revision, publication, or distribution of this guide without
written consent from THINKWARE is prohibited and is eligible for criminal charges.
Registered trademarks
THINKWARE T700 is a registered trademark of THINKWARE.
Other product logos and service names in this guide are trademarks of the relevant companies.
AD160016211
211-161102
D 19 0055 201
201-190188

3
Contents
Safety information 4
1. Product overview 7
1.1 Included items 7
1.1.1 Standarditems 7
1.1.2 Accessories(soldseparately) 7
1.2 Part names 8
1.2.1 Frontcamera(mainunit)-frontview 8
1.2.2Frontcamera(mainunit)-rearview 9
1.2.3Rearcamera 9
1.3 Removing and inserting the memory card 10
1.4 Removing and inserting the nano SIM card 10
2. Installing the product 11
2.1 Installing the front camera (main unit) 11
2.1.1 Selectinganinstallationlocation 11
2.1.2Securingtheproduct 11
2.1.3Connectingthepowercable 13
2.2 Installing the rear camera 16
2.2.1Selectinganinstallationlocation 16
2.2.2Securingtherearcamera 17
2.2.3Connectingtherearcameracable 18
3. Using recording features 19
3.1 Turning the product on or off 19
3.2 Learning about the LED indicator status and
file storage locations 19
3.3 Using the continuous recording feature 20
3.4 Recording manually 20
3.5 Using parking mode 21
3.6 Using the SOS recording feature 22
3.7 Using the Super Night Vision 23
3.8 Using the road safety features 23
4. Using THINKWARE CONNECTED LTE 24
4.1 Connecting the product to THINKWARE
CONNECTED LTE 24
4.2 Viewing the THINKWARE CONNECTED LTE
screen layout 25
5. Using the mobile viewer 26
5.1 Connect the product to a smartphone 26
5.2 Viewing the mobile viewer screen layout 26
6. Using the PC viewer 27
6.1 System requirements 27
6.2 Learning about the PC viewer 27
6.2.1InstallingthePCviewer 27
6.2.2PCviewerscreenlayout(forWindows) 28
6.2.3 Playing recorded videos on the PC
viewer(forWindows) 29
6.2.4PCviewerscreenlayout(forMac) 30
6.2.5 Playing recorded videos on the PC
viewer(forMac) 31
7. Settings 32
7.1 Managing the memory card 32
7.2 Setting the Camera 32
7.3 Setting recording features 32
7.4 Setting road safety features 33
7.5 Configuring the system settings 34
7.6 Configuring network function settings 34
8. Accessing the product information 35
8.1 Viewing the product information 35
8.2 Accessing and configuring the GPS 35
9. Upgrading the firmware 36
10. Troubleshooting 37
11. Specifications 38

4
Safety information
Read the following safety information to properly use the product.
Safety symbols in this guide
"Warning" - Indicates a potential hazard which, if not avoided, may result in injury or death.
"Caution" - Indicates a potential hazard which, if not avoided, may result in minor injury or property damage.
"Note" - Provides useful information to help users better utilize the product’s features.
Safety information for proper use
Driving and product operation
• Do not operate the product while driving a vehicle. Distraction while driving may cause accidents and
result in injury or death.
• Install the product in places where the driver’s view is not obstructed. Obstruction of the driver’s vision
may cause accidents and result in injury or death. Check with your state and municipal laws before
mounting the product to the windshield.

5
Power supply
• Do not operate or handle the power cable with wet hands. Doing so may result in electrocution.
• Do not use damaged power cables. Doing so may result in electrical fire or electrocution.
• Keep the power cable away from all heat sources. Failure to do so may cause the power cord insulation to
melt, resulting in electrical fire or electrocution.
• Use the power cable with the correct connector and make sure the power cable is connected securely
and is firmly in place. Failure to do so may result in electrical fire or electrocution.
• Do not modify or cut the power cable. Also, do not place heavy objects on the power cable or pull, insert,
or bend the power cable using excessive force. Doing so may result in electrical fire or electrocution.
• Use only genuine accessories from THINKWARE or an authorized THINKWARE dealer. THINKWARE does
not guarantee compatibility and normal operation of third-party accessories.
• When connecting the power cable to the product, ensure that the connection between the cable plug
and the power cable connector on the product is secure. If the connection is loose, the power cable may
become disconnected due to vehicle vibration. Video recording is not available if the power connector is
disconnected.
Children and pets
Ensure that the product is out of the reach of children and pets. If the product breaks, it may result in fatal
damage.

6
Other information about the product
Product management and operation
• Do not expose the product to direct sunlight or intense light. The lens or internal circuitry may fail
otherwise.
• Use the product at a temperature between 14°F and 140°F (-10°C to 60°C) and store the product at a
temperature between -4°F and 158°F (-20°C to 70°C). The product may not function as designed and some
permanent physical damages may result if it is operated or stored out of the specified temperature ranges.
Such damages are not covered by the warranty.
• Frequently check the product for the proper installation position. Impact caused by extreme road
conditions may alter the installation position. Ensure that the product is positioned as instructed in this
guide.
• Do not apply excessive force when pressing the buttons. Doing so may damage the buttons.
• Do not use chemical cleaners or solvents to clean the product. Doing so may damage plastic components
of the product. Clean the product using a clean, soft, and dry fabric.
• Do not disassemble the product or subject the product to impact. Doing so may damage the product.
Unauthorized disassembly of the product voids the product warranty.
• Handle with care. If you drop, mishandle, or expose the product to external shocks, it may cause damage
and/or result in the malfunction of the product.
• Do not attempt to insert foreign objects into the device. Doing so may damage the product.
• Avoid excessive humidity and do not allow any water to enter the product. Electronic components inside
the product may fail if exposed to humidity or water.
• Depending on the make and model of your car, the power may be constantly supplied to the dash cam
even when the ignition is turned off. Installation of the device to a continuously powered 12V outlet could
result in vehicle battery drainage.
• This device is designed to record video while the vehicle is in operation. The quality of the video might be
affected by weather conditions and the road environment, such as whether it is day or night, presence of
street lighting, entering/exiting tunnels, and the surrounding temperature.
• THINKWARE is NOT responsible for the loss of any recorded video during operation.
• Although the device was designed to withstand high-impact car collisions, THINKWARE does not
guarantee the recording of accidents when the device is damaged as a result of the accident.
• Keep the windshield and camera lens clean for optimal video quality. Particles and substances on the
camera lens or windshield may reduce the quality of the recorded videos.
• This device is intended to be used inside the vehicle only.

7
1. Product overview
1.1 Included items
Ensure that all the items are included when you open the product box.
1.1.1 Standard items
ACC
BATTERY
GND
Front camera (main unit) Mount Hardwiring cable Adhesive cable holder
MicroSD memory card
with adapter
(consumable)
Quick start guide & Warranty
/ CS information / User guide
(stored in the microSD card)
Rear camera Rear camera cable
• The standard items may change without prior notice.
• You can use the services provided by the THINKWARE CONNECTED LTE application by installing a
designated nano SIM card (sold with the product) in the product. If a SIM other than an authorized nano
SIM for the THINKWARE CONNECTED LTE application is installed, the service may not operate normally and
THINKWARE will not be responsible for any loss.
1.1.2 Accessories (sold separately)
Car charger
If the product is connected to a vehicle using the car charger, the parking mode features supported on the
THINKWARE mobile applications cannot be used.

Product overview
8
1.2 Part names
1.2.1 Front camera (main unit) - front view
Speaker
Outputs the voice guide and buzzer sounds
to indicate the product’s status.
Power button
• Press and hold
to turn off the
product.
• Press to turn on
the product.
Wi-Fi button
Press to connect
the product to a
smartphone via
Wi-Fi network.
Voice recording button
Press to enable or
disable voice recording.
Manual recording button
• Press to start manual
recording.
• Press to respond to
the request for device
registration on the
THINKWARE CONNECTED
LTE application.
Wi-Fi LED
• Indicates the Wi-Fi
connection status.
• Indicates the SOS
feature status.
LTE LED
• Indicates the LTE
connection status.
• Indicates the SOS
feature status.
SOS button
Press to upload the recorded footage to the THINKWARE
CONNECTED LTE application when an accident occurs.
Microphone
Used for voice recording.
Reset button
Insert the tip of a sharp object to reset the product
when an error occurs.
• To reset the product, press and hold the voice recording ( ) and manual recording (REC) buttons
simultaneously until you hear beeps.
• When you press the SOS button during an accident, the Wi-Fi LED and the LTE LED turn on and flick
simultaneously.
• According to the data service policy, if you have used all of the SOS recording upload usage times,
pressing the SOS button will save the recorded video to the SD card, but may not upload it to the
THINKWARE CONNECTED LTE application.

Product overview
9
1.2.2 Front camera (main unit) - rear view
DC-IN power port
Used to connect
the power cable.
V-IN input port
Used to connect
the rear camera.
Nano SIM card slot
Insert a nano SIM
card to use LTE
connection.
Memory card slot
Insert a memory card to save recordings.
Front camera lens
Records the front view.
Mount connector
Used to connect
the mount.
1.2.3 Rear camera
Adhesive mount
Used to fix the rear camera in the vehicle.
Rear camera lens
Records the rear view.
Security LED
Indicates that the video is being recorded.
Connection port
Used to connect the rear
camera to the front camera
using a rear camera cable.

Product overview
10
1.3 Removing and inserting the memory card
Follow the instructions to remove the memory card from the product or to insert the memory card into the
product.
Before removing the memory card, ensure that the product
is turned off. Gently push the bottom of the memory card
with your fingernail to release it, and then remove it from the
product.
To insert the memory card into the memory card slot, ensure
that the metal contacts on the memory card are facing toward
the product’s buttons, and insert it into the slot until you hear
a click.
• Ensure that the product is turned off before removing the memory card. The recorded video files may be
corrupted or lost if you remove the memory card while the product is on.
• Ensure that the memory card is in the correct direction before inserting it into the product. The memory
card slot or the memory card may be damaged if it is inserted incorrectly.
• Use only authentic memory cards from THINKWARE. THINKWARE does not guarantee the compatibility and
normal operation of third-party memory cards.
To prevent loss of recorded video files, periodically back up the video files on a separate storage device.
1.4 Removing and inserting the nano SIM card
Follow the instructions to remove the nano SIM card from the product or to insert the nano SIM card into
the product.
Before inserting the nano SIM card into the nano SIM card
slot, ensure that the metal contacts on the nano SIM card are
facing toward the product’s mount connector and then insert
it into the slot until you hear a click.
To remove the nano SIM card, ensure that the product is
turned off and gently push the bottom of the nano SIM card
with your fingernail to release it, and then remove it from the
product.
Ensure that the nano SIM card is in the correct direction before inserting it into the product. The nano SIM
card slot or the nano SIM card may be damaged if it is inserted incorrectly.
You can use the services provided on the THINKWARE CONNECTED LTE application by installing a designated
nano SIM card (sold with the product) in the product. If a SIM other than the genuine nano SIM for the
THINKWARE CONNECTED LTE application is installed, the service may not operate normally and THINKWARE
is not responsible for any loss.

11
2. Installing the product
2.1 Installing the front camera (main unit)
Follow the instructions to properly install the product.
2.1.1 Selecting an installation location
Select an installation location that can record the
entire view in front of the vehicle without obstructing
the driver’s vision. Ensure that the front camera lens
is located in the center of the windshield.
20 cm
If a GPS navigating device is installed on the dashboard,
its GPS reception may be affected depending on the
dashboard camera’s installation location.
Adjust the installation location of the GPS navigating
device to ensure that the two devices are separated by
at least 20 centimeters (approximately 8 inches).
2.1.2 Securing the product
Follow the instructions to secure the product at the installation location.
1
1
2
➊➊
➋➋
Align the mount to the mount rail on the product,
and then slide it until you hear a click ( ➊➊ ). Then,
carefully remove the protective film ( ➋➋ ).
2
After determining the installation location, wipe the installation location on the windshield with a dry
cloth.

Installing the product
12
3
2
1
➊➊➋➋
Remove the protective film from the adhesive mount,
and then press the mount to the installation location.
4
2
1
➊➊➋➋
Remove the product from the mount and push the
mount against the windshield to ensure that the
mount is firmly fixed.
5
Align the product to the mount, and then slide it into
the locking position until you hear a click.
• The product may fall and be damaged during
vehicle operation if it is not firmly fixed to the
mount.
• If you need to remove the mount from the
windshield to alter the installation location,
be careful not to damage the windshield’s film
coat.
6
Set the vertical angle of the camera appropriately.
• You can also set the vertical angle of the camera by using a flat-head screwdriver or a coin.
• To confirm the camera angle, record a video after installation and check the video using the mobile
viewer or the PC viewer. If necessary, adjust the camera angle again. For more information about the
mobile viewer or the PC viewer, refer to "5. Using the mobile viewer" on page 26 or "6. Using the PC
viewer" on page 27.

Installing the product
13
2.1.3 Connecting the power cable
When the engine and electrical accessories are turned off, connect the continuous power cable or the
cigar socket power cable (optional) to the product.
Connecting the continuous power cable
ACC
BATTERY
GND
If you connect the product to the vehicle via the
continuous power cable, the camera continues
operating even when the vehicle is not operating
(parking mode). In parking mode, the camera detects
impacts to the vehicle and nearby motion and
records video.
For more information about parking mode, refer to
"3.5 Using parking mode" on page 21.
• The continuous power cable must be professionally installed in the vehicle by a trained mechanic. Contact
an authorized service center to connect the continuous power cable to the vehicle. If the product is not
installed properly, the product may be damaged or an electrical fire or electrocution may occur.
• Use the authentic THINKWARE continuous power cable only. Using other manufacturer’s cable may
damage the product or cause electrocution due to the voltage difference.
• When connecting the continuous power cable, pay special attention to wiring. If the wires are connected
incorrectly, the product or the vehicle may be damaged.
1
Find the vehicle’s fuse box. Usually the fuse box is
installed under the driver’s seat.
The location of the fuse box may differ depending
on the make and model of the vehicle. For more
information, refer to your vehicle’s owner’s manual.
2
Open the fuse box, find the continuous power
terminal (which supplies power when the vehicle
is off) and the ACC terminal (which supplies power
when the ignition status is "ACC ON") by using an
electrical tester, and detach the fuses from the
terminals.

Installing the product
14
3
BATTERY
ACC
Connect the BATTERY wire to a fuse leg of the
continuous power terminal and connect the ACC
wire to a fuse leg of the normal (ACC) terminal.
4
Check the fuse panel’s input and output contact points by using an electrical tester.
5
Place the fuses back into their locations on the fuse panel, connecting each fuse leg with the wire to
the output contact point and taking care not to change the fuse position.
When you install the fuses on the fuse panel, the fuse legs for the BATTERY wire and the ACC wire
must be connected to the output terminals respectively. If the fuse leg with the wire is connected to an
input terminal, the product or vehicle may be damaged or electrical fire may result.
6
GND
Connect the ground wire (the GND wire) to a bolt
attached to a metallic part of the vehicle’s body.
Normally, the metallic bolt that you can
connect the ground wire to (the GND wire) is
fitted nearby fuse box or the driver seat’s door
interior.
7
Connect the continuous power cable to the product’s
DC-IN power connector and start the engine to make
sure the product operates normally.
Once the product is powered on, the LED indicator
and the voice guidance are turned on.

Installing the product
15
8
1/8 1/4
Connect the product to THINKWARE DASH CAM LINK
on your smartphone and adjust the camera angle so
that the hood of the vehicle covers 1/4 - 1/8 of the
screen while viewing the live view screen, as shown
in the image to the left.
For more information about connecting and using the
THINKWARE mobile applications, refer to "5. Using
the mobile viewer" on page 26.
Connecting the car charger (optional)
2
1
➊➊
➋➋
Connect the car charger to the product’s DC-IN power
port and insert the car charger into the vehicle’s power
socket.
• Use the authentic THINKWARE car charger. Use of third party power cables may damage the product and
result in electrical fire or electrocution due to the voltage difference.
• Do not cut or modify the power cable yourself. Doing so may damage the product or the vehicle.
• For safe driving, arrange the cables to prevent the driver’s vision from being obstructed or interfering with
driving. For more information about arranging cables, visit https://www.thinkware.com.
The location and specifications of the power socket may differ by vehicle make and model.

Installing the product
16
2.2 Installing the rear camera
Refer to the following instructions to properly install the rear camera.
2.2.1 Selecting an installation location
Select a location on the rear windshield where there
is no defrost grid wire and the camera can record
the entire rear view.
• For vehicles with a sunshade attached to the rear windshield, you must select a location where using the
sunshade will not interfere with camera operation.
• The adhesive part of the rear camera should not touch the defrost grid.

Installing the product
17
2.2.2 Securing the rear camera
Refer to the following instructions to secure the product to the installation location.
1
After determining the installation location, wipe the installation surface of the windshield with a dry
cloth.
Check the installation location before you secure the rear camera to the rear windshield. After
securing the rear camera to the windshield, it is hard to remove the camera or change the installation
location due to the strong adhesive.
2
1
2
➊➊
➋➋
Remove the protective film from the adhesive mount
and camera lens.
3
THINKWARE
Attach the product with the THINKWARE logo facing
indoors and press the adhesive tape firmly to secure
the camera.
If the product is fixed in reverse, the rear view
will be recorded upside down.
4
THINKWARE
Adjust the camera’s vertical angle.

Installing the product
18
2.2.3 Connecting the rear camera cable
Power off the product and connect the rear camera cable to the front camera (main unit).
1
Connect one end of the rear camera cable to the
front camera’s V-IN port.
2
THINKWARE
Connect the other end of the rear camera cable to
the rear camera’s connection port.
For safe driving, arrange the cables to prevent
the driver’s vision from being obstructed or
interfering with driving.
3
Turn on the ACC or start the engine to check if the product is powered on. After the product is powered
on, the voice guidance will be turned on.
The product is powered on when the ACC mode is turned on or when the engine starts.

19
3. Using recording features
3.1 Turning the product on or off
The product is turned on automatically and continuous recording starts when you turn on the ACC or start
the engine.
Wait until the product is completely booted up after turning it on, and then begin operating the vehicle. The
video recording does not begin until the product is completely turned on (booted up).
3.2 Learning about the LED indicator status and file storage locations
Refer to the following information to learn about the LED indicator status and file storage locations.
Viewing the LED indicator status
You can check the operation status of the product on the LED indicator on the front of the product.
For more information about the operation status of
the product according to the LED indicator, refer
to how to use each recording mode (continuous
recording, continuous incident recording, manual
recording, parking mode, and SOS recording).
Viewing the file storage location
Videos are stored in the following folders according to their recording mode.
On the mobile
viewer Continuous Continuous Incident
Manual
Recording
Motion
Detection
Parking
Incident
SOS
recording
In the memory
card cont_rec evt_rec manual_rec motion_ timelapse_rec parking_rec sos_rec
Play videos on Window/Mac computer or using the THINKWARE mobile applications. If you play videos by
inserting the memory card in devices such as a smartphone or a tablet PC, the video files may be lost.
A file name is composed of the recording start date and time, and the recording option.
REC_2020_07_01_10_25_30_
F.MP4
REC_2020_07_01_10_25_30_R.MP4
REC_2019_07_01_10_25_30_GS.MP4
Recording conditions
• F: Front camera
• R: Rear camera

Using recording features
20
3.3 Using the continuous recording feature
Connect the power cable to the product’s DC-IN power port and then turn on the vehicle’s electrical
accessories or start the engine. The voice guide will indicate that continuous recording has started.
During continuous recording, the product operates as follows.
Mode Operation description LTE LED
Continuous recording During driving, videos are recorded in 1 minute segments
and stored in the "cont_rec" folder.
(light on)
Incident continuous
recording*
When an impact to the vehicle is detected, a video is
recorded for 20 seconds (from 10 seconds before the
detection to 10 seconds after the detection) and stored in
the "evt_rec" folder.
* When an impact to the vehicle is detected during continuous recording, incident continuous recording starts with a
double beep sound.
• If the nano SIM is not connected, the LTE status indicator will be red.
• Wait until the product is completely booted up after turning it on, and then begin operating the vehicle. The
video recording does not begin until the product is completely turned on (booted up).
• When incident continuous recording starts, a double "beep" sounds as a notification.
• To enable recording, you must insert a memory card into the product.
3.4 Recording manually
You can record a scene you want to capture while driving and store it as a separate file.
To start manual recording, press the manual recording (REC)button. Then, the voice guide will indicate that
manual recording has started.
During manual recording, the product operates as follows.
Mode Operation description LTE LED
Manual recording
When you press the manual recording (REC) button, a
video will be recorded for 1 minute (from 10 seconds
before to 50 seconds after pressing the button) and stored
in the "manual_rec" folder.
(light on)
