Titan TTI931BVC User manual

Cordless blower
18V
Original Instructions_YAT_TITAN_MNL_18V Blower_BXIM220_TTI931BVC_GB-V01
TTI931BVC
CAUTION: Read the instructions before using the product.
EN

02
EN
These instructions are for your safety. Please read through them thoroughly
before use and retain them for future reference.
Safety information
Your product
Before you start
03
17
18
Getting started... 02
In more detail... 20
21
22
24
27
28
29
31
32
33
35
Product functions
Operation
Care and maintenance
Trouble shooting
Recycling and disposal
Guarantee
Customer Care and Technical Helpline
Availability of Spare Parts
Technical specications
Declaration of conformity
Let’s
get started...

TTI931BVC
03
Getting started...
EN
Safety warnings
General power tool safety warnings
WARNING! Read all safety warnings,
instructions, illustrations and specications
provided with this power tool. Failure to follow
all instructions listed below may result in electric
shock, re and/or serious injury.
Save all warnings and instructions for future
reference.
The term “power tool” in the warnings refers
to your mains-operated (corded) power tool or
battery-operated (cordless) power tool.
Work area safety
1. Keep work area clean and well lit. Cluttered or dark
areas invite accidents.
2. Do not operate power tools in explosive
atmospheres, such as in the presence of
ammable liquids, gases or dust. Power tools
create sparks which may ignite the dust or fumes.
3. Keep children and bystanders away while
operating a power tool. Distractions can cause you
to lose control.
Electrical safety
1. Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power
Safety information

04
Getting started...
EN TTI931BVC
tools. Unmodied plugs and matching outlets will
reduce risk of electric shock.
2. Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric
shock if your body is earthed or grounded.
3. Do not expose power tools to rain or wet
conditions. Water entering a power tool will increase
the risk of electric shock.
4. Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges
or moving parts. Damaged or entangled cords
increase the risk of electric shock.
5. When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of
a cord suitable for outdoor use reduces the risk of
electric shock.
6. If operating a power tool in a damp location is
unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk
of electric shock.
Personal safety
1. Stay alert, watch what you are doing and use
common sense when operating a power tool. Do
not use a power tool while you are tired or under
the inuence of drugs, alcohol or medication. A
moment of inattention while operating power tools
may result in serious personal injury.
2. Use personal protective equipment. Always wear
Safety information

TTI931BVC
05
Getting started...
EN
eye protection. Protective equipment such as dust
mask, non-skid safety shoes, hard hat, or hearing
protection used for appropriate conditions will reduce
personal injuries.
3. Prevent unintentional starting. Ensure the
switch is in the off-position before connecting
to power source and/or battery pack, picking up
or carrying the tool. Carrying power tools with your
nger on the switch or energising power tools that
have the switch on invites accidents.
4. Remove any adjusting key or wrench before
turning the power tool on. A wrench or a key left
attached to a rotating part of the power tool may
result in personal injury.
5. Do not overreach. Keep proper footing and
balance at all times. This enables better control of
the power tool in unexpected situations.
6. Dress properly. Do not wear loose clothing or
jewellery. Keep your hair, clothing and gloves
away from moving parts. Loose clothes, jewellery
or long hair can be caught in moving parts.
7. If devices are provided for the connection of dust
extraction and collection facilities, ensure these
are connected and properly used. Use of dust
collection can reduce dust-related hazards.
8. Do not let familiarity gained from frequent use
of tools allow you to become complacent and
ignore tool safety principles. A careless action can
cause severe injury within a fraction of a second.
Power tool use and care
Safety information

06
Getting started...
EN TTI931BVC
1. Do not force the power tool. Use the correct
power tool for your application. The correct power
tool will do the job better and safer at the rate for
which it was designed.
2. Do not use the power tool if the switch does not
turn it on and off. Any power tool that cannot be
controlled with the switch is dangerous and must be
repaired.
3. Disconnect the plug from the power source and/
or remove the battery pack, if detachable, from
the power tool before making any adjustments,
changing accessories, or storing power tools.
Such preventive safety measures reduce the risk of
starting the power tool accidentally.
4. Store idle power tools out of the reach of children
and do not allow persons unfamiliar with the
power tool or these instructions to operate the
power tool. Power tools are dangerous in the hands
of untrained users.
5. Maintain power tools. Check for misalignment or
binding of moving parts, breakage of parts and
any other condition that may affect the power
tool’s operation. If damaged, have the power tool
repaired before use. Many accidents are caused by
poorly maintained power tools.
6. Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges are
less likely to bind and are easier to control.
7. Use the power tool, accessories and tool bits etc.
in accordance with these instructions, taking into
account the working conditions and the work to
Safety information

TTI931BVC
07
Getting started...
EN
be performed. Use of the power tool for operations
different from those intended could result in a
hazardous situation.
8. Keep handles and grasping surfaces dry, clean
and free from oil and grease. Slippery handles and
grasping surfaces do not allow for safe handling and
control of the tool in unexpected situations.
Battery tool use and care
1. Recharge only with the charger specied by the
manufacturer. A charger that is suitable for one type
of battery pack may create a risk of re when used
with another battery pack.
2. Use power tools only with specically designated
battery packs. Use of any other battery packs may
create a risk of injury and re.
3. When battery pack is not in use, keep it away
from other metal objects, like paper clips, coins,
keys, nails, screws or other small metal objects
that can make a connection from one terminal to
another. Shorting the battery terminals together may
cause burns or a re.
4. Under abusive conditions, liquid may be ejected
from the battery; avoid contact. If contact
accidentally occurs, ush with water. If liquid
contacts eyes, additionally seek medical help.
Liquid ejected from the battery may cause irritation or
burns.
5. Do not use battery pack or tool that is damaged
or modied. Damaged or modied batteries may
exhibit unpredictable behaviour resulting in re,
Safety information

08
Getting started...
EN TTI931BVC
explosion or risk of injury.
6. Do not expose a battery pack or tool to re
or excessive temperature. Exposure to re or
temperature above 130 °C may cause explosion.
7. Follow all charging instructions and do not
charge the battery pack or tool outside the
temperature range specied in the instructions.
Charging improperly or at temperatures outside
the specied range may damage the battery and
increase the risk of re.
Service
1. Have your power tools serviced by a qualied
repair person using only identical replacement
parts. This will ensure that safety of the power tool is
maintained.
2. Never service damaged battery packs. Service
of battery packs should only be performed by the
manufacturer or authorized service providers.
Safety instructions for garden blower
Training
1. Read the instructions carefully. Be familiar with the
controls and the proper use of the product.
2. Never allow children, persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge or people unfamiliar with these
instructions to use the product. Local regulations may
restrict the age of the operator.
3. Never operate the machine while people, especially
children, or pets are nearby.
Safety information

TTI931BVC
09
Getting started...
EN
4. Keep in mind that the operator or user is responsible
for accidents or hazards occurring to other people or
their property.
Preparation
1. Obtain ear protection and safety glasses. Wear them
at all times while operating the machine.
2. While operating the machine always wear substantial
footwear and long trousers. Do not operate the
machine when barefoot or wearing open sandals.
Avoid wearing clothing that is loose tting or that has
hanging cords or ties.
3. To prevent dust irritation the wearing of a face mask
is recommended.
4. Do not wear loose clothing or jewellery that can be
drawn into the air inlet. Keep long hair away from the
air inlets.
5. Operate the machine in a recommended position and
only on a rm, level surface.
6. Do not operate the machine on a paved or gravel
surface where ejected material could cause injury.
7. Before using, always visually inspect to see, that the
bolts and other fasteners are secure, the housing
is undamaged and that guards and screens are
in place. Replace worn or damaged components
in sets to preserve balance. Replace damaged or
unreadable labels.
8. CAUTION! Do not touch a rotating impelling fan.
Operation
1. Do not allow hands or any other part of the body or
Safety information

10
Getting started...
EN TTI931BVC
clothing inside the feeding chamber, discharge chute,
or near any moving part.
2. Keep proper balance and footing at all times. Do not
overreach.
3. Always stand clear of the discharge zone when
operating this machine.
4. Never operate the product with defective guards or
shields, or without safety devices.
5. Keep the power source clean of debris and other
accumulations to prevent damage to the power
source or possible re.
6. Do not transport this product while the power source
is running.
7. Stop the product and remove the battery pack. Make
sure that all moving parts have come to a complete
stop
- whenever you leave the machine,
- before clearing blockages or unclogging chute,
- before checking, cleaning or working on the
product,
- if the machine starts to vibrate abnormally, for
immediately check.
8. Do not tilt the product while the power source is
running.
9. Walk, never run.
10. Never operate the product near open windows, etc.
11. Operate the product only in daylight or in good
articial light.
12. Do not blow hard objects such as nails, bolts, or
rocks.
13. Apply extra care when cleaning debris from stairs or
Safety information

TTI931BVC
11
Getting started...
EN
other tight areas.
14. Follow below recommendations when using the
product:
- Use rakes and brooms to loosen debris before
blowing;
- Use the full blower nozzle extension.
Maintenance and storage
1. Disconnect the product from the power supply (i.e.
remove the battery pack) before checking, cleaning
or working on the product and when it is not in use.
2. Disconnect the product from the power supply
(i.e. remove the battery pack) before carrying out
maintenance or cleaning work.
3. Improper maintenance will lead to malfunction/failure
of the product.
4. Inspect and maintain the product regularly. Keep all
nuts, bolts and screws tight to be sure the product is
in safe working condition.
5. Always allow the product to cool before storing.
6. When servicing the blades be aware that, even
though the power source is switched off, the blades
can still be moved.
7. Replace worn or damaged parts for safety. Use only
genuine replacement parts and accessories.
8. Have the product repaired only by an authorised
service centre or similar qualied specialist.
9. When not in use, store the product in a dry place out
of the reach of children.
Additional safety warnings for battery pack
Safety information

12
Getting started...
EN TTI931BVC
1. Battery pack needs to be charged before use.
Always refer to the charger’s instruction and charge
it properly.
2. Remove the battery pack from the product when
not in use.
3. Don’t maintain the battery pack on the charger
when not in use.
4. After extended periods of storage, it may be
necessary to charge and discharge the battery
pack several times to obtain the maximum
performance.
5. Longer life and better performance can be
obtained if the battery is charged when the air
temperature is between 18°C and 24°C. Do not
charge the battery in air temperature below 5°C
or above 40°C. This is important as it can prevent
serious damage to the battery.
6. Do not charge battery in a damp or wet location.
Following this rule will reduce the risk of electric
shock.
7. Do not disassemble the battery and avoid
mechanical damage to the battery. Risk of short
circuit and fumes may be emitted. Ensure fresh
air and seek medical assistance in the event of
discomfort.
8. When disposing of battery pack, keep the battery
pack of different electrochemical systems
separate from each other.
Vibration and noise reduction
To reduce the impact of noise and vibration
Safety information

TTI931BVC
13
Getting started...
EN
emission, limit the time of operation, use low-
vibration and low-noise operating modes as well as
wear personal protective equipment.
Take the following points into account to minimise the
vibration and noise exposure risks:
1. Only use the product as intended by its design and
these instructions.
2. Ensure that the product is in good condition and well
maintained.
3. Use correct attachments for the product and ensure
they are in good condition.
4. Keep tight grip on the handles/grip surface.
5. Maintain this product in accordance with these
instructions and keep it well lubricated (where
appropriate).
6. Plan your work schedule to spread any high vibration
tool use across a longer period of time.
7. Prolonged use of the product exposes the user
to vibrations that can cause a range of conditions
collectively known as hand-arm vibration syndrome
(HAVS) e.g. ngers going white; as well as specic
diseases such as carpal tunnel syndrome. To reduce
this risk when using the product, always wear
protective gloves and keep your hands warm.
Emergency
Familiarise yourself with the use of this product
by means of this instruction manual. Memorise the
safety directions and follow them to the letter. This
will help to prevent risks and hazards.
1. Always be alert when using this product, so that
Safety information

14
Getting started...
EN TTI931BVC
you can recognise and handle risks early. Fast
intervention can prevent serious injury and damage
to property.
2. Switch the product off and remove the battery
pack if there are malfunctions. Have the product
checked by a qualied professional and repaired, if
necessary, before you operate it again.
Residual risks
Even if you are operating this product in accordance
with all the safety requirements, potential risks of
injury and damage remain. The following dangers
can arise in connection with the structure and
design of this product:
1. Health defects resulting from vibration emission if the
product is being used over long periods of time or not
adequately managed and properly maintained.
2. Injuries and damage to property due to broken
attachments or the sudden impact of hidden objects
during use.
3. Danger of injury and property damage caused by
ying objects.
WARNING! This product produces an
electromagnetic eld during operation! This eld
may under some circumstances interfere with
active or passive medical implants! To reduce
the risk of serious or fatal injury, we recommend
persons with medical implants to consult their
doctor and the medical implant manufacturer
before operating this product!
Safety information

TTI931BVC
15
Getting started...
EN
Symbols
On the product, the rating label and within these instructions you will nd
among others the following symbols and abbreviations. Familiarise yourself
with them to reduce hazards like personal injuries and damage to property.
VVolt, (direct current voltage) mAh Milliampere per hour
/min or min-1 Per minute °C Degree Celsius
g Gram kg Kilogram
mm Millimetre m Metre
cm Centimetre m/s² Metres per second squared
dB(A) Decibel (A-rated) Lock / to tighten or secure.
Read the instruction manual.
Unlock / to loosen.
Note / Remark.
Caution / Warning.
xxWyy Manufacturing date code; year of manufacturing (20xx) and
week of manufacturing (Wyy)
Wear hearing protection.
Wear eye protection.
Wear a dust mask.
Wear face protection.
Wear protective gloves.
Wear protective, slip-resistant footwear.
Wear tight-tted protective clothes.
Switch the product off and remove battery pack before assembly,
cleaning, adjustments, maintenance, storage and transportation.
This product is of protection class III.
Do not expose the product to rain or wet conditions (moisture).
Safety information

16
Getting started...
EN TTI931BVC
Keep bystanders away!
Objects thrown by the product could hit the user or other
bystanders. Always ensure that other people and pets remain
at a safe distance from the product when it is in operation.
In general, children must not come near the area where the
product is.
Danger of rotating parts. Keep hands away from blowing device!
Danger of injuries.
Guaranteed sound power level value in 101 dB.
WEEE symbol. Waste electrical products should not be disposed
of with household waste. Please recycle where facilities exist.
Check with your Local Authority or local store for recycling
advice.
Crossed out dust bin. Batteries and battery packs should not
be disposed of with household waste. Please recycle where
facilities exist. Check with your Local Authority or local store for
recycling advice.
Do not dispose of battery packs in rivers or immerse in water.
Do not dispose of battery packs in re. They will explode and
cause injury.
max.40oC
Do note expose battery packs to heat in excess of 40 ºC.
Do not charge or store the battery pack in temperatures below 5
°C (41 °F) and above 40 °C (104°F).
The product complies with the applicable European directives
and an evaluation method of conformity for these directives was
done.
UK Conformity Assessed.
Safety information

TTI931BVC
17
Getting started...
EN
Your product
Your product
1
2
34
5
6
7
8
9
10
11
12
12b
12c 12a
1a
13
1. Air tube
a.Nozzle
b.Spigot*
2. Air outlet
a.Sliding slots*
3. Locking lever
4. On/off switch
5. Handle
6. Battery docking port
7. Air inlet
8. Rear support
9. Hanging hole
10. Front support
11. Clamp lever
12. Battery pack
a.Battery capacity button
b.Release button
c.Battery capacity indicators
13. Charger
NOTE: Parts marked with * are not shown in this overview. Please
refer to the respective part in the instruction manual.

18
Getting started...
EN TTI931BVC
Unpacking
1. Unpack all parts and lay them on a at, stable surface.
2. Remove all packing materials and shipping devices if applicable.
3. Make sure the delivery contents are complete and free of any damage. If
you nd that parts are missing or show damage do not use the product but
contact your dealer. Using an incomplete or damaged product represents a
hazard to people and property.
4. Ensure that you have all the accessories and tools needed for assembly
and operation. This also includes suitable personal protective equipment.
WARNING! The product and the packaging are not children’s toys!
Children must not play with plastic bags, sheets and small parts!
There is a danger of choking and suffocation!
You will need
(items not supplied)
Suitable personal protective equipment
Suitable hanging screw
(items supplied)
Battery pack (12)
Charger (13) and its manual
Setup
WARNING! The product must be fully assembled before operation!
Do not use a product that is only partly assembled or assembled
with damaged parts!
Follow the assembly instructions step-by-step and use the pictures
provided as a visual guide to easily assemble the product!
Before using the product, familiarise yourself with the operating
features read the entire instruction manual paying particular
attention to the safety rules and operating procedures.
Do not connect the product to battery pack (12) before it is
completely assembled!
Tube assembly
1. Align the spigot (1b) with the sliding slots (2a) onto the air outlet (2), then
insert the air tube (1) into the air outlet (2) all the way until an audible click
is heard (Fig. 1).
2. Pull the air tube (1) to verify that it is securely locked by the clamp lever (11).
Before you start

TTI931BVC
19
Getting started...
EN
Before you start
1
2a
1b
2
11
Fig. 1
Battery pack
Attaching / releasing the battery pack
1. Align the battery pack (12) with the sliding slots of the battery docking port (6)
and slide the battery pack (12) in to attach it. Ensure it clicks in place (Fig. 2).
2. Press the release button (12b) and remove the battery pack (12) from the
battery docking port (6) (Fig. 3).
6
12
6
12b
12
2.
1.
Fig. 2 Fig.3
Charging the battery pack
The battery pack (12) for this product has been shipped in a low charge
condition. Charge it fully before rst use.
Refer to the charger’s instruction manual (MC18) for the details.
Battery capacity indicators
The battery pack (12) is equipped with the battery capacity indicators (12c)
which are used to give an indication of the battery pack’s remaining capacity.
Press the battery capacity button (12a) to check battery capacity (Fig. 4). The
LEDs will stay lit for approximately 5 seconds.
12c
12a
12 76~100%
51~75%
26~50%
5~25%
Fig. 4

In more detail...
EN TTI931BVC
20
In more
detail...
Product functions 21
Operation 22
Care and maintenance 24
Troubleshooting 27
Recycling and disposal 28
Guarantee 29
Customer Care and Technical Helpline 31
Availability of Spare Parts 32
Technical specications 33
Declaration of conformity 35
