Tiger G450 User manual

GENERAL INFORMATION
INSTALLATION
MENU INFORMATION
3
10
11
Main Features
For your Safety
Unpacking
General Operation
RCU
Front Panel
Rear Panel
3
4
7
7
8
9
9
Connecting to Digital Amplifier
Connecting to TV using RCAsupport
10
10
Main Menu
1. Edit Channel
1.1 TV Channel List
1.2 Radio ChannelList
1.3 DeleteAll
1.4 Favorite
1.5
2. Installation
2.1 Installation
2.2 CA
2.3 Factory Setting
3. System Setup
3.1 Language
3.2 Information
3.3 TV System
3.4
3.5 Local Time setting
3.6 TimerSetting
3.7 Parental Lock
3.8 OSD Setting
3.9 Other
System Backup
1.6 System Recovery
Display Setting
11
12
12
14
14
14
14
15
15
15
19
20
20
20
20
21
21
21
22
22
22
22

4. Tools
5. Game
6. USB
6.1 Media Player
6.2 PVR StorageInformation
6.3 PVR Setting
6.4
6.5 Remove USBdevice safely
7. Hot key
7.1 Info
7.2 EPG
7.3 Find
7.4 Number
7.5 TV/Radio
7.6 Up/Down
7.7 Left/Right
7.8 Mute
7.9 Pause
7.10 OK
7.11 Audio
7.12 Recall
7.13 Fav
7.14 Teletext
7.15 Zoom
4.1 Network LocalSetting
4.2 WiFi Manager
4.3 Upgrade byNetwork
4.4 Weather Forecast
4.5 RSS Reader
Upgrade by USB
23
23
23
23
24
24
24
24
24
25
25
26
26
27
27
27
27
28
28
28
28
28
28
28
29
29
29
29
29
30

A Digital Satellite Receiver is a convenient product that allows you to view a variety
of programs provided through satellite. This user's guide covers the installation of
the DSR and the necessary steps to implement various features. This also explains
special features available only in thisDSR in detail, which will allow you to make full
use of thesefeature.
Information confirmed in this document is subject to change. We reserves the right,
without notice, to make change in product design or performances as progress in
engineering or technology.
Main Features
MPEG2 SD, MPEG2 HD, H.264/AVC SD, H.264/AVC HD,MP4,Divx
Embedded Conax(OPTION)
SCPC and MCPC receivable from C/Ku band satellite
Automatic PAL/NTSC conversion
4000 TV and Radio Channel Programmable
32 different favorite groups selection
Multi-language OSD
Fully support to 7 days Electronic Program Guide(EPG)
Picture in Graphics(PIG) support
True color On Screen Display
Automatic network search for newly added transponders
DiSEqC 1.2 fully support, 13/18V, 0/22K LNB control
Various channel editing functions(favorite, moving, locking, renaming, deleting
and sorting)
Parental control for channels
Ease to use Menu System
Software upgrades through RS232 port and Receiver to receiver, Support USB
upgrade
8 Timer Reservations, automatically switch to a specific channel Subtitle
support DVB EN300743 and EBU
Subtitle support DVB EN300743 and EBU
Teletext support DVB ETS300472 by VBI and OSD
Automatic save for last channel
Channel list can be sorted by alphabetic A Z,Scramble,Favorite,Lock,Sat
Support FAT16/FAT32/FAT12
Only list JPEG/BMP files
480i/p, 576i/p, 720p, 1080i, 1080p
Games
Recording, Timeshift, Mediaplayer

For Your Safety
Do not touch the receiver during thunder,
since that might create electric-shock
hazards.
Do not block ventilation holes of the
Receiver so that air can circulate freely.
Do not expose the receiver un-der the
sunlight. And keep it away from the heat
source.
Keep the receiver away from flower vases,
tubs, sinks, etc., in order to avoid damaging
the equipment.
To avoid electric-shock hazards, do not
open the cabinet, refer servicing to qualified
personnel only.
When the abnormal phenomenon occur,
you should cut off the power immediately.
Be sure to turn the Receiver off and
disconnect the AC power cord before
cleaning the Receiver surface. If the
surface is dirty, wipe clean with a cloth
which has been dipped in a weak soap-and-
water solution and wrung out thoroughly,
and then wipe again with a dry cloth.
Switch the receiver off whenever it remains
out of service for an extended period.

General Operation
Throughout this manual you will notice that the everyday operation of the receiver is
based on a series of user friendly on screen display and menus. These menus will
help you get the most from your receiver, guiding you through installation, channel
organizing, viewing andmany other functions.
All functions can be carried out using the buttons on the RCU, and some of the
functions can alsobe carried outusing the buttonson the frontpanel.
The receiver is easy to use, always at your command and adaptable for future
advances.
Please be awarethat new softwaremay change thefunctionality of thereceiver.
Should you experience any difficulties with the operation of your receiver, please
consult the relevant section of this manual, including the Problem Shooting, or
alternatively call yourdealer or acustomer service adviser.
Remote Control Batteries Guide
AV cable

RCU
The picture isonly for reference,please make theobject as thestandard.
Key Function
Standby on/off
When watching achannel, mute thesound
Switches between TVand Radio mode
0~9
MENU
EXIT
OK, LIST
PR+, PR-
Enter number ofthe required menuitem or
select a channelnumber to watch
Press this keyone time torun menu onscreen
Return to theprevious menu onthe menu
screen or escapefrom the menu
TV/R
Switches back toprevious channel
Displays the favoritegroup list
Show information ofthe current channel
Switch to teletextor subtitle mode
FAV
INFO
Executes the selecteditem in themenu screen
or enters thedesired value in any input mode
When watching achannel, change channelsor
move to thenext higher or lower item inthe menu
When watching achannel, adjust thevolume or
move to theleft or rightitem in themenu
Call up the EPG (Electronic Program Guide)
EPG
FIND Display the Findwindow
SLEEP
Enter into thesleep in mode
TXT/sub
Record and stoprecord the program
Press to fastforward or fastbackward
Press to slowforward or slow backward
Play list Enter into Playlist
SAT
Display the satellitewindow
CH+,CH- Change channels
Press once topause the screenpicture, press
once again togo to the normal mode
Display
PAUSE
rec/stop
Play and stopthe program
recall
zoom
VOL+, VOL- Adjust the volume
music
USB
movie
software
Audio
Enter into thezoom in mode
Choose audio mode
Change video mode
In Media Player menu, press to switch to music list
In Media Player menu, press to switch to picture list
Enter into USB list
In Media Player menu, press to switch to Movie list
Enter into upgrade by USB menu
event
Enter into Timer Setting menu

The picture isonly for reference,pleasemake the object as the standard.
Rear PanelFront Panel
Rear PanelRear Panel
POWER ON/OFF
CONNECT TOAUDIO R/LTO
TV ORAUDIO TUNER
CONNECT TOA PC
FOR S/W UPGRADE
LNB IN: CONNECTTO SATELLITE ANTENNA
LNB OUT:CONNECT TOTHE OTHER RECEIVER
CONNECT TO TV SET HDMI INPUT
CONNECT TO USB DEVICE
CONNECT TOTV SET OR VIDEO PROJECTORYPbPr OR
COMPONENT INPUTS
CONNECT TOA
DIGITALAMPLIFIER
CONNECT TO THE INTERNET
CONNECT VIDEO TO TV USING RCAJACK

The picture isonly for reference,pleasemake the object as the standard.
Connecting to TVusing RCA support
Connecting to DigitalAmplifier
DIGITALAUDIO
CONVERTOR OR
AMPLIFIER
SPEAKER
DIGITAL AUDIO
RL
LR
IN
TV
AUDIO
Satellite
Dish
Satellite
Dish

Main Menu
This menu consistsof 6 majormain menus
as follow.
- Edit Channel
- Installation
- System Setup
- Tools
- Game
-USB
During the installation the OK key confirms a selection and LIST key shows Down
List Box if the column has mark. You can also use the numeric keys on the RCU
to enter numericvalue.
Use the PR+,PR- key to move upwards and downwards from one line to another
line and use key to move from main menu to sub menu and move from left
side to rightside or versa.
Meantime, you want to escape the menu system, please press MENU or EXIT key
on the RCU.
Make sure thatyou have properlyinstalled and connected the cables of the receiver .
If the receiver is the factory status or there is no program list, when power on, the
Main Menu windowwill be displayedon the screen.
During the normal TV/Radio mode, press MENU key on the RCU to enter into the
Main Menu window.

If there is no program, you can not exit from the Main Menu window by pressing
MENU or EXIT key. System will inform"No channel" andthe following itemsturn grey.
1. Press OK key or key to pop up the "Input
Password" dialogue, you can not enter into the
menu unless the correct password is inputted.
The default passwordis "0000".
2. Press PR+, PR- keys to move the cursor up or
down.
Sub-menu Turn grey when there is no program
Edit Channel
Installation
System Setup
Tools
TV Channel List
Radio Channel List
Delete all
Language TV System
Local TimeSetting TimerSetting
Parental Lock OSDSetting
Other
1. Edit Channel
1.1 TV Channel List
Game Othello Sudoku
USB PVR Storage Information
Remove USB devicesafely
Upgrade by USB
Display Setting
Media Player
PVR Setting
Favorite
Network Local Setting WiFi Manager
Upgrade by Network Weather Forecast
RSS Reader
System Backup SystemRecovery
Installation
CA
Factory Setting
Information
1. Press keys to change page up and page
down.
2. Press PR+,PR- keys to select the program that
you want to play, and then press OK key to select.

3. Press red colour key to enter move list. In move list
select the program and press red key to mark this
program with the move mark. Press keys to move
the cursor to the position where you want to locate and
press OK key to confirm.
In move list press green key to group move, press
green key to select several channels and move these
channels at one time.
In move list, select channel and press yellow colour
key to pop up go to list, press number key to input
channel number you want, then the channel will move
to that position.
4. Select the program and press green key to mark
this program with the deletion mark. You can
cancel this markby pressing OK key again.
Press EXIT key to pop up the dialogue "Are you
sure to save?". Select Yes button and press OK
key to save, or select NO button and press OK key
to exit withoutsaving.
5. Select the program and press yellow key to pop
up a window ask you to input password, the default
password is "0000". After input the right password
program will bemarked with thedeletion mark. You
can cancel thismark by pressingOK key again.
Press EXIT key to pop up the dialogue "Are you
sure to save?". Select Yes button and press OK
key to save, or select NO button and press OK key
to exit withoutsaving.
6. Press blue colour key to pop up the Rename
window.
colour key to switch
between capital letter and lower letter; press green
colour key to switch between English characters
and arabic characters; press keys to move the
cursor left or right; press numeric keys (0-9) to
input the character, please refer to the down table.
Press yellow colour key to save and exit, or press
blue key to canceland exit.
In Rename window, press red key to delete
characters, press yellow

Numeric keys Press numeric keyrepeatedly, displayin circle
1
2
3
4
5
6
7
8
9
0
.,*?!@1
ABC2
DEF3
GHI4
JKL5
MNO6
PQRS7
TUV8
WXYZ9
[space]_-0
If the name is empty, system will pop up a dialogue informing "Name" once yellow
colour key ispressed. Press OK key to closethis dialogue.
1.2 Radio ChannelList
Same operation as1.1 TV ChannelList, here wedon't explain anymore.
1.3 Delete All
Move cursor to the Delete All item, and press OK
Key to pop up the dialogue "Warning! Do you really
want to deleteall channel?".
Press EXIT key to pop up the dialogue "Are you
sure to save?". Select Yes button and press OK
key to save, or select NO button and press OK key
to exit withoutsaving.
There are 8 favorites group listed in this window.
Press PR+, PR- keys to select one and press OK
key to the Rename window. Since the same
operation as the above the Add Satellite window,
here we don'texplain any more.
1.4 Favorite
1.5 System Backup
Move cursor to the System Backup item, and
press OK Key to pop up the dialogue "Backup the
current whole system". Select Yes button and
press OK key to save, or select NO button and
press OK key to exitwithout saving.

Satellite List
1. Satellite list is on the left side of the window. Press
PR+, PR- keys to select the satellite up or down. Press
OK key to select and mark, and you can press OK key
again to cancel the selection and the mark.
2.1Installation
Press keys to select between Motor
Antenna and FixedAntenna.
2. Installation
1. Press OK key or key to pop up the "Input
Password" dialogue, you can not enter into the menu
unless the correct password is inputted. The default
password is "0000".
2. Press PR+, PR- keys to move the cursor up or
down.
1.6 System Recovery
Move cursor to the System Recovery item, and press
OK Key to pop up the dialogue "Recovery will
overwrite the current system".
Select Yes button and press OK key to save, or select
NO button and press OK key to exit without saving.
2. Press red colour key to pop up the Single
Satellite Search window.
3. Press green colour key to pop up the Multi
Satellite Search window.
4. Press yellow colour key to pop up the Edit
window.
Name: User numeric keys to change the name of
the satellite, pleaserefer to theEdit Channel Name.
Longitude: You can press keys to switch between east longitude and west
longitude. After pressing OK key, you can use numeric keys to edit the longitude, press
EXIT key or the PR+, PR- keys to exit editing mode. The range of the longitude is from 1to
180 degree. If beyond this range, system will inform you "out of range" when you press
yellow colour key on the RCU.
After setting, press yellow colour key to save and exit, while press blue colour key to exit
without saving.

5. Press blue colour key to pop up the Add/Delete
window. The same operation as the above Edit
Satellite window
6. Press blue colour key and select delete, it will
pop up the dialogue "Are you sure to delete?".
Select Yes button and press OK key to delete the
selected satellite. You can cancel this operation by
pressing OK key at theNO button.
Suppose that you have selected Fixed Antenna in the
Antenna Connection window.
1. Satellite: All selected satellites in the satellite list are
displayed in this item.
Press keys to select the satellite in circle. Or
press OK key to pop up the drop-down list, then select
the desired satellite in the list and press OK key to
confirm.
Antenna Setup
Part A:Fixed
3. 22K, Polarity: You can press keysto select incircle.
Part B: Motor
Suppose that you have selected Motor Antenna in
the Antenna Connection window.
1. LNB Type: Select the properLNB type.
2. Motor Type: Select between DiSEqC1.2 and
USALS. If you select DiSEqC1.2, the following
Local Longitude and Local Latitude items will turn
grey.
3. Delete All: Press OK key to pop up the dialogue
"Are you sure to clear set satellite position of this
tuner?". Press OK key at the Yes button to clear all
the memories about the position of the satellites
that are connectedto the currenttuner.
2. LNB Freq,Transponder,DiSEqC1.0, DiSEqC1.1: The same operation as theabove.

4. Motor Setting: Press OK key to the Motor
Setting window.
Satellite: Press keys to select the satellite
in circle. Or press OK key to pop up the drop-down
list, then select the desired satellite in the list and
press OK key to confirm.
Transponder: The same operationas the above.
Position No., & Save: The range is from 0 to 63. "0" delegates the original position. You
can select the proper value when you has rotated the antenna.
Go to X: Press OK key to pop up the drop-down list, select the proper position (reference
or from 1to 63) to realize the selected position.
West <Save> East: Press key to turn east, while press key to turn west. Press
OK key to pop up the dialogue "Are you sure to change this satellite's position?". Press OK
key at the Yes button to save the current position, or press OK key at the No button to
cancel the operation.
Recalculation: Press OK key to pop up the dialogue "Are you sure to change this
satellite's position?". Press OK key at the Yes button to recalculation.
5. Limit Setup: Press OK key to pop up the Limit
Setup window.
Limit Setup: Press keys to switch among
Disable Limit, East Limit and West Limit.
Limit Setup: Move cursor to the Limit Setup button.
You can press key to turn west , or press key
to turn east.
Go to Reference: Press OK key to go to reference. If you select Disable Limit in the
above Limit Setup item, this button will turn grey.
6. If select USALS, Delete All item will turn grey.
Local Longitude, Local Latitude: Press keys to
switch between West and East, or press keys to
switch between North and South. Press OK key to
enter into the editing mode. Use numeric keys (0-9) to
input the longitude or latitude, press MENU key or
EXIT key to exit. The range of the longitude is from 0 to
180,while the range of the latitude is from 0 to 90. If the
inputted value is not in this range, system will pop up a
dialogue "Out of Range" when you exit from this
window. You can press OK key to close this dialogue.

7. Motor Setting: Press OK key to enter into the
Motor setting window.
Satellite, Transponder: Press keys to
select satellite or transponder, or press OK key to
pop up thedrop-down list andselect in thelist.
In Antenna Setup List
4. Press green colour key to pop up the Add TP
window. Since the same operation as the above
Edit TP window, herewe don't explainany more.
3. Press bluekey to enterTP list.
In TP list press red colour key to pop up the Edit
TP window.
Frequency, Symbol rate: Press keys to
add or reduce by step one. Or press numeric
keys (0-9) to input the desired value. The range
of the frequency is 3000-13500, while the range
of the symbol rate is 1000~45000. The inputted
value is beyond this range, the value will return
to the originvalue.
Polarity: Press keys to switch between
Vertical andHorizontal.
5. Press yellow colour key to pop up dialogue "
Are you sure to delete?". Press OK key at the
Yes button to delete the selected TP, or press
EXIT key to cancelthe operation.
1. Press red colour key topop up theSingle Satellite Search window.
2. Press green colour key topop up theMulti Satellite Search window.
6. Press blue colour key to pop up the TP
Search window.
FTA only, Scan Channel, Network Search:
Press keys toselect the properoption.
Press OK key at theOK button tostart searching.

2.2 CA
Select CAitem and press OK key, then you will enter
into its sub-menu which consists four items of About CA
Info, Change PIN, Change Signature PIN, Maturity
Level.
CA Slot
Insert the smart card with the golden chip facing down.
Push the smart card into the CA slot. Only a few
millimetres of the card should be visible outside the slot.
2.2.1 About CA Info
In About CA Info sub-menu, you can know the basic
information about this conditional access such as
Card Status, CAS System ID, Interface Version, Card
Number, Number of sessions, Country Indicator, and
Maturity Level.
2.2.2 Change PIN
Changes PIN window is designed for changing the
smart card's PIN, which is required if you want
change the maturity level settings.
In order to change the PIN, you must know the
current PIN also called the old PIN. Input the new
PIN and twice the PIN (New PIN and Confirm PIN
must be the same) your want to set. Move cursor to
OK button and press OK key, and then system will
pop up a dialogue informing you the changing result.
Note that thePIN can onlyconstructed withArabic numerals.
2.2.3 Change SignaturePIN
Do the sameway as theabove Change PIN.
Note: The signature PIN will be locked after the
three erroneous attempts to enter the correct PIN. If
locked, please call the dealer for help.
2.2.4 Maturity Level
Input the PIN then Move cursor to Select Maturity level,you can select A-Over18,X-
Erotic,G-General audience,PG-Parental Guidance,move cursor to Change Maturity level
button and press OK key,and then system will pop up a dialogue informing you the
changing result.
