1071 Decade Capacitance Box
Technical Manual

2
V1.1 Page | 21071 Technical Manual
Contents
1. S pecification.....................................................................................................2
2. Operation ..........................................................................................................3
3. Guarantee & S ervicing.....................................................................................4
All Time Electronics' instruments are subject to continuous development and improvement and in
consequence may incorporate minor detail changes from the information contained herein.
1. Specification
RANGE TYPE
ACCURACY
@ 1kHz
MAX
VOLTAGE
TEMP
COEFF
ppm/degC
max
POWER
FACTOR
@ 1kHz
INSULATION
TO CASE
RESISTANCE
9 x 10pF Silver mica 1% ± 5pF 300V dc
200V ac 200 < 0.0025 > 50G ohms
9 x 100pF Silver mica 1% ± 5pF 300V dc
200V ac 200 < 0.0015 > 50G ohms
9 x 1nF Silver mica 1% ± 5pF 300V dc
200V ac 50 < 0.002 > 50G ohms
9 x 10nF Silver mica 1% 100V dc
72V ac 50 < 0.01 > 30G ohms
9 x 100nF Poly-
carbonate 1% 100V dc 72V ac 75 < 0.01 > 30G ohms
9 x 1µF Poly-
carbonate 1% 100V dc 115V ac 75 < 0.01 > 30G ohms
9 x 10µF Polyester 5% 63V dc
50V ac 300 < 0.01 > 30G ohms
Zero Residual Capacitance: ≈55pF
Operating Temperature: 0 to 70°C
Construction: The case is of robust metal construction finished in
two-tone blue and black. A removable protective boot
houses the instrument
Dimensions: 215 x 100 x 120mm (incl. protective boot)
200 x 75 x 110mm (without)
Weight: 1kg (incl. protective boot), 0.6kg (without)

3
V1.1 Page | 31071 Technical Manual
2. Operation
The 1071 is a portable decade capacitance box, housed in a robust metal case and
designed for industrial, laboratory and education requirements.
The unit incorporates a colour coding system which divides the setting into three groups -
µF = Red ηF = White ρF = Yellow
The high accuracy obtained in the 1071 is achieved by the use of accurate, stable
capacitors. A thumbwheel switch provides precision selection of output capacitance.
A multiple gold contact switch arrangement ensures that should a contact fail, there is
always a back-up contact available.
To select a value simply dial up with the digit switches.
For example to set 2.746µF select:
•2 on the 1µF bank
•7 on the 100ηF bank
•4 on the 10ηF bank
•6 on the 1ηF bank
Connection to the box can be made via 4mm shrouded plugs, as well as standard plugs,
bare wires, and spade terminals. Two connections red and black connect to the capacitance
and the grey terminal connects to the case for screening purposes.
Note: Remember that all capacitance boxes have a residual capacitance, i.e. even when
the dials are set to zero there is still a capacitance value across the output. If you are
making precision measurements or recalibrating the instrument this residual value must be
subtracted from all measurements.

4
V1.1 Page | 41071 Technical Manual
3. Guarantee & Servicing
Guarantee Period
This unit is guaranteed against defects in materials and workmanship for a period of one
year from its delivery to the customer.
We maintain comprehensive after sales facilities and the unit can, if necessary be returned
to us for servicing. During this period, Time Electronics Ltd will, at its discretion, repair or
replace the defective items. For servicing under guarantee, the instrument type and serial
number must always be quoted, together with details of any fault and the service required.
The purchaser of the instrument must prepay all shipping charges. Time Electronics Ltd will
pay return shipping charges.
This guarantee is void if servicing has been attempted by an unauthorised person or agent.
If, during the guarantee period, failure is due to misuse or abuse of the unit, the repair will
be put in hand without delay and charged unless other instructions are received.
Please note that if you require a new UKAS Certificate during the warranty period, this will
be charged at the current rate on our price list.
Service After Guarantee Period
Even after the guarantee period has expired, Time Electronics Ltd., can still service your
instrument. As the manufacturer, we have the specialised knowledge needed to keep your
instrument in peak condition and we also maintain a comprehensive spare parts service.
Please enclose details of the service required and your full company details including a
contact name when returning for servicing.
Returning Instruments
When returning instruments, please ensure that they have been adequately packed,
preferably in the original packing supplied. Time Electronics Ltd will not accept
responsibility for units returned damaged. Please ensure that all units have details of
the service required and all relevant paperwork.
Send the instrument, shipping charges paid to:-
Time Electronics Ltd
Botany Industrial Estate, Tonbridge, Kent, TN9 1RH
Tel: [phone] Fax: [phone]
Email: [e-mail]
Web Site: www.TimeElectronics.com
Disposal of your old equipment
1. When this crossed-out wheeled bin symbol is attached to a product it means the
product is covered by the European Directive 2002/96/EC.
2. All electrical and electronic products should be disposed of separately from the
municipal waste stream via designated collection facilities appointed by the
government or the local authorities.
3. The correct disposal of your old appliance will help prevent potential negative
consequences for the environment and human health.
4. For more detailed information about disposal of your old appliance, please contact
your city office, waste disposal service or return to Time Electronics.
