Toro 30608 30644 User manual

FormNo.3440-741RevB
Groundsmaster®4100or4110
RotaryMower
ModelNo.30608—SerialNo.405600000andUp
ModelNo.30608—SerialNo.405700000andUp
ModelNo.30644—SerialNo.405600000andUp
Registeratwww.Toro.com.
OriginalInstructions(EN)*3440-741*

ThisproductcomplieswithallrelevantEuropean
directives;fordetailspleaseseetheseparateproduct
specicDeclarationofConformity(DOC)sheet.
ItisaviolationofCaliforniaPublicResourceCode
Section4442or4443touseoroperatetheengineon
anyforest-covered,brush-covered,orgrass-covered
landunlesstheengineisequippedwithaspark
arrester,asdenedinSection4442,maintainedin
effectiveworkingorderortheengineisconstructed,
equipped,andmaintainedforthepreventionofre.
Theenclosedengineowner'smanualissupplied
forinformationregardingtheUSEnvironmental
ProtectionAgency(EPA)andtheCaliforniaEmission
ControlRegulationofemissionsystems,maintenance,
andwarranty.Replacementsmaybeorderedthrough
theenginemanufacturer.
WARNING
CALIFORNIA
Proposition65Warning
Dieselengineexhaustandsomeofits
constituentsareknowntotheStateof
Californiatocausecancer,birthdefects,
andotherreproductiveharm.
Batteryposts,terminals,andrelated
accessoriescontainleadandlead
compounds,chemicalsknownto
theStateofCaliforniatocause
cancerandreproductiveharm.Wash
handsafterhandling.
Useofthisproductmaycauseexposure
tochemicalsknowntotheStateof
Californiatocausecancer,birthdefects,
orotherreproductiveharm.
Introduction
Thismachineisamulti-purposemachineintended
tobeusedbyprofessional,hiredoperatorsin
commercialapplications.Itisdesignedprimarilyfor
mowinggrassonwell-maintainedlawnsinparks,golf
courses,sportselds,andoncommercialgrounds.
Usingthisproductforpurposesotherthanitsintended
usecouldprovedangeroustoyouandbystanders.
Readthisinformationcarefullytolearnhowtooperate
andmaintainyourproductproperlyandtoavoid
injuryandproductdamage.Youareresponsiblefor
operatingtheproductproperlyandsafely.
Visitwww.T oro.comforproductsafetyandoperation
trainingmaterials,accessoryinformation,helpnding
adealer,ortoregisteryourproduct.
Wheneveryouneedservice,genuineT oroparts,or
additionalinformation,contactanAuthorizedService
DealerorToroCustomerServiceandhavethemodel
andserialnumbersofyourproductready.Figure1
identiesthelocationofthemodelandserialnumbers
ontheproduct.Writethenumbersinthespace
provided.
Important:Withyourmobiledevice,youcan
scantheQRcodeontheserialnumberdecal(if
equipped)toaccesswarranty,parts,andother
productinformation.
g243944
Figure1
1.Modelandserialnumberlocation
ModelNo.
SerialNo.
Thismanualidentiespotentialhazardsandhas
safetymessagesidentiedbythesafety-alertsymbol
(Figure2),whichsignalsahazardthatmaycause
seriousinjuryordeathifyoudonotfollowthe
recommendedprecautions.
g000502
Figure2
1.Safety-alertsymbol
Thismanualuses2wordstohighlightinformation.
Importantcallsattentiontospecialmechanical
informationandNoteemphasizesgeneralinformation
worthyofspecialattention.
©2021—TheToro®Company
8111LyndaleAvenueSouth
Bloomington,MN554202
Contactusatwww.Toro.com.
PrintedintheUSA
AllRightsReserved

Contents
Safety.......................................................................4
GeneralSafety...................................................4
SafetyandInstructionalDecals..........................4
Setup......................................................................14
1GreasingtheMachine....................................14
2CheckingtheTirePressure............................14
3CheckingtheFluidLevels..............................15
4InstallingtheDecal(CEMachines
Only).............................................................15
ProductOverview...................................................16
Controls...........................................................16
CabControls.................................................18
Specications..................................................20
Attachments/Accessories.................................21
BeforeOperation.................................................22
GeneralSafety.................................................22
FuelSafety.......................................................22
CheckingtheEngine-OilLevel..........................22
CheckingtheCoolingSystem...........................22
CheckingtheHydraulicSystem........................22
DrainingtheWaterSeparator...........................22
FillingtheFuelTank..........................................22
CheckingtheTirePressure...............................23
CheckingtheTorqueoftheWheelLug
Nuts..............................................................24
AdjustingtheMirrors.........................................24
AimingtheHeadlights.......................................25
AdjustingtheRolloverProtectionSystem
(ROPS).........................................................25
AdjustingtheHeightofCut...............................26
AdjustingtheSkids...........................................28
AdjustingtheMower-DeckRollers....................28
AdjustingtheBlade...........................................29
CorrectingaMismatchBetweentheCutting
Units..............................................................29
CheckingtheSafety-InterlockSwitches............31
SelectingaBlade..............................................32
UsingtheInfoCenterControl............................32
UsingtheMenus...............................................34
ProtectedMenus..............................................35
AccessingProtectedMenus.............................35
SettingtheAutoIdle.........................................36
SettingtheMaximumAllowedMow
Speed...........................................................36
SettingtheMaximumAllowedTransport
Speed...........................................................36
SettingtheServiceDueTimer...........................36
DuringOperation.................................................37
DuringOperationSafety...................................37
UnderstandingtheOperatingCharacteristics
oftheMachine..............................................38
OperatingtheMachine.....................................39
UnderstandingCounterbalance........................39
UsingtheBrakePedals....................................39
UnderstandingToroSmartPower™.................39
PerformingaFan-ReverseOperation...............39
UnderstandingAutoIdle...................................40
UsingtheCruiseControl...................................40
StartingtheEngine...........................................40
ShuttingOfftheEngine.....................................40
UsingtheEngine-SpeedSwitch........................40
AdjustingtheMowingSpeed............................40
AdjustingtheTransportSpeed..........................41
DieselParticulateFilterRegeneration...............41
OperatingTips.................................................54
AfterOperation....................................................55
GeneralSafety.................................................55
PushingorTowingtheMachine........................55
LocatingtheJackingPoints..............................55
HaulingtheMachine.........................................56
LocatingtheTie-DownPoints...........................56
Maintenance...........................................................57
MaintenanceSafety..........................................57
RecommendedMaintenanceSchedule(s)...........57
DailyMaintenanceChecklist.............................59
Pre-MaintenanceProcedures..............................61
OpeningtheHood............................................61
RemovingtheHood..........................................61
Lubrication..........................................................62
GreasingtheBearingsandBushings................62
EngineMaintenance...........................................65
EngineSafety...................................................65
ServicingtheEngineOil....................................65
ServicingtheAirCleaner..................................66
ServicingtheDiesel-OxidationCatalyst
(DOC)andtheSootFilter..............................68
FuelSystemMaintenance...................................69
ServicingtheFuelSystem................................69
ServicingtheWaterSeparator..........................69
ServicingtheFuelFilter....................................69
PrimingtheFuelSystem...................................70
ElectricalSystemMaintenance...........................70
ElectricalSystemSafety...................................70
ServicingtheBattery.........................................70
LocatingtheFuses...........................................71
DriveSystemMaintenance..................................72
AdjustingtheTraction-PedalAngle...................72
CheckingthePlanetary-Gear-Drive
Oil.................................................................72
ChangingthePlanetary-Gear-Drive
Oil.................................................................73
CheckingtheRear-AxleLubricant....................73
CheckingtheRear-Axle-Gearbox
Lubricant.......................................................74
ChangingtheRear-AxleLubricant....................74
CheckingtheRearWheelT oe-In......................75
ChangingtheFrontTires..................................75
CoolingSystemMaintenance..............................75
CoolingSystemSafety.....................................75
CoolantSpecication........................................75
CheckingtheCoolingSystem...........................76
ServicingtheEngine-CoolingSystem...............76
BrakeMaintenance.............................................77
AdjustingtheServiceBrakes............................77
3

BeltMaintenance................................................77
ServicingtheAlternatorBelt.............................77
ServicingtheAirConditionerCompressor
Belt................................................................77
TensioningtheBlade-DriveBelts......................78
ReplacingtheBlade-DriveBelt.........................78
HydraulicSystemMaintenance...........................79
HydraulicSystemSafety...................................79
ServicingtheHydraulicSystem........................79
CuttingUnitMaintenance.....................................83
Pivoting(Tilting)theCenterCuttingUnitto
theUprightPosition.......................................83
PivotingtheCenterCuttingUnitDown..............83
AdjustingtheCutting-UnitPitch........................84
ServicingtheCaster-ArmBushings..................84
ServicingtheCasterWheelsand
Bearings........................................................85
ReplacingtheCuttingUnitHinge
Covers..........................................................86
BladeMaintenance..............................................86
BladeSafety.....................................................86
CheckingforaBentBlade................................86
RemovingandInstallingtheCutting-Unit
Blade(s)........................................................87
InspectingandSharpeningtheCuttingUnit
Blade(s)........................................................87
CorrectingaCuttingUnitMismatch...................88
CabMaintenance.................................................89
CleaningtheCab..............................................89
CleaningtheCabAirFilters..............................89
CleaningtheCabPre-Filter..............................90
CleaningtheAir-ConditioningCoil....................90
Storage...................................................................91
StorageSafety..................................................91
PreparingtheMachineforStorage...................91
Safety
Thismachinehasbeendesignedinaccordancewith
ANSIB71.4-2017andwithENISO5395whenyou
completethesetupproceduresandinstalltheCEkit,
pertheDeclarationofConformity.
GeneralSafety
Thisproductiscapableofamputatinghandsand
feetandofthrowingobjects.Alwaysfollowallsafety
instructionstoavoidseriouspersonalinjury.
•Readandunderstandthecontentsofthis
Operator’sManualbeforestartingtheengine.
•Useyourfullattentionwhileoperatingthe
machine.Donotengageinanyactivitythat
causesdistractions;otherwise,injuryorproperty
damagemayoccur.
•Donotoperatethemachinewithoutallguards
andothersafetyprotectivedevicesinplaceand
functioningproperlyonthemachine.
•Keepyourhandsandfeetawayfromrotating
parts.Keepclearofthedischargeopening.
•Keepbystandersandchildrenoutoftheoperating
area.Neverallowchildrentooperatethemachine.
•Shutofftheengine,removethekey,andwait
forallmovementtostopbeforeyouleavethe
operator’sposition,Allowthemachinetocool
beforeadjusting,servicing,cleaning,orstoringit.
Improperlyusingormaintainingthismachinecan
resultininjury.Toreducethepotentialforinjury,
complywiththesesafetyinstructionsandalways
payattentiontothesafety-alertsymbol,which
meansCaution,Warning,orDanger—personalsafety
instruction.Failuretocomplywiththeseinstructions
mayresultinpersonalinjuryordeath.
SafetyandInstructionalDecals
Safetydecalsandinstructionsareeasilyvisibletotheoperatorandarelocatednearanyarea
ofpotentialdanger.Replaceanydecalthatisdamagedormissing.
decal58-6520
58-6520
1.Grease
decal93-6674
93-6674
1.Crushinghazard,hand—readtheinstructionsbefore
servicingorperformingmaintenance.
4

decal93-7272
93-7272
1.Cutting/dismembermenthazard;fan—stayawayfrom
movingparts.
decal93-7818
93-7818
1.Warning—readtheOperator'sManualforinstructionson
torquingthebladebolt/nutto115to149N∙m(85to110
ft-lb).
decal100-5622
100-5622
1.Height-of-cutadjustment
decal100-5623
100-5623
1.Lowheight-of-cut
adjustment
2.Highheight-of-cut
adjustment
decal100-6578
100-6578
1.Entanglementhazard,belt—donotoperatethemachine
withtheshieldsorguardsremoved;alwayskeeptheshields
andguardsinplace;stayawayfrommovingparts.
decal104-3579
104-3579
1.Lowheight-of-cut
adjustment
2.Highheight-of-cut
adjustment
decal106-4250
106-4250
1.Heightofcut
decal106-4251
106-4251
1.Heightofcut
5

decal106-6754
106-6754
1.Warning—donottouchthehotsurface.
2.Cutting/dismembermenthazard,fan;entanglementhazard,
belt—stayawayfrommovingparts.
decal106-6755
106-6755
1.Enginecoolantunder
pressure.
3.Warning—donottouchthe
hotsurface.
2.Explosionhazard—read
theOperator'sManual.
4.Warning—readthe
Operator'sManual.
decal114-0849
114–0849
1.Warning—1)Disengage
thePTO;2)Raisethedeck
4.Forwarddirection
2.Donotplaceyourfoot
here.
5.Reversedirection
3.Directionpedal
6

decal120-4159
120-4159
1.Off8.High
2.Lights9.Tractiondrive
3.On10.Low
4.Lightswitchlocation11.PTO
5.Fast12.Lowerleftdeck
6.Variablespeedadjustment13.Lowercenterdeck
7.Slow14.Lowerrightdeck
decal120-6604
120-6604
1.Thrownobjecthazard—keepbystandersawayfromthe
machine.
2.Cutting/dismembermenthazardofhand,mower
blade—stayawayfrommovingparts;keepallguardsand
shieldsinplace.
3.Cutting/dismembermenthazardoffoot,mowerblade—stay
awayfrommovingparts;keepallguardsandshieldsin
place.
7

decal120-8947
120-8947
1.Warning—readthe
Operator’sManual.
4.Iftherollbarisraised,
weartheseatbelt.
2.Thereisnorollover
protectionwhentheroll
barisdown.
5.Iftherollbarislowered,
donotweartheseatbelt.
3.Thereisrolloverprotection
whentherollbarisup.
6.Driveslowlywhenturning.
decal121-3884
121–3884
1.Engine—stop3.Engine—start
2.Engine—preheat
decal121-3887
121–3887
1.ReadtheOperator’sManual.
decalbatterysymbols
BatterySymbols
Someorallofthesesymbolsareonyourbattery.
1.Explosionhazard6.Keepbystandersaway
fromthebattery.
2.Nore,opename,or
smoking
7.Weareyeprotection;
explosivegasescan
causeblindnessandother
injuries.
3.Causticliquid/chemical
burnhazard
8.Batteryacidcancause
blindnessorsevereburns.
4.Weareyeprotection.9.Flusheyesimmediately
withwaterandgetmedical
helpfast.
5.ReadtheOperator's
Manual.
10.Containslead;donot
discard
decal125-9688
125-9688
1.Off3.On
2.Windshieldwipers4.Spraywindshieldwasher
uid.
8

decal121-1592
127-3700
1.Raisetheleftdeck.4.Locktheenginespeed.
2.Raisethecenterdeck.5.Unlocktheenginespeed.
3.Raisetherightdeck.
decal130-0594
130-0594
1.Warning—readtheOperator’sManual;whensittinginthe
cab,alwayswearaseatbelt;wearhearingprotection.
decal130-0611
130-0611
1.Warning—removethepin,raisethedoors,andexitthecab.
decal130-5355
130-5355
1.Closetherearwindow.2.Raisethehood.
decal130-5357
130-5357
1.Pushforwardtomove
forward.
2.Pushbacktoreverse.
decal130-5733
130-5733
1.Attention;readtheOperator'sManual—1)Removethe
optionaltrashbag;2)Tilttheseatforward.
decal130-5980
130-5980
1.Attention;readtheOperator'sManual—T oleavethe
machine:1)Lowerthecuttingdeck;2)Leavethemachine.
9

decal133-8062
133-8062
decal114-0846
114-0846
1.ReadtheOperator’sManualforinformationonstartingthe
engine—1)Settoneutral;2)Engagethebrake;3)Setthe
enginespeedtoslow;4)Turnthekeytopreheat;5)Turn
thekeytostarttheengine.
2.ReadtheOperator’sManualforinformationonshuttingoff
theengine—1)Settheenginespeedtoslow;2)Disengage
thedeck;3)Locktheparkingbrake;4)Wait5minutes;5)
Turnthekeytoshutofftheengine;6)Removethekey
fromtheswitch.
3.ReadtheOperator’sManual.
4.PulltheknobouttoengagethePTO.
5.PushtheknobintodisengagethePTO.
6.RaisethedeckstogotoHrange.
decal132-3600
132-3600
Cabonly
1.ReadtheOperator's
Manualformore
informationonfuses.
5.Workinglight(20A)
2.Headlight(25A)6.Auxiliarypower(15A)
3.CondenserfanandA/C
clutch(30A)
7.Cablight(15A)
4.Fan(25A)8.Windshieldwipers(15A)
decal120-0250
120-0250
1.Slow-movingvehicle
10

decal117-2754
117-2754
1.Warning—readtheOperator'sManual.
2.Warning—donotoperatethismachineunlessyouaretrained.
3.Warning—weartheseatbeltwhenseatedintheoperator'sposition.
4.Warning—wearhearingprotection.
5.Thrownobjecthazard—keepbystandersaway.
6.Cuttinghazardofhandorfoot—stayawayfrommovingparts;keepallguardsandshieldsinplace.
7.Tippinghazard—lowerthecuttingunitwhendrivingdownslopes;slowthemachinebeforeturning;donotturnathighspeeds.
8.Warning—engagetheparkingbrake,shutofftheengine,andremovethekeybeforeleavingthemachine.
AfxoverPartNo.117-2754forCEmachines.
decal117-2766
117-2766
Note:Thismachinecomplieswiththeindustrystandardstabilitytestinthestaticlateralandlongitudinaltestswiththemaximum
recommendedslopeindicatedonthedecal.ReviewtheinstructionsforoperatingthemachineonslopesintheOperator’sManualas
wellastheconditionsinwhichyouwouldoperatethemachinetodeterminewhetheryoucanoperatethemachineintheconditionson
thatdayandatthatsite.Changesintheterraincanresultinachangeinslopeoperationforthemachine.
1.Warning—readtheOperator'sManual.
2.Warning—alloperatorsshouldbetrainedbeforeoperatingthemachine.
3.Warning—weartheseatbelt.
4.Warning—wearhearingprotection.
5.Thrownobjecthazard—keepbystandersaway.
6.Cutting/dismembermenthazardofhandsorfeet—stayawayfrommovingparts;keepallguardsandshieldsinplace.
7.Tippinghazard—lowerthecuttingunitwhendrivingdownslopes;donotoperateonslopesgreaterthan15°.
8.Warning—engagetheparkingbrake,shutofftheengine,andremovethekeybeforeleavingthemachine.
11

decal121-8378
121-8378
1.Fan—off3.Coldair5.Externalair7.Airconditioner—on(If
equipped)
2.Fan—onfull4.Hotair6.Internalair8.Airconditioner—off(If
equipped)
decal136-4436
136-4436
1.ReadtheOperator’sManualforinformationonfuses.7.Infocenter—2A
2.Enginepreheat—60A8.Headlights—15A
3.Powersupply—7.5A9.Powerseat—10A
4.Turnsignals—10A10.Lighter—10A
5.Enginecontrolunit—10A11.Horn—10A
6.Systempower—10A
12

decal137-5495
137-5495
1.ReadtheOperator’sManual.
decal137-5498
137-5498
1.ReadtheOperator’sManual.
13

Setup
LooseParts
Usethechartbelowtoverifythatallpartshavebeenshipped.
ProcedureDescriptionQty.Use
1Nopartsrequired–Greasethemachine.
2Nopartsrequired–Checkthetirepressure.
3Nopartsrequired–Checktheuidlevels.
4Production-yeardecal1Installthedecal(CEmachinesonly).
MediaandAdditionalParts
DescriptionQty.Use
Operator'sManual1Reviewbeforeoperatingmachine
EngineOwner'sManual1Usetoreferenceengineinformation
DeclarationofConformity1
Ignitionkeys2Starttheengine.
CasterCapWrench1Usetoadjustcasterwheelassemblies
Note:Determinetheleftandrightsidesofthe
machinefromthenormaloperatingposition.
1
GreasingtheMachine
NoPartsRequired
Procedure
Greasethemachinebeforeuse;refertoLubrication
(page62).
Important:Failuretoproperlygreasethe
machinewillresultinprematurefailureofcritical
parts.
2
CheckingtheTirePressure
NoPartsRequired
Procedure
Checkthetirepressure;refertoCheckingtheTire
Pressure(page23).
Important:Maintainpressureinalltiresto
ensureagoodquality-of-cutandpropermachine
performance.Donotunderinatethetires.
14

3
CheckingtheFluidLevels
NoPartsRequired
Procedure
1.Checktheengine-oillevel;refertoCheckingthe
Engine-OilLevel(page65).
2.Checkthehydraulic-uidlevel;refertoChecking
theHydraulicFluid(page80).
3.Checkthecoolingsystem;refertoCheckingthe
CoolingSystem(page76).
4.Checktheplanetary-gear-driveoil;referto
CheckingthePlanetary-Gear-DriveOil(page
72).
5.Checktherear-axlelubricant;refertoChecking
theRear-AxleLubricant(page73).
6.Checktherear-axle-gearboxlubricant;refer
toCheckingtheRear-Axle-GearboxLubricant
(page74).
4
InstallingtheDecal(CE
MachinesOnly)
Partsneededforthisprocedure:
1Production-yeardecal
Procedure
OnmachinesrequiringCEcompliance,installthe
production-yeardecalincludedintheloosepartsand
theCEKit,soldseparately(Figure3).
g279510
Figure3
1.Production-yeardecal
15

ProductOverview
Controls
Note:Determinetheleftandrightsidesofthe
machinefromthenormaloperatingposition.
Becomefamiliarwithallthecontrolsbeforeyoustart
theengineandoperatethemachine.
g203048
Figure4
1.Brakepedal4.Parkingbrake
2.Pedal-lockinglatch5.Tilt-steeringlever
3.Tractionpedal
TractionPedal
Tostopthemachine,reducetheamountoffoot
pressurethatyouapplytothetractionpedaluntilthe
pedalreturnstotheNEUTRALposition(Figure4).
BrakePedals
Thereare2footpedalsthatoperateindividualwheel
brakesforturningassistance,parking,andtoaidin
betterside-hilltraction.Alatchconnectsthepedals
forparking-brakeoperationandtransport(Figure4).
Pedal-LockingLatch
Thepedal-lockinglatchconnectsthepedalstogether
toengagetheparkingbrake(Figure4).
Tilt-SteeringLever
Pressthetilt-steeringleverdowntotiltthesteering
wheeltothedesiredposition,thenreleasethelever
tolocktheadjustment(Figure4).
Parking-BrakeLatch
Toengagetheparkingbrake,connectthe2pedals
togetherwiththelockinglatchlocatedbehindthe
pedalpads,andpushdownontheparking-brakelatch
whileyouarepushingonthebrakepedals(Figure4).
Toreleasetheparkingbrake,pressthebrakepedals
andthelatchwilldisengageallowingthepedalsto
cometothedisengagedposition.Ensurethepedals
havefullyretractedafterdisengagingtheparking
brake.
KeySwitch
Thekeyswitch(Figure5)has3positions:OFF,
ON/PREHEAT,andSTART.
g028453
Figure5
1.Liftswitches5.High-Lowspeedcontrol
2.PTOswitch6.Engine-speedswitch
3.Keyswitch7.Lightswitch(optional)
4.InfoCenter
Engine-SpeedSwitch
Theengine-speedswitch(Figure5)has2modesto
changetheenginespeed.Taptheswitchtoincrease
ordecreasetheenginespeedin100rpmincrements.
HolddowntheswitchtoautomaticallymovetoHigh
orLowidle,dependingonwhichendoftheswitch
youpress.
16

PTOSwitch
ThePTOswitchhas2positions:OUT(START)and
IN(STOP).PullthePTObuttonouttoengagethe
mower-deckblades.Pushthebuttonintodisengage
themower-deckblades(Figure5).
High-LowSpeed-ControlSwitch
TheHigh-Lowspeed-controlswitchallowsthespeed
rangetoincreasefortransportofthemachine(Figure
5).
Mowerdecksdonotoperateinhighrange.T oswitch
betweentheHIGHandLOWrange,raisethedecks,
disengagethePTOandthecruisecontrol,movethe
tractionpedalintheNEUTRALposition,andhavethe
machinemoveataslowspeed.
LiftSwitches
Theliftswitchesraiseandlowerthecuttingunits
(Figure5).Presstheswitchesforwardtolowerthe
cuttingunitsandrearwardtoraisethecuttingunits.
Whenstartingthemachine,withthecuttingunitsin
thedownposition,presstheliftswitchdowntoallow
thecuttingunitstooatandmow.
Note:Thecuttingunitsdonotlowerwhileinthe
high-speedrangeandtheydonotraiseorlowerifyou
areoutoftheseatwhiletheengineisrunning.Also,
thecuttingunitslowerwiththekeyintheONposition
andyouareintheseat.
Cruise-ControlSwitch
Thecruise-controlswitchlocksinthepedalposition
tomaintainthedesiredgroundspeed(Figure6).
Pressingtherearoftheswitchturnsoffthecruise
control,themiddlepositionoftheswitchenablesthe
cruise-controlfunction,andthefrontoftheswitchsets
thedesiredgroundspeed.
Note:Pressingeitherbrakepedalormovingthe
tractionpedalintotheREVERSEposition,for1second,
alsodisengagesthepedalposition.
g028454
Figure6
1.Power-pointport2.Cruise-controlswitch
Power-PointPort
Usethepower-pointporttopoweroptionalelectrical
accessories(Figure6).
17

SeatControls
Seat-AdjustmentLever
Movetheseat-adjustmentleveronthesideofthe
seatoutward,slidetheseattothedesiredposition,
andreleasethelevertolocktheseatintoposition
(Figure7).
g037412
Figure7
1.Seat-adjustmentlever4.Weightgauge
2.Armrest-adjustmentknob5.Seat-backadjustment
lever
3.Weight-adjustmentlever
Armrest-AdjustmentKnob
Rotatetheknobtoadjustthearmrestangle(Figure7).
Seat-Back-AdjustmentLever
Movethelevertoadjusttheseat-backangle(Figure
7).
WeightGauge
Theweightgaugeindicateswhentheseatisadjusted
totheweightoftheoperator(Figure7).Adjustthe
heightbypositioningthesuspensionwithintherange
ofthegreenregion.
Weight-AdjustmentLever
Usethislevertoadjusttotheproperweightofthe
operator(Figure7).Pullupthelevertoincrease
theairpressureandpushdowntodecreasetheair
pressure.Theproperadjustmentiscorrectwhenthe
weightgaugeisinthegreenregion.
CabControls
g028431
Figure8
1.Air-recirculationcontrol5.Poweroutlet
2.Fancontrol6.Lightsswitch
3.Temperaturecontrol7.Flashersswitch
4.Windshield-wiperswitch8.Air-conditioningswitch
AirRecirculationControl
Setsthecabtoeitherrecirculatetheairinthecabinor
todrawairintothecabinfromoutside(Figure8).
•Setittorecirculatetheairwhenusingtheair
conditioning.
•Setittodrawairinwhenusingtheheaterorfan.
Fan-ControlKnob
Rotatethefan-controlknobtoregulatethespeedof
thefan(Figure8).
Temperature-Control-Knob
Rotatethetemperature-controlknobtoregulatethe
airtemperatureinthecab(Figure8).
Windshield-WiperSwitch
Usethisswitchtoturnthewindshieldwipersonor
off(Figure8).
Air-ConditioningSwitch
Usethisswitchtoturntheairconditioningonoroff
(Figure8).
PowerOutlet
Usethis15A,12VDCpoweroutlettopower
compatibledevices(Figure8).
LightsSwitch
Usethisswitchtoturntheheadlightsandtaillighton
oroff(Figure8).
18

FlashersSwitch
Usethisswitchtoturntheashers(hazardlights)on
oroff(Figure8).
WindshieldLatch
Liftupthelatchestoopenthewindshield(Figure9).
PressinthelatchtolockthewindshieldtotheOPEN
position.Pulloutanddownonthelatchtocloseand
securethewindshield.
g196911
Figure9
1.Windshieldlatch
RearWindowLatch
Liftupthelatchestoopentherearwindow.Pressin
onthelatchtolockthewindowinOPENposition.Pull
outanddownonthelatchtocloseandsecurethe
window(Figure9).
Important:Closetherearwindowbeforeopening
thehoodordamagemayoccurtothehoodorrear
window.
InfoCenterLCDDisplay
TheInfoCenterLCDdisplay(Figure5)shows
informationaboutyourmachine,suchastheoperating
status,variousdiagnostics,andotherinformation
aboutthemachine
Thescreensthatdisplaydependonwhichbuttons
youselect.Thepurposeofeachbuttonmaychange
dependingonwhatisrequiredatthetime.
19

Specications
g203228
Figure10
20
