thomann STAIRVILLE M-Fog 3000 Pro User manual

M-Fog 3000 Pro
fog machine
user manual

Musikhaus Thomann
Thomann GmbH
Hans-Thomann-Straße 1
96138 Burgebrach
Germany
Telephone: [phone]
E-mail: [email protected]
Internet: www.thomann.de
05.10.2021, ID: 526628

Table of contents
1 General information................................................................................................................................. 5
1.1 Further information........................................................................................................................... 6
1.2 Notational conventions.................................................................................................................... 7
1.3 Symbols and signal words............................................................................................................... 9
2 Safety instructions.................................................................................................................................. 12
3 Features....................................................................................................................................................... 17
4 Installation.................................................................................................................................................. 18
5 Starting up.................................................................................................................................................. 19
6 Connections and controls................................................................................................................... 21
7 Operating.................................................................................................................................................... 28
7.1 Basic settings..................................................................................................................................... 30
7.2 Manual control.................................................................................................................................. 33
7.3 Device information.......................................................................................................................... 36
7.4 Reset to factory default setting................................................................................................... 37
8 Technical specications....................................................................................................................... 38
Table of contents
M-Fog 3000 Pro
3

9 Troubleshooting...................................................................................................................................... 41
10 Cleaning....................................................................................................................................................... 43
11 Protecting the environment.............................................................................................................. 45
Table of contents
fog machine
4

1 General information
This user manual contains important information on the safe operation of the device. Read and
follow all safety notes and all instructions. Save this manual for future reference. Make sure
that it is available to all persons using this device. If you sell the device to another user, be sure
that they also receive this manual.
Our products and user manuals are subject to a process of continuous development. We there‐
fore reserve the right to make changes without notice. Please refer to the latest version of the
user manual which is ready for download under www.thomann.de.
General information
M-Fog 3000 Pro
5

1.1 Further information
On our website (www.thomann.de) you will nd lots of further information and details on the
following points:
Download This manual is also available as PDF le for you to download.
Keyword search Use the search function in the electronic version to nd the topics of
interest for you quickly.
Online guides Our online guides provide detailed information on technical basics
and terms.
Personal consultation For personal consultation please contact our technical hotline.
Service If you have any problems with the device the customer service will
gladly assist you.
General information
fog machine
6

1.2 Notational conventions
This manual uses the following notational conventions:
The letterings for connectors and controls are marked by square brackets and italics.
Examples: [VOLUME] control, [Mono] button.
Texts and values displayed on the device are marked by quotation marks and italics.
Examples: ‘24ch’ , ‘OFF’ .
Letterings
Displays
General information
M-Fog 3000 Pro
7

The individual steps of an instruction are numbered consecutively. The result of a step is
indented and highlighted by an arrow.
Example:
1. Switch on the device.
2. Press [Auto].
ðAutomatic operation is started.
3. Switch o the device.
References to other locations in this manual are identied by an arrow and the specied page
number. In the electronic version of the manual, you can click the cross-reference to jump to
the specied location.
Example: See Ä ‘Cross-references’ on page 8.
Instructions
Cross-references
General information
fog machine
8

1.3 Symbols and signal words
In this section you will nd an overview of the meaning of symbols and signal words that are
used in this manual.
Signal word Meaning
DANGER! This combination of symbol and signal word indicates an
immediate dangerous situation that will result in death or
serious injury if it is not avoided.
WARNING! This combination of symbol and signal word indicates a pos‐
sible dangerous situation that can result in death or serious
injury if it is not avoided.
CAUTION! This combination of symbol and signal word indicates a pos‐
sible dangerous situation that can result in minor injury if it
is not avoided.
NOTICE! This combination of symbol and signal word indicates a pos‐
sible dangerous situation that can result in material and
environmental damage if it is not avoided.
General information
M-Fog 3000 Pro
9

Warning signs Type of danger
Warning – high-voltage.
Warning – ammable substances.
Warning – hot surface.
Warning - slip hazard.
Warning – harmful or irritating substances.
General information
fog machine
10

Warning signs Type of danger
Warning – danger zone.
General information
M-Fog 3000 Pro
11

2 Safety instructions
This device is intended to be used to produce articial fog by vaporising fog uid. Use the
device only as described in this user manual. Any other use or use under other operating con‐
ditions is considered to be improper and may result in personal injury or property damage. No
liability will be assumed for damages resulting from improper use.
This device may be used only by persons with sucient physical, sensorial, and intellectual
abilities and having corresponding knowledge and experience. Other persons may use this
device only if they are supervised or instructed by a person who is responsible for their safety.
Safety
DANGER!
Danger for children
Ensure that plastic bags, packaging, etc. are disposed of properly and are not within reach of babies and young children. Choking
hazard! Ensure that children do not detach any small parts (e.g. knobs or the like) from the unit. They could swallow the pieces and
choke! Never let children unattended use electrical devices.
Intended use
Safety instructions
fog machine
12

DANGER!
Electric shock caused by high voltages inside
Within the device there are areas where high voltages may be present. Never remove any covers. There are no user-serviceable parts
inside. Do not use the device if covers, protectors or optical components are missing or damaged.
DANGER!
Electric shock caused by short-circuit
Do not modify the mains cable or the plug. Failure to do so could result in electric shock/death or re. If in doubt, seek advice from a
registered electrician.
WARNING!
Risk of burns from ammable liquids
The use of ammable liquids in this device may cause severe burns and damage to property. Always use approved fog uids. Never
ll ammable liquids into the tank of the device.
WARNING!
Risk of burns
The generated fog at the fog nozzle is hot and can cause burns. Occasionally hot uid drops may escape from the nozzle. The dis‐
tance of persons and objects to the fog nozzle must be at least fty centimetre (1.6 feet). Do not touch the fog nozzle during and
shortly after operation. It becomes very hot and may cause burns even several hours after switching o the device.
Safety instructions
M-Fog 3000 Pro
13

WARNING!
Risk of slipping caused by condensate
Fog machines can produce condensate. Do not direct the fog to oors. Floors and surfaces can become slippery by condensed fog.
Check regularly that all oors can be accessed without slipping hazard and remove any condensate, if necessary.
WARNING!
Health hazard caused by fog uid handling
Fog uid does contain glycols complying with the regulations for foodstus. However, it may be harmful if swallowed. Do not induce
vomiting. Seek medical advice immediately. Keep fog uid in a safe place. If the fog uid comes into contact with eyes rinse thor‐
oughly with water.
CAUTION!
Possible respiratory problems
The device can be operated safely only with the approved fog uid. The use of other uids can release toxic gases. Claims for dam‐
ages caused by the use of non-approved uids shall be excluded. Do not create fog in closed or poorly ventilated areas. Do not
expose persons with health problems (such as allergic respiratory conditions, asthma) to articial fog.
NOTICE!
Risk of re
Do not block areas of ventilation. Do not install the device near any direct heat source. Keep the device away from naked ames.
Safety instructions
fog machine
14

NOTICE!
Operating conditions
This device has been designed for indoor use only. To prevent damage, never expose the device to any liquid or moisture. Avoid
direct sunlight, heavy dirt, and strong vibrations. Only operate the device within the ambient conditions specied in the chapter
‘Technical specications’ of this user manual. Avoid heavy temperature uctuations and do not switch the device on immediately
after it was exposed to temperature uctuations (for example after transport at low outside temperatures). Dust and dirt inside can
damage the unit. When operated in harmful ambient conditions (dust, smoke, nicotine, fog, etc.), the unit should be maintained by
qualied service personnel at regular intervals to prevent overheating and other malfunction.
NOTICE!
Power supply
Before connecting the device, ensure that the input voltage (AC outlet) matches the voltage rating of the device and that the AC
outlet is protected by a residual current circuit breaker. Failure to do so could result in damage to the device and possibly injure the
user. Unplug the device before electrical storms occur and when it is unused for long periods of time to reduce the risk of electric
shock or re.
NOTICE!
Possible damage due to installation of a wrong fuse
The use of dierent types of fuses can cause serious damage to the unit. Fire hazard! Only fuses of the same type may be used.
Safety instructions
M-Fog 3000 Pro
15

NOTICE!
Possible staining
The plasticiser contained in the rubber feet of this product may possibly react with the coating of your parquet, linoleum, laminate
or PVC oor and after some time cause permanent dark stains. In case of doubt, do not put the rubber feet directly on the oor, but
use felt-pad oor protectors or a carpet.
The device was designed for use in professional event technology and works reliably when
used properly. Observe the following information:
nFollow all warnings in these operating instructions.
nNever leave the device running without supervision.
nThe device is not suitable for use in private households or as a child's toy.
nPlace the device on a stable, re-proof basis that is at least twice as large as the device.
nMaintain a safety distance of 1 m to ammable materials.
nThe device is not intended for suspended assembly (the so-called "ying operation").
nDuring operation, ensure that the visibility in the room does not fall below 2 m so that
everyone in the room can still orient themselves safely.
nThe fog or haze generated by the device may trigger smoke alarms.
General information about how
to safely operate fog machines
and hazers
Safety instructions
fog machine
16

3 Features
This fog machine is perfect for use on large stages and open air events.
Special features of the device:
nControl via DMX (1 channel), buttons and display on the unit or the supplied remote con‐
trol
nSuitable for mobile use
nLarge liquid container for the fog liquid
nCarrying handles for easy handling
nProtection circuit prevents the uid pump from running dry
nElectronic temperature control
Features
M-Fog 3000 Pro
17

4 Installation
Unpack and check carefully there is no transportation damage before using the unit. Keep the
equipment packaging. To fully protect the product against vibration, dust and moisture during
transportation or storage use the original packaging or your own packaging material suitable
for transport or storage, respectively.
Place the unit on a at surface. The unit should be installed horizontally, a maximum deviation
of 15° is allowed. The device requires 20 cm clearance at the sides and above.
Installation
fog machine
18

5 Starting up
Create all connections while the device is o. Use the shortest possible high-quality cables for
all connections. Take care when running the cables to prevent tripping hazards.
NOTICE!
Possible data transmission errors
For error-free operation make use of dedicated DMX cables and do not use ordi‐
nary microphone cables.
Never connect the DMX input or output to audio devices such as mixers or ampli‐
ers.
Starting up
M-Fog 3000 Pro
19

Connect the DMX input of the device to the DMX output of a DMX controller or another DMX
device. Connect the output of the rst DMX device to the input of the second one, and so on
to form a daisy chain. Always ensure that the output of the last DMX device in the daisy chain
is terminated with a resistor (110 Ω, ¼W).
Connections in DMX mode
