Titan 3515 Guide

Titan Implement, LLC 3 3515 Flex-Wing Rotary Cutter
[phone] February 2020
Pre-Delivery Checklist
The Dealer should inform the Purchaser of this product of the Warranty terms, provisions, and procedures that are
applicable. The Dealer and Purchaser should review the contents of the Operation and Parts Manual including
safety equipment, safe operation and maintenance, review the Safety Signs on the implement (and tractor if
necessary), and the Purchaser’s responsibility to train their operators in correct operating procedures.
• IMPLEMENTS: I have explained that Deectors, Guards, or Shields must be installed and maintained in good
repair.
• I have explained that it is not possible to guard against thrown objects when the cutter is lifted o󰀨 the ground,
and that the operator is responsible for watching out for persons in the work area.
• DRIVELINES: I have made certain that all driveline, gearbox, and other shields are in good repair and
fastened securely in place to prevent injuries from entanglement or thrown objects.
PRE-DELIVERY SERVICE
CHECK AND ADJUST OR LUBRICATE AS REQUIRED
See Operation and Parts Manual for Details
Inspection Performed - Warranty and Safety Procedures Explained - Installation Complete
LUBRICATION & HYDRAULICS
 Gearbox Lubricant Level, Factory Filled
 Make Sure Hydraulic Cylinders are Properly
Charged and Purged
 Grease All Zerks
CUTTER
Make Sure that Slip Clutches Operate Properly
 Make Sure the Gearbox Bolts are Properly Tightened
 Make Sure that Blade Carrier Bolts are Properly
Tightened and Cotter Pins are in Place
 Make Sure that Blades are Installed in Correct
Rotational Direction
 Make Sure that All Hardware is Properly Tightened
 Review Procedure to Adjust Cutting Height and Level
ATTACHMENTS & INSTALLATION
Make Sure the Chain Shielding is Attached
 Make Sure All Bolts, Pins, and Nuts Are Properly
Installed and Tightened
I have thoroughly instructed the buyer on the above-described equipment. This review included the Operation and
Parts Manual content, equipment care, adjustments, safe operation, and applicable warranty policy.
Date__________________ Dealer Rep. Signature_________________________________________
The above equipment and Operation and Parts Manual have been received by me, and I have been thoroughly
instructed as to care, adjustments, safe operation, and applicable warranty policy.
Date__________________ Owner’s Signature_________________________________________
CUTTER TO TRACTOR CONNECTIONS
 Make Sure Hitch Pin and Clevis are Properly
Installed
 Complete All Pre-Operation Checks. Refer to “6.7
Pre-Operation Checklist” on page 37
SAFETY ITEMS
 Make Sure Protective Shields are Properly Installed
 Make Sure Safety Decals are Installed
 Review Operation and Parts Manual (Supplied)
 Make Sure Tractor PTO Shield is Installed
 Make Sure S.M.V. Sign is Installed if Needed
 Make Sure ADMA Driveline Safety Manual is
Supplied
 Make Sure AEM Mower Safety Manual is Supplied
 AEM Mower Safety Video has Been Shown to
Purchaser
Cut Here to Remove Page or Make Copies of This Page

Titan Implement, LLC 5 3515 Flex-Wing Rotary Cutter
[phone] February 2020
Titan Implement Will Provide
One (1) AEM Mower Safety Practices Video
Please Send Me: ____VHS Format – AEM/FEMA Mower Operator Safety Video
____DVD Format – AEM/FEMA Mower Operator Safety Video
____Operation and Parts Manual
____AEM Mower Operator’s Safety Manual
Requester Name:________________________________________Phone:__________________________
Requester Address:______________________________________________________________________
City:________________________________________ State:_______________________
Zip Code:____________________________
Cutter Model:_______________________________ Serial Number:_______________________________
Date Purchased:____________________________ Dealer Salesperson:___________________________
Dealership Name:___________________________ Dealership Location:___________________________
Mail to:
Titan Implement
P.O. Box 649
Decatur, TN 37322
Or Fax to:
[phone]
Or E-mail to:
[email protected]
Cut Here to Remove Page or Make Copies of This Page

Titan Implement, LLC 7 3515 Flex-Wing Rotary Cutter
[phone] February 2020
Table of Contents
1. INTRODUCTION ........................8
1.1 Welcome . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.2 Safe Operation .........................8
1.3 Safety Shields ..........................8
1.4 Specications ..........................9
1.5 Intended Usage .........................9
1.6 Operator Orientation .....................9
1.7 Serial Number Location (Typical) ...........9
1.8 Product Improvements ..................10
1.9 Disposal of Equipment at End of Useful Life ..10
1.10 Unanswered Questions ..................10
2. SAFETY ..............................11
2.1 General ..............................11
2.2 Safety Alert Symbols ....................11
2.3 Safety Icon
Nomenclature .........................12
2.3.1 Personal Protection/
Important Information..............12
2.3.2 Prohibited Actions ................12
2.3.3 Hazard Avoidance ................12
2.4 Training ..............................14
2.5 OSHA Training Requirements .............14
2.6 Federal Laws and Regulations ............15
2.7 Sign-O󰀨 Form .........................16
2.8 Operation Safety .......................17
2.9 Transporting Safety .....................17
2.10 Storage Safety.........................17
2.11 Maintenance Safety.....................17
3. SAFETY SIGNS AND INSTRUCTIONAL
LABELS ..............................18
3.1 General Information.....................18
3.2 How to Install Replacement Safety Signs ....18
3.3 Safety Sign Locations ...................19
3.3.1 Cutter Deck Safety Signs...........20
4. NOMENCLATURE .....................23
4.1 Description and Intended Use .............23
4.1.1 Owner/Operator Manual Storage.....23
4.2 Nomenclature .........................23
5. ASSEMBLY............................24
5.1 Tools Required ........................24
5.2 Assembly Procedure ....................24
5.3 Final Assembly and Leveling..............27
5.3.1 Leveling the Center Deck...........27
5.3.2 Leveling the Wing Decks ...........28
5.4 Checking the Driveline Length ............30
5.5 Shortening the Driveline .................30
6. OPERATION...........................31
6.1 User Safety Training ....................31
6.2 Tractor Requirements ...................32
6.2.1 Equipment and Capabilities .........32
6.2.2 Tractor Safety Devices.............32
6.2.3 ROPS and Seat Belt ..............32
6.2.4 Power Take-O󰀨 (PTO) .............33
6.2.5 Drawbar ........................33
6.3 Attaching to Tractor ....................33
6.4 Setting the Rotary Cutter.................35
6.4.1 Leveling Front-to-Back.............35
6.4.2 Setting the Cutting Height ..........35
6.5 Initial Setup Checklist ...................36
6.6 Machine Break-In ......................37
6.7 Pre-Operation Checklist .................37
6.8 General Operating Procedure .............37
6.9 Chain Shielding ........................38
6.10 Right of Way (Roadway) Mowing ..........39
6.11 Detaching From Tractor .................39
7. TRANSPORTING.......................41
7.1 Transporting Safety (Road) ...............41
7.2 Transporting ..........................42
8. STORAGE.............................43
8.1 Storage Safety.........................43
8.2 Placing In Storage ......................43
8.3 Removing From Storage .................43
9. SERVICE AND MAINTENANCE ..........44
9.1 Maintenance Safety.....................44
9.2 Welding Repairs .......................45
9.3 Greasing .............................46
9.4 Gearbox Lubrication ....................47
9.5 Driveline Lubrication ....................47
9.6 Blade Servicing .......................47
9.6.1 Blade Removal...................47
9.6.2 Blade Installation .................47
9.6.3 Blade Sharpening ................48
9.7 Blade Carrier Removal ..................48
9.8 Blade Carrier Installation .................48
9.9 Slip Clutch Operational Check ............48
9.10 Slip Clutch Adjustment ..................49
9.11 Bolt Torque Requirements................50
9.12 Service Record ........................51
10. TROUBLESHOOTING ..................52
11. WARRANTY ..........................54
12. PARTS ...............................58
12.1 Hitch/Leveling Rods ....................58
12.2 Center Deck ..........................60
12.3 Wing Deck ............................62
12.4 Wheel Lift ............................64
12.5 Hydraulic System ......................66
12.6 Driveline & Shield ......................67
12.7 Splitter Shield .........................68
12.8 540/1000 RPM Splitter Gearbox ...........69
12.9 Outboard Gearbox......................70
12.10.1 540 RPM Driveline....................71
12.10.2 1000 RPM Driveline...................72
12.10.3 Center Deck Driveline . . . . . . . . . . . . . . . . . 73
12.10.4 Wing Deck Driveline ..................74
12.1 Chain Guard ...........................75

3515 Flex-Wing Rotary Cutter 8 Titan Implement, LLC
February 2020 [phone]
1. INTRODUCTION
1.1 Welcome
Titan Implement 3515 Flex-Wing Rotary Cutter
Congratulations on your choice of a Titan Implement
ex-wing rotary cutter. This equipment has been
designed and manufactured to meet the needs of
discerning users.
Many features incorporated into this rotary cutter are
the result of suggestions made by customers like you.
Read this manual carefully to learn how to operate
the rotary cutter safely and how to set it to provide
maximum cutting e󰀩ciency.
By following the operating instructions, in conjunction
with a good maintenance program, your Titan
Implement rotary cutter will provide many years of
trouble-free service.
1.2 Safe Operation
Safe, e󰀩cient, and trouble-free operation of your rotary
cutter requires that you, and anyone else who will be
using or maintaining the unit, read and understand the
information contained within the Owner’s Manual.
Use this manual for frequent reference and to pass on
to new operators or owners.
WARNING
Read And Understand Manual
To prevent personal injury or even death, be
sure you read and understand all of the
instructions in this manual and other related OEM
equipment manuals! The rotary cutter, if not used
and maintained properly, can be dangerous to users
unfamiliar with its operation. Do not allow operating,
maintaining, adjusting, or cleaning of this rotary
cutter until the user has read this manual and has
developed a thorough understanding of the safety
precautions and functions of the unit.
This rotary cutter is designed for the specic
purpose of cutting grass, weeds, and brush. DO NOT
modify or use this rotary cutter for any application
other than that for which it was designed.
Rotary cutters maintained or operated improperly or
by untrained personnel can be dangerous; exposing
the user and/or bystanders to possible serious
injury or death.
1.3 Safety Shields
Some of the illustrations in this manual may show
the equipment with safety shields removed for clarity.
Never operate the rotary cutter unless all safety shields
are in place.
WARNING
Cutting or Entanglement Hazard
Operating the rotary cutter without the
safety shields can result in physical
injury or death. Make sure all shields are properly
installed before operating the rotary cutter. This
equipment should never be operated with any safety
shielding removed.

Titan Implement, LLC 9 3515 Flex-Wing Rotary Cutter
[phone] February 2020
1.4 Specifications
Model 3515
Cutting Width 15'
Cutting Height 2” to 15”
Overall Width 188”
Transport Width 90"
Hitch Swivel Pivot Self
Leveling
Underneath Deck Heavily Braced
Minimum Tractor PTO 60 HP
Deck Thickness 10 Gauge
Side Skirt 1/4” x 13.5”
Approximate Weight 5600 LBS w/ 6 26"
Laminated Tire
Approximate Tongue
Weight
1900 LBS
Blade Tip Speed 17,135 FPM
Blade Overlap 6”
PTO Driveline ASAE Cat 6
Wing Flex 22 degrees down to 100
degrees up
Splitter Gearbox Rating 235 HP
Outboard Gearbox Rating 190 HP
Gearbox Warranty 5 Year Limited
Machine Warranty 1 Year Limited
Cutting Capacity 3.5”
Cutter Suspension
2 Heavy Duty springs
positioned on the center
tail wheel axle
Safety Tow Chain Standard
Chain Guards Standard
Skid Shoes Replaceable
Wheel Options
20” Laminated Tire
26” Laminated Tire
26” Foam Filled Aircraft
Tires
29” Pneumatic Aircraft
Tires
Specications subject to change without notice.
1.5 Intended Usage
Do not use this rotary cutter for any other purpose than
its intended use of cutting grass, weeds, and brush.
1.6 Operator Orientation
The directions left, right, front, and rear, as mentioned
throughout this manual, are as seen from the tractor
operator’s seat and facing in the direction of travel.
1.7 Serial Number Location (Typical)
The serial number decal is located on the left front of
the center deck.
Serial Number ______________________________

3515 Flex-Wing Rotary Cutter 10 Titan Implement, LLC
February 2020 [phone]
1.8 Product Improvements
Because Titan Implement, LLC maintains an ongoing
program of product improvement, we reserve the
right to make improvements in design or changes in
specications without incurring any obligation to install
them on units previously sold.
1.9 Disposal of Equipment at End of Useful
Life
The Titan Implement, LLC rotary cutter has been
designed for the specic purpose of cutting grass,
weeds, and brush. When this unit is no longer
capable of doing its designed purpose, it should be
dismantled and scrapped. Do not use any materials or
components from this unit for any other purpose.
1.10 Unanswered Questions
If you have any questions not answered in this manual,
require additional copies, or the manual is damaged,
please contact your dealer or:
Titan Implement, LLC
P.O. Box 649
232 Industrial Lane
Decatur, TN 37322
Phone: [phone]
Fax: [phone]
The manual is also available for download at:
www.titanimplement.com.
Navigate to the 3515 page for the manual link.

Titan Implement, LLC 11 3515 Flex-Wing Rotary Cutter
[phone] February 2020
2. Safety
2.1 General
Safety of the operator and bystanders is one of the
main concerns in designing and developing a new
piece of equipment. Designers and manufacturers
build in as many safety features as possible. However,
every year many accidents occur which could have
been avoided by a few seconds of thought and a more
careful approach to handling the equipment.
Most work-related accidents are caused by failure to
observe basic safety rules or precautions. An accident
can often be avoided by recognizing potentially
hazardous situations before an accident occurs. As
you assemble, operate, or maintain the rotary cutter
(unit), you must be alert to potential hazards. You
should also have the necessary training, skills,
and tools to perform any assembly or maintenance
procedures.
Improper operation and maintenance of this unit could
result in a dangerous situation that could cause injury
or death.
If you have any questions not answered in this manual
or require additional copies or the manual is damaged,
please contact your dealer or:
Titan Implement, LLC
P.O. Box 649
232 Industrial Lane
Decatur, TN 37322
Phone: [phone]
Fax: [phone]
WARNING
Do not assemble, operate, or maintain the
unit until you read and understand the
information contained in this manual.
Safety precautions and warnings are provided
in this manual and on the unit. If these hazard
warnings are not heeded, bodily injury or
death could occur to you or to other persons.
Titan Implement, LLC cannot anticipate every
possible circumstance that might involve a potential
hazard. The warnings in this manual and on the
unit are, therefore, not all-inclusive. If a method of
assembly, operation, or maintenance not specically
recommended by us is used, you must satisfy yourself
that it is safe for you and for others. You should also
ensure that the unit will not be damaged or be made
unsafe by the methods that you choose.
The information, specications, and illustrations in this
manual are based on the information that was available
at the time this material was written and can change at
any time without notice.
2.2 Safety Alert Symbols
This is the safety alert symbol. It is used to
alert you to potential personal injury hazards.
Obey all safety messages that follow this
symbol to avoid possible injury or death.
This manual contains DANGERS, SAFETY
INSTRUCTIONS, CAUTIONS, IMPORTANT NOTICES,
and NOTES which must be followed to prevent
the possibility of improper service, damage to the
equipment, personal injury, or death. The following key
words call the readers’ attention to potential hazards.
Hazards are identied by the “Safety Alert Symbol”
and followed by a signal word such as “DANGER”,
“WARNING”, or “CAUTION”.
DANGER
Indicates an imminently hazardous situation which,
if not avoided, will result in death or serious injury.
This signal word is limited to the most extreme
situations.
WARNING
Indicates a potentially hazardous situation which, if
not avoided, could result in death or serious injury.
CAUTION
Indicates a potentially hazardous situation which, if
not avoided, may result in minor or moderate injury.
NOTICE
Indicates that equipment or property damage can result
if instructions are not followed.
SAFETY
INSTRUCTIONS
Safety instructions (or equivalent) signs indicate
specic safety-related instructions or procedures.
Note: Contains additional information important to a
procedure.

3515 Flex-Wing Rotary Cutter 12 Titan Implement, LLC
February 2020 [phone]
2.3 Safety Icon
Nomenclature
Pictorial icons signal a type of
hazard and warn of personal
protection issues, prohibited
actions, and hazard avoidance.
2.3.1 Personal Protection/
Important Information
Read the manual
N
I
N G
AR
Damaged hazard label
Eye protection
Fire extinguisher
First aid kit
Hand protection
Head protection
Hearing protection
OEM
OEM parts only
Protective shoes
Remove key
Set parking brake
STOP Stop engine
THINK
SAFETY! Think safety
Transmission in park
Use proper support
Use proper tools
Visibility
Rollover protection
Wear seat belt
Weight rating
Clear vision
2.3.2 Prohibited Actions
Do not alter or modify
Do not leave out tools
Do not weld
No alcohol
No drugs
No smoking
No young children
No riders
2.3.3 Hazard Avoidance
Crush
hazard
Crush hazard (chock
wheels)
Crush hazard (foot)
Defective or broken part
Entanglement hazard
Explosive separation
hazard
Fire hazard
Cutter blade contact
hazard (hand)
Cutter blade contact
hazard (foot)
Pinch point hazard
Projectile hazard
Rollover protection
Safety alert symbol
Safety shields
Sharp object hazard
Slipping injury
Stay clear
0Zero pressure
Tripping injury
High-pressure fluid
hazard
Hose damage
Falling hazard
Crush hazard
Pressure hazard

Titan Implement, LLC 13 3515 Flex-Wing Rotary Cutter
[phone] February 2020
General Safety Instruction
The owner/operator is responsible for the SAFE use
and maintenance of the rotary cutter. Make sure
anyone who is operating, maintaining, or working
around the rotary cutter is familiar with the operating
and maintenance procedures and related SAFETY
information contained in this manual. This manual will
take you step-by-step through your working day and
alerts you to all good safety practices that should be
used while using the rotary cutter.
In addition to the design features of the rotary
cutter, including safety signs, accident prevention is
dependent upon the awareness, concern, prudence,
and proper training of the people involved in the
operation, maintenance, and storage of the rotary
cutter.
In addition to this safety section, refer also to safety
messages and instructions in each of the appropriate
sections of the rotary cutter manual.
These general safety instructions apply to the overall
use and maintenance of the rotary cutter.
More specic instructions on safety are found in the
operation, maintenance, and storage sections of this
manual. Refer to these sections before performing any
of these tasks.
WARNING
Failure to comply with the following safety
instructions can and will result in serious injury and
possibly even death if they are not understood and
followed.
Provide User with Literature
Titan Implement, LLC rotary cutter owners
must provide operator instructions to anyone
using the rotary cutter before use, and at least
annually thereafter. Refer to “2.5 OSHA Training
Requirements” on page 14.
Stay Clear
Clear the area of people, especially small
children, before using the rotary cutter.
Under no circumstances should young children be
allowed to work with or around the rotary cutter.
Impaired User Hazard
Do not attempt to assemble, operate, or
maintain this rotary cutter under the
inuence of drugs or alcohol. Consult your doctor
before using this rotary cutter while taking
prescription medications.
WARNING
Crush Hazard
Do not allow anyone to ride on the
tractor or the rotary cutter. Falling or
crushing hazards can result in severe injuries or
death.
Falling Hazard
Do not allow riders on the hitch,
tractor, or rotary cutter at any time.
Falling can result in severe injuries or death.
No Unauthorized Modications
Do not modify the rotary cutter or safety
devices. Do not weld on the unit.
Unauthorized modications may impair its function
and safety. Personal injury or death can result from
unauthorized modications.
If the rotary cutter has been altered in any way from
the original design, Titan Implement does not accept
any liability for injury or warranty.
Damaged Parts Hazard
Do not use the rotary cutter if any parts are
damaged. If the rotary cutter has a defect,
immediately stop using it and remedy the problem
before continuing.
Thrown Objects Hazard
Rotary cutter can throw objects up to 300
feet. To avoid serious injury or death:
Keep all thrown object shielding in place.
Inspect area for potential thrown objects before
cutting.
Do not operate the rotary cutter with the deck or
wings raised.
Safety Shields
Some illustrations in this manual show the
equipment with safety shields removed to
provide a better view. This equipment should never
be operated with any necessary safety shielding
removed.

3515 Flex-Wing Rotary Cutter 14 Titan Implement, LLC
February 2020 [phone]
CAUTION
The following safety instructions are provided to
help prevent potential injury. Not following these
instructions may lead to injury.
Personal Protection Equipment
When using this rotary cutter, wear appropriate
personal protective equipment. This list may
include, but is not limited to:
• Protective shoes with slip resistant soles
• Protective goggles, glasses, or face shield
• Protective clothing and gloves
• Safety vest (when operating near roads)
• Hearing protection
Ear Protection
Wear suitable ear protection during prolonged
exposure to excessive noise.
Hearing Loss
Prolonged Exposure To Loud Noise May
Cause Permanent Hearing Loss!
Working environments with noise-producing
equipment can cause partial to permanent hearing
loss. We recommend using hearing protection any
time noise levels exceed 80 decibels (dB). Noise
levels over 85 dB, on a long-term basis, can cause
severe hearing loss. Noise levels over 90 dB over a
period of time can cause permanent and even total
hearing loss.
Hearing loss from loud noise is cumulative over a
lifetime without hope of natural recovery.
Crush Hazard
The tractor should be equipped with a
Roll Over Protective Structure (ROPS)
and a seat belt. A crushing hazard can occur if the
driver is ejected from the seat while the tractor is in
motion. Fasten the seat belt whenever the tractor is
moving.
SAFETY
INSTRUCTIONS
The following safety instructions are provided to
help prevent injury or limit equipment damage.
N
I
N G
AR Safety Signs
Replace any missing or hard-to-read safety
signs or instructional labels. Use care when
washing or cleaning the rotary cutter.
Replacement safety sign locations and part numbers
are provided in this manual and are available from
an authorized dealer parts department or the factory.
First Aid Kit
Have a rst aid kit available for use should
the need arise and know how to use it.
Fire Extinguisher
Have a re extinguisher available for use
should the need arise and know how to use it.
THINK
SAFETY! Think SAFETY!
Work SAFELY!
2.4 Training
Anyone who will be using and/or maintaining the
rotary cutter must read, clearly understand, and follow
ALL safety, operation, and maintenance information
presented in this manual, other related OEM manuals,
and the safety signs
If you do not understand any information in this
manual, see your dealer or contact Titan Implement
before proceeding.
Do not use or allow anyone else to use this rotary
cutter until all information has been reviewed. Annually
review this manual before the season start-up.
Make periodic reviews of SAFETY and OPERATION
of the rotary cutter a standard practice. An untrained
operator is not qualied to use this rotary cutter.
2.5 OSHA Training Requirements
The following training requirements have been taken
from Title 29, Code of Federal Regulations Part
1928.57 (a) (6). www.osha.gov.
Operator instructions. At the time of initial assignment
and at least annually thereafter, the employer shall
instruct every employee who operates an agricultural
tractor and implements in the safe operating practices
and servicing of equipment with which they are or will
be involved, and of any other practices dictated by the
work environment.

Titan Implement, LLC 15 3515 Flex-Wing Rotary Cutter
[phone] February 2020
2.6 Federal Laws and Regulations
IMPORTANT FEDERAL LAWS AND REGULATIONS
CONCERNING EMPLOYERS, EMPLOYEES AND OPERATORS
This section is intended to explain in broad terms the concept and e󰀨ect of the following federal laws and
regulations. It is not intended as a legal interpretation of the laws and should not be considered as such.
U.S. PUBLIC LAW 91-596 (The Williams-Steiger Occupational Safety and Health Act of 1970) OSHA
This Act Seeks:
“ ... to assure so far as possible every working man and woman in the nation safe and healthful working conditions and to
preserve our human resources ... “
DUTIES
Sec. 5(a) Each Employer -
(1) shall furnish to each of its employees employment and a place of employment which are free from
recognized hazards that are causing or are likely to cause death or serious physical harm to its
employees.
(2) shall comply with occupational safety and health standards promulgated under this Act.
(b) Each employee shall comply with occupational safety and health standards
and all rules, regulations, and orders issued pursuant to this Act which are
applicable to his or her own actions and conduct.
OSHA Regulations
Current OSHA regulations state in part: “At the time of initial assignment and at least annually thereafter, the
employer shall instruct every employee in the safe operation and servicing of all equipment with which the
employee is, or will be involved.” These will include (but are not limited to) instructions to:
Keep all guards in place when the machine is in operation;
Permit no riders on equipment;
Stop engine, disconnect the power source, and wait for all machine movement to stop before servicing,
adjusting, cleaning, or unclogging the equipment, except where the machine must be running to be
properly serviced or maintained, in which case the employer shall instruct employees as to all steps and
procedures which are necessary to safely service or maintain equipment.
Make sure no one is within 300 feet of machinery before starting the engine, engaging power,
or operating the machine.
EMPLOYEE TRACTOR OPERATING INSTRUCTIONS:
1. Securely fasten your seat belt if the tractor has a ROPS.
2. Where possible, avoid operating the tractor near ditches, embankments, and holes.
3. Reduce speed when turning, crossing slopes, and on rough, slick, or muddy surfaces.
4. Stay o󰀨 slopes too steep for safe operation.
5. Watch where you are going, especially at row ends, on roads, and around trees.
6. Do not permit others to ride.
7. Operate the tractor smoothly - no jerky turns, starts, or stops.
8. Hitch only to the drawbar and hitch points recommended by tractor manufacturers.
9. When tractor is stopped, set brakes securely and use park lock if available.
Child Labor Under 16 Years Old
Some regulations specify that no one under the age of 16 may operate power machinery. It is your responsibility to
know what these regulations are in your own area or situation. (Refer to U.S. Dept. of Labor, Employment Standard
Administration, Wage & Home Division, Child Labor Bulletin #102).

3515 Flex-Wing Rotary Cutter 16 Titan Implement, LLC
February 2020 [phone]
2.7 Sign-Off Form
Titan Implement, LLC follows the general Safety
Standards specied by the Farm Equipment
Manufacturers Association (FEMA), and the American
National Standards Institute (ANSI). Anyone who will
be using and/or maintaining the rotary cutter must
read and clearly understand ALL safety, operation and
maintenance information presented in this manual.
Do not use or allow anyone else to use this rotary
cutter until all information has been reviewed. Annually
review this manual before the season start-up.
Make periodic reviews of SAFETY and OPERATION
of the rotary cutter a standard practice. An untrained
operator is not qualied to use this rotary cutter.
Sign-O󰀨 Form
Date User’s Signature Owner’s Signature
This sign-o󰀨 sheet is provided for your records to
show that all personnel who will be working with the
equipment have read and understand the information
in this Operation and Parts Manual and have been
instructed in the operation of the equipment.

Titan Implement, LLC 17 3515 Flex-Wing Rotary Cutter
[phone] February 2020
2.8 Operation Safety
Refer to “6.1 User Safety Training” on page 31 for
safety recommendations related to using the rotary
cutter. All applicable safety recommendations in other
sections should also be followed.
2.9 Transporting Safety
Refer to “7.1 Transporting Safety (Road)” on page 41
for safety recommendations related to transporting the
rotary cutter. All applicable safety recommendations in
other sections should also be followed.
2.10 Storage Safety
Refer to “8.1 Storage Safety” on page 43 for safety
recommendations related to storing the rotary cutter.
All applicable safety recommendations in other
sections should also be followed.
2.11 Maintenance Safety
Refer to “9.1 Maintenance Safety” on page 44 for
safety recommendations related to maintaining the
rotary cutter. All applicable safety recommendations in
other sections should also be followed.

3515 Flex-Wing Rotary Cutter 18 Titan Implement, LLC
February 2020 [phone]
3. SAFETY SIGNS AND INSTRUCTIONAL LABELS
3.1 General Information
The types of safety signs (hazard labels) and
instructional labels, along with their locations on the
equipment, are shown in the following illustrations.
Good safety practices require that you familiarize
yourself with the various safety signs, the type of
warning, and the area or particular operation related to
that area that requires your SAFETY AWARENESS.
THINK
SAFETY!
Think SAFETY!
Work SAFELY!
Pay close attention to the safety signs and instructional
labels attached to the tractor and the rotary cutter.
Duplicate safety signs, which are attached to the rotary
cutter, can also be found in this section. If the rotary
cutter is missing a label or one is unreadable, replace
the label before using the rotary cutter.
SAFETY
INSTRUCTIONS
N
I
N G
AR
Safety Signs and Instructional Labels
1. Keep safety signs or instructional labels clean
and legible at all times. Use a clean, damp cloth
to clean safety decals.
2. Replace any missing or hard-to-read safety signs
or instructional labels.
3. Use care when washing or cleaning the equipment
not to remove or damage the labels. When using
a pressure washer to clean the rotary cutter, avoid
spraying too close to decals; high-pressure water
can enter through very small scratches or under
edges of decals causing them to peel or come o󰀨.
4. Locations for the labels and replacement part
numbers are shown in this section.
5. Replacement parts must have replacement labels
attached during installation and/or before the
rotary cutter is used.
6. Labels are available from your authorized dealer
or from Titan Implement at no charge.
3.2 How to Install Replacement Safety Signs
1. Clean and dry the installation area.
Note: Do not install the signs if the temperature is
below 50°F.
2. Determine the exact position before you remove the
backing paper.
3. Remove the backing paper.
4. Align the sign over the specied area and carefully
press the sign to the part/frame.
Note: Small air pockets can be pierced with a pin and
smoothed out using the piece of backing paper.

Titan Implement, LLC 19 3515 Flex-Wing Rotary Cutter
[phone] February 2020
3.3 Safety Sign Locations
TI-00352
5
9
3
6
78or
4
1
3
2
11
14 15
10 10
15
14
13
17 12
16
Safety Sign Locations.
Item Type Description Qty.
1DANGER Follow Safety Messages 1
2DANGER Maintain Shields and Deectors 1
3 INSTRUCTIONAL Blade Rotation (CCW) 2
4DANGER Rotating Driveline, Keep Away, Outer Shield Tube 1
5DANGER Shield Missing, Do Not Operate 1
6WARNING Use Paper or Cardboard to Check for Leaks 1
7* WARNING PTO Speed 540 RPM 1
8* WARNING PTO Speed 1000 RPM 1
9WARNING Keep Mower Deck Clear of Debris 1
10 WARNING No Riders 4
11 SERIAL Serial Number 1
12 INSTRUCTIONAL Made In the USA 1
13 INSTRUCTIONAL Blade Rotation (CW) 1
14 DANGER Keep Away - Thrown Objects 2
15 DANGER Stay Clear 2
16 WARNING Do Not Transport at Speeds Over 20 MPH 1
17 INSTRUCTIONAL 5 Year Gearbox Limited Warranty 1
* Use item 7 or 8, as appropriate.

3515 Flex-Wing Rotary Cutter 20 Titan Implement, LLC
February 2020 [phone]
3.3.1 Cutter Deck Safety Signs
1.
TI-00336
2.
TI-00337
3.
TI-00338
4.
TI-00339
5.
TI-00340
