TLS TBD.DMX-4C-RJ45 User manual

TLS
TBD.DMX-4C-RJ45 User Manual & Wiring Guide
4 CHANNEL RGB DMX DECODER
REV 03272019
TBD LED SOLUTIONS
218 E Valley Rd, Ste 104 – PMB377, Carbondale, CO 81623
www.tbdledsolutions.com
INSTALLATION
!
THIS PRODUCT IS ONLY TO BE INSTALLED BY A QUALIFIED TECHNICIAN
IN ACCORDANCE WITH NATIONAL AND LOCAL ELECTRICAL CODES.
BEFORE YOU BEGIN
Make sure the controller has the proper voltage and
wattage for the intended job. Check wiring and make
sure they match the diagram on this guide.
MOUNTING
Select a suitable and proper location to mount the
DMX decoder. Consider distance of transformer and
LED fixture from controller to determine appropriate
wire gauge.
SAFETY & WARNINGS
■ Install this product in accordance with local and
national electrical codes.
■ This product is rated for indoor use, avoid installing
outdoors.
■ Make sure this product is mounted in a well
ventilated area to avoid over-heating.
■ Make sure power from main breaker is off before
installing to avoid risk of electric shock.
POWER SUPPLY
AC110-230V
DMX MASTER
LED STRIP
L
N
12-24VDC
N L
R
G
B
W
SIGNAL INPUT
SIGNAL OUTPUT
RGB-DMX-4C-RJ45
RGB-DMX-4C-RJ45
R
G
B
W
SIGNAL OUTPUT
SIGNAL INPUT
POWER SUPPLY
AC110-230V
PERFORMANCE PARAMETER
-RJ 45 port, could be connected to WIFI & BLUETOOTH
signal, could be RF remote controlled or IOS/Android
programmed by WIFI (through a DMX Master SR-2817-
DMX or SR2816).
-Addressable. Address can be freely set through the
digital display.
-3-Channel or 4-channel output is selectable, per channel
maximum output can be 5A
Example, when we set address to 001
When select 1cH, all four channels will be the same
address 001.
When select 2cH, channel one and channel three will be
the same address 001, channel two and channel four
will be 002.
When select 3cH, channel 1,2,3 will be address
001,002,003, and channel 4 address is also 001. When
select 4cH, channel 1, 2, 3,4 will be address 001,
002,003,004.
SET DMX ADDRESS
Press 1st button for 2 seconds, digital display flashes to
set the required DMX address, then press any button for
>2 seconds to confirm.
CHOOSE PWM FREQUENCY
Press 1st button and 3rd button for 2 seconds, digital
display flashes to show P-c.
P means PWM frequency, press 1st to show "1", means
1500Hz, "2" means 200Hz.
c means dimming options, press 3rd to show "1", means
logarithmic dimming, "2" means linear dimming.
The factory preset default is PWM frequency 200Hz with
linear dimming. 2-2
WIRING

TLS
TBD.DMX-4C-RJ45 User Manual & Wiring Guide
4 CHANNEL RGB DMX DECODER
REV 03272019
TBD LED SOLUTIONS
218 E Valley Rd, Ste 104 – PMB377, Carbondale, CO 81623
www.tbdledsolutions.com
USER INSTRUCTION
Connection to DMX512 Decoder
ANT
Power Supply
Input 12VDC
NL
110-240V
V+
OUTPUT
R-
CH1
G-
2
BB--
33
W-
4
TBD.DMX-4C-RJ45
DMX 512 Dec oder
DC IN PUT
12/ 24D C
V+
V-
DMX S tart Ch annel
PRI :
Uin =12 -2 4VD C
Iin =32 .5 A
SEC :
Uou t=4 x( 12- 24) VDC
Iou t=4 x8 A
Pou t=4 x( 96- 192 )W
TEM P RANGE :-2 0℃-+5 0℃
0-90-5 0 -9
87654321
Pin 1:D ata +
Pin 2:D ata -
Pin 7:G ND
Pin 8:G ND
87654321
DMX
OUT PUT 1
Power Supply
Input 12-24VDC
NL
110-240V
R
G
B
R
G
B
W W
D1 D1 D2 D 2
SR-2102B
Iin =20. 5A
DMX 512 D eco de r
GND
whit e
Power Supply
Input 12-24VDC
NL110-240V
R
G
B
R
G
B
W W
D1 D1 D2 D 2
SR-2102B
Iin =20. 5A
DMX 512 D eco de r
GND
whit e
R
G
B
R
G
B
W W
D1 D1 D2 D 2
SR-2102B
Iin =20. 5A
DMX 512 D eco de r
GND
whit e
R
G
B
R
G
B
W W
DMX
OUT PUT 2
DMX
OUT PUT 3
DMX Master
Setting desired DMX512 address by keys. “1”button set “hundred’s place” , “2”button set “ten’s place”, “3” set
“unit’s place.” Address cannot be more than 512.
“1" button
“2" button
“3" button
Power on the DMX512
CHOOSE CHANNEL
Press 2nd button and 3rd button at the same time for 2 seconds, cH digital display flashes, then press
1st button to choose 1/2/3/4, 3 means total 3 channels, 4 means total 4 channels. Press any button for
>2 seconds to confirm the 1,2,3 or 4 channels. The factory preset default is 4 channels outputs.
