1050W PERCUSSION DRILL TTB085DRL
SAFETY AND OPERATING MANUAL

1050W PERCUSSION DRILL TTB085DRL
GUARANTEE
This product carries a guarantee of 12 months. If your product develops a fault
within this period, you should,in the first instance contact the retailer where the item
was purchased.
This guarantee specifically excludes losses caused due to:
- Fair wear and tear
- Misuse or abuse
- Lack of routine maintenance
- Failure of consumable items (such as batteries)
- Accidental damage
- Cosmetic damage
- Failure to follow manufacturer’s guidelines
- Loss of use of the goods
This guarantee does not affect your statutory rights. This guarantee is only valid in the
UK.
For further technical advice, spare parts or repair service (outside of guarantee) please
contact the customer helpline number on 0845 607 6380
Congratulations on your purchase of a power tool from Titan Power
Tools (UK) Ltd. We want you to continue getting the best performance from
it so this handbook includes information on safety, handling and care. Please
retain this handbook in case you need to refer to any of the information in
the future.
Your power tool comes with a 12-month guarantee,so should it develop
a fault within this period contact your retailer.

1050W PERCUSSION DRILL TTB085DRL
SAFETY INSTRUCTIONS
WARNING! Read all instructions. Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury.
SAVE THESE INSTRUCTIONS
1. Work area.
a. Keep work area clean and well lit. Cluttered and dark areas invite
accidents.
b. Do not operate power tools in explosive atmospheres, such as in the
presence of flammable liquids, gases or dust. Power tools create sparks
which may ignite the dust or fumes.
c. Keep children and bystanders away while operating a power tool.
Distractions can cause you to lose control.
2. Electrical safety.
a. Power tool plugs must match the outlet. Never modify the plug in
any way. Do not use any adapter plugs with earthed (grounded) power
tools. Unmodified plugs and matching outlets will reduce risk of electric shock.
b. Avoid body contact with earthed or grounded surfaces such as pipes,
radiators, ranges and refrigerators. There is an increased risk of electric
shock if your body is earthed or grounded.
c. Do not expose power tools to rain or wet conditions. Water entering a
power tool will increase the risk of electric shock.
d. Do not abuse the cord. Never use the cord for carrying, pulling or
unplugging the power tool. Keep cord away from heat,oil,sharp edges or
moving parts. Damaged or entangled cords increase the risk of electric shock.
e. When operating a power tool outdoors, use an extension cord suitable
for outdoor use. Use of a cord suitable for outdoor use reduces the risk of
electric shock.
f. Use a Residual Circuit Breaker on all 230V Power tools. This can help
minimise the risk of an electrical shock if an earth fault or short circuits occurs.
g. If using a power cable extension ensure that the cable is fully unwound
and that its length is less than 30m. Lengths over 30 m will effect the tools
performance as a result of voltage drop.
3. Personal safety.
a. Stay alert, watch what you are doing and use common sense when
operating a power tool. Do not use a power tool while you are tired
or under the influence of drugs, alcohol or medication. A moment of
inattention while operating power tools may result in serious personal injury.
b. Use safety equipment. Always wear eye protection. Safety equipment
such as dust mask, non-skid safety shoes, hard hat, or hearing protection used
for appropriate conditions will reduce personal injuries.
c. Avoid accidental starting. Ensure the switch is in the off-position
before plugging in. Carrying power tools with your finger on the switch or
plugging in power tools that have the switch on invites accidents.
d. Remove any adjusting key or wrench before turning the power tool
on. A wrench or a key left attached to a rotating part of the power tool may result
in personal injury.
e. Do not overreach. Keep proper footing and balance at all times. This
enables better control of the power tool in unexpected situations.
f. Dress properly. Do not wear loose clothing or jewellery. Keep your
hair, clothing and gloves away from moving parts. Loose clothes, jewellery
or long hair can be caught in moving parts.
g. If devices are provided for the connection of dust extraction and
collection facilities, ensure these are connected and properly used. Use
of these devices can reduce dust-related hazards.
4. Power tool use and care.
a. Do not force the power tool. Use the correct power tool for your
application. The correct power tool will do the job better and safer at the rate for
which it was designed.
b. Do not use the power tool if the switch does not turn it on and off.
Any power tool that cannot be controlled with the switch is dangerous and must
be repaired.
c. Disconnect the plug from the power source before making any
adjustments, changing accessories, or storing power tools. Such
preventive safety measures reduce the risk of starting the power tool accidentally.
d. Store idle power tools out of the reach of children and do not allow
persons unfamiliar with the power tool or these instructions to operate
the power tool. Power tools are dangerous in the hands of untrained users.
e. Maintain power tools. Check for misalignment or binding of moving
parts, breakage of parts and any other condition that may affect the
power tools operation. If damaged, have the power tool repaired before
use.
f. Keep cutting tools sharp and clean. Properly maintained cutting tools with
sharp cutting edges are less likely to bind and are easier to control.
g. Use the power tool, accessories and tool bits etc., in accordance with
these instructions and in the manner intended for the particular type of
power tool, taking into account the working conditions and the work to
be performed. Use of the power tool for operations different from intended could
result in a hazardous situation.
5. Service.
a. Have your power tool serviced by a qualified repair person using only
identical replacement parts. This will ensure that the safety of the power tool
is maintained.
HEALTH ADVICE
WARNING! When drilling, sanding, sawing or grinding, dust particles will be
produced. In some instances, depending on the materials you are working with,
this dust can be particularly harmful to you (e.g. lead from old gloss paint).
You are advised to consider the risks associated with the materials you are
workingwith and to reduce the risk of exposure. You should:
-- Work in a well-ventilated area.
-Work with approved safety equipment, such as those dust masks that are specially
designed to filter microscopic particles.

1050W PERCUSSION DRILL TTB085DRL
VIBRATION
The European Physical Agents (Vibration) Directive has been brought in to help
reduce hand arm vibration syndrome injuries to power tool users. The directive
requires power tool manufacturers and suppliers to provide indicative vibration test
results to enable users to make informed decisions as to the period of time a power
tool can be used safely on a daily basis and the choice of tool.
Further Advice can be found at www.hse.gov.uk
Vibration total values (triax vector sum) determined according to EN 60745:
Work mode description 1
(Vibration for Drill )
Vibration emission value ah = 3.11m/s²
Uncertainty K = 1.5m/s²
Work mode description 2
(Vibration for Impact Drilling)
Vibration emission value ah = 17.36m/s²
Uncertainty K = 1.5m/s²
The declared vibration emission value should be used as a minimum level should be
used with the current guidance on vibration.
Calculating the actual period of the actual period off use can be difficult and the HSE
website has further information.
The declared vibration emission been measured in accordance with a standardised
test stated above and may be used to compare one tool with another
The declared vibration emission value may also be used in a preliminary
assessment of exposure.
Warning: The vibration emission value during actual use of the power tool
can differ from the declared value depending on the ways in which the tool is
used dependant on the following examples and other variations on how the tool is
used:-
How the tool is used and the materials being cut or drilled.
The tool being in good condition and well maintained
The use the correct accessory for the tool and ensuring it is sharp and in good
condition.
The tightness of the grip on the handles.
And the tool is being used as intended by its design and these instructions.
This tool may cause hand-arm vibration syndrome if its use is not adequate-
ly managed
Warning: identify safety measures to protect the operator that are based on
an estimation of exposure in the actual conditions of use (taking account of
all parts of the operating cycle such as the times when the tool is switched off and
when it is running idle in addition to the trigger time).Note The use of other tools will
reduce the users’ total working period on this tool.
ADDITIONAL SAFETY INSTRUCTIONS FOR YOUR HAMMER DRILL
1. Always wear ear protectors with impact drill. Exposure to noise can cause hearing
loss.
2. Always wear eye protectors when using this impact drill.
3. Always use the auxiliary handles supplied with the tool. Loss of control can cause
personal injury.
4. Always check walls and ceiling to avoid hidden power cables and pipes. A metal
detector can be obtained from any good DIY store for this purpose.
5. Do not start the drill with the chuck key in chuck.
6. Make sure the power switch is not “on” before you plug in. Always switch off before
you put your drill down.
7. Hold your impact drill firmly in both hands.
8. Make sure drill bits are tightened securely in chuck.
9. Do not use damaged or worn drill bits.
10. Use clamps or a vice to hold workpiece, if possible.
11. Always use the appropriate safety equipment that is required for the product. e.g.
Goggles / Safety Spectacles, Ear defenders (essential with tools with a noise rating of
over 85 dBA), Gloves and face masks. In all cases ensure that the safety equipment is
in good condition.
12.Ensure that if a side handle or auxiliary handle is provided with the power tool then
this is adjusted into a comfortable position and that both handles are used to securely
grip the power tool when in use. Side or auxiliary handle must be fitted and used.
13.The Front and rear handle must be firmly held to resist any movement of the drill
when the drill or drill bit becomes jammed.
14. ALWAYS use this drill when standing on a firm and secure platform or the
ground.(DO NOT USE ON LADDERS OR STEPS)
15. NEVER Start the Drill with the drill jammed in position.
16. DO NOT stretch to hold the drill. Do not drill above shoulder height or below Knee
height, as the drill cannot be securely held.
17. This unit is not suitable for use with TCT Core Drill bits and Diamond Core drill bits
and diamond drill bits.

1050W PERCUSSION DRILL TTB085DRL
1. DEPTH GAUGE
2. CHUCK
3. TWO SPEED GEARBOX SELECTOR
4. DRILL/IMPACT ACTION SELECTOR SWITCH
5. SWITCH LOCK-ON BUTTON
6. ON/OFF SWITCH
7. VARIABLE SPEED CONTROL
8. FORWARD/REVERSE SELECTOR SWITCH
9. CHUCK KEY
10. AUXILIARY HANDLE
Helping to minimise your vibration exposure risk.
ALWAYS use sharp chisels, drills and blades
Maintain this tool in accordance with these instructions and keep well lubricated
(where appropriate)
Avoid using tools in temperatures of 10C or less
Plan your work schedule to spread any high vibration tool use across a number of
days.
Health Surveillance
All employees should be part of an employer’s health surveillance scheme to help
identity any vibration related diseases at an early stage, prevent disease progression
and help employees stay in work.
SYMBOLS
Read the manual Double insulation Warning
Wear dust mask,eye & ear protection WEEE marking

1050W PERCUSSION DRILL TTB085DRL
TECHNICAL DATA
Rated Voltage
Rated power
No load speed
Impact rate
Drilling capacity
Steel
Masonry
Wood
Protection class
Weight
ACCESSORIES
auxiliary handle: 1pc
depth gauge: 1pc
chuck key: 1pc
230 V~ 50 Hz
1050 W
0-1100 / 0-3000 min-1
0-17600 / 0-48000 min-1
13 mm
16 mm
32 mm
/II
3 kg
OPERATION INSTRUCTIONS
NOTE: Before using the tool, read
the instruction book carefully.
1. Installing the auxiliary handle (see A)
Slide the handle onto the drill and rotate to the
desired working position. To clamp the auxiliary
handle rotate the handgrip clockwise. To loosen
the auxiliary handle rotate the handgrip anti-
clockwise. Always use the auxiliary handle.
2. Installing the depth gauge (see B)
The depth gauge can be used to set a constant
depth to drill. To use the depth gauge, loosen the
handle by rotating the bottom section of handle
anti-clockwise. Insert the depth gauge through
hole in handle. Slide the depth gauge to required
depth and tighten fully.
3. Mounting a tool into chuck (see C)
When mounting the drill bit, insert bit between
the chuck jaws as far as it will go. Ensure drill
bit is in the center of the chuck jaws. Using the
chuck key provided, there are three holes in which
the chuck key should be inserted. Tighten them
equally in turn at each of the three holes, not
just at one hole. Your drill bit is now locked in the
chuck. The bit can be removed by reversing the
above procedure.
WARNING: Before installing accessory,
remove plug from power supply. Do
not attempt to tighten drill bits (or any other
accessory) by gripping the front part of the chuck
and turning the tool on. Damage to the chuck
and personal injury may result.Always check
chuck key has been removed before plugging in
and starting the drill
4. Operating the On/Off switch (see D)
ON/OFF SWITCH
Depress the switch to start the tool and release it
to stop your tool.
SWITCH LOCK-ON BUTTON
Depress on/off switch then lock-on button, release
on/off switch first and lock-on button second. Your
switch is now locked on for continuous use. To
switch off your tool just depress and release the
on/off switch.
Fig A
Fig B
Fig C
Fig D

1050W PERCUSSION DRILL TTB085DRL
5. Variable speed control (see E)
The maximum speed can be altered by turning
the variable speed control. Turn the variable speed
control to “+” to increase and “-” to decrease
speed. Adjust the variable speed control to
increase or decrease the speed according to the
material and accessory to be used (also possible
during no load operation). Low speed will provide
low torque and high speed gives higher torque.
Using the drill at low speed can cause excess
heat , set the speed to maximum and run for 2-3
minutes
6. Forward and reverse rotation control
(see F)
The forward/reverse selector switch located
above the switch trigger, controls the direction of
rotation. Move the selector switch to the left to
operate the drill in forward direction. Move the
selector switch to the right to operate the drill in
reverse direction.
Note: Never move the forward/reverse
switch whilst the drill is in operation or the
on/off switch is locked as this will damage
the drill.
7. Drill/Impact action switch (see G)
When drilling masonry and concrete,rotate the
drill/impact action selector switch to the hammer
position “ ”. When drilling wood, metal, plastic,
rotate the switch to the drill position. “ ”.
8. Two speed gearbox selector (see H)
Choose position I for high torque/low speed
range for large diameter drill bits and screw
driving. Choose position II for low torque/ High-
speed range for small diameter drill bits. If the
gears do not engage easily then rotate the chuck
by hand to align the gears. Never change the
gears when the tool is rotating, wait until it has
stopped.
Fig E
Fig F
Fig G
Fig H
WORKING HINTS FOR YOUR DRILL
1 Drilling masonry and concrete
Select the drill/impact action selector switch to
the “hammer symbol” position. Tungsten carbide
drill bits should always be used for drilling
masonry, concrete etc with a high speed.
2 Drilling steel
Select the drill/impact action selector switch to
the “drill symbol” position. HSS drill bits should
always be used for drilling steel with a lower
speed.
3 Pilot holes
When drilling a large hole in tough material (i.e.
steel), we recommend drilling a small pilot hole
first before using a large drill bit.
4 Drilling tiles
Select the drill/impact action selector switch to
the “drill symbol” position to drill the tile. When
tile has been penetrated, switch over to “hammer
symbol” position.
5 Cool the motor
If your power tool becomes too hot, set the speed
to maximum and run no load for 2-3 minutes to
cool the motor.
MAINTENANCE
Remove the plug from the socket before
carrying out any adjustment, servicing or
maintenance.
Your power tool requires no additional
lubrication or maintenance.
There are no user serviceable parts in your
power tool. Never use water or chemical cleaners
to clean your power tool. Wipe clean with a dry
cloth. Always store your power tool in a dry place.
Keep the motor ventilation slots clean. Keep all
working controls free of dust. Occasionally you
may see sparks through the ventilation slots. This
is normal and will not damage your power tool.
If the supply cord is damaged, it must be replaced
by the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.

1050W PERCUSSION DRILL TTB085DRL
TROUBLESHOOTING
If your power tool does not start, check the plug
on the power supply first.
If your power tool use in low efficiency, check the
tool speed and type of accessory.
If a fault can not be rectified, return the tool to an
authorised dealer for repair.
ENVIRONMENTAL PROTECTION
Waste electrical products should not be
disposed of with household waste. Please
recycle where facilities exist. For further
information visit www.recycle-more.co.uk
PLUG REPLACEMENT
The fuse in the main plug on the charger should
always be replaced with one of identical rating.
Check the voltage given on the charger matches
the supply voltage.
The fast charger include with you drill is supplied
with a fitted plug, however if you should need to
fit a new plug follow the instruction below.
IMPORTANT
The wire in the mains lead are coloured in
accordance with the following code:
Blue ---Neutral
Brown ---Live
The wire that is coloured blue must be connected
to the terminal that is marked with the letter N .The
wire that is coloured brown must be connected
to the terminal that is marked with the letter L .
If a 13AMP (BS1363 or BS1363/A) plug is used, a
13 AMP fuse must be fitted, or if any other type of
plug is used a 13 AMP fuse must be fitted.
13 AMP
FUSE
BROWN
L (LIVE)
BLUE
N (NEUTRAL)
OUTER
SLEEVE CABLE GRIP

1050W PERCUSSION DRILL TTB085DRL
Declaration of Conformity
We, Importer
Titan Power Tools (UK) Ltd
BA22 8RT
Declare that the product
PERCUSSION DRILL
TTB085DRL
Complies with the following Directives,
Machinery Directive 98/37/EC
Low Voltage Directive 2006/95/EC
Electromagnetic Compatibility Directive 2004/108/EC
Restrictions of the Use of Certain Hazardous Substances in Electrical and Electronic Equipment 2002/95/EC
Standards and technical specifications referred to:
EN 55014-1:2006
EN 55014-2:1997+A1:2001
EN 61000-3-2:2006
EN 61000-3-3:1995+A1:2001+A2:2005
EN 60745-1:2006
EN 60745-2-1:2003+A1+A11:2007
2008
Authorised Signatory
Date: 01/03/08
Signature:
Name: Peter Harries
Titan Power Tools (UK)Ltd
Quality Manager

1050W PERCUSSION DRILL TTB085DRL
