Silvercrest KH 2430 User manual

■ USB RECORD PLAYER
KOMPERNASS GMBH ⋅ BURGSTRASSE 21 ⋅ D-44867 BOCHUM
www.kompernass.com
ID-Nr.: KH2430 07/2009-V3
USB RECORD PLAYER
Operating instructions
USB-PLADESPILLER
Betjeningsvejledning
USB-GRAMOFON
Navodila za uporabo
3C + 4C
KH 2430

Operating instructions................................................................... 5
Betjeningsvejledning ...................................................................35
Navodila za uporabo.................................................................65
DK
KH 2430
8
5
6
2
3
4
7
9
10
11
12
13
14
15 16 17
GB
SI

5
USB Record Player KH 2430
GB
Index
Introduction . . . . . . . . . . . . . .6
Preface . . . . . . . . . . . . . . . . . . . . . . . 6
Information for these operating
instructions . . . . . . . . . . . . . . . . . . . . 6
Copyright . . . . . . . . . . . . . . . . . . . . . 6
Limited liability . . . . . . . . . . . . . . . . . 7
Warnings . . . . . . . . . . . . . . . . . . . . . 7
Proper use. . . . . . . . . . . . . . . . . . . . . 8
Safety . . . . . . . . . . . . . . . . . . .9
Danger from electric current . . . . . . 9
Basic Safety Instructions . . . . . . . . .10
Setting up and connecting . .11
to the power supply . . . . . . . . . . . .11
Safety instructions. . . . . . . . . . . . . .11
Package contents and
transportation inspection . . . . . . . .11
Disposal of packaging . . . . . . . . .12
Requirements for the setup
location . . . . . . . . . . . . . . . . . . . . .12
Before initial use . . . . . . . . . . . . . .13
Electrical connection . . . . . . . . . . .13
Connection to an external
amplifier . . . . . . . . . . . . . . . . . . . .13
Connection to a computer . . . . . . .14
Installation and configuration
of the Programme Audacity . . . . . .14
Operating components
(see fold out sides) . . . . . . . .19
Audacity programme . . . . . . . . . . .20
Service and operation . . . . .21
Switching the device on and off. . .21
Starting the Audacity programme .21
Starting playback of records . . . . .21
Operation during playback . . . . . .22
Setting recording level . . . . . . . . . .22
Recording with the Audacity
programme . . . . . . . . . . . . . . . . . .23
Exporting recordings . . . . . . . . . . .24
Maintenance . . . . . . . . . . . . .26
Removing the cartridge
and needle . . . . . . . . . . . . . . . . . .26
Installing a new needle . . . . . . . . .26
Cleaning . . . . . . . . . . . . . . . .27
Safety instructions. . . . . . . . . . . . . .27
Cleaning. . . . . . . . . . . . . . . . . . . . .27
Troubleshooting . . . . . . . . . .27
Safety instructions. . . . . . . . . . . . . .27
Malfunction causes and remedies .28
Storage/Disposal . . . . . . . .29
Storage. . . . . . . . . . . . . . . . . . . . . .29
Disposing of the device . . . . . . . . .29
Appendix . . . . . . . . . . . . . . .30
Technical data . . . . . . . . . . . . . . . .30
Notes on the
EG conformity declaration . . . . . .31
Warranty . . . . . . . . . . . . . . . . . . . .31
Importer . . . . . . . . . . . . . . . . . . . . .31

6
Introduction
USB Record Player KH 2430
GB Introduction
Preface
Dear customer,
by purchasing the record turntable KH 2430 you have decided on a quality product
from SilverCrest which, in terms of technology and functionality, meets the most
up-to-date development standards.
Read the information included here so that you can quickly familiarize yourself
with your device and thus make full use of its functions.
We wish you a great deal of enjoyable use.
Information for these operating instructions
These operating instructions are a component of the record turntable KH 2430
(henceforth designated as the device) and supplies you with important informa-
tion for intended use, safety, installation and connection as well as operation of
the device.
The operating instructions must be constantly kept available close to the device.
They are to be read and used by anyone assigned to install, service and repair
faults in the device.
Keep these operating instructions and hand them over with the device to any future
owners.
Copyright
This documentation is copyright protected.
Any duplication and/or reprinting, entirely or partially, as well as reproduction of
illustrations, also in modified form, is only permitted with written consent from the
manufacturer.

7
Introduction
USB Record Player KH 2430
GB
Limited liability
All technical information, data and information for installation, connection and
operation contained in these operating instructions correspond to the latest at time
of printing and, to the best of our knowledge, take into account our previous experi-
ence and know-how.
No claims can be derived from the details, illustrations and descriptions in these
instructions.
The manufacturer assumes no responsibility for damage caused by failure to observe
the instrutions, improper use, inappropriate repairs, making unauthorized changes
or for using unapproved replacement parts.
Warnings
In the present operation insructions the following warnings are used:
DANGER
A warning of this danger level signifies a life threatening
dangerous situation.
If the dangerous situation is not avoided it can lead to serious injury or death.
The directives in this warning are there in order to avoid serious personal►
injuries or death.
WARNING
A warning of this danger level signifies a possible dangerous
situation.
If the dangerous situation is not avoided it can lead to injuries.
The directives in this warning are there in order to avoid personal injuries.►

8
Introduction
USB Record Player KH 2430
GB IMPORTANT
A warning of this danger level signifies possible property
damage.
If the situation is not avoided it can lead to property damage.
The directives in this warning are there in order to avoid property damage.►
NOTE
A note signifies additional information that assists in the handling of the►
device.
Proper use
This device is intended for the playback of records only. In addition you can con-
nect the device to a computer that makes recordings of records and saves these
as files in various formats.
This device is not intended for any other use or for uses beyond those mentioned.
WARNING
Danger from unintended use!
Danger can arise from the device if used for unintended purposes and/or
other types of use.
Use the device exclusively for intended purposes.►
Observe the procedures described in these operating instructions.►
Claims of any kind for damage resulting from unintended use will not be accepted.
The operator alone bears liability.

9
Safety
USB Record Player KH 2430
GB
Safety
In this chapter you receive important safety information regarding handling of
the device.
This device complies with the statutory safety regulations. Incorrect usage can,
however, lead to personal injury and property damage.
Danger from electric current
DANGER
Danger to life from electrical current!
Danger to life exists from contact with live electrical wires or
components!
Observe the following safety information in order to avoid the danger of
electric shock:
Do not use the device if the power cable or the power plug is damaged.►
Before using the device again have a new connection cable installed by an►
authorized specialist.
Under no circumstances open the device's casing. The risk of electric shock►
exists from touching voltage carrying connections and changing the electrical/
mechanical construction.

10
Safety
USB Record Player KH 2430
GB Basic Safety Instructions
For safe handling of the device observe the following safety information:
Before use check the device for externally visible damage. Do not operate a■
damaged device or one that has been dropped.
If the cable or connections are damaged have them exchanged by an author-■
ized specialist or the customer service department.
Persons who, due to their physical, intellectual or motor abilities, are incapable■
of operating the device safely may only use the device under supervision or
direction from a responsible person.
Only permit children to use the device under supervision.■
Repairs should only be carried out by authorized specialist companies or by the■
customer service department. Incorrect repairs can result in significant dangers
for the user. In addition warranty claims become invalid.
A repair to the device during the warranty period may only be carried out by■
a customer service department authorized by the manufacturer otherwise no
additional warranty claims can be considered for subsequent damage.
Defective components may only be replaced with original replacement parts.■
Only by using original replacement parts can you guarantee that the safety
requirements are complied with.
Protect the device from moisture and liquid penetration.■
Always pull the cord from the mains power by the plug and not by the cable.■
Do not carry the device by the connection cable.■
Do not allow the connection cable to hang down. The danger exists of pulling■
the device down by the cable.
Avoid direct sunlight.■
Do not use the device in the vicinity of open flames.■
In the case of malfunctions and during thunderstorms pull the power plug out■
of the mains power socket.
Do not spray and/or drip water on the device and do not place any object filled■
with liquid, such as vases or open drink containers, on or near the device.

11
Setting up and connecting
USB Record Player KH 2430
GB
Setting up and connecting
to the power supply
Safety instructions
WARNING
When operating the device personal injury and property
damage can occur!
To avoid danger observe the following safety instructions:
Pakaging materials may not be used as playthings. There is a risk of►
suffocation!
Observe the information regarding the setup location requirements as well►
as the device's electrical connection to avoid personal injury and property
damage.
Package contents and transportation inspection
The device is delivered with the following components as standard:
Record turntable●
USB connection cable●
Adapter for single records (45's)●
Audacity programme CD●
Operating instructions●
NOTE
Check the contents to make sure everything is there and for visible damage.►
If the contents are not complete or are damaged due to defective packaging►
or through transportation contact the service hotline (see warranty card).

12
Setting up and connecting
USB Record Player KH 2430
GB Disposal of packaging
The packaging protects the device from transpot damages. The packaging
materials are selected from the point of view of their environmental friendliness
and disposal technology and are therefore recyclable.
The recirculation of packaging into the material circuit saves on raw material and
reduces generated waste. Dispose of packaging material that is no longer needed
according to the regionally established regulations.
NOTE
If possible preserve the device's original packaging during the warranty►
period so that, in the event of a warranty claim, you can package the
device properly for return.
Requirements for the setup location
For safe and trouble free operation of the device the setup location must fulfill the
following provisions:
The device must be placed on a firm, flat and level base.■
Do not place the device in a hot, wet or very damp environment or in the vicinity■
of flammable materials.
Do not remove the device's feet. Otherwise proper air circulation can not be■
guaranteed.
The mains power socket must be easily accessible so that the power cable can■
be easily disconnected in an emergency.
The surface areas of furniture may possibly contain components that could affect■
the device's rubber feet, softening them. If necessary place a base under the
device's feet.
Operating temperature range: +5 to +40 °C■
Humidity (no condensation): 5 - 90 %■

13
Setting up and connecting
USB Record Player KH 2430
GB
Before initial use
The following transportation protections are attached to the device:
Plastic band for holding down the pick-up arm–
Transport screw–9for securing the turntable
Protective cover for the needle–
Styrofoam blocks–
Information sheet for the turntable–
Remove all packaging material and all transport protection from the device.■
Release the turntable's transport protection by tightening the■ transport screw 9.
Electrical connection
Observe the following electrical connection for safe and failure free operation of
the device:
Before connecting the device compare the connection data (voltage and■
frequency) with that on the rating plate of your electric supply. This data must
agree in order to avoid damaging the device.
Make sure that the power cable is not damaged and is not laying over hot■
surfaces and/or sharp edges.
The connection cable must not be stretched tight.■
Connection to an external amplifier
Connect both cinch plugs of the LINE-OUT connection cable16 to the AUX
input of an external amplifier. For this follow the operating instructions for the
external amplifier.

14
Setting up and connecting
USB Record Player KH 2430
GB Connection to a computer
System prerequisites
You will need a computer with a vacant USB port and with either Windows®XP
or Windows®Vista operating system from Microsoft®.
Connection
Connect the USB cable to the USB port15 and to a USB port on your com-
puter. The device will be automatically recognized by the operating system
and all necessary drivers will be installed.
NOTE
If you connect the device to another USB port the drivers will be installed►
again.
Installation and configuration of the Programme Audacity
NOTE
In these operating instructions only the settings and programme components►
are described that you will need for recording and converting your records.
Further information can be found on the internet under the address
http://audacity.sourceforge.net.
The illustrations are applicable to the operating system Microsoft®►
Windows® XP. The screen image can differ, depending on the display
settings, with other operating systems.
Installation
Place the supplied Audacity pro-
gramme CD in your computer's CD
drive. The installation will begin au-
tomatically and the window "Setup
- Audacity" is shown.
Click on the button "Next >".

15
Setting up and connecting
USB Record Player KH 2430
GB
NOTE
If you have switched off the auto start function and the installation process does►
not start automatically you can start the installation process by double clicking
on the file "audacity-win-1.2.6.exe" in the directory " Audacity_for_WIN".
The window "License Agreement" is shown.
Select "I accept the agreement"
and click on the button "Next >".
The window "Information" is shown.
Click on the button "Next >".
The window for the selection of installation
directory is shown.
Select the desired installation di-
rectory and click on the button
"Next >".

16
Setting up and connecting
USB Record Player KH 2430
GB The window for the selection of further
installation options is shown.
Select the desired options and click
on the button "Next >".
All installation settings are shown.
Click on the button "Install".
The programme will now be installed.
The installation progress is shown.
Then is shown that the installation has been
completed successfully.
Click on the button "Next >". If the
option "Launch Audacity" is selected
the programme will start.

17
Setting up and connecting
USB Record Player KH 2430
GB
Configuration
Copy the file "lame_enc.dll" from the directory "Audacity_for_WIN" on the
Audacity programme CD to your computer's hard drive, i.e. to the Audacity
installation directory.
You start the Audacity programme by double clicking on the programme icon
on the desktop or by selecting the corresponding input from the start menu.
When the programme starts for the first time after
installation you will be asked to select the language.
Select the desired language and click on the
button "OK".
NOTE
The language setting can be changed any time at a later date in the►
programme settings.
Select the menu option "Settings" in the "Process" menu.
Select the tab "Audio E/A".
Carry out the following settings
in the section "Record":
Device: "USB Audio CODEC"–
Channels: "2 (Stereo)"–
Select the option "Listen to new
tracks during playback" if the
record is to be played back
simultaneously when recording.
The option "USB Audio CODEC" is only
available if you have correctly connected
the turntable before the programme
starts.

18
Setting up and connecting
USB Record Player KH 2430
GB Select the tab "File format".
Click on the button "Search
library".
An information window will be
shown.
Click on the button "Yes".
Select the directory in which the
file "lame_enc.dll" is located.
Select the file and click on the
button "Open".
Select the bitrate for the MP3
files.
Click on the button "OK" to
finalise the setting.

19
Operating components
USB Record Player KH 2430
GB
Operating components (see fold out sides)
Dust cover
2Stop playback button
3End playback button
4Continue playback button
5Turntable
6POWER switch: Device on/off switch
7Adapter for single records (45's)
8USB connection cable
9Transport securing screw/Turntable adjustment
Transport position: Screw loosened
Operating position: Screw tightened to end stop.
10 Pick-up arm security lever
11 Pick-up arm elevating lever
12 Turntable speed selection switch: 33 ⅓, 45 or 78 Rev/min
13 Pick-up arm
14 Needle with cartridge
15 USB port
16 LINE-OUT connection cable for connection of an amplifier (Cinch)
17 Mains power connection cable

20
Operating components
USB Record Player KH 2430
GB Audacity programme
1 3 4
2
5
1 Menu bar
2 Tool bars
3 Time indicators
4 Project zones (Recordings will be filed as sound tracks)
5 Status bar

21
Service and operation
USB Record Player KH 2430
GB
Service and operation
In this chapter you will receive important information for the service and operation
of the device.
Switching the device on and off
To switch the device on activate the switchPOWER 6.
To switch the device off activate the switchPOWER 6again.
Starting the Audacity programme
You start the Audacity programme by double clicking on the programme icon
on the desktop or by selecting the corresponding input from the start menu.
Starting playback of records
Open the dust cover.
Place the record onto the turntable5.
NOTE
For playing records with a large centre hole (Singles) you use the adapter► 7.
With the Turntable speed selection switch12 set the required speed.
Release the security lever10 from the pick-up arm 13 .
Move the pick-up arm lever11 to the rear position to raise the pick-up arm.
Swing the pick-up arm to the desired position.
Move the pick-up arm lever11 to the forward position to lower the pick-up
arm and to place the needle 14 onto the record.
NOTE
After the end of the recording is reached the pick-up arm will return auto-►
matically to its starting position.

22
Service and operation
USB Record Player KH 2430
GB Operation during playback
To stop playback press the buttonStop playback 2. The turntable stops
and the pick-up arm remains in its current position.
IMPORTANT
Possible damage to the record or the needle.
If playback is stopped when the needle is still on the record it can lead to
damage.
Move the pick-up arm lever► 11 to the rear position before pressing the
Stop playback 2button.
To continue after stopping playback press the buttonContinue playback 4
and move the pick-up arm lever 11 to the forward position.
To end playback press the buttonEnd playback 3. The turntable stops
and the pick-up arm 13 returns to its starting position.
Setting recording level
NOTE
The recording level setting is not possible with all operating systems.►
In the operating systems mixer settings set the re-
cording level so that in the drive indicator (1) -6dB
is not exceeded.
1
