Toro 51593 User manual

FormNo.3364-164RevA
SuperBlower/Vacuum
ModelNo.51593—SerialNo.310000001andUp
Operator'sManual
Thisproductishandheldelectricblowerandvacuum.Itisintended
forresidentialuseforblowingdirt,debris,andloosematerialsandfor
vacuuminglightorganicmatter,suchasgrassandleaves.Itisnot
intendedforuseinenclosedorhighlydustyareas,forstartingres,or
forvacuuminghardobjects.ProductWeight:10.2lb(4.6kg)
ThisproductcomplieswithallrelevantEuropeandirectives,fordetails
pleaseseetheseparateproductspecicDeclarationofConformity
(DOC)sheet.
Safety
Toensuremaximumsafety,bestperformance,andtogainknowledge
oftheappliance,itisessentialthatyouoranyotheroperatorofthe
appliancereadandunderstandthecontentsofthismanualbefore
operatingtheappliance.Payparticularattentiontothesafetyalert
symbolwhichmeansCAUTION,WARNINGorDANGER-personal
safetyinstruction.Readandunderstandtheinstructionbecauseithas
todowithsafety.Failuretocomplywiththeseinstructionsmay
resultinpersonalinjury,riskorre,orelectricalshock.
NOTICE!Thisapplianceisforhouseholduseonly.
Training
•Readtheinstructionscarefully.Befamiliarwiththecontrolsand
theproperuseoftheappliance.
•Neverallowchildrentousetheappliance.
•Neverallowpeopleunfamiliarwiththeseinstructionstousethe
appliance.Localregulationsmayrestricttheageoftheoperator.
•Neveroperatetheappliancewhilepeople,especiallychildren,
orpetsarenearby.
•Theoperatororuserisresponsibleforaccidentsorhazards
occurringtootherpeopleortheirproperty.
Preparation
•Whileoperatingtheappliance,alwayswearsubstantialfootwear
andlongtrousers.
•Donotwearlooseclothingorjewelrythatcanbedrawnintothe
airinlet(refertothefollowinggure).Keeplonghairawayfrom
theairinlets.
•Wearprotectivegoggleswhileoperating.
•Topreventdustirritation,wearafacemask.
•Beforeusing,checkthesupplyandextensioncordforsigns
ofdamageandaging.Donotusetheapplianceifthecordis
damagedorworn.
•Neveroperatetheappliancewithdefectiveguardsorshields,or
withoutsafetydevicesinplace,suchasthevacuumbag/vacuum
tubeorblowertube/inletcover.
•OnlyuseaCEapproved,weatherproofextensioncordttedwith
theproperplugforyourlocation,accordingtolocalordinances.
Operation
•Donotusetheapplianceonwetsurfaces.Donotexposeitto
rain.Storeitindoors.
•Donothandleplugorappliancewithwethands.
•Alwaysdirectthecordtotherearawayfromtheappliance.
•Ifacordbecomesdamagedduringuse,disconnectthesupply
cordfromthemainsimmediately.Donottouchthecordbefore
disconnectingthesupply.
•Donotcarrytheappliancebythecord,usethecordasahandle,
closeadooronthecord,orpullthecordaroundsharpedgesor
corners.Keepthecordawayfromheatedsurfaces.
•Turnoffallcontrolsbeforeunplugging.
•Donotunplugbypullingoncord.T ounplug,grasptheplug,not
thecord.
•Disconnecttheappliancefromthepowersourceasfollows:
–Wheneveryouleavethemachine
–Beforeclearingablockage
–Beforechecking,cleaning,orworkingontheappliance
–Iftheappliancestartstovibrateabnormally
•Operatetheapplianceonlyindaylightoringoodarticiallight.
•Donotoverreachandkeepyourbalanceatalltimes.
•Alwaysbesureofyourfootingonslopes.
•Walk,neverrun.
•Keepallcoolingairinletsclearofdebris.Donotputanyobjectinto
openings.Donotusewithanyopeningblocked.
•Neverblowdebrisinthedirectionofbystanders.
•Useextracarewhencleaningonstairs.
•Donotusetovacuumupammableorcombustibleliquids,such
asgasoline,oruseinareaswheretheymaybepresent.
•Donotvacuumanythingthatisburningorsmoking,suchas
cigarettes,matches,orhotashes.
•Thisapplianceisprovidedwithdoubleinsulation(i.e.,Class2
device).Useonlyidenticalreplacementparts.Seeinstructionsfor
servicingofDouble-Insulated(Class2)appliances.
•Lightningcancausesevereinjuryordeath.Iflightningisseenor
thunderisheardinthearea,donotoperatethemachine;seek
shelter.
Maintenanceandstorage
•Keepallnuts,bolts,andscrewstighttobesuretheapplianceisin
safeworkingcondition.
•Checkthevacuumbagfrequentlyforwearordeterioration.
•Replacewornordamagedparts.
•Ifapplianceisnotworkingasitshould,hasbeendropped,
damaged,leftoutdoors,ordroppedintowater,returnittoaservice
dealer.
©2009—TheToro®Company
8111LyndaleAvenueSouth
Bloomington,MN55420
Registeratwww.Toro.com.OriginalInstructions(EN)
PrintedintheUSA.
AllRightsReserved

•Useonlygenuinereplacementpartsandaccessories.
•Storetheapplianceinadryplace.
SoundPressure
Thisunithasasoundpressurelevelattheoperator’searof97dBA,
whichincludesanUncertaintyValue(K)of1dBA.
Soundpressurelevelwasdeterminedaccordingtotheprocedures
outlinedinENISO11201.
SoundPower
Thisunithasaguaranteedsoundpowerlevelof103dBA,which
includesanUncertaintyValue(K)of1dBA.
Soundpowerlevelwasdeterminedaccordingtotheprocedures
outlinedinISO11094.
Vibration
•Measuredvibrationlevel=4.0m/s2
•UncertaintyValue(K)=2.0m/s2
Measuredvaluesweredeterminedaccordingtotheprocedures
outlinedinENISO20643.
WasteofElectrical/ElectronicEquipment(WEEE)
•EUdirective2002/96/ECclassiesthisproductasanelectricalorelectronictool.
•DoNotdisposeofthistoolasunsortedmunicipalwaste.
•Disposeofthistoolatacollectionorrecyclingcenteraccordingtolocalandnationallaw.
•Theconsumerhasanimportantroleinreducingthedisposalofwastebyreturningwasteelectronic/electrical
toolsforrecycling.
•Recyclingavoidsthedispersionofhazardousmaterialsintothemunicipalwastestream.
•Thecrossed-outbinsymbolremindstheusernottodisposeofthisproductasunsortedmunicipalwaste.
SafetyandInstructionalDecals
NOTICE!Safetyandinstructiondecalsarelocatednearareasofpotentialdanger.Replacedamagedorlostdecals.
110-7425
1.ReadtheOperator’sManual.4.Thrownobjecthazard—weareyeprotection.
2.Electricshockhazard—keepthebloweroutoftherainandother
wetconditions.
5.Thrownobjecthazard—keepbystandersasafedistancefrom
themachine.
3.Warning—disconnecttheblowerfromthepoweroutletandread
theinstructionsbeforeservicingorperformingmaintenance.
6.Containsrecyclablematerials,donotdiscard.
110-7434
1.Cutting/dismembermenthazard,impeller—stayawayfrommovingparts.
2.Warning—disconnecttheblowerfromthepoweroutletandreadtheinstructionsbeforeservicingorperformingmaintenance.
2

Setup
1
AssemblingtheBlower
Partsneededforthisprocedure:
Installtheblowertubeandthentheinletcoverontotheblowerhousing.
NOTICE!Youmustinstalltheblowertubebeforeinstallingthe
inletcoverbecausetheinletcoverhooksontotheblowertube.
Theblowerwillnotrununlessthebottominletcoverislocked
inplace.
2
ConvertingfromBlowertoVacuum
Partsneededforthisprocedure:
WARNING
Theimpellerrotatesforafewsecondsafteryouturnoffthe
blowerandcancutorinjurengers.
Donotremovethebottominletcoverwhenthemotorisrunning
orwhentheunitispluggedintoapoweroutlet.
1.Removetheinletcoverandtheblowertubefromtheblower
housing.
2.Installthevacuumtubeontotheblowerhousingandconnectthe
lowervacuumtubetotheuppertube,securingitwiththesupplied
fastener.
NOTICE!Thevacuumwillnotrununlessthevacuumtube
islockedinplace.
Note:Youmayneedtopushtheconnectorrmlytoensurethat
itseatsallthewayintothevacuumtube.
3

3.Installthevacuumbag.
4.Adjustthestrapasneededforcomfortableoperation.
3
ConvertingfromVacuumtoBlower
Partsneededforthisprocedure:
1.Removethevacuumbagandthevacuumtubefromtheblower
housing.
2.Installtheblowertubeandthentheinletcoverontotheblower
housing.
NOTICE!Theblowerwillnotrununlessthebottominletcover
islockedinplace.
Operation
NOTICE!Thisblowerisintendedforoutdoor,residentialuseonly.
Donotuseitindoorsorforcommercialorindustrialpurposes.
ConnectingtoaPowerSource
Thepowersupplyyouusewiththisapplianceshouldbearesidential
currentdevice(RCD)withatrippingcurrentofnotmorethan30mA.
UseonlyaCEapprovedextensioncordrecommendedforoutdoor
use.Donotchangetheapplianceorextensioncordpluginanyway.
WARNING
Ifyoudonotfullyseattheextensioncordontheinletplug,orif
theplugandcorddonottrmly,thelooseplugcouldleadto
overheatingandcauseare,possiblyburningyouorothers.
•Ensurethatyoufullyseatthecordontheplug.
•Checktheconnectionregularlytoensurethatthecordis
rmlyattached.
•Donotuseaworn-outorlooseextensioncord.
ExtensionCordLengthMinimumWireGage
30m1.0mm2
45m2.0mm2
Note:Donotuseanextensioncordover45m.
NOTICE!Checktheextensioncordfrequentlyduringusefor
holesintheinsulation.Donotuseadamagedcord.Donotrun
thecordthroughstandingwaterorwetgrass.
Securetheextensioncordtotheblowercordusinganoverhandknot,
asshown.
4

Starting/Stopping/AdjustingtheAirSpeed
UsingtheConcentratorNozzleAccessory
Installtheconcentratornozzleintotheblowertubetohelpreachinto
narrowspacesortoremovematteddebrisfromhardsurfaces.
Removetheconcentratornozzlewhennished.
UsingtheBlower
Theblowerisintendedforresidentialuseonly.Usetheblower
outdoorstomovedebrisasneeded.
WARNING
Theblowercanthrowdebris,possiblycausingseriouspersonal
injurytotheoperatororbystanders.
•Donotblowhardobjectssuchasnails,bolts,orrocks.
•Donotoperatetheblowernearbystandersorpets.
•Useextracarewhencleaningdebrisfromstairsorothertight
areas.
•Wearsafetygogglesorothersuitableeyeprotection,long
pants,andshoes.
UsingtheVacuum
WARNING
Thevacuumcanthrowdebris,possiblycausingseriouspersonal
injurytotheoperatororbystanders.
•Donotoperatethevacuumwithoutthebaginstalledorwith
thebagzipperopen.
•Donotvacuumsharp,pointed,orhardobjectsthatcouldbe
thrownthroughthefabricofthebag,suchaswires,staples,
nails,orrocks.
NOTICE!Vacuumonlyleavesandsoftitems.Harditemssuchas
sticks,rocks,acorns,andpineconeswilldamagetheimpeller.
NOTICE!Donotforcethevacuumtubeintoapileofdebrisor
holdthetubeuprightwhileforcefeedingdebrisintothetube.
Eitheractionmaycloganddamagetheimpeller.Ifthevacuum
startstovibrateormakeabnormalnoise,stopit,unplugthecord,
andcheckforthecause.
EmptyingtheBag
1.Turnoffandunplugthevacuumfromthepowersource.
2.Emptyanydebrisfromthebag.
Donotstoredebrisinthebag.Tocleanthebag,turnitinsideout
andshakeoutanyexcessdebris.Onceayear,handwashthe
baginsoapywaterandallowittoairdry.
DANGER
Normalusageofthebagcausesittowearanddeteriorate
overtime.Awornordeterioratedbagallowssmallobjectsto
bethrownthroughthebag,possiblyinjuringtheoperator
orbystanders.
Checkthebagfrequently.Ifitiswornordeteriorated,replace
itwithagenuineTorovacuumbag.
5

RemovingCloggedDebrisfromthe
Impeller
1.Turnoffandunplugthevacuumfromthepowersourceandwait
forallmovingpartstostop.
2.Removethevacuumtube.
3.Removethedebrisfromimpellerblades.
4.Checktheimpellerforanysignsofdamage.Ifitisdamaged,
contactyourAuthorizedT oroDealer.
5.Installthevacuumtubeor,ifyouwanttoswitchtoblowermode,
thebottominletcover.RefertoConvertingfromBlowertoVacuum
orConvertingfromVacuumtoBlowerformoreinformation.
Service
Torohasdesignedthisproducttogiveyouyearsoftroublefreeuse.
Shoulditneedservice,bringtheproducttoyourAuthorizedToro
ServiceDealer.Y ourToroDealerisspeciallytrainedtorepairT oro
productsandwillensurethatyourT orostays“All”T oro.
Double-insulated(Class2)Appliances
Inadouble-insulated(Class2)appliance,twosystemsofinsulation
areprovidedinsteadofgrounding.Nogroundingmeansisprovided
onadouble-insulated(Class2)appliance,norshouldameansfor
groundingbeaddedtotheappliance.Servicingadouble-insulated
(Class2)appliancerequiresextremecareandknowledgeofthe
system,andshouldbedoneonlybythequaliedservicepersonnel
atyourAuthorizedT oroServiceDealer.Replacementpartsfora
double-insulated(Class2)appliancemustbeidenticaltothepartsthey
replace.Adouble-insulated(Class2)applianceismarkedwiththe
symbol(squarewithinasquare).
Storage
Storetheblower/vacuumandextensioncordindoors,inacooldry
location,outofreachofchildrenandanimals.
Troubleshooting
•Ensurethatthebottominletcoverorvacuumtubeislockedin
place.
•Ensurethatthepowercordissecuredinplaceonthebackofthe
blowerandthattheplugisfullyseated.
6

InternationalDistributorList
Distributor:Country:PhoneNumber:
AtlantisSuveSulamaSisstemleriLtTurkey902163448674
BalamaPrimaEngineeringEquip.HongKong85221552163
B-RayCorporationKorea82325512076
CascoSalesCompanyPuertoRico7877888383
CeresS.A.CostaRica5062391138
CSSCTurfEquipment(pvt)Ltd.SriLanka94112746100
CyrilJohnston&Co.NorthernIreland442890813121
EquiverMexico525553995444
FemcoS.A.Guatemala5024423277
G.Y .K.CompanyLtd.Japan81726325861
GeomechanikiofAthensGreece30109350054
GuandongGoldenStarChina862087651338
HakoGroundandGardenSweden4635100000
HakoGroundandGardenNorway4722907760
HayterLimited(U.K.)UnitedKingdom441279723444
HydroturfInt.CoDubaiUnitedArabEmirates97143479479
HydroturfEgyptLLCEgypt2025194308
IbeaS.P .A.Italy390331853611
IrriamcPortugal351212388260
IrrigationProductsInt’lPvtLtd.India862283960789
JeanHeybroekb.v.Netherlands31306394611
Lely(U.K.)LimitedUnitedKingdom441480226800
MaquiverS.A.Colombia5712364079
MaruyamaMfg.Co.Inc.Japan81332522285
MetraKftHungary3613263880
Mountelda.s.CzechRepublic420255704220
MunditolS.A.Argentina541148219999
OslingerTurfEquipmentSAEcuador59342396970
OyHakoGroundandGardenAbFinland35898700733
ParklandProductsLtd.NewZealand6433493760
Prochaska&CieAustria4312785100
RTCohen2004Ltd.Israel97298617979
RiversaSpain34952837500
RothMotorgerateGmBh&Co.Germany4971442050
ScSvendCarlsenA/SDenmark4566109200
SolvertS.A.S.France33130817700
SpyprosStavrinidesLimitedCyprus35722434131
SurgeSystemsIndiaLimitedIndia911292299901
T-MarktLogisticsLtd.Hungary3626525500
ToroAustraliaAustralia61395807355
ToroEuropeBVBABelgium3214562960

TheToroWarranty
ConditionsandProductsCovered
TheT oro®Companyanditsafliate,T oroWarrantyCompany,pursuantto
anagreementbetweenthem,jointlypromisetorepairtheT oroProduct
listedbelowifusedforresidentialpurposes*ifdefectiveinmaterialsor
workmanship.
Thefollowingtimeperiodsapplyfromthedateofpurchase:
ProductsWarrantyPeriod
WalkPowerMowers2yearlimitedwarranty
RearEngineRiders2yearlimitedwarranty
Lawn&GardenTractors2yearlimitedwarranty
ElectricHandHeldProducts2yearlimitedwarranty
Snowthrowers2yearlimitedwarranty
ConsumerZeroTurn2yearlimitedwarranty
*OriginalPurchasermeansthepersonwhooriginallypurchasedtheToro
Product
*Residentialpurposesmeansuseoftheproductonthesamelotasyour
home.Useatmorethanonelocation,orinstitutionalorrentaluse,is
consideredcommercialuse,andthecommercialusewarrantywould
apply.
LimitedWarrantyforCommercialUse
ToroConsumerProductsandattachmentsusedforcommercial,
institutional,orrentaluse,arewarrantedagainstdefectsinmaterials
orworkmanshipforthefollowingtimeperiodsfromthedateoforiginal
purchase:
ProductsWarrantyPeriod
WalkPowerMowers90daywarranty
RearEngineRiders90daywarranty
Lawn&GardenTractors90daywarranty
ElectricHandHeldProducts90daywarranty
Snowthrowers90daywarranty
ConsumerZeroTurn45daywarranty
InstructionsforObtainingWarrantyService
IfyouthinkthatyourT oroProductcontainsadefectinmaterialsor
workmanship,followthisprocedure:
1.Contactyoursellertoarrangeserviceoftheproduct.Ifforanyreason
itisimpossibleforyoutocontactyourseller,youmaycontactany
ToroAuthorizedDistributortoarrangeservice.
2.Bringtheproductandyourproofofpurchase(salesreceipt)tothe
ServiceDealer.IfforanyreasonyouaredissatisedwiththeService
Dealer’sanalysisorwiththeassistanceprovided,contactusat:
CustomerCareDepartment,ConsumerDivision
TheToroCompany
8111LyndaleAvenueSouth
Bloomington,MN55420-1196
Manager:TechnicalProductSupport:001–952–887–8248
SeeattachedDistributorList
OwnerResponsibilities
YoumustmaintainyourT oroProductbyfollowingthemaintenance
proceduresdescribedintheOperator’sManual.Suchroutine
maintenance,whetherperformedbyadealerorbyyou,isatyourexpense.
ItemsandConditionsNotCovered
Thisexpresswarrantydoesnotcoverthefollowing:
•Costofregularmaintenanceserviceorwearparts,suchasrotor
blades(paddles),scraperblades,belts,fuel,lubricants,oilchanges,
sparkplugs,cable/linkageorbrakeadjustments
•Anyproductorpartwhichhasbeenalteredormisusedandrequires
replacementorrepairduetoaccidentsorlackofpropermaintenance
•Repairsnecessaryduetofailuretousefreshfuel(lessthanone
monthold),orfailuretoproperlypreparetheunitpriortoanyperiod
ofnon-useoveronemonth
•Engineandtransmission.Thesearecoveredbytheappropriate
manufacturer’sguaranteeswithseparatetermsandconditions
Allrepairscoveredbythesewarrantiesmustbeperformedbyan
AuthorizedT oroServiceDealerusingToroapprovedreplacementparts.
GeneralConditions
Thepurchaseriscoveredbythenationallawsofeachcountry.Therights
towhichthepurchaserisentitledwiththesupportoftheselawsarenot
restrictedbythiswarranty.
Other manuals for 51593
1
Table of contents
Other Toro Blower manuals

Toro
Toro Flex-Force Power System User manual

Toro
Toro Power Sweep 51585 User manual

Toro
Toro 319000001 User manual

Toro
Toro 600 User manual

Toro
Toro Pro Force 44553 User manual

Toro
Toro 51594 User manual

Toro
Toro 318000001 User manual

Toro
Toro 30855 User manual

Toro
Toro Versa Vac User manual

Toro
Toro Powervac 51988 User manual

Toro
Toro 30506 User manual

Toro
Toro PowerPlex Series User manual

Toro
Toro Ultra 350 User manual

Toro
Toro UltraPlus 51558 User manual

Toro
Toro PowerJet F700 User manual

Toro
Toro 44531 User manual

Toro
Toro 44044 User manual

Toro
Toro 51593 User manual

Toro
Toro RAKE-O-VAC 07050 User manual

Toro
Toro 62925 User manual
