Tiger Box 4U24 Assembly Guide Product Overview: Product Overview
3
Congratulations on your purchase of Tiger Box 4U24, Tiger Technology’s all-in-one
shared storage appliance. This manual describes how to install and connect Tiger Box
4U24 at your site - from unpacking the appliance to powering on the system and
setting it up.
Before proceeding, make sure that you have read carefully all instructions, paying
special attention to the following symbols used in this guide:
SAFETY WARNING
IMPORTANT NOTE
TIP
You can find the most up-to-date version of this manual at the following address:
https://www.tiger-technology.com/software/tiger-store/docs
Product Overview
Tiger Box 4U24 is a state of the art, high-performance shared storage system that
offers the simplicity of NAS and the performance characteristics of a true SAN. The
rack-mountable 4U appliance combines a metadata controller and highly optimized
RAID 5 storage, comprised of 24 enterprise-class drives (drive capacity depends on
specific configuration), which can be accessed by client computers via 8/16Gb Fibre
Channel, 10Gb Ethernet and/or 1Gb Ethernet.
The appliance is shipped fully configured to you. To deploy it you should simply:
1. Rack-mount the appliance or install it on a table top (see “Install Tiger Box” on
page 6).
2. Connect the appliance to the power source (see “Connecting The Appliance to The
Power” on page 7).
3. Turn on the appliance (see “Powering On The Appliance” on page 8).
4. Connect client computers to the ports of the appliance - 8/16Gb FC,10GbE and/or
1GbE, depending on the model (see “Cabling Tiger Box” on page 8).
5. Perform the initial setup of the appliance (see “Initial Setup of the Appliance” on
page 18).
Tiger Box 4U24 Features
• 4U, 19'' rack-mount chassis with excellent anti-vibration mechanical design and
thermal solution.
• RAID 5 shared storage comprised of 24 hot-swappable drives (a failed RAID drive
can be replaced while the system is operating and no data on the volume will be lost).
• 8/16Gb Fibre Channel, 10GbE and/or 1GbE ports for connecting client computers.
• Redundant power supply (a failed power module can be replaced while the system is
operating).
• 1 x internal 2.5" system drive.
• 2 x SAS ports for directly connecting Tiger Boxexpansion chassis.
• Tiger Store software for shared storage management and diagnostics.

Tiger Box 4U24 Assembly Guide Product Overview: Package Content
4
Package Content
The package you have received weighs approximately 40 kg (88.7 lbs) and has the
following dimensions:
It must contain the following:
• 1 x 4U, 19" rack-mount chassis with 24 x 3.5” or 2.5" disks each installed in a hot-
swappable drive carrier
• ( optional )1 xsparediskinstalledina hot-swappabledrivecarrierforonlinerecovery
of a failed RAID disk
• 1 x rack-mount rails kit
• 2 x power cables
• 1 x 1.80m UTP network cable
• 1 x system restore USB flash drive
• 1 x Tiger Box reset tool (used for pressing the shut down and reset buttons at the
front of the appliance)
Important: If any of the components listed above is missing from your
shipment, please contact your reseller or Tiger Technology support
immediately.
Important: Check if both warranty stickers at the back of the chassis are
intact. If a warranty sticker is damaged, immediately contact Tiger
Technology at [e-mail]
Hardware Overview
Note: The pictures used to illustrate the product in this manual may differ from the
Tiger Box appliance you have received depending on the model and firmware version.
Technical Characteristics
Description Specification
Chassis dimensions Height 7" (178 mm)
Width 17.2" (437 mm)
Depth 26" (660 mm)
Gross weight
(with RAID drives installed) approx. 34 kg/75 lbs
Power Consumption Max 800W: 100-127V a.c./12-9A/50-60Hz
1000W: 200-240V a.c./7.2-6A/50-60Hz
Power Supply Unit 1U 1280W Redundant Platinum 95%+ Super Quiet
Power Supply with PMbus
Temperature Range Operating: 5°C - 35°C (41°F - 95°F)
Non-operating: -40°C - 70°C (-40°F - 158°F)
Humidity Range 8% - 90% (non-condensing)

Tiger Box 4U24 Assembly Guide Product Overview: Hardware Overview
5
Front View
Note: Your Tiger Box appliance is shipped to you with its front panel bezel already
installed and to view the front panel you need to remove the bezel, following the steps
in “Install/Remove The Front Panel Bezel” on page 7.
Apart from the 24 drive bays for the drives comprising the shared storage, Tiger Box's
front panel features the following elements:
• LED indicators for monitoring system activity (see “Monitoring the
System Activity” on page 11).
• system reset button
• system power button
Rear View
The back of the appliance features the following elements:
• 2 x power supply modules
• 2 x system hard drives
• 2 x SAS port for directly connecting a Tiger Box expansion chassis
• depending on the configuration you have purchased client connectivity through:
• 8/16Gb FC ports;
• 10Gb Ethernet ports;
• 1Gb Ethernet ports;
• 1 x Ethernet port for public and Internet communication (Public port).
• 1 x Ethernet port for safety net access to the appliance (Admin port).
Tiger Box supports the following types of cables for connection of client computers
and/or switches:
Clients via Fibre Channel — fibre optic cable with LC connectors for SFP+
transceivers.

Tiger Box 4U24 Assembly Guide Site Installation: Site Installation
6
Clients via 10GbE — depending on the 10GbE adapter model:
• fiber-optic cable with LC connectors for SFP+ transceiver or copper cable with SFP+
transceiver
• patch cable with RJ-45 modular connectors
Clients via 1GbE — patch cable with RJ-45 modular connectors.
Site Installation
Unpack Tiger Box
Important: Do not throw away any of the packaging components, until you
ensure that the appliance works properly and there is no need to return any
part.
Tip: It is advisable to keep all packaging components until the warranty of
your appliance expires.
1. Cut the straps of the box, cut or remove the tape and open the flaps.
2. Take out the rack-mount rails kit.
3. Take out the box, containing the power cables, the network cable, the Tiger Box
System Restore USB Flash Drive and the spare RAID drive (if your order includes
one).
4. Take out the two foamprotectors and take the appliance out of the box and place it
on a surface, ensuring that the system remains stable.
Important: Tiger Box 4U24 weighs approximately 34 kg/75 lbs.
Attempting to move it without assistance could cause personal injury.
Request assistance and use proper lifting techniques when lifting the
appliance.
Install Tiger Box
Before installing Tiger Box 4U24 in a rack or on a table top, consider the limitations
for maximum cable lengths, when deciding on the location of the appliance within
your facility. Also check the appliance's technical characteristics to make sure that the
rack/the table meets the physical, electrical, and thermal specifications.
Rack-mount Tiger Box
You can mount Tiger Box 4U24 in a standard, 19-inch-wide, four-post rack.
A rack-mount rails kit is included in your shipping. If you are installing Tiger Box in a
rack, follow the instructions supplied in the rack-mount rails kit to install the
appliance.
Tip: Install the heaviest devices in the lowest position in the rack.
Install Tiger Box on a Table Top
If you do not plan to install your Tiger Box 4U24 in a rack, and you opt for tabletop
installation, ensure that:
• the surface is clean and in a safe location;
• the appliance is stable, its bottom faces down and its top faces up.
Tip: To determine the top and bottom of the appliance, use the text direction
on the printed labels.
• theapplianceis installed off the floortoavoiddrawing dustaccumulatedon thefloor
into the interior of the appliance by the cooling fans.
Important: Excessive dust inside the appliance can cause overheating and
component failures.
• there must be at least 50cm (19 inches) of clearance at the front and rear of the
appliance for installing and replacing the RAID drives, or accessingnetwork cables or
equipment;

Tiger Box 4U24 Assembly Guide Site Installation: Install/
7
• the appliance receives adequate ventilation (it is not being installed in an enclosed
cabinet where ventilation is inadequate);
• the appliance is not in close proximity to devices that emit strong electromagnetic
waves;
Install/Remove The Front Panel Bezel
Tiger Box is shipped with a bezel, which covers the front panel.
You may have to remove the bezel in order to:
• monitor RAID drives activity (see steps on page 12)
• replace a failed RAID drive (see steps on page 14)
• power on/off or restart the appliance
• perform system restore.
Tip: You can install/remove the bezel at any time without having to turn off
or dismount the appliance from the rack.
To remove the bezel:
1. Loosen the thumb screws on either side of the bezel.
2. Gently pull away the bezel from the front panel of the appliance.
To install the bezel:
1. Insert the tabs on each end of the bezel into the flanges on each side of the
appliance's front panel.
2. Screw the two thumb screws on either side clockwise.
Connecting The Appliance to The Power
Your Tiger Box 4U24 is shipped to you with two power supply modules, installed in
the rear of the appliance. These modules supply redundant power to Tiger Box -
should a power supply module fail, you can replace it while the system is operating
(see “Replacing a Failed Power Module” on page 16). You can replace a failed power
module only with a power module of the same model.
To connect the appliance to the power supply:
1. Plug the power cord in the power socket of the power supply module.
2. Connect the power cord to the power outlet.
If the appliance is properly connected, the power module LED indicator will
display solid green light. If there's problem with the module installation, its LED
indicator is amber (solid or blinking) or there is no light at all.

Tiger Box 4U24 Assembly Guide Site Installation: Powering On The Appliance
8
Powering On The Appliance
To power on the appliance:
Note: If the front panel bezel is installed, to power on/off or restart the appliance you
must first remove the bezel, following the steps in“Install/Remove The Front Panel
Bezel” on page 7.
1. Press once the power button on the front panel of the appliance.
2. Wait until the power status LED goes on.
To power off the appliance:
Important: It is advisable to always attempt to shut down the appliance
through the web UI, before resorting to hard shut down.
Press continuously the power button on the front panel of the appliance, until the
power status LED’s light goes off.
To restart the appliance:
Important: It is advisable to always attempt to restart the appliance through
the web UI, before resorting to forced restart of the system.
Press the Reset button on the front panel of the appliance.
Cabling Tiger Box
Tiger Box 4U24 features a Public network port for connection to a computer, from
which to perform the initial setup of Tiger Box and assign IPaddresses to all available
network ports. Before cabling Tiger Box 4U24 it is important to carefully plan the
topology of your network. Client computers can connect to Tiger Box as SAN clients
(connected via Fibre Channel) or LAN clients (connected via 1GbE or 10GbE). While
SANclientsneed theadditionalnetworkconnection (througha 1GbE/10GbEport)for
metadata exchange with Tiger Box, LAN clients use only one network port for both
data traffic and metadata exchange. As metadata overhead is kept to an absolute
minimum, there's no need to connect each SAN client to a separate network port, but
rather connect them to the Public port through an Ethernet switch and spare the
remaining network ports for connecting LAN clients. You can connect client
computers directly to the available FC/10GbE/1GbE ports for full bandwidth, or you
can expand the number ofconnected clients by deploying FC/Ethernet switches. Note
that in this configuration the bandwidth available to each node decreases, as
additional nodes are added.
Important: If you want to connect your Fibre Channel clients using multipathing,
prior to connecting them to the appliance, contact Tiger Technology support for
instructions.
Tiger Box also allows you to team the ports of a single 1/10GbE NIC (the Ethernet
switch or the client computer NIC must support link aggregation). Besides allowing a
network card to be accessed through a single IP address, and sparing you the need to
specify a separate IP address for each port, port teaming also can provide more
bandwidth through a single IP address.
Important: It is advisable when planning the topology of the network, to
make sure that no client computer has more than one network connection
(through two or more IP addresses) to the appliance - for example, direct
connection through a 10GbE port and connection through an Ethernet switch.
Additionally, Tiger Box 4U24 features an Admin network port, which is assigned a
preset IP address, which you cannot change. The Admin port is designed as a safety
net, providing you with access to web interface in case you misconfigure the
appliance’s network identification and fail to connect to it.

Tiger Box 4U24 Assembly Guide Site Installation: Cabling Tiger Box
9
To connect a computer to the Public port:
1. Plug one end of the network cable provided in the shipment in the port with label
Public port.
2. Plug other end of the network cable in the LAN port of the computer, from which
you want to perform the initial setup.
Note: If you intend to provide SAN computers with network communication to the
appliance through the Public port, once you perform the initial setup, you can
disconnect the computer, from which you have performed the setup, and connect
the Public port to an Ethernet switch, to which to connect all SAN computers.
To connect a SAN computer:
Note: Your Tiger Box shipment does not include fiber optic and copper Fibre Channel
cables. The FC ports are with optical SFPs.
1. If your fiber-optic cable has protective caps, remove them.
2. Plug one end of the fiber-optic cable into the SFP socket of the appliance port.
3. Do one of the following:
• Plug other end of the fiber-optic cable in the port of the Fibre Channel card of the
client computer.
• Plug otherend of the fiber-optic cable in the port of the Fibre Channel switch and
then connect the switch to the client computer's FC port.
Note: If you opt for interconnection via switch, refer to your switch documentation
for further setup instructions.
4. Plug one end of the network cable into one of the available network ports of the
appliance.
Note: As metadata overhead is kept to an absolute minimum, there's no need to
connect each SAN client to a separate network port, but rather connect them to
the Public port through an Ethernet switch and spare the remaining network ports
for connecting LAN clients.
5. Do one of the following:

Tiger Box 4U24 Assembly Guide Site Installation: Cabling Tiger Box
10
• Plug other end of the network cable in the port of the network card of the client
computer.
• Plug other end of the network cable in the port of the Ethernet switch and then
connect the switch to the client computer's network port.
Note: If you opt for interconnection via switch, refer to your switch documentation
for further setup instructions.
To connect a LAN computer via 10GbE port:
Note: Your Tiger Box shipment does not include copper and fiber-optic cables.
1. Plug one end of the cable into the 10GbE port of the appliance.
2. Do one of the following:
• Plug other end of the cable in the 10GbE port of the client computer.
• Plug other end of the cable in the 10GbE port of the Ethernet switch and then
connect the switch to the client computer's 10GbE port.
Note: If you opt for interconnection via switch, refer to your switch documentation
for further setup instructions.
To connect a LAN computer via 1GbE port:
Note: Your Tiger Box shipment does not include twisted pair cables.
1. Plug one end of the cable into the network port of the appliance.
2. Do one of the following:
• Plug other end of the cable in the network port of the client computer.
• Plug other end of the cable in the port of the Ethernet switch and then connect the
switch to the client computer's network port.
Note: If you opt for interconnection via switch, refer to your switch documentation
for further setup instructions.

Tiger Box 4U24 Assembly Guide Hardware Monitoring: Hardware Monitoring
11
To connect a computer to the Admin port:
1. Plug one end of the network cable provided in the shipment in the port with label
Admin port.
2. Plug other end of the network cable in the LAN port of the computer, from which
you want to access the web interface.
Important: The Admin port is designed solely as a safety net, allowing you to
access the web interface, when you have misconfigured the appliance’s network
identification and fail to access it from any computer.
Hardware Monitoring
Monitoring the System Activity
The LEDs on the bezel of Tiger Box allow you to monitor the system activity. You can
monitor the system activity without removing the front panel bezel:
Indicator LED color Status Description
power fail LED red solid power supply error

Tiger Box 4U24 Assembly Guide Hardware Monitoring:
12
Monitoring RAID Drives Activity
Note: To monitor RAID drives activity, you should remove the front panel bezel.
You can monitor the activity of the RAID drives using the LED indicators on the top
of each HDD carrier:
Important: To diagnose RAID drive failure, it is advisable to regularly check
the RAID status in the Storage page of Tiger Store’s web UI (refer to the Tiger
Store Administration Guide). Degraded RAID status indicates that a drive has
failed and needs to be replaced with the spare drive, following the steps described in
“Replacing a Failed Drive” on page 14.
Monitoring Client Connectivity
You can monitor the connectivityof SAN/LAN clients using the LEDindicators on the
FC/10GbE/1GbE ports respectively.
FC ports
Your configuration can include 8Gb or 16Gb FC cards. The FC cards are set up to work
in auto mode i.e. their ports transmit datadepending on the connectivity mode of the
client’s (or the switch’s) FC card. You can view the transmission mode through any FC
information LED red solid an overheat condition
has occurred
red slow blinking
(once a second) fan failure, check for an inoperative fan.
red fast blinking
(morethan4timesa
second)
powerfailure,checkfor
a non-operational
power supply.
blue solid The UID button at the
back of the appliance is
pressed. To turn off the
LED, continuously
press the UID button
again.
inactive LED - - -
IPMI port activity LED green blinking there is activity on the
IPMI port
- - offline or no activity
Appliance HDD LED green blinking appliance flash drive
activity
Power LED green solid Thesystem isoperating
and power is properly
supplied to the system
power units.
Indicator LED color Status Description
Activity LED blue blinking I/O activity
blue solid SAS RAID drive is idle
- - SATA RAID drive is idle
Status LED red solid Drive failure
red slow blinking
(once a second) Drive is rebuilding.
red two blinks
followed by a
pause
Drive operates as a hot spare.

Tiger Box 4U24 Assembly Guide Hardware Monitoring: Monitoring Power Supply
13
port using the LED indicators above it. If the FC port LED’s light is off the port is
inactive.
8Gb Cards
16Gb Cards
10 GbE Ports
You can view the status of your connection through a 10GbE port using the LED
indicator above it.
1 GbE Ports
You can view the status of your connection through an 1 GbE port using the LED
indicators above it.
Monitoring Power Supply
You can monitor the activity of the power modules using their LED indicator:
Indicator LED color Status Description
left green solid 2Gb mode
right green solid 4Gb mode
both green solid 8Gb mode
Indicator LED color Status Description
left green solid 4Gb mode
right green solid 8Gb mode
both green solid 16Gb mode
Indicator LED color Status Description
activity LED
(left indicator) green blinking The adapter is sending or receiving network data at up to
10Gbps.
- - No network activity on the link.
link LED
(right indicator) amber solid or blinking The 10GbE LAN card is initialized.
- - The adapter is not receiving
powerorthe10GbELANcardis
not initialized.
Indicator LED color Status Description
speed LED
(left indicator)
amber solid Operating as a Gigabit
connection (1000 Mbps).
green solid Operating as a 100-Mbps
connection.
- - Operating as a 10-Mbps
connection.
link LED
(right indicator) green blinking There is activity on this port.
- - No link is established.
Indicator LED color Status Description

Tiger Box 4U24 Assembly Guide Post Installation Maintenance:
14
Post Installation Maintenance
Replacing a Failed Drive
You can replace a failed hard disk, while Tiger Box 4U24 is operating and no data on
the storage will be lost. If your order includes a spare drive, it is shipped to you pre-
installed in a drive carrier and is ready to replace the one that has failed.
You can also replace a failed drive with a drive not included in your shipment. In this
case the new drive must be exactly the same size and make as the one that has failed.
Additionally, you should uninstall the failed drive from its drive carrier and then
install the replacement drive in the carrier.
Important: Periodically check the RAID status in the Storage page of Tiger
Store’s web UI. Degraded RAID status indicates that a drive has failed and
needs to be replaced. If more than one RAID drive fails, the RAID will become
inaccessible and data loss is possible.
To replace a failed RAID disk with the spare drive:
Important: To prevent electrostatic discharge (ESD), touch grounded metal
before touching any of the appliance components. You can also prevent ESD
when inserting the drive carrier into the enclosure, by holding the appliance
enclosure with the other hand.
1. Remove the front panel bezel.
2. Find the failed drive - its HDD status LED indicator (the left indicator) is red.
3. Presstheleverbutton onthe frontof thedrivecarriertoreleasetheleverandgently
pull out the drive carrier.
Important: If by accident you pull out other than the failed drive, the RAID
becomes offline. Insert back the healthy drive and wait until the RAID is again
online. After that find the failed drive and proceed with the steps.
4. ( if your order does not include a spare drive ) Uninstall the failed drive from its
drive carrier and then install the replacement drive in the carrier.
5. ( if your order includes a spare drive ) Take out the drive carrier from its antistatic
bag.
Important: Handle the hard drive by the sides only, making sure you do not
touch the printed circuit board or the connectors.
power module LED
green solid power supply is on
amber
solid power supply is plugged in and
turned off, or the system is off
but in an abnormal state.
blinking power supply temperature has
reached 63°C. The system will
automatically power-down
when the power supply
temperature reaches 70°C and
restart when the power supply
temperature goes below 60°C.

Tiger Box 4U24 Assembly Guide Post Installation Maintenance:
15
6. Press the lever release button on the front of the drive carrier.
The lever opens.
7. Find the label onthe drive that specifies its corresponding drive bay and then slide
the drive carrier into the corresponding slot until the lever makes contact with the
enclosure.

Tiger Box 4U24 Assembly Guide Post Installation Maintenance:
16
8. Push the lever to finish sliding the drive carrier into the drive bay. To ensure that
the lever is locked, you must hear a clicking sound.
9. To check that thedrive carrier is properly installed and makes full contact with the
drive bay, try to pull it out without unlocking the lever.
Important: If the drive carrier can be pulled out, repeat the steps for
installing it from the beginning.
10. Whenthe HDDstatus LEDofthe drive stopsblinking,rebuild the RAID,following
the steps described in the Tiger Store Administration Guide.
Important: Make sure you order an additional spare drive in case another
RAID drive fails in the future.
Replacing a Failed Power Module
Your Tiger Box 4U24 is shipped to you with two power supply modules, installed in
the rear of the appliance. These modules supply redundant power to Tiger Box -
should a power supply module fail, you can replace it while the system is operating.
You can replace a failed power module only with a power module of the same model.

Tiger Box 4U24 Assembly Guide System Restore: System Restore
17
To replace a failed power module:
1. Find the failed power module (the light of its LED indicator is amber).
2. Unplug its power cable from the module's socket.
3. Lift the lever of the powermodule andpushing downthe tab of themodule with the
finger, slide out the unit from the appliance.
4. Slide in the new power module and hear the side tab click into the bay.
5. Push back the lever of the power module to lock it.
6. Plug the power cable in the module's socket and power on the appliance.
System Restore
Important: Do not plug the USB flash drive from your Tiger Box appliance
shipment in the USB port of any other computer.

Tiger Box 4U24 Assembly Guide Initial Setup of the
18
Use the USB flash drive included in your Tiger Box appliance shipment to restore the
appliance to the factory default settings in case of system malfunction or failure.
Important: All your settings (IP addresses, defragmentation preferences, password
for the web interface, etc.) will be lost after restoring the system to the default factory
settings.
Follow the instructions below or contact Tiger Technology support for assistance at:
[e-mail]
To perform system restore:
1. Shut down the appliance.
2. Plug the USB flash drive in the USB port of the appliance and press the power
button to start it.
When the system restore finishes, the appliance automatically shuts down.
3. Unplug the USB flash drive and press the power button of the appliance to start it.
4. Wait several minutes until the appliance node shuts down again and then press the
power button to start it.
Note: On appliances shipped before 20 December 2016, the system restarts
automatically instead of shutting down one last time before the appliance is ready.
To ensure that the system restore is finalized, wait between 5 and 10 minutes
before attempting to access it.
Initial Setup of the Appliance
Before you begin work with the product on a Tiger Box appliance, you need to perform
its initial setup. The initial setup includes the following procedures:
• Configure the IP address of each network port of the appliance (see “Configure the
IP Addresses of the Appliance” on page 20).
• Change thename of the appliance (see “Change the Name of The Appliance” on page
21).
• Specify the time and date settings of the appliance (see “Specify The Time and Date
Settings of the Appliance” on page 22).
• Set the environment in which Tiger Box operates - workgroup or Active Directory
domain (see “Select The Deployment Environment of Tiger Box” on page 22).
Once you go through the initial setup, Tiger Boxcan operate normally without having
to change any of itssettings. Later on you can change any ofthe settings that you have
specified during the initial setup from any computer that has access to Tiger Store’s
web interface.
You can perform the initial setup of the appliance in the web interface of your storage
server.
Access the Web Interface
Tiger Box appliances are shipped to you with preset IP address of the Public port
(172.16.100.100) and a preset address of the Admin port (1.2.3.4 or 1.21.32.1), if such
port is predefined by vendor.
Note: The Admin port is designed as a safety net in case you misconfigure the
appliance’s network identification and fail to connect to it. For detailed procedure,
refer to steps on page 19.
To access the web interface of the appliance for the first time, your computer should
be connected to the Public port of the appliance and should use an IP address that is
on the same subnet as the preset IP address of the Public port. During the initial setup
of Tiger Box, you can change the IP address of the Public port and of all other network
ports of the appliance (except the Admin port), letting all computers on the same
network (with or without the Tiger Client software installed) access Tiger Store’s web
interface.
To access the web interface of the appliance for the first time:
1. Connect your computer to the Public port of the appliance directly or through an
Ethernet switch.
Important: It is advisable to connect directly to the Public port, if another
computer on the network has the same IP address (172.16.100.100), as conflicts
may arise.
2. Make sure the IP address of your computer is on the same subnet as the Public port
(set it to 172.16.100.101, for example).
Note: For more details about changing your IP address, refer to the
documentation of your operating system).

Tiger Box 4U24 Assembly Guide Initial Setup of the
19
Tip: Once you finish the initial setup and set another IP address to the Public port,
you can revert back to your old IP address.
3. In a web browser, type the pre-defined IP address of the appliance for the Public
port:
172.16.100.100
4. Press Enter.
The web interface of Tiger Store loads.
5. Click Manage and enter the following password:
admin
To access the web interface through the Admin port:
Important: You can access the appliance through the Admin port if such port is
predefined by your vendor.
1. Set the IP address of the computer on which you will connect to the Admin port to
be on the same network as the preset IP address of the Admin port - 1.21.32.1 (for
Tiger Box appliances shipped before 01 November 2016) or 1.2.3.4 (for Tiger Box
appliances shipped after 01 November 2016).
Important: Even though your Tiger Box may be keeping the original IP address
(1.21.32.1), should you restore on the appliance a firmware image from a USB
flash drive, which has been sent to you after 01 November 2016, the IP address
of the Admin port will change to 1.2.3.4.
For example, if the Admin port of your appliance uses IP address 1.21.32.1, set the
IP address of your computer to 1.21.32.2 and the subnet mask to 255.255.255.0. If
the Admin port of your appliance uses IP address 1.2.3.4, set theIP address of your
computer to 1.2.3.10 and the subnet mask to 255.255.255.0.
2. Connect the computer to the Admin port of the appliance.
3. In a web browser, type the preset IP address of the appliance for the Admin port:
1.21.32.1
or
1.2.3.4
4. Press Enter.
The web interface of Tiger Store loads.

Tiger Box 4U24 Assembly Guide Initial Setup of the
20
5. Click Manage and type the password for the web interface.
Configure Appliance Identification and
Connectivity
Each Tiger Box appliance is identified in the network by IP address and name (by
default, this is the serial number of the appliance).
The appliance must have an IP address for each network port through which it
communicates with Tiger Clients (directly or via an Ethernet switch). The IP address
of each network port must be on the same LAN as the Tiger Client that will
communicate with the appliance through this port. For more information, refer to
“Configure the IP Addresses of the Appliance” on page 20.
Tiger Box supports teaming of the ports of each network card. If you choose to team
the ports of a network card, all its ports will be accessible through just one IP address.
To benefit from ports teaming, you must use an Ethernet switch, which supports Link
Aggregation Control Protocol (IEEE 802.1ax, LACP) and is set up for teaming.
Additionally, Tiger Box allows you to assign two or more IP addresses to the same
network card, thus making it accessible from networks on different subnets.
Changing the name of the appliance can be useful to more easily identify your
appliance onthe network or, if youdeploy more than one Tiger Box appliances in your
organization, to facilitate you in distinguishing them. For more information, refer to
“Change the Name of The Appliance” on page 21.
Team/Unteam Network Ports
To facilitate you with assigning IP addresses to the network ports of the appliance, Tiger
Box allows you to team the ports of a single network card. This way all ports of a network
card will be accessible through a single IP address.
Important: To benefit from ports teaming, you must use an Ethernet switch, which
supports Link Aggregation Control Protocol (IEEE 802.1ax, LACP) and is set up for
teaming.
You can unteam the ports of a network card at any time. When you unteam the ports
of a network card, they are automatically assigned the IP addresses they have had
before teaming them - either the default ones assigned by the appliance, or the ones
you have manually specified. Should you decide to team the ports again, you will have
to specify the IP address manually again.
To team/unteam the ports of a network card:
1. In the left pane of Tiger Store’s web interface, click System and then Network
Configuration.
The page lists all detected network cards, except the Public port and the Admin
port, if such is predefined.
2. In the tile of a network card, do one of the following:
• Select Use as a team, and then click Apply.
The teamed ports are listed on the IP Configuration page, where you can assign an
IP address to them.
• S elect “Use as individual ports”, and then click Apply.
The ports are listed on the IP Configuration page individually with their previous
IP addresses (the ones you have manually specified, or, if none has been specified,
the default ones).
Configure the IP Addresses of the Appliance
Your Tiger Box appliance can have any of the following network ports:
