Tongke Electronics T8 User manual

SAFETY PRECAUTIONS
* This product is designed for use in moderate climates. Do not use or
install this unit where it would be exposed to direct sunlight or in
extremely hot temperatures, or near a radiator, stove or appliance that
produces heat.
* Do not take this unit into the bathroom, or near a swimming pool. Do
not use it where it would expose to water, moisture, dripping or
splashing.
* No objects filled with liquids, such as vases, should be placed on the
product.
* No naked flame sources, such as candles, should be placed on the
product.
* If water gets inside the unit. Unplug the power cord from the supply
socket and consult your dealer.
* Do not handle the power cord with wet hands. To avoid electric shock,
NEVER touch any internal parts. Repairs/Servicing should be left too a
qualified service person.
* When connecting or disconnecting from the mains supply, hold the
plug, not the cord. Pulling the cord may damage it and could be
dangerous.
* Do not drop the unit, spill liquid into it or allow objects to fall in it.
* If the unit fails to operate, disconnect from the mains and consult a
qualified service person.
* When plugged in, a very small current will flow. To save electricity
and for safety when not using the unit for an extended period of time,
it is recommended that the product is completely disconnected at the
AC mains socket.
* Do not bend the cord sharply, pull or twist it.
* Do not modify the power cord in any manner.
* Do not insert any metallic object into the unit.
* Unplug the power cord when there is the possibility of lighting.
* In case of malfunction due to electrostatic discharge just reset the
product (reconnect of power source may be required) to resume
normal operation.

1
We certify that the power supply is used as a device for
disconnecting the power distribution network, which should stay
easily accessible.
POSITIONING THE UNIT
* A minimum distance of 6 INCHES must be maintained to provide
sufficient ventilation.
* Allow adequate ventilation for the unit. Ventilation should not be
impeded by covering the ventilation openings with items such as
newspapers, table cloths, curtains etc. Do not stand it on a thick pile
carpet, or install it in a place with poor air flow.
* Place the unit on a flat even surface.
* Do not use the unit in excessively hot, cold, dusty, damp or humid
place.
* Condensation may form inside the CD player if the unit is left
anywhere warm and damp, or if you move the unit from somewhere
cold (e.g. Your car boot) to a warm room. In this case, let the unit
stand for 1-2 hours, or gradually increase the room temperature so
the unit is dry before you use it.
* Do not place it where it could be subject to vibration.
* Do not place it where it could be magnetised by a magnet or speaker
since there are magnets in the speakers, do not place tapes or
magnetic cards on them as recorded data could be erased.
* When this unit is used near a TV, the TV picture could be distorted. If
this happens, move the unit away from the TV. If this does not correct
the situation, avoid using the unit when the TV is turned on.
* Keep the CD door closed so the lens is not contaminated by dust. Do
not touch the lens.

2
SAFETY MECHANISM
This unit incorporates a safety interlock mechanism which switches the
laser beam on and off, so that when the disc holder is open, the laser
beam stops automatically.
This set employs an optical laser beam system in the CD mechanism designed with
built-in safeguards. Do not attempt to disassemble. Exposure to this invisible laser
light beam may be harmful a human eye. This is a Class 1 laser product. Use of
controls, adjustments or procedures other than those specified here in may result in
hazardous laser light beam exposure. This compact disc player should not be adjusted
or repaired by anyone except qualified service personnel. The laser mechanism in the
set corresponds to the stylus (needle) of a record player. Although this product uses a
laser pick-up lens, it is completely safe when operated according to directions.

3
LOCATION OF CONTROLS

4
FRONT VIEW
1. Turntable Cover
7. AM/FM Button
2. FM Radio Knob
8. CD Open/Close Button
3. Volume Knob; Power ON/OFF
9. Stop Button
4. Function Knob
(CD/PH/FM/AUX/BT/TAPE)
10. Play/Pause Button
5. PREV Button
11.LED Display
6. Next Button
12. CD Door
REAR VIEW
13. AUX input 14. DC IN port
22. AM/FM Antenna
TOP VIEW
15. Turntable pickup 19. Control Perch
16. Tone Arm 20. 45 RPM Adaptor
17. Speed Control Switch 21. Turntable
18. Tone Arm Lock
TAPE SIDE VIEW
23. Tape Eject/ Fast-Forward Button
24. Tape entrance

5
LED DISPLAY
PREPARATION FOR USE
Carefully unpack the Main unit from its carton (do not attempt to
connect anything at this stage).
You should have the following items:
Packing included
1. User Manual
2. Main Unit.
3. Adaptor
4. AUX-IN cable

6
If any of these items are missing, consult your dealer. Keep any
packaging in case you want to transport the main unit at some later
date.
Connections
* Connect the Adaptor to the DC outlet.
* Connect the AUX-IN cable to the R/L outlet.
* Unwind the FM antenna.
Adjusting the sound
To adjust the sound, turn the Volume Knob located on the Left side of
your system in any mode.
USING THE CD PLAYER
Loading CDs
-Switch ON/OFF button to ON position. Set the Function Knob to the
CD position.
- Press the OPEN/CLOSE button to open the CD door. Do not force open
the CD door by hand at any time.
- Place the CD in the compartment with the label side facing upwards.
- Press OPEN/CLOS to Close the CD door.
Notes :
* Do not put anything other than a CD in the compartment. Other
objects can damage the mechanism.
* Do not force open/close the CD door by hand at any time.
* Keep the CD door closed when not in use to prevent dirt and dust
from getting into the mechanism.
* Never insert more than one CD at a time.
If a disc is deeply scratched or too dirty, it may not play.

7
Playing CDs
Press PLAY/PAUSE button to play/pause, when pause, LED screen will
indicate II.
- Press Stop Button, will stop playing.
- To resume play, press the Play/Pause Button again.
- Press the Play/Pause Button again.
- Press the PREV/NEXT Button to enter into last/next songs.
USING THE TURNTABLE
- Switch ON/OFF button to ON position. Set the Function Knob to the
PH (phonograph) position..
-Place the record on the turntable.
-Select the speed of record: 33, 45,
78rpm according to vinyl to played.
-Remove the stylus guard and push
the lift lever upward to raise the
tone arm from the arm park, and then move the cartridge holder over
the record gently, now the platter will run automatically .Then put down
the lever, the tone arm would drop and touch record surface gently.
Now users can enjoy their favorite songs.
-Push the arm lift lever up to raise the arm, now platter will still running
but play will pause. To continue the play, user just need to put down the
lever
How to replace the stylus
To replace the needle, please refer to the instructions below.
Removing the needle form the cartridge

8
a. Place a screwdriver at the tip of the needle heads hell and push
downwards in the direction shown in sketch “A”
b. Remove the needle head shell by pulling it forwards and pushing
downwards.
Inserting the needle
c. Hold the tip of the needle head shell and insert it by pressing in the
direction illustrated by “B”
d. Push the needle head shell upwards in the direction illustrated by “C”
until the needle locks into the tip position.
Cleaning the Lens
A dirty lens will cause sound skipping and, if the lens is very dirty, the
CD may not work.
USING THE AM/FM RADIO
-Switch ON/OFF button to ON position.
-Set the Function Knob to the FM position.
-Turn the FM radio Knob to select the FM channel you want.
-Switch AM/FM button to AM.

9
-Turn the FM radio Knob to select the AM channel you want.
Antenna
For best FM reception, extend the wire antenna located at the back of
the unit.
Move it around until you get the best FM reception.
AUX-IN OPERATION
-Switch ON/OFF button to ON position.
-Set the Function Knob to the AUXposition..
-Connect the two ends of the included Audio cable to the LINE IN jack
on the back of the speaker(white end into white slot, red end into red
slot), and the other end of the cable to the output jack on your mobile
phone or tablet etc.
BLUETOOTH FUNCTION OPERATION
-Switch ON/OFF button to ON position.
-Set the Function Knob to the BT (Bluetooth) position.
- The red BLUE will quickly flash in the LED screen.
- Keep the turntable and Bluetooth enable device within 3 feet of each
other during the pairing process.
- Set your Bluetooth enable device to search for Bluetooth devices.
- When the Bluetooth enable device finds the turntable, select
RETRO10E-BTH from the list of the found devices.
- If required, enter the password 0000. Select OK or Yes to pair the two
units.
- After a successful pairing, the red “BLUE”will solid in the LED screen.
USING THE CASSETTE PLAYER

10
-Switch ON/OFF button to ON position.
-Set the Function Knob to the TAPE position.
-Put the tape into the right of tape seat by your hand, then it can work.
-Push the tape button of Grade1, it can go faster. When you push
Grade2, The tape will come out.
-When tape is finish playing, it will stop automatically.
TECHNICAL SPECIFICATIONS
Power Supply AC adaptor
5V 2000mAh
Power Consumption
10W
Audio Output Power
2 x 5 Watts
Unit Dimension
400 x 300 x 215mm
Net Weight
6.0kg
Radio frequency coverage
AM
530 - 1620KHZ
FM
88 - 108 MHz
CD Player
Frequency Response
100Hz - 16 KHz
Bluetooth 2.1
- Bluetooth profiles: A2DP, AVRCP
- Bluetooth range: Line of sight, 10M or 30FT
Remarks: The manufacturer reserves the right to amend the specification
without prior notice.

11
DETAILS AND PRECAUTIONS ON THE USE OF BATTERIES
- Discard a used battery in nature or garbage pollutes and prevents the
recovery of recyclable materials.
It is therefore important to limit consumption of batteries and follow
these guidelines:
focus on alkaline batteries (that last longer than the saline
batteries) and when possible, rechargeable batteries
deposit batteries and accumulators in specific containers
arranged among traders.
For example, metals will be valued and polluted the environment
because they contain heavy metals hazardous to health and the
environment primarily (cadmium and nickel)
- The piles must installation by respecting the polarity indicated on the
apparatus and the pile.
An incorrect positioning can is to damage the apparatus, is to cause
escapes on the level of the pile, is to the extreme to cause a fire or the
explosion of the pile.
- To ensure proper operation, the batteries must be in good condition.
In case of abnormality in the functioning of the device, put fresh
batteries
- Never attempt to recharge non-rechargeable batteries. They could
run, warm up, causing a fire or explosion.
- Replace all batteries at the same time. Never mix zinc batteries with
alkaline batteries or rechargeable batteries
- The batteries must be removed from the device
- Also, remove the batteries from your device if you do not use it for a
long time, if the batteries may leak and cause damage.
- Never try to short-circuit the battery terminals
- Never dispose of batteries in fire, they might explode
- Charging of batteries is to be performed by an adult.
- Remove batteries from the device before reloading.

12
- We recommend an adult to supervise children when they change the
batteries so that these instructions are complied with or to make
himself the replacement of batteries.
- If a battery is swallowed, immediately consult a doctor or poison
control center nearest you.
Do not forget to carry the product with you.
NOTE: This equipment has been tested and found to comply with
the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These
limits are
designed to provide reasonable protection against harmful
interference in a
residential installation. This equipment generates uses and can
radiate radio
frequency energy and, if not installed and used in accordance
with the instructions,
may cause harmful interference to radio communications.
However, there is no
guarantee that interference will not occur in a particular
installation. If this
equipment does cause harmful interference to radio or television
reception, which
can be determined by turning the equipment off and on, the user
is encouraged to
try to correct the interference by one or more of the following

13
measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from
that to which the
receiver is connected.
-Consult the dealer or an experienced radio/TV technician for
help
Changes or modifications not expressly approved by the party
responsible for compliance
could void the user's authority to operate the equipment.
This device complies with Part
15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including
interference that may
cause undesired operation.
