Tidylife AF1834A1 User manual

AIR FRYER
READ THIS BOOKLET THOROUGHLY
BEFORE USING AND SAVE IT FOR FUTURE REFERENCE
INSTRUCTION MANUAL
Model: AF1834A1
Shenzhen TidylifeTrading Co., Ltd.
Xingduhaoting,Buji Street,Longgang District,Shenzhen
Facebook Page:www.facebook.com/Tidylifeservice
Website:www.tidylife.cc
4007446

Introduction
Read this user manual carefully before you use the appliance
and save it for future reference.
2
Important
- Never immerse the housing, which contains electrical compo-
nents and the heating elements, in water nor rinse under the
tap.
- Do not let any water or other liquid enter the appliance to
prevent electric shock.
- Always put the ingredients to be fried in the basket, to prevent
it from coming into contact with the heating elements.
- Do not cover the air inlet and the air outlet openings while the
appliance is operating.
- Do not fill the pan with oil as this may cause a fire hazard.
- Never touch the inside of the appliance while it is operating.
Danger
- This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have been
given supervision or instruction concerning the use of appliance
by a person responsible for their safety. Children should be
supervised to ensure that they do not play with the appliance.
- Check if the voltage indicated on the appliance corresponds to
the local mains voltage before you connect the appliance.
- Do not use the appliance if the plug, the mains cord or the
appliance itself is damaged.
Warning
Your new air fryer allows you to prepare your favorite ingredi-
ents and snacks in a healthier way. The air fryer uses hot air in
combination with high-speed air circulation (rapid hot air) and a
top grill to prepare a variety of tasty dishes in a healthy, fast and
easy way. Your ingredients are heated from all sides at once
and there is no need to add oil to most of the ingredients.
Technical Data
Description: 3.4L Air Fryer
Model: AF1834A1
Rated Voltage: 120V 60Hz
Power Consumption：1500W
General Description
1

34
Caution
- If the mains cord is damaged, you must have it replaced by
the manufacturer, its service agent or similarly qualified persons
in order to avoid a hazard.
- This appliance can be used by children aged 8 or over and
persons with reduced physical, sensory or mental capabilities, or
lack of experience and knowledge, provided they have been
given supervision or instruction concerning use of the appliance
in a safe way and understand the hazards involved.
- Children should be supervised to ensure that they do not play
with the appliance. Cleaning and user maintenance shall not be
made by children unless they are older than 8 and supervised.
- Keep the appliance and its mains cord out of the reach of
children younger than 8 when the appliance is switched on or is
cooling down.
- Keep the mains cord away from hot surfaces.
- Do not plug in the appliance or operate the control panel with
wet hands.
- Only connect the appliance to an earthed wall socket. Always
make sure that the plug is inserted into the wall socket properly.
- Never connect this appliance to an external timer switch or
separate remote-control system in order to avoid a hazardous
situation.
- Do not place the appliance on or near combustible materials
such as a tablecloth or curtain.
- Do not place the appliance against a wall or against other
appliances. Leave at least 10cm free space on the back and
sides and 10cm free space above the appliance. Do not place
anything on top of the appliance.
- Do not use the appliance for any other purpose than described
in this manual.
- Do not let the appliance operate unattended.
- During hot air frying, hot steam is released through the air
outlet openings. Keep your hands and face at a safe distance
from the steam and from the air outlet openings. Also be careful
of hot steam and air when you remove the pan from the appli-
ance.
- The accessible surfaces may become hot during use.
- Immediately unplug the appliance if you see dark smoke
coming out of the appliance. Wait for the smoke emission to
stop before you remove the pan from the appliance.
- Place the appliance on a horizontal, even and stable surface.
- This appliance is intended for normal household use only. It is
not intended for use in environments such as staff kitchens of
shops, offices, farms or other work environments. Nor is it
intended to be used by clients in hotels, motels, bed and break-
fasts and other residential environments.
- If the appliance is used improperly or for professional or
semi-professional purposes or if it is not used according to the
instructions in the user manual, the guarantee becomes invalid
and we could refuse any liability for damage caused.
- Always unplug the appliance after use.
- Let the appliance cool down for approx. 30 minutes before
you handle or clean it.
- Make sure the ingredients prepared in this appliance come out
golden-yellow instead of dark or brown. Remove burnt rem-
nants.

- The appliance with the micro switch inside, when pull out the
pan during cooking, the appliance will be shut-off power auto-
matically.
This appliance is equipped with a timer. When the timer has
counted down to 0, the appliance produces a bell sound and
switches off automatically.
Note: If pull out the pan during cooking, the appliance will be
switched off automatically, too.
56
1. Remove all packaging material.
2. Remove any stickers or labels from the appliance.
3. Thoroughly clean the basket and pan with hot water, some
washing-up liquid and a non-abrasive sponge.
4. Wipe the inside and outside of the appliance with a moist cloth.
This is an air fryer that works on hot air. Do not fill the pan with
oil or frying fat.
1. Place the appliance on a stable, horizontal and level surface.
Do not place the appliance on non-heat-resistant surfaces.
2. Place the basket in the pan properly
Note: the basket MUST be put into the appliance properly, other-
wise the appliance doesn’t work!
3. Pull the mains cord and plug into the earthed wall socket.
Do not fill the pan with oil or any other liquid.
Do not put anything on top of the appliance.
Before first use
Preparing for use
The air fryer can prepare a large range of ingredients. Pls refer to
the section “settings” table hereinafter.
Using the appliance
1. Put the mains plug into an earthed wall socket.
2. Carefully pull the pan out of the air fryer (fig.1).
3. Put the ingredients in the basket (fig.2).
Note: Never fill the basket in full or exceed the recommended
Hot air frying
Automatic switch-off
This appliance complies with all standards regarding electro-
magnetic fields (EMF). If handled properly and according to the
instructions in this user manual, the appliance is safe to use
based on scientific evidence available today.
Electromagnetic fields (EMF)
IEC 60335-2-9: 2002 + A1: 2004 + A2: 2006
IEC 60335-1: 2001 + A1: 2004 + A2: 2006
EN 60335-2-9: 2003 + A1: 2004 + A2: 2006 + A12: 2007 +
A13: 2010
EN 60335-1: 2002 + A11: 2004 + A1: 2004 + A12: 2006 +
A2: 2006 + A13: 2008
Test specifications/Standard:

8
7
amount ( see section ‘Settings’in this chapter), as this could affect
the quality of the end result.
4. Slide the pan back into the air fryer properly (fig.3).
Never use the pan without the basket in it.
If the pan doesn’t be fixed into the air fryer properly, the appli-
ance won’t work!
Caution: Do not touch the pan during and some time after use,
as it gets very hot. Only hold the pan by the handle.
5. Press the MODE button to the required temperature. See sec-
tion’ Settings’ in this chapter to determine the right temperature
(fig.4)
6. Determine the required preparation time for the ingredient (see
section ‘Settings’ in this chapter) by press the button TIMER+ or
TIMER-.
7. To switch on the appliance, press the ON button, to witch off
the appliance, press the OFF button or press the TIMER- to adjust
the time to 00 (fig.5)
a The LCD light go on.
b The timer starts counting down the set preparation time.
c During the hot air frying process, the heating-up comes on and
goes off from time to time. This indicates that the heating element
is switched on and off to maintain the settled temperature.
d Excess oil from the ingredients is collected on the bottom of the
pan.
8. Some ingredients require shaking halfway through the prepara-
tion time (see section ’Settings’ in this chapter). To shake the
ingredients, pull the pan out of the appliance by the handle and
shake it. Then slide the pan back into the air fryer and continue to
cook (fig.7, fig.8 & fig.9).
Caution: Do not press the button of the handle during shaking.
Tip: To reduce the weight, you can remove the basket from the
pan and shake the basket only. To do so, pull the pan out of the
appliance, place it on a heat-resistant surface and press the button
of the handle.
Tip: If you set the timer to half the preparation time, you hear the
timer bell when you have to shake the ingredients. However, this
means that you have to set the timer again to the remaining
preparation time after shaking.
Tip: If you set the timer to full preparation time, there is no timer
bell during cooking before finishing, you can pull out the pan at
any time to check the ingredients cooking condition, the power will
shut down automatically and resume after slide the pan back into
the appliance(timer still on).
9. When you hear the timer bell, the set preparation time has
elapsed. Pull the pan out of the appliance and place it on a
heat-resistant surface (fig.10).
Note: You can also switch off the appliance manually. To do this,
press the OFF button, or press the TIMER- button to 0, or pull out
the pan directly.
10. Check if the ingredients are ready.
If the ingredients are not ready yet, simply slide the pan back into
the appliance and set the timer to a few extra minutes.
11. To remove small ingredients (e.g. fries), press the basket
release button and lift the basket out of the pan (fig.11).
Do not turn the basket upside down with the pan still attached to it,
as any excess oil that has collected on the bottom of the pan will
leak onto the ingredients.
After hot air frying, the pan and the ingredients are hot. Depending

10
9
on the type of the ingredients in the air fryer, steam may escape
from the pan.
12. Empty the basket into a bowl or onto a plate (fig.12).
Tip: To remove large or fragile ingredients, use a pair of tongs to
lift the ingredients out of the basket
13. When a batch of ingredients is ready, the air fryer is instantly
ready for preparing another batch.
- Do not prepare extremely greasy ingredients such as sausag-
es in the air fryer.
- Snacks that can be prepared in a oven can also be prepared
in the air fryer.
- The optimal amount for preparing crispy fries is 500 grams.
- Use pre-made dough to prepare filled snacks quickly and
easily. Pre-made dough also requires a shorter preparation time
than home-made dough.
- Place a baking tin or oven dish in the air fryer basket if you
want to bake a cake or quiche or if you want to fry fragile ingre-
dients or filled ingredients.
- You can also use the air fryer to reheat ingredients. To reheat
ingredients, set the temperature to 150℃for up to 10 minutes.
Note: Add 3 minutes to the preparation time when you start
frying while the air fryer is still cold.
To make home-made fries, follow the steps below.
1. Peel the potatoes and cut them into sticks.
2. Wash the potato sticks thoroughly and dry them with kitchen
paper.
3. Pour 1/2 tablespoon of olive oil in a bowl, put the sticks on
top and mix until the sticks are coated with oil.
4. Remove the sticks from the bowl with your fingers or a kitch-
en utensil so that excess oil stays behind in the bowl. Put the
sticks in the basket.
Note: Do not tilt the bowl to put all the sticks in the basket in
one go, to prevent excess oil from ending up on the bottom of
the pan.
This table below helps you to select the basic settings for the
ingredients you want to prepare.
Note: Keep in mind that these settings are indications. As ingre-
dients differ in origin, size, shape as well as brand, we cannot
guarantee the best setting for your ingredients.
Because the rapid hot air technology instantly reheats the air
inside the appliance, pulling the pan briefly out of the appliance
during hot air frying barely disturbs the process.
Tips
- Smaller ingredients usually require a slightly shorter prepara-
tion time than larger ingredients.
- A larger amount of ingredients only requires a slightly longer
preparation time, a smaller amount of ingredients only requires
a slightly shorter preparation time.
- Shaking smaller ingredients halfway through the preparation
time optimizes the end result and can help prevent unevenly
fried ingredients.
- Add some oil to fresh potatoes for a crispy result. Fry your
ingredients in the air fryer within a few minutes after you added
the oil.
Settings
Making home-made fries

12
11
5. Fry the potato sticks according to the instructions in this
chapter. 1. Unplug the appliance and let it cool down.
2. Make sure all parts are clean and dry.
3. Put the air fryer on the clean and dry place.
Clean the appliance after every use.
The pan and the basket do not use metal kitchen utensils or
abrasive cleaning materials to clean them, as this may
damage the non-stick coating.
1. Remove the mains plug from the wall socket and let the
appliance cool down.
Note: Remove the pan to let the air fryer cool down more quick-
ly.
2. Wipe the outside of the appliance with a moist cloth.
3. Clean the pan and the basket with hot water, some wash-
ing-up liquid and a non-abrasive sponge.
You can use a degreasing liquid to remove any remaining dirt.
Tip: If dirt is stuck to the basket or the bottom of the pan, fill the
pan with hot water with some washing-up liquid. Put the basket
in the pan and let the pan and the basket soak for approximate-
ly 10 minutes.
4. Clean the inside of the appliance with hot water and
non-abrasive sponge.
5. Clean the heating element with a cleaning brush to remove
any food residues.
Cleaning
Storage
If you need service or information or if you have a problem,
please visit our website or contact your distributor.
Website：www.tidylife.cc
Facebook Page：www.facebook.com/Tidylifeservice
E-Mail：[email protected]
Guarantee and service
Troubleshooting
problem
The air fryer does
not work
The appliance is
not plugged in.
You have not set
the timer.
Put the mains plug in
an earthed wall socket.
Possible cause Solution
Adjust the timer to the required
preparation time to switch on the
appliance.
Slide the pan into the appliance
properly.
The pan is not put into the
appliance properly
Use a pointed object to press the
RESET button at the bottom of the
appliance.
The overheating protection is
turned on
The amount of ingredients in
the basket is too big.
Put smaller batches of ingredi-
ents in the basket. Smaller
batches are fried more evenly.
The preparation time is too
short.
Adjust the timer to the required
preparation time (see section
‘Settings’ in chapter’ Using the
appliance’).
The ingredients
fried with the air
fryer are not done.

14
13
Use oven snacks or lightly brush
some oil onto the snacks for a
crispier result.
You used a type of snacks
meant to be prepared in a
traditional deep fryer.
Fried snacks are
not crispy when
they come out of
the air fryer.
Ingredients that lie on top of or
across each other (e.g.fries)
need to be shaken halfway
through the preparation time.
See section‘Settings’ in chapter
‘Using the appliance’.
Certain types of ingredients
need to be shaken halfway
through the preparation time.
Do not fill the basket beyond the
MAX indication.
There are too much ingredi-
ents in the basket.
I cannot slide the
pan into the appli-
ance properly.
Push the basket down into the
pan until you hear a click.
The basket is not placed in the
pan correctly.
You are preparing greasy
ingredients.
When you fry greasy ingredients
in the air fryer, a large amount of
oil will leak into the pan. The oil
produces white smoke and the
pan may heat up more than
usual. This does not affect the
appliance or the end result.
The pan still contains grease
residues from previous use.
White smoke is caused by
grease heating up in the pan .
make sure you clean the pan
properly after each use.
Fresh fries are fried
unevenly in the air
fryer.
You did not use the right
potato type.
Use fresh potatoes and make
sure they stay firm during frying.
Fresh fries are not
crispy when they
come out of the air
fryer.
The crispiness of the fries
depends on the amount of oil
and water in the fries.
Make sure you dry the potato
sticks properly before you add
the oil.
Cut the potato sticks smaller for
a crispier result.
Add slightly more oil for a
crispier result.
You did not rinse the potato
sticks properly before you
fried them.
Rinse the potato sticks properly
to remove starch from the
outside of the sticks.
White smoke
comes out of the
appliance.
The ingredients are
fried unevenly in
the air fryer.
