Toro 30789 User manual

Operator’s Manual
Domestic English (EN)
Form No. 3329–120
Groundsmaster 345
Traction Unit
Model No. 30789—Serial No. 230000001 and Up

2
All Rights Reserved
Printed in the USA
2002 by The Toro Company
8111 Lyndale Avenue South
Bloomington, MN 55420-1196
CALIFORNIA
Proposition 65 Warning
The engine exhaust from this product contains
chemicals known to the State of California to cause
cancer, birth defects, or other reproductive harm.
Warning
Contents
Page
Introduction 3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Safety 4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Safe Operating Practices 4. . . . . . . . . . . . . . . . . . . .
Toro Riding Mower Safety 6. . . . . . . . . . . . . . . . . .
Safety and Instruction Decals 8. . . . . . . . . . . . . . . .
Specifications 11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
General Specifications 11. . . . . . . . . . . . . . . . . . . . .
Dimensions and Weights (approx.) 12. . . . . . . . . . .
Optional Equipment 12. . . . . . . . . . . . . . . . . . . . . . .
Setup 13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Loose Parts 13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installing the Steering Wheel 14. . . . . . . . . . . . . . . .
Removing the Battery from the Chassis 14. . . . . . . .
Installing the Seat 14. . . . . . . . . . . . . . . . . . . . . . . . .
Pushing the Traction Unit Off of the Pallet 16. . . . .
Activating and Charging the Battery 16. . . . . . . . . .
Installing the Battery in the Chassis 16. . . . . . . . . . .
Installing the Ball Joint and Connecting the Lift
Cylinder 17. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Checking the Tire Pressure 17. . . . . . . . . . . . . . . . . .
Checking the Torque of the Front Wheel Nuts 17. . .
Greasing the Traction Unit 18. . . . . . . . . . . . . . . . . .
Install Rear Weight 18. . . . . . . . . . . . . . . . . . . . . . . .
Before Operating 19. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Hood Prop 19. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Check Engine Oil 19. . . . . . . . . . . . . . . . . . . . . . . . .
Single Viscosity Oils 19. . . . . . . . . . . . . . . . . . . . . .
Multi– Viscosity Oils 19. . . . . . . . . . . . . . . . . . . . . .
Filling the Fuel Tank 20. . . . . . . . . . . . . . . . . . . . . .
Check Cooling System 20. . . . . . . . . . . . . . . . . . . . .
Checking the Hydraulic System Fluid 21. . . . . . . . .
Page
Operation 22. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Controls 22. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Starting/Stopping Engine 24. . . . . . . . . . . . . . . . . . .
Checking the Interlock Switches 25. . . . . . . . . . . . .
Pushing or Towing the Traction Unit 25. . . . . . . . . .
Operating Characteristics 26. . . . . . . . . . . . . . . . . . .
Maintenance 27. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Recommended Maintenance Schedule 27. . . . . . . . .
Daily Maintenance Checklist 28. . . . . . . . . . . . . . . .
Lubricating the Machine 29. . . . . . . . . . . . . . . . . . .
General Air Cleaner Maintenance 30. . . . . . . . . . . .
Servicing Dust Cup And Baffle 30. . . . . . . . . . . . . .
Servicing Air Cleaner Filter 30. . . . . . . . . . . . . . . . .
Inspecting Filter Element 31. . . . . . . . . . . . . . . . . . .
Cleaning the Radiator and Screen 31. . . . . . . . . . . .
Changing Engine Oil And Filter 31. . . . . . . . . . . . . .
Servicing Fuel System 32. . . . . . . . . . . . . . . . . . . . .
Cleaning Radiator And Screen 32. . . . . . . . . . . . . . .
Changing Coolant In Cooling System 32. . . . . . . . .
Servicing Belts 33. . . . . . . . . . . . . . . . . . . . . . . . . . .
Replacing Spark Plugs 34. . . . . . . . . . . . . . . . . . . . .
Adjusting Governor 34. . . . . . . . . . . . . . . . . . . . . . .
Checking Oil Level In Governor 35. . . . . . . . . . . . .
Servicing Spark Arrestor Muffler 35. . . . . . . . . . . . .
Adjusting Traction Control Rod 36. . . . . . . . . . . . . .
Adjusting Traction Pedal Friction Wheel 36. . . . . . .
Adjusting the Traction Drive for Neutral 36. . . . . . .
Adjusting the Traction Interlock Switch 37. . . . . . . .
Replacing the PTO Switch 37. . . . . . . . . . . . . . . . . .
Adjusting the Parking Brake Interlock Switch 38. . .
Adjusting the Tilt Steering Control 38. . . . . . . . . . .
Adjusting Rear Wheel Toe–in 38. . . . . . . . . . . . . . .
Adjusting the Rear Wheel Bearings 39. . . . . . . . . . .
Adjusting the Brakes 39. . . . . . . . . . . . . . . . . . . . . .
Replacing the Hydraulic Fluid Filter 40. . . . . . . . . .
Changing the Hydraulic System Fluid 40. . . . . . . . .
Fuses 41. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Servicing the Battery 42. . . . . . . . . . . . . . . . . . . . . .
Hydraulic Schematic 43. . . . . . . . . . . . . . . . . . . . . .
Electrical Schematic 44. . . . . . . . . . . . . . . . . . . . . . .
Seasonal Storage 45. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Traction Unit 45. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine 45. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
The Toro General Commercial Products Warranty 48. .

3
Introduction
Read this manual carefully to learn how to operate and
maintain your product properly. The information in this
manual can help you and others avoid injury and product
damage. Although Toro designs and produces safe
products, you are responsible for operating the product
properly and safely.
Whenever you need service, genuine Toro parts, or
additional information, contact an Authorized Service
Dealer or Toro Customer Service and have the model and
serial numbers of your product ready. Figure 1 illustrates
the location of the model and serial numbers on the
product.
1
Figure 1
1. Location of the model and serial numbers
Write the product model and serial numbers in the space
below:
Model No.
Serial No.
This manual identifies potential hazards and has special
safety messages that help you and others avoid personal
injury and even death. Danger, Warning, and Caution are
signal words used to identify the level of hazard. However,
regardless of the hazard, be extremely careful.
Danger signals an extreme hazard that will cause serious
injury or death if you do not follow the recommended
precautions.
Warning signals a hazard that may cause serious injury or
death if you do not follow the recommended precautions.
Caution signals a hazard that may cause minor or moderate
injury if you do not follow the recommended precautions.
This manual uses two other words to highlight information.
Important calls attention to special mechanical
information and Note: emphasizes general information
worthy of special attention.

4
Safety
This machine meets or exceeds ANSI B71.4-1999
specifications in effect at the time of production when
and equipped with rear weight as listed in the weight
chart.
Improper use or maintenance by the operator or owner
can result in injury. To reduce the potential for injury,
comply with these safety instructions and always pay
attention to the safety alert symbol, which means
CAUTION, WARNING, or DANGER—“personal
safety instruction.” Failure to comply with the
instruction may result in personal injury or death.
Safe Operating Practices
The following instructions are from ANSI B71.4-1999.
Training
•Read the operator’s manual and other training material
carefully. Be familiar with the controls, safety signs,
and the proper use of the equipment.
•If the operator or mechanic can not read the language of
is the owner’s responsibility to explain this material to
them.
•Never allow children or people unfamiliar with these
instructions to use or service the mower. Local
regulations may restrict the age of the operator.
•Never mow while people, especially children, or pets
are nearby.
•Keep in mind that the operator or user is responsible for
accidents or hazards occurring to other people or their
property.
•Do not carry passengers.
•All drivers and mechanics should seek and obtain
professional and practical instruction. The owner is
responsible for training the users. Such instruction
should emphasize:
– the need for care and concentration when working
with ride-on machines;
– control of a ride-on machine sliding on a slope will
not be regained by the application of the brake. The
main reasons for loss of control are:
•insufficient wheel grip;
•being driven too fast;
•inadequate braking;
•the type of machine is unsuitable for its task;
•lack of awareness of the effect of ground
conditions, especially slopes;
•incorrect hitching and load distribution.
•The owner/user can prevent and is responsible for
accidents or injuries occurring to himself or herself,
other people, or property.
Preparation
•While mowing, always wear substantial footwear, long
trousers, hard hat, safety glasses, and ear protection.
Long hair, loose clothing, or jewelry may get tangled in
moving parts. Do not operate the equipment when
barefoot or wearing open sandals.
•Thoroughly inspect the area where the equipment is to
be used and remove all objects which may be thrown by
the machine.
•Warning—Fuel is highly flammable. Take the
following precautions:
– Store fuel in containers specifically designed for this
purpose.
– Refuel outdoors only and do not smoke while
refueling.
– Add fuel before starting the engine. Never remove
the cap of the fuel tank or add fuel while the engine
is running or when the engine is hot.
– If fuel is spilled, do not attempt to start the engine
but move the machine away from the area of
spillage and avoid creating any source of ignition
until fuel vapors have dissipated.
– Replace all fuel tanks and container caps securely.
•Replace faulty silencers/mufflers.
•Evaluate the terrain to determine what accessories and
attachments are needed to properly and safely perform
the job. Only use accessories and attachments approved
by the manufacturer.
•Check that operator’s presence controls, safety switches
and shields are attached and functioning properly. Do
not operate unless they are functioning properly.
Operation
•Do not operate the engine in a confined space where
dangerous carbon monoxide fumes can collect.
•Mow only in daylight or in good artificial light.
•Before attempting to start the engine, disengage all
blade attachment clutches, shift into neutral, and engage
the parking brake.
•Do not put hands or feet near or under rotating parts.
Keep clear of the discharge opening at all times.

5
•Do not use on slopes of more than
–20°when mowing across a slope
–30°when mowing up or down a slope
•The maximum value of 50% of the limit of stability for
EN836 is
–10°when mowing across a slope
–15°when mowing up or down a slope
•Remember there is no such thing as a safe slope. Travel
on grass slopes requires particular care. To guard
against overturning:
– do not stop or start suddenly when going up or
downhill;
– engage clutch slowly, always keep machine in gear,
especially when travelling downhill;
– machine speeds should be kept low on slopes and
during tight turns;
– stay alert for humps and hollows and other hidden
hazards;
– never mow across the face of the slope, unless the
mower is designed for this purpose.
•Stay alert for holes in the terrain and other hidden
hazards.
•Use care when pulling loads or using heavy equipment.
– Use only approved drawbar hitch points.
– Limit loads to those you can safely control.
– Do not turn sharply. Use care when reversing.
– Use counterweight(s) or wheel weights when
suggested in the operator’s manual.
•Watch out for traffic when crossing or near roadways.
•Stop the blades rotating before crossing surfaces other
than grass.
•When using any attachments, never direct discharge of
material toward bystanders nor allow anyone near the
machine while in operation.
•Never operate the machine with damaged guards,
shields, or without safety protective devices in place. Be
sure all interlocks are attached, adjusted properly, and
functioning properly.
•Do not change the engine governor settings or
overspeed the engine. Operating the engine at excessive
speed may increase the hazard of personal injury.
•Before leaving the operator’s position:
– stop on level ground;
– disengage the power take-off and lower the
attachments;
– change into neutral and set the parking brake;
– stop the engine and remove the key.
•Disengage drive to attachments when transporting or
not in use.
•Stop the engine and disengage drive to attachment
– before refuelling;
– before removing the grass catcher/catchers;
– before making height adjustment unless adjustment
can be made from the operator’s position.
– before clearing blockages;
– before checking, cleaning or working on the mower;
– after striking a foreign object or if an abnormal
vibration occurs. Inspect the mower for damage and
make repairs before restarting and operating the
equipment.
•Reduce the throttle setting during engine run-out and, if
the engine is provided with a shut-off valve, turn the
fuel off at the conclusion of mowing.
•Keep hands and feet away from the cutting units.
•Look behind and down before backing up to be sure of
a clear path.
•Slow down and use caution when making turns and
crossing roads and sidewalks. Stop cylinders/reels if not
mowing.
•Be aware of the mower discharge direction and do not
point it at anyone.
•Do not operate the mower under the influence of
alcohol or drugs
•Use care when loading or unloading the machine into a
trailer or truck
•Use care when approaching blind corners, shrubs, trees,
or other objects that may obscure vision.
Maintenance and Storage
•Keep all nuts, bolts and screws tight to be sure the
equipment is in safe working condition.
•Never store the equipment with fuel in the tank inside a
building where fumes may reach an open flame or
spark.
•Allow the engine to cool before storing in any
enclosure.
•To reduce the fire hazard, keep the engine,
silencer/muffler, battery compartment and fuel storage
area free of grass, leaves, or excessive grease.

6
•Check the grass catcher frequently for wear or
deterioration.
•Keep all parts in good working condition and all
hardware and hydraulic fittings tightened. Replace all
worn or damaged parts and decals.
•If the fuel tank has to be drained, do this outdoors.
•Be careful during adjustment of the machine to prevent
entrapment of the fingers between moving blades and
fixed parts of the machine.
•On multi-spindle mowers, take care as rotating one
blade can cause other blades to rotate.
•Disengage drives, lower the cutting units, set parking
brake, stop engine and remove key and disconnect spark
plug wire. Wait for all movement to stop before
adjusting, cleaning or repairing.
•Clean grass and debris from cutting units, drives,
silencers/mufflers, and engine to help prevent fires.
Clean up oil or fuel spillage.
•Use jack stands to support components when required.
•Carefully release pressure from components with stored
energy.
•Disconnect battery and remove spark plug wire before
making any repairs. Disconnect the negative terminal
first and the positive last. Reconnect positive first and
negative last.
•Use care when checking the cylinders/reels. Wear
gloves and use caution when servicing them.
•Keep hands and feet away from moving parts. If
possible, do not make adjustments with the engine
running.
•Charge batteries in an open well ventilated area, away
from spark and flames. Unplug charger before
connecting or disconnecting from battery. Wear
protective clothing and use insulated tools.
Toro Riding Mower Safety
The following list contains safety information specific to
Toro products or other safety information that you must
know that is not included in the ANSI standard.
This product is capable of amputating hands and feet and
throwing objects. Always follow all safety instructions to
avoid serious injury or death.
Use of this product for purposes other than its intended use
could prove dangerous to user and bystanders.
Engine exhaust contains carbon monoxide, which
is an odorless, deadly poison that can kill you.
Do not run engine indoors or in an enclosed area.
Warning
•Know how to stop the engine quickly.
•Do not operate the machine while wearing tennis shoes
or sneakers.
•Wearing safety shoes and long pants is advisable and
required by some local ordinances and insurance
regulations.
•Handle fuel carefully. Wipe up any spills.
•Check the safety interlock switches daily for proper
operation. If a switch should fail, replace the switch
before operating the machine. After every two years,
replace all interlock switches in the safety system,
whether they are working properly or not.
•Before starting the engine, sit on the seat.
•Using the machine demands attention. To prevent loss
of control:
– Do not drive close to sand traps, ditches, creeks, or
other hazards.
– Reduce speed when making sharp turns. Avoid
sudden stops and starts.
– When near or crossing roads, always yield the
right-of-way.
– Apply the service brakes when going downhill to
keep forward speed slow and to maintain control of
the machine.
•Raise the cutting units when driving from one work
area to another.
•Do not touch the engine, silencer/muffler, or exhaust
pipe while the engine is running or soon after it has
stopped because these areas could be hot enough to
cause burns.
•If the engine stalls or loses headway and cannot make it
to the top of a slope, do not turn the machine around.
Always back slowly, straight down the slope.
•When a person or pet appears unexpectedly in or near
the mowing area, stop mowing. Careless operation,
combined with terrain angles, ricochets, or improperly
positioned guards can lead to thrown object injuries. Do
not resume mowing until the area is cleared.

7
Maintenance and Storage
•Make sure all hydraulic line connectors are tight and all
hydraulic hoses and lines are in good condition before
applying pressure to the system.
•Keep your body and hands away from pin hole leaks or
nozzles that eject hydraulic fluid under high pressure.
Use paper or cardboard, not your hands, to search for
leaks. Hydraulic fluid escaping under pressure can have
sufficient force to penetrate the skin and cause serious
injury. Seek immediate medical attention if fluid is
injected into skin.
•Before disconnecting or performing any work on the
hydraulic system, all pressure in the system must be
relieved by stopping the engine and lowering the cutting
units and attachments to the ground.
•Check all fuel lines for tightness and wear on a regular
basis. Tighten or repair them as needed.
•If the engine must be running to perform a maintenance
adjustment, keep hands, feet, clothing, and any parts of
the body away from the cutting units, attachments, and
any moving parts, especially the screen at the side of the
engine. Keep everyone away.
•To ensure safety and accuracy, have an Authorized Toro
Distributor check the maximum engine speed with a
tachometer. Maximum governed engine speed should be
3200 RPM.
•If major repairs are ever needed or if assistance is
desired, contact an Authorized Toro Distributor.
•Use only Toro-approved attachments and replacement
parts. The warranty may be voided if used with
unapproved attachments.

8
Safety and Instruction Decals
Safety decals and instructions are easily visible to the operator and are located near any area
of potential danger. Replace any decal that is damaged or lost.
27-7310
93-6686
1. Hydraulic oil 2. Read the Operator’s
Manual.
82-8940
1. Locks and unlocks the steering column
TRACTION PEDAL
27-7320
55-4300
77–3100
1. Fan blades can cause injury—stay away from moving parts.
67-1720
82-8930
1. Read the operator’s manual for further instructions.
67–1710

9
82-8970
1. Fill coolant to within 1 in. (25 mm) of the top of the tank.
2. Read the operator’s manual for further instructions.
27-7290
53-4420
105-7822
92-7802

10
105-0080

11
Specifications
Note: Specifications and design subject to change without notice.
General Specifications
Engine
Ford, 4 cycle, 4-cylinder, overhead valve, liquid cooled gas engine with centrifugal
water pump. Ford rates engine @ 52 hp (De–rated to 25.5 hp). Mechanically
governed to a maximum speed of 3200 ±100 rpm. 79 cu. in. (1300 cc)
displacement. Distributor less electronic ignition. 3.5 quart (3.25 liter) oil capacity;
replaceable oil filter. Forged connecting rods, cast iron cylinder head and block.
Mechanical fuel pump. Spark arrestor muffler is standard.
Air Cleaner Heavy duty, remote mounted
Cooling System Radiator has tube and fin construction with hydraulic oil cooler in lower tank.
Capacity of cooling system is approximately 6 quarts (5.7 l) of a 50% mixture of
permanent, ethylene glycol anti-freeze and water.
Electrical The 12 volt battery has 42 plates and is rated at 45 ampere hours. A 55 amp
alternator with integral regulator is standard.
Fuel System Fuel tank capacity is approximately 6-1/2 gal. (25 l).
Front Axle The heavy duty Dana GT 20 axle has reduction of 20:9:1. Axle has automotive type
differential, bevel gear pinion and ring gear with spur gear reduction from
transmission. All axle components are mounted in tapered roller bearings.
Transmission
The in-line hydrostatic transmission is mounted directly to the front axle and is
driven by flexible drive couplings. Operating pressure is 500 to 3000 psi (3447 to
20685 kPa) and normal charge pressure is 70 to 150 psi (453 to 1034 kPa).
Implement relief valve setting is 700 to 900 psi (4826 to 6205 kPa). Displacement is
0.913 cubic inch (15 cm3) per revolution, and transmission is controlled by
foot-actuated pedal. Front axle is the hydraulic fluid reservoir, and its capacity is 5
quarts (4.7 l). The 25 micron hydraulic filter is a screw on replaceable type. For
replacement filters, order Toro Part No. 23-9740.
Ground Speed Speed is infinitely variable from 0 to 9.5 MPH (0 to 15 km/h) forward or reverse.
Tires Two rear tires are 16 x 6.50-8, 4-ply, extra traction tread, on demountable, drop
center wheels. The two from tires are 23 x 8.50-12, extra traction tread, 4-ply rating,
on demountable, drop center wheels. Recommended air pressure for both the front
and rear tires is 21 psi (145 kPa).
Brakes Brakes controlled by 3 pedals. Two are for steering assist. Are individually
controlled by left foot. Third pedal operates both brakes; is controlled by either foot.
Parking brake latch provided for third pedal. Pedals are connected to brakes by
multi-stranded cable and conduit.
Steering
The 13 inch (33 cm) steering wheel is mounted on a steering valve consisting of a
control valve and metering section which regulates pressure and meters flow to the
steering cylinder. Minimum turning radius is 18 in. from center of turn to closest side
of drive wheel; however, zero turning radius results when individual wheel brakes
are used. Steering wheel adjustable fore and aft for operator comfort.
Main Frame Frame is welded, formed 11 ga. steel, reinforced with square and rectangular
tubing.
Instrument Panel and
Controls
Warning light cluster for battery, oil pressure and engine temperature. Hour–meter,
fuel gauge, ignition switch, coolant temperature switch and gauge to prevent
overheating, choke and throttle control are on instrument panel. Hand operated
PTO lever is located to right of the seat. Foot pedal control for transmission
operation at right of steering column.

12
General Specifications (continued)
PTO Drive
Shaft is driven by a tight-slack double “A” section, torque team V-belt directly from
output shaft of engine. Shaft is clutched by pivoting the shaft support with a spring
loaded, over center, hand operated lever. PTO speed 1810 RPM @ 3200 RPM
engine speed. Connection to implement is with high quality, needle bearing
universal joint with slip joint.
Implement Lift Cutting unit or implement is lifted by hydraulic cylinder that has 2-1/2 in. (64 mm)
bore and 3-1/4 in. (82 mm) stroke.
Dimensions and Weights
(approx.)
Width (measured from
outside of front tires) 46 in. (117 cm)
Length 91 in. (231 cm)
Height 50 in. (127 cm)
Height w/ROPS 78.5 in. (199 cm)
Dry Weight 1300 lb. (590 kg)
Wheel Base 49 in. (124 cm)
Optional Equipment
72” Side Discharge Cutting Unit Model No. 30722
72” Rear Discharge Cutting Unit Model No. 30710
72” Flex Deck Cutting Unit Model No. 30799
Guardian 72″Recycler Cutting Unit Model No. 30716
Cushion Seat Model No. 30623
Deluxe Suspension Seat Kit (requires
Model No. 30628) Model No. 30625
Seat Adapter Kit Model No. 30628
Armrest Kit
(for seat models 30623 & 30625) Model No. 30707
Speed Control Kit Model No. 30677
48 in. V-Plow
(requires Model No. 30757) Model No. 30750
V-Plow Mounting Kit
(w/o tire chains) Model No. 30757
Debris Blower Model No. 30855
Rotary Broom Model No. 30743
Quick Attach Receiver Kit
(for traction unit) Model No. 30711
Quick Attach (for Guardian 72″
Recycler Cutting Unit, Model No.
30716)
Model No. 30729
Quick Attach (for 72” Side
Discharge Cutting Unit, Model No.
30722, 72” Rear Discharge Cutting
Unit, Model No. 30710 and Rotary
Broom, Model No. 30743)
Model No. 30719
Tire Chains (front) (set of 2) Part No. 11-0390
Wheel Weight Kit (set of 2) Part No. 11-0440
Rear Weight Kit (set of 2) Part No. 24-5780
Rear Weight Kit (set of 1) Part No. 24-5790
4-Ply Wide Tire w/Rim, 23 x 10.5 x
12 (2 required; will not fit with 72”
Rear Discharge Cutting Unit, Model
No. 30710)
Part No. 62-7020
6–Ply Wide Tire w/ Rim
23 x 10.5 x 12 (2 required; will not
fit with 72” Rear Discharge Cutting
Unit, Model No. 30710)
Part No. 69-9870
Jack Pad Kit Part No.
106–4386

13
Setup
Note: Determine the left and right sides of the machine from the normal operating position.
Loose Parts
Note: Use the chart below to verify that all parts have been shipped.
Description Qty. Use
Steering wheel
Foam seal
Nut
Screw
Cap
1
1
1
1
1
Installing the steering wheel
Manual tube (shipped in tool box)
R-clamp 1 2Holding the operator’s manual. Install on right
underside of seat.
Right-hand ball joint (shipped in tool box) 1Install ball joint (implement installation) and
connect lift cylinder
Hydraulic oil filter 1Change after 10 hours
Parts catalog 1
Operator’s Manual (traction unit) 2Read before operating the machine.
Engine Dealer Listing 1
Operator Video 1Watch before operating the machine.
Registration card 1Fill out and return to Toro.

14
Installing the Steering Wheel
1. Move rear wheels so they point straight ahead.
2. Remove jam nut from steering shaft. Slide foam seal
and steering wheel onto steering shaft (Fig. 2).
3. Secure steering wheel to shaft with jam nut and tighten
it to 10–15 ft.-lb.
4. Install cap to steering wheel with screw (Fig. 2).
1
2
3
4
5
Figure 2
1. Steering wheel
2. Jam nut
3. Cap
4. Screw
5. Foam seal
Removing the Battery from the
Chassis
1. Release the two latches holding instrument cover in
place. Carefully remove instrument cover to expose the
battery.
2. Remove two wing nuts and hold down strap that secures
battery (Fig. 3). Lift battery out of chassis. Keep wing
nuts and hold down strap in safe place for later use.
CALIFORNIA
Proposition 65 Warning
Battery posts, terminals, and related accessories
contain lead and lead compounds, chemicals
known to the State of California to cause cancer
and reproductive harm. Wash hands after
handling.
Warning
1
2
3
4
Figure 3
1. Wing nuts
2. Hold down strap 3. Positive terminal 4. Negative terminal
Installing the Seat
The machine is shipped without the seat assembly. Either
optional Seat Kit, Model No. 30623 or 30625 must be
installed.
Seat Kit, Model No. 30623, Standard Seat
1. Loosely secure (2) R-clamps to right side of seat bottom
with 2 capscrews and flat washers supplied in kit
(Fig. 4). Install manual tube into R-clamps and tighten
capscrews (Fig. 4).
1
2
3
4
Figure 4
1. R-clamps
2. Seat support 3. Manual tube 4. Cap
2. Mount seat pivot bracket to frame with 2 flange screws
supplied in kit (Fig. 5)

15
1
Figure 5
1. Seat pivot bracket
3. Mount seat and seat support to seat pivot bracket with
pivot shaft and roll pin (Fig. 6).
1
2
Figure 6
1. Pivot shaft 2. Roll pin
4. Hold seat up with seat support rod (Fig. 7).
1
Figure 7
1. Seat support rod
5. Connect seat switch connector to traction unit wire
harness connector.
Seat Kit, Model No. 30625, Deluxe Seat
with Model No. 30628 Seat Adapter Kit
1. Mount seat suspension assembly to 4 capscrews on seat
bottom and secure with 4 lock washers, flat washers,
and nuts (Fig. 8).
2. Loosely secure 2 R-clamps to right side of seat bottom
with 2 capscrews and flat washers supplied in kit
(Fig. 8). Install manual tube into R-clamps and tighten
capscrews (Fig. 8).
3. Mount seat support over four threaded studs at the
bottom of seat suspension assembly and secure in place
with flangenuts (Fig. 8).
Note: When mounting seat suspension, use forward set of
mounting holes for a shorter operator, as shown in figure 7,
or rear set for a taller operator.
4. Mount seat pivot bracket to frame with (2) flange
screws supplied in kit (Fig. 5)
5. Mount seat and seat support to seat pivot bracket with
pivot shaft and roll pin (Fig. 6).
16
42
5
3
Figure 8
1. Seat suspension
assembly
2. R-clamps
3. Lock washer, flat washer,
and nut
4. Manual tube
5. Cap
6. Seat support
6. Hold seat up with seat support rod (Fig. 7).
7. Connect seat switch connector to traction unit wire
harness connector.

16
Pushing the Traction Unit Off
of the Pallet
1. Reach in and rotate bypass valve on transmission
(Fig. 9) counterclockwise 1/2 to 1 turn. Opening the
valve opens an internal passage in the pump, thereby
bypassing transmission oil. Because fluid is bypassed,
the machine can be pushed without damaging the
transmission.
1
Figure 9
1. Bypass valve
2. Lift machine over shipping braces and push machine off
pallet.
3. Close bypass valve by rotating it clockwise until it is
securely seated. Do not exceed 5 to 8 ft.-lb. (7 to
11 N⋅m). Do not start engine when valve is open.
Activating and Charging the
Battery
1. If battery is not filled with electrolyte or charged, bulk
electrolyte with 1.280 specific gravity @ 77° F
(25°C) must be purchased from a local battery supply
outlet.
Danger
Battery electrolyte contains sulfuric acid which is a
deadly poison and causes severe burns.
•Do not drink electrolyte and avoid contact with
skin, eyes or clothing. Wear safety glasses to
shield your eyes and rubber gloves to protect
your hands.
•Fill the battery where clean water is always
available for flushing the skin.
2. Remove filler caps from battery and slowly fill each
cell until electrolyte is just above the plates. Install filler
caps.
3. Connect a 3 to 4 amp. battery charger to the battery
posts. Charge the battery at a rate of 3 to 4 amperes for
4 to 8 hours.
4. When battery is fully charged, disconnect charger from
electrical outlet and battery posts.
5. Remove filler caps and slowly add electrolyte to each
cell until level is up to fill ring. Install fill caps.
Installing the Battery in the
Chassis
Battery terminals or metal tools could short
against metal machine components causing sparks.
Sparks can cause the battery gasses to explode,
resulting in personal injury.
•When removing or installing the battery, do not
allow the battery terminals to touch any metal
parts of the machine.
•Do not allow metal tools to short between the
battery terminals and metal parts of the
machine.
Warning
1. Install battery and secure with hold down strap and
wing nuts (Fig. 3).Remove tape over ends of each
cable.
2. Slide the red, positive battery cable (Fig. 3) onto
positive battery post and tighten nut securely.
Incorrect battery cable routing could damage the
machine and cables causing sparks. Sparks can
cause the battery gasses to explode, resulting in
personal injury.
•Always disconnect the negative (black) battery
cable before disconnecting the positive (red)
cable.
•Always connect the positive (red) battery cable
before connecting the negative (black) cable.
Warning
3. Slide the black, negative battery cable (Fig. 3) onto
negative battery post and tighten nut securely.
4. Coat both battery connections with either Grafo 112X
(skin-over) grease, Toro Part No. 505-47, petroleum
jelly or light grease to prevent corrosion and slide
rubber boot over positive terminal (Fig. 3).

17
5. Install the instrument cover and lock the two latches.
Installing the Ball Joint and
Connecting the Lift Cylinder
Note: Ball joints are not required for all implements; refer
to implement operator’s manual for requirements.
1. Thread jam nut fully onto right-hand ball joint.
2. Screw ball joint into right hand push arm until center of
ball joint is 2-3/8 in. (60 mm) away from front of push
arm (Fig. 10). Do not tighten jam nut.
1
2
4
4
Figure 10
1. Jam nut
2. Ball joint mount 3. 2-3/8 in. (60 mm) 4. Right-hand push arm
Sudden release of the spring-loaded push arms
could cause injury.
Acquire the help of another person to help push
the arms down during installation of the ball joints
or other implements.
Warning
3. Have a helper push down on the left push arm. Then
insert a 2 x 4 in. (51 x 102 mm) block of wood between
the frame and top of the push arm (Fig. 11). Screw ball
joint into left hand push arm until center of ball joint is
2-3/8 in. (60 mm) away from front of push arm
(Fig. 11). Do not tighten jam nut.
4. Carefully remove 2 x 4 in. (51 x 102 mm) block of
wood from between frame and push arm.
5. Remove spring pin from cylinder pin and slide cylinder
pin out of cylinder.
1
2
3
4
5
Figure 11
1. Jam nut
2. 2 x 4 in. (51 x 102 mm)
block
3. Left-hand push arm
4. Ball joint mount
5. 2-3/8 in. (60 mm)
6. Raise front of lift arm until hole in movable end of
cylinder lines up with holes in lift arm brackets. Use
caution as lift arm is spring-loaded. Hold parts together
with cylinder pin, spring pin, and cotter pin. Cotter pin
must be to the outside.
7. Install implement; refer to implement Operator’s
Manual for proper installation procedures.
Checking the Tire Pressure
The tires are over-inflated for shipping. Therefore, release
some of the air to reduce the pressure. Correct air pressure
in the front and rear tires is 21 psi (145 kPa).
Checking the Torque of the
Front Wheel Nuts
Failure to maintain proper torque of the front
wheel nuts could result in failure, loss of wheel, or
personal injury.
Torque the front wheel nuts to 45–55 ft.-lb.
(61–75 Nm) after 1–4 hours of operation and
again after 10 hours of operation. Torque every
250 hours thereafter.
Warning

18
Greasing the Traction Unit
Before the machine is operated, it must be greased to assure
proper operating characteristics; refer to Lubrication
Maintenance. Failure to grease the machine will result in
premature failure of critical parts.
Note: After setup has been completed, remove protective
edging (used for shipping) from fenders.
Install Rear Weight
To comply with ANSI/OPEI B71.4–1999 Standard, rear weight must be added to rear of traction unit. Use chart below to
determine weight requirements. Order parts from your local Authorized Toro Distributor.
Cutting Unit
Description Rear Weight Required Weight Part Number Weight Description Qty.
72″Side Discharge
(Model No. 30722)
or
72″Rear Discharge
(Model No. 30710)
or
Guardian 72″
Recycler
(Model No. 30716)
105 lb.
24–5780
&
24–5790
325–8
3253–7
3–8847
3217–9
Rear Weight Kit
(two 35 lb. weights and mounting hardware)
&
Rear Weight Kit
(one 35 lb. weight)
Capscrew 1/2–13 x 2”
Lockwasher 1/2”
Spacer
Nut 1/2”
1
1
2
2
2
2
72” Flex Deck
(Model 30799) 210 lb. 24–5780 Rear Weight Kit (two 35 lb. weights and mounting hardware) 3

19
Before Operating
Hood Prop
1. Position the machine on a level surface.
2. Disengage hood latch and open the hood.
3. Slide bottom of hood prop (Fig. 12) out of retaining
bracket. Lower hood prop, pivot upward, then
downward to prop up hood.
1
Figure 12
1. Hood prop
Check Engine Oil
The engine is shipped with 3.5 qt (3.25 l) of oil in the
crankcase; however, level of oil must be checked before
and after the engine is first started.
1. Park machine on a level surface, stop engine and
remove key from ignition switch. Open hood and install
hood prop.
2. Remove dipstick and wipe it with a clean rag (Fig. 13).
Push dipstick down into the tube and ensure it is fully
seated. Pull dipstick out of the tube and check level of
oil.
1
2
Figure 13
1. Dipstick 2. Oil fill cap
3. If oil level is low, remove filler cap (Fig. 13) and add
enough oil to raise level to top notch on dipstick. DO
NOT OVERFILL.
4. The engine uses any high–quality detergent oil having
the American Petroleum Institute—API—“service
classification” SG, SG/CC or SG/CD. Oil
viscosity–weight– must be selected according to
ambient temperature. Temperature/viscosity
recommendations are:
Single Viscosity Oils
Outside Temperature
–10F to +60FSAE 10W
+10F to +90FSAE 20W–20
Above +32FSAE 30
Above +50FSAE 40
Multi– Viscosity Oils
Outside Temperature
Below +60FSAE 5W–30
–10F to +90FSAE 10W–20
Above –10FSAE 10W–40 or 10W50
Above +10FSAE 20W–40 or 20W50
Important Check level of oil after every 5 hours of
operation or daily. Change oil and filter initially after 50
hours and every 100 hours thereafter. Change oil and filter
more frequently when engine is operated in extremely
dusty or dirty conditions.
5. Install dipstick into tube.

20
Filling the Fuel Tank
THE TORO COMPANY STRONGLY
RECOMMENDS THE USE OF FRESH, CLEAN,
UNLEADED REGULAR GRADE GASOLINE IN
TORO GASOLINE POWERED PRODUCTS.
UNLEADED GASOLINE BURNS CLEANER,
EXTENDS ENGINE LIFE, AND PROMOTES GOOD
STARTING BY REDUCING THE BUILD–UP OF
COMBUSTION CHAMBER DEPOSITS. LEADED
GASOLINE CAN BE USED IF UNLEADED IS NOT
AVAILABLE.
Note: Never Use Methanol, Gasoline Containing Methanol,
Gasoline Containing More Than 10% Ethanol, Gasoline
Additives, Premium Gasoline Or White Gas Because
Engine Fuel System Damage Could Result.
Danger
In certain conditions, gasoline is extremely
flammable and highly explosive. A fire or
explosion from gasoline can burn you and others
and can damage property.
•Fill the fuel tank outdoors, in an open area,
when the engine is cold. Wipe up any gasoline
that spills.
•Do not fill the fuel tank completely full. Add
gasoline to the fuel tank until the level is 1 in.
(25 mm) below the bottom of the filler neck.
This empty space in the tank allows gasoline to
expand.
•Never smoke when handling gasoline, and stay
away from an open flame or where gasoline
fumes may be ignited by a spark.
•Store gasoline in an approved container and
keep it out of the reach of children. Never buy
more than a 30-day supply of gasoline.
•Always place gasoline containers on the ground
away from your vehicle before filling.
•Do not fill gasoline containers inside a vehicle or
on a truck or trailer bed because interior
carpets or plastic truck bed liners may insulate
the container and slow the loss of any static
charge.
•When practical, remove gas-powered equipment
from the truck or trailer and refuel the
equipment with its wheels on the ground.
•If this is not possible, then refuel such
equipment on a truck or trailer from a portable
container, rather than from a gasoline dispenser
nozzle.
•If a gasoline dispenser nozzle must be used, keep
the nozzle in contact with the rim of the fuel
tank or container opening at all times until
fueling is complete.
1. Tip seat forward and prop it with the support rod so
it cannot fall accidentally. Using a clean rag, clean
area around fuel tank cap (Fig. 14).
2. Remove cap from the fuel tank and fill the 6-1/2 gallon
(24 L) tank to within 1 inch (25 mm) from the top with
gasoline. DO NOT OVERFILL.
3. Install fuel tank cap tightly after filling tank.
1
Figure 14
1. Fuel tank cap
Check Cooling System
Clean debris off screen and radiator/oil cooler daily, more
often if conditions are extremely dusty and dirty.
The cooling system is filled with a 50 / 50 solution of water
and permanent ethylene glycol anti–freeze. Check level of
coolant in expansion tank at beginning of each day before
starting the engine. Capacity of cooling system is 6 quarts
(5.6 l).
•If engine has been running, pressurized hot
coolant can escape when radiator cap is
removed and cause burns.
Caution
1. Carefully remove radiator cap. Coolant is pressurized
and may be hot if engine has been running.
2. Check level of coolant in radiator. Level of coolant
must be above the core and about 1 inch (25 mm) below
bottom of filler neck.
3. If coolant level is low, replenish the system. DO NOT
OVERFILL.
4. Install radiator cap.
