Tiara Yachts C49 2024 User manual

2024 OWNERS MANUAL

CALIFORNIA PROPOSITION 65 WARNING
WARNING
!
WARNING: Operating, servicing and maintaining a recre-
ational marine vessel can expose you to chemicals includ-
ing engine exhaust, carbon monoxide, phthalates, and
lead, which are known to the State of California to cause
cancer and birth defects or other reproductive harm. To
minimize exposure, avoid breathing exhaust, service your
vessel in a well-ventilated area and wear gloves or wash
your hands frequently when servicing this vessel. For
more information go to www.P65warnings.ca.gov/marine.

Welcome to the family of Tiara Yachts boat owners and congratulations on your purchase of
your new Tiara.
We understand there are many choices available to you, and we appreciate the investment
that you’ve made and the subsequent faith and condence that you’ve placed into our
product. Hopefully, during the selection and buying process, you discovered that each Tiara
has been designed, engineered, and built with care and precision.
When our company was started, it was the goal of my father, Leon Slikkers, to provide you
with the nest quality boat available. We want to be the best and deliver the best to you. And
part of that includes a delightful ownership experience. Everything we have achieved since
our humble beginnings has been with this same goal in mind.
The information within this owner’s manual was assembled to assist you in understanding
how to operate your boat to obtain the maximum enjoyment of your Tiara. So please take
time to read the manual completely and please operate your boat safely and courteously.
I would also like to ask you a personal favor. Shortly, you will receive a survey asking
for your opinion about the sales process you experienced when you purchased your
boat. Approximately nine months later, you’ll be sent another survey inquiring about your
ownership experience. By taking a few minutes to complete these surveys, you will be
providing us with valuable information.
Best wishes for many happy hours aboard your new Tiara Yacht,
Thomas B. Slikkers
CEO/President S2 Yachts

This page intentionally left blank.

44731021.1
2023 MODELS TIARA YACHTS, INC. LIMITED WARRANTY COVERAGE Tiara Yachts, Inc. (Tiara) provides limited warranty coverage on Tiara Yachts products sold for use by retail (non-commercial) customers, as described in this Limited Warranty. For customers in the U.S.: this warranty gives you specific legal rights; you also may have other rights, which vary from state to state. For customers in the European Union: the purchaser may have additional legal rights under applicable national legislation governing the sale of consumer goods, and those rights (if applicable) are not affected by this warranty. This warranty is provided only to the original purchaser of the boat from an authorized Tiara Yachts dealer but can be transferred to subsequent owners. Contact Tiara’s Customer Relations Department if you need information about transferring this warranty. No warranty coverage is provided to subsequent owners unless they follow Tiara’s transfer procedures. This warranty does not extend or apply to anyone else. The terms of this written warranty cannot be changed or modified, except by a written agreement signed by an officer of Tiara Yachts, Inc. COVERED PRODUCTS AND LIMITATIONS: Tiara’s limited warranty coverage applies only to: 1. Defects in materials and workmanship in the boat and all components and accessories (except
for the excluded items described below) for a period of two (2) years;
2. Structural defects in materials and workmanship in the hull and deck for a period of five (5) years; 3. Blistering due to defects in material and workmanship in the gelcoat surface of the hull bottom for
a period of five (5) years, provided that the gelcoat surface has not been altered in any way such as sanding, sandblasting or application of a coating other than standard antifouling paint, any of which will void this warranty.
Each of the warranty coverage periods runs from the date of purchase of the boat from an authorized Tiara Yachts dealer and applies only to warranted defects that first manifest themselves and are reported to Tiara within the applicable warranty period. Tiara retains the right to determine to its reasonable satisfaction whether any claimed defect is covered by this warranty. Certain items are excluded from warranty coverage by Tiara, and this limited warranty coverage does not apply to: 1. Engines, transmissions, generators, air conditioning systems, swim platforms and lifts,
seakeeping systems, electronics and batteries, and other components manufactured by other manufacturers. These products may come with separate warranties from their manufacturers; see the Owner Packet for warranty registration requirements and details on these products.
2. Dealer final assembly and pre-delivery commissioning, and dealer installed components. 3. Scratching, chipping, discoloration or flaking of any powder coated or painted surface including
engines and hardtop components.
4. Gelcoat stress cracking, chalking, fading or discoloration. This includes bilge gelcoat. 5. Damage caused by accident, wear, storm damage, grounding, towing, commercial use of the
boat, or misuse or abuse, or deterioration resulting from normal use (including gaskets, seals, springs, wipers and sealants).
6. Maintenance, adjustments or realignments to any components including latches, hinges,
hatches, doors and drive train components.
7. Mold, mildew, upholstery damage or deterioration and cleaning. 8. Damage or deterioration resulting from environmental conditions, including electrolysis, crevice
or galvanic corrosion, any deterioration of underwater equipment, or any damage or deterioration resulting from any failure to undertake reasonable, routine maintenance.
9. Any repairs, adjustments, alterations or modifications made by anyone other than an employee of
Tiara Yachts, or an authorized Tiara Yachts dealer with Tiara’s prior, written authorization.
10. Damage which has occurred as a result of the boat being operated as a demonstrator and/or
displayed for sale.
11. Damage or deterioration of the hull or deck structure due to the attachment of hardware or other
components.
12. Weight, speed, fuel consumption or other performance characteristics. 13. Damage or deterioration resulting from improper trailering, hauling, launching or storage. 14. Boats purchased or used for commercial or governmental purposes or uses. REMEDIES UNDER THIS LIMITED WARRANTY If a defect covered by this warranty occurs, Tiara (or one of its authorized dealers, as determined by Tiara) will repair and replace the defective component, in its sole discretion. This ‘repair or replacement’ remedy is the exclusive remedy under this warranty. Tiara has no responsibility or liability for any consequential or incidental damages, such as loss of use, storage charges, interest or finance charges, insurance or depreciation, transportation or lodging charges, or charges for towing or hauling out, etc. which are specifically excluded and disclaimed from this warranty. For customers in the U.S.: some states do not allow the exclusion or limitation of incidental or consequential damages, so the above
limitation or exclusion may not apply to you. UNDER CERTAIN APPLICABLE LAWS, THERE MAY BE NO IMPLIED WARRANTIES OR GUARANTEES FROM TIARA APPLICABLE TO YOUR BOAT, AND ALL IMPLIED OR STATUTORY CONDITIONS AND WARRANTIES (INCLUDING ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE) AND GUARANTIES ARE DISCLAIMED WHERE ALLOWED BY LAW. TO THE FULLEST EXTENT ALLOWED BY LAW, ANY AND ALL APPLICABLE IMPLIED WARRANTIES AND GUARANTIES (IF ANY), INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY OR PARTICULAR PURPOSE, ARE LIMITED IN DURATION TO THE DURATION OF THE APPLICABLE PROVISIONS OF THIS WRITTEN WARRANTY. For customers in the U.S.: some states do not allow limitations on how long an implied warranty lasts, so the above limitation may not apply to you. RESPONSIBILITY OF PURCHASER 1. No warranty coverage is provided by Tiara unless the customer and dealer complete and return
all Vessel Registration and Customer Acceptance Forms to Tiara Yachts, Inc. within seven (7) days after delivery of the boat to the original purchaser.
2. The original purchaser or approved transferee must notify the Tiara Yachts dealer from which the
boat was purchased of any claimed defect within fifteen (15) days after first detecting the claimed defect. Warranty work in excess of $500 requires Tiara’s prior written approval.
3. If the dealer fails to satisfactorily repair the claimed defect within fifteen (15) days, written notice must
then be promptly given directly to Tiara. Tiara is not responsible for unreported warranted defects.
4. The boat, including any claimed defective part, must be returned to the Tiara Yachts dealer from
which the boat was purchased (or to another dealer or facility as directed by Tiara Yachts) within the warranty period for inspection and warranty service. The expense of returning and transporting the boat or any part for warranty service, and the expense of returning and transporting it back to the owner after repair or replacement, is the responsibility of the owner, and will not be reimbursed by Tiara.
5. If the dealer from whom the boat was purchased is no longer an authorized Tiara Yachts dealer,
contact Tiara for instructions on how to obtain warranty service.
S2 reserves the right to improve its products through changes in design or materials without being
obligated to the owners of the boats of similar or the same model of prior manufacture. We may be contacted as follows: Tiara Yachts Customer Relations Department, 725 East 40th Street, Holland, Michigan 49423 (616/394-7460) or [e-mail].
LIMITED WARRANTY
2024

SUPPLEMENTAL LIMITED WARRANTY INFORMATION ON FINISHED WOOD COMPONENTS
Your Tiara Yachts® Boat may be furnished with certain nished wood panels and components that require periodic maintenance
and renishing to maintain their appearance and nish. S2 Yachts, Inc.’s Limited Warranty coverage does not include the match-
ing of wood grains, or the condition or durability of any nishes for such panels and components. This statement supplements S2
Yachts, Inc.’s Limited Warranty with respect to these wood panels and components. All other terms of S2 Yachts, Inc.’s Limited
Warranty remain in effect, and you should refer to the Limited Warranty for other terms, conditions and requirements
CALIFORNIA EVAPORATIVE EMISSIONS CONTROL SYSTEM WARRANTY STATEMENT:
YOUR WARRANTY RIGHTS AND OBLIGATIONS
The California Air Resources Board and S2 Yachts, Inc. is pleased to explain the evaporative emission control system’s warranty
on your 2024 model year spark-ignition marine watercraft. In California, new spark-ignition marine watercraft (SIMW) must be
designed, built, and equipped to meet the State’s stringent anti-smog standards. S2 Yachts, Inc. must warrant the evaporative
emission control system on your spark-ignition marine watercraft for the period listed below provided there has been no abuse,
neglect, or improper maintenance of your SIMW.
Your evaporative emissions control system may include parts such as: canisters, carburetors, clamps, connectors, lters, fuel
caps, fuel lines, fuel tanks, valves, vapor hoses, and other associated evaporative emissions control system components.
MANUFACTURER’S WARRANTY COVERAGE:
This evaporative emission control system is warranted for two years. If any evaporative emission-related part on your SIMW is
defective, the part will be repaired or replaced by S2 Yachts, Inc.
OWNER’S WARRANTY RESPONSIBILITIES:
• As the spark-ignition marine watercraft owner, you are responsible for performance of the required maintenance listed in
your owner’s manual. S2 Yachts, Inc. recommends that you retain all receipts covering maintenance on your spark-ignition
marine watercraft, but S2 Yachts, Inc. cannot deny warranty solely for the lack of receipts.
• As the spark-ignition marine watercraft owner, you should however be aware that S2 Yachts, Inc. may deny you warranty
coverage if your spark-ignition marine watercraft or a part has failed due to abuse, neglect, or improper maintenance or
unapproved modications.
• You are responsible for presenting your spark-ignition marine watercraft to a S2 Yachts, Inc. dealer or authorized service
center as soon as the problem exists. The warranty repairs should be completed in a reasonable amount of time, not to
exceed 30 days. If you have a question regarding your warranty coverage, you should contact S2 Yachts, Inc. at 1-616-
392-7163.
The California evaporative emissions control system warranty covers the following list of components:
(1) Canister Mounting Brackets
(2) Carbon Canister
(3) Carburetor Purge Port Connector
(4) Clamps*
(5) Control Cables*
(6) Control Linkages*
(7) Control Solenoids*
(8) Control Valves*
(9) Electronic Controls*
(10) Fuel Cap
*Note: As they relate to the evaporative emissions control system.
(11) Fuel Line
(12) Fuel Line Fittings
(13) Fuel Tank
(14) Liquid/Vapor Separator
(15) Pressure Relief Valves*
(16) Purge Valves
(17) Vacuum Control Diaphragms*
(18) Vapor Hoses
(19) All other parts not listed that may affect the evaporative
emissions control system

i
IMPORTANT INFORMATION
Your Tiara Owner’s Manual has been written to include a number of safety in-
structions to assure the safe operation and maintenance of your boat. These
instructions are in the form of WARNING and CAUTION statements. The follow-
ing denitions apply:
All instructions given in this book are as seen from the stern looking toward the
bow, with starboard being to your right, and port to your left. A glossary of boating
terms is included in the Appendix.
DANGER
!
DANGER INDICATES A HAZARDOUS SITUATION WHICH, IF NOT
AVOIDED, WILL RESULT IN DEATH OR SERIOUS INJURY.
WARNING
!
WARNING INDICATES HAZARDS OR UNSAFE PRACTICES WHICH
COULD RESULT IN SEVERE PERSONAL INJURY OR DEATH.
CAUTION
!
CAUTION indicates hazards or unsafe practices which could result in mi-
nor personal injury, or product and property damage.
NOTICE
NOTICE is used to address best practices not related to physical injury.

IMPORTANT INFORMATION
ii
IMPORTANT NOTE: Your boat uses internal combustion engines and ammable
fuel. Every precaution has been taken by Tiara Yachts to reduce the risks as-
sociated with possible injury and damage from re or explosion, but your own
precaution and good maintenance procedures are necessary in order to enjoy
safe operation of your boat.
If for any reason you have trouble with your Tiara Owner’s Manual, or require re-
placement pages, please contact our Customer Service department at the address
on the cover page. We will be happy to supply replacement pages at no charge.
This manual has been compiled to help you to operate your craft with safety and
pleasure. It contains details of the craft, the equipment supplied or tted, its sys-
tems, and information on its operation and maintenance. Please read it carefully,
and familiarize yourself with the craft before using it.
If this is your rst craft, or you are changing to a type of craft you are not familiar
with, for your own comfort and safety, please ensure that you obtain handling
and operating experience before assuming command of the craft. Your dealer or
national sailing federation or yacht club will be pleased to advise you of local sea
schools, competent instructors, and reference material.
PLEASE KEEP THIS MANUAL IN A SECURE PLACE, AND PRESENT IT TO
THE NEW OWNER WHEN YOU SELL THE CRAFT.
Owner’s manuals for the installed equipment on your boat have also been pro-
vided for your reference. They have been stored in a valise that is included in
your new boat. Please read this information, and also hand them over to the new
owner when you sell the boat.

Table of Contents
i
49 COUPE
49 COUPE
Safety Labels
Interior ............................................................... 1
Exterior .............................................................. 2
General Information
Engine and General Specications ................... 9
Boat Information .............................................. 10
Warranty & Warranty Registration Cards .........11
Product Changes .............................................11
Transferring the Warranty ................................11
Owner/Operator Responsibilities ......................11
Pre-Cruise Checklist
Fire Extinguisher Locations ............................. 13
Pre-Cruise Checklist ........................................ 13
Propulsion Systems
1.1 General ..................................................... 1-1
1.2 Engine Lubrication .................................... 1-1
1.3 Propellers ................................................. 1-1
1.4 Engine Instrumentation............................. 1-1
1.5 Gauge Maintenance ................................. 1-2
1.6 Seakeeper Gyro Stabilization System
(optional) ................................................ 1-3
Helm Systems
2.1 General ..................................................... 2-1
2.2 Multi-Function Displays ............................ 2-1
2.3 Engine Throttle and Shift Controls ............ 2-1
2.4 Neutral Safety Switch ............................... 2-2
2.5 Automatic Fire Suppression System ........ 2-3
2.6 Steering System ....................................... 2-3
2.7 Seakeeper Gyro Stabilization System
(optional) ................................................ 2-5
2.8 12-Volt DC Helm Switches ....................... 2-5
2.9 Outboard of the Helm ............................... 2-6
2.10 Blower and Bilge Pump Controls ............ 2-6
2.11 Compass .................................................2-6
2.12 Spotlight (optional).................................. 2-7
2.13 Control Systems Maintenance................ 2-7
Fuel Systems
3.1 General ..................................................... 3-1
3.2 Generator Fuel System ............................ 3-4
3.3 Fuel System Maintenance ........................ 3-5
Electrical Systems
4.1 General ..................................................... 4-1
4.2 12V DC System ........................................ 4-1
4.3 DC Distribution Panel ............................... 4-5
4.4 Seakeeper Gyro (optional) ...................... 4-6
4.5 AC System ................................................ 4-7
4.6 AC Distribution Panel................................ 4-8
4.7 Shore Power Connection.......................... 4-9
4.8 Generator ............................................... 4-11
4.9 Other Electrical Controls......................... 4-13
4.10 Electrical System Maintenance ............ 4-14
Plumbing Systems
5.1 Fresh Water System ................................. 5-1
5.2 Fresh Water System Commissioning ...... 5-2
5.3 Marine Head System ............................... 5-5

Table of Contents
ii 49 COUPE
5.4 Raw Water Washdown ............................ 5-7
5.5 Drainage ................................................... 5-8
5.6 Plumbing System Routine Maintenance... 5-9
Ventilation Systems
6.1 Air Conditioning System ........................... 6-1
6.2 Portlights .................................................. 6-1
6.3 Carbon Monoxide and Proper Ventilation . 6-2
6.4 Bilge Ventilation ........................................ 6-2
6.5 Ventilation Maintenance ........................... 6-2
Exterior Equipment
7.1 Forward Deck ........................................... 7-1
7.2 Hardtop ..................................................... 7-3
7.3 Aft Cockpit ................................................ 7-4
7.4 Stern ......................................................... 7-4
7.5 Swim Platform Lift System (optional)........ 7-7
Interior Equipment
8.1 Safety Equipment ..................................... 8-1
8.2 Electrical Components.............................. 8-1
8.3 Helm ......................................................... 8-1
8.4 Hardtop ..................................................... 8-2
8.5 Lighting ..................................................... 8-2
8.6 Climate Control ......................................... 8-2
8.7 Stereo and Radios .................................... 8-2
8.8 Television .................................................. 8-2
8.9 AC and DC Distribution Panels................. 8-2
8.10 Salon and Galley .................................... 8-2
8.11 Atrium ...................................................... 8-3
8.12 Atrium Lounge ........................................ 8-4
8.13 Master Stateroom ................................... 8-4
8.14 Master Head ........................................... 8-5
8.15 VIP Stateroom ........................................ 8-5
8.16 V.I.P. Head .............................................. 8-5
Safety Information
9.1 General ..................................................... 9-1
9.2 Engine Alarms .......................................... 9-1
9.3 Neutral Safety Switch ............................... 9-1
9.4 Fire Safety ................................................ 9-2
9.5 Carbon Monoxide Safety .......................... 9-4
9.6 First Aid..................................................... 9-7
9.7 Required Safety Equipment...................... 9-7
9.8 Additional Safety Equipment..................... 9-9
Operation
10.1 General ................................................. 10-1
10.2 Homeland Security Restrictions ........... 10-2
10.3 Rules of the Road ................................. 10-2
10.4 Operating your Boat ............................. 10-3
10.5 Fishing .................................................. 10-5
10.6 Docking, Anchoring and Mooring.......... 10-5
10.7 Controls, Steering or Propulsion System
Failure ................................................. 10-7
10.8 Collision ............................................... 10-7
10.9 Grounding, Towing and Rendering
Assistance ........................................... 10-7

Table of Contents
iii
49 COUPE
49 COUPE
10.10 Flooding or Capsizing ........................ 10-7
10.11 Transporting your Boat ...................... 10-8
10.12 Man Overboard .................................. 10-8
10.13 Trash Disposal ................................... 10-8
10.14 Multi-Colored Lighting......................... 10-9
Routine Maintenance
11.1 General ................................................ 11-1
11.2 Exterior Hull and Deck ......................... 11-1
11.3 Seats, Upholstery, Canvas and Enclosures
11-6
11.4 Cabin Interior ....................................... 11-7
11.5 Oil Change System ............................... 11-7
11.6 Fuel System .......................................... 11-8
11.7 Bilge ..................................................... 11-8
11.8 Electrical ............................................... 11-8
11.9 Generator .............................................. 11-8
Seasonal Maintenance
12.1 Winterizing ........................................... 12-1
12.2 Storage and Lay-up .............................. 12-6
12.3 Recommissioning ................................ 12-8
Appendices
Maintenance Guides.......................................B-1
Maintenance Schedule .................................. C-1
Boating Accident Report ................................ D-1
Float Plan .......................................................E-1
Troubleshooting Guide ...................................F-1
Schematics .................................................... G-1

Table of Contents
iv 49 COUPE
Operator Notes

1
27
1
1
The following diagrams indicate where safety labels can be found on your Tiara. The
numbers correspond to the list in the table that follows. To obtain replacement labels
refer to the part number of the label in the table and contact your Tiara dealer.
Interior
Safety Labels
1
49 COUPE
49 COUPE

4
5
6
10
11
12
13
15
7
20
1
25
28
29
30
31
32
33
34
19
1
14
8
18
9
26 16
21
Exterior
Safety Labels
249 COUPE

1010
22
2424
2424
1616
22
23
17
35
3
23
22
20
35
Safety Labels
3
49 COUPE
49 COUPE

1
FIRE EXTINGUISHER INSIDE
P/N: 5452010
Location: Master stateroom hanging locker,
VIP stateroom hanging locker, port galley,
starboard aft facing seat in aft cockpit.
2
NO SMOKING
P/N: 5451130
Location: Port & starboard fuel ll
3
NOTICE: ANCHOR LINE LOSS
P/N: 5453180
Location: Underside of anchor hatch
4
NOTICE: FIRE EXTINGUISHING SYSTEM
P/N: 5453300
Location: Helm
5
BOATERS CHECK LIST
P/N: 5453130
Location: Helm
6
YACHT CERTIFICATION PLATE
P/N: 5450570
Location: Helm
7
PRIDE OF OWNERSHIP
P/N: 5450058
Location: Helm
8
DANGER: CARBON MONOXIDE
P/N: 5453670
Location: Top of transom buffet
Safety Labels
449 COUPE

9
WARNING: SEAT USE WHILE UNDER-
WAY
P/N: 5455875
Location: Sun pad
10
WARNING: CLOSE TRANSOM DOOR(S).
P/N: 5453220
Location: Helm & near port and starboard
transom doors.
11
WARNING: LEAKING FUEL
P/N: 5453150
Location: Helm
12
DANGER: ROTATING PROPELLERS
P/N: 5450151
Location: Helm
13
WARNING: CARBON MONOXIDE
P/N: 5453690
Location: Port galley
14
WARNING: CARBON MONOXIDE
P/N: 5453680
Location: Helm
15
WARNING: SUNSHADE STOWAGE
P/N: 5450054
Location: Under port covering board aft
cockpit
16
WARNING: HARDTOP
P/N: 5453160
Location: Helm, underside of hardtop port &
underside of hardtop starboard
Safety Labels
5
49 COUPE
49 COUPE

17
WARNING: GASOLINE VAPORS
P/N: 545323
Location: Inside trunk at top of opening
18
WARNING: OPEN TRUNK
P/N: 5455620
Location: Top of transom buffet
19
WARNING: GRILL SHOCK AND FIRE
P/N: 5455876
Location: Underside of grill lid
20
WARNING: HAZARDOUS VOLTAGE
P/N: 5451110
Location: Port shore power locker & option-
al forward shore power connection
21
LOCK SEAT
P/N: 5454050
Location: Salon port end table
22
FRESH WATER
P/N: 5455490
Location: Cockpit water connection locker
23
RAW WATER
P/N: 5455480
Location: Starboard aft cockpit water con-
nection locker & optional forward wash
down connection
24
SLING
P/N: 5450240
Location: Port & starboard hull sides
Safety Labels
649 COUPE

25
DISCHARGE OF OIL PROHIBITED
P/N: 5450190
Location: Underside of engine room hatch
26
DUMPING TRASH OVERBOARD
P/N: 5451640
Location: Galley trash cabinet
27
TAG: OVERBOARD DISCHARGE OF
SEWAGE
P/N: 5450050
Location: Optional overboard discharge
seacock
28
TAG: BATTERY MOUNTING REQUIRE-
MENTS
P/N: 5450160
Location: Batteries in the engine room
29
TAG: FUEL SYSTEM STBD WITHDRAWAL
P/N: 5451290
Location: Forward engine room bulkhead
30
TAG: FUEL SYSTEM STBD RETURN
P/N: 5451300
Location: Forward engine room bulkhead
31
TAG: FUEL SYSTEM PORT WITHDRAWAL
P/N: 5451310
Location: Forward engine room bulkhead
32
TAG: FUEL SYSTEM PORT RETURN
P/N: 5451320
Location: Forward engine room bulkhead
Safety Labels
7
49 COUPE
49 COUPE

33
TAG: FUEL SYSTEM GENERATOR WTH-
DRWL
P/N: 5451350
Location: Forward engine room bulkhead
34
TAG: FUEL SYSTEM GENERATOR RE-
TURN
P/N: 5451360
Location: Forward engine room bulkhead
35
DANGER: ROTATING PROPELLERS
P/N: 5450152
Location: Port and starboard side of swim
platform
Safety Labels
849 COUPE
