Tiger TI - 02 P User manual

TI – 02 P
Weighing indicator
User’s Guide
PLEASE READ THIS MANUAL VERY CAREFULLY BEFORE
ATTEMPT TO OPERATE THE INSTRUMENT
May 2015
Specifications subject to change without prior notice

CONTENTS
1. INSTALLATION
2. SPECIFICATIONS
3. KEYS, DISPLAY AND CONNECTIONS
4. GETTING STARTED
5. INITIAL SETUP
6. INSTRUCTION FOR USE
7. RS232 DATA OUTPUT
8. BATTERY POWER AND RECHARGING
9. ERROR CODES
10. DAILY CARE AND MAINTENANCE

1. INSTALLATION
Because of metrological legislation, installation/some
metrological parameter settings are limited to be done by
authorized personnel only. Do not attempt to change any of the
built-in metrological parameters. Contact your dealer for more
information and technical assistance.
To ensure performance accuracy, do not use the instrument in
where or when the environment condition falls beyond as those
listed on SPECIFICATIONS.
Do not attempt to open the instrument, no user serviceable
parts inside.

2. SPECIFICATIONS
2.1 GENERAL SPECIFICATIONS
Maximum Capacity
Single Range Mode:-
Max = 1 ~ 999,999 (kg or lb)
Dual Range Mode: -
Max1 = 1 ~ 999,998( kg or lb)

Max2 = 2 ~ 999,999( kg or lb)
External Resolution
Single Range Mode:-
Recommend = 15,000 ~ 30,000
High = 30,000 ~ 60,000
Dual Range Mode: -
Recommend (Max2/ d1) = 15,000 ~ 30,000

High (Max
2
/ d
1
) = 30,000 ~ 60,000
Weight Units
Metric (kg) and Imperial (lb),g,oz
Min. Internal Count/d
15 Count
Offset Range
≥0.2mv (10000 Count)
Tare Range
- Max (Subtractive Tare)
Max. Measuring Range
15 mV
A/D Sampling Speed
15 times/ second
Power Voltage
Requirements
Built-in Rechargeable Battery = 6V DC
External Power Adaptor = 12V DC, 800mA
Load Cell Excitation
Voltage
5 VDC
Minimum/Maximum
Load Cell Impedance
350Ω/1000Ω
Load Cell Connection Supports 4-wire and 6-wire Load Cell
Connections
Maximum Load Cell
Connection
8 x 350ΩLoad Cells, or
16 x 700ΩLoad Cells
Operation Environment
-10 ~ 40
o
C. Non-condensed. R.H.≦85%
Specifications subject to change prior to notice

3. KEYS, DISPLAY AND CONNECTIONS
1.CNT KEY
Press this key to enter counting function
Press this key as next parameter when setting
2. WEIGHT UNIT KEY
Press this key to shift among various weight units.
Press this key as previous parameter when setting
3. WEIGH KEY
Press this key to back weighing status after counting, checking, animal
weighing, percentage function
4. PRINT KEY
Press this key to print the results to a computer or a printer through the
RS-232 output. according to the parameter setting whether accumulate or
not when printing
5.TARE KEY
Press this key to tare off the weight of a container.
Press this key to enter parameter setting when self-checking after power on
Press this key to confirm the parameter option
1
CNT 2 UNIT 3 WEIGH CE
4
PRT 5 MC 6 CHK ZERO
7
ANI 8 PCENT 9 PTARE TARE
0
SET ON/ OFF

6. ZERO KEY
Press this key to set weight displayed to zero when an empty scale has
drifted away from a true zero reading.
Cancel or quit from the operations
6. CHECK KEY
Press this key to start check weighing function and to enter value for HI and
LO limit.
7. ANI KEY
Press this key to enter animal weighing function
8.PERCENTAGE KEY
Press this key to enter percentage weighing function
9.PTARE KEY
Press this key to enter pre-set tare value
10.MC KEY
Press this key to recall total stored transactions.
11.CE KEY
Press this key to clear value entered.
12. NUMERIC KEYS
Numeric keys 0 ~ 9 and decimal key.
13.ON/OFF
Power on /off the indicator
◆
LED VERSION(HE200P) AS BELOW
14. CHECK SYMBOLS
HI = Weight reading is higher than the HI limit entered,
OK = Weight reading is in between than the low and HI limits entered,
LO = Weight reading is lower than the LO limit entered.

15. TARE INDICATOR
Visible when the tare function is in effect. Weight reading shown is net value
16. STABLE INDICATOR
Visible when weight reading is stable.
17. ZERO INDICATOR
Visible when instrument is at true zero weight status.
18. WEIGHT UNIT
LED indication as below:
kg =”kg” on,lb = “lb” on
oz = both “kg” and “lb” on; g= neither “kg “ nor “lb” on
19. CHARGE INDICATION
Flicker when charging ; invisible when full of charge
◆
LCD VERSION (HC200P) AS BELOW
14. CHECK SYMBOLS
HI = Weight reading is higher than the HI limit entered,
OK = Weight reading is in between than the low and HI limits entered,
LO = Weight reading is lower than the LO limit entered.
15. SPARE
W1/W2 ，if assigned , the scale are in dual range capacity status
Blank, no function assigned.
16. BATTERY POWER / LEVEL INDICATOR
Visible to show:-
This instrument is being powered by the built-in rechargeable battery,
Remaining battery level.

17. HOLD INDICATOR
(When under animal mode) Visible when weight reading being displayed is
a frozen value.
18. AUTO INDICATOR
Visible when the instrument is in animal weighing function.
19. NET INDICATOR
Visible when the tare function is in effect. Weight reading shown is net
value.
20. GROSS INDICATOR
Visible when gross weight reading is displayed.
21. STABLE INDICATOR
Visible when weight reading is stable.
22. ZERO INDICATOR
Visible when instrument is at true zero weight status.
23. CAPACITY TRACK BAR
The ratio (increment = 10%) of applied & remaining weighing capacities are
shown here.
24. WEIGHT UNITS AND FUNCTIONS
% = Percentage (when in Percentage Mode in function),
kg = kilogram,
PCS = Pieces (Piece Count Mode in function),
kg/PCS and g/PCS = Weight per piece (when Piece Count Mode in
function),
lb = pound.

BACKSIDE INSTRUCTION
The recommend (from left to right):
1) power plug
2) Load cell
LOAD CELL
CONNECTOR PIN #
ASSIGNMENT
1
EXCITATION +ve
2
SENSE +ve
3
EXCITATION -ve
4
SENSE -ve
5
SIGNAL +ve
6
SIGNAL -ve
7
GROUND
3) Com1 RS232
RS232 COMPORT ON
INSTRUMENT
1 = GND
2 = TXD
3= RXD
IF USE CABLE
GLANDS,LOADCELL AND
RS232 CABLE NEED TO GO
THROUGH GLANDS TO
CONNECT ON THE PCB.
FOLLOW THE RIGHT POSITION
SIGN OF CONNECTION
PRINTED ON PCB

4. GETTING STARTED
In order to obtain an accurate weighing result, the weighing platform,
(hereinafter referred as platform) must be placed on a strong and level
surface. Avoid using the platform and this instrument (hereinafter
collectively referred as scale) in environment where excessive wind flow,
vibration and extreme temperature change exist
General Warning: -
The instrument is not an explosion proof device.
Do not open the instrument, no user serviceable parts inside.
Always contact your dealer for service.
The instrument not to be subject to shock, excessive vibration
or extremes of temperature (before or after installation).
4.1 BUILT-IN RECHARGEABLE BATTERY
The instrument is equipped with a built-in rechargeable battery. Before first
time use, recharge it for at least 8 hours to ensure the best battery
performance.
4.2 POWER ADAPTOR
Before plugging in the power adaptor, check and make sure the input
voltage of the adaptor matches with output voltage of the electricity outlet. If
not, contact your dealer immediately.
4.3 CONNECTING OTHER DEVICES1
4.3.1 Connection with Weighing Platform (Load Cell)
Connect this instrument with a weighing platform (load cell) through load
cell connector located at the back according to the assignment table.
4.3.2. Connecting RS232 to computer, printer

5. INITIAL SETUP
5.1 INTERNAL SETTINGS
Application parameters can be checked and set through internal functions.
Refer to 5.4 for description of all internal functions.
5.2 HOW TO ENTER AND SELECT INTERNAL FUNCTION
Follow the below steps to enter and select desired parameter of an internal
function.
a. Turn this instrument off and on again,
b. Press [TARE] during countdown,
c. Display RS232,
d. This instrument is now in internal function,
5.3 KEY FUNCTION DURING INTERNAL FUNCTION MODE
[TARE] = Go to internal function during power on countdown, or
Enter, save and return,
[ZERO] = Quit without saving,
[1 CNT] = Go next,
[2 UNIT] = Go previous,
[CE] = Clear,

6. INSTRUCTION FOR USE
6.1 POWER ON
Powered on this instrument, it will: -
a. Display software number and revision (if any)
b. Display all display segments,
c. Display the calibration count value,
d. Display the parameter set count value,
e. This instrument is now ready for operation.
6.2 START WEIGHING
a. If zero weight cannot be obtained when unloaded, press [ZERO]. After
[ZERO] is pressed, the ZERO INDICATOR will appear. Refer to
SPECIFICATIONS for maximum zero range,
b. Always place an object onto platform gently. Excessive force applied
to platform may cause damage to the weight sensor,
c. The weight of the object is displayed on thus unit automatically,
d. It is a good practice to remove all loads from platform after weighing. It
will prolong the life of the weight sensor.
6.3 ABOUT WEIGH UNIT CONVERSION
Depends on the internal settings, this instrument supports kg , g, lb and oz
And can convert when weighing status by the setting of UNIT(on)
When a 3 or 4 place (0.000 or 0.0000) decimal place is selected, reading in
g is possible during normal operation by the setting of UNIT(on)
The weight unit employed before power off will be employed when this
instrument is turned on again.
6.4 TARE OFF THE WEIGHT OF A CONTAINER
Tare function is used to temporarily set the scale to zero (such as
cancelling the weight of a box or a container) in order to get the net weight
result

6.4.1 Manual Tare
When a container is used, follow the below steps to tare the weight of the
container off to get a net weight result.
a. Remove all loads from platform,
b. Make sure that the ZERO INDICATOR is on. If not, press [ZERO],
c. Place container on platform,
d. Press [TARE] ,
e. NET INDICATOR appears to indicator tare is in effect and weight
displayed display is net result. To cancel tare effect, remove all loads
from platform and press [TARE] ,
f. NET INDICATOR disappears. GROSS INDICATOR appears to
indicator tare effect has been removed and weight displayed display is
gross result.
6.4.
2
Repeated Tare
When M-tare is set to Mode 1, this instrument does not permit multiple tare
operation. Tare effect can only be cancelled when container is removed and
gross weight = zero.
When M-tare is set to Mode 2, this instrument will permit multiple tare
operations provided that both of the below requirements are met: -
a. The tare operation does not permit a reduction of the value of the tare;
b. The tare effect can only be cancelled when there is no load on the
platform.
6.4.3 Preset Tare
A pre-determined tare weight can be entered via keyboard.
During normal operation, press [PTARE],
enter the pre-determined tare weight through numeric keys ,then press
[TARE]to confirm. This pre-determined tare value will be deducted.
“NET” and “PT” indicator will be shown on
To cancel the preset tare effect, remove all loads from platform then press
[ZERO].

NOTE: -
1) The pre-determined tare weight entered must be equal to the multiple
of d. While this multiple factor must be an integer. Thus, in case the
exact tare weight is not equal to the multiplied value, maximum
possible error of the preset tare function is ±0.5d.
2) Manual tare is possible when preset tare is in function.
3) Preset Tare is also governed by Repeated Tare
6.5 MEMORY ACCUMULATION FUNCTION
6.5.1 To Accumulate a Transaction to Memory23
a. Press [Prt]4to save and accumulate data of current transaction to
memory,
b. This instrument returns to normal display status after 2 seconds,
c. Repeat ato cfor subsequent transactions5,
NOTE: -
1. Unstable weight will not be accumulated to memory. If Prt is
pressed when weight is unstable, this instrument will reject this
command and response with beeps.
6.5.2 Memory Recall and Clearance
a. Press MC to recall total accumulated weight from memory,
b. After MC is pressed, This instrument displays “≡ n” (nmeans the
number of transactions accumulated) follow by the total accumulated
weight stored in memory,
c. At this point: -
Press [ZERO] to quit, or
Press [ZERO] followed by [Weigh]to clear memory and return
operation.
6.6 FUNCTION MODES
Besides weighing function, this instrument is equipped with the below
supplementary function modes: -
2Memory Accumulation Function support weighing function only.
3All data stored will be erased when this instrument is powered off.
4or press [PRINT] if RS232 –Manual-ACC = ON
6. below how many d , can accumulate again

Piece Count,
Percentage,
Animal weighing
Check weighing (HI/LO check)
6.7 PIECE COUNT FUNCTION6
Follow the below steps to enter Piece Count Function: -
a. select the desired weight unit,
b. If a container will be used, place this container to platform and press
[TARE] to tare off the weight of it,
c. Press [CNT]to enter counting function
d. Enter sample quantity through numeric keys,
e. Place samples (with same quantity) on platform then press [Tare],
f. Now the indicator display the sample quantity
g. Go to sampling process7before start counting.
h. Place the goods which desired to counting
Shift among Quantity, Average Piece Weight and Weight Info
a. Press [UNIT] to shift among quantity, average piece weight and
weight info,
b. Quantity Display format = numeric numbers & PCS (e.g1000 PCS) ,
c. Average piece weight display format = numeric numbers & weight unit
& / (slash) & PCS (e.g. 499.960g/PCS) ,
d. Weight display format (when Piece Count Function is in effect) =
numeric numbers & weight unit & PCS (e.g. 500 kg PCS).
Press [Weigh]back weighing function.
6.8 PERCENTAGE FUNCTION8
Follow the below steps to enter Percentage Function: -
a. select the desired weight unit,
b. If a container will be used, place this container to platform and press
[TARE] to tare off the weight of it,
6Piece Count Function Mode does not support memory accumulation function.
7Before this instrument starts counting, the average piece weight must be determined. The
process of getting the average piece weight is called sampling.
8Percentage Function does not support memory accumulation (M+) function.

c. If a reference mass (as the 100%) is available, apply it on platform.
NOTE: - If reference mass is not available or the reference mass will
be entered through numeric keys, then ignore this step,
d. Press [PCENT];
e. Press [TARE] to enter,
f. Reference mass is obtained by either one of the below: -
By applying the reference mass is applied on step c, or
In case there is no reference weight applied to platform, the last
reference mass used will be display. To confirm press [TARE]
g. This instrument is now ready for percentage calculation. Any other
weight applied to the platform will be displayed as a percentage of the
reference mass.
Press [Weigh]back weighing function.
6.9 ANIMAL WEIGHING FUNCTION910 11
Follow the below steps to enter Animal Weighing Function: -
a. select the desired weight unit,
b. If a container will be used, place this container to platform and press
[TARE] to tare off the weight of it.
c. Press [ANI]to Animal Weighing Function (Ani) appears,
d. Now is ready to weighing animal
e. Display Ani. AUTO INDICATOR appears to indicator Animal Weighing
Function is in effect.
Set the Animal weighing parameter .
f. Press [SET], Display RS232 ,shift to Animal; Press [TARE] to enter
g. Display last filter (FLt) value applied. Select the preferred filter value12
9Animal weighing function of this instrument should not be used for trade purposes,
10 Animal weighing function does not support memory accumulation (M+) function.
11 Animal Weighing function will not operate when weight is less than 20d (or 20d1 for dual
range).
12 It is a trade off between motion filtering and accuracy. The faster the filter, the shorter the
amount of time over which the averaging is taken. The slower the filter, the longer averaging
time will take before a reading is displayed. It is recommended that FLt 3 should be applied
first. Should situation requires, change to a lower FLt number.

by pressing [CNT] or [UNIT] key, 3 filer values are available: -
FLt 1 = Fast
FLt 2 = Normal (For human weighinge, select this parameter),
FLt 3 = Slow
h. Display last weight release variation value (rE) applied. Under the
animal weighing function, this instrument will hold a weight result until
a pre-defined weight release variation value is achieved,
i. Select the preferred weight release variation value by pressing [CNT]
or [UNIT] key. 5 auto release range values are available: -
rE 1= auto release disabled,
rE 2 = auto release when weight varies ≥2% of rate capacity
rE 3= auto release when weight varies ≥5% of rate capacity
rE 4= auto release when weight varies ≥10% of rate capacity
rE 5 =auto release when weight varies ≥20% of rate capacity
Press [TARE] to enter,
Weighing Animal
a. Get animal on platform,
b. This instrument will calculate the mean weight of an animal or a group
of animals. The result obtained will be displayed.
HOLD (charging) INDICATOR appears to indicate that this weight value
is being held (frozen)13,and at the same time , indicator sounds 2beeps
c. Get other animals on platform in case more animals have to be weight
in the same transaction,
d. An updated weight will be calculated and displayed14 as above step b.
Press [Weigh]back weighing function.
6.10 CHECKWEIGHING MODE15 16
This instrument is equipped with check weighing mode. Check-weighing
mode is used to compare the value obtained meets with the preset limits
(high and LO limit) set to this instrument. The comparison result (HI, OK or
13 When weight value is being frozen, weight unit conversion is not possible.
14 Provide that extra weight added fulfill the weight release variation value listed on 6.8 step g.
15 Check weighing mode will not operate when weight is less than 20d (or 20d1 for dual
range).
16 Set also CHK Bp for desired Check weighing buzzer output.

LO) will then be displayed with or without buzzer17.
If a relay board is installed, the comparison results are also sent through the
relay output at the back of this instrument.
Follow the below steps to trigger check weighing mode: -
a. During normal operation (of a function), press [CHECK].
b. The current HI limit is displayed with the Hi symbol on, press [TARE]
to confirm, or
c. Enter a new HI limit through the numeric keys and then press [TARE],
d. Display current LO limit with the Lo symbol on, press [TARE]to
confirm, or
e. Enter a new HI limit through the numeric keys and then press [TARE]
f. Check weighing function is now enabled. The check is result is shown
by one of the HI/OK/LO symbols,
g. The same result will be sent to the relay output (if ordered) together
with the buzzer signal (if ordered).
NOTE: -
1. For normal comparison, set both HI and LO limits,
2. To check only if result is lower or equal to LO (result ≤LO?), set HI limit
= 0,
3. To check only if result is higher or equal to HI (result ≥HI), set LO limit
= 0,
4. To check if result is equal to a specified value, set both HI limit and LO
limit = the specified value
To quit check weighing mode, set both HI and LO limits to zero.
6.11. Quick setting
Press [SET]to get quick setting parameter ,Press [TARE] to enter and
[CNT] and [UNIT] to shift : PARA,CHECK,ANIMAL,RS232, and
RECHARGE : To check the currency when charging(mA)
Count : Display the calibration count value, and the parameter set count
value, (press[ZERO]or [TARE] for 3secs to exit)
17 Set CHK Bp to obtain the required buzzer output configuration.
