Tidylife AF1855 User manual

AIR FRYER
INSTRUCTION MANUAL
MODEL NO.:AF1855
BEFORE USE, PLEASE READ AND FOLLOW ALL IMPORTANT
SAFEGUARDS, WARNINGS, CAUTIONS AND OPERATING INSTRUCTIONS.
Made In China
HOUSEHOLD USE ONLY
Shenzhen TidylifeTrading Co., Ltd.
Xingduhaoting,Buji Street,Longgang District,Shenzhen
Facebook Page:www.facebook.com/Tidylifeservice
Website:www.tidylife.cc

-1- - 2-
Thank you for purchasing this Air Fryer from the products.Please
read this Manual carefully BEFORE using the Air Fryer for your own
safety.It has been designed to provide many years of trouble-free
use.There are many benefits to using a Air Fryer:
•Simple to use controls for cooking quick, healthy meals.
•Generous 5.5L frying capacity to cook for an army.
•Rapid air circulation system to cook food fast and saves energy.
•Healthy alternative to cooking deep fried food with no oil.
•Air Fried food retains its nutritional value, but still has the taste of
delicious fried food.
INTRODUCTION
6. Basket
7. Pan
8. Basket Handle
GENERAL DESCRIPTION OF MAIN PARTS
1
2
3
4
5
6
7
8
1. Top Cover
2. Timer (0-60 min.)/ power-on knob
3. Temperature control knob (80-200℃)
4. Up Housing
5. Down Housing
Please read this manual carefully before you use the appliance
and save it for future reference.
-Never immerse the housing, which contains electrical compo- nents
and the heating elements, in water or rinsing under the tap.
-Avoid any liquid enter the appliance to prevent electric shock or
short-circuit.
-Keep all ingredients in the basket or prevent any contact from heat-
ing elements.
-Do not cover the air inlet and the air outlet when the appliance is
working.
-Fill the pan with oil may cause a fire hazard.
-Don't touch the inside of the appliance while it is operating.
IMPORTANT
Danger
- Children should be supervised to ensure that they do not play with
the appliance. Cleaning and user maintenance shall not be made by
children unless they are older than 8 and supervised.
- Keep the appliance and its mains cord out of the reach of children
younger than 8 when the appliance is switched on or is cooling down.
-Check if the voltage indicated on the appliance fits the local mains
voltage.
-Do not use the appliance if there is any damage on plug, mains cord
or other parts.
-Do not go to any unauthorized person to replace or fix damaged main cord.
-Keep the mains cord away from hot surfaces.
-Do not plug in the appliance or operate the control panel with wet hands.
-Do not place the appliance against a wall or against other appli-
ances. Leave at least 10cm free space on the back and sides and
10cm free space above the appliance.
-Do not place anything on top of the appliance.
-Do not use the appliance for any other purpose than described in
this manual.
Warning

-3- - 4-
-Do not let the appliance operate unattended.
-During hot air frying, hot steam is released through the air outlet
openings, Keep your hands and face at a safe distance from the
steam and from the air outlet openings. Also be careful of hot steam
and air when you remove the pan from the appliance.
-Any accessible surfaces may become hot during use .
-Immediately unplug the appliance if you see dark smoke coming out
of the appliance. Wait for the smoke emission to stop before you
remove the pay from the appliance.
-Never connect this appliance to an external timer switch or separate
remote-control system in order to avoid a hazardous situation.
-Do not place the appliance on or near combustible materials such
as a tablecloth or curtain.
-After using the appliance, the metal cover inside is very hot, avoid to
contact the hot metal inside after cooking.
- Only connect the appliance to an earthed wall socket. Always make
sure that the plug is inserted into the wall socket properly.
-Ensure the appliance in placed on a horizontal, even and stable
surface.
-This appliance is designed for household use only. It may not suit-
able to be safely used in environments such as staff kitchens, farms,
motels, and other non-residential environments. Nor is it intended to
be used by clients in hotels, motels, bed and break- fasts and other
residential environments.
-If the appliance is used improperly or for professional or semi-pro-
fessional purposes or if it is not used improperly or for professional or
semi-professional purposes or it is not used according to the instruc-
tions in the user manual, the guarantee becomes invalid and we
could refuse any liability for damage caused.
-Always unplug the appliance while not using.
-The appliance needs approximately 30 minutes to cool down for
handle or cleaning safely.
Caution
- The appliance with overheating protection system, if the inner
temperature control system invalid, the overheating protection is
automatically turned on, the appliance is no longer ready to be
used. Unplug the mains cord.
- Only after the appliance has been left to cool down completely
should the RESET button at the bottom of the machine (beside the
rating label) be operated in order to use the air fryer again. Please
use a pointed object for this purpose(refer to the figures hereinafter).
Overheating Protection
This appliance is equipped with a timer, when the timer has count-
ed down to 0, the appliance produces a bell sound and switches off
automatically. To switch off the appliance manually, turn the timer
knob anticlockwise to 0.
Note: If pull out the pan during cooking, the appliance will be
switched off automatically, too.(Timer still in counting down).
Automatic switch-off

-5- - 6-
Hot air frying
1.Connect the mains plug into an earthed wall socket.
2.Carefully pull the pan out of the Hot-air fryer.
3. Put the ingredients in the basket.
Note: Never fill the basket in full or exceed the recommended
amount (see section ‘Settings’ in this chapter), as this could
affect the quality of the end result.
4. Slide the pan back into the Hot-air fryer.
Never use the pan without the basket in it.
If the pan doesn’t be fixed into the air fryer properly, the
appliance won’t work!
Caution: Do not touch the pan during and some time after use,
as it gets very hot. Only hold the pan by the handle.
5.Determine the required preparation time for the ingredient ( see
section ‘Settings’ in this chapter).
6.To switch on the appliance, turn the timer knob to the required
preparation time.
7.Turn the temperature control knob to the required temperature. See
section ‘Settings’ in this chapter to determine the right temperature.
Add 3 minutes to the preparation time when the appliance is cold.
Note: If you want, you can also let the appliance preheat
without any ingredi- ents inside. In that case, turn the timer
knob to more than 3 minutes and wait until the heating-up light
goes out ( after approx. 3 minutes). Then fill the basket and
turn the timer knob to the required preparation time.
a.The power-on light and the heating-up light go on.
b.The timer starts counting down the set preparation time.
c.During the hot air frying process, the heating-up light comes on
and goes out from time to time. This indicates that the heating
element is switched on and off to maintain the set temperature.
d.Excess oil from the ingredients is collected on the bottom of the pan.
8.Some ingredients require shaking halfway through the preparation
time. To shake the ingredients, pull the pan out of the appliance by
the handle and shake it. Then slide the pan back into the I fryer.
1.Remove all packaging materials
2.Remove any stickers or labels from the appliance
3.Thoroughly clean the basket and pan with hot water, some wash-
ing-up liquid and a non-abrasive sponge.
Note: You can also clean these parts in the dishwasher.
4.Wipe inside and outside of the appliance with a moist cloth.
This is an oil-free fryer that works on hot air, Do not fill the pan
with oil or frying fat.
BEFORE FIRST USE
1. Place the appliance on a stable, horizontal and level surface.
Do not place the appliance on non-heat-resistant surfaces.
2. Place the basket in the pan properly
3. Put the pan into the machine.
Note: the pan MUST be put into the appliance properly, other-
wise the appliance doesn’t work!
4. Pull the mains cord and plug into the earthed wall socket.
Do not fill the pan with oil or any other liquid.
Do not put anything on top of the appliance.
Do not put anything on the air-inlet on the two sides of the
appliance, this disrupts the airflow and affects the hot air
frying result.
The oil-free can prepare a large range of ingredients. The recipe
booklet included helps you get to know the appliance. Pls refer to
the section “settings” table hereinafter and the using guidance
figures at last page.
PREPARING FOR USE
USING THE APPLIANCE

-7- - 8-
Caution: Do not press the button the handle during shaking.
Tip: To reduce the weight, you can remove the basket from the pan
and shake the basket only. To do so, pull the pan out of the appli-
ance, place it on a heat-resistant surface and press the button of
handle. and lift the basket out of the pan
Tip: If you set the timer to half the preparation time, you hear the
timer bell when you have to shake the ingredients. However, this
means that you have to set the timer again to the remaining prepa-
ration time after shaking.
9.When you hear the timer bell, the set preparation time has
elapsed. Pull the pan out of the appliance and place it on a heat-re-
sistant surface.
Note: You can also switch off the appliance manually. To do
this, turn the time control knob to 0 or pull out the pan directly.
10.Check if the ingredients are ready.
If the ingredients are not ready yet, simply slide the pan back into
the appliance and set the timer to a few extra minutes.
11.To remove ingredients (e.g. fries), pull the pan out of the Hot-air
fryer and place it on trial framework, and press the basket release
button and lift the basket out of the pan.
Do not turn the basket upside down with the pan still attached
to it, as any excess oil that has collected on the bottom of the
pan will leak onto the ingredients.
The pan and the ingredients are hot and hot fryer. Depending on
the type of the ingredients in the I fryer, steam may escape from
the pan.
12.Empty the basket into a bowl or onto a plate.
Tip: To remove large or fragile ingredients, lift the ingredients out of
the basket by a pair of tongs.
13.When a batch of ingredients is ready, the Hot-air fryer is instantly
ready for preparing another batch.
14.If you want to cook two ingredients at the same time, you
can use the basket separator to divide them and prevents the
flavor mixing with each other.
After hot air frying, the pan and the inside metal cover are hot,
avoid to touch is needed.
Settings
This table below will help you to select the basic settings for the
ingredients.
Note: Keep in mind that these settings are indications. As
ingredients differ in origin, size, shape as well as brand, we
cannot guarantee the best setting for your ingredients.Because
the Rapid Air technology instantly reheats the air inside the
appliance instantly.
Pull the pan briefly out of the appliance during hot air frying barely
disturbs the process.
Tips
-Smaller ingredients usually require a slightly shorter preparation
time than larger ingredients.
-A larger amount of ingredients only requires a slightly longer prepa-
ration time, a smaller amount of ingredients only requires a slightly
shorter preparation time.
-Shaking smaller ingredients halfway through the preparation time
optimizes the end result and can help prevent unevenly fried ingre-
dients.
-Add some oil to fresh potatoes for a crispy result. Fry your ingredi-
ents in the Hot-air fryer within a few minutes after you added the oil.
-Do not prepare extremely greasy ingredients such as sausages in
the Hot-air fryer .
-Snacks that can be prepared in a oven can also be prepared in the
Hot-air fryer
-The optimal amount for preparing crispy fries is 500 grams.
-Use pre-made dough to prepare filled snacks quickly and easily.
Pre-made dough also requires a shorter preparation time than
home-made dough.
-Place a baking tin or oven dish in the Hot-air fryer basket if you
want to bake a cake or quiche or if you want to fry fragile ingredi-
ents or filled ingredients
-You can also use the Hot-air fryer to reheat ingredients. To reheat
ingredients, set the temperature to 150℃for up to 10 minutes.

-9- - 10-
Min-max
Amount(g) Time (min.) temperature
(℃)
Shake Extra
information
Potatos & fries
Meat & Poultry
Snacks
Baking
Thin frozen fries
Thick frozen fries
Potato gratin
Steak
Pork chops
Hamburger
Sausage roll
Drumsticks
Chicken breast
Cake
Quiche
Muffins
Sweet snacks
Spring rolls
Frozen chicken
nuggets
Frozen fish fingers
Frozen breadcrumbed
cheese snacks
Stuffed vegetables
300-700
300-700
500
100-500
100-500
100-500
100-500
100-500
100-500
100-400
100-500
100-400
100-400
100-400
300
400
300
400
8-12
10-14
7-14
13-15
18-22
10-15
8-10
6-10
6-10
8-10
10
20-25
20-22
15-18
20
320
360
400
320
180
180
180
200
360
360
400
400
400
360
320
shake
shake
9-16
20-25
15-18
200
200
200
shake
shake
shake
Note: Add 3 minutes to the preparation time when you start frying
while the air fryer is still cold.
Use oven-ready
Use oven-ready
Use oven-ready
Use oven-ready
Use baking tin
Use baking tin/
oven dish
Use baking tin
Use baking tin/
oven dish
Clean the appliance after every use.
Don’t touch the hot metal inside before cleaning while just after
frying. Cool down the appliance is needed before cleaning!
The pan and the non-stick coating basket. Do not use metal kitchen
utensils or abrasive cleaning materials to clean them, as this may
damage the non-stick coating.
1.Remove the mains plug from the wall socket and let the appliance
cool down. Note: Remove the pan to let the Hot-air fryer cool down
more quickly.
2.Wipe the outside of the appliance with a moist cloth.
3.Clean the pan, separator and basket with hot water, some wash-
ing-up liquid and a non-abrasive sponge.
You can use degreasing liquid to remove any remaining dirt.
Note: The pan and basket are dishwasher-proof.
Tip: If dirt is stuck to the basket or the bottom of the pan, fill the pan
with hot water with some washing-up liquid. Put the basket in the pan
and let the pan and the basket soak for approximately 10 minutes.
4.Clean the inside of the appliance with hot water and non-abrasive
sponge.
5.Clean the heating element with a cleaning brush to remove any
food residues.
CLEANING
STORAGE
1. Unplug the appliance and let it cool down.
2. Make sure all parts are clean and dry.
3. Put the air fryer on the clean and dry place.

-11- - 12-
WARRANTY INFORMATION
ENVIRONMENT
This marking indicates that this product should not be disposed with
other household wastes throughout the EU. To prevent possible
harm to the
environment or human health from uncontrolled waste disposal, recy-
cle it responsibly to promote the sustainable reuse of material resourc-
es. To return your used device, please use the return and collection
systems or contact the retailer where the product was purchased. They
can take this product for environmental safe recycling.
The manufacturer provides warranty in accordance with the legisla-
tion of the customer's own country of residence, with a minimum of
18 months, starting from the date on which the appliance is sold to
the end user.
The warranty only covers defects in material or workmanship. The
warranty will not apply in cases of:
-Normal wear and tear
-Incorrect use, e.g. overloading of the appliance, use of non-ap-
proved accessories
-Use of force, damage caused by external influences
-Damage caused by non-observance of the user manual, e.g.
connection to an unsuitable mains supply or non-compliance with
the installation instructions
-Partially or completely dismantled appliances.
TROUBLESHOOTING
problem
The air fryer does
not work
The ingredients fried
with the air fryer are
not done.
The appliance is not
plugged in.
Put the mains plug in
an earthed wall socket.
You have not set the
timer.
The pan is not put into
the appliance properly
Turn the timer knob to
the required prepara-
tion time to switch on
the appliance.
Slide the pan into the
appliance properly.
The overheating
protection is turned on
The amount of ingre-
dients in the basket is
too big.
The set temperature
is too low.
The preparation time
is too short.
Turn the temperature
control knob to the required
temperature setting (see
section ‘settings’ in chapter
‘Using the appliance’).
Turn the timer knob to the
required preparation time
(see section ‘Settings’ in
chapter’ Using the appliance’).
Put smaller batches of
ingredients in the basket.
Smaller batches are
fried more evenly.
Use a pointed object
to press the RESET
button at the bottom
of the appliance.
Possible cause Solution
The ingredients are
fried unevenly in the
air fryer.
Fried snacks are not
crispy when they come
out of the air fryer.
You used a type of
snacks meant to be
prepared in a tradition-
al deep fryer.
Use oven snacks or
lightly brush some oil
onto the snacks for a
crispier result.
Certain types of
ingredients need to be
shaken halfway through
the preparation time.
Ingredients that lie on top of
or across each other (e.g.
fries) need to be shaken
halfway through the prepara-
tion time. See section
‘Settings’ in chapter ‘Using the
appliance’.

-13-
I cannot slide the pan
into the appliance
properly.
White smoke comes
out of the appliance.
Fresh fries are fried
unevenly in the air
fryer.
Fresh fries are not
crispy when they
come out of the air
fryer.
The crispiness of the
fries depends on the
amount of oil and
water in the fries.
You are preparing
greasy ingredients.
The pan still contains
grease residues from
previous use.
You did not use the
right potato type.
You did not rinse the
potato sticks properly
before you fried them.
White smoke is caused
by grease heating up
in the pan. Make sure
you clean the pan
properly after each use.
Use fresh potatoes and
make sure they stay
firm during frying.
Rinse the potato sticks
properly to remove
starch from the outside
of the sticks.
Make sure you dry the
potato sticks properly
before you add the oil.
Cut the potato sticks
smaller for a crispier
result.
Add slightly more oil
for a crispier result.
When you fry greasy
ingredients in the air fryer, a
large amount of oil will leak
into the pan. The oil produc-
es white smoke and the pan
may heat up more than usual.
This does not affect the
appliance or the end result.
There are too much
ingredients in the
basket.
The basket is not
placed in the pan
correctly.
Push the basket down
into the pan until you
hear a click.
Do not fill the basket
beyond in full, refer to
the “Setting” table above.
