Tineco iFloor User manual

OFF
Spot
ON
BC

CONTENTS
1.Important Safety Instructions 01
2.Product Components 05
3.Accessory Instructions 06
4.Assembly 07
5.Product Operation 08
6.Daily Maintenance 12
7.Trouble Shooting 16
9.Warranty 18
8.Specification 17

SAVE THESE INSTRUCTIONS
Household use only.
When using an electrical appliance, basic precautions should always be
followed, including the following:
READ ALL INSTRUCTIONS BEFORE USING (THIS APPLIANCE), Failure to
follow the warnings and instructions may result in electric shock, fire and/or
serious injury.
WARNING–To reduce the risk of fire, electric shock, or injury:
1. Use only indoors, on non-carpeted floor surfaces such as vinyl, tile, sealed
wood, etc. Be careful not to run over loose objects or edges of area rugs. Stalling
the brush may result in premature belt failure.
.
2. Do not allow to be used as a toy. Close attention is necessary when used by
or near children, pets or plants.
3. Use only as described in this manual. Use only manufacturer’s recommended
attachments.
4. Do not use with damaged cord or plug. If appliance is not working as it should,
has been dropped, damaged, left outdoors, or dropped into water, return it to a
service center.
5. Do not handle charger, including charger plug, and charger terminals with wet
hands.
6. Do not put any object into openings. Do not use with any opening blocked;
keep free of dust, lint, hair, and anything that may reduce air flow.
7. Keep hair, loose clothing, fingers, and all parts of body away from openings
and moving parts.
8. Use extra care when cleaning on stairs.
9. Do not use to pick up flammable or combustible liquids, such as gasoline, or
use in areas where they may be present.
10. Do not pick up anything that is burning or smoking, such as cigarettes,
matches, or hot ashes.
11. Do not use without filter.
12. Prevent unintentional starting. Ensure the switch is in the off-position before
picking up or carrying the appliance. Carrying the appliance with your finger on
the switch or energizing appliance that have the switch on invites accidents.

13. Always switch off the appliance before making any adjustments, changing
accessories, or storing appliance. Such preventive safety measures reduce the
risk of starting the appliance accidentally.
14. Recharge only with the charger specified by TINECO. A charger that is
suitable for one type of battery pack may create a risk of fire when used with
another battery pack.
15. Use appliances only with specifically designated TINECO battery packs. Use
of any other battery packs may create a risk of injury and fire.
16. Under abusive conditions, liquid may be ejected from the battery; avoid
contact. If contact accidentally occurs, flush with water. If liquid contacts eyes,
additionally seek medical help. Liquid ejected from the battery may cause
irritation or burns.
17. Do not use a battery pack or appliance that is damaged or modified. Dam-
aged or modified batteries may exhibit unpredictable behavior resulting in fire,
explosion or risk of injury.
18. Do not expose a battery pack or appliance to fire or excessive temperature.
Exposure to fire or temperature above 130°C ( 266°F ) may cause explosion.
19. Follow all charging instructions and do not charge the battery pack or appli-
ance outside of the temperature range specified in the instructions. Charging
improperly or at temperatures outside of the specified range may damage the
battery and increase the risk of fire.
20. Have servicing performed by a qualified repair person using only identical
replacement parts. This will ensure that the safety of the product is maintained.
21. Do not modify or attempt to repair the appliance or the battery pack except
as indicated in the instructions for use and care.
22. Always turn off this appliance before connecting or disconnecting motorized
nozzle.
23.Do not charge or store the appliance outdoors or inside the car. Only charge,
store or use the battery in a dry indoor area where the temperature is higher than
4°C (39.2°F) but lower than 40°C ( 104°F ). The charger is for indoor use only.
24. Do not use to pick up ultrafine particles, such as lime, cement, sawdust,
gypsum powder, or ashes.
25. Do not use to pick up sharp objects, such as metallic nails, pieces of glass,
metal paper clips, or pins.

26. Do not use to pick up hazardous material and chemicals, such as solvent,
drain cleaner, strong acids or strong alkali.
27. Stop using immediately if the machine is overheating, making unusual noises,
issuing unusual odor, performing low suction, or leaks electricity.
28. Turn cleaner OFF and disconnect from electrical outlet in case of long-term
storage.
29. Always clean dirty water tank after each use to avoid potential blockage,
which may result to low suction power, motor overheating or reduce the service
life.
30. Store appropriately indoors in a dry place after use.
31. Do not place or submerge machine in standing water or try to clean flooded
areas.
32. All date and technical instruction of this manual based on results from lab
33. Do not use the appliance when the water depth is more than 5mm above
the surface.
tests of Tineco or designated third party. The company reserves all rights for final
explanation.
Range of Usage
• The iFloor cordless hard floor cleaner is to be used on indoors hard floor, such
as vinyl, tile, sealed wood, etc. Use on a rough surface may not get the best
performance.
• Keep your appliance away from heat sources, such as fireplace or heater, to
avoid casing deformation.
• Do not use to pick up flammable or combustible liquids, ultrafine particles, sharp
objects, hazardous material, chemicals or anything that is burning or smoking, as
described above.
About Cleaning Solution
• A large amount of cleaning solution entering into the motor may cause danger.
• Add solution as instructed in the Product Operation. We recommend using the
provided cleaning solution. Do not use the product with acidic, alkaline solution or
any substances harmful to the environment.
• Keep out of reach of children. If any solution gets into the eyes, immediately
flush them with clean water. If any solution be swallowed by accident, seek
medical care immediately.
• Dirty water and solution disposal should comply with local environmental regula-
tions.

About the Cleaner
• Do not modify or attempt to repair the cleaner except as indicated in the instruc-
tions for operating and cleaning.
• Charge the machine with Tineco iFloor adaptor. Input Voltage: AC 100-240V.
Both high and low voltages can damage the adaptor or the machine, even cause
danger to the user.
• Use extra care when cleaning on stairs.
• Ensure that the Power Switch is in the OFF-position before picking up or carry-
ing the machine. Do not lay flat or lean down the machine to prevent dirty water
from entering into the motor.
• To avoid being tripped accidentally , please put away the unit on the storage tray
near wall.
• Always install the tanks rightly before use.
• Do not allow the appliance or charger to get wet to avoid risk of fire or injury
caused by short circuit.

I. Solution trigger
C. Clean water tank release button
L. Clean water tank (CWT)
F. Dirty water tank Handle
O. Air outlet cover
Q. Deodorizing & sanitizing solution
T. Self-cleaning storage tray
B. Spot button
K. Handle fix screw
E. Dirty water tank release button
N. Floater
H. Brush roll
R. 3 in 1 cleaning tool
A. Switch button
J. Handle
D. Indicator light
M. Dirty water tank (DWT)
G. Brush roll cover
P. Brush rotator
S. Charger adaptor
Product Components

Deodorizing & sanitizing solution
3 in 1 cleaning tool
Self-cleaning Storage Tray
A full brush to clean DWT, brush chamber and the
opening; the end with bristle to remove dirt and mud on
the roller and DWT; the end with small blade to remove
hair and debris wrapped around the roller.
Store the 3-in-1 cleaning tool and the brush roll in the
tool caddy.
Remove dirt, grime, grease and tough stains from most
types of hard surfaces, vinyl, tile, sealed wood, etc.
Always use Tineco solution in your machine.
Add one bottle cap of solution to the water at a time.
Place the appliance on the storage tray vertically.
Accessory Instructions

To assemble the handle, insert it into
the unit base until you hear a click.
In case of product returning, please disassemble the
handle, first remove the screw with screwdriver, then
press the spring located with a tool to release the
handle. Lift the released handle from the unit.
Assembly

Note:
*
Note :
Before the first use, please charge the appliance for 3-4 hours (refer to “Charging Instructions”
for details).
Based on results from Tineco lab tests. Lab temperature 39.2°F (4℃) ~ 104°F (40℃)
Use directly when you just need to absorb water; add water/solution when you need to
deep clean the floor (refer to “Filling Clean Water Tank Operation” for details).
Switch ON to start the machine.
Press Spot button for spot mode to remove tough spots
and stains with higher speed and stronger spray.
Place the appliance on the storage tray vertically after use.
Do not recline the appliance over than 144° to against
water leakage.
Squeeze the Solution trigger when moving backward
to spray liquid as needed.
*Do not use for absorbing foam liquid.
*When cleaning excessively dirty, press Spot button forSpot mode.
Product Operation
<144°

Press dirty water tank release
button to remove it from the unit.
Pour dirty water and
debris out.
Place back the tank until
you hear a click.
Press clean water tank release button to
remove it from the unit.
Open the tank cap, fill the tank with warm tap water
(140°F/60°C MAX) to Max line. When need deep
cleaning, add one bottle cap of solution to the water,
then close the cap tightly.
Place back the tank until you hear a click.
Product Operation
Filling Clean Water Tank
Empty Dirt Water Tank

Product Operation
Charging Instructions
The indicator light will flash red when it’s power is low.
Please charge it.
1. Before charging the unit, please ensure that all
water has been removed from the clean and dirty
water tanks and the machine is dry.
2. To charge the unit, connect the external charger
cord to the unit and plug into the wall outlet.
3. To avoid being tripped accidentally, please put
away the unit on the storage tray near wall during
charging.
• Charge the unit only with the adaptor from TINECO.
• For optimal performance, the unit must be charged every 3 months. It may take 3 -4 hours for
a full charge.
• Store appropriately indoors in a dry place. Do not expose machine to sunlight or freezing
temperature. Recommended temperature range: 39.2°F(4
℃) ~ 104°F( 40 ℃).

Flashing red light: The appliance/brush roll is blocked, or out of power
Product Operation
Solid blue light: Normal mode
Flashing blue light: Spot mode
During Charging
Charging Complete
Breathing blue light.
Solid blue light for 2 minutes then turns off.
*Battery Disposal Warning:
• Remove the built-in battery before disposing.
• Switch OFF and disconnect plug from electrical outlet before removing the battery.
• Dispose of batteries properly and safely. DO NOT dispose of battery in fire, water, soil or trash
compactor.
• Leaks from battery cells can occur under extreme conditions. If any liquid gets on the skin wash
quickly with soap and water. If any liquid gets into the eyes, do not rub eyes, immediately flush them
with clean water continuously for a minimum of 15 minutes. Seek medical attention immediately.

Daily Maintenance
Note:
• In order to maintain machine performance, it is recommended that you clean the components
regularly.
• For optimal performance and prevent odor , always clean and dry DWT, floater, filters, pre
filter, brush roll, brush roll cover after each use.
To reduce the risk of injury, switch off and disconnect
plug from electrical outlet before performing mainte-
nance.
Use cloth to clean the surface with neutral detergent.
The cloth should be dry to prevent water from
entering the appliance.
Main Body
Note:
After performing maintenance, place back the appliance on the storage tray vertically. Do not
expose machine to direct sunlight, and store it appropriately indoors in a dry place.

Daily Maintenance
Note:
When dirty water reaches MAX line, the floater will block off your DWT creating a high pitched
sound indicating it’s time to switch OFF the appliance.
Dirty Water Tank
Switch OFF then pull up the tank lid to empty the DWT. Use 3 in 1 cleaning tool to
remove remaining debris. Rinse the inside of the dirty water tank.
Take off the filter from the tank lid, pull out the floater, and rinse them with water.
Note:
If the filter and the floater have been blocked, rinse with water.
Filter & Floater
Grasp recessed area on each side of the pre-filter and pull upward to remove, then rinse with water.
Let it dry out before placing back into the lid of the dirty water tank .
Pre-filter

Daily Maintenance
Brush roll self-cleaning
Place unit on storage tray. The clean water tank should be
at least 1/3 full of water. Press and hold the switch button
for 3 seconds to start the brush roll self-cleaning mode.
The appliance will automatically shut off once finished.
The entire self-cleaning process takes about 40 seconds.
Note:
• For optimal performance, use quick self-cleaning
fuction as often as needed.
• Please empty the dirty water tank before and after
self-cleaning.
hold the switch button for 3 sec
Grab the front handle while pressing the
button and pull upward to remove.
Rinse with water
Press hook A into the lock hole A, then
Press hook B into the lock hole B.
Always latch brush cover into right place to
avoid suction loss or water leak.
Note:
For optimal performance, please clean the brush roll cover periodically.
Brush Roll Cover

Daily Maintenance
Remove the brush roll by grabbing the brush
roll tab and pulling upward.
Take off the brush roll tab. Remove the hair and
debris wrapped around the roller with included 3 in
1 cleaning tool.Rinse with water.
Put the brush roll back into the tool caddy and let it
dry out before reinstalling.
Note:
For optimal performance, please clean the brush roll after each use.
Brush Roll
Remove hair and debris from the brush roll
chamber and the opening with tissue or cloth.
Put back brush roll by inserting the brush roll
end into the left side of the foot, then lock the
pull tab into place by pressing downward.

Trouble Shooting
Problem Possible cause Solution
Let your device cool down
before using
Device overheating
The light flashes
alternatively blue and redDefective product
Please contact us at
[email protected]
for further support
Loss of suction power
Solid red right
Brush malfunction
The sponge for pre-filter is dirty
Brush cover is not latched in place Reinstall brush cover
The DWT has picked up
maximum amount of dirty water
and has reached MAX line
Make sure brush roll and brush
roll cover installed correctly,
clean brush roll and debris
channel
Clean the pre-filter
Empty the dirty water then
reinstall the DWT
Machine makes unusual
noises during normal usage
The debris channel or the airway
is blocked
The DWT has picked up
maximum amount of dirty water
and has reached MAX line
Remove blockages
The debris channel or the airway
is blocked Remove blockages
Empty the dirty water then
reinstall the DWT
Machine won't charged The external charger cord not
correctly plugged
Unplug the charger, then plug
again into the machine and
then into the wall outlet
Machine won't spray
The CWT may be empty
The CWT may not be installed
correctly
Air outlet cover is leaking
water
Then floater or the sponge for
pre-filter may not be installed
The DWT has picked up
maximum amount of dirty water
and has reached MAX line
The sponge for Pre-filter is moist
The floater is blocked
Refill CWT
Install the CWT correctly
Install the floater and the
sponge correctly
Empty the dirty water then
reinstall the DWT
Let the sponge dry out
Remove blockages
Note:
Please make sure your machine has sufficient power. In any other case or if the solution
explained above did not solve the problem, please contact us at [email protected]

Model
Voltage
Rated Power
CWT Capacity
DWT Capacity
Waterproof
Charging Time
Charging Input
Running Time
Water Flow Rate
22mins
Normal: about 40ml/min
Spot: 220ml/min
100-240V
3-4hrs
13.53FL.OZ.(400ML)
IPX4
17.92FL.OZ.(530ML)
120W
iFloor
22.2V 2500mAH Li-ion
17

Web: www.tineco.com
Email: [email protected]
US Service Call: [phone]
Service Hours: Mon. – Fri. 9am - 6pm (CST)
tinecoglobal
Contact us - We'll get back to you within 1 business day.
