FormNo.3377-883-ASMRevA
20inRecycler®/RearBaggingLawnMower
ModelNo.20319—SerialNo.313000001andUp
Operator'sManual
Introduction
Thisrotary-blade,walk-behindlawnmowerisintended
tobeusedbyresidentialhomeownersorprofessional,
hiredoperators.Itisdesignedprimarilyforcuttinggrass
onwell-maintainedlawnsonresidentialorcommercial
properties.Itisnotdesignedforcuttingbrushorfor
agriculturaluses.
Readthisinformationcarefullytolearnhowtooperateand
maintainyourproductproperlyandtoavoidinjuryand
productdamage.Youareresponsibleforoperatingthe
productproperlyandsafely.
YoumaycontactTorodirectlyatwww.Toro.comforproduct
andaccessoryinformation,helpndingadealer,ortoregister
yourproduct.
Wheneveryouneedservice,genuineToroparts,oradditional
information,contactanAuthorizedServiceDealerorToro
CustomerServiceandhavethemodelandserialnumbersof
yourproductready.Figure1identiesthelocationofthe
modelandserialnumbersontheproduct.Writethenumbers
inthespaceprovided.
G020042
1
Figure1
1.Modelandserialnumberplate
ModelNo.
SerialNo.
Thismanualidentiespotentialhazardsandhassafety
messagesidentiedbythesafetyalertsymbol(Figure2),
whichsignalsahazardthatmaycauseseriousinjuryordeath
ifyoudonotfollowtherecommendedprecautions.
Figure2
1.Safetyalertsymbol
Thismanualuses2wordstohighlightinformation.
Importantcallsattentiontospecialmechanicalinformation
andNoteemphasizesgeneralinformationworthyofspecial
attention.
WARNING
CALIFORNIA
Proposition65Warning
Thisproductcontainsachemicalorchemicals
knowntotheStateofCaliforniatocausecancer,
birthdefects,orreproductiveharm.
Theengineexhaustfromthisproduct
containschemicalsknowntotheStateof
Californiatocausecancer,birthdefects,
orotherreproductiveharm.
Important:Thisengineisnotequippedwithaspark
arrestermufer.ItisaviolationofCaliforniaPublic
ResourceCodeSection4442touseoroperatetheengine
onanyforest-covered,brush-covered,orgrass-covered
land.Otherstatesorfederalareasmayhavesimilarlaws.
ThissparkignitionsystemcomplieswithCanadianICES-002.
Theenclosed
EngineOwner'sManual issuppliedfor
informationregardingtheUSEnvironmentalProtection
Agency(EPA)andtheCaliforniaEmissionControl
Regulationofemissionsystems,maintenance,and
warranty.Replacementsmaybeorderedthroughthe
enginemanufacturer.
Formodelswithstatedenginehorsepower,thegross
horsepoweroftheenginewaslaboratoryratedbytheengine
manufacturerinaccordancewithSAEJ1940.Ascongured
tomeetsafety,emission,andoperatingrequirements,the
actualenginehorsepoweronthisclassoflawnmowerwill
besignicantlylower.
©2013—TheToro®Company
8111LyndaleAvenueSouth
Bloomington,MN55420
Registeratwww.Toro.com.OriginalInstructions(EN)
PrintedintheUSA
AllRightsReserved*3377-883-ASM*A

Contents
Introduction..................................................................1
GeneralOperation..................................................2
SlopeOperation......................................................2
Children.................................................................3
Service...................................................................3
SafetyandInstructionalDecals.................................4
Setup............................................................................4
UnfoldingtheHandle..............................................4
InstallingtheRecoil-starterRopeintheRope
Guide.................................................................5
FillingtheEnginewithOil........................................5
ProductOverview..........................................................6
Operation.....................................................................6
Attachments/Accessories.........................................6
FillingtheFuelTank................................................6
CheckingtheEngineOilLevel..................................7
AdjustingtheCuttingHeight....................................7
StartingtheEngine..................................................8
StoppingtheEngine................................................8
MulchingtheClippings............................................8
BaggingtheClippings..............................................8
OperatingTips.......................................................9
Maintenance.................................................................10
RecommendedMaintenanceSchedule(s)......................10
PreparingforMaintenance.......................................10
ServicingtheAirCleaner.........................................11
ChangingtheEngineOil.........................................11
ReplacingtheBlade................................................12
CleaningtheundertheMachineHousing...................13
Storage........................................................................13
PreparingtheMachineforStorage............................13
FoldingtheHandle.................................................14
RemovingtheMachinefromStorage.........................14
Safety
ThislawnmowermeetsorexceedstheCPSCbladesafety
requirementsforwalk-behindrotarylawnmowersandthe
B71.1specicationsoftheAmericanNationalStandards
Instituteineffectatthetimeofproduction.
Readandunderstandthecontentsofthismanualbefore
youstarttheengine.
Thesafetyalertsymbol(Figure2)isusedtoalertyouto
potentialpersonalinjuryhazards.Obeyallsafetymessages
thatfollowthissymboltoavoidpossibleinjuryordeath.
Improperlyusingormaintainingthismowercouldresultin
injuryordeath.Toreducethispotential,complywiththe
followingsafetyinstructions.
Thefollowinginstructionshavebeenadaptedfromthe
ANSI/OPEIstandardB71.1-2003.
Thiscuttingmachineiscapableofamputatinghands
andfeetandofthrowingobjects.Failuretoobserve
thefollowingsafetyinstructionscouldresultinserious
injuryordeath.
GeneralOperation
•Read,understand,andfollowallinstructionsonthe
machineandinthemanual(s)beforestarting.
•Donotputhandsorfeetnearorunderthemachine.
Keepclearofthedischargeopeningatalltimes.
•Onlyallowresponsibleadults,whoarefamiliarwiththe
instructions,tooperatethismachine.
•Cleartheareaofobjectssuchasrocks,wire,toys,etc.,
whichcouldbethrownbytheblade.Staybehindthe
handlewhentheengineisrunning.
•Besuretheareaisclearofbystandersbeforeoperating.
Stopmachineifanyoneentersthearea.
•Donotoperatemachinebarefootedorwhilewearing
sandals.Alwayswearsubstantialfootwear.
•Donotpullmachinebackwardunlessabsolutely
necessary.Alwayslookdownandbehindbeforeand
whilemovingbackward.
•Neverdirectdischargedmaterialtowardanyone.Avoid
dischargingmaterialagainstawallorobstruction.
Materialmayricochetbacktowardtheoperator.Stopthe
bladewhencrossinggravelsurfaces.
•Donotoperatemachinewithouttheentiregrasscatcher,
dischargeguard,rearguard,orothersafetyprotective
devicesinplaceandworking.
•Neverleavearunningmachineunattended.
•Stoptheengineandwaituntilthebladecomestoa
completestopbeforecleaningthemachine,removing
grasscatcher,oruncloggingthedischargeguard.
•Operatemachineonlyindaylightorgoodarticiallight.
•Donotoperatemachinewhileundertheinuenceof
alcoholordrugs.
•Neveroperatemowerinwetgrass.Alwaysbesureof
yourfooting;walk;neverrun.
•Disengagethedrivesystem,ifsoequipped,before
startingtheengine.
•Ifthemachineshouldstarttovibrateabnormally,stop
theengineandcheckforthecauseimmediately.Vibration
isgenerallyawarningoftrouble.
•Alwaysweareyeprotectionwhenoperatingmachine.
•Lightningcancausesevereinjuryordeath.Ifyousee
lightningorhearthunderinthearea,donotoperatethe
machine;seekshelter.
•Seemanufacturer'sinstructionsforproperoperationand
installationofaccessories.Onlyuseaccessoriesapproved
bythemanufacturer.
SlopeOperation
Slopesareamajorfactorrelatedtoslipandfallaccidents,
whichcanresultinsevereinjury.Operationonallslopes
2

requireextracaution.Ifyoufeeluneasyonaslope,donot
mowit.
•Mowacrossthefaceofslopes;neverupanddown.
Exerciseextremecautionwhenchangingdirectionon
slopes.
•Watchforholes,ruts,bumps,rocks,orotherhidden
objects.Uneventerraincouldcauseaslipandfall
accident.Tallgrasscanhideobstacles.
•Donotmowonwetgrassorexcessivelysteepslopes.
Poorfootingcouldcauseaslipandfallaccident.
•Donotmowneardrop-offs,ditches,orembankments.
Youcouldloseyourfootingorbalance.
Children
Tragicaccidentscanoccuriftheoperatorisnotalerttothe
presenceofchildren.Childrenareoftenattractedtothe
machineandthemowingactivity.Neverassumethatchildren
willremainwhereyoulastsawthem.
•Keepchildrenoutofthemowingareaandunderthe
watchfulcareofaresponsibleadultotherthanthe
operator.
•Bealertandturnmoweroffifachildentersthearea.
•Neverallowchildrentooperatethemachine.
•Useextracarewhenapproachingblindcorners,shrubs,
trees,orotherobjectsthatmayblockyourviewofachild.
Service
SafeHandlingofGasoline
Toavoidpersonalinjuryorpropertydamage,use
extremecareinhandlinggasoline.Gasolineisextremely
ammableandthevaporsareexplosive.
•Extinguishallcigarettes,cigars,pipes,andothersources
ofignition.
•Useonlyanapprovedgasolinecontainer.
•Neverremovegascaporaddfuelwiththeengine
running.Allowenginetocoolbeforerefueling.
•Neverrefuelthemachineindoors.
•Neverstorethemachineorfuelcontainerwherethereis
anopename,spark,orpilotlightsuchasonawater
heateroronotherappliances.
•Neverllcontainersinsideavehicleoronatruckor
trailerbedwithaplasticliner.Alwaysplacecontainerson
thegroundawayfromyourvehiclebeforelling.
•Removegas-poweredequipmentfromthetruckortrailer
andrefuelitontheground.Ifthisisnotpossible,then
refuelsuchequipmentwithaportablecontainer,rather
thanfromagasolinedispensernozzle.
•Keepthenozzleincontactwiththerimofthefueltank
orcontaineropeningatalltimesuntilfuelingiscomplete.
Donotuseanozzlelock-opendevice.
•Iffuelisspilledonclothing,changeclothingimmediately.
•Neveroverllfueltank.Replacegascapandtighten
securely.
WARNING
Exhaustcontainscarbonmonoxide,anodorless,
deadlypoisonthatcankillyou.
Donotruntheengineindoorsorinanenclosed
area.
GeneralService
•Neveroperatemachineinaclosedarea.
•Keepallnutsandboltstighttobesuretheequipmentis
insafeworkingcondition.
•Nevertamperwithsafetydevices.Checktheirproper
operationregularly.
•Keepmachinefreeofgrass,leaves,orotherdebris
build-up.Cleanupoilorfuelspillageandremoveany
fuel-soakeddebris.Allowmachinetocoolbeforestoring.
•Ifyoustrikeaforeignobject,stopandinspectthe
machine.Repair,ifnecessary,beforestarting.
•Nevermakeanyadjustmentsorrepairswiththeengine
running.Disconnectthespark-plugwireandground
againstenginetopreventunintendedstarting.
•Checkgrasscatchercomponentsandthedischargeguard
frequentlyandreplacewithmanufacturer'srecommended
parts,whennecessary.
•Mowerbladesaresharp.Wrapthebladeorweargloves,
anduseextracautionwhenservicingthem.
•Donotchangetheenginegovernorsettingoroverspeed
theengine.
•Maintainorreplacesafetyandinstructionlabels,as
necessary.
3

SafetyandInstructional
Decals
Important:Safetyandinstructiondecalsarelocated
nearareasofpotentialdanger.Replacedamageddecals.
94-8072
117–2718
117-4143
1.Warning—readtheOperator'sManual.
2.Thrownobjecthazard—keepbystandersasafedistance
fromthemachine.
3.Cutting/dismembermenthazardofhandorfoot,mower
blade—disconnectthespark-plugwireandreadthe
instructionsbeforeservicingorperformingmaintenance.
4.Cutting/dismembermenthazardofhandorfoot,mower
blade—stayawayfrommovingpartsandkeepallguards
andshieldsinplace.
5.Cutting/dismembermenthazardofhandorfoot,mower
blade—donotmowupanddownslopes,onlymowacross;
stopthemowerandengine,pickupdebrisbeforeoperating;
lookbehindanddownwhenreversing.
Setup
Important:Removeanddiscardtheprotectiveplastic
sheetthatcoverstheengine.
UnfoldingtheHandle
WARNING
Foldingorunfoldingthehandleimproperlycan
damagethecables,causinganunsafeoperating
condition.
•Donotdamagethecableswhenfoldingor
unfoldingthehandle.
•Ifacableisdamaged,contactanAuthorized
ServiceDealer.
1.Removethehandleknobsfromthemachinehousing
(Figure3).
Important:Routethecablestotheoutsideofthe
handleasyouinstallthehandle.
1
G021276
Figure3
1.Handleknob(2)
2.Movethehandletotheoperatingposition.
3.Installthehandleknobsandtightenthemrmlyby
hand(Figure3).
4

InstallingtheRecoil-starter
RopeintheRopeGuide
Important:Tostarttheenginesafelyandeasily
wheneveryouusethemachine,installtherecoil-starter
ropeintheropeguide.
Holdtheblade-controlbartotheupperhandleandpullthe
recoil-starterropethroughtheropeguideonthehandle
(Figure4).
Figure4
1.Recoil-starterrope2.Ropeguide
FillingtheEnginewithOil
Important:Yourmachinedoesnotcomewithoilin
theengine.Beforestartingtheengine,lltheengine
withoil.
1.Movethemachinetoalevelsurface.
2.Removethedipstick(Figure5)andpourabout3/4of
thecrankcasecapacityofoilintotheoil-lltube.
Note:Max.ll:16oz.(0.47l),type:10W-30orSAE
30detergentoilwithanAPIserviceclassicationof
SJorhigher.
G020039
Figure5
3.Wipeoffthedipstickendwithacleancloth.
4.Insertthedipstickintotheoil-lltube.
5.Removethedipstickandreadtheoillevelonthe
dipstick(Figure5).
•IftheoillevelisbelowtheAddmark,addasmall
amountofoilslowlytotheoil-lltube,wait3
minutes,andthenrepeatsteps3through5until
theoillevelonthedipstickisattheFullmark.
•IftheoillevelisabovetheFullmark,drainthe
excessoiluntiltheoillevelonthedipstickisat
theFullmark.Todraintheexcessoil,referto
ChangingtheEngineOil(page11).
Important:Iftheoillevelinthecrankcaseis
toolowortoohighandyouruntheengine,
youmaydamagetheengine.
6.Installthedipsticksecurely.
Important:
Changetheengineoilaftertherst5
operatinghours
;changeityearlythereafter.Refer
toChangingtheEngineOil(page11).
5

ProductOverview
G021277
1
2
3
4
5
6
7
8
Figure6
1.Blade-controlbar5.Grassbag
2.Recoil-starthandle6.Fuel-tankcap
3.Oilll/Dipstick7.Airlter
4.Sparkplug8.Cutting-heightlever(4)
Operation
Attachments/Accessories
AselectionofToroapprovedattachmentsandaccessoriesis
availableforusewiththemachinetoenhanceandexpand
itscapabilities.ContactyourAuthorizedServiceDealeror
Distributororgotowww.Toro.comforalistofallapproved
attachmentsandaccessories.
FillingtheFuelTank
DANGER
Gasolineisextremelyammableandexplosive.A
reorexplosionfromgasolinecanburnyouand
others.
•Topreventastaticchargefromignitingthe
gasoline,placethecontainerand/ormachine
directlyonthegroundbeforelling,notina
vehicleoronanobject.
•Fillthetankoutdoorswhentheengineiscold.
Wipeupspills.
•Donothandlegasolinewhensmokingoraround
anopenameorsparks.
•Storegasolineinanapprovedfuelcontainer,out
ofthereachofchildren.
•Forbestresults,useonlyclean,fresh,unleadedgasoline
withanoctaneratingof87orhigher((R+M)/2rating
method).
•Oxygenatedfuelwithupto10%ethanolor15%MTBE
byvolumeisacceptable.
•Donotuseethanolblendsofgasoline(suchasE15
orE85)withmorethan10%ethanolbyvolume.
Performanceproblemsand/orenginedamagemayresult
whichmaynotbecoveredunderwarranty.
•Donotusegasolinecontainingmethanol.
•Donotstorefueleitherinthefueltankorfuelcontainers
overthewinterunlessafuelstabilizerisused.
6

Important:Toreducestartingproblems,addfuel
stabilizertothefuelallseason,mixingitwithgasoline
lessthan30daysold.
g020044
Figure7
CheckingtheEngineOilLevel
ServiceInterval:Beforeeachuseordaily
Max.ll:16oz.(0.47l),type:10W-30orSAE30detergent
oilwithanAPIserviceclassicationofSJorhigher.
1.Movethemachinetoalevelsurface.
2.Removethedipstick(Figure8).
G020039
Figure8
3.Wipeoffthedipstickendwithacleancloth.
4.Insertthedipstickintotheoil-lltube.
5.Removethedipstickandreadtheoillevel;referto
Figure8.
•IftheoillevelisbelowtheAddmark,addasmall
amountofoilslowlytotheoil-lltube,wait3
minutes,andthenrepeatsteps3through5until
theoillevelonthedipstickisattheFullmark.
•IftheoillevelisabovetheFullmark,drainthe
excessoiluntiltheoillevelonthedipstickisat
theFullmark.Todraintheexcessoil,referto
ChangingtheEngineOil(page11).
Important:Iftheoillevelinthecrankcaseis
toolowortoohighandyouruntheengine,
youmaydamagetheengine.
6.Installthedipsticksecurely.
AdjustingtheCuttingHeight
WARNING
Adjustingthecuttingheightmaybringyouinto
contactwiththemovingblade,causingserious
injury.
•Stoptheengineandwaitforallmovingparts
tostop.
•Donotputyourngersunderthehousingwhen
adjustingthecuttingheight.
CAUTION
Iftheenginehasbeenrunning,themuferwillbe
hotandcanseverelyburnyou.Keepawayfromthe
hotmufer.
7

AdjustingtheCuttingHeight
Adjustthecuttingheightasdesired.Setall4wheelstothe
sameheight.
Note:Toraiseorlowerthemachine,movethecutting-height
leversasshowninFigure9.
12
G020106
Figure9
1.Raisethemachine2.Lowerthemachine
Important:Thecuttingheightsettingsare1inch(25
mm);1-1/2inch(38mm);2inches(51mm);2-1/2inches
(64mm);3inches(76mm);3-1/2inches(89mm);and4
inches(102mm).
StartingtheEngine
1.Holdtheblade-controlbar(Figure10)againstthe
handle.
G021278
Figure10
1.Blade-controlbar
2.Pullrecoil-starthandle(Figure11).
G021279
Figure11
Note:Ifthemachinedoesnotstartafterseveral
attempts,contactanAuthorizedServiceDealer.
StoppingtheEngine
Tostoptheengine,releasetheblade-controlbar(Figure12).
Important:Whenyoureleasetheblade-controlbar,
boththeengineandbladeshouldstopwithin3seconds.
Iftheydonotstopproperly,stopusingyourmachine
immediatelyandcontactanAuthorizedServiceDealer.
Figure12
MulchingtheClippings
Yourmachinecomesfromthefactoryreadytomulchthe
grassandleafclippingsbackintothelawn.
Ifthegrassbagisonthemachine,removeitbeforemulching
theclippings.RefertoRemovingtheGrassBag(page9).
BaggingtheClippings
Usethegrassbagwhenyouwanttocollectgrassandleaf
clippingsfromthelawn.
WARNING
Aworngrassbagcouldallowsmallstonesand
othersimilardebristobethrownintheoperator'sor
bystander'sdirectionandresultinseriouspersonal
injuryordeathtotheoperatororbystanders.
Checkthegrassbagfrequently.Ifitisdamaged,
installanewTororeplacementbag.
WARNING
Thebladeissharp;contactingthebladecanresult
inseriouspersonalinjury.
Stoptheengineandwaitforallmovingpartstostop
beforeleavingtheoperatingposition.
8

InstallingtheGrassBag
1.Liftupthereardeector(Figure13).
G020048
Figure13
1.Reardeector
2.Insertthegrass-baghandleontothenotchesonthe
handlebrackets(Figure13).
RemovingtheGrassBag
1.Liftupthereardeector(Figure13).
2.Liftthegrass-baghandleoutfromthenotchesonthe
handlebracketsandremovethebagfromthemachine.
3.Closethereardeector.
OperatingTips
GeneralMowingTips
•Cleartheareaofsticks,stones,wire,branches,andother
debristhatthebladecouldhit.
•Avoidstrikingsolidobjectswiththeblade.Never
deliberatelymowoveranyobject.
•Ifthemachinestrikesanobjectorstartstovibrate,
immediatelystoptheengine,disconnectthewirefrom
thesparkplug,andexaminethemachinefordamage.
•Forbestperformance,installanewbladebeforethe
cuttingseasonbegins.
•ReplacethebladewhennecessarywithaToro
replacementblade.
CuttingGrass
•Cutonlyaboutathirdofthegrassbladeatatime.Donot
cutbelowthe2inch(51mm)settingunlessthegrassis
sparseoritislatefallwhengrassgrowthbeginstoslow
down.RefertoAdjustingtheCuttingHeight(page7).
•Whencuttinggrassover6inches(15cm)tall,mowatthe
highestcuttingheightsettingandwalkslower;thenmow
againatalowersettingforthebestlawnappearance.If
thegrassistoolong,themachinemayplugandcause
theenginetostall.
•Mowonlydrygrassorleaves.Wetgrassandleavestend
toclumpontheyardandcancausethemachinetoplug
ortheenginetostall.
WARNING
Wetgrassorleavescancauseseriousinjuryif
youslipandcontacttheblade.Mowonlyindry
conditions.
•Alternatethemowingdirection.Thishelpsdispersethe
clippingsoverthelawnforevenfertilization.
•Ifthenishedlawnappearanceisunsatisfactory,tryone
ormoreofthefollowing:
–Replacethebladeorhaveitsharpened.
–Walkataslowerpacewhilemowing.
–Raisethecuttingheightonyourmachine.
–Cutthegrassmorefrequently.
–Overlapcuttingswathsinsteadofcuttingafullswath
witheachpass.
–Setthecuttingheightonthefrontwheelsonenotch
lowerthantherearwheels.Forexample,setthefront
wheelsat2inches(51mm)andtherearwheelsat
2-1/2inches(64mm).
9

Maintenance
Note:Determinetheleftandrightsidesofthemachinefromthenormaloperatingposition.
RecommendedMaintenanceSchedule(s)
MaintenanceService
IntervalMaintenanceProcedure
Aftertherst5hours•Changetheengineoil.
Beforeeachuseordaily•Checktheengineoillevel.
•Ensurethattheenginestopswithin3secondsafterreleasingtheblade-controlbar.
Aftereachuse•Cleangrassclippingsanddirtfromunderthemachine.
Every25hours•Replacetheair-cleanerelement(morefrequentlywhenoperatingthemachinein
dustyordirtyoperatingconditions).
Every100hours•Cleanthecoolingsystem(refertoyourengineowner'smanual).
•Replacethesparkplug.
Beforestorage•Emptythefueltankbeforerepairsasdirectedandbeforeannualstorage.
Yearly
•Changetheengineoil.
•Replacethebladeorhaveitsharpened(morefrequentlyiftheedgedullsquickly).
•RefertoyourEngineOperator'sManualforanyadditionalyearlymaintenance
procedures.
Important:Refertoyour EngineOperator'sManual foradditionalmaintenanceprocedures.
PreparingforMaintenance
1.Stoptheengineandwaitforallmovingpartstostop.
2.Disconnectthespark-plugwirefromthesparkplug
(Figure14)beforeperforminganymaintenance
procedure.
1
G020049
Figure14
1.Spark-plugwire
3.Afterperformingthemaintenanceprocedure(s),
connectthespark-plugwiretothesparkplug.
Important:Beforetippingthemachinetochange
theoilorreplacetheblade,allowthefueltankto
rundrythroughnormalusage.Ifyoumusttip
themachinepriortorunningoutoffuel,usea
handfuelpumptoremovethefuel.Alwaystipthe
machineontoitssidewiththedipstickdown.
WARNING
Tippingthemachinemaycausethefuelto
leak.Gasolineisammable,explosiveand
cancausepersonalinjury.
Runtheenginedryorremovethegasoline
withahandpump;neversiphon.
10

ServicingtheAirCleaner
ServiceInterval:Every25hours/Yearly(whichevercomes
rst)—Replacetheair-cleanerelement
(morefrequentlywhenoperatingthe
machineindustyordirtyoperating
conditions).
1.Performthepre-maintenanceprocedures;referto
PreparingforMaintenance(page10).
2.Pressthebuttonontheaircleanercover(Figure15)
andopenthecover.
G020045
123
Figure15
1.Air-cleanerhousing3.Air-cleanercover
2.Air-cleanerelement
3.Replacetheair-cleanerelement.
4.Installtheair-cleanercover.
ChangingtheEngineOil
ServiceInterval:Aftertherst5hours
Yearly
Runtheengineafewminutesbeforechangingtheoiltowarm
it.Warmoilowsbetterandcarriesmorecontaminants.
1.Performthepre-maintenanceprocedures;referto
PreparingforMaintenance(page10).
2.Tipthemachineontoitsside,withthedipstickdown,
thenremovethedipsticktodraintheusedoilout
throughtheoil-lltube(Figure16).
G020050
Figure16
3.Afterdrainingtheusedoil,returnthemachinetothe
normaloperatingposition.
4.Removethedipstickandpourabout3/4ofthe
crankcasecapacityofoilintotheoil-lltube.
Note:Max.ll:16oz.(0.47l),type:10W-30orSAE
30detergentoilwithanAPIserviceclassicationof
SJorhigher.
5.Wipeoffthedipstickendwithacleancloth.
6.Insertthedipstickintotheoil-lltube.
7.Removethedipstickandreadtheoillevelonthe
dipstick(Figure17).
G020039
Figure17
•IftheoillevelisbelowtheAddmark,addasmall
amountofoilslowlytotheoil-lltube,wait3
minutes,andthenrepeatsteps5through7until
theoillevelonthedipstickisattheFullmark.
•IftheoillevelisabovetheFullmark,drainthe
excessoiluntiltheoillevelonthedipstickisatthe
Fullmark.
Important:Iftheoillevelinthecrankcaseis
toolowortoohighandyouruntheengine,
youmaydamagetheengine.
11

8.Installthedipsticksecurely.
9.Recycletheusedoilproperly.
ReplacingtheBlade
ServiceInterval:Yearly
Important:
Youwillneedatorquewrenchtoinstallthe
bladeproperly
.Ifyoudonothaveatorquewrenchor
areuncomfortableperformingthisprocedure,contact
anAuthorizedServiceDealer.
Examinethebladewheneveryourunoutofgasoline.Ifthe
bladeisdamagedorcracked,replaceitimmediately.Ifthe
bladeedgeisdullornicked,haveitsharpenedorreplaceit.
WARNING
Thebladeissharp;contactingthebladecanresult
inseriouspersonalinjury.
•Disconnectthewirefromthesparkplug.
•Weargloveswhenservicingtheblade.
1.Disconnectthespark-plugwirefromthesparkplug.
RefertoPreparingforMaintenance(page10).
2.Tipthemachineontoitsside,withtheairlterup.
3.Useablockofwoodtoholdthebladesteady.
4.Removetheblade(turnthebladebolt
counterclockwise),savingallthemounting
hardware.
5.Installthenewblade(turnthebladeboltclockwise)
andallmountinghardware(Figure18).
Figure18
Important:Positionthecurvedendsoftheblade
topointtowardthemachinehousing.
6.Useatorquewrenchtotightenthebladeboltto
60ft-lb(82N-m).
Important:Abolttorquedto60ft-lb(82N-m)is
verytight.Whileholdingthebladewithablock
ofwood,putyourweightbehindtheratchetor
wrenchandtightentheboltsecurely.Thisboltis
verydifculttoovertighten.
12

Cleaningtheunderthe
MachineHousing
ServiceInterval:Aftereachuse
WARNING
Cleaningthemachinemaydislodgematerialfrom
underthemachinehousing.
•Weareyeprotection.
•Stayintheoperatingposition(behindthe
handle).
•Donotallowbystandersinthearea.
1.Withtheenginerunningonaatpavedsurface,spray
astreamofwaterinfrontoftherightrearwheel
(Figure19).
Thewaterwillsplashintothepathoftheblade,
cleaningouttheclippings.
Figure19
2.Whennomoreclippingscomeout,stopthewaterand
movethemachinetoadryarea.
3.Runtheengineforafewminutestodrythehousing
topreventitfromrusting.
Storage
Storethemachineinacool,clean,dryplace.
PreparingtheMachinefor
Storage
WARNING
Gasolinevaporscanexplode.
•Donotstoregasolinemorethan30days.
•Donotstorethemachineinanenclosurenear
anopename.
•Allowtheenginetocoolbeforestoringit.
1.Onthelastrefuelingoftheyear,addfuelstabilizerto
thefuelasdirectedbytheenginemanufacturer.
2.Runthemachineuntiltheenginestopsfromrunning
outoffuel.
3.Starttheengineagain.
4.Allowtheenginetorununtilitstops.Whenyoucan
nolongerstarttheengine,itissufcientlydry.
5.Disconnectthewirefromthesparkplug.
6.Removethesparkplug,add1oz.(30ml)ofoilthrough
thesparkplughole,andpullthestarterropeslowly
severaltimestodistributeoilthroughoutthecylinder
topreventcylindercorrosionduringtheoff-season.
7.Installthesparkplugandtightenitwithatorque
wrenchto15ft-lb(20N-m).
8.Tightenallnuts,bolts,andscrews.
13

FoldingtheHandle
WARNING
Foldingorunfoldingthehandleimproperlycan
damagethecables,causinganunsafeoperating
condition.
•Donotdamagethecableswhenfoldingor
unfoldingthehandle.
•Ifacableisdamaged,contactanAuthorized
ServiceDealer.
1.Loosenthehandleknobsuntilyoucanmovethe
handlefreely(Figure20).
1
G021280
Figure20
1.Handleknob(2)
2.MovethehandleforwardasshowninFigure20.
RemovingtheMachinefrom
Storage
Connectthewiretothesparkplug.
14

Notes:
15

TheToroTotalCoverageGuarantee22inRecycler®
A2-YearFullWarranty(45DayLimitedWarrantyforCommercialUse)20inMulcher/Bagger
TheToroGTSStartingGuaranteeWalkPowerMowers
A3-YearFullWarranty(NotApplicableforCommercialUse)
ConditionsandProductsCovered
TheToroCompanyanditsafliate,ToroWarrantyCompany,pursuantto
anagreementbetweenthem,jointlypromisetorepairtheToroProduct
listedbelowifusedforresidentialpurposes*;ifitisdefectiveinmaterials
orworkmanshiporifitstopsfunctioningduetothefailureofacomponent;
oriftheToroGTS(GuaranteedtoStart)enginewillnotstartontherstor
secondpull,providedtheroutinemaintenancerequiredintheOperator's
Manualhavebeenperformed.
Thiswarrantycoversthecostofpartsandlabor,butyoumustpay
transportationcosts.
Thefollowingtimeperiodsapplyfromthedateofpurchase:
ProductsWarrantyPeriod
22inRecyclerand20in
Mulcher/BaggerandAttachments2-yearfullwarranty
GTS(GuaranteedtoStart)3-yearfullwarranty
Engine3-yearfullwarranty
Battery1-yearfullwarranty
LimitedWarrantyforCommercialUse*
Gas-poweredToroProductsusedforcommercial,institutional,or
rentaluse,arewarrantedfor45daysagainstdefectsinmaterialsor
workmanship.Componentsfailingduetonormalweararenotcovered
bythiswarranty.
TheToroGTS(GuaranteedtoStart)StartingGuaranteedoesnotapply
whentheproductisusedcommercially*.
InstructionsforObtainingWarrantyService
IfyouthinkthatyourT oroProductcontainsadefectinmaterialsor
workmanship,orifanormal,able-bodiedadultcannolongerstartyour
product'sengineinoneortwopulls,followthisprocedure:
1.ContactanyAuthorizedToroServiceDealertoarrangeservice
attheirdealership.Tolocateadealerconvenienttoyou,referto
theYellowPagesofyourtelephonedirectory(lookunder“Lawn
Mowers”)oraccessourwebsiteatwww.Toro.com.Youmayalso
callthenumberslistedinitem#3tousethe24-hourToroDealer
locatorsystem.
2.Bringtheproductandyourproofofpurchase(salesreceipt)tothe
ServiceDealer.Thedealerwilldiagnosetheproblemanddetermine
ifitiscoveredunderwarranty.
3.IfforanyreasonyouaredissatisedwiththeServiceDealer’s
analysisorwiththeassistanceprovided,contactusat:
CustomerCareDepartment,RLCDivision
TheToroCompany
8111LyndaleAvenueSouth
Bloomington,MN55420-1196
Tollfreeat866-214-9807(U.S.customers)
Tollfreeat866-214-9808(Canadiancustomers)
OwnerResponsibilities
YoumustmaintainyourToroProductbyfollowingthemaintenance
proceduresdescribedintheOperator'sManual.Suchroutine
maintenance,whetherperformedbyadealerorbyyou,isatyourexpense.
ItemsandConditionsNotCovered
Thereisnootherexpresswarrantyexceptforspecialemissionsystem
coverageandenginewarrantycoverageonsomeproducts.Thisexpress
warrantydoesnotcoverthefollowing:
•Costofregularmaintenanceserviceorparts,suchaslters,fuel,
lubricants,oilchanges,sparkplugs,airltersbladesharpening
orwornblades,cable/linkageadjustments,orbrakeandclutch
adjustments
•Anyproductorpartwhichhasbeenalteredormisusedandrequires
replacementorrepairduetoaccidentsorlackofpropermaintenance
•Repairsnecessaryduetofailuretousefreshfuel(lessthanone
monthold),orfailuretoproperlypreparetheunitpriortoanyperiod
ofnon-useoveronemonth
•Pickupanddeliverycharges
•Operationalmisuse,neglect,oraccidents
•RepairsorattemptedrepairsbyanyoneotherthananAuthorized
ToroServiceDealer
•Repairsoradjustmentstocorrectstartingdifcultiesduetothe
following:
–failuretofollowpropermaintenanceprocedures
–rotarymowerbladestrikinganobject
–contaminantsinthefuelsystem
–improperfuel(consultyourOperator'sManualifindoubt)
–failuretodrainthefuelsystempriortoanyperiodofnon-use
overonemonth
•Specialoperationalconditionswherestartingmayrequiremorethan
twopulls:
–rsttimestartsafterextendedperiodofnon-useoverthree
monthsorseasonalstorage
–cooltemperaturestartssuchasthosefoundinearlyspringand
lateautumn
–improperstartingprocedures-ifyouarehavingdifcultystarting
yourunit,pleasechecktheOperator'sManualtoensurethat
youareusingthecorrectstartingprocedures.Thiscansavean
unnecessaryvisittoanAuthorizedToroServiceDealer.
GeneralConditions
Allrepairscoveredbythesewarrantiesmustbeperformedbyan
AuthorizedToroServiceDealerusingToro-approvedreplacementparts.
RepairbyanAuthorizedToroServiceDealerisyoursoleremedyunder
thiswarranty.
NeitherTheToroCompanynorToroWarrantyCompanyisliablefor
indirect,incidental,orconsequentialdamagesinconnectionwiththe
useoftheToroProductscoveredbythesewarranties,includingany
costorexpenseofprovidingsubstituteequipmentorserviceduring
reasonableperiodsofmalfunctionornon-usependingcompletionof
repairsunderthesewarranties.
Somestatesdonotallowexclusionsofincidentalorconsequential
damages,sotheaboveexclusionsmaynotapplytoyou.
Thiswarrantygivesyouspeciclegalrights,andyoumayalsohaveother
rightswhichvaryfromstatetostate.
CountriesOtherthantheUnitedStatesorCanada
CustomerswhohavepurchasedToroproductsexportedfromtheUnitedStatesorCanadashouldcontacttheirToroDistributor(Dealer)toobtain
guaranteepoliciesforyourcountry,province,orstate.IfforanyreasonyouaredissatisedwithyourDistributor'sserviceorhavedifcultyobtaining
guaranteeinformation,contacttheToroimporter.Ifallotherremediesfail,youmaycontactusatToroWarrantyCompany.
AustralianConsumerLaw:AustraliancustomerswillnddetailsrelatingtotheAustralianConsumerLaweitherinsidetheboxoratyourlocalToro
Dealer.
*Residentialpurposesmeansuseoftheproductonthesamelotasyourhome.Useatmorethanonelocation,orinstitutionalorrentaluse,isconsidered
commercialuse,andthecommercialusewarrantywouldapply.
374-0254RevD

FormNo.3377-883-ASMRevA
CortacéspedRecycler®/Ensacadotraserode51cm
(20pulgadas)
Nºdemodelo20319—Nºdeserie313000001ysuperiores
Manualdeloperador
Introducción
Estecortacéspeddirigidodecuchillasrotativasestá
diseñadoparaserusadoporusuariosdomésticosopor
operadoresprofesionalescontratados.Estádiseñado
principalmenteparasegarcéspedbienmantenido
enzonasverdesresidencialesocomerciales.No
estádiseñadoparacortarmalezaoparaaplicaciones
agrícolas.
Leaestemanualdetenidamenteparaaprenderautilizary
mantenercorrectamentesuproducto,yparaevitarlesiones
ydañosalproducto.Ustedeselresponsabledeoperarel
productodeformacorrectaysegura.
PuededirigirsedirectamenteaToro:www.Toro.compara
buscarinformaciónsobreproductosyaccesorios,para
localizarundistribuidoropararegistrarsuproducto.
Cuandonecesiteasistenciatécnica,piezasgenuinasToroo
informaciónadicional,póngaseencontactoconunServicio
TécnicoAutorizadooconAsistenciaalClienteToro,ytenga
amanolosnúmerosdemodeloyseriedesuproducto.
Figura1identicalaubicacióndelosnúmerosdemodelo
yserieenelproducto.Escribalosnúmerosenelespacio
provisto.
G020042
1
Figura1
1.Placaconlosnúmerosdemodeloydeserie
Nºdemodelo
Nºdeserie
Estemanualidenticapeligrospotencialesycontiene
mensajesdeseguridadidenticadosporelsímbolodealerta
deseguridad(Figura2),queseñalaunpeligroquepuede
causarlesionesgravesolamuertesiustednosiguelas
precaucionesrecomendadas.
Figura2
1.Símbolodealertadeseguridad
Estemanualutiliza2palabraspararesaltarinformación.
Importantellamalaatenciónsobreinformaciónmecánica
especial,yNotaresaltainformacióngeneralquemereceuna
atenciónespecial.
ADVERTENCIA
CALIFORNIA
AdvertenciadelaPropuesta65
Esteproductocontieneunaomássustancias
químicasqueelEstadodeCaliforniaconsidera
causantesdecáncer,defectoscongénitoso
trastornosdelsistemareproductor.
Losgasesdeescapedeesteproductocontienen
productosquímicosqueelEstadodeCalifornia
sabequecausancáncer,defectoscongénitos
uotrospeligrosparalareproducción.
Importante:Estemotornoestáequipadoconun
silenciadorconparachispas.Esunainfraccióndela
legislacióndeCalifornia(CaliforniaPublicResource
CodeSection4442)lautilizaciónolaoperacióndel
motorencualquierterrenodebosque,monteoterreno
cubiertodehierba.Otrosestadosozonasfederales
puedentenerleyessimilares.
Estesistemadeencendidoporchispacumplelanorma
canadienseICES-002.
El
Manualdelpropietariodelmotor adjuntoofrece
informaciónsobrelasnormasdelaAgenciade
protecciónambientaldeEE.UU.(U.S.Environmental
ProtectionAgency/EPA)ydelaNormadecontrol
©2013—TheToro®Company
8111LyndaleAvenueSouth
Bloomington,MN55420
Registresuproductoenwww.Toro.com.Traduccióndeloriginal(ES)
ImpresoenEE.UU.
Reservadostodoslosderechos*3377-883-ASM*A

deemisionesdeCalifornia(CaliforniaEmission
ControlRegulation)sobresistemasdeemisiones,
mantenimientoygarantía.Puedesolicitarseunmanual
nuevoalfabricantedelmotor.
Enloscasosenqueseindicalapotenciaencvdelmotor,la
potenciabrutadelmotorfuecalculadaenellaboratorioporel
fabricantedelmotor,conarregloaloestipuladoenSAEJ1940.
Debidoaqueelmotorestáconguradoparacumplirlos
requisitosdeseguridad,emisionesyoperación,supotencia
realenestetipodecortacéspedserásignicativamentemenor.
Contenido
Introducción.................................................................1
Operacióngeneral...................................................2
Operaciónenpendientes..........................................3
Niños....................................................................3
Mantenimiento.......................................................3
Pegatinasdeseguridadeinstrucciones.......................5
Montaje........................................................................6
Cómodesplegarelmanillar.......................................6
Instalacióndelacuerdadearranqueenlaguíadela
cuerda................................................................6
Llenadodelcárterdeaceite.......................................6
Elproducto...................................................................7
Operación.....................................................................8
Accesorios..............................................................8
Cómollenareldepósitodecombustible......................8
Vericacióndelniveldeaceitedelmotor.....................8
Ajustedelaalturadecorte........................................9
Cómoarrancarelmotor...........................................9
Cómopararelmotor...............................................9
Recicladodelosrecortes..........................................9
Ensacadodelosrecortes.........................................10
Consejosdeoperación............................................10
Mantenimiento.............................................................11
Calendariorecomendadodemantenimiento..................11
Preparaciónparaelmantenimiento...........................11
Mantenimientodellimpiadordeaire.........................12
Cómocambiarelaceitedelmotor.............................12
Cómocambiarlacuchilla.........................................13
Limpiezadelosbajosdelamáquina..........................14
Almacenamiento...........................................................14
Preparacióndelamáquinaparael
almacenamiento.................................................14
Cómoplegarelmanillar...........................................15
Despuésdelalmacenamiento...................................15
Seguridad
Estecortacéspedcumpleosuperalosrequisitosdeseguridad
decuchillasCPSCparacortacéspedesgiratoriosdirigidosy
lasespecicacionesB71.1delInstitutoNorteamericanode
EstándaresNacionalesenvigorenelmomentodefabricación.
Leaycomprendaelcontenidodeestemanualantesde
arrancarelmotor.
Elsímbolodealertadeseguridad(Figura2)seutilizapara
advertirlesobrepotencialesriesgosdelesionespersonales.
Observesiempretodoslosmensajesdeseguridadquesiguena
estesímboloconelndeevitarposibleslesionesolamuerte.
Elusoomantenimientoincorrectosdeestecortacésped
puedencausarlesionesolamuerte.Parareduciresta
posibilidad,cumplalassiguientesinstruccionesdeseguridad.
Lassiguientesinstruccioneshansidoadaptadasdelanorma
ANSI/OPEIB71.1-2003.
Estamáquinadecorteescapazdeamputarmanos
ypiesydelanzarobjetosalaire.Elnoobservarlas
siguientesinstruccionesdeseguridadpuededarlugara
lesionescorporalesgraveseinclusolamuerte.
Operacióngeneral
•Lea,comprendaysigatodaslasinstruccionesdel/de
losmanual(es)ylascolocadasenlamáquinaantesde
arrancarésta.
•Nocoloquelasmanosolospiescercadelamáquina
odebajodeésta.Manténgasealejadodelconductode
descargaentodomomento.
•Sólopermitaqueutilicenestamáquinaadultos
responsablesyfamiliarizadosconlasinstrucciones.
•Despejelazonadeobjetostalescomopiedras,alambres,
juguetes,etc.,quepodríanserarrojadosporlacuchilla.
Permanezcadetrásdelmanillarcuandoelmotorestáen
marcha.
•Asegúresedequenohayaotraspersonasenlazonaantes
deusarlamáquina.Parelamáquinasialguienentraenla
zona.
•Noutilicelamáquinasiustedestádescalzoolleva
sandalias.Llevesiemprecalzadofuerte.
•Notirehaciaatrásdelamáquinaamenosquesea
absolutamentenecesario.Antesdedesplazarsehaciaatrás
ymientraslohace,miresiemprehaciaabajoydetrásde
usted.
•Nodirijanuncaelmaterialdescargadohacianadie.Evite
descargarmaterialcontraunapareduotraobstrucción.
Elmaterialpodríarebotarhaciaeloperador.Parela
cuchillaalcruzarsuperciesdegrava.
•Nohagafuncionarlamáquinasinoestáncolocados
yfuncionandoelrecogedorcompleto,elprotectorde
descarga,elprotectortraserouotrosdispositivosde
protección.
•Nodejenuncadesatendidalamáquinasiestáfuncionando.
2

•Pareelmotoryesperehastaquelacuchillasedetenga
completamenteantesdelimpiarlamáquina,retirarel
recogedorodesatascarelprotectordedescarga.
•Utilicelamáquinasolamenteconluznaturaloconuna
buenailuminaciónarticial.
•Noutilicelamáquinabajolainuenciadedrogaso
alcohol.
•Noutilicenuncaelcortacéspedenhierbamojada.
Asegúresedepisarrmemente;camine;nocorranunca.
•Desengraneelsistemadetransmisión,silamáquinaestá
equipadaconuno,antesdearrancarelmotor.
•Silamáquinacomienzaavibrardemaneraanormal,
pareelmotorycompruebelacausainmediatamente.La
vibraciónsueleserunavisodeproblemas.
•Siempreutiliceprotecciónocularalusarlamáquina.
•Losrayospuedencausargraveslesionesoinclusola
muerte.Sisevenrelámpagosorayososeoyentruenos
enlazona,noutilicelamáquina;busqueunlugardonde
resguardarse.
•Consultelasinstruccionesdelfabricanterespectoala
formacorrectadeinstalaryutilizarlosaccesorios.Utilice
solamenteaccesorioshomologadosporelfabricante.
Operaciónenpendientes
Laspendientessonunfactordeprimeraimportancia
relacionadoconaccidentes,especialmenteresbalonesycaídas,
quepuedencausarlesionesgraves.Entodaslaspendientesy
cuestassenecesitateneruncuidadoespecial.Siustednose
sienteconconanzaenunapendiente,nolasiegue.
•Sieguedetravéslascuestasypendientes,nuncahacia
arribaohaciaabajo.Extremelasprecaucionesalcambiar
dedirecciónencuestasopendientes.
•Estéalertaaagujeros,surcos,montículos,rocasu
otrosobjetosocultos.Losterrenosdesigualespueden
causarcaídasyresbalones.Lahierbaaltapuedeocultar
obstáculos.
•Nosieguelahierbamojadaoenpendientesexcesivamente
empinadas.Sinopisarme,puederesbalarycaer.
•Nosieguecercadeterraplenes,fosasotaludes.Usted
podríaperderelequilibrooresbalar.
Niños
Puedenocurriraccidentestrágicossieloperadornoestá
alertaalapresenciadeniños.Amenudolosniñossesienten
atraídosporlamáquinaylaactividaddesegar.Nosuponga
nuncaquelosniñosvayanapermanecerenelúltimolugar
enquelosvio.
•Mantengaalosniñosalejadosdelazonadesiegaybajo
laatentamiradadeunadultoresponsablequenoseael
operador.
•Estéalertaypareelcortacéspedsientranniñosenlazona.
•Nuncapermitaalosniñosutilizarlamáquina.
•Extremelaprecauciónalacercarseaesquinasciegas,
arbustos,árbolesuotrosobjetosquepuedanimpedirque
ustedveaunniño.
Mantenimiento
Manejosegurodelagasolina
Paraevitarlesionespersonalesodañosmateriales,
extremelasprecaucionesalmanejarlagasolina.La
gasolinaesextremadamenteinamableylosvapores
sonexplosivos.
•Apaguecualquiercigarrillo,cigarro,pipauotrafuente
deignición.
•Utilicesolamenteunrecipientedegasolinahomologado.
•Noretirenuncaeltapóndecombustibleniañada
combustibleconelmotorenmarcha.Dejequeseenfríe
elmotorantesderepostarcombustible.
•Norepostenuncalamáquinaenunrecintocerrado.
•Noguardenuncalamáquinaounrecipientede
combustiblecercadeunallamadesnuda,chispaollama
piloto,porejemploenuncalentadordeaguauotro
electrodoméstico.
•Nollenenuncalosrecipientesdentrodeunvehículoo
sobrelaplataformadeuncamiónoremolqueconforro
deplástico.Coloquesiemprelosrecipientesdegasolina
enelsuelo,lejosdelvehículo,antesdellenarlos.
•Retireunequipoconmotordegasolinadelcamiónodel
remolqueyrepósteloenelsuelo.Siestonoesposible,
reposteelequipodesdeunrecipienteportátil,envezde
usarunsurtidoroboquilladosicadoradegasolina.
•Mantengalaboquillaencontactoconelbordedel
depósitodecombustibleoeloriciodelrecipienteen
todomomentohastaqueterminederepostar.Noutilice
dispositivosquemantenganabiertalaboquilla.
•Sisederramacombustiblesobresuropa,cámbiesede
ropainmediatamente.
•Nuncallenedemasiadoeldepósitodecombustible.
Vuelvaacolocareltapóndegasolinayapriételo
rmemente.
ADVERTENCIA
Losgasesdeescapedelmotorcontienenmonóxido
decarbono,queesunvenenoinodoroquepuede
matarle.
Nohagafuncionarelmotordentrodeunedicioo
enunlugarcerrado.
Mantenimientogeneral
•Nohagafuncionarnuncalamáquinaenunlugarcerrado.
3

•Mantengaapretadostodoslospernosytuercaspara
asegurarsedequeelequipoestáencondicionesde
funcionamientoseguras.
•Nomanipulenuncalosdispositivosdeseguridad.
Comprueberegularmentequefuncionancorrectamente.
•Mantengalamáquinalibredeacumulacionesdehierba,
hojasyotrosresiduos.Limpiecualquierderramede
aceiteocombustibleyretirecualquierresiduoempapado
encombustible.Dejequeseenfríelamáquinaantesde
almacenarla.
•Sigolpeaunobjetoextraño,pareeinspeccionela
máquina.Siesnecesario,repárelaantesdearrancarde
nuevo.
•Nuncahagaajustesoreparacionesconelmotoren
marcha.Desconecteelcabledelabujíayhagamasacon
élcontraelmotorparaevitarunarranqueaccidental.
•Compruebefrecuentementeloscomponentesdel
recogedoryelprotectordedescargaysustitúyalos
porpiezasrecomendadasporelfabricantecuandosea
necesario.
•Lascuchillasdelcortacéspedestánmuyaladas.Envuelva
lacuchillaolleveguantes,yextremelasprecaucionesal
manejarlascuchillas.
•Nocambielosajustesdelreguladordelmotornihaga
funcionarelmotoraunavelocidadexcesiva.
•Reviseosustituyalaspegatinasdeseguridade
instruccionescuandoseanecesario.
4
