Titan TTB521GRB User manual

Original instructions : MNL_TTB521GRB_V1
400W Bench Grinder
TTB521GRB
Barcode: 5052931248193
WARNING! Read the instructions before using the product!

02 03
TTB521GRB by TITAN
Let’s
These instructions are for your safety. Please read through them thoroughly
before use and retain them for future reference.
Getting started...
In more detail...
Your product
Technical and legal information
Before you start
Care and maintenance
Trouble shooting
EC declaration of conformity
get started...
03
04
06
14
Operation 15
18
21
Recycling and disposal 21
22
GB
IE
11
Congratulations on your purchase of a TITAN power tool from
TITAN Power Tools (UK) Ltd. We want you to continue getting the
best performance from it so this handbook includes information
on safety, handling and care. Please retain this handbook in case
you need to refer to any of the information in the future.
Your TITAN power tool comes with a 2 year guarantee, so should
it develop a fault within this period contact your retailer.
This TITAN product carries a 2 year guarantee. Ifyour product develops a fault within this
period, you should, in the first instance contact the retailer where the item was purchased.
This guarantee specifically excludes losses caused due to:
- Fair wear and tear
- Misuse or abuse
- Lack of routine maintenance
- Failure of consumable items (such as batteries)
- Accidental damage
- Cosmetic damage
- Failure to follow manufacturer’s guidelines
- Loss of use of the goods
This guarantee does not affect your statutory rights. This guarantee is only valid in the UK.
GUARANTEE

04 05
TTB521GRB by TITAN TTB521GRB by TITAN Technical and legal
information
Your product
Your product
GB
IE
Getting started...
GB
IE
Getting started...
Technical data
1
1. Grinder assembly
2. Lamp
3. Spark guard
4. Workpiece support
5. Wheel guard securing bolt
6. On/off switch
7. Mounting holes (1 at each corner)
>Voltage :230V-240V ~50Hz
>Rated input :400 W, S2:30min
>Idling speed of grinding disc :2950min-1
>Protection glass : I
>Degree of protection : IP20
>Dimensions grinding disc :Ø200x20xØ16mm
>Coarse wheel grit :#36
>Medium wheel grit :#60
>Weight :11.5kg
Noise data
>Sound power level (LWA*) :89dB(A)
>Uncertainty KpA :3dB
>Noise pressure level (LPA*) :102dB(A)
>Uncertainty KwA :3dB
Vibration level :2.5 m/s2
Uncertainty K :1.5m/s2
W A R N I N G : When using electric tools basic
safety precautions should always be followed to
reduce the risk of fire, electric shock and personal
injury including the following.
Read all these instructions before attempting to
operate this product and save these instructions.
The declared vibration total value has been measured in accordance with a
standard test method and may be used for comparing one tool with another.
The declared vibration total value may also be used in a preliminary assessment
of exposure.WARNING: The vibration emission during actual use of the power
tool can differ from the declared total value depending on the ways in which the
tool is used. The need to identify safety measures and to protect the operator are
based on an estimation of exposure in the actual conditions of use (taking account
of all parts of the operating cycle, such as the times the tool is switched off, when it
is running idle, in addition to trigger time).
Load factor:
A load factor of S2 30 min(temporary duty)means that you may operate the
motor continuously at its nominal power level (250W) for no longer than the
time stipulated on the specifications label (30minutes ON period). If you fail to
observe this time limit the motor will overheat. During the OFF period the motor
will cool again to its starting temperature.
2
3
4
5
6
7

Getting
FR
IE
Getting started...
06 07
GB
IE
GB
IE
Getting started...
Getting started...
TTB521GRB by TITAN TTB521GRB by TITAN
Technical and legal
information Technical and legal
information
Symbols
Read the instruction manual.
Wear respiratory protection.
Warning! Denotes risk of personal injury, loss of life, or damage
to the tool in case of non-observance
Wear protective gloves
The product complies with the applicable European directives
and an evaluation method of conformity for this directives
was done.
yyWxx: Manufacturing date code; year of manufacturing (20yy)
and week of manufacturing (Wxx)
Wear ear protection.
Wear eye protection.
General safety
WARNING: When using electric tools basic safety
precautions should always be followed to reduce the risk
of fire, electric shock and personal injury including the
following. Read all these instructions before attempting
to operate this product and save these instructions.
1Keep work area clear
> Cluttered areas and benches invite injuries.
2 Consider work area environment
> Do not expose tools to rain.
> Do not use tools in damp or wet locations.
> Keep work area well lit.
> Do not use tools in the presence of flammable liquids or gases.
3Guard against electric shock
> Avoid body contact with earthed or grounded surfaces (e.g. pipes, radiators,
ranges, refrigerators).
4Keep other persons away
> Do not let persons, especially children, not involved in the work touch the tool
or the extension cord and keep them away from the work area.
5Store idle tools
> When not in use, tools should be stored in a dry locked-up place, out of reach
of children.
6 Do not force the tool
> It will do the job better and safer at the rate for which it was intended.
7 Use the right tool
> Do not force small tools to do the job of a heavy duty tool. Do not use tools for
purposes not intended; for example do not use circular saws tocut tree limbs
or logs.
8 Dress properly
> Do not wear loose clothing or jewellery, they can be caught in moving parts.
> Non-skid footwear is recommended when working outdoors.
> Wear protective hair covering tocontain long hair.
9 Use protective equipment
> Use safety glasses.
> Use face or dust mask if working operations create.
10 Connect dust extraction equipment
> If the tool is provided for the connection of dust extraction and collecting equipment,
ensure these are connected and properly used.

Getting
FR
IE
Getting started...
08 09
GB
IE
GB
IE
Getting started...
Getting started...
TTB521GRB by TITAN TTB521GRB by TITAN
Technical and legal
information Technical and legal
information
General safety Additional safety
11 Do not abuse the cord
> Never yank the cord to disconnect it from the socket.
> Keep the cord away from heat, oil and sharp edges.
12 Secure work
> Where possible use clamps or a vice to hold the work.
> It is safer than using your hand.
13 Do not over reach
> Keep proper footing and balance at all times.
14 Maintain tools with care
> Keep cutting tools sharp and clean for better and safer performance.
> Follow instruction for lubricating and changing accessories. Inspect tool cords
periodically and if damaged have them repaired by an authorized service facility.
Inspect extension cords periodically and replace if damaged. Keep handles dry,
clean and free from oil and grease.
15 Disconnect tools
> When not in use, before servicing and when changing accessories such as
blades, bits and cutters, disconnect tools from the power supply.
16 Remove adjusting keys and wrenches
> Form the habit of checking to see that keys and adjusting wrenches are removed
from the tool before turning it on.
17 Avoid unintentional starting
> Ensure switch is in "off" position when plugging in.
18 Use outdoor extension leads
> When the tool is used outdoors, use only extension cords intended for outdoor
use and so marked.
19 Stay alert
> Watch what you are doing, use common sense and do not operate the tool when
you are tired.
20 Check damaged parts
> Before further use of tool, it should be carefully checked to determine that it will
operate properly and perform its intended function.
> Check for alignment of moving parts, binding of moving parts, breakage of parts,
mounting and any other conditions that may affect its operation.
> A guard or other part that is damaged should be properly repaired or replaced by
an authorised service centre unless otherwise indicated in this instruction
manual.
> Have defective switches replaced by an authorised service centre.
> Do not use the tool if the switch does not turn it on and off.
21 Warning
> The use of any accessory or attachment other than one recommended in this
instruction manual may present a risk of personal injury.
22 Have your tool repaired by a qualified person
> This electric tool complies with the relevant safety rules. Repairs should only be
carried out by qualified persons using original spare parts, otherwise this may
result in considerable danger to the user.
> Never drape the power cable over the machine bench.
> The machine is to be used only for its prescribed purpose.
> Wear protective clothing. Wear full face protection, eye protection or safety
goggles, in accordance with the job at hand. Where appropriate, wear a dust
mask, ear defenders, protective gloves or special aprons that keep grinding and
material particles away from you.
Protect your eyes from the foreign bodies that fly off during certain applications.
Dust or breathing masks must be used to filter particles generated by the
application.
Hearing loss can be caused by exposure to high intensity noise.
> Always wear a dust mask and safety goggles.
Contact with or breathing in noxious / toxic dust produced by grinding metal that is
finished with lead paint can be dangerous for the user and surrounding people.
> This power tool must not be used for wet grinding. Use for dry grinding only.
Coolant can weaken the bonding strength of the wheel and cause it to fail.
> This bench grinder should only be used when stationary. Secure to a solid, even
surface.
> Do not use any accessories that have not been especially designed and
recommended for this power tool by the manufacturer. Simply because an
accessory can be connected to your power tool does not guarantee it can be used
safely.
> Only use grinding disks whose diameter, thickness and intended use meet the
equirements of this power tool. Incorrectly sized grinding disks may not be
sufficiently screened or controllable. Use of unsuitable grinding disks can result in
danger to the user or damage to the power tool.
> Never touch the spinning grinding disks! Make sure the grinding disks have come
to a complete standstill after turning off before you touch them.
> When you have checked the tool attachment and have attached it, make sure you
and others nearby keep away from the area of the rotating tool attachment and let
the appliance run at the maximum speed for a minute. Most damaged tool
attachments will break off in this test period.
> Make sure bystanders are a safe distance from your work area. Anyone entering
the work area must wear personal protective clothing. Pieces may break off the
work piece or sparks may fly off and can also cause injuries outside the direct
work area.
> Position the power cable clear of the spinning tool attachment. If you lose control
of the appliance,the power cable can be severed or tangled and your hands or
arms may get caught in the spinning tool attachment.
> Do not leave the power tool running when you are not using it. Your clothing can
become entangled when it comes into contact with the spinning tool attachment,
causing the tool attachment to drill into your body.
> Clean the power tool’s air vents regularly. The motor’s fan draws dust into the
housing and the heavy build-up of metal dust can result in electrical hazards.
> Do not use the power tool in the vicinity of flammable materials. Sparks may
cause these materials to ignite.

Getting
FR
IE
Getting started...
10 11
GB
IE
GB
IE
Getting started...
Getting started...
TTB521GRB by TITAN TTB521GRB by TITAN
Technical and legal
information Before you start
Additional safety
> Do not use any tool attachments that require liquid coolants. Use of water or other
liquid coolants can result in electric shock.
> Before starting up the bench grinder for the 1st time, check the grinding wheels
with a sound test. Faultless grinding wheels will make a clear sound when struck
gently with a plastic hammer (or piece of wood). If new grinding discs are attached,
check these also beforehand.
> Always use the protective features and wheel guard fitted to or supplied with this
power tool.The wheel guard and protective features should be attached securely to
the power tool and set so that the maximum safety level can be achieved. The
protective features are there to protect the user from broken pieces and accidental
contact with the grinding disks.
Unpack
You will need
> Unpack all parts and lay them on a flat, stable surface.
> Remove all packing materials and shipping devices if applicable.
> Make sure the delivery contents are complete and free of any
damage. If you find that parts are missing or show damage do not
use the product but contact your dealer. Using an incomplete or
damaged product represents a hazard to people and property.
> Ensure that you have all the accessories and tools needed for
assembly and operation. This also includes proper personal
protective equipment.
Items not supplied Items supplied
1. Protective gloves 1. worepiece support
2. Screwdriver with PH2
head
2. spark guard
3. Mounting nuts, bolts and
washers
WARNING! Do not connect to power supply until assembly
is complete. Failure to comply could result in accidental starting
and possible serious injury.

Getting
FR
IE
Getting started...
12 13
GB
IE
GB
IE
Getting started... Getting started...
Install the spark guard
Mounting the bench grinder
Connection to the power supply
Install the workpiece support
TTB521GRB by TITAN TTB521GRB by TITAN Before you startBefore you start
> To fit the eye shields locate the nut, screw and washers provided through
the slot in the eye shield and hole on the grinding wheel guard and finger
tighten. Position the eye shield so it does not come in to contact with the
grinding wheel. Tighten the nut and screw to secure the eye shield in place.
> The workpiece support (2) must be assembled in such a way that the gap
between grinding disc and workpiece support is max. 3mm.
> The machine is to be assembled firmly on a suitable place. Four holes are
available to fix on a firm and solid base e.g. on a workbench or machine stand.
– Ensure that the mains connection is located not more than approx.
100–150cm from the place of fixation.
– The machine must be easily accessible from front and left side.
> Connect the plug with a suitable socket.
WARNING! Check the voltage! The voltage must comply with the
information on the rating label!
> Your product is now ready to be used.
WARNING! Do not use until the product has been
securely installed to a work bench.
≤5 mm
1
WARNING! The adjustable safety plate (1) of the spark
guard must be assembled in such a way that the gap
between cutting disc and adjustable safety plate is max. 5 m
Max. 3 mm
2

14
GB
IE
15
GB
IE
Getting started...
TTB521GRB by TITAN TTB521GRB by TITAN
In more detail...
Care and maintenance
Trouble shooting
EC declaration of conformity
Operation
Recycling and disposal
GB
IE
In more detail...
GB
IE
In more detail...
Grinding workpiece
Operation
Place the workpiece on the tool rest. Make sure that the workpiece touch
the front wheel without pressing too hard. Use the side of the wheel under any
circumstances.
Do not worry about the large number of sparks emitted during grinding Wear
eye protection and gloves: grinding of ferrous metals sparks and heats the
workpiece.
15
18
21
21
22

16 17
Operation GB
IE
GB
IE
In more detail...
TTB521GRB by TITAN TTB521GRB by TITAN
In more detail...
Care and maintenance
General operation
Grinding wheel replacement
General cleaning
1. Clean the product with a dry cloth. Use a brush for areas that are hard to reach.
2. Check for worn or damaged parts. Replace worn parts as necessary or contact
an authorised service centre for repair before using the product again.
The golden rules of care
1. Keep the product clean. Remove debris from it after each use and before storage.
2. Regular and proper cleaning will help ensure safe use and prolong the life of the
product.
3. Inspect the product before each use for worn and damaged parts. Do not operate
it if you find broken and worn parts.
NOTE: Do not use chemical, alkaline, abrasive or other
aggressive detergents or disinfectants to clean this
product as they might be harmful to its surfaces.
WARNING! Always switch the product off, disconnect it
from power supply and let the product cool down before
performing inspection, maintenance and cleaning work!
WARNING! Only perform repairs and maintenance
work according to these instructions! All further works
must be performed by a qualified specialist!
1. After switching the grinder on, allow it to reach full speed before performing
grinding operation.
2. The eye shields are able to be adjusted and should be positioned to allow the
operator a clear view of the work through the shields.
3. The appropriate adjustments of the tools rests will provide the correct working
angle for efficient grinding. As the diameter of the grinding wheel is subject to
wear. It will be necessary to re-adjust the edge of the grinding wheel.
Fix the grinder to horizontal, stable surface before using. Positing the grinder towards
the front edge of the bench will facilitate the handing of long tools. If possible, leave
space to the left hand side of the machine for easy access to the wet wheel. An
alternative method is to secure the grinder to a sheet of plywood which can then be
clammed to a bench or table to present the grinder in the most convenient position.
Before using the dry wheel ensures that the spark guard (behind the eye shield) is
positioned as close to the surface of the wheel as possible and that the eye shield is
in a position to prevent sparks flying up. It is a sensible precaution to wear safety
spectacles as well when operating a grinding machine.
The dry wheel can be used for grinding profiles or virtually any cutting tool; plane
irons, chisel, gouges, turning tools, drill bits, etc. The aluminum oxide will cut cleanly
and without undue heating of the tip of the tool. However care should be taken not to
grind a tool too hard or for too long in case over-heating occurs.
To renew or change the grinding wheels, follow these series of steps:
1. Switch off the unit and disconnected from the mains supply.
2. Remove the fixing screws(1) on the outside cover(2) and then pull out the
outside cover(2).
3. Remove the nut (3) from the spindle (5) using spanner supplied. The nut on the
right spindle has a right thread; the nut on the left spindle has a left thread.
4. Take out the outer flange (4) from the spindle (5).
5. Place the new wheel onto the spindle. once secured rotate the grinding wheel by
hand to confirm that the wheel moves freely and doesn't contact any surfaces
6. Reassemble the flange, nut, and outside cover.
7. Switch on the machine and let the wheel run with no load for one minute to
check for cracks.

Getting
FR
IE
Getting started...
18 19
GRINDING WHEEL INFORMATION
GB
IE
GB
IE
Getting started...
Getting started...
TTB521GRB by TITAN TTB521GRB by TITAN
Care and maintenance Care and maintenance GB
IE
In more detail...
GB
IE
In more detail...
The following information is a guide only on the different types of grinding wheels
and their uses.
TYPES OF ABRASIVE GRAIN
Grinding wheels are made of four main types of abrasive grain: aluminum oxide,
silicon carbide, CBN (cubic boron nitride) and diamond. In the home workshop you
will probably only use wheels of aluminum oxide or silicon carbide. Both types are
available from your tool stockiest. Grain size is separated into four main categories:
course, medium, fine and very fine. Table 1 shows the breakdown of grain size in
each category. For most work a medium or fine wheel is recommended.
TABLE 1
The four main categories of abrasive grains
CoarseMedium Fine VeryFine
12 46 70 150
14 60 80 180
16 90 220
20 100 240
24 120
30
36
TYPES OF BOND
There are five main kinds of bonding agents namely, ceramic (vitrified), phonetic
resin, rubber, shellac and metal. The abrasive can be bonded with its particles close
together or with spaces between each grain particle. Bond material creates a link
between each grain. The spaces between the grains will determine how dense the
wheel is, large spaces will give an open wheel and smaller spaces will give a close
or dense wheel.
The structure is measured on a scale of 0-14 with 0 being very close and 14 being
very open with wide spacing between the grains.
WHEEL HARDNESS OR GRADE
Grade or hardness is the strength of bonding between the abrasive grains. Wheel
hardness is graded alphabetically, in increasing order of hardness; letters A through
D represent very soft wheels, and letters V through Z represent very hard ones.
Letter K in the illustration below represents a soft to medium wheel.
9A – 46 – K5 – V 22
Kind of
Abrasive
9A
Grain
Size
46
Grade
K
Destiny
5
Bond
Type
V
Manufacturers
Symbol
22
The number shown in the above illustration is an example of a grinding wheel
description. 9A means that the abrasive is aluminum oxide46 means that the
grain size is medium, K means that the wheel is soft, 5 means that the wheel
is dense, V stands for vitrified bonding and 22 is the manufacturer’s symbol.
Wheels supplied with bench grinders are generally “N” on the hardness scale,
which is considered hard. Do not try to sharpen carbide tools, knives, scissors
or high-speed tools (router bits, wood turning tools) with this hard wheel. A
tandard wheel will not cut carbide. If you try, you will only create heat and glaze
over the wheel. Hard wheels will burn router bits and other high-speed tools.
Overheating the tools will destroy their hardness and render them ussels.
Soft wheels give themselves up while grinding. When grinding, only a small
amount of material is removed, and the wheel releases grains a little at a time,
presenting new cutting edges. This releasing activity helps to keep the tool from
heating up and gives a finer grinding result.
Table 2 shows wheel hardness and uses.
Wheel Hardness (Grade) Uses for designated hardness Description of hardness
A B C D
E F G H I J K L
M N O P Q R S T
U
V W X Y Z
Not used very often
Use these soft wheels to sharpen high -speed
-steel tools, such as router bits,drills, and tool bits.
Use these wheels for rough grinding on
soft materials.
This hard grade is used for dressing sticks
to dress grinding wheels.
Not used very often
Very soft
Soft to medium
Medium to hard
Hard
Very hard
TABLE 2
The following table 3 should help you to select the correct grinding wheel for the
job. New bench grinders are supplied with grey wheels. All other types of grinding
wheel are available from your tool stockiest.
TABLE 3
Type of tool
Drill bits
Spade boring bits
Masonry drill bits
Lathe tool bits
Chisels
Router bits
High-speed steel carbide tipped
Rotary lawnmower blade
Scissors & snips
Tool material
High-speed steel
High-speed steel
Cutting edge is carbide
High-speed steel
High-speed steel
High-speed steel
Cutting edge is carbide
Non heat-treated steel
Hard steel (but not file hard)
Recommended wheel type
Aluminum oxide (grey)
Aluminum oxide (grey)
Silicon carbide (green)
Soft aluminum oxide(Pink or white)
Soft aluminum oxide(Pink or white)
Soft aluminum oxide(Pink or white)
Silicon carbide (green)
Aluminum oxide(grey)
Aluminum oxide (Pink or white)

20 21
Care and maintenance
GB
IE
Power cord
If the power cord is damaged, it must be replaced by the manufacturer, its
service agent or similarly qualified persons in order to avoid a safety hazard.
Repair
1. This product does not contain any parts that can be repaired by the
consumer. Contact a qualified specialist to have it checked and repaired.
Storage
1. Clean the product as described above.
2. Store the product and its accessories in a dry, frost-free place.
3. Always store the product in a place that is inaccessible to children. The
ideal storage temperature is between 10 and 30°C.
4. We recommend using the original package for storage or covering the
product with a suitable cloth to protect it against dust.
Transportation
1. Switch the product off and disconnect it from power supply before
transporting it anywhere.
2. Attach transportation guards, if applicable.
3. Protect the product from any heavy impact or strong vibrations which may
occur during transportation in vehicles.
4. Secure the product to prevent it from slipping or falling over.
> No connection is to be made to the Earth terminal of the plug.
> Only fit an approved 13 Amp BS1363/a plug and the correct rated fuse.
> If in doubt, consult a qualified electrician.
> NOTE: If a moulded plug is fitted and has to be removed take great care in
disposing of the plug and severed cable, it must be destroyed to prevent
engaging into a socket.
UK plug
> As the colours of the wire in the mains lead of this appliance may not
correspond with the coloured markings identifying the terminals in your
plug, proceed as follows. The wire, which is coloured blue, must be
connected to the terminal, which is marked with N or coloured black. The
wire, which is coloured brown, must be connected to the terminal, which is
marked L or coloured red.
Trouble shooting
Recycling and disposal
Waste electrical products should not be disposed of with
household waste. Please recycle where facilities exist. Check
with your Local Authority or local store for recycling advice.
Suspected malfunctions are often due to causes that the user can fix
themselves. Therefore check the product using this section. In most cases the
problem can be solved quickly.
WARNING! Only perform the steps described within
these instructions! All further inspection, maintenance
and repair work must be performed by an authorised
service centre or a similarly qualified specialist if you
cannot solve the problem yourself!
Problem Possible cause Solution
1. Product does
not start
1.1 Not connected to
power supply
1.2 Power cord or plug
is defective
1.3 Other electrical
defect to the product
1.1. Connect to power
supply
1.2. Check by a specialist
electrician.
1.3. Check by a specialist
electrician
2. Product does not
reach full power
2.1 Extension cord not
suitable for operation
with this product
2.2 Power source (e.g.
generator) has too low
voltage
2.1. Use a proper
extension cord
2.2. Connect to another
power source
3. Unsatisfactory
result
3.1 Accessory not
suitable for work piece
material
3.1. Use proper accessory
Trouble shooting
TTB521GRB by TITAN
TTB521GRB by TITAN

FR
2322
FR
détail...
Plus en détail... Plus en détail...
GB
IE
In more detail...
FR
Et dans le détail...
GB
IE
In more detail...
GB
IE
In more detail...
FR
Et dans le détail...
GB
IE
In more detail...
TTB521GRB by TITAN EC declaration of
conformity
Declaration of conformity
Signature:_________________
Authorised Signatory and technical file holder
Date : 05/09/2013
We, Importer
Declare that the product:
Designation: 400w Bench Grinder
Model: TTB521GRB
Complies with the following Directives
2004/108/EC Electromagnetic Compantibility Directive
2006/42/EC Machinery Directive
2006/95/EC Low voltage Directive
2011/65/EU Restrictions of the Use of Certain Hazardous Substances
in Electrical and Electronic Equipment
2002/96/EC and 2003/108/EC Waste Electrical and Electronic Equipment(WEEE)
Standards and technical specifications referred to:
EN61029-1/A11:2010
EN61029-2-4:2011
EN55014-1/A2:2011
EN55014-2/A2:2008
EN61000-3-2/A2:2009
EN61000-3-3:2008
2013
Titan Power Tools (UK) Ltd.
Trade House, Mead Avenue, BA22 8RT
Name / title: Peter Harries / Quality Manager
Titan Power Tools (UK) Ltd. Trade House, Mead Avenue, BA22 8RT

GB-IE
Powersmith (UK) LTD.
Trade House Mead Avenue, BA22 8RT
