Tidylife AF1835A1 User manual

AIR FRYER
READ THIS BOOKLET THOROUGHLY
BEFORE USING AND SAVE IT FOR FUTURE REFERENCE
INSTRUCTION MANUAL
AF1835A1
Made In China
HOUSEHOLD USE ONLY
Shenzhen TidylifeTrading Co., Ltd.
Xingduhaoting,Buji Street,Longgang District,Shenzhen
Facebook Page:www.facebook.com/Tidylifeservice
Website:www.tidylife.cc

Introduction
Your new air fryer allows you to prepare your favorite ingredients
and snacks in a healthier way. The air fryer uses hot air in combi-
nation with high-speed air circulation (rapid hot air) and a top
grill to prepare a variety of tasty dishes in a healthy, fast and easy
way. Your ingredients are heated from all sides at once and there
is no need to add oil to most of the ingredients.
Touchscreen Air Convection Fryer
Product may vary slightly from illustrationTouchscreen Air Convection Fryer
1 2
POWER on/off, plug in, this light will be on, pls touch this to
make the appliance ready.
MODE, touch this to choose the cooking menu and
start/stop the process. Long press 3 seconds to start the
program you chose. Then it will flicker quickly during working
process.
Note: If you want to change the mode from one to another,
need to touch this first to pause the process.
Note: this symbol will slow flicker when paused or before
working process, and quick flicker during working.
COOKING, after you chose the mode, the fans will flicker
quickly, means it’s working.
Note: this symbol will slow flicker when paused or before
working process. And quick flicker during working.
TEMPERATURE. By touch the up and down symbol to adjust
the temperature you want.
TIMER. By touch the up and down symbol to adjust the time
you want.
PLUS. Touch this to plus the cooking time and termpature
accordingly.
MINUS. Touch this to minus the cooking time and termpa-
ture accordingly.
General description
Control Panel Details
Removable Frying Basket
with Cool Touch Handle
Basket Release Button
Clear Basket Lock
Frying Basket Drawer
Air Inlets
Air Outlet (not show)
Touchscreen Control
Air Convection Fryer Body
Power Cord with Polarized Plug
Non-skid Feet

34
Settings of Control Panel:
Important
Warning
- This appliance is not intended for use by persons (including
children younger 8) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they
have been given supervision or instruction concerning the use
of appliance by a person responsible for their safety.
- Check if the voltage indicated on the appliance corresponds
to the local mains voltage before you connect the appliance.
- Do not use the appliance if the plug, the mains cord or the
appliance itself is damaged.
- If the mains cord is damaged, you must have it replaced by the
manufacturer, its service agent or similarly qualified persons in
order to avoid a hazard.
- Children should be supervised to ensure that they do not play
with the appliance. Cleaning and user maintenance shall not
be made by children unless they are older than 8 and super
vised.
- Keep the appliance and its mains cord out of the reach of
children younger than 8 when the appliance is switched on or is
cooling down.
- Keep the mains cord away from hot surfaces.
- Do not plug in the appliance or operate the control panel with
wet hands.
- Only connect the appliance to an earthed wall socket. Always
make sure that the plug is inserted into the wall socket properly.
- Never connect this appliance to an external timer switch or
separate remote-control system in order to avoid a hazardous
situation.
- Do not place the appliance on or near combustible materials
such as a tablecloth or curtain.
- Do not place the appliance against a wall or against other
appliances. Leave at least 10cm free space on the back and
sides and 10cm free space above the appliance. Do not place
anything on top of the appliance.
ModeMode Default Temp Default Time
French Fry
Roast
Shrimp
Cake
Chicken
Steak
Fish
200°C
185°C
160°C
150°C
180°C
200°C
180°C
18 min
25 min
8 min
30 min
20 min
12 min
10 min
Please read this manual carefully before you use the appliance
and save it for future reference..
Danger
- Never immerse the housing, which contains electrical compo
nents and the heating elements, in water nor rinse under the
tap.
- Avoid any liquid enter the appliance to prevent electric shock
or short-circuit.
- Keep all ingredients in the basket, to prevent any contact with
the heating elements.
- Do not cover the air inlet and the air outlet while the appliance
is working.
- Do not fill the pan with oil as this may cause a fire hazard.
- Never touch the inside of the appliance while it is operating.

Caution
- Place the appliance on a horizontal, even and stable surface.
- This appliance is intended for normal household use only. It is not
intended for use in environments such as staff kitchens of shops,
offices, farms or other work environments. Nor is it intended to
be used by clients in hotels, motels, bed and breakfasts and
other residential environments.
- If the appliance is used improperly or for professional or
semi-professional purposes or if it is not used according to the
instructions in the user manual, the guarantee becomes invalid
and we could refuse any liability for damage caused.
- Always unplug the appliance after use.
- Let the appliance cool down for approx. 30 minutes before you
handle or clean it.
- Make sure the ingredients prepared in this appliance come out
golden-yellow instead of dark or brown. Remove burnt rem
nants.
- The appliance with the micro switch inside, when pull out the
pan during cooking, the appliance will be shut-off power auto
matically.
- Do not use the appliance for any other purpose than described
in this manual.
- Do not let the appliance operate unattended.
- During hot air frying, hot steam is released through the air outlet
openings. Keep your hands and face at a safe distance from
the steam and from the air outlet openings. Also be careful of
hot steam and air when you remove the pan from the appli
ance.
- The accessible surfaces may become hot during use.
- After using the appliance, the metal cover inside is very hot,
avoid to contact the hot metal inside after cooking.
- Immediately unplug the appliance if you see dark smoke
coming out of the appliance. Wait for the smoke emission to
stop before you remove the pan from the appliance.
56
1. Remove all packaging material.
2. Remove any stickers or labels from the appliance.
3. Thoroughly clean the basket and pan with hot water, some
washing-up liquid and a non-abrasive sponge.
Note: You can also clean these parts in the dishwasher.
4. Wipe the inside and outside of the appliance with a moist
cloth.
This is an air fryer that works on hot air. Do not fill the pan with oil
or frying fat.
Before first use
1. Place the appliance on a stable, horizontal and level surface.
Do not place the appliance on non-heat-resistant surfaces.
2. Place the basket in the pan properly
3. Put the pan into the machine.
Note: the pan MUST be put into the appliance properly, otherwise
the appliance doesn’t work!
4. Pull the mains cord and plug into the earthed wall socket.
Do not fill the pan with oil or any other liquid.
Do not put anything on top of the appliance.
Do not put anything on the air-inlet on the two sides of the appli-
ance, this disrupts the airflow and affects the hot air frying result.
Preparing for use
The air fryer can prepare a large range of ingredients. Use the
recipes included in the procut package and the section “set-
tings” table hereinafter to its full potential.
Hot air frying
1. Connect the mains plug into an earthed wall socket.
2. Carefully pull the pan out of the air fryer.
3. Put the ingredients into the basket.
Using the appliance

Note: Never fill the basket above the recommended amount as
this could affect the quality of the end result or interfere with the
electric heating coils.
4. Slide the pan back into the air fryer properly.
Never use the pan without the basket in it.
If the pan doesn’t be fixed into the air fryer properly, the appli-
ance won’t work!
Caution: Do not touch the pan during and right after use, as it
gets very hot. Only hold the pan by the handle.
5. Touch the preset menu symbol to start the cooking process.
6. Determine the required preparation time and temperature for
the ingredients by touch the button up and down if the default
time and temperature not your desired.
7. Some ingredients require shaking halfway through the prepara-
tion time, especially the large quantity. To shake the ingredients,
pull the pan out of the appliance by the handle and shake it.
Then slide the pan back into the air fryer and continue to cook.
Caution: Do not press the button of the handle during shaking.
Tip: To reduce the weight, you can remove the basket from the
pan and shake the basket only. To do so, pull the pan out of the
appliance, place it on a heat-resistant surface and press the
button of the handle.
Tip: If you set the timer to half the preparation time, you hear the
timer bell when you have to shake the ingredients. However, this
means that you have to set the timer again to the remaining
preparation time after shaking.
Tip: If you set the timer to full preparation time, there is no timer
bell during cooking before finishing, you can pull out the pan at
any time to check the ingredients cooking condition, the appli-
ance will pause automatically and resume after slide the pan
back into the appliance(timer still on).
9. When you hear the timer bell, the set preparation time has
elapsed. Pull the pan out of the appliance and place it on a
heat-resistant surface.
Note: You can also switch off the appliance manually. To do this,
touch the power button, or touch the TIMER- button to 0, or pull
out the pan directly.
10. Check if the ingredients are ready.
If the ingredients are not ready yet, simply slide the pan back into
the appliance and set the timer to a few extra minutes.
11. To remove small ingredients, press the basket release button
and lift the basket out of the pan.
Do not turn the basket upside down with the pan still attached to
it, as any excess oil that has collected on the bottom of the pan
will leak onto the ingredients.
After hot air frying, the pan and the ingredients are hot. Depend-
ing on the type of the ingredients in the air fryer, steam may
escape from the pan.
12. Empty the basket into a bowl or onto a plate.
Tip: To remove large or fragile ingredients, use a pair of tongs to
lift the ingredients out of the basket
13. When a batch of ingredients is ready, the air fryer is instantly
ready for preparing another batch.
Making home-made fries
To make home-made fries, follow the steps below.
1. Peel the potatoes and cut them into sticks.
2. Wash the potato sticks thoroughly and dry them with kitchen
paper.
78

3. Pour 1/2 tablespoon of olive oil in a bowl, put the sticks on top
and mix until the sticks are coated with oil.
4. Remove the sticks from the bowl with your fingers or a kitchen
utensil so that excess oil stays behind in the bowl. Put the sticks in
the basket.
Note: Do not tilt the bowl to put all the sticks in the basket in one
go, to prevent excess oil from ending up on the bottom of the
pan.
5. Fry the potato sticks according to the instructions in this chap-
ter.
910
Clean the appliance after every use.
The pan and the basket are non-stick coated, do not use metal
kitchen utensils or abrasive cleaning materials to clean them, as
this may damage the non-stick coating.
1. Remove the mains plug from the wall socket and let the appli-
ance cool down.
Note: Remove the pan to let the air fryer cool down more quickly.
2. Wipe the outside of the appliance with a moist cloth.
3. Clean the pan and the basket with hot water, some wash-
ing-up liquid and a non-abrasive sponge.
You can use a degreasing liquid to remove any remaining dirt.
Tip: If dirt is stuck to the basket or the bottom of the pan, fill the
pan with hot water with some washing-up liquid. Put the basket in
the pan and let the pan and the basket soak for approximately
10 minutes.
4. Clean the inside of the appliance with hot water and
non-abrasive sponge.
5. Clean the heating element with a cleaning brush to remove
any food residues.
Cleaning
1. Unplug the appliance and let it cool down.
2. Make sure all parts are clean and dry.
3. Put the air fryer on the clean and dry place.
Storage
Do not throw away the appliance with the normal household
waste at the end of its life, but hand it in at an official collection
point for recycling. By doing this, you help to preserve the envi-
ronment.
Environment
The manufacturer provides warranty in accordance with the
legislation of the customer's own country of residence, with a
minimum of 18 months, starting from the date on which the
appliance is sold to the end user.
The warranty only covers defects in material or workmanship. The
warranty will not apply in cases of:
-Normal wear and tear
-Incorrect use, e.g. overloading of the appliance, use of non-ap-
proved accessories
-Use of force, damage caused by external influences
-Damage caused by non-observance of the user manual, e.g.
connection to an unsuitable mains supply or non-compliance
with the installation instructions
-Partially or completely dismantled appliances.
If you need service or information or if you have a problem,
please visit our website or contact our customer service team.
Guarantee and service

11
Troubleshooting
problem
The air fryer does
not work
The appliance is not plugged in.
You have not set the timer.
The pan is not put into the
appliance properly
The overheating protection
is turned on
Put the mains plug in an earthed wall socket.
Turn the timer knob to the required
preparation time to switch on the appliance.
Slide the pan into the appliance properly.
Use a pointed object to press the RESET button
at the bottom of the appliance.
Possible cause Solution
The ingredients fried
with the air fryer are
not done.
The ingredients are
fried unevenly in the air
fryer.
Certain types of ingredients
need to be shaken halfway
through the preparation time.
The amount of ingredients
in the basket is too big.
The set temperature is too
low.
The preparation time is too
short.
Put smaller batches of ingredients in the basket.
Smaller batches are fried more evenly.
Turn the temperature control knob to the required
temperature setting (see section ‘settings’ in chapter
‘Using the appliance’).
Turn the timer knob to the required preparation time
(see section ‘Settings’ in chapter’ Using the appliance’).
Ingredients that lie on top of or across each other
(e.g.fries) need to be shaken halfway through the
preparation time. See section‘Settings’ in chapter ‘Using
the appliance’.
Fried snacks are not
crispy when they come
out of the air fryer.
I cannot slide the pan into
the appliance properly.
White smoke comes out
of the appliance.
Fresh fries are fried
unevenly in the air fryer.
Fresh fries are not crispy
when they come out of
the air fryer.
You used a type of snacks
meant to be prepared in a
traditional deep fryer.
There are too much
ingredients in the basket.
The basket is not placed in
the pan correctly.
You are preparing greasy
ingredients.
The pan still contains grease
residues from previous use.
You did not use the right potato
type.
You did not rinse the potato sticks
properly before you fried them.
The crispiness of the fries
depends on the amount of oil and
water in the fries.
Use oven snacks or lightly brush some oil onto the
snacks for a crispier result.
Do not fill the basket beyond in full, refer to the “Setting”
table above.
Push the basket down into the pan until you hear a
click.
White smoke is caused by grease heating up in the pan .
make sure you clean the pan properly after each use.
Use fresh potatoes and make sure they stay firm during
frying.
Rinse the potato sticks properly to remove starch from
the outside of the sticks.
Make sure you dry the potato sticks properly before you
add the oil.
Cut the potato sticks smaller for a crispier result.
Add slightly more oil for a crispier result.
When you fry greasy ingredients in the air fryer, a large
amount of oil will leak into the pan. The oil produces
white smoke and the pan may heat up more than usual.
This does not affect the appliance or the end result.
