thomann Stairville AF-250 DMX User manual

AF-250 DMX
Fog Machine
User Manual

Thomann GmbH
Hans-Thomann-Straße 1
96138 Burgebrach
Germany
Telephone: [phone]
Internet: www.thomann.de
11.12.2023, ID: 340945 (V7)

Table of contents
1 General information................................................................................................................................. 5
1.1 Symbols and signal words............................................................................................................... 5
2 Safety instructions..................................................................................................................................... 8
3 Features....................................................................................................................................................... 12
4 Installation.................................................................................................................................................. 13
5 Starting up.................................................................................................................................................. 14
6 Connections and operating elements........................................................................................... 16
7 Operating.................................................................................................................................................... 22
7.1 Remote control functions............................................................................................................. 24
7.2 DMX control....................................................................................................................................... 25
8 Technical specications....................................................................................................................... 26
9 Plug and connection assignments.................................................................................................. 29
10 Troubleshooting...................................................................................................................................... 30
11 Cleaning....................................................................................................................................................... 31
12 Protecting the environment.............................................................................................................. 33
Table of contents
AF-250 DMX 3
Fog Machine

4AF-250 DMX
Fog Machine

1 General information
This document contains important instructions for the safe operation of the product. Read and
follow the safety instructions and all other instructions. Keep the document for future refer‐
ence. Make sure that it is available to all those using the product. If you sell the product to
another user, be sure that they also receive this document.
Our products and documentation are subject to a process of continuous development. They
are therefore subject to change. Please refer to the latest version of the documentation, which
is ready for download under www.thomann.de.
1.1 Symbols and signal words
In this section you will nd an overview of the meaning of symbols and signal words that are
used in this document.
General information
AF-250 DMX 5
Fog Machine

Signal word Meaning
DANGER! This combination of symbol and signal word indicates an
immediate dangerous situation that will result in death or
serious injury if it is not avoided.
WARNING! This combination of symbol and signal word indicates a pos‐
sible dangerous situation that can result in death or serious
injury if it is not avoided.
CAUTION! This combination of symbol and signal word indicates a pos‐
sible dangerous situation that can result in minor injury if it
is not avoided.
NOTICE! This combination of symbol and signal word indicates a pos‐
sible dangerous situation that can result in material and
environmental damage if it is not avoided.
Warning signs Type of danger
Warning – high-voltage.
Warning – ammable substances.
General information
6AF-250 DMX
Fog Machine

Warning signs Type of danger
Warning – hot surface.
Warning - slip hazard.
Warning – harmful or irritating substances.
Warning – danger zone.
General information
AF-250 DMX 7
Fog Machine

2 Safety instructions
This device is intended to be used to produce articial fog by vaporising fog uid. Use the
device only as described in this user manual. Any other use or use under other operating con‐
ditions is considered to be improper and may result in personal injury or property damage. No
liability will be assumed for damages resulting from improper use.
This device may be used only by persons with sucient physical, sensorial, and intellectual
abilities and having corresponding knowledge and experience. Other persons may use this
device only if they are supervised or instructed by a person who is responsible for their safety.
Safety
DANGER!
Risk of injury and choking hazard for children!
Children can suocate on packaging material and small parts. Children can injure themselves when handling the device. Never allow
children to play with the packaging material and the device. Always store packaging material out of the reach of babies and small
children. Always dispose of packaging material properly when it is not in use. Never allow children to use the device without supervi‐
sion. Keep small parts away from children and make sure that the device does not shed any small parts (such knobs) that children
could play with.
DANGER!
Danger to life due to electric current!
Within the device there are areas where high voltages may be present. Never remove any covers. There are no user-serviceable parts
inside. Do not use the device when covers, safety equipment or optical components are missing or damaged.
Intended use
Safety instructions
8AF-250 DMX
Fog Machine

DANGER!
Danger to life due to electric current!
A short circuit could lead to a re hazard and risk of death. Do not modify the mains cable or the plug! In case of isolation damage,
disconnect immediately the power supply and arrange repair. If in doubt, seek advice from a qualied electrician.
WARNING!
Risk of burns from ammable liquids!
The use of ammable liquids in the device may cause severe burns and damage to property. Use only approved fog uids. Never ll
ammable liquids into the tank of the device.
WARNING!
Risk of burns on the hot fog nozzle!
The fog generated on the fog nozzle is hot. Occasionally hot uid drops may escape from the nozzle. The fog nozzle may be hot for
several hours after switching o the device. Skin contact with hot fog and drops of hot liquid can lead to burns. Ensure a minimum
distance of 50 cm to persons and objects during operation. Do not touch the fog nozzle during and immediately after operation.
Before touching the device, always ensure that all surfaces have cooled down suciently.
WARNING!
Slip hazard due to condensate pools!
The fog generated by the fog machine can condense on oors and surfaces. People can slip and injure themselves on pools of con‐
densate. Do not direct the fog to oors or other surfaces that may be stepped on. Regularly check all oors and other surfaces that
can be accessed for slipping hazards. If necessary, remove any pools of condensate.
WARNING!
Health hazard when handling fog uid!
Fog uid contains glycols. There is a health risk in case of eye contact and if uid is swallowed. Keep fog uid in a safe place and out
of the reach of children. Never ingest fog uid and avoid contact with eyes. In case of accidental ingestion of or eye contact with fog
uid: Do not induce vomiting if swallowed. Thoroughly rinse the eyes with water upon contact. Get immediate medical attention.
Safety instructions
AF-250 DMX 9
Fog Machine

CAUTION!
Possible respiratory problems due to fog uid!
Fog uid can lead to respiratory problems in case of prolonged exposure and in certain people. Using unsuitable uids can generate
toxic gases. Do not use any fog uids other than the ones approved for the device. Any claims for compensation for damages caused
by using non-approved uids are excluded. Do not let the device produce fog in poorly ventilated areas. Do not expose people with
health problems (e.g. allergy-related respiratory symptoms, asthma) to articial fog.
NOTICE!
Risk of re due to covered vents and neighbouring heat sources!
If the vents of the device are covered or the device is operated in the immediate vicinity of other heat sources, the device can over‐
heat and burst into ames. Never cover the device or the vents. Do not install the device in the immediate vicinity of other heat
sources. Never operate the device in the immediate vicinity of naked ames.
NOTICE!
Damage to the device if operated in unsuitable ambient conditions!
The device can be damaged if it is operated in unsuitable ambient conditions. Only operate the device indoors within the ambient
conditions specied in the “Technical specications” chapter of this user manual. Avoid operating it in environments with direct sun‐
light, heavy dirt and strong vibrations. Avoid operating it in environments with strong temperature uctuations. If temperature uc‐
tuations cannot be avoided (for example after transport in low outside temperatures), do not switch on the device immediately.
Never subject the device to liquids or moisture. Never move the device to another location while it is in operation. In environments
with increased dirt levels (for example due to dust, smoke, nicotine or mist): Have the device cleaned by qualied specialists at reg‐
ular intervals to prevent damage due to overheating and other malfunctions.
NOTICE!
Damage to the device due to high voltages!
The device can be damaged if it is operated with the incorrect voltage or if high voltage peaks occur. In the worst case, excess vol‐
tages can also cause a risk of injury and res. Make sure that the voltage specication on the device matches the local power grid
before plugging in the device. Only operate the device from professionally installed mains sockets that are protected by a residual
current circuit breaker (FI). As a precaution, disconnect the device from the power grid when storms are approaching or it the device
will not be used for a longer period.
Safety instructions
10 AF-250 DMX
Fog Machine

NOTICE!
Risk of re due to installation of a wrong fuse!
Using fuses of a dierent type than compatible with the device may cause a re and seriously damage the device. Only use fuses of
the same type. Observe the labelling on the device casing and the information in the "Technical data” chapter.
NOTICE!
Possible staining due to plasticiser in rubber feet!
The plasticiser contained in the rubber feet of this product may react with the coating of the oor and cause permanent dark stains
after some time. If necessary, use a suitable mat or felt slide to prevent direct contact between the device’s rubber feet and the oor.
The device was designed for use in professional event technology and works reliably when
used properly. Observe the following information:
nFollow all warnings in these operating instructions.
nNever leave the device running without supervision.
nThe device is not suitable for use in private households or as a child's toy.
nPlace the device on a stable, re-proof basis that is at least twice as large as the device.
nMaintain a safety distance of 1 m to ammable materials.
nThe device is not intended for suspended assembly (the so-called "ying operation").
nDuring operation, ensure that the visibility in the room does not fall below 2 m so that
everyone in the room can still orient themselves safely.
nThe fog or haze generated by the device may trigger smoke alarms.
General information about how
to safely operate fog machines
and hazers
Safety instructions
AF-250 DMX 11
Fog Machine

3 Features
This fog machine is suitable for use in clubs, bars, discotheques and on stages.
Special features of the device:
nSuperior performance by highly ecient heating element
nControl via DMX (one channel) or via the supplied remote control
nSuitable for mobile use due to compact design
nBracket included
Features
12 AF-250 DMX
Fog Machine

4 Installation
Unpack and check carefully there is no transportation damage before using the unit. Keep the
equipment packaging. To fully protect the product against vibration, dust and moisture during
transportation or storage use the original packaging or your own packaging material suitable
for transport or storage, respectively.
Place the device on a stable, re-proof basis that is at least twice as large as the device. The
device requires 20 cm clearance at the sides and above. The unit should be installed horizon‐
tally, a maximum deviation of 15° is allowed.
Installation
AF-250 DMX 13
Fog Machine

5 Starting up
Create all connections while the device is o. Use the shortest possible high-quality cables for
all connections. Take care when running the cables to prevent tripping hazards.
NOTICE!
Data transfer errors due to improper wiring!
If the DMX connections are wired incorrectly, this can cause errors during the data
transfer.
Do not connect the DMX input and output to audio devices, e.g. mixers or ampli‐
ers.
Use special DMX cables for the wiring instead of normal microphone cables.
Starting up
14 AF-250 DMX
Fog Machine

Connect the DMX input of the device to the DMX output of a DMX controller or another DMX
device. Connect the output of the rst DMX device to the input of the second one, and so on
to form a daisy chain. Always ensure that the output of the last DMX device in the daisy chain
is terminated with a resistor (110 Ω, ¼W).
Connections in DMX mode
Starting up
AF-250 DMX 15
Fog Machine

6 Connections and operating elements
&
#
$
&
%
Front panel
Connections and operating elements
16 AF-250 DMX
Fog Machine

1 Fog nozzle
2 Fog uid container with screw-cap
3 Bracket
4 Carrying handle
5 Locking screws for the bracket
Connections and operating elements
AF-250 DMX 17
Fog Machine

PUSH
FUNC ENTER
PUSH
&
(
)
%
$
'
&
/
-
.
#
+
,
*
Rear panel
Connections and operating elements
18 AF-250 DMX
Fog Machine

2 Fog uid container with screw-cap
3 Bracket
4 Carrying handle
5 Locking screws for the bracket
6 Main switch. Turns the device on and o.
7[FUSE] | fuse holder
8 Mains cable for power supply
9 Display with control buttons:
[ENTER] | button to select a menu option and to conrm the entered values
| button to page down in the menu system, and to increase the displayed value
| button to page up in the menu system, and to decrease the displayed value
[FUNC] | button to open the menu control
10 [DMX OUT] | DMX output
11 [DMX IN] | DMX input
12 [REMOTE CONTROL] | connection for the receiver of the wireless remote control (optionally available, item no. 464052)
13 [WIRE CONTROL] | connection for the wired remote control
14 Liquid level indicator.
Connections and operating elements
AF-250 DMX 19
Fog Machine

0
3
4
2
1
5
Remote control
