TOMATIS TOM01 User manual

USER MANUAL
Bluetooth Headphone
| TOM01 |

2
©2018 - TOMATIS DÉVELOPPEMENT S.A.
• 1x Tomatis® Bluetooth Headphone
• 1x USB 5V/2A charger
• 1x USB cable
• 1x 3.5mm jack cable
To turn ON and OFF the headphones, press and hold the
ON/OFF button for a few seconds. The Tomatis® Bluetooth
Headphone have been especially designed to be used with
the TalksUp®-BT. It is possible to use them with a regular
TalksUp® using an aptX transmitter. Easy to use and pair,
the Bluetooth Headphone offer great comfort and freedom
of movement. You can use 2 headphones simultaneously
Content of a Bluetooth Headphone package
Using the Bluetooth Headphone
during sessions, please refer to the TalksUp-BT (TUBT01)
user manual for more information. As these headphones
are wireless, they come with a battery that needs to
be regularly recharged (approximately every 8 hours).
Recharging is done via the USB port. It is also possible to
use the headphones as wired by plugging in the 3.5mm jack
cable provided for this purpose.
+
-
Volume +
USB Port
Laterality Knob
(Level 2, 3 and 4)
ON/OFF Button
Power LED
Volume -
3,5mm jack input
Indication LED

3
©2018 - TOMATIS DÉVELOPPEMENT S.A.
BT connection and pairing
1. On your Talksup®-BT go to “Settings” and switch the
button from OFF to ON .
2. Enable pairing detection on your Tomatis® Bluetooth
Headphone (TOM01) by pressing and holding the middle
button until the light ashes red and green.
3. Press on the icon and then press on Analyze, wait
10sec.
4. Press on your headphones address on the list and press
the grey round , the headphones icon should be blue
after a few seconds.
5. Go back to the Start menu, select your day and start your
program.
If you want to pair 2 headphones, switch the number button
from 1 to 2 on the “Settings” menu, press on the
1st headphone address on the list and press on (rst
column).
Repeat the operation for the second headphones, pressing
on the second column. After a few seconds the two icons
should be blue .
If the headphones disconnect during a session, press on
the Pause button, turn back on the headphones and press
on this icon to re-pair the headphones . Press play
again to continue the listening.
Once your session is over, do not forget to turn off the
TalksUp®-BT and the Bluetooth Headphone.
Please note: If you own a regular Talksup® you will need a
bluetoothreceiver (aptX)touse with theBluetoothHeadphone.

4
©2018 - TOMATIS DÉVELOPPEMENT S.A.
Impedance
Frequency response
Sound pressure level
THD
Wireless protocole
Jack plug
Cable length
Weight
32 Ohm
20-20KHZ
95DBSPL 1KHZ
<5%
A2DP aptX (NO phone call previous/next song/pause/playing)
3.5mm
2m
227g
Bluetooth Headphone Specications
NOTE: This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to part
15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates uses
and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause
harmful interference to radio communications. However,
there is no guarantee that interference will not occur in
a particular installation. If this equipment does cause
harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one
or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and
receiver.
-Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician
for help.
Changes or modications not expressly approved by the
party responsible for compliance could void the user’s
authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation
is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired operation.
