Timago TableTIM User manual

Strona 1z 4
INSTRUCTIONS FOR USE
Bedside table
Product code: TableTIM
1. Characteristics
The bedside table is shaped like a C-shaped metal frame. It has an
adjustable top on which objects can be placed and casters with a brake
to ensure mobility and movement over the bed
Support components:
a. Frame
b. Base with wheels (2 sets)
c. Tabletop frame
d. Tabletop arbor
e. Mounting butterfly
f. Mounting butterfly with screw
g. Bushing
h. Screw with washer (2 sets)
i. Tabletop

Strona 2z 4
2. Application
The bedside table is designed for use directly above a patient's bed to
provide a surface for eating, reading or writing while in bed. The
product is designed for use both during care in medical facilities and at
home.
3. Assembly and adjustment
•to the frame (a) screw both bases with wheels (b) - remember to
properly match the letter markings - the letter "A" from the frame
to the letter "A" of the base with wheels, similarly for the letters
"B" / "C" / "D",
•after twisting the base, set it on 4 wheels and lock the wheel
brakes for further assembly,
•into the square hole of the frame (a) insert the frame of the top
(c),
•into the angled chamfered hole of the tabletop frame (c) insert
the tabletop pin (d) in such a way that the two chamfered surfaces
overlap,
•into the circular hole of the tabletop frame (c) insert the sleeve (g)
on the protruding thread in such a way that the previously
inserted tabletop mandrel (d) is not moved,
•on the protruding thread of the tabletop arbor (d) screw the
mounting butterfly (e) - do not tighten the butterfly firmly -
tighten it enough so that it does not fall out,
•put the tabletop (i) on the prepared tabletop frame. To facilitate
the installation of the countertop, grasp it with one hand by the
tube located from the underside of the countertop. After applying
the countertop, tighten the mounting butterfly (e),
•fix the mounting butterfly with the screw (f) in the frame hole (a)
and tighten it,
Adjusting the tilt of the tabletop
•to adjust the angle of the tabletop, loosen the mounting butterfly
(e) located on the side of the tabletop.

Strona 3z 4
•after setting the correct angle, tighten the mounting butterfly (e)
Adjusting the height of the tabletop
•to adjust the height of the tabletop, loosen the mounting butterfly
with screw (f) located on the base frame (a).
•after setting the correct height, tighten the mounting butterfly
with screw (f)
Brakes
•lock the wheel brakes for the time of use of the table
4. Technical data
Dimensions (length x width)
60,5 cm x 40,2 cm
Tabletop dimensions
60 x 40 cm
angle adjustment of the tabletop
0°- 90°
Height adjustment
72 –112 cm
Weight
6,7 kg
Max. capacity
10 kg
Wheels diameter
1,50”
5. Storage and transport conditions
The product should not be exposed to direct sunlight, water or
moisture.
6. Warranty information
All products distributed by our company are covered by a warranty, the
terms of which are described in the warranty card available on our
website. Please contact the retailer from whom you purchased the
product. Please, keep in mind that for warranty purposes, the proof of
purchase (receipt or invoice) should be retained.

Strona 4z 4
7. Labels
Reference
number
Manufacturer
LOT number
Manufacture date
Serial number
Medical device
Note
Please read the
instruction
The manufacturer checked for compliance with
essential medical devices requirements.
Timago International Group
Spółka z o.o. i Spółka – Spółka komandytowa
ul. Karpacka 24/12
43-316 Bielsko-Biała, Poland
T.: [phone]
F.: [phone]
E.: [email protected]
12/2022(I)
