TopflyTech TLP1-P User manual

TOPFLYTECH TLP1-P Asset GPS Tracker
User Manual
Revision 1.2

Shenzhen TOPFLYTECH Co., Limited. All Rights Reserved 2
Thanks for your purchasing of the high-quality GPS tracker from TOPFLYTECH. Please read this
user manual carefully before installation and operation. Information in this manual is the property
of TOPFLYTECH. Changes to the specifications and features in this manual may be made by
TOPFLYTECH without prior notice. No part of this manual could be reproduced, copied, translated,
transmitted, or published in any form or by any means without TOPFLYTECH's prior written
permission.
The tracker is using GNSS & LTE technologies and could collect device coordinates then transfer
them via LTE network to the server. It provides customer with cost-effective, efficient and safety
management. It has been widely used in commercial transportation, company vehicle fleet
management, intelligent transportation, logistics, car rental, engineering machinery, marine
transportation and other segments.

Shenzhen TOPFLYTECH Co., Limited. All Rights Reserved 3
Contents
1. QUICK REFERENCE ..............................................................................................................................5
2. PRODUCT SPECIFICATIONS..............................................................................................................5
3. STANDARD ACCESSORIES INTRODUCTION ................................................................................6
4. LED INDICATOR ...................................................................................................................................6
4.1 NETWORK........................................................................................................................................................6
4.2 GNSS ..............................................................................................................................................................6
4.3 BATTERY...........................................................................................................................................................6
5. INSTALLATION GUIDE .......................................................................................................................7
5.1 SIM CARD PRE-INSTALLATION NOTE............................................................................................................7
5.2 SIM CARD INSTALLATION AND TRACKER POWER SWITCH...........................................................................7
5.3 INSTALLATION .................................................................................................................................................7
6. TRACKER OPERATION........................................................................................................................7
6.1 PHYSICAL POWER ON OR OFF ........................................................................................................................7
6.2 SOFTWARE CONTROLLED POWER ON OR OFF ..............................................................................................7
6.3 CHECK THE BATTERY LEVEL.............................................................................................................................8
6.4 CHECK THE GNSS AND NETWORK STATUS ..................................................................................................8
6.5SEND SOS ALARM..........................................................................................................................................8
6.6 QUICK SET/CANCEL THE GEOFENCE ..............................................................................................................8
6.7 MOTION OPERATIONS....................................................................................................................................8
6.7.1 Check the battery status.....................................................................................................................8
6.7.2 Check the GNSS and network status .............................................................................................9
6.7.3 Check the GNSS and network status .............................................................................................9
6.7.4 Send SOS alarm.....................................................................................................................................9
6.7.5 Quick set/cancel the geofence.........................................................................................................9
6.7.6 Motion controlled power on or off ................................................................................................9
6.8 THE BATTERY ...................................................................................................................................................9
6.9 GET CURRENT POSITION............................................................................................................................. 10
7. ALARM CONFIGURATION.............................................................................................................. 10
7.1 ALARM SENT THROUGH NETWORK............................................................................................................. 10
7.2 ALARM SENT THROUGH SMS..................................................................................................................... 10
8. QUICK TROUBLE SHOOTING......................................................................................................... 10
8.1 UNABLE TO CONNECT TO THE TRACKING PLATFORM.............................................................................. 10
8.2 TRACKER SHOWS OFFLINE.......................................................................................................................... 11
8.3 UNABLE TO LOCATE .................................................................................................................................... 11
8.4 POSITION DRIFT........................................................................................................................................... 11
8.5 NO COMMAND REPLY ................................................................................................................................ 11
9. WARRANTY AND STOCK ............................................................................................................... 11

Shenzhen TOPFLYTECH Co., Limited. All Rights Reserved 4
10. FREQUENTLY USED COMMANDS............................................................................................ 11
10.1 APN SETTING .............................................................................................................................................. 12
10.2 SERVER SETTING........................................................................................................................................... 12
10.3 UPLOAD INTERVAL SETTING........................................................................................................................ 13
10.4 HEARTBEAT SETTING.................................................................................................................................... 13
10.5 PIN SETTING ................................................................................................................................................ 13
10.6 ADD MANAGER PHONE NUMBER.............................................................................................................. 14
10.7 DELETE MANAGER PHONE NUMBER ......................................................................................................... 14
10.8 LIST MANAGER PHONE NUMBER............................................................................................................... 14
10.9 GOOGLE MAP SEARCH................................................................................................................................ 14
10.10 FORGOT THE PIN.................................................................................................................................... 15

Shenzhen TOPFLYTECH Co., Limited. All Rights Reserved 5
1. Quick Reference
2. Product Specifications
Network Specifications
Operating Band
FDD: B1/B2/B3/B4/B5/B8/B12/B13/B17/B18/
B19/B20/B25/B26/B28
TDD: B39 (Cat M1 only)
EGPRS 850/900/1800/1900MHz
Certification
FCC: B2/B4/B5/B12/B13/B25/B26
(Cat M1 and NB-IoT)
Data Transmission
eMTC: Max. 300Kbps (DL), Max. 375Kbps (UL)
NB1: Max. 32Kbps (DL), Max. 70Kbps (UL)
EDGE: Max. 296Kbps (DL), Max. 236.8Kbps (UL)
GPRS: Max. 107Kbps (DL), Max. 85.6Kbps (UL)
GNSS Specifications
GNSS Chipset
Qualcomm Gen 8C GNSS receiver
GNSS System
GPS+Glonass+Galileo+Beidou
Receiver type:
33 tracking / 99 acquisitions- channel GNSS
receiver
Sensitivity
Cold start: -149 dBm
Tracking: -163 dBm
Position Accuracy in open sky (CEP-50)
< 2m
Standalone TTFF
Cold start: < 29s
Warm start: < 27s
Hot start: < 1s
Interfaces
Charging and Data Transmission
4 Pin port with magnet
Network, GNSS Antenna
Internal only
Indicator LED
Network, GNSS and Battery level

Shenzhen TOPFLYTECH Co., Limited. All Rights Reserved 6
FOTA
Yes
Function Button
1
Light Sensor
2 light sensors (front and back)
Temperature Sensor
1 temperature sensor
General Specifications
Waterproof
IP67
Dimensions
69.3mm*120mm*22.8mm
Weight
195g
Battery
Rechargeable Li-Polymer 4800 mAh/ 3.7V
Standby Time
Without reporting: 720 hours (30 Days)
10 minutes reporting: 320 hours (13 Days)
5 minutes reporting: 250 hours (10 Days)
Charging & Data Communication
Magnetic USB cable
(recommend using 5V 1A adaptor, 10 hours
charging)
Operating Temperature
-20℃ ~ +60℃ (-4°F ~ 140°F)
Air Interface Protocol
Transmit Protocol
TCP, UDP, MQTT, SMS
Protocol Check & Encryption Support
MD5/ AES256
Scheduled Timing/angle/distance Report
Report position and status at preset intervals
Geo-fence
Support up to 64 internal geo-fence regions
Alarms
Support up to 31 types of alarm
(refer 7. Alarm Configuration)
3. Standard Accessories Introduction
USB cable Screwdriver
4. LED indicator
4.1 Network
Fast Flashing
Network Searching
Slow Flashing
Network Connected
4.2 GNSS
Fast Flashing
Satellite Searching
Slow Flashing
Positioned
4.3 Battery
Always on
Battery level
Some of them flashing
Charging

Shenzhen TOPFLYTECH Co., Limited. All Rights Reserved 7
Note:
1) Indicator lights will go out automatically after the tracker turns on for 70 seconds without
connecting to the external power via USB cable.
2) Slow flashing: on for 4 seconds, then goes out for 1 second.
Fast flashing: on for 1 second, then goes out for 1 second.
5. Installation Guide
5.1 SIM card pre-installation note
5.1.1 Data service should be enabled.
5.1.2 If SIM card is locked via PIN, please unlock it first.
5.1.3 Ensure there is sufficient balance in the SIM card.
5.2 SIM card installation and tracker power switch
5.2.1 Open the tracker with the screwdriver.
5.2.2 Open the SIM card slot
5.2.3 Insert and fix the SIM card.
5.2.4 Turn the power switch to on position before using.
5.3 Installation
5.3.1 Away from emission source such as all kinds of sensors, burglar alarm and other
communication devices.
6. Tracker Operation
6.1 Physical power on or off
6.1.1 Turn the power switch to on or off position.
6.1.2 Physical power off is recommended when the tracker is stored in the warehouse.
6.2 Software controlled power on or off
6.2.1 It only works when physical power switch at on position.

Shenzhen TOPFLYTECH Co., Limited. All Rights Reserved 8
6.2.2 Software controlled power off: hold the function button over 15s. (after the GNSS
light goes off).
6.2.3 Software controlled power on: after power off, hold the function button until all
the LED flashing, then release. The tracker will power on.
6.2.4 Software controlled power off is recommended when the tracker is going to be
shipped to the user.
6.3 Check the battery level
6.3.1 It only works when physical power switch at on position.
6.3.2 One quick press then release the function button.
6.4 Check the GNSS and network status
6.4.1 It only works when physical power switch at on position.
6.4.2 Hold the function button for 2s then release.
6.5 Send SOS alarm
6.5.1 It only works when physical power switch at on position.
6.5.2 Customer has to enable the alarm by command (alarm_set,0000,3,1,0,0,#) first.
6.5.3 Hold the function button for 3~8s until the network light flashing, then release.
6.5.4 If customer wants to disable the alarm, command is (alarm_set,0000,3,0,0,0,#)
6.6 Quick set/cancel the geofence
6.6.1 It only works when physical power switch at on position.
6.6.2 Customer has to enable the function by command gfence_en first.
6.6.3 gfence_en,0000,a,b# (a=0, disable; a=1, enable; b=1~65535, unit is meter)
6.6.4 Set geofence: hold the function button for 10~15s until the GNSS light flashing,
then release. The tracker GNSS light will slowly flash at the beginning. Once the
geofence is set successfully, the GNSS light will stay on without flashing then goes
out shortly.
6.6.5 Cancel geofence: after the geofence is set, hold the function button for 10~15s
until the GNSS light flashing, then release. The tracker GNSS light will fast flash at
the beginning. Once the geofence is set successfully, the GNSS light will stay on
without flashing then goes out shortly.
6.7 Motion operations
Device also can use motion to detect different operations. Hold the tracker and keep the
brand label side towards the sky. Use normal speed to turn it over 180°(the brand label
side towards the ground) then recover. This can be called one-time standard turning. By
repeating the standard turning different times, the tracker will execute different operations:
6.7.1 Check the battery status
(1) It only works when physical power switch at on position
(2) Repeat the standard turning 3 times

Shenzhen TOPFLYTECH Co., Limited. All Rights Reserved 9
6.7.2 Check the GNSS and network status
(1) It only works when physical power switch at on position
(2) Repeat the standard turning 4 times
6.7.3 Check the GNSS and network status
(1) It only works when physical power switch at on position
(2) Repeat the standard turning 4 times
6.7.4 Send SOS alarm
(1) It only works when physical power switch at on position.
(2) Customer has to enable the alarm first (alarm_set,0000,3,1,0,0,#)
(3) Repeat the standard turning 5 times
(4) If customer wants to disable the alarm, command is (alarm_set,0000,3,0,0,0,#)
6.7.5 Quick set/cancel the geofence
(1) It only works when physical power switch at on position.
(2) Customer has to enable the function by command gfence_en first
(3) gfence_en,0000,a,b# (a=0, disable; a=1, enable; b=1~65535, unit is meter)
(4) Set geofence: repeat the standard turning for 6 times then the GNSS light
will slowly flash at the beginning. Once the geofence is set successfully, the
GNSS light will stay on without flashing then goes out shortly
(5) Cancel geofence: after the geofence is set, repeat the standard turning for 6
times. The tracker GNSS light will fast flash at the beginning. Once the
geofence is cancelled successfully, the GNSS light will stay on without flashing
then goes out shortly.
6.7.6 Motion controlled power on or off
(1) It only works when physical power switch at on position.
(2) Motion controlled power off: Repeat the standard turning 7 times. The
tracker will power off. Customer can repeat other motion operation to verify.
(3) Repeat the standard turning 5 times
(4) Motion controlled power on: after power off, repeat the standard turning 7
times, then all the LED will be flashing. The tracker will power on.
6.8 The battery
6.8.1 Recommend connecting the device to a 5V 1A (cellphone) adaptor through
magnet USB cable for 10 hours charging to make sure the battery is fully charged.
6.8.2 Customer also can connect the tracker to other USB connectors. But lower current
output will cause longer charging time.
6.8.3 When the battery voltage value drops to 3.4V, usually a battery charging is
needed to avoid unexpected shutdown due to low power. If the battery runs out
completely, only when the battery is charged to 3.4V, the device will power on
again.

Shenzhen TOPFLYTECH Co., Limited. All Rights Reserved 10
6.9 Get Current Position
6.9.1 SMS Query (only when the device in working mode and registered on the network)
Device default PIN is 0000. Send a location inquiry SMS command (google,0000#)
to the tracker. The location information will be sent back through SMS (the tracker
SIM card must support receiving and sending SMS first).
6.9.2 Platform Query
Connect your tracker to the tracking platform then check the real-time position
online. (Additional tracking service charge may happen. Contact with your service
provider to get more details)
7. Alarm Configuration
7.1 Alarm sent through network
7.1.1 alarm_set,0000,a,b,0,0,#
7.1.2 0000 is device default PIN
7.1.3 a=alarm code, value from 1 to 31
Alarm Code
Description
Alarm Code
Description
1
Device removal (VS alarm 21)
17
Stop moving
2
Rear cover open (VS alarm 22)
18
Idle start (VS alarm 19)
3
SOS
19
Idle stop
4
Front light detected (VS alarm 23)
20
Power on (via function button)
5
Start falling (VS alarm 24)
21
Device mounted
6
Low battery (Vs alarm 7)
22
Rear cover close
7
Battery recover
23
Front light disappear
8
Device high temperature (VS alarm 25)
24
Stop falling
9
Vibration start (VS alarm 26)
25
Device high temperature disappear
10
Collision (VS alarm 27)
26
Vibration stop
11
Tilt start (VS alarm 28)
27
Collision stop
12
USB cable connected (VS alarm 13)
28
Tilt stop
13
USB cable disconnected
29
Power off (via function button)
14
Enter geofence (VS alarm 15)
30
Device low temperature (VS alarm 31)
15
Leave geofence
31
Device low temperature disappear
16
Start moving (VS alarm 17)
7.1.4 b=enable or disable, value is 0 (disable) or 1 (enable)
7.2 Alarm sent through SMS
Alarm also can be sent through SMS. But the tracker SIM card must support SMS function
first. Then it needs customer set manager cellphone number. Please refer the frequently
used commands part to get further information. Related commands: managera,
managerd, manager.
8. Quick Trouble Shooting
8.1 Unable to Connect to the Tracking Platform

Shenzhen TOPFLYTECH Co., Limited. All Rights Reserved 11
8.1.1 Check the APN and IP settings.
8.1.2 Check the SIM card data service whether enabled.
8.1.3 Make sure there is no limitation or already added server IP to the SIM card IP
white list when using a M2M SIM card.
8.1.4 Check the balance/signal of the SIM card.
8.2 Tracker Shows Offline
8.2.1 Check if the device entered into network blind area.
8.2.2 Check the SIM card balance.
8.2.3 If the connection lost happens on the last several days of the month, check
whether the network service is terminated by carrier because of exceeding the
max data usage volume.
8.3 Unable to Locate
8.3.1 The device may shield by metallic things.
8.3.2 The device may enter into an area with no satellite signal coverage.
(underground, building, etc)
8.4 Position Drift
In an area with poor GNSS signal (like the areas with lots of high buildings), position drift
may happen. When the device moves to open area, the drift will no longer exist.
8.5 No Command Reply
8.5.1 Check the command format. Make sure it’s correct.
8.5.2 The device may be in network blind area.
8.5.3 Ensure the SIM card is properly inserted.
9. Warranty and Stock
The device standard warranty period is 12 months starting from the date of purchasing. If the
device will be stored for a long time, please connect it to the external power and recharge the
internal battery (10 hours) every 3 months. It will be helpful to extend the internal battery life.
10. Frequently Used Commands
Commands are not case-sensitive and can be sent via mobile phone. The content is separated
by comma and ends with #. When set successfully, the tracker will return OK and execute it.
Otherwise there will be no message returned.
Function
Command Format
APN Setting
APN ,Current PIN , APN Name , Username , Password #
Server Setting
IP ,Current PIN , Server Domain Name or IP , Port Number #
Upload Interval Setting
TIMER, Current PIN , Upload Time(ACC on) : Upload Time(ACC
off) : Angle Compensation : Distance Compensation #

Shenzhen TOPFLYTECH Co., Limited. All Rights Reserved 12
Heartbeat Setting
HBT, Current PIN , Heartbeat Interval #
PIN Setting
PASSWORD, Current PIN , New PIN #
Add Manager Phone Number
MANAGERA, Current PIN , Manager Code : Manager Phone Number #
Delete Manager Phone Number
MANAGERD, Current PIN , Manager Code #
List Manager Phone Number
MANAGERL, Current PIN #
Google Map Search
GOOGLE, Current PIN #
Forgot the PIN
MYSELF#
10.1 APN Setting
APN, Current PIN,APN Name,Username,Password#
APN Name:
Range: APN of service provider
Length Limit: 1~32
Username:
Range: Letters and Numerals
Length Limit: 0~32
Password:
Range: Letters and Numerals
Length Limit: 0~32
Note:
1) Tracker will return “SET APN OK” when received this command.
2) If there is no Username and Password, the SMS setting is:
APN,Current PIN,APN Name,,#
3) If there is no APN PIN, the SMS setting is:
APN,Current PIN,APN Name,Username,#
10.2 Server Setting
IP, Current PIN,Server Domain Name or IP,Port Number#
Server Domain Name or IP:
Range: Letters, Numerals and Symbols
Length Limit: 1~128
Port Number:

Shenzhen TOPFLYTECH Co., Limited. All Rights Reserved 13
Range: Positive Integer
Length Limit: 0~65535
Note: Tracker will return “SET IP OK” when received this command.
10.3 Upload Interval Setting
TIMER, Current PIN,Upload Time(ACC on):Upload Time(ACC off):Angle Compensation:
Distance Compensation#
Upload Time (ACC on):
Range: Positive Integer
Range Limit: 0, 3~65535 second
Default: 60
Upload Time (ACC off):
Range: Positive Integer
Range Limit: 0, 3~ 4294967295 second
Default: 240
Angle Compensation:
Range: Positive Integer
Range Limit: 0~90 degrees
Default: 30 degrees
Distance Compensation:
Range: Positive Integer
Range Limit: 0 ~ 65535 meters
Default: 0 meters
Note: Tracker will return “SET TIMER OK” when received this command.
10.4 Heartbeat Setting
HBT, Current PIN,Heartbeat Interval#
Heartbeat Interval:
Range: Positive Integer
Range Limit: 1 ~ 255 minutes
Default: 30 minutes
Note: Tracker will return “SET HBT OK” when received this command.
10.5 PIN Setting
PASSWORD, Current PIN,New PIN#

Shenzhen TOPFLYTECH Co., Limited. All Rights Reserved 14
PIN:
Range: Letters and Numerals
Length Limit: 1 ~ 10
Default: 0000
Note: Tracker will return “SET PASSWORD OK” when received this command.
10.6 Add Manager Phone Number
MANAGERA, Current PIN,Manager Code:Manager Phone Number#
Manager Code:
Range: Positive Integer
Range limit: 1~4
Manager Phone Number:
Range: Phone number
Length Limit: 0~40
Default: <Null>
Note:
1) Tracker will return “SET MANAGERA OK” when received this command.
2) The max manager number is 4
10.7 Delete Manager Phone Number
MANAGERD, Current PIN,Manager Code#
Manager Code:
Range: Positive Integer
Range limit: 1~4
Note: Tracker will return “SET MANAGERD OK” when received this command.
10.8 List Manager Phone Number
MANAGERL, Current PIN#
Note:
1) Tracker will return “SET MANAGERL OK” when received this command.
2) All the manager phone numbers will be listed.
10.9 Google Map Search
GOOGLE, Current PIN#
Note: Tracker will return below message when received this command.
http://maps.google.com/maps?q=<Latitude>, <Longitude>

Shenzhen TOPFLYTECH Co., Limited. All Rights Reserved 15
10.10 Forgot the PIN
MYSELF#
Note:
1) If the manager phone number has been set, only the manager can use “MYSELF#”.
If no manager setting, the tracker will return the IMEI and current PIN when it
received “MYSELF#” from any mobile phone.
2) This command can be used to retrieve password.
