Toastmaster TRE36C1M User manual

Foodservice Equipment
Job Item#
Toastmaster ®10 Sunnen Dr. St. Louis, MO 63143• www.toastmastercorp.com
Toll Free: 1-800-264-7827 • Telephone: [phone] • Toll Free Fax: [phone] • Fax: [phone]
Features:
• Stainless steel exterior
• Hatchable to pass through
26” opening
• Includes 6” NSF-listed legs
• Front-serviceable
• 36” Cooking Height
Additional features of models
with convection oven:
• Includes three oven racks
• Vented, air-cooled motor
Additional features of
models with deck oven:
• Includes one oven rack
• Aluminized steel oven liner
Note: “C” in model denotes Convection Oven base.
“D” denotes Deck Oven base.
TRE36D5M
Marine unit with deck oven base
TRE36C1M/D1M
• Three 12” x 24”
hotplates
TRE36C2M/D2M
• Two 12” x 24” hotplates
• Two round hotplates
TRE36C3M/D3M
• One 36” x 24” x 1/2”
griddle plate
TRE36C4M/D4M
• Six round
hotplates
TRE36C5M/D5M
• One 12” x 24” x 1/2”
griddle plate
• Two round hotplates
Marine Ranges
*All ranges require field assembly

Toastmaster ®10 Sunnen Dr. St. Louis, MO 63143• www.toastmastercorp.com
Toll Free: 1-800-264-7827 • Telephone: [phone] • Toll Free Fax: [phone] • Fax: [phone]
INTENDED FOR COMMERCIAL USE ONLY. NOT FOR HOUSEHOLD USE.
Toastmaster, in line with its policy to continually improve its product,
reserves the right to change materials or specifications without notice. Such
revisions do not entitle the buyer to corresponding changes, improvements,
additions, or replacements for previously purchased equipment.
Models shown may ship UPS
Model Number TRE36C1M TRE36C2M TRE36C3M TRE36C4M TRE36C5M
Type of oven base Convection Oven
Supply (1 or 3 Phase) 208V, 240V or 480V
Rated heat input 21.6 KW 21.6 KW 21.6 KW 21.6 KW 21.6 KW
Width 36” W 36” W 36” W 36” W 36” W
Height 37-1/4” H 37-1/4” H 37-1/4” H 37-1/4” H 37-1/4” H
Depth 38-1/2” D 38-1/2” D 38-1/2” D 38-1/2” D 38-1/2” D
Ship Weight 525 lbs. 485 lbs. 525 lbs. 430 lbs. 495 lbs.
Model Number TRE36D1M TRE36D2M TRE36D3M TRE36D4M TRE36D5M
Type of oven base Deck Oven
Supply (3 Phase) 208V, 240V or 480V
Rated heat input 21 KW 21 KW 21 KW 21 KW 21 KW
Width 36” W 36” W 36” W 36” W 36” W
Height 37-1/4” H 37-1/4” H 37-1/4” H 37-1/4” H 37-1/4” H
Depth 37” D 37” D 37” D 37” D 37” D
Ship Weight 525 lbs. 485 lbs. 525 lbs. 430 lbs. 495 lbs.
Specifications
“C”
Convection
Ovens
“D”
Deck Ovens
Marine units are designed to provide shipboard stability. Includes bolt-down legs, door latch, grab rails, sea
racks, grease trays with latches and stainless steel backs. Field assembly required.
Type of
Range Top
Model Description Wt. Available
Number
for Use With
TRE36D-RACK Deck oven 5 TRE36D
rack lbs. models
slide-out
TRE36C-RACK Convection Oven 5 TRE36C
rack lbs. models
TRE36-CM Curb Mount 35 All TRE
lbs. models
TRE36-HS High Shelf N/A All TRE
models
Accessories
Three
12” x 24”
Hotplates
Two 12” x 24”
Hotplates
&Two
Round Hotplates
One
36” x 24” x 1/2”
Griddle
Six
Round
Hotplates
One 24” x 24”
Griddle
& Two Round
Hotplates
Three
12” x 24”
Hotplates
Two 12” x 24”
Hotplates
&Two
Round Hotplates
Six
Round
Hotplates
One 24” x 24”
Griddle
& Two Round
Hotplates
TM127/1070
One
36” x 24” x 1/2”
Griddle
