Tomy The first years baby glow y7817 User manual

810

Y7817

™

Baby Glow™

Ultrasonic Humidiﬁer

Instruction Manual

READ ALL INSTRUCTIONS

BEFORE USING.

KEEP THESE INSTRUCTIONS

FOR FUTURE REFERENCE.

FOR HOUSEHOLD USE ONLY.

1. Nebulizer

2. Water Level Gauge with Floater

3. Air Tower

4. Water Tank

5. Tank Lid

6. Mist Vent

7. Control Knob

8. Basket

9. Basket Ring

10. LED Nightlight on/off switch (back of unit)

USING YOUR HUMIDIFIER

Set Up

NOTE: Humidifier should always be on a solid, level, and moisture-resistant surface.

1. Ensure humidifier is unplugged.

2. Remove the lid from the top of the tank.

3. Fill the tank with water. DO NOT fill above the MAX fill line.

4. Place the lid back on to the top of the water tank.

5. Plug in the humidifier and turn the mist control knob to turn it on.

NOTE: If the low water alert appears and the humidifier still has enough water, check to

confirm that the floater has not become stuck below the water line. Please reference #2

on the diagram on page 1.

For optimal performance, we recommend using distilled water.

Mist Control

Use the Mist control knob to control the level of mist. The humidifier features 360 degree

mist control. Simply rotate the cover so that the mist vent points in your chosen direction.

NOTE: DO NOT aim mist directly at your child, the wall, or nearby furniture.

IMPORTANT:

• Water level should NEVER be higher than the “MAX” line.

• When first using, we do NOT recommend setting the mist output to the maximum

level. Too much mist could cause a pool of water to form near the humidifier.

• It is best to start with lower mist settings until you confirm what works best for your

home’s unique humidity levels.

Light Show Mode

Use the red switch at the rear of the humidifier to turn the multicolored LED nightlights

on and off.

Auto Shut Off

This humidifier has a safety system that switches it off before the water runs out. When

the water is almost empty, a red light will appear above the mist control knob. This safety

feature protects the nebulizer from being damaged due to lack of water and lets you

know it’s time to add more water.

Aromatherapy – For Adult Use Only:

If using this humidifier in an adult’s room or a home without children, adding two to three

drops of your favorite essential oils into the water tank allows the humidifier to fill the

room with a pleasant aroma. NOTE: If using essential oils, you may need to clean the

humidifier more frequently as these oils can leave a residue.

Cleaning and Maintenance

IMPORTANT: Before any cleaning, always switch the appliance off and unplug it.

1. Remove the basket from the water tank by rotating counter-clockwise.

2. Remove the basket ring from the basket.

3. Apart from the electrical controls, any part of the humidifier may be cleaned with a

soft damp cloth and then wiped with a dry cloth.

NOTE: Check the nebulizer for mineral deposits. These can happen over time and are

especially common in areas with hard water. These deposits will influence the

humidification process and gradually decrease performance.

4. To clean mineral deposits from the nebulizer, dampen a soft cloth with vinegar and

wipe the nebulizer gently until the mineral deposit disappears. You may also use a very

soft brush, like a toothbrush, to gently remove the deposits.

5. Use a dry clean cloth to rub it down.

IMPORTANT: Do NOT use hard or abrasive objects to clean the nebulizer. NEVER use

chemical products to clean the nebulizer.

6. After cleaning, place the basket ring back inside of the basket. Reinstall the basket

by rotating clockwise.

For optimal performance, we recommend using distilled water and cleaning the

humidifier once a week.

Notes about Humidity

1. It is best to keep the humidity level at about 30-50 percent of relative humidity.

2. The level of humidity needed will vary from room to room and with changing room

conditions.

3. In cold weather, especially in unventilated areas, windows and even some walls may

fog or develop frost from excessive indoor humidity. If this occurs, reduce the mist

setting to avoid damage from condensed water dripping on windows, walls or

furniture.

4. To prevent excessive humidity, especially in small rooms, leave the room door open

and use a lower mist setting.

This device complies with Part 18 of the FCC Rules. Operation is subject to the

following two conditions:

(1) This device may not cause harmful interference.

(2) This device must accept any interference received, including interference that may

cause undesired operation.

FCC WARNING: Changes or modifications to this unit not expressly approved by the

party responsible for compliance could void the user’s authority to operate the

equipment.

FCC NOTE: This equipment has been tested and found to comply with the limits for

Consumer ISM equipment, pursuant to Part 18 of the FCC Rules. These limits are

designed to provide reasonable protection against harmful interference in a residential

installation. This equipment generates, uses and can radiate radio frequency energy

and, if not installed and used in accordance with the instructions, may cause harmful

interference to radio communications. However, there is no guarantee that interference

will not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by turning the

equipment off and on, the user is encouraged to try to correct the interference by one

or more of the following measures:

• Reorient or locate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected

• Consult the dealer or an experienced radio/TV technician for help.

CAN ICES-1(B)/NMB-1(B)

DISTRUBUTED BY TOMY

THE FIRST YEARS is the U.S. registered trademark of TOMY

Y7817 201208

Capacity: 2.2 L (0.58 gal)

Main material: PP

Rated voltage: 120V AC, 60HZ

Output: about 130 ml/h (4.4 oz/h)

If you have a warranty question or any other customer care questions, please contact

our Customer Care team by calling 800-704-8697 or by e-mailing cs@tomy.com.

You can also visit our warranty page at: https://us.tomy.com/warranty

CAUTION

• Adult assembly is required. Keep small parts away from children.

When using electrical appliances, basic precautions should always be followed to

reduce the risk of fire, electric shock and injury to person, including the following:

• Use appliance only as described in this manual. Any other use not recommended

by the manufacturer may cause fire, electric shock, or injury to persons. The use

of attachments not recommended or sold by the manufacturer may cause

hazards.

• To avoid fire or shock hazard, plug the appliance directly into a

120V AC electrical outlet. DO NOT plug in the cord with wet hands.

• Keep the cord out of heavy traffic areas. To avoid fire hazard,

NEVER put the cord under rugs or near heat registers.

• DO NOT operate any appliance with a damaged cord or plug, after the appliance

malfunctions, or if it has been dropped or damaged in any manner. Return

appliance to nearest authorized service facility for examination, electrical or

mechanical adjustment, or repair.

• DO NOT attempt to repair or adjust any electrical or mechanical functions

on this unit. The inside of the unit contains no user serviceable parts.

All servicing should be performed by qualified personnel only.

• No serviceable parts inside.

• DO NOT use outdoors.

• DO NOT let cord hang over edge of table or counter, or touch hot surfaces.

• The use of accessory attachments is not recommended by the appliance

manufacturer as they may cause injuries.

• DO NOT use appliance for other than intended use.

• Humidifier should be unplugged when not in use.

• DO NOT place humidiﬁer near heat sources such as stoves, radiators, and

heaters. DO locate your humidiﬁer on an inside wall near an electrical outlet.

The humidifier should be at least 4 inches (10 cm) away from the wall for best

results. DO NOT allow the mist outlets to directly face the wall. Moisture could

cause damage, particularly to wallpaper.

• NEVER place humidifier in an area where it is accessible to children. NEVER use

humidifier in a closed room, particularly where a child may be sleeping, resting, or

laying (a closed room may result in excessive humidity).

• DO NOT attempt to refill humidifier without first unplugging the unit from

its electrical outlet. Failure to heed this warning may cause personal injury.

Be sure to unplug the unit by pulling on the plug and not the cord. NEVER

tilt, move, or attempt to empty unit while it is operating. Shut off and

unplug before moving the unit.

• DO NOT block air inlet or outlet while unit is running.

• Always place humidifier on a firm, flat, level surface. A waterproof mat or

pad is recommended for use under the humidifier. NEVER place it on a rug

or carpet, or on a finished floor that may be damaged by exposure to water or

moisture. To prevent damage to surfaces, DO NOT place humidifier under

overhanging surfaces.

• DO NOT use humidifier in an area where humidity level is in excess of 50%. Use a

hygrometer, available at your local retailer, to measure the humidity. Turn

humidifier off if excessive humidity occurs.

• DO NOT pour water in any openings other than the water tank.

• NEVER place base under water flow or immerse in liquids.

• NEVER operate unit without water in the tank.

• NEVER touch exposed metal diaphragm in base after use. Metal will be HOT.

• This humidifier requires daily and weekly maintenance to operate appropriately.

Refer to cleaning and maintenance procedures. Use only cleaners recommended

by the manufacturer.

• NEVER drop or insert any object into any openings.

WARNING:

ALWAYS turn off appliance and unplug to clean.

DO NOT immerse appliance in water.

DO NOT use scouring pads, solvents or abrasive cleaners to clean.
