Superlux HDB671 User manual
1
Contact
Marketing and sales
Superlux Taiwan
+886-2-26931323
Manufacturing & logistics
Superlux Enterprise
Development ( Shanghai ) Co., Ltd.
HDB671
COMPOSITE MATERIAL
WIRELESS BT HEADPHONE
English
2
HDB671
COMPOSITE MATERIAL
WIRELESS BT HEADPHONE
GENERAL DESCRIPTION
HDB671 is the latest BT circumaural
headphone of Superlux which is simple
and styling. What even better is that, the
40mm dynamic drivers of HDB671 de-
liver the nearly perfect balance between
the variety of the musical instruments
and clarity. Furnished with the soft
composite material earpads, HDB671
delivers the ultimate comfort, great and
the surprsing isolation. HDB671 presents
every music details in a limitless ow.
FEATURES
• Extra long battery life 17-19 hours
• The soft composite material earpads
provide incredible isolation and ultimate
comfort
• New developed 40mm driver
• Much tighter bass, purer vocals.
Spaciousness, balance, clarity carried
through among ranges
• Furnished with headphone cable
3
SPECIFICATIONS
Type Dynamic, closed-back
Driver Ø40mm, neodymium
Sensitivity 95dB SPL (1mW) at 1KHz
Frequency Response 20 – 20,000 Hz
Headphone Caliper Pressure Approx. 3.5N
Rated Impedance 32Ω(copper-coated aluminum wire)
Cable 0.5 meter
Operating Distance 10m ( free space)
Wireless BT VERSION Version 4.1
Support HFP v1.6/ HSPv1.2 / A2DP v1.2 / AVRCP v1.4
Battery Talk time: up to 16 hrs
Music playime: up to 12 hrs
Charging time: Around 2 hrs
WATERPROOF IP4
Net Weight 238.5g
Dimensions (HxWxD) 205*175*100 (mm)
What's In The Box Micro-USB cable / Connection Cable / Carrying Pouch
*Note:Specications are subject to change.
4
INSTRUCTIONS
Indicator activity System state
Blinking blue/red Ready to pair
Blinking blue Connected
Blinking Red Need to charge
˙Powering on/off
ON Keep press the “Power But-
ton” for around 5 seconds,
blue light remains bright, the
headset enters to pairing
mode
OFF Keep press the “Power But-
ton” for around 5 seconds,
red light switch off
˙To pair your headset with your
mobile phone
1. Keep distance of the headset and mo-
bile phone within 1 meter, the closer,
the better.
2. Switch on the headset, ensure the
headset entered to pairing mode, the
LED indicator light blinking blue/red.
3. Switch on BT search function in your
mobile phone or other device needs
to be connected, the mobile phone
will display the BT model "Superlux
HDB671".
4. Select BT model "Superlux HDB671"
（some mobile phone need to enter
the password “ 0000 ” or “ 1111 ” to
pair the headset）, your headset
will automatically connect with your
mobile phone, blue light blinks.
*IMPORTANY: Generally, pairing time of
headset has limited to 150 seconds, if the
blue light has been off or blinks, means
headset pairing mode has stopped. If
pariing remains unsuccessful, please retry
step 1 to 4 again.
˙Disconnect the headset from the
mobile
Switch off the headset; or switch off the
BT function of your mobile.
Indicator
5
˙Reconnect the paired headset with
the mobile phone
1. Keep distance of the headset and
mobile phone within 1 meter.
2. Keep press the “Power Button” until
the blue light blinks, the headset will
automatically reconnect with your
mobile phone.
˙Charging
1. Before charging, make sure the power
has been switched off.
2. Plug USB cable into the charging jack
of headset; plug other side of USB
charging cable into the USB charger
or other charging device. Charging will
start and the red light remains bright
on the headset.
3. The headset takes approximately
2 hours for fully charged, blue light
remains bright or red light switch off
after charging completed.
˙Checking the battery
1. While the headphones are in use, the
battery indicator blinks red when the
battery needs charging.
2. If you are connected to an Apple
device, the device displays the head-
phone battery charge level near the
upper right corner of the screen.
Function What to do
Play/Pause Press“Power Button”
Skip Forward Keep press
"＋"around 2 seconds
Skip Backward Keep press"－"around
2 seconds
Volume Up press "＋"
Volume Down press "－"
˙Media playback
and volume functions
Function What to do
Answer a call Press “ Power Button ”
End a call Press “ Power Button ”
Decline an
incoming call
Keep press “ Power
Button ” around 2
seconds
Last call
redialing
Double press “ Power
Button ”
˙Call functions
6
Unit:mm/inch
A
B
C
D
E F
LED indicating light
A
Power button
B
Volume Up and Volume Down
C
Microphone
D
USB connector
EHeadphone out connector ( 3.5mm )
F
LAYOUT
203.01
99.66
175
205
100
7
!
!
!
SAFETY PRECAUTIONS
Safety symbols-“WARNING” AND “CAUTION”- and messages described below are
used in this manual to prevent bodily injury and property damage which could result
from mishandling. Before operating your product, read this manual rst and understand
the safety symbols and messages so you are thoroughly aware of the potential safety
hazards.
!WARNING: Indicates a potentially hazardous situation which, if mishandled,
could result in death or serious personal injury.
CAUTION: Indicates a potentially hazardous situation which, if mishandled,
could result in moderate or minor personal injury, and/or property damage.
WARNING
‧Do not expose the unit to rain or an environment where it may be splashed by
water or other liquids, as doing so may result in re or electric shock.
‧Do not attempt to modify this product. Doing so could result in personal injury
and/or product failure.
CAUTION
‧Do not subject to extreme force and do not pull on the cable or failures may
result.
‧Keep the device dry and avoid exposure to extreme temperatures and humidity.
8
LIMITED WARRANTY
Superlux Enterprise warrants all materials and workmanship under use as instructed by the user’s
manual of this product for a period of one year from the original date of purchase. Warranty period
might be different by each area. Please contact your local dealer for more information. If any defects
are found in the materials or workmanship or if the product fails to function properly during the applica-
ble warranty period, Superlux Enterprise, at its option, will repair or replace the product. This warranty
applies only to equipment sold and delivered by Superlux Enterprise’s authorized distributors or
dealers. However, the following are not covered: Damage caused by accident, misuse, abuse, product
modication or neglect; damage occurring during shipment; damage resulting from failure to follow
instructions contained in your Instruction manual; damage resulting from the performance of repairs
by someone not authorized by Superlux; claims based upon any misrepresentations by the seller; any
Superlux product on which the serial number has been defaced, modied or removed. Service and
repairs of Superlux products are to be performed only at a factory-authorized facility or authorized
distributors or dealers. Unauthorized service, repairs, or modication will void this warranty. To obtain
repairs under warranty, you must have a copy of your sales receipt from the authorized Superlux
dealer where you purchased the product. It is necessary to establish purchase date and determine
whether your Superlux product is within the warranty period. To obtain factory authorized service,
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES CLASS B. OPERATION IS SUB-
JECT TO THE FOLLOWING TWO CONDITIONS:
(1) THIS DEVICE MUST NOT CAUSE HARMFUL INTERFERENCE, AND
(2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED INCLUDING INTERFERENCE
THAT MAY CAUSE UNDESIRED OPERATION. SUITABLE FOR HOME OR OFFICE USE.
www.superlux.com.tw
P/N:LB100B67101CE JAN, 2018
9
Contact
中国地区营销和业务
旭 广 企 业 发 展（ 上 海 ）有 限 公 司
021-69223756
support_cn@superlux.com.tw
国际营销和业务
Superlux 舒伯乐 台湾
+886-2-26931323
sales@superlux.com.tw
简体中文
HDB671
复合式材质无线 BT 立体耳机
10
概述
HDB671Superlux
HDB67140
HDB671
复合式材质无线 BT 立体耳机
特征
• 17~19
• BT V4.1Class2
•
• 40mm
•
•
11
规格
Ø40mm,
95dB SPL (1mW) at 1KHz
20 - 20,000 Hz
3.5
32
10
Version 4.1
HFP v1.6/ HSPv1.2 / A2DP
v1.2 / AVRCP v1.4
16
12
2
IP4
238.5
205*175*100mm
USB / /
*
/
203.01
99.66
175
205
100
12
指示灯活动 系统状态
操作说明
˙打开∕关闭电源
3 ~ 5
3 ~ 5
˙配对您的无线装置
1.
1
2.
3.
BT
BT Superlux HDB671
4. BT Superlux HDB671
0000 1111
*注意：无线耳机配对一般为150秒，如果蓝灯
熄灭或是闪烁，表示无线配对状况已经停止。
如果您仍未配对成功，请重复1至4步骤再次
配对
˙断开耳机与手机无线连接
BT
13
功能 措施
/
"＋"2
""2
""
""
˙媒体播放和音量功能
功能 措施
2
˙呼叫功能
˙重新连接已配对的耳机
1.
1
2.
˙充电方式
1.
2. USB
3. 2
˙检查电池
1.
2. Apple
14
A
B
C
D
E
功能說明 LED
A
B
C
Microphone
D
USB
E3.5mm
F
F
15
!
!
!
!
安全事项
16
保固服务
Superlux
Superlux
Superlux
Superlux
SuperluxSuperlux
Superlux
support_cn@superlux.com.tw
FCCB15
www.superlux.com.tw
P/N:LB100B67101CE JAN, 2018
17
HDB671
複合式材質無線 BT 立體耳機
Contact
中國地區行銷和業務
旭廣企業發展（上海）有限公司
021-69223756
support_cn@superlux.com.tw
國際行銷和業務
Superlux 舒伯樂 台灣
+886-2-26931323
sales@superlux.com.tw
繁體中文
18
概述
HDB671是Superlux最新的無線耳罩
式 耳 機。擁 有 簡 約 時 尚 的 設 計。更 棒 的
是，HDB671使用40毫米動圈單體，器樂
聲響和清晰度之間近乎完美的平衡。再
搭配柔軟的複合式材質耳罩，不僅配戴
舒適，包覆性與隔音效果更是意想不到。
讓所有的音樂細節都能流暢的呈現。
HDB671
複合式材質無線 BT 立體耳機
特徵
• 超強電池續航力 17~19 小時
• 搭配柔軟複合式材質耳罩，超乎想像的
包覆性與隔音 效果
• 全新開發的 40mm 單體
• 更緊實的超低音、更無瑕的人聲、貫徹
各 音 域 間 的 空 間 感、平 衡 感、透 徹 感
• 配備耳機線
19
規格
聲學結構 封閉式
驅動單元 Ø40mm, 釹鐵
靈敏度 95dB SPL (1mW) at 1KHz
頻率響應 20 - 20,000 Hz
夾力 3.5 牛頓
額定阻抗 32Ω（銅包鋁線）
工作範圍 10 米（無障礙環境下）
無線版本 Version 4.1
支持協議 HFP v1.6/ HSPv1.2 / A2DP
v1.2 / AVRCP v1.4
電量 通話時間：約 16 小時
音樂播放時間：約 12 小時
充電時間：約 2小時
防潑水 IP4
重量 238.5 公克
尺寸 205*175*100（mm）
配件 USB 充電線 / 連接線 /
便攜袋
*注意：技術規格可能有所更動
尺 寸 單 位：公 釐 /英吋
203.01
99.66
175
205
100
20
指示燈活動 系統狀態
閃爍的紅藍光 準備配對
閃爍的藍光 已連接
閃爍紅色 需要充電
操作說明
˙ 打 開∕關 閉 電 源
開啟無線
接收裝置
按住電源按鍵約3 ~ 5
秒，直到指示燈轉為藍
燈放開即可
關閉無線
接收裝置
按住電源按鍵約3 ~ 5
秒，直 到 指 示 燈 紅 燈 熄
滅即可
˙配 對 您 的 無 線 裝 置
1. 請將無線耳機和手機（或其他用作連
接的裝置）的距離控制在1米 範 圍 內，
越近越好
2. 將無線耳機開機，並確認已經進入配
對模式，此時紅藍燈交叉閃爍
3. 打開手機或是其他所需連接的裝置的
BT搜索功能，手機上會顯示已經找到
BT型 號“ Superlux HDB671＂
4. 選擇此BT型 號“ Superlux HDB671＂
（ 部 分 手 機 須 輸 入“ 0000“ 或“ 1111＂
作為配對密碼），無線耳機會自動與手
機連接藍燈閃爍
* 注 意：無 線 耳 機 配 對 一 般 為 1 5 0 秒，如 果 藍 燈 熄
滅或是閃爍，表示無線配對狀況已經停止。如
果您仍未配對成功，請重複1至4步驟再次配對
˙斷開耳機與手機無線連接
關閉耳機，或關閉手機的BT功能
指示燈
