Tiger 370 CNC--MR User manual

USE AND MAINTENANCE MANUAL
YEAR OF MANUFACTURE: ______________
TIGER 370 CNC--MR
EN

EN
”CE” CONFORMITY DECLARATION
(according to EEC MACHINES DIRECTIVE 2006/42/CE annex II A)
The manufacturer:
SPA
SEGATRICI
Via Enzo Magnani, 1
61045 Pergola (PU) ITALIA
Tel. [phone]--Fax [phone]
Hereby declares that the circular sawing machine:
Machine model:
Serial number:
Year of manufacture:
TIGER 370 CNC--MR
is in specification with the following directives:
•DIRECTIVE EEC MACHINES DIRECTIVE 2006/42/CE
•DIRECTIVE 2006/95/CE ”LVD”
•DIRECTIVE 2004/108/CE ”EMC”
•D. Lgs. 17/2010
Responsible of a Technical File
(Walter Di Giovanni) c/o MEP SPA
Via Enzo Magnani, 1
61045 -- Pergola -- PU -- ITALY
Pergola, lì
Managing Director
(William Giacometti)

5
Introduction and technical specifications 1--1..........
Foreword 1--1...................................
Machine presentation 1--1..........................
Machine specification 1--2.........................
Technical Data 1--2...............................
Technical Data 1--4...............................
Dimensions 1--4.................................
Functional parts 2--1..............................
TIGER 370 CNC--MR model 2--1...................
Cutting head 2--2.................................
Cutting vice 2--2.................................
Control Panel 2--3................................
Feeder 2--3......................................
Base 2--4.......................................
Safety and accident prevention 3--1..................
Use of the machine 3--1...........................
General recommendations 3--1......................
Recommendations to the operator 3--2................
Machine safety devices 3--4........................
Reference standards 3--4...........................
Protection against accidental contact with the blade 3--5..
Electrical equipment 3--5..........................
Emergency devices 3--5...........................
Noise level of the machine 3--6......................
Noise level measurement 3--6.......................
Noise level values 3--7............................
Vibration emission 3--7............................
Electromagnetic compatibility 3--7...................
Machine installation 4--1...........................
Packaging and storage 4--1.........................
Anchoring the machine 4--4........................
Minimum requirements 4--4........................
Check list 4--4...................................
Connection to the compressed air supply 4--6..........
Connection to the power supply 4--6.................
Description of machine operation 5--1................
Description of the control panel 5--1.................

6
Key for control console keyboard 5--1................
Basic instructions for carrying out a cutting cycle 5--4...
Manoeuvring the cutting head 5--4...................
Access to the cutting head 5--4......................
Manoeuvring the feeder 5--4........................
Clamping the work piece in the vice 5--4..............
Lubricant/coolant fluid supply 5--6...................
Preliminary check list for cutting operation 5--6........
Starting up the machine 5--7........................
Semi--automatic operating cycle 5--8.................
Automatic operating cycle 5--12......................
Single program 5--15...............................
Multiple programming 5--22.........................
Multiple programming cuts 5--29.....................
Automatic loop operating cycle 5--30..................
Diagrams, exploded views and replace--
ment parts 6--1...................................
Pneumatic diagram TIGER 370 CNC--MR 6--1.........
Pneumatic diagram TIGER 370 CNC--FE HR 6--2......
APS/P drive for step motors 6--3....................
MEANING OF THE PARAMETERS IN THE TABLE 6--3
SCHEMATIC CONFIGURATION
OF INPUTS / OUTPUTS 6--7......................
LAYOUT OF APS/P DRIVE COMPONENTS 6--8.....
How to read the wiring diagrams 6--9.................
D2--Letter codes used to designate the type
of component 6--11................................
Standardised Wiring Diagrams TIGER 370 CNC--MR
(IEC 750 EN 60204--1 Standard) 6--14.................
List of cables 6--29................................
List of components 6--34............................
List of terminals 6--37..............................
List of IUD--IUV Card Inputs and Outputs 6--39.........
IUD: Digital Inputs and Outputs 6--39.................
IUV card: Miscellaneous Inputs and Outputs 6--39.......
CN 1 VICE 6--40..................................
CNSL card: Console Inputs and Outputs 6--41...........
Exploded views 6--42..............................

7
Base 6--42.......................................
Fixed worktable 6--44..............................
Turntable 6--46...................................
Vice assembly 6--48...............................
Head unit 6--50...................................
Motor assembly 6--52..............................
Blade guard unit 6--54..............................
Electro--cylinder unit 6--56..........................
Supply carriage unit 6--58...........................
Supply roller unit 6--60.............................
Control panel 6--62................................
Guard rail 6--64...................................
Adjustments 7--1.................................
Displaying and editing the set--up parameters 7--1.......
Set language parameter 7--1........................
Set parameter for machine type 7--2..................
Set parameter for step motor 7--2....................
Setting blade characteristics, head downstroke
speed and bar initializing 7--5.......................
Blade motor and supply unit setting 7--5..............
Set minimum blade tension threshold 7--6.............
Optional settings 7--6.............................
Cutting head setting 7--7...........................
Head transducer calibration Set--up 7--7...............
Electronic systems 7--9............................
Replacing the microchip C8 on the control console 7--9..
Machine parameters Eeprom memory 7--9.............
Replacing the MEP 24 controller Eprom 7--10..........
Adjusting the display brightness 7--11.................
Mechanical systems 7--12...........................
Cutting head stroke 7--12...........................
Adjusting the position of the blade--cleaning brush 7--12..
Replacing tool 7--14...............................
Feeder 7--15......................................
Vice 7--17.......................................
Adjusting the vice play 7--17........................
Adjusting the anti--chip device 7--18..................
Maintenance and choice of consumables 8--1...........

8
The role of the operator 8--1........................
Maintenance requirements 8--2......................
General maintenance 8--2..........................
Daily 8--2.......................................
Weekly 8--2.....................................
Monthly 8--3....................................
Maintenance of working parts 8--3...................
Transmission box 8--3.............................
Consumable materials 8--4.........................
Oils for transmission box 8--4.......................
Oils for lubrication/coolant liquid 8--4................
Oils for spray mist system (optional) 8--4..............
Cutting speed and choice of tools 9--1................
Cutting speed 9--1................................
Basic version 9--1................................
Choice of blade 9--2..............................
Tooth pitch 9--2..................................
Types of swarf: 9--3...............................
Cutting and feeding speed 9--3......................
Lubricant/coolant 9--4.............................
Blade structure 9--4...............................
Types of blades 9--5..............................
Tooth shape 9--5.................................
Blade selection table with respect to cutting speed and
downstroke speed 9--8.............................
Classification of steels 9--9.........................
Classification of steels 9--10.........................
Troubleshooting 10--1..............................
Troubleshooting blade and cutting problems 10--1........
Troubleshooting (control console diagnostics) 10--3......
Displaying the diagnostics menu 10--3.................
Diagnostics 10--4..................................
Error messages, alarm and emergency 10--7............
Optional 11--1....................................
Accessories available on request 11--1.................
Chute type bar loader CB 6001 11--1..................
Optional 11--3....................................
Blade 11--3......................................

9
Roller table 11--3..................................
Can of emulsible oil 11--3...........................
Adattatore pianale a rulli lato scarico 11--3.............
Feed side roller table support 11--4....................
Motor chip discharger unit 11--4......................

1--1
Introduction and
technical
specifications
Foreword
We have decades of experience in the construction of the best metal---cutting
machines. Our experience, our knowledge of our customers and constant
technological development of design and production equipment allow us to offer
a specific solution for every type of cutting need. This work tool has been
designed as a simple and reliable answer to the wide range of cutting needs of the
modern workshop. TIGER 370 CNC---MR is rugged, quiet and safe. It cuts
various kinds of material, with very little scrap and great applicative flexibility for
cutting copper, brass and bronze.
Congratulations for having chosen this product which, by following the instruc-
tions contained in this user and maintenance handbook, will guarantee you years
of dependable service.
This band saw has been exclusively designed to cut metals.
Machine presentation
TIGER 370 CNC---MR is an electromechanical pneumatic saw, which cuts metal
profiles and solids. It can operate in SEMIAUTOMATIC or AUTOMATIC
mode. In Semiautomatic mode, after setting the cutting head stroke and the head
downstroke speed on the control panel, position the vice 2÷3 mm from the
material being processed and press the start button on the control panel to
activate the disk (or foot pedal if supplied);
1.Thecuttervicecloses 2. The head lowers un-
til the cut is made
(FCTA)
3. The head returns to
start position (FCTI)
4. The cutter vice
opens
In Automatic mode, after setting the cutting head stroke and the head downstro-
ke speed on the control panel, position the vice 2÷3 mm from the material being
processed and press the start button on the control panel to activate the disk (or
foot pedal if supplied):
Warning
1

MEP S.p.A.
1--2 2 Use and maintenance manual TIGER 370 CNC-- MR
1.Thecuttervicecloses 2. The head lowers un-
til the cut is made
(FCTA)
3. The head returns to
start position (FCTI)
4. The feed vice closes
5.Thecutterviceopens 6. The cutting material
is fed
7. The cutting
v
ice closes 8. The feed vice opens
and the cutting cycle
starts up
Machine specification
Theanodisedaluminiumnameplateisrivetedonthesideofthemachine;the
same data are reproduced on the declaration of conformity included with this use
and maintenance manual.
TIGER 370 CNC--FE MR
When communicating with the Technical Service department, the model, serial
number and year of manufacture of the machine must be quoted.
Technical Data
WORKING PRESSURE
Max. working pressure for opening/closing vice Bar 6
Air consumption for a complete cycle Nl/min 5,74
The “air consumption” value refers to standard conditions (temperature 0°and
pressure 1.013 bar, i.e. density 1.3 x 10-- 3 Kg/l) where 1 Kg/min. = 772 Nl/min.
N.B.
N.B.

1--3
3Introduction and technical specifications
LUBRICANT/COOLANT FLUID AND OIL
Lubricant/coolant fluid (oil concentration 5---6%) capacità Lt. 105
Oil for transmission box capacità Lt. 10
VICE
Vice max. opening mm 190
CUTTING CAPABILITY
Model Blade diameter
0° 370 120 100 180 x 100
45° '370 70 70 70 x 100
45° a370 70 70 70 x 100
60° a370 50 50 50 x 100
CUTTING CAPABILITY
Model Blade diameter
0° 370 120 100 180 x 100
45° '370 115 100 120 x 100
45° a370 115 100 120 x 100
60° a370 115 90 90 x 100
PACKED WEIGHT
Wooden cage and pallet Kg 250
Wooden pallet Kg 100
2600
1800
2100

MEP S.p.A.
1--4 4 Use and maintenance manual TIGER 370 CNC-- MR
Technical Data
CUTTING SPEEDS
Speed rpm 900
Speed (optional) rpm 600900
Disk blade (HSS type)
External disc diameter mm 370
Internal hole diameter mm 32
Blade thickness mm 3
RATED ELECTRICAL POWER
Head spindle motor Kw 3
Electric coolant pump motor Kw 0,09 x 2
Feed step motor Kw 0,44
Step head motor kW 0,048
Max installed power kW 3.668
SPINDLE MOTOR
No.of poles Current (Volts) Absorption (Amps) Power (Kw) rpm
6 380 8,4 3 940---1130
Stator wound with enamelled copper wire, class H 200° C.
Class F insulation (limit temperature TL 155° C).
IP 54 protection rating (total against contact with live parts, water sprayed from all directions, with shaft oil
seal).
Conforming to CEI norms, publication: IEC 34 of 01/07/1985.
Dimensions
MACHINE INSTALLED
Work table height mm 1000
Weight Kg 1060

1--5
5Introduction and technical specifications

2--1
Functional parts
TIGER 370 CNC--MR model
In order for the user to move towards a full understanding of how the machine
works, which is described in detail in the chapter 5, this chapter deals with the
main units and their locations.
2

MEP S.p.A.
2--2 7 Use and maintenance manual TIGER 370 CNC-- MR
Cutting head
The cutter head makes the cut. It is contained inside guards preventing accidental
contact with the tool and moving parts. It is moved by an electro---mechanical
cylinder (step motor), and runs on a twin linear guide with ball---bushing sliding
blocks. This system makes the structure highly rigid, providing a better cutting
finish with less vibration and noise.
Cutting vice
The vice is the unit that clamps the workpiece during cutting; it consists of a vice
support, commonly known as a “lead nut” fixed to the work table on which a
mobile jaw is mounted. The vice is operated manually by a handwheel and locked
by a Pneumatic cylinder.

2--3
8Functional parts
Control Panel
The control panel has a protection rating of IP 54 and contains the electronic
equipment. Access to the control panel is protected by a safety panel mounted on
hinges and fastened with screws, specially designed to prevent tampering. The
control panel swivels on two articulated joints so that it can be positioned by the
operator for greater ease---of---use and safety.
Feeder
The material, locked by means of the pneumatic vice, is delivered by a carriage
which conveys it along ground guides. The numeric check controls, with great
precision, the step motor of the infeed carriage, enabling the operator to set, on
the same bar, 32 batches of pieces to be cut, each with different amounts and
lengths.The material, locked by means of the pneumatic vice, is delivered by a
carriage which conveys it along ground guides. The numeric check controls, with
great precision, the step motor of the infeed carriage, enabling the operator to
set, on the same bar, 32 batches of pieces to be cut, each with different amounts
and lengths.

MEP S.p.A.
2--4 9 Use and maintenance manual TIGER 370 CNC-- MR
Base
This unit features a large coolant collection surface which conveys the coolant to
the rear tank via the tank cover, and a swarf collection drawer. An electric pump
is housed inside the tank which draws the clean fluid from the filter system.

3--1
Safety and accident
prevention
The TIGER 370 CNC---MR has been designed and produced in accordance with
European standards. For the correct use of the machine we recommend that the
instructions contained in this chapter are carefully followed.
Use of the machine
The TIGER 370 CNC---MR circular saw is designed to cut exclusively non---fer-
rous profiles and solid metal sections. Other types of material and machining are
not compatible with the specific characteristics of the saw. The employer is
responsible for instructing the personnel who, in turn, are obliged to inform the
operator of any accident risks, safety devices, noise emission and accident
prevention regulations provided for by international standards and national laws
regardingtheuseofthemachine.Theoperatormustbeperfectlyawareofthe
position and function of all the machine’s controls.The instructions, warnings and
accident prevention standards in this manual must be respected without question
by all those concerned.The following definitions are those provided for by EEC
MACHINES DIRECTIVE 2006/42/CE :
H“Danger zone”: any zone in and/or around a machine in which the presence of a
person constitutes a risk for the safety and health of that person.
H“Person exposed”: any person finding himself either completely or partly in a
danger zone.
H“Operator”: the person or persons given the responsibility of installing, operating,
adjusting, maintaining, cleaning, repairing or transporting the machine.
The manufacturer declines any responsibility whatsoever, either civil or crimi-
nal, should there be unauthorised interference or replacement of one or more
parts or assemblies on the machine, or if accessories, tools and consumable
materials are used that are different from those recommended by the manu-
facturer itself or if the machine is employed in a plant system and its proper
function is thereby altered.
General recommendations
LIGHTING
Insufficient lighting for the types of operation envisaged could constitute a safety
hazard for the persons concerned. For this reason, the machine user must provide
lighting in the working area sufficient to eliminate all shadowy areas while also
avoiding any blinding light concentrations. (Reference standard ISO 8995---89
”Lighting in work environments”).
CONNECTIONS
Check that the power supply cables and pneumatic feed systems comply with the
maximum machine absorption values listed in the “Machine Specification” tables;
replace if necessary.
Attention
3
