Topica TP-2000 User manual

TP-2000

General
New TOPICA TP-2000 High Resolution B/W
CCD Camera use high sensitive 1/3" interline
transfer CCD (Charge Coupled Device).
Inside of its attractive and modern body
(PATENT AUTHORIZED) are full advanced
functions. Video Drive/Direct Drive (V.D./D.D.)
Switch, Back Light Compensation (B.L.C.),
Built-in microphone, AC 24V L.L. Or AC
110V/220V L.L. All of these competitive
features make TP-2000 suitable for both
industry and consumer use.
.........
.............................
1

Features
(1)V.D./D.D. Switch
For Video drive auto iris lens, please set
switch to V.D. For Direct drive iris lens, set
switch to D.D.
(2)Back Light Compensation(B.L.C.)
Normal function is for the regular circum-
stance. B.L.C. function is for the better back
light treatment for objects under bright-light
area.
(3)Built-In microphone
High sensitivity built-in audio function is
applied as a standard feature.
(4)E.S. on/off switch
To select manual lens or auto iris lens
under different circumstance. Selection of
manual iris lens will save the cost of lens
and even keep the similar functions like
auto iris lens.
2

Features
(5)Modern design
Patent authorized two-color match body
design meets today's taste.
(6)AC 24V L.L. or AC 110V/220V L.L.
(7)Auto Gain Control (AGC) on/off switch
The subject can be distinguished much
clearer even in the dark area.
(8)Iris adjustment with L/H position
When using the economical Direct Drive
(D.D.) auto iris lens, iris control function still
ensure perfect operation.
(9)Vertical SYNC phase (V. Phase)
Can be adjusted while line-lock function
(AC 24V, AC 110V/220V) is working. It
achieves much more stable operation when
connected to VCR sequential switchers,
quad or multiplexer.
(10)Flickerless on/off switch
To reduce the flicker phenomenon when it
is on.
3

Precautions
(1)To protect camera, do not expose the
device to humidity and dust.
(2)Handle with careful
This camera consists of sensitive
highprecision parts. Do not place it in a
location subject to vibration or on an
unstable base.
(3)CCD sensor consists of sensitive highpre-
cision. Do not touch it by hand directly.
(4)When the device is not in use, please put
the lens mount cap on the lens.
(5)Please avoid to install the camera directly
toward the strong light source, such as sun,
spotlight...etc.
4

Precautions
5
Compositions
(6)Projection of the lens or other piece of
optical equipment must be less than 6mm
from the lens mount face.
(7)In case the camera with any defect,
please inform the qualified service person.
Don't try to disassemble the camera by
yourself.
Camera...........................................................1
Iens mount cap...............................................1
L-shape wrench..............................................1
Instruction manual..........................................1
C Mount 5mm Adaptor ring............................1
Warranty Card................................................1

Function of parts and wiring
(1)Lens mount
Use CS mount lens or C mount lens with
the attached 5mm adaptor ring.
(2)Video signal output connector (BNC
connector)
Connect to CCTV monitor by using a
coaxial cable.
(3)V.D./D.D. switch
Switch to Video Drive (V.D.) for auto iris
lens w/EE AMP. Switch to Direct Drive
(D.D.) for auto iris lens w/o EE AMP.
(4)Auto iris connector
Connect the cable from auto iris lens to the
pin no. 1 to 4 on camera according to the
fllowing Instruction.
6

Function of parts and wiring
12345
1. AES
2. BLC
3. F.L.
4. L.L.
5. AGC
AES : Electronic shutter
BLC : Back Light Compensation
Fl : Flickerless
L.L. : Auto Line-lock
AGE : Auto Gain Control
7
Pin V.D.
1. DC 12V
2. Iris out
3. N.C.
4. GND
D.D.
Control -
Control +
Drive +
Drive -

Connections
8
(1) Single Connection (one camera to one
CCTV monitor)
(2) Multiple Connection (plural cameras to one
CCTV monitor)

(1)Install lens to the camera.
(2)Connect a cable between camera and
CCTV monitor and then turn on the power of
each device.
(3)To obtain the best picture, adjust the focus
and the diaphragrm while observing the
image plane.
(4)Back focus adjustment
If the subject is not in focus after adjusted
the focus of lens, it's need to make the back
focus adjustment. First, set the focus ring of
lens to the widest position and take picture of
the subject at a distance of 20m away from
camera.
Second, loosen the screw at the front panel
by L-shape wrench. Then, turn the lens and
mount at the same time. So the subject will
be in focus. Finally, secure the screw firmly.
Operation & adjustment
9

Specifications
10
PICK UP DEVICE
PICTURE ELEMENTS
SYNC SYSTEM
HORIZONTAL RESOLUTION
LENS MOUNT
WHITE BALANCE
B.L.C.
AUTO GAIN CONTROL
GAMMA CORRECTION
AUDIO
ELECTRONIC SHUTTER
IRIS CONTROL
POWER SOURCE
S/N RATIO
VIDEO OUTPUT
MINIMUM ILLUMINATION
POWER CONSUMPTION
STORAGE TEMPERATURE
WORKING TEMPERATURE
DIMENSIONS
WEIGHT
1/3" Interline Transfer CCD
NTSC: 768(H) x 494(V)
PAL: 752(H) x 582(V)
Internal sync, Line-Lock
580 TV lines
CS mount or C mount with
5mm adaptor ring
Preset Auto White Balance(A.W.B)
Back Light Compensation, on/off switch
On/Off switch
> 0.45
Built-in high sensitive microphone
Up to 1/100,000
Video/Direct Drive A.I. switch
DC 12V/AC 24V Line-lock compatible or
AC90 ~ 265V Line-lock (Optional)
Over 48dB
BNC VBS 1.0Vp-p, 75 ohm
0.04 LUX / F1.2
Approx. 3W
(Including auto iris power consumption)
60(W) x 50(H) x 108(D) mm
Approx. 342g
-40 to +60
-10 to +60

AC 24V/DC 12V AC 90~265V
AUTO IRIS
VIDEO OUT
AC24V/DC12V
1. AES
2. BLC
3. F.L.
4. AGC
5. L.L.
AUTO IRIS
VIDEO OUT
AC IN
1. AES
2. BLC
3. F.L.
4. AGC
5. L.L.
Dimensions & parts location
11
1. DC12V
2. IRIS OUT
3. N.C.
4. GND
1. DC12V
2. IRIS OUT
3. N.C.
4. GND
