DRIVER’S HANDBOOK
CARMINAT TOMTOM®

1
ENG_UD16127_4
NFA - Sommaire (XNX - NFA - Renault)ENG_NW_859-3_TTY_Renault_0
Contents
Precautions during use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
General information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
General description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Introduction to the controls. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Swivel screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
SD card: use, initialisation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Switching on/off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Guided tours. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Operating principles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Reading a map. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Preparing and creating a journey . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Entering a destination . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Guidance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Preparing a route . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Traffic information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Browse map . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Add and manage favourites. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
System settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Safety cameras . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Help me! . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Image viewer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Reversing camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
System update. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Operating faults . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

SD card.................................................(up to the end of the DU)
navigation system................................. (up to the end of the DU)
precautions during use .........................(up to the end of the DU)
2
ENG_UD13031_2
NFA/Précautions d’utilisation (XNX - NFA - Renault)ENG_NW_859-3_TTY_Renault_0
Precautions during use
PRECAUTIONS DURING USE
The description of the models given in this manual is based on the specifications at the time of writing. This manual covers all
existing functions for the models described. Whether or not they are fitted depends on the equipment model, options selected
and the country where it is sold. This manual may also contain information about functions to be introduced later in the year.
Precautions when operating the system
– Operate the controls and read the information on the screen only when road conditions allow.
– Set the volume to a reasonable level so that outside noise can be heard.
Precautions regarding navigation
– Use of the navigation system does not in any way replace the responsibility or vigilance of the driver when driving the vehi-
cle.
– Depending on the geographical area, the map on the SD card may not have the latest information on new roads. Be alert. In
all cases, Road Traffic Regulations and road signs always take precedence over the directions of the navigation system.
Precautions concerning the equipment
– Do not attempt to dismantle or modify the system, as there is a risk of damage to equipment and fire.
– Contact a representative of the manufacturer in the event of malfunction and for all operations involving disassembly.
– Do not insert foreign objects or a damaged or dirty SD card into the reader.
– Allows clean your screen with a microfibre cloth or a soft, moistened cloth.
– Use an SD card which is suitable for your navigation system.
It is essential to follow the precautions below when using the system, both in the interest of safety and to prevent material damage.
You must always comply with the laws of the country in which you are travelling.

SD card..................................................................(current page)
GPS
receiver ............................................................(current page)
3
ENG_UD16627_3
NFA/ Description générale (XNX - NFA - Renault)ENG_NW_859-3_TTY_Renault_0
The navigation system
The navigation system calculates your
position and guides you using data:
– vehicle speed and information from
the gyro (measuring the vehicle di-
rection);
– from the GPS receiver;
– from the digital map.
Note: When using the vehicle for the
first time, the speed information and
the gyro will be undergoing final cali-
bration. It is therefore normal that the
system does not provide a very precise
location until the vehicles has travelled
around fifty kilometres and undertaken
about forty pronounced corners.
General information
General description
GENERAL DESCRIPTION (1/3)
Navigation assistance
function
The system suggests a route to your
chosen destination using:
– its road map (on the SD card),
– the positioning sensors which esti-
mate your location even if the GPS
signals are lost,
– information from the traffic informa-
tion service (depending on country).
Finally, it indicates the route to take,
step by step, using the display screen
and voice messages.
The GPS receiver
The navigation system uses GPS satel-
lites (Global Positioning System) orbit-
ing around Earth.
The GPS receiver receives signals
transmitted from several satellites. The
system can then locate the position of
the vehicle.
Note: after moving a long distance
without driving (ferry, rail freight), the
system may take several minutes to
adjust before retuning to normal opera-
tion.
The digital map
The digital map contains the road maps
and town maps that the system re-
quires. This is found on the SD card.

screen
map..................................................................(current page)
screen
menu................................................................(current page)
4
ENG_UD16627_3
NFA/ Description générale (XNX - NFA - Renault)ENG_NW_859-3_TTY_Renault_0
Jaune Noir Noir texte
GENERAL DESCRIPTION (2/3)
Displays
Menu screen
AMenu name
BSub-menu name
CMenu page scroll bar
Map screen
DNavigation maps
EIndication of the next navigation in-
struction (road sign)
FTraffic information
GClock
HInstructions for navigation and dis-
tance to next change of direction
IEstimated arrival time and total re-
maining distance
JExterior temperature
KCurrent location
LAudio information (depending on the
vehicle)
Note: at any time you can access the
map screen by pressing the MAP2D/3D
button on the remote control or the cen-
tral control.
If you have just modified a parameter,
remember to confirm it using the soft
buttons before returning to the map
screen.
Use night
colors
Show POI
on map
Safety pref-
erences
Preferences 1 of 5
Voice prefer-
ences
Turn off
sound
Manage
Favorites
BA
C
Marc Bloch
Avenue du Golf
Avenue Léon
Marc Bloch
Avenue du Golf
Avenue Léon
4.5km
6:52
300
metres
6:47
LW 10245 66 RDS-AF 26°C
A2/E35 Utrecht
14
km
30
DEF G
L K J I H

screen
audio ................................................................(current page)
Jaune Noir Noir texte
5
ENG_UD16627_3
NFA/ Description générale (XNX - NFA - Renault)ENG_NW_859-3_TTY_Renault_0
Audio screen
MSource currently in use (Radio, CD,
etc.)
NInformation on the current track or
station.
OAdditional information on radio mes-
sages and services (I news…) and
the CD play mode (Random).
Audio and telephone screen
When you use your audio system to
modify a source or change the audio
parameters, the information appears in
full screen mode.
When the operations are completed,
the window closes again, the audio in-
formation is displayed on band Oand
the navigation screen appears.
Refer to the user guide for your
audio and/or telephone system for
further information.
GENERAL DESCRIPTION (3/3)
Telephone screen
(depending on the vehicle)
PFunctions
QPhone information
4.5km
6:52
300
metres
6:47
26°C
News
RADIO FM
102.45 66
O N
M
RandomTraffic
4.5km
6:52
300
metres
6:47
26°C
6
FM 102.45 RADIO 1
Traffic
NM
O
4.5km
6:52
300
metres
6:47
26°C
RADIO 1
List of contacts
Update
P Q
O

controls................................................. (up to the end of the DU)
3D/2D mode .........................................(up to the end of the DU)
soft button............................................. (up to the end of the DU)
6
ENG_UD16630_4
NFA_Présentation commande (XNX - NFA - Renault)ENG_NW_859-3_TTY_Renault_0
Jaune Noir Noir texte
Introduction to the controls
Function
1Soft buttons Select and confirm
2INFO/ROUTE Accessing the Traffic information (short press), access-
ing the programmed route summary (long press).
3Rotary button
Rotate:
– move vertically and horizontally through the
menus;
– modify the scale (ZOOM mode).
Shift (up, down, right, left):
– move vertically or horizontally through the menus;
– move around the map.
Press:
– confirm;
– display the quick menu.
5MENU/SET Accesses the full navigation system menu (short
press), accesses the system settings (long press).
6LIGHT/DARK Changes the brightness of the screen (short press) or
activates the standby screen (long press).
7REPEAT/MUTE Repeats the instruction (short press), deactivates the
voice guidance (long press).
8DEST/HOME Accesses the “Navigate to...” (short press), navigate to
your Home (long press).
9MAP-2D/3D From a menu: displays the map
From the map: switches the map to 2D/3D mode.
10 BACK Back to previous screen.
INTRODUCTION TO THE CONTROLS (1/2)
Central control
BACK
MAP
2D/3D
INFO
ROUTE
DEST
HOME
MENU
SET
REPEAT
MUTE
LIGHT
DARK
BACK
1 1 2
356789
10
Note: depending on the vehicle, the
system has either a central control
or a remote control.

Jaune Noir Noir texte
7
ENG_UD16630_4
NFA_Présentation commande (XNX - NFA - Renault)ENG_NW_859-3_TTY_Renault_0
INTRODUCTION TO THE CONTROLS (2/2)
Function
1Soft buttons Select and confirm
4Remote control
Shift (up, down, right, left):
– move vertically or horizontally through the menu;
– move around the map.
Press the central button:
– confirm;
– displays the quick menu.
5MENU Accesses the full navigation system menu.
9MAP-2D/3D From a menu: displays the map
From the map: switches the map to 2D/3D mode.
10 BACK Back to previous screen.
LED Aon the remote control flashes
once your navigation system is con-
nected to it. To replace the batteries,
refer to the section entitled “Remote
control: batteries”.
Note: to connect your remote con-
trol more quickly, press one of the
remote control buttons when the
system starts, before the legal no-
tices appear.
Note: the remote control unit does
not have press and hold functions.
Remote control
Store the remote control in its hous-
ing, away from sunlight, to ensure
the batteries are not damaged.
A
4
1
5
1
10
9
Note: depending on the vehicle, the
system has either a central control
or a remote control.

8
ENG_UD16035_1
Ecran pivotant (XNX - NFA - Renault)ENG_NW_859-3_TTY_Renault_0
Swivel screen
Definition
Depending on the vehicle, your navi-
gation screen can be turned to the left
and right to ensure it can be read with
the utmost comfort under any circum-
stances.
SWIVEL SCREEN
Manipulation
To avoid any temporary faults with the
guidance system, it is recommended
that the screen is moved when station-
ary.
Push the screen on the left or right to
swivel it.

SD card.................................................(up to the end of the DU)
system
initialisation ..................................... (up to the end of the DU)
9
ENG_UD16631_3
Carte SD Utilisation/Initialisation (XNX - NFA - Renault)ENG_NW_859-3_TTY_Renault_0
SD card: use, initialisation
SD card
An SD card is supplied with the navi-
gation system. It includes, among other
things, a map of your country.
Updates are regularly issued, in par-
ticular for maps and safety cameras.
They are only available for download
by inserting your navigation system’s
SD card into a computer which is con-
nected to the internet.
Once your new vehicle has been de-
livered, you will have a maximum of
60 days in which to update the map for
free. Once this time has elapsed, you
will need to pay for updates.
To update your system and your map,
refer to the section entitled “System
update” in your user manual.
Only use an SD card which is com-
patible with your vehicle's naviga-
tion system.
Inserting the SD card
Switch off the ignition to switch off the
navigation system and insert the SD
card in slot A.
SD CARD: use, initialisation
The SD card is fragile; do not bend
it.
Insert it the right way round, as
shown in the diagram.
Remember to back up the data on
the card regularly. Refer to the sec-
tion entitled “System update” in your
user manual.
L
éon
L
éon
4.5km
6:52
300
metres
6:47
RDS-AF 26°C
e
cht
14
km
A
15:15
AB
?
?
Main Menu 3 of 3
Image viewer
Prepare
route
Current position:
Remove SD
card
Guided tours
Only use your SD card for operat-
ing and updating your navigation
system. Do not insert any other
device (camera, portable GPS,
etc.).
Removing the SD card
From the main menu, select “Remove
SD card”, then confirm using the right-
hand soft button. A message informs
you when you can remove the SD card.
To remove the SD card from slot A,
press on the card, then release it. The
card is released a few millimetres.
Pull the card to remove it completely.

operation...............................................(up to the end of the DU)
switching off.......................................... (up to the end of the DU)
screen
monitor............................................(up to the end of the DU)
10
ENG_UD16434_2
NFA/Marche/Arrêt (XNX - NFA - Renault)ENG_NW_859-3_TTY_Renault_0
Switching on/off
SWITCHING ON/OFF
Switching on
The multimedia system switches on au-
tomatically when the ignition is switched
on.
In other cases, press the On/Off button
on your audio system.
With the ignition off, you can use the
system for 20 minutes. A bleep and
message will then indicate that it is
switching off.
Press the On/Off button on your audio
system to make the multimedia system
run for an extra 20 minutes.
Switching off
With the ignition off, the system is deac-
tivated automatically when the driver’s
door is opened.
With the ignition on, press the On/Off
button on your audio system.
Exterior temperature/clock
With the ignition on, press the On/
Off button on your audio system. The
system then stops the guidance and
displays a simple clock screen (and the
temperature, depending on the vehi-
cle).
Depending on the vehicle, you can then
switch to a completely black screen by
pressing and holding the LIGHT/DARK
button.
12:00
24°C
Standby screen
(depending on the vehicle)
The standby screen mode (black
screen) allows the display screen to be
switched off.
When in standby screen mode, the
system is still operating. Guidance con-
tinues, along with the radio.
Press and hold the “LIGHT/DARK"
button on your central control.
Any other action will reactivate the
screen.
Resetting the system
To reset all the system parameters and
delete all personal data, use the “MENU/
SET” button to access the main menu
and select “Change preferences” then
“Reset factory settings”, then follow the
instructions on the screen using the soft
buttons.

guided tours.......................................... (up to the end of the DU)
11
ENG_UD16435_3
Initiations rapide (XNX - NFA - Renault)ENG_NW_859-3_TTY_Renault_0
15:15
16:30
15:15
AB
?
?
Guided tours
GUIDED TOURS
Guided tours
Your navigation system offers you tuto-
rials so that you can quickly become fa-
miliar with the different functions:
“Central Control operation” or
“Remote control”
This tutorial will teach you to use the
central control and the remote control
for your navigation system.
“Driving view”
This tutorial will teach you about the dif-
ferent areas of your navigation screen
and the best way to use them.
“Menu options”
This tutorial teaches you about the dif-
ferent menus.
“Browse map”
This tutorial teaches you how to use the
“Browse map” menu.
“Planning preferences”
This tutorial teaches you how to use the
“Planning preferences” menu.
“Itinerary planning”
This tutorial teaches you how to use the
“Itinerary planning” menu.
“Traffic information”
This tutorial teaches you how to use the
“Traffic info” menu.
“Warnings and notifications”
This tutorial teaches you about the dif-
ferent notices and information which
appear on the navigation screen.
“Quick menu”
This tutorial teaches you how to use the
“Quick menu” menu.
“Tom Tom Home”
This tutorial teaches you how to use the
“Tom Tom Home” application.
Guided tours
Central
control
Driving view Menu op-
tions
Browse
map
Itinerary
planning
Planning pref-
erences
Guided tours
viewer
Guided
tours
Remove
SD card
Guided tours
Traffic infor-
mation
Quick menu
Warnings and
notifications
Prepare
route
Tom Tom
Home

controls.................................................................. (current page)
soft button............................................. (up to the end of the DU)
buttons................................................................... (current page)
MENU................................................... (up to the end of the DU)
12
ENG_UD16634_2
NFA/Principes d’utilisation (XNX - NFA - Renault)ENG_NW_859-3_TTY_Renault_0
Jaune Noir Noir texte
Operating principles
Navigating a menu
Central control
– turn rotary switch 3for vertical or
horizontal movement (movement A
or B);
– push 3to move vertically or horizon-
tally (movement Aor B).
Remote control
Press buttons 5to move vertically or
horizontally (movement Aor B).
OPERATING PRINCIPLES (1/2)
Shortcuts
From the navigation map, some but-
tons on your remote control unit have
shortcuts giving direct access to menus
and functions.
4Zoom,
6Info Menu.
Soft buttons
Soft buttons 1are used to select or con-
firm an action Cor Dwhich appears at
the bottom of the screen.
BACK
MAP
2D/3D
INFO
ROUTE
DEST
HOME
MENU
SET
REPEAT
MUTE
LIGHT
DARK
BACK
B
A
1 12
3
5
4
6
7
1
2
1
A
B
15 sec
9:13am
1 2 3 4 5
6 7 8 9 0
Done
D
C
Confirming/cancelling a
selection
Always confirm the selection by press-
ing 3 or 7. To return to the previous
menu, press 2.
Special features of the
remote control
From the navigation map:
– the left soft button can be used to
repeat the voice instruction;
– the right soft button can be used to
display the programmed route sum-
mary.

short menu.............................................................(current page)
Jaune Noir Noir texte
13
ENG_UD16634_2
NFA/Principes d’utilisation (XNX - NFA - Renault)ENG_NW_859-3_TTY_Renault_0
15:15
OPERATING PRINCIPLES (2/2)
Quick menu from the central
control
To access the quick menu directly
from your central control, press the OK
button.
Quick menu from the remote
control
To access the quick menu directly from
your remote control, press the OK
button.
Quick menu
Use night
colors
Report
safety
camera
Clear
route
Help me!Mark location of
map error
Add position to
Favorites
15:15
Quick menu
Turn off
sound
Use night
colors
Report
safety
camera
Mark location of
map error
Add position to
Favorites
Brightness
preferences

volume.................................................. (up to the end of the DU)
voice
activate ...........................................(up to the end of the DU)
voice
deactivate .......................................(up to the end of the DU)
sounds
activate ...........................................(up to the end of the DU)
sounds
deactivate .......................................(up to the end of the DU)
14
ENG_UD16636_2
Volume (XNX - NFA - Renault)ENG_NW_859-3_TTY_Renault_0
15:15
Volume
VOLUME
Volume
Changing the volume
To change the volume, use the audio
system volume control during a voice
instruction. If the instruction is too quick,
you can repeat it using the “REPEAT/
MUTE" on your central control unit, or
use the left soft button on your remote
control.
Refer to your audio system’s hand-
book.
Deactivating the sound
To turn off the sound, in the main menu,
select “Change preferences”, or from
the quick menu on the remote control
by pressing the central button, then
“Turn off sound”.
To turn the sound back on, select the
“Turn on sound” heading.
Deactivating the voice
To deactivate the guidance instructions,
press and hold the “REPEAT/MUTE"
button on the central control or select
"Change preferences” then “Disable
voice”
Selecting a voice
Your system allows you to select either
a synthesised or human voice. This
voice is used to give the voice instruc-
tions.
To modify the voice used by your navi-
gation system, from the main menu,
select “Change preferences” then
“Speech preferences” and “Change
voice”. Selecting a voice from the list.
Your navigation system has two voice
types.
Synthesised voices
Synthesised voices are generated by
your navigation system. They give you
verbal instructions while you are driv-
ing. They can give road directions, traf-
fic sign information, etc.
Recorded human voices
The human voices are recorded by an
actor.
Note: the human voices only give you
simplified guidance instructions.
Safety pref-
erences
Speech pref-
erences
Turn off
sound
Manage
Favorites
Speech preferences
Change voice
Speech preferences
Disable voice
Preferences 1 of 5
Use night
colors
Show POI
on map

map
display..............................................................(current page)
map
scale ................................................................(current page)
map
map symbols....................................................(current page)
compass ................................................................(current page)
15
ENG_UD16439_2
NFA/Lire une carte (XNX - NFA - Renault)ENG_NW_859-3_TTY_Renault_0
Marc Bloch
Avenue du Golf
Avenue Léon
Marc Bloch
Avenue du Golf
Avenue Léon
4.5km
6:52
300
metres
6:47
LW 10245 66 RDS-AF 26°C
A2/E35 Utrecht
14
km
30
Reading a map
READING A MAP
Map key
AWarning of the next risk area with
the related distance (fixed or mobile
speed camera, school, etc.).
BName of the next major road or road
sign information, if applicable.
CTraffic sidebar: display of incidents
on the route, traffic info reception in-
dicator.
DCurrent time.
EDistance to and direction of next
change of direction.
FExterior temperature (depending on
the vehicle).
A
FHI
Map icons
The navigation system uses icons Kto
display points of interest (POI).
Compass
To display or hide compass Lin the
main menu (“MENU” key), select
“Change preferences” then “Enable
compass”.
B D E
GJ
C
Marc Bloch
Avenue du Golf
Avenue Léon
Marc Bloch
Avenue du Golf
Avenue Léon
4.5km
6:52
300
metres
6:47
LW 10245 66 RDS-AF 26°C
A2/E35 Utrecht
14
km
30
GInformation about your journey, such
as journey time, remaining distance
and arrival time.
Note: to select what will be shown,
select “Change preferences” in the
main menu, then “Status bar prefer-
ences”.
HAudio system information.
ICurrent location.
JSign giving the speed limit (the speed
given depends on the unit chosen).
Note: the sign turns red and flashes
if you drive faster than the speed
limit
Colour codes
The roads are displayed differently de-
pending on the type of carriageway.
You have the option to change the col-
ours: in the main menu (MENU button),
select "Change preferences” then
“Change map colors”.
L
K

address................................................. (up to the end of the DU)
guidance
activation.........................................(up to the end of the DU)
16
ENG_UD16440_3
NFA/Entrer une destination (XNX - NFA - Renault)ENG_NW_859-3_TTY_Renault_0
Jaune Noir Noir texte
Preparing and creating a journey
Entering a destination
ENTERING A DESTINATION (1/4)
“Navigate to..” menu
Press the “MENU" button to access the
"Navigate to..” menu.
The “Navigate to..” menu offers you
several ways to enter a destination:
– enter a full “Address”;
– select your “Home” as the destina-
tion;
– select an address from the “Favorite”
section;
– select a destination from a “Recent
destination”;
– select an address from the “Points of
Interest” section (POI);
– select a “Crossing or intersection”;
– select a “City center”;
– select a “Zip Code”;
– select a “Point on map”;
– select a “Latitude” or “Longitude”.
Entering a “New address”
This item allows you to enter all or part
of the address: country, city, street and
house number.
Note: only addresses known to the
system through the digital map are au-
thorised.
– When using for the first time, choose
the destination country.
– Enter the name of the desired city.
The system may suggest several
cities, the first line is always high-
lighted in yellow. Press the “Done”
key to confirm this city.
– Access the full list corresponding to
your search by selecting arrow 1.
– Select the desired city and confirm.
Proceed in the same way for “Street”
and “No.”.
Note: the system stores previously en-
tered cities in its memory. You can di-
rectly select one of these cities by se-
lecting arrow 1.
Main Menu 1 of 3
Navigate to... Find alternative Traffic info
Change pref-
erences
Help me! TomTom Safety
Cameras
Current position:
9:13am
France
: Vers
Vers (Haute-Savoie)
Vers (Lot)
123
A B C D E F G H I
J K L M N O P Q R
ST U V W X Y Z
1
Done

destination .............................................................(current page)
Jaune Noir Noir texte
17
ENG_UD16440_3
NFA/Entrer une destination (XNX - NFA - Renault)ENG_NW_859-3_TTY_Renault_0
15:15
Navigate to... 1 of 2
15:15
15:15
ENTERING A DESTINATION (2/4)
“Home”
This box allows you to navigate to your
home and you can activate it from the
central control by pressing and holding
the “DEST/HOME" button.
To store the address of your home lo-
cation, refer to the section entitled
“Manage favourites”.
“Recent destination”
This item enables you to select a des-
tination from the list of addresses last
used. These are automatically stored.
In the main menu, select the heading
“Navigate to...” and then “Recent des-
tination”.
From the list of stored destinations,
select an address then confirm this ad-
dress as a destination.
“Favorite”
The “Favorite” box contains the fre-
quently stored destinations and favour-
ites such as your place of work.
– In the main menu, select the heading
“Navigate to..”.
– Select “Favorite” and confirm.
– Select the required destination ad-
dress in the list of stored addresses.
– Confirm.
To store a destination in the favourites,
refer to the section entitled “Manage fa-
vourites” in your user manual.
Home Favorite Address
Recent
destina-
tion
Point of
Interest
Point on
map
Navigate to... 1 of 2
Home Favorite Address
Recent
destina-
tion
Point of
Interest
Point on
map
Home Favorite Address
Recent
destina-
tion
Point of
Interest
Point on
map
Navigate to... 1 of 2

points of interest (PI) .............................................(current page)
18
ENG_UD16440_3
NFA/Entrer une destination (XNX - NFA - Renault)ENG_NW_859-3_TTY_Renault_0
Jaune Noir Noir texte
15:15
15:15
ENTERING A DESTINATION (3/4)
“Point of Interest” (POI)
A point of interest (POI) is a service,
establishment or tourist area close to a
location (start point, destination city, en
route, etc.). POIs are classed in differ-
ent categories, e.g. restaurants, muse-
ums, car parks, etc.
There are several options to find a point
of interest:
– category,
– the name of the desired POI.
In the main menu, select the heading
“Navigate to..” then “Point of Interest”
and confirm.
Search by POI name
Enter the name of the POI that you wish
to find and the system will automatically
search for the point of interest.
Search by POI category
Select your desired category type.
Choose the area you require: “POI
near youPOI”, “POI in city” or “POI near
Home”.
Enter a city name and start the search
by selecting “Done”.
“Point on map”
This function allows you to define a
destination from the map. In the main
menu, select “Navigate to..” then “Point
on map” using the buttons on the
remote control or the rotary button on
the central control.
From the central control or the remote
control, move around the map to po-
sition the cursor on your destination,
then confirm: the system calculates the
route.
Navigate to... 1 of 2
Home Favorite Address
Recent
destina-
tion
Point of
Interest
Point on
map
Navigate to... 1 of 2
Home Favorite Address
Recent
destina-
tion
Point of
Interest
Point on
map
POI category:
Nightlife
Airport
Rest area
Embassy
Government office
Library
Find

Jaune Noir Noir texte
19
ENG_UD16440_3
NFA/Entrer une destination (XNX - NFA - Renault)ENG_NW_859-3_TTY_Renault_0
9:13am
0:13 hrs - 9.4 km
GO
VIROFLAY
CHAVILLE
LE CHESNAY
SEVRES
VIROFLAY
CHAVILLE
LE CHESNAY
SEVRES
15:15
ENTERING A DESTINATION (4/4)
Confirming the destination
Once the destination information has
been entered, the system calculates
the route.
At the end of the calculation, the system
displays the navigation summary and
suggests two options:
– “Details” enables you to see details
of the journey in various forms (refer
to the information on “Route informa-
tion” in the “Guidance” section).
– “Done”, guidance starts.
Note: if you do not confirm, this page
will close after ten seconds and guid-
ance will start automatically.
“Latitude Longitude”
This function allows you to define a
destination using latitude and longitude
values.
Navigate to... 2 of 2 Home
Fastest route - IQ Routes
Details Done
Note: “IQ routes" is a function which
optimises the journey time using statis-
tical data.
To activate or deactivate this function,
refer to the information on “Planning
preferences” in the “System settings”
section
Planning a route in advance
You can use your navigation system to
plan journeys in advance by selecting
both your starting point and your des-
tination. For example, to find out how
long a journey is going to take before
you start, or to check the route of a jour-
ney you are planning.
To access the menu, from the main
menu (MENU/SETbutton), select
"Prepare route”.
Select a starting point in the same way
as you would select your destination.
Select a destination.
Choose the type of route, then confirm.
The system plans the route and allows
you to view the details.
Latitude
Longitude
