Toner OLS1315A User manual

www.tonercable.com
OLS1315A
Optical Light Source
User’s Manual

- 2 -
www.tonercable.com
OLS1315A
Optical Light Source
Content
1. Overview…………………………………………………………………….…….2
2. Features………………………….……………………….......…………………..2
3. Applications……….……………………….……………..……………………...2
4. Specifications………….…………………………….………………………......3
5. Standard Packages…………………………………….………………….…….3
6. Panel & Functions……………………………………………………….………4
7. Operation and Notes……………………………..…………………….…….....5
8. Maintenance………………………………….…………………………….……..5
9. Trouble –shooting………………………………………………………….…….6
10. Warranty and Service……………………………………………….………......6

- 3 -
www.tonercable.com
OLS1315A
Optical Light Source
The information contained in this document is assumed to be correct and current. The
manufacturer is not responsible for errors of omissions and reserves the right to
change specifications at any time without notice.
1. Overview
The handheld Light Source is designed to meet the high-end requirements. It
features portable size, stable output wavelength and high stability of output
power. Optional frequency mode is easily for the identification of the optical fiber.
It is able to provide single to quad-wavelength output for the single mode fiber or
multimode fiber. Together with our Handheld Power Meter, they combine a
perfect test solution for the installation and maintenance of fiber optic projects.
2. Features
Locates breaks, Micro-bends even through jacketed fibers
End-to-end fiber identification
Stabilized Output Power
High Reliability
3. Applications
Telecommunication networks
CATV networks
Cabling systems engineering
Research and education

- 4 -
www.tonercable.com
OLS1315A
Optical Light Source
4. Technical Specifications
Product
Handheld Light Source
Operating Wavelength (nm)
650
1310/1550
850/1300
Max
quad-wavelength
combination
Emitter
FP- LD
Output Power (dBm)
0
-7
-7
Modulation
CW,2Hz
CW, 270Hz, 1KHz ,2KHz,
Fiber Type
SM/MM
Optical Interface
FCuniversal adapter
FC/PC
Power Supply
1.5V batteries
Rechargeable Time (h)
12 (typical)
Operating Temperature (℃)
-10 ~ +60
Storage Temperature (℃)
-25 ~ +70
Battery Operating Time (h)
45
Weight (g)
180
Dimension (mm)
152 x 74x26
Ordering information:
(Three-Wavelength) Handheld Light Source -X-Y
X: Emitter Type, FP-LD,DFB. LED;
Y: Operating Wavelength: 850/1300nm,1310/1550nm
5. Standard Packages
Unpack this Handheld Light Source package and check that the following
standard components are included with your order.
The Handheld Light Source…..……….…………………………………….…..….1
Manual…………………………………………………………………….…...…..….1
Protective Holster……………………………………………….……………………1
Cleaning Swabs..……………………………………………….………………....…1
1.5V battery…………………………………………………….…………………..…3
Portable Bag………………………………………………………………..………...1
Your order has been provided with the safest possible packing, but shipping damage
does occasionally occur. Inspect your order carefully for damage that may have
occurred during shipment. If you discover any shipping damage, please notify the
carrier and us immediately.

- 5 -
www.tonercable.com
OLS1315A
Optical Light Source
6. Panels and Functions
Keys and Functions:
(1) The output interface: FC/PC connector.
(2) Liquid Crystal Display: For wavelength display; Modulation indicator.
(3) “ON/OFF” Key: Press it to turn the Handheld Light Source Light on or off.
(4) “Wave”key:Press this key to switch the wavelength.
(5) ”Mode” key: Continuous wavelength light output or modulated light output
can be selected by pushing “Mode” key. When modulated light output is
selected, a dot appears in LCD.
7. Operation
7.1 Press “ON/OFF” key about one second to switch on this unit.
7.2 To use this light source.
1. Connection: FC/PC connector.
2. Wavelength selection: Press “Wave”key for wavelength selection.
3. Modulation: Press the “MODE” key, choose the “CW”,”270Hz”,”1KHz” or
“2KHz” light output,.
7.4 Switch off: Press “ON/OFF” key to turn the unit off.
3
5
4
2
1

- 6 -
www.tonercable.com
OLS1315A
Optical Light Source
8. Maintenance
8.1 If the Dual-wavelength Handheld Light Source is not used for a long time,
the light output port must be protected with the dustproof hat.
8.2 When the Dual-wavelength Handheld Light Source is used for a period of
time, the output port may be polluted. It results in the output power decreasing.
So the connector must be cleaned with alcohol cotton. If it couldn’t be cleaned,
please send it to the manufacturer.
8.3 Once not using for a long time, please take out the battery.
8.4 Don’t take apart the Dual-wavelength Handheld Light Source please. If there
are any other troubles, please contact with the manufacturer.
8.5 DO NOT look into the Handheld Light Source adapters directly when light
source is on, laser output is harm to your eyes.
9. Trouble-shooting
No.
Problem
Measures
1
The output light is unstable or
decreases rapidly while operation.
Replace battery or re-charge
battery.
2
Output power is fluctuating.
First warm it up for 15 minutes,
then operate it.
3
The output port is polluted.
Clean the connector with alcohol
smoothly or contact with supplier.

- 7 -
www.tonercable.com
OLS1315A
Optical Light Source
10. Warranties and Service
Caution: Repair the Handheld Light Source in the field is NOT recommended.
10.1 18 months Warranty for our series Dual-Wavelength Handheld Light Source,
We warrants that every Dual-wavelength Handheld Light Source will be free
from defects in material and workmanship for a period of 18 months. This
warranty covers the original user only and is not transferable. Should the device
fail at any time during this warranty period, We will, at its sole discretion, replace,
repair or refund the purchase price of the product.
This warranty is limited to defects in workmanship and materials and does not
cover damage from accident, acts of God, neglect, contamination, misuse or
abnormal conditions of operation or handling.
To return a defective product for warranty coverage, contact us for a written
authorization. Failure to properly protect the product during shipping may avoid
this warranty.
We will pay return transportation for products repaired or replace under the
warranty. Before making repairs not covered the warranty, We will estimate cost
and obtain authorization, then invoice for repair and return transportation. We
reserves the right to charge for all testing and shipping costs incurred, if test
results determine that the device is without defect.
