TimeTec Smart Curtain Control Panel User manual

www.i-timetec.com
User Guide
SMART CURTAIN CONTROL PANEL
AUTOMATES YOUR BORING DAILY ROUTINE

2
www.i-timetec.com
Smart Curtain Control Panel
PRODUCT BRIEF
The TimeTec Smart Curtain Control Panel can use its touch buttons
to control the electric curtain, or control by i-TimeTec smartphone App
after the smart home system is setup.

3
www.i-timetec.com
Smart Curtain Control Panel
FEATURES
1Soft touch control button
2Beeper for operation
3LED indicator
4Smartphone App control
TECHNICAL SPECIFICATION
Working voltage: AC 180V-250V 50Hz
Standby current: <=4mA
Working temperature: -10 - 55°C
Working humidity: <=90%RH
Communication distance: <=100M (open environment)
Type of output: dry contact
Dimension: 85mm x 85mm x 36mm
Installation: flush mount

4
www.i-timetec.com
Smart Curtain Control Panel
How to add the device to your smart home system?
Log in to your i-TimeTec App account
In the main menu, select Add Device, then scan the QR code of the device
(QR code is on the back and also on the PCB after remove the front panel).
Add the device to the TimeTec Smart Gateway or TimeTec Smart Camera
Gateway.
Connect the device to electricity wires, power it up so it will connect to the
TimeTec Smart Gateway by wireless.
Touch the button to control the curtain, the beeper sounds
The device can also be controlled by the i-TimeTec smartphone App.
HOW TO USE

5
www.i-timetec.com
Smart Curtain Control Panel
WIRING DIAGRAM
Remark:
This wiring example is based on the above control logic. If your curtain motor uses a differ-
ent logic by default, please change the setting to make it match.

6
www.i-timetec.com
Smart Curtain Control Panel
Install the standard 86 electric box onto the wall
Connect the electric wires to the switch correctly
Fix the switch onto the 86 electric box with screws
Fix the front panel onto the switch
Finish the installation
INSTALLATION
The device shall be installed in a dry place without chemical corrosion
The device shall be installed in a place without high electromagnetic in-
terference.
Do not connect to the electricity supply during installation. Double check
the wiring before power it up.
Please contact service agent if the unit does not work properly.
IMPORTANT NOTICES
If i-TimeTec Smartphone App control fail:
Check whether the device is already added and connected to the TimeTec
Smart Gateway.
If Curtain control fail:
Check the setting of your curtain motor, make sure it match the control logic
as shown in this manual.
TROUBLESHOOTING

7
www.i-timetec.com
Smart Curtain Control Panel
The device shall be installed in a dry place without chemical corrosion
The device shall be installed in a place without high electromagnetic in-
terference.
Do not connect to the electricity supply during installation. Double check
the wiring before power it up.
Please contact service agent if the unit does not work properly.
IMPORTANT NOTICES
If i-TimeTec Smartphone App control fail:
Check whether the device is already added and connected to the TimeTec
Smart Gateway.
If Curtain control fail:
Check the setting of your curtain motor, make sure it match the control logic
as shown in this manual.
TROUBLESHOOTING
