Titan TS142 User manual

Quick Install Guide
www.titaninnovations.cawww.titaninnovations.ca
For Automatic
& Manual Transmission
Vehicles
For Automatic
& Manual Transmission
Vehicles
Advanced LED 2-Way
Remote Car Starter
Advanced LED 2-Way
Remote Car Starter
Revision 2.01Revision 2.01

Action
Operation
Press Button 1 Once
Locks doors and Arms Titan-Secure (If Alarm
features are turned on in Menu M2-3)
Press and Hold Button 1 for 2
Seconds
Remote Panic
Press Button 2 Once
Unlocks doors and Dis-Arms Titan-Secure (If
Alarm features are turned on in Menu M2-3)
Press and Hold Button 2 for 2
Seconds
Trunk Release (Doors will also Unlock)
Press Buttons 1 and 2 Together
Sets silent arming/disarming mode (If Titan-Secure
Alarm features are turned on in Menu M2-3)
Press Button 3 Once
Remote engine Start On/Off (Start / Stop)
Press Button 4 Once, then Push and
Hold Button 3 for 3 Seconds
Remote Timer Start mode On/Off (See Owner’s
Guide for more details)
Press Button 3 Once (with Engine
Running by Key)
Idle Mode (Takeover Mode)
Press Button 4 Once (with Engine
Running by Key)
Turbo Mode (Turbo Cooldown Mode)
Press Button 4 Once, then Push
Button 1 for less than 2 Seconds
Long Aux. Door Lock Function (See Menu M2-6
for options (15 sec, 30 sec, or Latched))
Press and Hold Button 3 for 2
Seconds
Auxiliary Output #1 (See Menu M4-1)
Press and Hold Button 4 for 2
Seconds
Auxiliary Output #2 (See Menu M4-1)
Press Button 5 Once
Indicates vehicle Status (T85RC Only)
TS142 Quick Install Guide
Transmitter Operation T85RC (LED 2-Way)
& T85SRC (Companion Remote)
Button 2
L
Button 1
S rtS rt
Button 3 ar ar
Button 4
Part # T85RC
2-Way LED Transmitter
Part # T85SRC
1-Way Transmitter
ar ar
Button 5

Version 2.01 TS132/TS142/TS152 QIG
TRANSMITTER LEARNING
Important! The remote starter will hold 4 transmitter codes. It is
recommended that when programming in transmitters, you fill up all four
transmitter codes, even if only using one or two transmitters. This will
clear all other transmitter coding from the unit and prevent stray coding
or possible interference from other remote transmitters.
a. Turn ignition ON ±OFF ±ON ±OFF ±ON.
b. Press the valet switch (button) in the antenna and hold on, siren/horn (optional) will
chirp once, the LED will turn on constantly.
c. Keep on holding the valet switch, siren/horn will chirp 5 times to indicate you have
entered transmitter learning mode.
d. Press button 1 (Lock) of every transmitter to be coded. The siren/horn will chirp once
and the parking lights will flash once to indicate successfully learning. If only using
only 2 transmitters, code in each transmitter twice.
e. Up to 4 transmitters can be learned to each unit, each transmitter must be finished in 8
seconds.
f. Turn ignition OFF and the unit will exit code-learning mode. You will hear one long
siren/horn chirp to confirm.
VALET MODE
a. To activate Valet mode, turn ignition ON. Within 10 seconds, press and hold the valet
switch for 5 seconds. Parking lights will flash once and siren/horn will chirp 5 times to
enter VALET mode. LEDs in the antenna will be constantly ON when the ignition is
OFF. When Ignition ON, the LED will turn off.
b. In valet mode, the system can¶t be armed or remote started, however lock and trunk
functions will still operate. If you attempt to start the vehicle in valet mode, the unit
will not start and you will get 3 long flashes from the park lights.
c. To disable valet mode: turn ignition ON. Within 10 seconds press and hold the valet
switch for 5 seconds. LED will turn OFF, siren/horn will chirp and parking lights will
flash twice to indicate exiting valet mode.

Version 2.01 TS132/TS142/TS152 QIG
SYSTEM RESET
a. Turn ignition ON ±OFF ±ON ±OFF ±ON.
b. Press the valet switch once and release. The parking lights will turn on and the
siren/horn will chirp once.
c. Press and hold the valet switch on, until the parking lights flash 3 times and the
siren/horn will chirp 3 times, which means the system has reset to factory default
settings.
d. Turning the ignition key to the off position or 30 seconds of no activity will exit
program mode, indicated by a single long siren/horn chirp.
NOTE: The system reset does not erase transmitter coding, but does reset tach settings.
PROGRAMMING:
a. Turn ignition ON ±OFF ±ON ±OFF ±ON.
b. Press the valet switch once and release. The parking lights will turn on and the
siren/horn will chirp once.
c. With the park lights staying on, select a desired Program Menu using the transmitter.
Pressing button 1 on the transmitter will select MENU 1; pressing button 2 will select
MENU 2; pressing button 3 will select MENU 3; pressing button 4 will select MENU
4.The park lights will flash and the siren/horn will chirp once to confirm the selected
menu.
d. Select Programmable Settings in Sub-Menus (Still in programming mode):
1. Press and release the Valet (Program) Button the correct number of times to select the
desired Sub-Menu. The park lights will flash once each time the programming button is
pressed. The LEDs in the antenna will flash and the siren/horn will chirp to indicate
which Sub-Menu has been selected. For example: 1 LED flash and 1chirp= Sub-Menu
M1-1; 2 LED flashes and 2 chirps= Sub-Menu M1-2; etc.
2. Once the correct Sub-Menu has been selected, press and hold the Program Button until
the park lights flash and the siren/horn chirps to confirm the desired setting. For example:
1 park light flash and 1 chirp= Setting 1; 2 park light flashes and 2 chirps= Setting 2; 3

Version 2.01 TS132/TS142/TS152 QIG
park light flashes and 3 chirps= Setting 3. The LEDs will continue to flash indicating
which Sub-Menu you are in (Note: LEDs turn off when the programming button is held
down).
3. Turning the ignition key to the off position or 30 seconds of no activity will exit program
mode. This will be indicated by a long siren/horn chirp.
PROGRAMMING CHART
MENU 1 (Button 1) 1 flash 2 flash
3 flash
4 flash
M1-1 Ignition Auto
Lock Enabled Lock only
Disabled*
M1-2 Door Unlock/Lock
Options Double Unlock
/Single Lock Single Unlock/Lock *
M1-3 Door Unlock/Lock
Pulse Duration Unlock/Lock
1/4s Unlock/Lock 3s
Unlock 1/4s
Lock 8s
Unlock/
Lock3/4S*
M1-4 Unlock/Lock Type Type 1 Type 2
Type 3
Normal*
M1-5 Chirp/Honk
Settings Type 1 Type 2
Type 3
All horn
honks*
M1-6 Chirp/Honk Timing & Alarm
Duration
5ms Output
30s Duration 50ms Output 60s Duration
10ms Output*
30s Duration*
M1-7 Data Format iDatalink
Protocol mode
Fortin Protocol
mode*
MENU 2 (Button 2) 1 flash 2 flash
3 flash
4 flash
M2-1 Safety Start Press Start 2X Press Start 1X*
M2-2 Park Light
Output
Park Lights On for
30 Seconds After
Unlock (-) Park light
(+) Park light*
M2-3 Titan-Secure
Alarm Features
Alarm Features
ON
Alarm Features
OFF*
M2-4 Rearm Output Type 1 Type 2
Type 3
Normal
Rearm*

Version 2.01 TS132/TS142/TS152 QIG
M2-5
Negative Horn
Output/GWR/
Starter Kill
Starter Kill
(Ground When
Armed) (Titan
Secure Only)
GWR (Ground
When Running)
Negative Horn
output *
M2-6 Long Aux. Lock
Output 30 seconds Latched
15 Seconds*
M2-7 Active/Passive
Arm (Titan Secure
Only) Passive arm Active arm *
MENU 3 (Button 3) 1 flash 2 flash
3 flash
4 flash
M3-1 Gas/Diesel
Mode 8s Delay 15s Delay
Gas/Diesel up to
30s* (Monitors
Glow Plug)
M3-2
Glow
Plug/Instant
Trigger to Start
Glow Plug Only
(Instant Trigger
Off)
Both On
(GlowPlug &
InstantTrigger) *
M3-3 Run time 4 Minutes 30 Minutes
45 Minutes
15
Minutes*
M3-4 Tach Sensing 4 Cyl Sense Smart Sense
2 Cyl Sense *
M3-5
Ready mode
(Manual
Transmission
Only)
Foot &
ParkBrake Park Brake Only
Transmitter*
AUXILIARY PROGRAMMING MENU 4
MENU 4 (Button 4) 1 flash 2 flash
3 flash
M4-1
Auxiliary Outputs
(Blue &
Green/Black
wires)
Auxiliary on
WITH Unlock
Auxiliary on
WITHOUT
Unlock
LONG
Auxiliary Pulse
(3.5 Seconds)
WITH Unlock
Re-arm
Dis-arm
Outputs
as
Default*

Version 2.01 TS132/TS142/TS152 QIG
M4-3
Auxiliary Trunk
wire
(Red/White wire)
Defrost Drivers Priority
(2nd unlock)
Long Trunk
Release (3.5
Seconds)
Normal
Trunk
Release*
M4-4
Auxiliary Sensor
Use
(Only available
on Alarm)
Internal Only External Only
Both Sensors*
³
᧦
´Indicates factory default setting.
PROGRAMMING MENU SETTING DETAILS:
Note: Bold Settings Indicate Default Setting
MENU 1EXPLANATION
IGNITION AUTO LOCK
M1-1-1 Flash Door Locks will activate Lock when ignition is turned on for more than
3 seconds and Unlock when the ignition is turned off.
M1-1-2 Flashes Door Locks will only Lock when ignition is turned on.
M1-1-3 Flashes Door lock outputs will not activate with ignition input.
DOOR UNLOCK/LOCK OPTIONS
M1-2-1 Flash Double Unlock Pulse and Single Lock Pulse (Timing Controlled by M1-3)
M1-2-2 Flashes Single Unlock and Lock pulses. (Timing Controlled by M1-3)
DOOR UNLOCK/LOCK PULSE DURATION
M1-3-1 Flash Door Unlock and Lock Pulses will be ¼ seconds long.
M1-3-2 Flashes Door Unlock and Lock Pulses will be 3 seconds long.
M1-3-3 Flashes Door Unlock pulse will be ¼ second and Door LOCK pulse will be 8
seconds long.
M1-3-4 Flashes Door Unlock and Lock Pulses will be ¾ seconds long.

Version 2.01 TS132/TS142/TS152 QIG
SPECIAL UNLOCK /LOCK FUNCTIONS
M1-4-1 Flash Unlock before start, lock after start and after shutdown.
M1-4-2 Flashes Lock pulse ONLY after remote start shutdown.
M1-4-3 Flashes IGN(+), ACC(+), and GWR(-) (White/Violet ONLY) pulse with
Unlock.
M1-4-4 Flashes No special Unlock or Lock functions.
CHIRP/HONK SETTINGS
M1-5-1 Flash Arm/Disarm and Start chirps Disable - Honks for Panic ONLY
M1-5-2 Flashes Arm/Disarm chirps Enable - No Honks for Start ONLY
M1-5-3 Flashes Arm/Disarm chirps Disable ±Honks for Programming and Panic
ONLY
M1-5-3 Flashes All Chirps Enable - Honks for all features.
CHIRP/HONK TIMING AND ALARM DURATION SETTINGS
M1-6-1 Flash 5ms Chirp/Honk timing with 30 second duration on alarm sounding
M1-6-2 Flashes 50ms Chirp/Honk timing with 60 second duration on alarm sounding
M1-6-3 Flashes 10ms Chirp/Honk timing with 30 second duration on alarm sounding
DATA MODE
M1-7-1 Flash Setting if using an iDatalink module connected to Data Port
M1-7-2 Flashes Setting if using a Fortin module connected to Data Port
MENU 2EXPLANATION
SAFETY START
M2-1-1 Flash Press Start button 2X within 3 seconds to activate remote start.
M2-1-2 Flashes Press Start Button 1X to activate remote start.

Version 2.01 TS132/TS142/TS152 QIG
PARK LIGHT /TRUNK OUTPUT
M2-2-1 Flash Park light output will stay active for 30 seconds after the Unlock
button is pressed.
M2-2-2 Flashes Park light output becomes negative on the Red / White wire and
Trunk release output becomes positive on the White wire.
M2-2-3 Flashes No special functions with regard to Park light and Trunk
Outputs.
CAR ALARM FEATURES
M2-3-1 Flash Titan Secure Alarm Features ON (Active or Passive arming and
locking controlled by M2-7)
M2-3-2 Flashes Titan-Secure Alarm Features OFF (Default): Turns off all car
alarm security features.
REARM OUTPUT FUNCTIONS
M2-4-1 Flash Rearm wire will Pulse after start, with lock, and shutdown.
M2-4-2 Flashes Rearm wire will pulse after start only.
M2-4-3 Flashes Rearm wire will pulse after remote start shutdown only
M2-4-4 Flashes Rearm wire pulses with lock, and after remote start shutdown.
NEGATIVE HORN HONK/GWR/STARTER DISABLE FUNCTIONS (ORANGE
WIRE)
M2-5-1 Flash Starter Disable / Ground Out When ARMED.
Passive /Active controlled by M2-7 (Titan-Secure must be ON).
M2-5-2 Flashes GWR ±Ground Out When RUNNING with remote start.
M2-5-3 Flashes Negative Horn output 300mA (Default) (Timing and duration
controlled by M1-6).

Version 2.01 TS132/TS142/TS152 QIG
LONG AUX.LOCK OUTPUT
M2-6-1 Flash Lock output will activate for 30 seconds if buttons 1 and 4 are
pressed together on T96 style remotes OR button 4 THEN button 1
on T85 and T99 style remotes.
M2-6-2 Flashes Latched Lock output will activate until ANY other input is received
from the transmitter.
M2-6-3 Flashes Lock output will activate for 15 seconds if buttons 1 and 4 are
pressed together on T96A.
ACTIVE/PASSIVE ARM (TITAN SECURE FEATURES ON ONLY)
M2-7-1 Flash Passive ±Titan-Secure features and Starter disable will arm
Passively (See notes below).
M2-7-2 Flashes Active ±Titan-Secure features & Starter Disable will arm
only with the transmitter (Lock/Arm & Unlock/DisArm).
PASSIVE ARMING:
a. Turn ignition ON, then OFF and close the last door. After 30 seconds, the system will
arm and lock automatically (LAST DOOR ARMING). Note: The system will still arm
with lock function if programmed to this mode.
b. When alarm is disarmed, if Accessory (Key) is not turned on / doors are not opened,
30sec later, the system will be automatically Re-Arm and the doors will lock. (AUTO
RE-ARMING)
MENU 3EXPLANATION
WAIT TO START LINE (GREY/BLACK)
This wire is foU'LHVHO(QJLQHV7KHZLUHFDQEHFRQQHFWHGWRD³:DLW7R6WDUW´ODPSDJORZ
plug, or manifold heater and will not allow the remote starter to crank (up to a maximum of 30
seconds) until the input is off allowing Glow Plugs or Manifold Heaters to sufficiently warm
up before cranking the engine.

Version 2.01 TS132/TS142/TS152 QIG
GAS /DIESEL MODE
M3-1-1 Flash Timed Diesel Mode - Remote Starter will delay 8 seconds with ignition
on before cranking.
M3-1-2 Flashes Timed Diesel Mode - Remote Starter will delay 15 seconds with ignition
on before cranking.
M3-1-3 Flashes Gasoline/Glow Plug Mode - The remote starter will monitor the glow
plug wire for a negative input for up to a maximum of 30 seconds and
then crank. If there is no input on this wire, the unit will crank after
3.5 seconds. Use this mode for Gasoline vehicles or if you are hooking
up a negative glow plug wire on a diesel vehicle.
INSTANT TRIGGER INPUT
M3-2-1 Flash Glow plug line will not instant trigger for start.
M3-2-2 Flashes Glow plug line will function as instant trigger to start and Glow
plug input.
RUN TIME
M3-3-1 Flash Remote Starter will run for 4 minutes.
M3-3-2 Flashes Remote Starter will run for 30 minutes.
M3-3-3 Flashes Remote Starter will run for 45 minutes.
M3-3-4 Flashes Remote Starter will run for 15 minutes.
TACH SENSING
M3-4-1 Flash Remote starter will detect 4 cycle pulses.
M3-4-2 Flashes Remote starter will sense by altering tach pulse frequency.
M3-4-3 Flashes Remote starter will detect 2 cycle pulses.
READY MODE SETUP ±MANUAL TRANSMISSION ONLY
M3-5-1 Flash Foot & ParkBrake.
M3-5-2 Flashes Park Brake Only.
M3-5-3 Flashes Transmitter Only.

Version 2.01 TS132/TS142/TS152 QIG
MENU 4EXPLANATION
REARM OUTPUT LINE (BLUE)-0.75 second pulse output when LOCK button is pressed
and start remote start shutdown. Used for factory alarm Re-arm. Observe that this output
comes on at the end only after all the other output have shutdown.
DISARM OUTPUT LINE (GREEN/BLACK) -0.75 second pulse when and is UNLOCK
button is pressed and before remote starting. Used for factory alarm Dis-arm. This wire pulses
before any other output comes on except the parking lights.
BLUE AND GREEN/BLACK AS AUXILIARY OUT
Menu 4 (Auxiliary Programming) is to program the Rearm Wire (Blue), Disarm wire (Green /
Black), GWR Wire (Orange), and Trunk wire (Red / While) for special outputs if so required.
The outputs can be used to activate sliding doors, or other auxiliary outputs.
This can be only be done if you are NOT using the normal analog ARM/DISARM wires
or if you are using a Data compatible interface module that Dis-arms and Re-arms
factory security.
The Blue Re-arm wire and the Green / Black Dis-arm wires (when programmed for M4-1
setting 1 or 2), will be activated by either pressing and holding button 3 for 2 seconds
(Activates Blue wire) or pressing and holding button 4 for 2 seconds (Activates Green / Black
wire). If programming them for sliding doors, and you need to unlock the doors first, program
it for setting 1 and there will be an unlock pulse before the Auxiliary pulse. If these wires are
programmed for setting 3, they will function as normal Re-arm and Dis-arm wires.
M4-1-1 Flash Press and hold button 3 for 2 seconds, there will be an Unlock pulse
followed by a .75 second output pulse from the Blue Re-arm wire.
Press and hold button 4 for 2 seconds, there will be an Unlock pulse
followed by a .75 second output pulse from the Green / Black Dis-
arm wire.

Version 2.01 TS132/TS142/TS152 QIG
M4-1-2 Flash Press and hold button 3 for 2 seconds, there will be a .75 second
pulse from the Blue Re-arm wire. Press and hold button 4 for 2
seconds, there will be a .75 second output pulse from the Green /
Black Dis-arm wire.
M4-1-3 Flash Press and hold button 3 for 2 seconds, there will be a 3.5 second
pulse from the Blue Re-arm wire. Press and hold button 4 for 2
seconds, there will be a 3.5 second output pulse from the Green /
Black Dis-arm wire.
M4-1-4 Flash Wires operate as default Re-arm and Dis-arm outputs. (Default)
RED/WHITE AS AUXILIARY OUT
M4-3-1 Flash Red / White Trunk release output will operate as a defrost output and
provide a .75 second pulse 30 seconds after the vehicle remote starts.
M4-3-2 Flash Red / White Trunk release output will operate as a driver¶s priority
output and provide a .75 second pulse with a second press of the
Unlock button on the remote. This second button press must be
within 5 seconds of the first for the output to happen.
This output takes precedence over negative park light switchover in
program M2-2. In other words if this output is programmed as
driver¶s door priority, polarity will be negative and the park light
output will go back to positive. At this point an installer would have
to use a relay for negative park lights.
M4-3-3 Flash Red / White Trunk release output operates with a 3.5 second output.
M4-3-4 Flash Red / White Trunk release output operates with a .75 second
output

Version 2.01 TS132/TS142/TS152 QIG
TACH LEARNING
᧤
THE TACH WIRE MUST BE CONNECTED TO A GOOD TACH SOURCE)
a. Start the vehicle with the key.
b. Press footbrake and hold down.
c. Within 10 seconds, press and release the valet switch then then press and hold it for at
least 2 seconds. The unit will enter Tach Learning Mode.
d. If a viable tach signal is detected then it is put in memory and learning is confirmed by
2 park light flashes and two horn/siren/horn (optional) chirps.
e. If no Tach signal is detected, the parking light will flash and the siren/horn will chirp 3
times.
MANUAL TRANSMISSION LOOP
The wire loop on the module determines if the module works as an automatic
transmission remote starter or a manual transmission remote starter. The default
setting with the loop uncut is manual transmission operation. It is the responsibility of
the installer to ensure that the loop is connected if the remote starter is being installed
into a manual transmission vehicle. If the remote starter is to be used in an automatic
transmission vehicle, you must cut the loop for normal operation. If the loop is not cut,
WKHXVHUZLOOKDYHWRSXWWKHUHPRWHVWDUWHULQWR³5HDG\0RGH´HYHU\WLPHWKH\XVHLW

Version 2.01 TS132/TS142/TS152 QIG
NEVER INSTALL A UNIT WITH THE LOOP CUT INTO A MANUAL
TRANSMISSION VEHICLE. SERIOUS INJURY OR DEATH COULD
RESULT. TITAN INNOVATIONS WILL NOT BE RESPONSIBLE FOR
ANY INJURIES OR DEATH RESULTING FROM AN INCORRECTLY
INSTALLED REMOTE STARTER. IF THE LOOP HAS BEEN CUT OR
TAMPERED WITH IN ANY WAY AND THE UNIT IS INSTALLED IN A
MANUAL TRANSMISSION VEHICLE, TITAN ACCEPTS NO
RESPONSIBILITY FOR ANY INJURIES RESULTING FROM ANY
ACCIDENTS.
PLEASE NOTE: If you have a unit that was previously installed in an automatic
transmission vehicle and the loop has been cut and you would like to install it into a
manual transmission vehicle, please contact Titan Innovations and we would be happy to
EXCHANGE the unit for you free of charge for a new unit with the loop intact and not
tampered with.
MANUAL TRANSMISSION ±Ready Mode
7RUHPRWHVWDUWWKH YHKLFOH\RX PXVW ILUVW SODFH WKH V\VWHP LQ³5HDG\0RGH´7KHUHDUH
different programming options for doing this. To use a method other than the default setting,
you must have your system re-programmed by an authorized dealer.
Default - Transmitter Activation
1. With the engine running and the transmission in Neutral, apply the parking brake.
2. Press and release the Start button on the remote transmitter.
3. Turn off key and remove from the ignition (the vehicle will stay running).
4. Exit the vehicle and make sure all doors are closed.
5. Press the Start button on the transmitter to shut the vehicle off.
7KHYHKLFOHLVQRZLQ³5HDG\0RGH´DQG can be started by remote.

Version 2.01 TS132/TS142/TS152 QIG
Option 2 - Brake Pedal Activation
1. With the engine running and the transmission in Neutral, apply the parking brake.
2. Press and release the brake pedal 2 times (once if it was already on when you applied the
park brake in step 1).
3. Turn off key and remove from the ignition (the vehicle will stay running).
4. Exit the vehicle, upon closing the last door, the vehicle will shut down.***
7KHYHKLFOHLVQRZLQ³5HDG\0RGH´DQGFDQEHVWDUWHGE\UHPRWH
Option 3 - Park Brake Activation
1. With the engine running and the transmission in Neutral, apply the parking brake.
2. Turn off key and remove from the ignition (the vehicle will stay running).
3. Exit the vehicle, upon closing the last door, the vehicle will shut down.***
7KHYHKLFOHLVQRZLQ³5HDG\0RGH´DQGFDQEHVWDUWHGE\UHPRWHUHDG\PRGH
REMOTE STARTING ±ALL MANUAL TRANSMISSION MODES
1. With the engine off, press the Start button.
2. The park lights will flash and the horn will chirp once (if connected).
7KHYHKLFOH¶VLJQLWLRQV\VWHPZLOOFRPHRQ and within 3 seconds, the vehicle will start.
4. The parking lights will flash 5 times to confirm a successful start.
5. The vehicle will run for the programmed runtime (15 minutes default).
If the vehicle does not start, see the diagnostics section on the next page for possible solutions.
*** If you press the Start button on the transmitter while the door is open, the system will go
LQWR ³,GOH PRGH´ DQG 127 VKXW GRZQ ZKHQ \RX FORVH WKH GRRU  ,W ZLOO UXQ IRU WKH
programmed run time or until it is shut down by the remote. This feature is convenient if you
need to open other doors after having closed yours. ***

Version 2.01 TS132/TS142/TS152 QIG
,03257$17,IDGRRULVRSHQHGZKLOHWKHYHKLFOHLVQRWUXQQLQJDQGLQ³5HDG\0RGH´WKH
V\VWHPZLOOH[LW³5HDG\0RGH´DQGZLOOQRWUHPRWHVWDUW<RXZLOOQHHGWRVWDUWWKHYHKLFOH
with the key and repeat the procedure. If you need to open doors and want to avoid repeating
WKH ³5HDG\0RGH´ VHWXS DJDLQVLPSO\ UHPRWH VWDUWWKH YHKLFOHDQG RSen the door while the
vehicle is running. When you are done, and the doors are closed, you can shut down the
YHKLFOHZLWKWKHUHPRWHDQG³5HDG\0RGH´ZLOOVWLOOEHHQJDJHG
DIAGNOSTICS
If the remote starter does not activate when the Start button is pressed, the park lights will
flash a diagnostic code to indicate what shutdown input has been triggered.
Parking light flashes Reason
3 slow flashes In ³Service Mode´
4 flashes 1RWLQ³5HDG\0RGH´'RRU2SHQ
(Manual Transmission Only)
5 slow flashes Ignition on
5 flashes Brake pedal is on
6 flashes Hood Open
7 times Tach lockout or Tach not learned

FUSEBOX
OPTIONAL
RELAY
TRUNK
+12V
GND
BATTERY
12V
START
MOTOR
30A
FUSE
30A
FUSE
START
LOCK
ACC
OFF
ON
8687a
8530
Starter Disable/
Anti-Grind
RED+12V
PINK/WHITE -
(selectable)*
ORANGE - ACC
PURPLE - START
PINK - IGN1
RED+12V
OPTIONAL
Wiring diagram
*The ouput on the PINK/WHITE wire is determined by the
position of the jumper
TS142
J1J2J3
FUNCTIONJUMPERPOSITION
StartsignaloutputwhenremotestartJP1
AccessoryoutputwhenremotestartJP2
Ignition signaloutputwhenremotestartJP3
Manual Transmission Wire Loop
Uncut - Manual Transmission
Cut - Automatic Transmission
Manual Transmission Wire Loop

PINK- BRAKESWITCH INPUT (+)
BLACK-SYSTEMGROUND
GREEN- DOOR PIN INPUT (-)
GRAY- HOODPININPUT (-)
WHITE - PARKLI
G
HTS (+) OR TRUNK (+) SEE PROGRAM MENU M2-2
PURPLE - DOOR PIN INPUT (+)
BROWN - SIREN
OUTPUT (+)
ORANGE -
HORN OUTPUT/GWR/STARTER KILL (-) (PROGRAMMABLE)
BLACK/WHITE - PARK BRAKE INPUT (-) (Manual Transmission Only)
PURPLE/WHITE- TACHDETECTION (AC)
PARKING LIGHTS
BRAKEPEDAL
HOODPIN
ENGINE COIL OR FUEL INJECTOR
GREEN/BLACK- DISARM/AUX OUT (PROGRAMMABLE)
(-300
m
A)
BLUE- REARM/AUX OUT (PROGRAMMABLE)
(
-300mA)
RED/WHITE- TRUNKOPEN (-) OR PARK LIGHTS (-) SEE PROGRAM MENU M2-2
ANTENNA/VALET SWITCH/LEDs
BLACK GROUND OUTPUT
RED 12VOLT OUTPUT
GREEN DOOR LOCK OUTPUT
BLUE DOOR UNLOCK OUTPUT
EMPTY
WHITE/VIOLET GROUND WHEN RUNNING OUTPUT
TS142
GRAY/BLACK - WAIT TO START (-) / (-) TRIGGER TO START (INSTANT START WIRE)
Note: The GRAY/BLACK wire is a
dual-purpose wire. If the remote
starter is inactive this wire can function
as an “instant trigger to start” wire. If
the remote starter is running, this wire
will also work as a shutdown wire. If
the ignition is on, but the engine is not
yet running (no tach signal), this wire
acts as a “wait to start” wire that hooks
up to a glow plug or manifold heater
wire. You can hook this wire up to
perform dual functions provided you
diode-isolate the “wait to start” and
“instant start” wires. For diesel
vehicles you can also just program a
delay to start “wait time” as in Menu
M3-1 programming settings. The
instant start function of this wire is also
programmable as “Off” or “Both Instant
Start & Glow Plug” as per Menu M3-2.
Call tech support if you need details on
the function of this or any other input.
Toll Free 1-800-279-0636
12v+
OPTIONAL USB PROGRAMMING CABLE
DATA PORT
CONNECTOR
12V+
GND
RX
TX
SIREN

Quick Install GuideQuick Install Guide
www.titaninnovations.cawww.titaninnovations.ca
Revision 2.01Revision 2.01
