1. Warnings
These are the most critical warnings summarized below.
•If the instructions in this manual are not followed exactly, a fire or explosion may result, causing
property damage, personal injury or death.
•Do not store or use gasoline or other flammable substances and liquids near this or other appliance,
•Never use this appliance as a space heater to warm aroom.
•Installation of this appliance must be done by a qualified service agency or gas supplier.
Using a dual gas detector highly recommended
This is a dual fuel stove that can run on Propane or Methane. Both fuels have added a
hydrogen sulfide, which smell like rotten eggs, to make it easier to detect. However, some
individuals may not be able to detect the smell. Because fuel gas leaks cannot always be
detected by smell, the use of a gas detector is highly recommended,
Inexpensive dual fuel gas detectors are available commercially today.
•Gas suppliers recommend that you use a gas detector approved by UL or CSA.
•For more information, contact your gas supplier.
•If a gas leak is detected, follow the “What to do if you smell gas” instructions below
What to do if you smell natural methane or propane gas
•Do not light any appliance
•Do not touch an electrical switch
•Immediately call the gas supplier from a neighbor’s phone
•Open a window and leave the area
•Follow the gas supplier’s instructions
•If you cannot reach the gas supplier, call the firedepartment
Important Food Safety Warnings
•According to the United Sates Department of Agriculture:
DO NOT hold foods at temperatures between 40ºF to 140ºF more than 2 hours. Cooking raw foods
below 275ºF is not recommended.
Suffocation Warning / Carbon Monoxide Poisoning
•Never cover any slots, holes or passages in the oven bottom or cover an entire rack with materials
such as aluminum foil. Doing so blocks air flow through the oven and may cause carbon monoxide
poisoning.
•Aluminum foil lining may also trap heat, causing a firehazard.

Safety and Warnings
6
2. Welcome
Thank you for purchasing your HRG dual fuel indoor range. We appreciate your business and we
recommend that you read this entire User’s Manual before operating your new appliance for the
first time.
This manual contains instructions on how to properly install and set up your new range, as well as
insights into the unique features that our product offers. Please keep this manual for future
reference, as it contains answers to questions that you might have as you begin to cook.
Thank you,
Thor Group
This manual applies to the following models’ series:
HRD3088U
HRD3606U
HRD4803U
3. Before You Start
Make sure that the anti-tip device of the range has been properly installed.
Find the model and serial numbers on the side of the oven door insider. the CSA label Note
these numbers down for future reference in the space provided in section “Warranty and
service”. You will also find the serial number in the bottom right-hand corner of the
backboard.
Read this guide, taking special note of the “Safety and Warnings” section.
Remove all the packaging from the oven(s) and cooktop. Recycle items that you can. If any
adhesive residue is left on surfaces, remove this using dish washing liquid on a soft cloth. Do
not use any harsh or abrasive cleaners.
Make sure you follow the instructions under “First Use” before using your range for cooking.
Follow the instructions below to reduce the risk of fire, electrical shock, injury, or property damage,
follow the important safety instructions listed below:

Safety and Warnings
7
4. Safety and Warnings
Safety Symbols
Symbol
Definition
This symbol will alert you to potential personal or property
safety hazards. Obey all safety rules to avoid any property
damage, personal injury or death
WARNING which indicates a potentially hazardous situation,
which could result in serious injury or death
CAUTION indicates a moderate hazardous situation, which
could result in minor or moderate injury
CAUTION –when used without the safety alert symbol, indicates
a potentially hazardous situation, which, if not avoided, could
result in property damage
IMPORTANT used for installation, operation and maintenance
information that are not related to safety.

Safety and Warnings
8
Electrical Shock Hazard
✓ Before removing a faulty oven light bulb, make sure you turn OFF the
power to the range at the main fuse or circuit breaker panel. If you don’t
know how to do this, contact an electrician.
✓ Do not remove the kick strip grate. Due to electrical wires behind it, the
kick strip grate should only be removed by a qualified technician.
✓
This appliance is equipped with a three-prong grounding plug for your
protection against shock hazard and should be plugged directly into a properly grounded power
outlet. Do not under any circumstances cut or remove the grounding prong from this plug.
✓
Proper Installation –The range, when installed, must be electrically grounded in
accordance with local codes or, in the absence of local codes, with the National Electrical Code,
ANSI/NFPA 70. In Canada, the range must be electrically grounded in accordance with
Canadian Electrical Code. Be sure the range is properly installed and grounded by a qualified
technician.
Failure to follow this advice may result in death or electrical shock.
Tipping Hazard
A child or adult can tip the range over and be killed. Verify that the anti-tip
bracket is securely installed.
Ensure the anti-tip bracket is engaged when the range is moved.
(The Exact anti-tip bracket design might vary)
Do not operate the range without the anti-tip brackets in place. Failure to
follow the instructions in this manual can result in death or serious burns
to children and adults.
Check the below for the proper installation and use of anti-tip brackets.
Even after the safety device is installed, do not step, lean or sit on the oven door or place any
heavy objects on it. Doing so may result in personal injury.
Make sure anti-tip device is installed as follows:

Safety and Warnings
9
Slide the range forward.
Install the anti-tip device as described in the instruction sheet
Safely tilt the front section of the range and slide the range slowly back against the wall.
The rear pins should slide under the bracket.
Do not use the appliance until it has been secured.
Failure to follow this advice may result in serious injury.
1. Find the two anti-tip brackets and screws placed in the plastic bag with manual.
2. Fasten the two anti-tip brackets to the wall with the screws, two screws for each bracket.
3. Slide range completely back, make sure the fore-end of the brackets withhold the two screws
on side panel of range
Explosion Hazard
✓ If you smell gas, do not use the appliance. Open a window or door to let
the gas escape, then follow the instructions on the inside front cover of
this manual.
✓ Do not use water on grease fires. A violent steam explosion mayresult.
✓ Turn all burners off, then smother fire or flame with a dry chemical or
foam-type extinguisher. Do not try to smother with flammable blankets.

Safety and Warnings
9
✓ Do not heat unopened food containers such as cans. Build-up of pressure may causecontainer
to burst and result in injury.
Failure to follow this advice may result in injury or death
Fire Hazard
✓
Never use your appliance as a space heater. Persons could be injured or
a fire could start.
✓ Keep the area around the appliance free from combustible materials (e.g.
wall coverings, curtains, drapes), gasoline and other flammable vapors
and liquids.
✓ Clean the stove and burners regularly. Do not let cooking grease or other flammable materials
accumulate on the surfaces or near the appliance.
✓ Do not hang any articles (e.g. dish towels) off the oven handle. Some fabrics may ignite or melt
from the heat.
✓ Never leave the cooktop burners unattended when in use. Boil over causes smoking and greasy
spillovers that may ignite.
✓ Never spray an aerosol cleaner on or around the appliance while burners are lit. Be sure all the
controls are turned off and the appliance is cool. The aerosol gas and chemicals in such
cleaners could, in the presence of heat, ignite or cause metal partsto corrode.
✓ Do not store flammables near cooktop. Flammable materials should not be stored in an oven or
near the cooktop. An accident could cause a serious fire.
Poisoning Hazard
✓ Never cover any slots, holes or passages in the oven bottom or cover an
entire rack or the oven floor with materials such as aluminum foil. Doing
so blocks airflow through the oven and may cause carbon monoxide
poisoning. Aluminum foil linings may also trap heat, creating a fire hazard.
✓ Clean the appliance with caution. If a wet sponge or cloth is used to wipe
spills on a hot cooking area, be careful to avoid a steam burn. Some
cleaners can produce noxious fumes if applied to a hot surface. Follow
