Toho Electronics TRM20A User manual

TRM20A
PAPERLESS RECORDER
OPERATION MANUAL
TOHO ELECTRONICS INC.
WXPVM70mnAT001E
Sep., 2018(Rev.13)
Copyright © 2009-2018 TOHO ELECTRONICS INC. All Rights Reserved.

- i -
To use this equipment safely
Thank you for purchasing our TRM20A Paperless Recorder.
Manufacturer ：TOHO ELECTRONICS INC.
Model number ：It is recorded in marking plate on the main body.
Serial number ：It is recorded in marking plate on the main body.
Country of manufacture ：Japan
Note1：Windows 7/8 / 8.1 / 10 and Excel are registered trademarks of Microsoft Corporation.
Note2：Modbus is registered trademarks of Schneider Electric.
Note3：Ethernet is registered trademarks of Fuji Xerox.
・Please installs it, operates it and prepares it, after this manual is often read, and it understands enough.
There is danger where the accident and the trouble occur when handling is mistaken.
・This specification of Recorder is subject to change without prior notice for product improvement.
・It is prohibited to remodeling this Paperless Recorder without our permission.
It doesn't assume the responsibility about the accident caused by having remodeled it without our permission.
・Please keep this manual if you actually use the Recorder.
・After reading this manual, keep it carefully by the instrument.
・Please consider this manual to be sure to extend to the final user.
・Don't use this product in any method not specification by manufacturer. The protective features of this
product may be impaired if it is used in a method not specified in the operation manual.
・
It is prohibited to copy this manual without our permission.
・
This instruction manual is subject to change without prior notice.
[Note]

- ii -
The symbols below are used on this instrument for the cautioning information.
Be sure to observe the following warnings/cautions and those provided in the
text in order to secure safety in handling the instrument.
WARNING
●
In order to prevent electric shock; be to disconnect this instrument from the main
power source when wiring it.
●When the effect on the system is expected by the error occurs due to external
factors or failure the instruments, take precautions to ensure the overall safety of
your system.
●Take precautions to so that an alien substance does not get into the instruments
aperture.
●In case of damage or failure, contacting serviceman of our company, instruments
should be against unintended operation.
●In order to prevent an electric shock; be sure to provide protective grounding prior
to turning on this instrument.
●Do not cut a protective grounding conductor or disconnect protective grounding.
●
Make sure that the supply voltage for this instrument conforms to the voltage of the
supply source.
Rated power voltage range ：100-240VAC
Working supply voltage range ：85-264VAC
Rated power frequency ：50/60Hz
Power consumption ：25VA max
Power module that is used in the instruments conform to
EN60950-1/A12: 2011.
●
Please use in an environment that is shown in the following.
Installation features ：Indoor
Altitude ：2000m or less
Ambient temperature ：0-50℃
Ambient humidity ：20-80％RH(Non condensing)
Overvoltage category ：Category Ⅱ
Allowable pollution degree ：Pollution degree 2
Vibration ：10～60Hz 0.2m/s2
Impact ：The impact is not allowed.
●Do not operate this instrument in the environment where it is exposed to a
combustible / explosive / corrosive gas or water / steam.
●Do not use in an environment where there is strong Electromagnetic wave.
May cause the operation to become unstable.
●Provide input and output wiring after turning off the power.
Symbols used on the instrument
This shows “Caution for handling”.
This symbol is used on the parts need to reference the instruction manual for saving
human body and the instrument.
This shows “Protective grounding”.
Be sure to provide protective grounding prior to operate this instrument.
This shows “Risk of electric shock”.
This symbol is used on the parts, which has a risk of electric shock.
General
Protective
Grounding
Power Source
Working
Environment
Input and
Output Wiring

- iii -
CAUTION
●Do not use empty terminals for other purposes such as relaying, etc.
●
Please confirm the direction to the insertion of SD card.
When forcibly inserting it in a wrong direction, SD card and the terminal on the
main body side might be destroyed.
Please mote that the damage of the equipment by the reverse-insertion becomes off
the subject of amends.
●Do not replace the main unit or printed circuit boards. When this is neglected, we
cannot guarantee functioning of the instrument. Contact our dealer where you
purchased the instrument, or our sales representative.
［
Note
］
●Deliver this instruction manual to an end user.
●Prior to handling this instrument, be sure to read this manual.
●If you have any questions on this manual or find any errors or omissions in this
manual, contact our sales representative.
●After reading this manual, keep it carefully by the instrument.
●When the manual is lost or stained, contact our sales representative.
●It is prohibited to copy or reproduce this manual without our permission.
●When installing this instrument, put on a protective gear such as safety shoes,
helmet, etc. for your safety.
●Do not put your foot on the installed instrument or get on it, because it is
dangerous.
●Only our serviceman or persons authorized by TOHO are allowed to remove and
take the inner module, the main unit and printed circuit boards apart.
●Use dry cloth to clean the surface of this instrument.
●Do not use any organic solvent.
●Cleaning the instrument after turning off the power.
●This instruction manual is subject to change without prior notice.
Inside of
Instrument
Instruction
Manual
Installation
Maintenance
Cleaning
Revisions
Input and
Output Wiring
Reverse-insertion
attention

- iv -
＜
CONTENTS
＞
1
．
INTRODUCTION.......................................................................................... 1-1
1.1 Paperless Recorder ......................................................................................................................... 1-1
1.2 Accessory check .............................................................................................................................. 1-1
1.3 When temporarily keeping it............................................................................................................. 1-1
1.4 Confirmation of model number and specification ............................................................................. 1-2
1.5 Handling SD card............................................................................................................................. 1-3
2
．
NAMES AND FUNCTIONS OF PARTS ....................................................... 2-1
2.1 Names and functions of parts .......................................................................................................... 2-1
2.2 Set of O-ring for waterproof.............................................................................................................. 2-3
3
．
INSTALLATION ........................................................................................... 3-1
3.1 Installation place .............................................................................................................................. 3-1
3.2 Installation on panel ......................................................................................................................... 3-1
4
．
WIRING........................................................................................................ 4-1
4.1 Terminal stand array and LAN connector......................................................................................... 4-1
4.2 Wiring for power supply.................................................................................................................... 4-2
4.3 Wiring for analog input ..................................................................................................................... 4-3
4.4 Wiring for COM ALM........................................................................................................................ 4-4
4.5 Wiring for LAN cable ........................................................................................................................ 4-4
4.6 Wiring for DI/DO (Option)................................................................................................................. 4-5
4.7 Wiring for RS-485 (Option)............................................................................................................... 4-8
5
．
OPERATION................................................................................................ 5-1
5.1 Before operating .............................................................................................................................. 5-1
5.2 Start and stop of record.................................................................................................................... 5-1
5.3 Output timing of recorded data to SD card....................................................................................... 5-1
5.4 Recording operation at power failure ............................................................................................... 5-2
6
．
DISPLAY FUNCTION .................................................................................. 6-1
6.1 Basic composition of data display screen ........................................................................................ 6-1
6.2 Real time trend display of measured data........................................................................................ 6-4
6.3 Display of measured data in bar graphs........................................................................................... 6-4
6.4 Digital display of measured data ...................................................................................................... 6-5
6.5 Historical trend display..................................................................................................................... 6-6
6.6 Event history / communication history display.................................................................................. 6-8
6.7 Security log display .......................................................................................................................... 6-9
6.8 Comment list display........................................................................................................................ 6-10
6.9 Production information display......................................................................................................... 6-12
7
．
SETTING AND CHECKING PARAMETERS................................................ 7-1
7.1 Operational mode............................................................................................................................. 7-1
7.2 Setting and checking........................................................................................................................ 7-2
7.3 Outline of parameter setting procedure............................................................................................ 7-3
7.4 Basic operation of setting screens ................................................................................................... 7-4
7.5 Setting the input spec....................................................................................................................... 7-7
7.6 Setting the scaling............................................................................................................................ 7-9
7.7 Setting the display method of channel ............................................................................................. 7-11

- v -
7.8 Setting the scale of channel............................................................................................................. 7-13
7.9 Setting the alarm value .................................................................................................................... 7-15
7.10 Setting the alarm action ................................................................................................................... 7-17
7.11 Setting the REC/CALC..................................................................................................................... 7-18
7.12 Copy the channel setting.................................................................................................................. 7-21
7.13 Setting the F value ........................................................................................................................... 7-22
7.14 Setting the timer of channel ............................................................................................................. 7-23
7.15 Setting the group name.................................................................................................................... 7-24
7.16 Setting the displayed channel .......................................................................................................... 7-25
7.17 Select the ON/OFF of graph type..................................................................................................... 7-26
7.18 Setting the automatic change function of a display group................................................................ 7-27
7.19 Setting the record cycle of main record............................................................................................ 7-28
7.20 Setting the record cycle of sub record.............................................................................................. 7-30
7.21 Setting the schedule......................................................................................................................... 7-32
7.22 Setting the unit ................................................................................................................................. 7-33
7.23 Setting the message ........................................................................................................................ 7-34
7.24 Setting the DI function...................................................................................................................... 7-35
7.25 Counts the progress time................................................................................................................. 7-36
7.26 Setting the production information.................................................................................................... 7-37
7.27 Setting the Int. SP DO...................................................................................................................... 7-38
7.28 Initialization of parameter ................................................................................................................. 7-40
7.29 Using the wizard function................................................................................................................. 7-42
7.30 “Input CH” list ................................................................................................................................... 7-43
7.31 “Calc. CH” list................................................................................................................................... 7-45
7.32 “Display” list ..................................................................................................................................... 7-47
7.33 “Record” list...................................................................................................................................... 7-48
7.34 “Others” list ...................................................................................................................................... 7-49
8
．
SETTING AND CHECKING SYSTEMS ....................................................... 8-1
8.1 Outline of system setting procedure................................................................................................. 8-1
8.2 Remove the SD card........................................................................................................................ 8-2
8.3 Format the SD card.......................................................................................................................... 8-3
8.4 Save the set value............................................................................................................................ 8-4
8.5 Load the set value............................................................................................................................ 8-5
8.6 Output log ........................................................................................................................................ 8-6
8.7 Setting the IP address...................................................................................................................... 8-7
8.8 Setting the keep alive function ......................................................................................................... 8-9
8.9 Setting the SNTP client function ...................................................................................................... 8-10
8.10 Setting the time zone and SNTP server function ............................................................................. 8-11
8.11 Setting the FTP user ........................................................................................................................ 8-12
8.12 Setting Modbus1 (RS485 communication setting, timeout, etc.)...................................................... 8-14
8.13 Setting Modbus2 (communication type)........................................................................................... 8-15
8.14 Setting the Modbus master .............................................................................................................. 8-17
8.15 Setting the remote AI. ...................................................................................................................... 8-19
8.16 Setting the LCD sleep time .............................................................................................................. 8-20
8.17 Setting the clock............................................................................................................................... 8-21
8.18 Setting the FUNC key ...................................................................................................................... 8-22

- vi -
8.19 Setting the file format ....................................................................................................................... 8-24
8.20 Setting the jump menu ..................................................................................................................... 8-25
8.21 Setting the operation mode.............................................................................................................. 8-26
8.22 Setting the language ........................................................................................................................ 8-27
8.23 Display the system information ........................................................................................................ 8-28
8.24 Setting the security mode................................................................................................................. 8-29
8.25 Setting the key lock function ............................................................................................................ 8-30
8.26 Setting the user................................................................................................................................ 8-32
8.27 “SD / Param” list............................................................................................................................... 8-34
8.28 “Comm.” list...................................................................................................................................... 8-34
8.29 “Device / Other” list .......................................................................................................................... 8-36
8.30 "Security" list .................................................................................................................................... 8-38
8.31 Engineering...................................................................................................................................... 8-38
9
．
MAINTENANCE........................................................................................... 9-1
9.1 Inspection......................................................................................................................................... 9-1
9.2 Recommended replacement cycle of parts ...................................................................................... 9-1
9.3 Troubleshooting ............................................................................................................................... 9-2
10
．
SPECIFICATION ......................................................................................... 10-1
10.1 Basic specification............................................................................................................................ 10-1
10.2 Measurement range......................................................................................................................... 10-2
10.3 Display part ...................................................................................................................................... 10-3
10.4Operation Button.............................................................................................................................. 10-3
10.5 Record function................................................................................................................................ 10-4
10.6 Alarm function .................................................................................................................................. 10-5
10.7 Ethernet(10BASE-T) ........................................................................................................................ 10-5
10.8 Power supply part ............................................................................................................................ 10-6
10.9 Structure .......................................................................................................................................... 10-6
10.10 Normal operating condition .............................................................................................................. 10-6
10.11 Others .............................................................................................................................................. 10-6
10.12 Compatible specification .................................................................................................................. 10-7
10.13 Transportation and storage conditions............................................................................................. 10-7
10.14 Optional function (Option) ................................................................................................................ 10-7
10.15 Support software.............................................................................................................................. 10-9
10.16 Dimension ........................................................................................................................................ 10-10
10.17 Folder composition of SD card(Standard) ........................................................................................ 10-11
10.18 Folder composition of SD card (Extended security) ......................................................................... 10-13
10.19 Parameter log file............................................................................................................................. 10-15
10.20 List of Security Logs......................................................................................................................... 10-17
10.21 Option item....................................................................................................................................... 10-19

1-1
1
．
INTRODUCTION
1.1 Paperless Recorder
(1) This Recorder displays measured data in real time on the liquid crystal display. It is a paperless
type that is also capable of saving the measured data to a SD memory card (hereinafter referred
to as SD card). It can operate easily with the liquid crystal with the touch panel.
(2) It can set up to 12 channels for the input types such as thermocouple, resistance bulb, and DC
voltage (or current).
(3) It allows the measured data saved to the SD card to be displayed on the display unit.
Use of the support software attached to the Recorder allows the saved data to be displayed on a
personal computer.
1.2 Accessory check
Upon receiving the Recorder unit, check the appearance for damage, and if the correct quantity of
the accessories are supplied. Please contact the shop that purchases it or our salesman when there is
a part not suitable by any chance.
1.3 When temporarily keeping it
Please keep this Recorder in the following environment. Please keep it in the following
environment when it is built in the device.
(1) Panel-mounting
bracket
(
3) Panel packing
(
2) CD-ROM
（Operation manual，
Support software）
CAUTION
Externals, the function, and the longevity etc. of the product might be ruined when
keeping it in poor surroundings.
Environment when keeping it
・Place where dust are little.
・Place that doesn't include flammable gas, firedamp, causticity gas (SO2, H2S).
・Place without vibration and impact.
・Place where and where steam is a little. Place where moisture is a little.
・Place where direct sunshine doesn't strike. Place that doesn't become high temperature.
・Place that becomes low temperature too much.
(
4) O-ring for waterproof

1-2
1.4 Confirmation of model number and specification
The marking plate to which the model number has been described is on the case. Please confirm this
instrument is a specification the same as the order referring to the table below.
Digit Specifications Code
5-6
<Number of input points>
06 point 06
09 point 09
12 point 12
【Option】
Digit Specifications Code
8
< Communication >
Without 0
RS-485 1
9
< I/O >
Without 0
DI/DO 1
10
< Examination result
b
ook >
Without 0
With（Japanese）1
With（English）2
21 3 4 5 6 7 8 9 10
11
Ｒ Ｍ ２ ０ Ａ Ｔ Ｔ
12

1-3
1.5 Handling SD card
Correspondence SD card is as follows.
・Panasonic corporation 1～32GB
・SanDisk corporation 1～32GB
There is no SD card in this equipment. Please buy it in the computer shop etc.
●Standard of record
The standard of the record when the SD card of 2GB is used is as follows. Please note that the
capacity that can be recorded by the situation of the occurrence of warning and the message is
different.
[Condition]
－Number of inputs ：6 point
－Recorded data form ：Binary
－Record type ：Maximum/minimum value record
－There is no event of the alarm, message etc.
Capacity of SD card
2GB
File preservation cycle
1 hour
1 day
Data logging cycle
1 sec
2 sec
5 sec
10 sec
1 min
Capacity that can be recorded
1.0 year
1.4 year
1.8 year
14.0 year
33.7 year
※The record exceeding the product-life cycle is not guaranteed.
●Timing of data writing
For the timing of outputting recorded data to the SD card, refer to Section 5.3.
For the format of the recording file, refer to Section 10.17.
CAUTION
・SD card on the market is sold having formatted it usually, therefore, it is not necessary to
format it again. Please go with this Recorder when formatting it. When formatting it by
the format feature of the personal computer standard, it is likely not to operate correctly.
・Please confirm it is a correct direction and the firm insertion when it installs it. The
Recorder cannot recognize the SD card when forcibly inserting it in a wrong direction.
Moreover, it causes the breakdown of the SD card and the main body of the Recorder.
Please note that the damage of the equipment when it reversely inserts it becomes off the
subject of the guarantee.
・Please do not turn off power in recording of the SD card, and do not detach the SD card.
Data might damage, and delete it.
・When the SD card breaks, important recorded data is lost. The data preserved on the card
recommends the backup to be booked once a month.
・MiniSD and the microSD card cannot be used. The use of miniSD and the microSD card
adaptor has the possibility that the card doesn't come off,therefore, please do not use it.

2-1
2
．
NAMES AND FUNCTIONS OF PARTS
2.1 Names and functions of parts
①Display area
The LCD is provided with touch panel. Display the measurement data and other various
Parameter set screens. Touch the surface to set data.
②Button operation part cover
This panel protects the button operation part. It pulls it forward while pushing two knobs below to
appear function keyboard.
Note: Please do the both hands to the opening and shutting of cover. It causes damage.
Please be performed in both hands open and close the cover.
It causes the damage.
During the opening and closing of the cover, please be careful not to pinch
your fingers.
①
Display Unit
②
Button operation part cover
Knob
【
When opening cover of button operation part】
【
When closing cover of button operation part】
CAUTION
CAUTION

2-2
③Status display lamp
Allow the power ON/OFF, LCD (display) ON/OFF and record status to be displayed.
Lamp ON (highlighted) ：Power ON, recording suspended
Lamp blinks(1 sec ON/1 sec OFF)：Power ON, recording in progress
Lamp blinks(high speed) ：Power ON, SD card writing
Lamp OFF ：Power OFF
④REC button
Used to start or stop recording.
⑤MENU button
Display the menu screen.
Used to the continuance of record when check screen of stops recording.
⑥FUNC button
The content of operation is allocated, and the operation can be done. It can select the “Change
display”, “Capture”, “Message” and “Addition reset”.
Select “OFF”, when you use as a start/a stop of Sub record.
(Refer to Section 8.17 for FUNC key.)
⑦SD card slot
Used for inserting the SD card.
To remove the SD card from the slot, press SD card to insert.
Please confirm the direction to the insertion of SD card. When forcibly
inserting it in a wrong direction, SD card and the main body are destroyed.
When you pull out the SD card while recording, it becomes impossible to
record data normally and causes past preservation data to destroy. Please
pull out the SD card after stopping recording.
CAUTION
③
Status display lamp
④
REC button
⑤
MENU button
⑥
FUNC button
⑦
SD card slot
CAUTION

2-3
2.2 Set of O-ring for waterproof
When the factory is shipped, O-ring for the waterproof is not installed. When the waterproof and
dustproof uses it by the necessary environment, please install it according to the figure below.
It is not abnormal though the opening and shutting operation of the cover
becomes very hard if O-ring for the waterproof is installed.
O-ring for waterproof
CAUTION

3-1
3
．
INSTALLATION
3.1 Installation place
Install place
This equipment is a structure that is installed in the panel and used.
Please choose and install the following places.
・Place without vibration and impact. (Vibration：10 ～60Hz 0.2m/s2Impact：The impact is
not allowed.)
・Place where dust and oily smoke are few.
・Place where ambient temperature doesn't exceed 0 ～50℃, and place where temperature
change is a little.
・Place where high radiant heat is not received directly.
・Place where drop of water doesn't hang within the range of humidity 20 ～80%RH, and place
where dewfall is not done.
・Place where circulation of air is good.
・Place where space to be able to facilitate wiring, maintenance and
check, can be taken.
・Place where electromagnetic radiation is not generated.
・Place where doesn't include flammable gas, firedamp, causticity gas (SO2, H2S).
・Place where machinery vibration is a little.
・The inclination at the installation must not incline at the right and the
left, and it become the horizontal.
(Inclining forward 0°, Backward tilting 0 ～30°)
Install Panel
・The installation panel is recommended to use the steel board whose thickness is 1.2 mm or more.
・Mounting panel can be used up to 7 mm thick at the maximum.
3.2 Installation on panel
Please put and install appended panel packing between the Recorder and the panel.
Refer to Section 10.16 for externals size.

4-1
4
．
WIRING
4.1 Terminal stand array and LAN connector
The terminal stand is one row in the uppermost part, and 4 rows or less are in the lower side for the
analog input and option.
The part of “Terminal No.41 ～49” becomes a connector for the type that the DI/DO of option is
mounted.
Fig. 4-1 Terminal stand array(The back of recorder)
Terminal
No. 51 52 53 54 55 56 57 58 59
Name POW NC COM ALM NC RS-485
Sign L N G A C ＋－
Terminal
No. 41 42 43 44 45 46 47 48 49
CH. 10 11 12
Input +/A -/B V+/B +/A -/B V+/B +/A -/B V+/B
Terminal
No. 31 32 33 34 35 36 37 38 39
CH. 7 8 9
Input +/A -/B V+/B +/A -/B V+/B +/A -/B V+/B
Terminal
No. 21 22 23 24 25 26 27 28 29
CH. 4 5 6
Input +/A -/B V+/B +/A -/B V+/B +/A -/B V+/B
Terminal
No. 11 12 13 14 15 16 17 18 19
CH. 1 2 3
Input +/A -/B V+/B +/A -/B V+/B +/A -/B V+/B
Terminal No.
LAN connector

4-2
4.2 Wiring for power supply
［Power supply terminal］
Power supply terminal is “Terminal No. 51 ～53”.
［Wiring procedure］
①The protection cover of the transparency of the terminal stand is removed. It pulls forward while
pushing the hook of two places of one side of cover part internally at the same time and it removes.
②
The cable is connected with the power supply terminal. The protective grounding is connected with
terminal No.53(G). Non-earth side of the power supply is connected with terminal No.51(L), and the
earth side of the power supply is connected with terminal No.52(N).
③
The protection cover of the transparency is installed.
④
It is confirmed that the protection earth is correctly done.
51 52 53
L N G
CAUTION
●Please use the one that corresponds to 600V vinyl insulation electric wire (IEC
60227-3) or it for the electric wire for the power supply.
●Please install round shape pressure connection terminal (for M3.5) to which the
insulation sleeve adheres on the electric wire terminal.
●Please connect the protective grounding terminal (resistance:100Ω or lower, minimum
diameter of a ground line 1.6 mm) to protective ground.
●When you share the protective earth conductor with other equipment, the influence of
the noise from the ground line might be received. Sharing with other equipment is
recommended to be avoided.
●For safety, please install the breaker or the switch, that conformed to EN60947-1 and
EN60947-3, within easy reach of the operator, and please indicate that these are the
breaker or the switch for power supply disconnection of this instrument.
●The voltage rating must use the main source of electrical power in the variation range
in ±10%.
●A transitional current might flow to the main source of electrical power when the
power supply is turned on.
Warning
●Please energize to this equipment after doing the protection earth without fail for the
electric shock prevention.
●Please do not cut the protective earth, and please do not remove connecting wires of the
protective earth.
●Please confirm the power-supply voltage of this equipment is corresponding to the
voltage of the power supply.
●Please energize to this equipment after applying the protection cover of the transparency.
●When performing maintenance work, etc. , please start work from after 10 seconds turn
off the power.
Rated supply voltage: 100～240V AC

4-3
4.3 Wiring for analog input
［Analog input terminal］
Analog input terminal is “No.11 ～49”. The number of terminals is different depending on the
number of input channels.
［Details of terminal array of each input of CH.1～12］
<TC・mV> <V> <mA> <RTD>
Terminal
No. 41 42 43 44 45 46 47 48 49
CH. 10 11 12
Input +/A -/B V+/B +/A -/B V+/B +/A -/B V+/B
Terminal
No. 31 32 33 34 35 36 37 38 39
CH. 7 8 9
Input +/A -/B V+/B +/A -/B V+/B +/A -/B V+/B
Terminal
No. 21 22 23 24 25 26 27 28 29
CH. 4 5 6
Input +/A -/B V+/B +/A -/B V+/B +/A -/B V+/B
Terminal
No. 11 12 13 14 15 16 17 18 19
CH. 1 2 3
Input +/A -/B V+/B +/A -/B V+/B +/A -/B V+/B
CAUTION
●Notes of input wire
・Please do not mix the noise about the input wiring. Moreover, the use of an effective shield
line or twist line is recommended to the noise in the input wiring.
・At the thermo-couple input, please connect thermoelectricity vs. wire directly or use the
protective conductor. The use of the input line with the shield is recommended.
・At the resistance temperature sensor input, the difference of the line resistance in three lines
is assumed below the following. The use of the input line with the shield is recommended.
Pt100, JPt100: Under 50mΩ.
・When there is a possibility of receiving the influence by the inductive noise, especially,
when wiring near the high frequency power supply, the use of the twist line with the shield
is recommended.
・Please install round shape pressure connection terminal (for M3.5) to which the insulation
sleeve attaches on the electric wire terminal.
・If you want to use by branching the input wiring, please use it with the setting of burnout
“OFF”. If the setting of burnout “ON”, may have influence to equipment.
●Notes in wiring
・Please separate from the power supply circuit (power supply or DO circuit of 25V or more)
and use this equipment and wiring between measurement points.
・
Please ground the shield of the shield line.
－V+ A B B＋－－V+
（
250
Ω
shunt resistance
connection）

4-4
4.4 Wiring for COM ALM
COM ALM can be used as an alarm output of measurements etc.
［COM ALM terminal］
COM ALM terminal is “Terminal No. 55～56”.
※Please connect neither “A terminal (output terminal)” nor “C terminal (COM terminal)” oppositely.
The circuit might be damaged when not correctly connected.
［Schematic diagram］
Open collector output (1 point)
Rating：30V DC 20mA/1 point
4.5 Wiring for LAN cable
［Communication specification］
Specification 10BASE-T
Transmission speed 10Mbps
Transmission scheme Baseband
The maximum network length or
The maximum node interval 500m(Cascade 4 steps)
The maximum segment length 100m(Between the node and HUB)
Connecting cable UTP(Unshielded Twist Pair cable)
Category 5
Protocol TCP/IP
［Connection with personal computer］
Please connect it through HUB.
Please use the cross cable when connecting it directly with the personal computer.
55 56
A C
CAUTION
・To avoid the influence of the inductive noise, LAN cable, please separate from the power
supply line and strong electricity line as much as possible.
C(COM)
+5
～
30V
A(output)
Load

4-5
4.6 Wiring for DI/DO (Option)
DI/DO becomes a connector joint.
[Pin array]
Pin No. Signal name Pin No. Signal name
1 DI1 21 DO1
2 DI2 22 DO2
3 DI3 23 DO3
4 DI4 24 DO4
5 DI5 25 DO5
6 DI6 26 DO6
7 DI7 27 DO7
8 DI8 28 DO8
9 DI9 29 DO9
10 NC 30 DO10
11 NC 31 DO11
12 NC 32 DO12
13 DI_COM 33 DO_COM
14 DI_COM 34 DO_COM
15 DI_COM 35 DO_COM
16 DI_COM 36 DO_COM
17 DI_COM 37 DO_COM
18 DI_COM 38 DO_COM
19 DI_COM 39 DO_COM
20 DI_COM 40 DO_COM
DI/DO connector

4-6
[Connector]
For DIDO, a 40-pin MIL compliant connector plug is used.
Therefore, we recommend the following for the cable side connector.
- HIROSE ELECTRIC CO., LTD
HIF3BA-40D-2.54R(Socket, Pressure welding) or HIF3BA-40D-2.54C(Socket, Crimping)
The DI/DO cable (WMSU0468A01: cable length 1m, WMSU0468A02: cable length 3m) is available as
an option.
For details, please contact to state of the purchase, or our salesperson.
Refer to below table for signal arrangement of the cable.
DI cable DO cable
Pin No. Signal name Cable Color Pin No. Signal name Cable Color
1 DI1 Red 21 DO1 Red
2 DI2 Gray 22 DO2 Gray
3 DI3 Gray 23 DO3 Gray
4 DI4 Gray 24 DO4 Gray
5 DI5 Green 25 DO5 Green
6 DI6 Gray 26 DO6 Gray
7 DI7 Gray 27 DO7 Gray
8 DI8 Gray 28 DO8 Gray
9 DI9 Gray 29 DO9 Gray
10 NC Green 30 DO10 Green
11 NC Gray 31 DO11 Gray
12 NC Gray 32 DO12 Gray
13 DI_COM Gray 33 DO_COM Gray
14 DI_COM Gray 34 DO_COM Gray
15 DI_COM Green 35 DO_COM Green
16 DI_COM Gray 36 DO_COM Gray
17 DI_COM Gray 37 DO_COM Gray
18 DI_COM Gray 38 DO_COM Gray
19 DI_COM Gray 39 DO_COM Gray
20 DI_COM Green 40 DO_COM Green
