1. Contents Of Kit :
1 no. Outside Air kit (Stainless Steel—Unpainted)
2. Warnings
IMPORTANT—Please ensure the appliance is cold and unlit before commencing fitting this
accessory kit.
Please refer to the main instruction booklet, relevant to your stove, for guidance on the installation
and operation of the appliance.
Arada Ltd will not be responsible for any consequential or incidental loss or injury however caused.
Please note, this accessory kit can only be fitted prior to the appliance (stove) being installed and
connected to the flue system, within the property.
When handling the components of the kit, it is recommended to wear suitable gloves to prevent
hand injuries.
Outside Air Fing Instrucons
