EchoStar D-2510 IP Viaccess User manual

User Manual
DIGITAL, POSITIONER RECEIVER WITH
EMBEDDED VIACCESS AND COMMON INTERFACE

CONTENTS
1
Trade Mark of the DVB Digital Video Broadcasting Project (1970)
3.
4. Remote Control Unit (RCU) ------------------------------------------------------- 6
5. Getting started ------------------------------------------------------------------------ 7
7. Operation and menu program ---------------------------------------------------- 12
8. Specifications ------------------------------------------------------------------------- 27
Front & rear view ------------------------------------------------------------------- 4
2. Features ------------------------------------------------------------------------------- 3
A. Receiver and TV set-up ------------ ------------------------------------------- 12
B. Main menu & Installation ---------------------------------------------------- 18
C. Advanced Installation --------------------------------------------------------- 25
Safety instructions ------------------------------------------------------------------- 2
How to connect your dish to the EchoStar D-2510IP VIACCESS -------- 10
1.
6.
Dear Customer,
Thank you for purchasing an EchoStarreceiver with Common Interface. We want you to get maximum enjoyment from
your receiver and for this reason we advise you to use only conditional access C.I. modules which are approved by the
service provider of the encrypted program you want to receive. This will enable your receiver to function properly.
Irregularities can be expected when unapproved C.I. modules are utilized, and EchoStar cannot and will not be held responsibl
e for the performance of such modules. If you choose to utilize an unapproved conditional access module with
your EchoStar receiver, EchoStarwill be unable to provide any support or assistance for the receiver.
If you have any doubt about which module you should be using, we highly recommend that you contact your programming ser
vice provider.
We hope you will enjoy using your EchoStar receiver.
Best Regards
EchoStar Int Corporation
The Netherlands.
WARRANTY LIMITATION

WARNING!
Always follow these instructions to avoid the risk of injury to yourself or damage to your equipment.
Unplug the receiver from the AC power outlet before cleaning. Use only a damp cloth for cleaning
the exterior of the receiver.
Do not use accessories or attachments not recommended by the receiver manufacturer, as they may
cause hazards and will void the warranty.
Do not operate the receiver in high-humidity areas, or expose it to water or moisture.
Do not place the receiver on an unstable cart, stand, tripod, bracket, or table. The receiver may fall,
causing serious personal injury and damage to the receiver.
Do not block or cover slots and openings in the receiver. These are provided for ventilation and
protection from overheating. Never place the receiver near or over a radiator or heat register. Do
not place the receiver in an enclosure such as a cabinet without proper ventilation.
Do not stack the receiver on top of or below other electronic devices.
Operate the receiver using only the type of power source indicated on the marking label. Unplug the
receiver power cord by gripping the power plug, not the cord.
Route power supply cords so that they are not likely to be walked on or pinched by items placed upon
or against them. Pay particular attention to cords at plugs, convenience receptacles, and the point
where they exit from the unit.
Use an outlet that contains surge suppression or ground fault protection. For added protection during
a lightning storm, or when the receiver is left unattended and unused for long periods of time, unplug
it from the wall outlet and disconnect the lines between the receiver and the antenna. This will
provide some protection against damage caused by lightning or power line surges.
Do not attempt to service the receiver yourself, as opening or removing covers may expose you to
dangerous voltage, and will void the warranty. Refer all servicing to authorized service personnel.
Unplug the receiver from the wall outlet and refer servicing to authorized service personnel whenever
the following occurs:
The power supply cord or plug is damaged;
Liquid has been spilled, or objects have fallen into the receiver;
The receiver has been exposed to rain or water;
The receiver has been dropped or the chassis has been damaged;
The receiver exhibits a distinct change in performance.
2
1. Safety Instructions

2. Features
3
1. MPEG-2 Video(MP@ML)
2. MPEG-1 Audio layer 1, layer 2
3. MPEG-2 Digital & fully DVB compliant
4. Viaccess embedded with 1 smart card
5. Capable of Interfacing with the CAMs of DVB Common Interface standard
6. Capable of scanning the frequency for SMATV system
7. Superb On-screen graphics with 256 colorful resolution
8. Plug & Play installing program setup
9. LD quality video, CD quality audio
10. Variety of LNB polarity control, 13/18V, 0/22kHz tone, 0/12V,
mechanical, magnetic polarizer and DiSEqC 1.0TM
11. RS-232C port for additional information service and updating of the receiver control software
12. 4-digit 7-segment LED on the front panel displays channel information
13. Displays local time on the front panel in stand-by mode
14. Displays signal level to setup the satellite antenna with ease
15. Power recovery function
16. 64-step volume control
17. Powerful editing facilities
; PIDs, TV or radio channel, Channel name, Satellite name/Transponders
18. Teletext function (Your TV should support teletext) & Subtitling
19. Favorite channel function
20. SCPC/MCPC receivable from C/Ku-band satellites
21. Proprietary Echostar OSG menu for full integrated functions
22. Last channel memory function
23. Variable aspect ratio (4:3, 16:9) with pan vector
24. EPG for on-screen channel information
25. Parental lock / Installation & Edit lock / Receiver lock
26. Multi-lingual function when provided by the satellite and broadcasting service provider
27. Total 5,000 channels programmable (TV: 4000 CH. & Radio : 1000 CH.)
28. DiSEqC 1.0TM compatible
29. Mechanical and magnetic polarizer control for each satellite
30. Channel storing for multi-satellites
31. Satellites : up to 50 satellites, 999 transponders
32. Built-in positioner (high power azimuth control(36Vdc, 5A))
33. VCR timer (Position, channel, start time, stop time)
34. Auto Sat position search
35. C/Ku control function
36. Receiver-to-receiver download function for program and data transmission

Front Panel
Front Panel
3. Front & Rear View
Rear Panel
Rear Panel
4
AC power cord
RF output connector to TV
Antenna input
LNB input
Loop through
Note: All the cables used for Input/Output connection for the receiver should be well shielded.
Note: All the cables used for Input/Output connection for the receiver should be well shielded.
Selection / confi
rmation
Channel up / down
Volume up / down 2 Slots for CI module
ON/Standby
1 Smart card slot

4. Remote Control Unit (RCU)
6
The Power key turns the receiver on and off.
The LED (Light Emitting Diode) flashes red to show the remote is working.
The TV, VCR and SAT keys select the device to be controlled.
Pressing the SATkey allows the remote to control the functions
of the receiver.
The Volume and Channel keys control the two most
frequently used functions of the receiver.
The Mute key switches the sound on and off.
The MENU key is used to see main menu or to return to previous
menu.
The cursor keys are for channel ?and ?and volume ?and ?.
The OK key is used to select a program, a highlighted line or
parameter value. Also you can see TV/Radio channel list while
watching TV or listening to the radio.
The EXIT key exits to the video viewing mode at any time.
Number / Inputkeys enable direct channel selection command
selection using numeric keys.
The TV/RAD(Radio) key switches between TV and radio mode.
The FAV key shows a list of your selected favorite channels (To
define channels as favorite select the “Edit TV channel”menu).
The EPG key shows program information of the selected channel.
(EPG; Electronic Program Guide)
The Subtitlekey enables subtitling (only when provided by the broadcaster).
Selects the Audio Language or Soundtrack from among the data transmitted for the current
channel.
Shows a thumbnail representation of the current channel in the “Edit TV Channel”,
“Parental Lock”and “EPG”.
The SATkey shows a list of selectable satellites.
VIEW
The Information key provides additional information about the
current channel and program (only available when provided by
the broadcaster). In the menus pressing this key provides up to
four lines of help.

Smart Card and CI Module
To watch payable program channels, a CI module and a smart card from the service provider is necessary.
(The service provider is the distributor of the programs). CI modules and smart cards are only licensed to
service providers only and they are distributed by their dealers or agents.
If you are subscribed to the services of more than one service provider, you might have to insert or change
proper smart card and proper CI module of your choice.
Without CI module and smart card,only FTA (free-to-air) programs are available to watch.
Note : 1)The main plug must not be plugged in before inserting the CI module.
2) Insert the CI module fully into the slot behind the lid in the front panel of the receiver,
towards the arrow on the module facing upwards and inwards.
3) Insert your smart card fully into the slot on the CI module towards the arrow on the card facing
upwards and inwards.
4) CI module and smart card may give special menus which are not described in this manual.
5) A smart card is connected to a single service provider and to a specific range of channels.
6
The receiver has a Viaccess build in conditional access system. If a service provider uses the
Viaccess conditional access system, it is not necessary to use a CI module. The smart card may directly
inserted in the smart card reader to watch the encrypted channels.
Embedded Viaccess

DO NOT PLUG the receiver into Main Power Outlet, until you complete all the connections to the receiver.
DO NOT PLUG the receiver into Main Power Outlet, until you complete all the connections to the receiver.
5. Getting Started
TV ANTENNA
TV
RF IN
7
Receiver to TV with RF
VCR
TV
RF IN RF INRF OUT
Receiver to VCR and then to TV with RF
1. Connect the Off-air TV antenna or cable if available to the ANT IN socket of the EchoStar D-2510IP VIACCESS.
2. Connect the TV OUT socket of theEchoStar D-2510IP VIACCESS to the RF IN of the TV set.
3. Search on the TV set for UHF channel # 38. This is the default channel where theEchoStar D-2510IP VIACCESS
is set to.
1. Connect the Off-air TV antenna or cable if available to the ANT IN socket of the EchoStar D-2510IP VIACCESS.
2. Connect the TV OUT socket of theEchoStar D-2510IP VIACCESS with the RF IN of the VCR.
3. Connect the RF OUT of the VCR to the RF IN of the TV set.
4. Search on the TV set and the VCR for UHF channel # 38. This is the default channel where the EchoStar D-2510IP VIACCESS
is programmed to.
Note : Use different UHF channels for VCR and EchoStar D-2510IP VIACCESS.
TV ANTENNA

TV ANTENNA
TV
RF IN
8
Receiver to TV with Audio and Vide RCAs
VIDEO AUDIO
IN IN
Receiver to TV and VCR with SCART Cables
1. Connect the Off-air TV antenna or cable if available to the ANT IN socket of the EchoStar D-2510IP VIACCESS.
2. Connect the TV OUT socket of theEchoStar D-2510IP VIACCESS with the RF IN of the VCR.
3. Connect the RF OUT of the VCR to the RF IN of the TV set.
4. Search on the VCR for UHF channel # 38. This is the default channel where the EchoStar D-2510IP VIACCESSis programmed to.
5. Connect the SCART cable from the TV SCART of the EchoStar D-2510IP VIACCESSto the SCART of the TV set.
6. Connect the SCART cable from the VCR SCART of theEchoStar D-2510IP VIACCESS to the SCART of the VCR.
7. When the EchoStar D-2510IP VIACCESS is switched on the TV set, TV set will automatically switch to the relevant SCART
input of the TV.
Note : Use different UHF channels for VCR and EchoStar D-2510IP VIACCESS.
TVSCART RF IN RF OUT RF IN VCR SCART
1. Connect the Off-air TV antenna or cable if available to the ANT IN socket of the EchoStar D-2510IP VIACCESS.
2. Connect the TV OUT socket of theEchoStar D-2510IP VIACCESS with the RF IN of the TV set.
3. Connect the Video and Audio RCAs of the EchoStar D-2510IP VIACCESS to the Video and Audio RCAs of the TV set.
TV ANTENNA
VCR
TV

9
Receiver to TV, VCR and Decoder with SCART Cables
DECODER
DECODER SCART
1. Connect the Off-air TV antenna or cable if available to the ANT IN socket of the EchoStar D-2510IP VIACCESS.
2. Connect the TV OUT socket of theEchoStar D-2510IP VIACCESS to the RF IN of the VCR.
3. Connect the RF OUT of the VCR to the RF IN of the TV set.
4. Search on the VCR for UHF channel # 38. This is the default channel where the EchoStar D-2510IP VIACCESS is
programmed to.
5. Connect the SCART cable from the TV SCART of the EchoStar D-2510IP VIACCESS to the TV SCART from the TV
set.
6. Connect the SCART cable from the VCR SCART of theEchoStar D-2510IP VIACCESS to the SCART of the VCR.
7. Connect the SCART cable from the DECODER SCART of theEchoStar D-2510IP VIACCESS to the SCART of the
DECODER.
Note : Use different UHF channels for VCR and EchoStar D-2510IP VIACCESS.
TVSCART RF IN RF OUT RF IN VCR SCART
TV ANTENNA
VCR
TV

10
One Actuated Dish
1. Connect the LNB IN socket of theEchoStar D-2510IP VIACCESS to the LNB.
2. Connect motor wires to M1 and M2. Switch these connections if the motor moves to the wrong direction.
3. Connect sensor wires to M.PULSE and GND connector.
4. Connect a mechanical polarotor to +5V, GND and SKEW connectors. [optional]
5. Connect ferrite polarizer to ferrite connectors. [optional]
Universal LNB
6. How to connect your dish to the EchoStar D-2510IP VIACCESS
One Actuated Dish with C/Ku feed
C-band Ku-band
LNB LNB
ACTUATED DISH
WITH C/KU FEED
1. Connect the cables from C and Ku-band LNB to a 12 Volt C/Ku switch.
2. Connect the coaxial cable from the 0/12 Volt switch to the LNB IN connector.
3. Connect the power cable which comes from the 0/12 Volt switch to the 0/12V(connector).
4. Connect motor wires to M1 and M2. Switch these connections if the motor moves to the wrong direction.
5. Connect sensor wires to M.PULSE and GND connector.
6. Connect polarotor to +5V, GND and SKEW connectors. [optional]

11
Two Fixed Dishes using DiSEqC mode
1. Connect the DiSEqC1.0 or Toneburst switch to the LNB IN connector of the EchoStar D-2510IP VIACCESS.
2. Connect both dishes to the 2 inputs from theDiSEqCswitch.
LNBLNB
FIXED DISH # 1
(Digital or Analog) FIXED DISH # 2 (Digital or Analog)
DiSEqCswitch

A. Receiver and TV set-up
Check the Installation
To get the most out of the EchoStar D-2510IP VIACCESS it should be correctly installed, the dish should
be optimally aligned and the mechanical limit switched on the dish should be set properly. Press /I on
the remote control unit (RCU) or press on the front panel of the EchoStar D-2510IP VIACCESS to
switch the unit on.
5. Operation and Menu Program
12
After selecting the language settings, the ”LNB Setting”menu will be shown. Please follow the steps outlined
below to properly install the EchoStar D-2510IP VIACCESS.
You can select the desired language for the OSG (On-
Screen Graphics) display using the , keys when the
“Menu Language”option is selected. Similarly you can
selected a different audio channel when the “Audio
Language”option is selected. This option allows you to
select a different language to listen to if supported.
LNB Setting
Select the LNB type which conforms to your LN
B using the , keys.
Other parameter values should be changed
manually according to your LNB type.
Press the OKkey to confirm your selection.
Select the “LNB Setting”menu in the “Installation”m
enu using the ,keys.
If you have a Mechanical Polarizer with your LNB, you have to set the “Polarity Control”parameter in this
menu to [Polarotor].
Language Setting
LNB Setting
LNB Freq. Low Universal
LNB Frq. High Universal
DiSEqC None
DiSEqC Port 1
Polarity Control 13/18V
LNB Freq. Band Control 0/22kHz
Ku/C Control Disable
LNB Type Index (1..8)
0/22kHz Control Off
0/12V Control Off
LNB Power On
1
2
43
5
6
7
8
9
10
11
×Type 1 Ø
i
Language Setting
Menu Language
Main Audio Language English
×English Ø1
22nd Audio Language English
Subtitle Language English
3
4
Exit
i

13
Move the dish a few counts to the west by pressing the key and press the OKkey to store east limit in this p
osition. The indicated number will be set at 1000 and the highlight will be moved down to the “West Limit”li
ne. Now set the west limit by moving the dish using the key until you have reached the dish limit. The indica
ted number will increase from 1000. Move the dish back a couple of counts using the key and pressthe OK
key to store the west limit.
If either the numeric value is not shown or the message
“...Motor Error...”is displayed on the lower part of the s
creen, then ;
Press the key on the “East Limit”parameter line.
The initial value of 5000 will decrease as the dish i
s moved. Keep moving the dish unit until the east li
mit is reached. If the dish moves to the west when
you press the key, reverse the motor wires.
Antenna Installation
First the east and west limits have to be set before
any satellites can be programmed.
The dish limits are now stored in the receiver and t
he dish is in the most western position. Press the S
ATkey to start the “Auto Sat”function or you can
press MENU to program the satellites manually.
If you do not have a moveable dish, just press the
OK key twice to program the east and west limit in
the same position. This will be indicated by a
numeric value of 1000 for both limits.
1) an error occurred when moving the dish(which could be caused by e.g. loose wires), or
2) the dish has reached its east limit. In this case continue with the installation procedure.
Antenna Installation
East Limit
West Limit Not Set
iExit
×Not Se t Ø1
2
Antenna Installation
West Limit 1070
East Limit 1000
1
2
iExit
Press SAT to go to the Auto SAT feature.
Press menu if you want to program the satellites manually.
Press Exit to return to TV/Radio channel.
Now press the or key to select the most western
position you can receive.
Press the OK key.
Select the Position option and move the dish using
the key to correct location of the western satellite.
Peak the dish to obtain the highest signal quality
using the and keys. Then press the OK key to
store this setting.
8
Please Store most western satellite
Satellite 018.0°W
LNB Type Type1
TP/Polar/SR(Digital) 11525/H/12225
Skew Not set
Position E 1000 W
Re-align dish +00
Search type Auto Search
Start Search(Press OK)
2
3
4
5
×INTEL705 Ø1
EL WL
Signal Level
Signal Quality
6
7
11%
00%
8
Auto SAT

Go back to the Satellite option using the key.
Now press the or key to select the most
eastern satellite you can receive.
Press the OK key.
Select the Position option using the key move
the dish to the correct location of the eastern
satellite. Peak the dish to obtain the highest
signal quality using the and keys.
14
Press the SATkey to let the receiver calculate all
intermediate satellite positions. All selected satellite
positions are now stored for the digital mode.
Press the MENU key twice to return to the installation
screen. Select Auto Search (for more information on
this option please refer to page 20). The EchoStar D-
2510IP VIACCESS will start the search on the most
eastern satellite.
üCAKRAWAR 107.7°E üTHAICOM 078.5°E
üASIASAT3S 105.5°E üAPSTAR2R 076.5°E
üGORIZT25 103.0°E üPAS4 068.5°E
üASIASAT2 100.5°E üASTRA1 018.0°E
üABC 100.5°E
üMESAT 091.5°E
üST1 088.0°E
üINSAT2E 083.0°E
* Page Change = Ú,Ù
* Press SAT to Calculate satellite positions
Auto SAT
Select Satellite 019.2 °E×ASTRA1 Ø
iDelete Add Exit
1
Please Store most eastern satellite
Satellite 004.0 °W AMOS1
LNB Type Type1
TP/Polar/SR(Digital) 11224/H/27500
Skew Not set
Position
Realign dish +00
Search type Auto Search
Start Search(Press OK)
1
2
3
4 E 1053 W
EL WL
Signal Level
Signal Quality
6
7
8
12%
00%
5
üCAKRAWAR 107.7°E THAICOM 078.5°E
ASIASAT3S 105.5°E APSTAR2R 076.5°E
GORIZT25 103.0°E PAS4 068.5°E
ASIASAT2 100.5°E üASTRA1 018.0°E
ABC 100.5°E
üMESAT 091.5°E
ST1 088.0°E
INSAT2E 083.0°E
* Page Change = Ú,Ù
* Press SAT to Calculate satellite positions
Auto SAT
Select Satellite 019.2 °E×ASTRA1 Ø
iDelete Add Exit
1
Go back to Satellite option using the key.
Now press the or key to select the middle
satellite.
Press the OK key.
Select the position using the keyand with the
key move the dish to the correct location of the
middle satellite. Peak the dish to obtain the
highest signal quality using the and keys.
Then press the OK key to store this setting.
Please Store middle satellite
Satellite 028.2°E ASTRA2
LNB Type Type1
TP/Polar/SR(Digital) 11478/H/30000
Skew Not set
Position
Realign dish +00
Search type Auto Search
Start Search(Press OK)
2
3
4
E 1238 W
EL WL
Signal Level
Signal Quality
6
12%
00%
1
5
[ E 1238 W ]
7
8

15
If you are not satisfied with the Limit parameters e.g. since the
mechanical limits might not be set properly, you can erase the
position data and start again after adjusting the mechanical
limits at the dish.
Motorized Dish Setting
Erase Position Data
If you want to erase all the position data, select “Erase Posit
ion Data”and press the RED key twice.
Motorized Dish Setting
Fixed dish
Antenna Installation1
2
Exit
i
The EchoStar D-2510IP VIACCESS now has
programmed the position of all selected satellites.
The next step is to store all channels on these
satellites. To do this press the MENU key, select
the Installation option followed by the Program
Satellites option. Use the key to select the next
satellite and press the OK key. The dish will
move to the selected satellite.
Select Start Search to store all channels.
Repeat this procedure for all satellites.
ProgramSatellites
LNB Type Type 1
TP/Pol/SR(Digital) 11662/V/27500
Skew Not set
Position E 1070 W
Re-align Dish +00
Search Type Auto Search
Start Search (Press OK)
Satellite 013.0?E
1
2
43
5
6
7
8
×HOTBIRD Ø
[E 1070 W]
EL WL
Signal Level 10%
Signal Quality 5%
Program Satellites
Erase Position Data3
Fixed Dish Fixed dish
LNB Type Type 1
SelectSatellite1
2
Fixed Cancel LNB set
iExit
×ASTRA1 Ø
If you want a fixed dish and an actuated dish, you can set
in this menu the “Fixed dish”.
Start with selecting the appropriate satellite and LNB Type
and press the RED key twice.
To make a satellite again actuated, change the LNB Type
to the actuated LNB type and press the RED key twice.
Motorized Dish Setting
Fixed Dish
Antenna Installation
3
2
Delete Cancel Exit
i
Erase Position Data
1

User’s Setting
16
Local Time Setting
User’s Settings are only accessible via the Installation screen.
Language Setting
Subtitle
None
Eng
Ita
Subtitle
Select the “Subtitle Language”in the “Language Setting”menu. While viewing a
channel, the subtitling option is available only when the selected subtitling language
is provided by the broadcaster.
To check if the subtitling language is available, press “”key on the remote
control unit, to show a list with all available subtitling languages.
To set your local time, input all the required data for the time
and date. This information has to be entered to enable
recording of the programs of your choice.
After entering the correct data for year, month, date, day,
hour, minute, select option 7 (Press the OK key to set the
time) and press the OK key to save the data.
It is recommended that the time and date set in this menu is
the same as of your VCR.
Now that the date and time has been set you could edit the
VCR timer settings.
You can select the desired language for the OSG (On-Screen Graphics) display using the , keys when the
“Menu Language”option is selected. Similarly you can selected a different audio channel when the “Audio
Language”option is selected. This option allows you to select a different language to listen to if supported.
User’s Setting
Local Time Setting
A/V Output Setting
About Echostar
Language Setting
3
1
4
2
Exit
i
Language Setting
Menu Language
Main Audio Language English
×English Ø1
22nd Audio Language English
Subtitle Language English
3
4
Exit
i
Local Time Setting
Year
Month Jan.
Date 01
Day Sun.
Minute 00
Hour 00
Local Time = --:--
1
3
6
2
4
5
Press OK to set the time
iExit
×1999 Ø
7

Please select your TV format.
4:3 for normal screen TV
16:9 for wide screen TV
Aspect
A/V Output Setting
17
AboutEchoStar
Here you can find the information about our co
mpany.
If you have any questions about the EchoStar
D-2510IP VIACCESS, firstly contact your loca
l dealer.
You can select the time out
time(2,3,4,5,8,10 secs) of the banner
information about the current channel and
program using the , keys.
Banner
You can select the type of Video standard by using the , keys.
* Video standard : PAL B/G,I , D/K
Select the vacant channel considering your local channels and preset channels below.
* Pre-set : Ch 38 for PAL B/G,I Ch 40 for PAL D/K
UHFfrequency is set automatically according to the channel selection.
UHF Tuning
Sub.backg.Select ‘On’for Subtitle background on TV (Subtitle background).
A/V Output Setting
Aspect
Banner 3Sec
Sub. backg. On
PAL B/G
Frequency = 607.25MHz
Channel 38
<<<UHF Tuning >>>
2
3
5
4
1
iExit
×4:3 Ø
i
Company info
Exit
Company Echostar Intl. Corp.
Address Schuilenburglaan 5a
City 7604 BJAlmelo
About EchoStar
Fax Number [phone]
Phone Number [phone]
Country Netherlands
Unit D-2510IP VIACCESS
Software version XXXXXX
Home page HTTP://www.echostar.nl
Unit info

18
Installation
B. Main menu and Installation
Press the MENU key to display the “Main Menu”o
n the screen.
Main Menu
Select a sub-menu using the , keys or the numeric k
eys. Please note that the OK key is always a confirma
tion of your selection. To go back to the previous me
nu, press the MENU key.
The Installation Lock “Enter PIN code”menu is displayed only when the Installation and Edit Lock is se
t as [ON]. The initial code is set as [0000]but you can change it (See “Change PIN code”on page 20).
Program Satellites
In some cases it might be necessary to reposition all satellites at once. This can be achieved with the “Re-align di
sh”option.
You can move the dish using the , keys when the “Position”option is selected. . To locate a satellite move the
dish until you have the location of the satellite at which the best signal quality is achieved. Press the OK key wh
ile still on the “Position”option to store the position. The stored locations for each satellite are shown above the
Signal Level bar.
If you are unable to get any signal quality, please check the LNB Setting to ensure you have selected the correct
LNB and switch settings.
This menu is to align your dish to the selected satellite.
If you set the “Polarity Control”parameter in the “LNB
Setting”menu as “Polarotor”or “Ferrite”, you canadjust
the “Skew”parameter in this menu while you are watchi
ng the signal level at the same time.
Refer to the Signal Quality bar and the Signal Lev
el bar at the bottom of the screen. It is recommend
ed that the signal is at the Medium level or higher.
If it is not , please adjust your satellite dish.
Enter PIN Code
[ ? ? ? ?]
Installation Lock
7
8
Program Satellite
Satellite 028.2°E
LNB Type Type1
TP/Pol/SR(Digital) 11478/H/30000
Skew Not set
Position
Re-align dish +00
Search type Auto Search
Start Search(Press OK)
2
3
4
E 1172 W
EL WL
Signal Level
Signal Quality
6
12%
00%
1
[ E 1172 W ]
ASTRA2
5
i
Installation
SMATV Configuration
User’s Setting
LNB Setting
Motorized Dish Setting
ProgramSatellites
1
43
5
6AdvancedInstallation
2
Exit
i
Main Menu
TVChannels
Radio Channels
Parental Control
VCR Timer
Edit
SelectSatellite
Conditional Access
32
5
6
7
Exit
8
4
I
Installation
6
1

Note: To stop searching press the key on the
Using the Auto Search option, the EchoStar D-2510IP
VIACCESS searches for all available channels(Radio an
d TV) on the currently selected satellite. The names of th
e found TV channels are shown on the left and the total n
umber of found TV and Radio channels are mentioned o
n the right.
Auto Search
A Satellite Master Antenna Television (SMATV) system
is intended for the distribution of television and
sound signals to household in one or 6more adjacent
buildings.
A SMATV System represents a means for sharing
the same resources among several users for satellite and
terrestrial reception, and it is designed to perform
the adaptation of the satellite TV signals to the SMATV
channel characteristics.
This receiver has a SMATV-IF facility to operate with SMATV.
This configuration allows the direct distribution of the QPSK signal received from the satellite
to the SMATV-IF distribution network in the extended IF band (above 950 MHz).
Before you start, you have to check your condition whether it is possible to use this facility or not in your
households. (You can ask your household supervisor.)
If this receiver is connected to a SMATV network, select “SMATV Configuration”.
The most common alternatives for “Symbol rate”and “FEC”are already preprogrammed.
(When you need to change the “Symbol rate”for the exceptional frequency, select as you know.)
Move to “Start Auto Search”and just press OK.
Then, the “Auto Search”procedure will start.
To cancel the processing while the “Auto Search”is proceeding, press the MENU key.
SMATV Configuration
19
SMATV Configuration
Symbol rate alternative 2 27500
Symbol rate alternative 3 27500
FEC AUTO
Start Auto Search
Symbol rate alternative 11
2
43
5
×27500 Ø
i
Exit
Auto Search
ASTRA1
Channel searching status
0% 50% 100%
Found TV ch. : 240
Found RAD. Ch. : 100
Index Freq SR FEC Polarity
45 12670 22000 5/6 vertical
Arte
Beta BC
BD1
Estilo
Musicals
Reqqae
remote control or on the front panel. This
cancels the searches and the found channels
will be discarded. All other keys of the remote
are disabled during searching
