Time Module VD37 Installer manual

Revised on : 23. Jun. 2017
SII Products
ANALOGUE QUARTZ
TECHNICAL GUIDE
&
PARTS CATALOGUE
Cal.VD37&VD38

[SPECIFICATION]
*Cal VD38
・・・
・・・・・・
・・・
Cal.VD37 without calendar
Outside diameter φ29.50 mm × 26.00 mm (3H-9H)
Casing diameter φ28.80 mm
3 Hands ( Hour , Minute , Second )
Dual time of 24 hour regulator hand
Dual time of 12 hour regulator hand
Dual time of 60 minute regulator hand , Calendar (Cal.VD37 only)
Two pole stepping motor
Step motor 3 pieces
Electronic circuit reset switch
Second setting device
Date setting (Cal.VD37 only)
Time difference correction
[ Time ]
Indicated by Hour , Minute , Second
Dual time of 24 hour regulator , dual time of 12 hour regulator , and
dual time of 60 minute regulator hands
[ Dual time of 24 hour regulator , dual time of 12 hour regulator , and
dual time of 60 minute regulator ] ±1hour / push
SR920SW (Silver oxide battery)
Battery life is approximately 2 years
Use 10-second gate
*Set the winding stem with crown at the normal position
0 Jewel
+1hour/push Time difference correction
-
Buttons
Antimagnetic
Button B
VD37 VD38
Free
Free
Date setting
Time setting with stop-second device
Time setting with stop-second device
Normal position
Crown
position
Button A
Second click
Free
Movement
Movement
size
1
SII Products
Less than ± 20seconds : Monthly rate at normal temperature range
≧ 1600A/m
Jewels
Measuring gate by
quartz tester
Battery
Accuracy
First
click
Left rotation
Right rotation
-1hour/push Time difference correction
Additional mechanism
Cal.
PARTS CATALOGUE / TECHNICAL GUIDE
Cal. No.
Item
Cal.VD37&VD38
Version-01
VD37&VD38
Time indication
Driving System
Cal.VD37...4.57 mm
Cal.VD38…3.97 mm
Total height

0012 079
0808 368 …Cal.VD37 only Auxiliary train wheel bridge screw
Date dial guard
Date dial …Cal.VD37 only
Refer to page 5 for each parts code
Auxiliary train wheel bridge
24 hours wheel Refer to page 5 for each parts code
Refer to page 5 for
each parts code
0810 368 …Cal.VD37 only
0885 002 Date jumper
Intermediate 24 hours
wheel 0802 368 …Cal.VD37 only
Date driving wheel
0806 368 …Cal.VD37 only 0817 368 …Cal.VD37 only
Date corrector wheel Intermediate date driving wheel
0737 891 …Cal.VD37 only 0836 369 …Cal.VD37 only
Intermediate wheel Intermediate wheel for date
for date corrector (D) corrector holder
0962 891 …Cal.VD37 only
0886 003
Intermediate 12 hours
wheel (B) 0962 891 …Cal.VD37 only
12 hours wheel
Refer to page 5 for
each parts code
0885 002
0886 001
Intermediate 12 hours
wheel (A)
Hour wheel Small minute wheel
Refer to page 5 for Refer to page 5 for
each parts code each parts code
2
18
PARTS CATALOGUE
Version-02
VD37&VD38
1
7
6
11
16
Intermediate wheel for date corrector (B)
3
12
10
Intermediate wheel for date corrector (C)
Intermediate 24 hours wheel
SII Products
2
20 19
17
15
4
13
9
85
14
Type of oil Oil quantity mark
Moebius 9010 NORMAL QUANTITY
Moebius 9030 SUFFICIENT QUANTITY
Disassembling procedures Figs.
53
⇒
1Reassembling procedures Figs.
1
⇒
53

Battery
Winding stem
Cal.VD37 …0351 177
0012 079 Cal.VD38 …0351 178
Switch spring screw
0012 079
Switch spring screw
Switch spring
Cal.VD37 …4250 100
Cal.VD38 …4250 102
4004 333
Circuit block
4270 358
Battery connection (-)
0012 079
0012 079 Train wheel bridge (B) screw
Train wheel bridge (B) screw
0125 331 0125 331
Train wheel bridge (B) Train wheel bridge (B)
0701 014 4146 177
Fifth wheel and pinion (B) Step rotor (B)
4146 177
Step rotor (B) 4002 923
Coil block (B)
4002 923
Coil block (B) 4239 357
Rotor stator (B)
4239 357
Rotor stator (B)
0701 014
Fifth wheel and pinion (B)
*All parts code are subject to changewithout notice.
30
31
29
SII Products
3
38
36
37
28
27
32
PARTS CATALOGUE
35
26
23
23
24
25
Version-03
VD37&VD38
21
22
34
33
Type of oil Oil quantity mark
Moebius 9010 NORMAL QUANTITY
Moebius 9030 SUFFICIENT QUANTITY

0125 248
Train wheel bridge (A)
Fourth wheel and pinion
Refer to page 5 for each parts code
0701 904
Fifth wheel and pinion (A)
0231 904
Third wheel and pinion
4146 890
Step rotor (A)
0261 034
Minute wheel and pinion
Center wheel and pinion
Refer to page 5 for each
parts code
0281 904
Setting wheel
Train wheel setting lever
4002 904 Refer to page 5 for each
Coil block (A) parts code
Setting lever
Refer to page 5 for
each parts code
0384 470
Yoke
4239 357
Rotor stator (A) 0282 890
Clutch wheel
Intermediate wheel for
*All parts code are subject to changewithout notice. date corrector (A)
PARTS CATALOGUE
Version-03
VD37&VD38
46
39
40
41
42
SII Products
4
43
44
47
48
50
51
52
53
49
0962 890 …Cal.VD37 only
45
*1
*1
Type of oil Oil quantity mark
Moebius 9010 NORMAL QUANTITY
Moebius 9030 SUFFICIENT QUANTITY
S-6

Remarks:
Date dial …Cal.VD37 only
*All parts code are subject to change without notice.
45 Center wheel and pinion 0221 157 0221 156
Version-04
VD37&VD38
Page
Auxiliary train wheel bridge4
Parts code
0126 357
Parts form
Parts code
0126 368
VD37 VD38 Parts formParts name
5
③
Part code
Position of
crown
Position of
date frame
Color of
figure
Color of
background
0878 220 3H 3H Black White
0878 221
No
SII Products
13 24 hours wheel 0888 014
0241 177
16 12 hours wheel 0902 016
0241 178
PARTS CATALOGUE
3H 3H White Black
P-2
0271 40620
0902 015
19
Hour wheel 0271 407
Small minute wheel 0888 014 0888 013
0888 013
P-4
50 Setting lever 0383 368 0383 470
49 Train wheel setting lever 0391 368 0391 357
40 Fourth wheel and pinion

・
The explanation here is only for the particular point of Cal.VD37&VD38
1.REMARKS ON INSTALLING THE BATTERY
(1) Battery
・
How to install the battery
Remove the hook of the switch springs battery clamp portion.
Insert the battery sideways, and have the hook of the switch springs battery clamp portion catch
the main plate.
Battery clamp position
Hook
Main plate
Hook
(2) After the battery is replaced with a new one or after the
Tweezers
battery is reinstalled following the repairing procedures,
Be sure to touch the short-circuit the AC terminal of circuit
block and the switch spring with conductive tweezers
to reset the circuit as illustrated at right.
(3) When the battery replaced with a new one, the time information stored in the built-in IC and the time
indicated by the dual time of 24 hour regulator , dual time of 12 hour regulator , and dual time of
60 minute regulator hands do not correspond with each other.
Reset the dual time of 24 hour regulator , dual time of 12 hour regulator , and dual time of 60 minute
regulator hands to "0" position following the procedure below.
If the dual time of 24 hour regulator , dual time of 12 hour regulator , and dual time of 60 minute
regulator hands should move improperly, also follow the same procedure.
Note
Refer to page 8 for each adjustment method.
TECHNICAL GUIDE
Version-01
VD37&VD38
6
SII Products
①
②

2.To remove the winding stem
(1) set the winding stem to normal position.
(2) While pushing the indented portion of the arrow,
pull out the winding stem.
Push
3.How to attach hands
Place the movement directly on a flat metal plate or the like and press in the hands.
*install the hour , minute , and second hands at the "12"o'clock position.
*nstall the dual time of 24 hour regulator hand at the "24" position.
*Install the dual time of 12 hour regulator and dual time of 60 minute regulator hands at the "12" and "60"
position respectively.
[ Reference ] The power of press hands
Minute & Hour Hands
< 5kg
Second Hand < 5kg
Dual time of 24 hour regulator hand < 3kg
Dual time of 12 hour regulator hand < 3kg
Dual time of 60 minute regulator hand < 3kg
SII Products
7
TECHNICAL GUIDE
Version-01
VD37&VD38

Minute hand
(Difference in time correct, move together
with dual time of 12 hour regulator and Button A … -1 hour / push
dual time of 60 minute regulator hands)
Hour hand
(Difference in time correct, move together
with dual time of 24 hour regulator and First position
dual time of 60 minute regulator hands) VD37…Date setting
VD38…Time setting
Second hand Crown at normal position
Dual time of 60 minute regulator hand Button B … +1 hour / push
(Difference in time correct, move together with dual time of
24 hour regulator and dual time of 12 hour regulator hands)
Note
*Dual time of 60 minute regulator hand rotates one revolution every 15 minute.
There is no problem because this is typical function.
Before setting the time , check if the dual time of 24 hour regulator , dual time of 12 hour regulator ,
and dual time of 60 minute regulator hands are in the "0"(12o'clock) position.
If either of the dual time of 24 hour regulator , dual time of 12 hour regulator , and dual time of
60 minute regulator hands are not in the "0" position, reset them following the procedure below.
The battery setting and after battery change, please execute the "0" position adjustment.
1.Pull out the crown. 3.Press button A or B to reset the 4.Push the crown back to
VD37…second click dual time of 24 hour regulator , the normal position.
VD38…first click dual time of 12 hour regulator ,
and dual time of 60 minute regulator hands to "0"position.
2.Keep the buttons "A"&"B" *By pressing button A the dual time of 24 hour regulator hand
pressed at the same time move clockwise. (+1step/push)
more than 2 seconds, *By pressing button B the dual time of 12 hour regulator and
and then release the buttons. dual time of 60 minute regulator hands move clockwise.
*Dual time of 24 hour regulator and (+1step/push)
dual time of 60 minute regulator hands *Dual time of 12 hour regulator hand are linked to dual time of
moves. Returned to whereit was. 60 minute regulator hand.
*Press and hold the button, possible to fast-forward modification.
Note
Please repeat above 4 steps, as 0 position adjustment, if the dual time of 60 minute regulator hand
moves as follows;
Up to 1 minute to 14 minutes, one step/push, in 15 minutes, repeat the one rotation / push
of 12 hour regulator hands adjustment
of 12 hour regulator hands adjustment
OPERATION
Version-01
VD37&VD38
SII Products
8
DISPLAY AND CROWN / BUTTON OPERATION
ADJUSTING THE DUAL TIME OF 24 HOUR REGULATOR , DUAL TIME OF 12 HOUR REGULATOR ,
AND DUAL TIME OF 60 MINUTE REGULATOR HANDS POSITION
Dual time of 24 hour regulator and dual time
Dual time of 24 hour regulator and dual time
Dual time of 24 hour regulator hand
Dual time of 12 hour regulator hand
A
B
A
B
Second position
VD37…Time setting

1.Pull out the crown when the second hand is at the
12 o'clock position.
[ Crown position ]
VD37…second click
VD38…first click
2.Turn the crown to set the hour and minute hands.
(Check that AM/PM is set correctly)
3.Push the crown back normal position in accordance with
a time signal.
Note
*The moment the date changes is midnight.
■
Using the time different correction
When moving to a country or area which is in a different timezone , the current time in the local time
can be corrected.
1.Crown the normal position
2.To adjust the time by pressing the button A or B.
*By pressing button A the hands move counter clockwise. -1hour / push
*By pressing button B the hands move clockwise. +1hour / push
1.Pull out the crown when the second hand is at the
12 o'clock position.
[ Crown position ]
VD37…second click
VD38…first click
2.To adjust the time by pressing the buttons A or B.
*By pressing button A the dual time of 24 hour regulator ,
dual time of 12 hour regulator , and dual time of 60 minute
regulator hands move counter clockwise.
*By pressing button B the dual time of 24 hour regulator ,
dual time of 12 hour regulator , and dual time of 60 minute
Note
regulator hands move clockwise.
Every 15 minutes, dual time of *Press and hold the button, possible to fast-forward modification.
60 minute hand is one rotation/push.
3.Push the crown back in to the normal position.
OPERATION
Version-01
VD37&VD38
TIME SETTING
SII Products
9
TIME SETTING...DUAL TIME OF 24 HOUR REGULATOR , DUAL TIME OF
12 HOUR REGULATOR , AND DUAL TIME OF 60 MINUTE REGULATOR HANDS
A
B

*Before setting the date, be sure to set the time.
1.Pull out the crown to the first click.
2.Turn the crown to clockwise until the next date appears.
3.Push the crown back in to the normal position.
Note
*Do not set the date during any time between 9:00 P.M. and 1:00 A.M.
Otherwise, the date may not change properly. If it is necessary to set the date during that time period,
First change the time to any time outside it, set the date and then reset the correct time.
OPERATION
Version-01
VD37&VD38
DATE SETTING …Cal.VD37 only
SII Products
10
