Toro 71253 User manual

FormNo.3358-701RevB
WheelHorseXL440HLawn
Tractor
ModelNo.71253—SerialNo.280000001andUp
G006889
Registeratwww.Toro.com.OriginalInstructions(EN)

Introduction
Readthisinformationcarefullytolearnhowtooperate
andmaintainyourproductproperlyandtoavoidinjury
andproductdamage.Youareresponsibleforoperating
theproductproperlyandsafely.
YoumaycontactTorodirectlyatwww .Toro.comfor
productandaccessoryinformation,helpndinga
dealer,ortoregisteryourproduct.
Wheneveryouneedservice,genuineToroparts,or
additionalinformation,contactanAuthorizedService
DealerorToroCustomerServiceandhavethemodel
andserialnumbersofyourproductready.Figure1
identiesthelocationofthemodelandserialnumbers
ontheproduct.Writethenumbersinthespace
provided.
Figure1
1.Modelandserialnumberlocation
ModelNo.
SerialNo.
Thismanualidentiespotentialhazardsandhas
safetymessagesidentiedbythesafetyalertsymbol
(Figure2),whichsignalsahazardthatmaycauseserious
injuryordeathifyoudonotfollowtherecommended
precautions.
Figure2
1.Safetyalertsymbol
Thismanualuses2wordstohighlightinformation.
Importantcallsattentiontospecialmechanical
informationandNoteemphasizesgeneralinformation
worthyofspecialattention.
Contents
Introduction.................................................................2
Safety...........................................................................3
SafeOperationPracticesforRide-on(Riding)
RotaryLawnMowers........................................3
ToroRidingMowerSafety....................................5
SoundPressure.....................................................5
SoundPower........................................................5
Vibration..............................................................5
SlopeChart..........................................................6
SafetyandInstructionalDecals.............................7
ProductOverview......................................................10
Controls.............................................................10
Operation...................................................................10
GasolineandOil................................................10
UsingtheParkingBrake......................................11
PositioningtheSeat............................................12
OperatingtheHeadlights....................................12
OperatingtheBladeControl(PTO)....................12
SettingtheHeight-of-Cut...................................12
StartingtheEngine.............................................13
StoppingtheEngine...........................................13
UsingtheSafetyInterlockSystem.......................14
TestingtheSafetyInterlockSystem.....................15
PushingtheTractorManually.............................15
DrivingForwardorBackward.............................16
StoppingtheTractor...........................................16
OperatingTips...................................................16
Maintenance...............................................................18
RecommendedMaintenanceSchedule(s)................18
Lubrication.............................................................19
GreasingandLubricatingtheTractor..................19
EngineMaintenance...............................................19
ServicingtheEngineOil.....................................19
ServicingtheAirCleaner....................................20
ServicingtheSparkPlug.....................................21
FuelSystemMaintenance.......................................22
DrainingtheFuelTank.......................................22
ReplacingtheFuelFilter.....................................23
ElectricalSystemMaintenance................................23
ServicingtheBattery...........................................23
ServicingtheFuse..............................................25
DriveSystemMaintenance.....................................26
ServicingtheTransaxleFluid..............................26
CoolingSystemMaintenance..................................26
CleaningtheCoolingSystem...............................26
BrakeMaintenance.................................................27
ServicingtheParkingBrake................................27
©2008—TheToro®Company
8111LyndaleAvenueSouth
Bloomington,MN554202
Contactusatwww.Toro.com.
PrintedintheUSA
AllRightsReserved

..............................................................................28
CheckingtheTirePressure.................................28
ServicingtheHeadlights.....................................28
Cleaning.................................................................29
WashingtheUndersideoftheMower..................29
Storage.......................................................................30
Troubleshooting.........................................................31
Schematics.................................................................33
Safety
SafeOperationPracticesfor
Ride-on(Riding)RotaryLawn
Mowers
Readandunderstandthecontentsofthismanualbefore
operatingthetractor.
ThefollowinginstructionsarefromtheCENstandard
EN836:1997.
Thisproductiscapableofamputatinghandsandfeet
andofthrowingobjects.Alwaysfollowallsafety
instructionstoavoidseriousinjuryordeath.
Training
•Readtheinstructionscarefully.Befamiliarwiththe
controlsandtheproperuseoftheequipment.
•Neverallowchildrenorpeopleunfamiliarwiththese
instructionstousethelawnmower.Localregulations
canrestricttheageoftheoperator.
•Nevermowwhilepeople,especiallychildren,orpets
arenearby.
•Keepinmindthattheoperatororuserisresponsible
foraccidentsorhazardsoccurringtootherpeopleor
theirproperty.
•Donotcarrypassengers.
•Alldriversshouldseekandobtainprofessional
andpracticalinstruction.Suchinstructionshould
emphasize:
–theneedforcareandconcentrationwhen
workingwithride-onmachines;
–controlofaride-onmachineslidingonaslope
willnotberegainedbytheapplicationofthe
brake.Themainreasonsforlossofcontrolare:
◊insufcientwheelgrip;
◊beingdriventoofast;
◊inadequatebraking;
◊thetypeofmachineisunsuitableforitstask;
◊lackofawarenessoftheeffectofground
conditions,especiallyslopes;
◊incorrecthitchingandloaddistribution.
Preparation
•Whilemowing,alwayswearsubstantialfootwearand
longtrousers.Donotoperatetheequipmentwhen
barefootorwearingopensandals.
3

•Thoroughlyinspecttheareawheretheequipment
istobeusedandremoveallobjectswhichmaybe
thrownbythemachine.
•Warning—Fuelishighlyammable.
–Storefuelincontainersspecicallydesignedfor
thispurpose.
–Refueloutdoorsonlyanddonotsmokewhile
refuelling.
–Addfuelbeforestartingtheengine.Never
removethecapofthefueltankoraddfuelwhile
theengineisrunningorwhentheengineishot.
–Iffuelisspilled,donotattempttostartthe
enginebutmovethemachineawayfromthe
areaofspillageandavoidcreatinganysourceof
ignitionuntilfuelvaporshavedissipated.
–Replaceallfueltanksandcontainercapssecurely.
•Replacefaultysilencers.
•Beforeusing,alwaysvisuallyinspecttoseethatthe
blades,bladeboltsandcutterassemblyarenotworn
ordamaged.Replacewornordamagedbladesand
boltsinsetstopreservebalance.
•Onmulti-bladedmachines,takecareasrotatingone
bladecancauseotherbladestorotate.
Operation
•Donotoperatetheengineinaconnedspacewhere
dangerouscarbonmonoxidefumescancollect.
•Mowonlyindaylightoringoodarticiallight.
•Beforeattemptingtostarttheengine,disengageall
bladeattachmentclutchesandshiftintoneutral.
•Donotuseonslopesofmorethan
–5°whenmowingonsidehills;
–10°whenmowinguphill;
–15°whenmowingdownhill.
•Rememberthereisnosuchthingasasafeslope.
Travelongrassslopesrequiresparticularcare.To
guardagainstoverturning:
–donotstoporstartsuddenlywhengoingupor
downhill;
–engageclutchslowly,alwayskeepmachinein
gear,especiallywhentravellingdownhill;
–machinespeedsshouldbekeptlowonslopes
andduringtightturns;
–stayalertforhumpsandhollowsandother
hiddenhazards;
–nevermowacrossthefaceoftheslope,unless
thelawnmowerisdesignedforthispurpose.
•Usecarewhenpullingloadsorusingheavy
equipment.
–Useonlyapproveddrawbarhitchpoints.
–Limitloadstothoseyoucansafelycontrol.
–Donotturnsharply.Usecarewhenreversing.
–Usecounterweight(s)orwheelweightswhen
suggestedintheinstructionhandbook.
•Watchoutfortrafcwhencrossingornearroadways.
•Stopthebladesrotatingbeforecrossingsurfaces
otherthangrass.
•Whenusinganyattachments,neverdirectdischarge
ofmaterialtowardbystandersnorallowanyonenear
themachinewhileinoperation.
•Neveroperatethemachinewithdamagedguardsor
withoutsafetyprotectivedevicesinplace.
•Donotchangetheenginegovernorsettingsor
overspeedtheengine.Operatingtheengineat
excessivespeedcanincreasethehazardofpersonal
injury.
•Beforeleavingtheoperator’sposition:
–disengagethepowertake-offandlowerthe
attachments;
–changeintoneutralandsettheparkingbrake;
–stoptheengineandremovethekey.
•Disengagedrivetoattachments,stoptheengine,
anddisconnectthesparkplugwire(s)orremovethe
ignitionkey
–beforeclearingblockagesoruncloggingchute;
–beforechecking,cleaningorworkingonthelawn
mower;
–afterstrikingaforeignobject.Inspectthelawn
mowerfordamageandmakerepairsbefore
restartingandoperatingtheequipment;
–ifthemachinestartstovibrateabnormally(check
immediately).
•Disengagedrivetoattachmentswhentransporting
ornotinuse.
•Stoptheengineanddisengagedrivetoattachment
–beforerefuelling;
–beforeremovingthegrasscatcher;
–beforemakingheightadjustmentunless
adjustmentcanbemadefromtheoperator’s
position.
•Reducethethrottlesettingduringenginerun-out
and,iftheengineisprovidedwithashut-offvalve,
turnthefueloffattheconclusionofmowing.
4

MaintenanceandStorage
•Keepallnuts,boltsandscrewstighttobesurethe
equipmentisinsafeworkingcondition.
•Neverstoretheequipmentwithfuelinthetank
insideabuildingwherefumescanreachanopen
ameorspark.
•Allowtheenginetocoolbeforestoringinany
enclosure.
•Toreducetherehazard,keeptheengine,silencer,
batterycompartmentandfuelstorageareafreeof
grass,leaves,orexcessivegrease.
•Checkthegrasscatcherfrequentlyforwearor
deterioration.
•Replacewornordamagedpartsforsafety.
•Ifthefueltankhastobedrained,thisshouldbe
doneoutdoors.
•Onmulti-bladedmachines,takecareasrotatingone
bladecancauseotherbladestorotate.
•Whenmachineistobeparked,storedorleft
unattended,lowerthecuttingmeansunlessapositive
mechanicallockisused.
ToroRidingMowerSafety
Thefollowingparagraphcontainssafetyinformation
specictoToroproductsthatisnotincludedinthe
CENstandard.
UseonlyToro-approvedattachments.Thewarranty
maybevoidedifyouusethetractorwithunapproved
attachments.
SoundPressure
Thisunithasamaximumsoundpressurelevelatthe
operator’searof87dBA,basedonmeasurementsof
identicalmachinesperEN836andISO11201.
SoundPower
Thisunithasaguaranteedsoundpowerlevelof100
dBA,basedonmeasurementsofidenticalmachinesper
ISO11094.
Vibration
Thisunitdoesnotexceedahand/armvibrationlevel
of10.0m/s2,basedonmeasurementsofidentical
machinesperEN836andEN1033.
Thisunitdoesnotexceedawholebodyvibration
levelof0.4m/s2,basedonmeasurementsofidentical
machinesperEN836andEN1032.
5

SlopeChart
6

SafetyandInstructionalDecals
Safetydecalsandinstructionsareeasilyvisibletotheoperatorandarelocatednearanyareaof
potentialdanger.Replaceanydecalthatisdamagedorlost.
92-5730
1.Choke3.Continuousvariable
setting
2.Fast4.Slow
93-6674
1.Crushinghazard,hand—readtheinstructionsbefore
servicingorperformingmaintenance.
Manufacturer’sMark
1.Indicatesthebladeisidentiedasapartfromtheoriginal
machinemanufacturer.
93-6676
1.Parkingbrake—toengage,pressthebrake/clutchpedal
andlifttheparkingbrakelever;todisengagepressand
releasethebrake/clutchpedal.
2.Brakeandclutch—toengage,pressthebrake/clutchpedal.
3.Tractiondrive—todriveforward,pressthetopofthetraction
controlpedalforwardanddown;todriveinreverse,press
thebottomofthetractioncontrolpedalrearwardanddown.
4.Warning—readtheOperator’sManual.
5.Warning—toavoidtippingthetractor,donotdriveacross
slopesgreaterthan5degrees,upslopesgreaterthan10
degrees,ordownslopesgreaterthan15degrees.
6.Thrownobjecthazard-keepbystandersasafedistance
fromthemachine.
7.Thrownobjecthazard,mower—keepthedeectorinplace.
8.Cutting/dismembermenthazardofhandorfoot,mower
blade—stayawayfrommovingparts.
9.Crushing/dismembermentofabystander—keepbystanders
asafedistancefromthemachine.
7

93-6677
1.Warning—don’toperatethemowerwiththedeectorupor
removed;keepthedeectorinplace.
2.Cutting/dismembermenthazardofhandorfoot,mower
blade—stayawayfrommovingparts.
93-6679
1.Engine
93-7009
1.Warning—don’toperatethemowerwiththedeectorupor
removed;keepthedeectorinplace.
2.Cutting/dismembermenthazardofhandorfoot,mower
blade—stayawayfrommovingparts.
93-7010
1.Thrownobjecthazard—keepbystandersasafedistance
fromthemachine.
2.Thrownobjecthazard,mower—keepthedeectorinplace.
3.Cutting/dismembermentofhandorfoot—stayawayfrom
movingparts.
99-2986
1.Crushing/dismembermenthazardofbystanders—donot
turnthekeywhilechildrenarepresent;keepchildrenasafe
distancefromthemachine.
99-5340
1.KeyChoice—turntoenablereversemowing.
99-8141
1.Mowinginreverseenabled4.Engine—Start
2.Engine—Stop5.Headlights
3.Engine—Run
8

100-7449
1.Pulltheleverouttopush
themachine.
3.Readtheinstructions
beforeservicingor
performingmaintenance.
2.Pushtheleverintorideon
themachine.
4.Donottowthemachine.
107-4922
1.Warning—toavoidtippingthetractor,donotdriveacross
slopesgreaterthan5degrees,upslopesgreaterthan10
degrees,ordownslopesgreaterthan15degrees.
2.Disengage
3.Engage
4.Powertake-off(PTO)
5.Parkingbrake
BatterySymbols
Someorallofthesesymbolsareonyourbattery
1.Explosionhazard6.Keepbystandersasafe
distancefromthebattery.
2.Nore,opename,or
smoking.
7.Weareyeprotection;
explosivegasescan
causeblindnessandother
injuries
3.Causticliquid/chemical
burnhazard
8.Batteryacidcancause
blindnessorsevereburns.
4.Weareyeprotection9.Flusheyesimmediately
withwaterandgetmedical
helpfast.
5.ReadtheOperator’s
Manual.
10.Containslead;donot
discard.
9

ProductOverview
Controls
Becomefamiliarwiththecontrols(Figure3)beforeyou
starttheengineandoperatethetractor.
Figure3
1.Steeringwheel7.Height-of-cutlever
2.Lightswitch—on/off8.Parkingbrakelever
3.Ignitionswitch9.Throttlelever
4.Clutch/brakepedal10.Hoodopening
5.Bladecontrol(PTO)11.Operating-in-reverselight
6.Tractioncontrolpedal12.KeyChoice®switch
Operation
Note:Determinetheleftandrightsidesofthe
machinefromthenormaloperatingposition.
GasolineandOil
RecommendedGasoline
Useunleadedregulargasolinesuitableforautomotive
use(85pumpoctaneminimum).Youmayuseleaded
regulargasolineifunleadedregularisnotavailable.
Important:Neverusemethanol,gasoline
containingmethanol,orgasoholcontainingmore
than10%ethanolbecausethefuelsystemcouldbe
damaged.Donotmixoilwithgasoline.
10

Incertainconditions,gasolineisextremely
ammableandhighlyexplosive.Areor
explosionfromgasolinecanburnyouand
othersandcandamageproperty.
•Fillthefueltankoutdoorsinanopenarea
whentheengineiscold.Wipeupany
gasolinethatspills.
•Donotllthefueltankcompletelyfull.Add
gasolinetothefueltankuntilthelevelis1/4
to1/2inch(6to13mm)belowthebottomof
thellerneck.Thisemptyspaceinthetank
allowsthegasolinetoexpand.
•Neversmokewhenhandlinggasoline,and
stayawayfromanopenameorwherea
sparkmayignitethegasolinefumes.
•Storegasolineinanapprovedcontainerand
keepitoutofthereachofchildren.
•Neverbuymorethana30-daysupplyof
gasoline.
•Alwaysplacegasolinecontainersonthe
groundawayfromyourvehiclebeforelling.
•Donotllgasolinecontainersinsidea
vehicleoronatruckortrailerbedbecause
interiorcarpetsorplastictruckbedliners
mayinsulatethecontainerandslowtheloss
ofanystaticcharge.
•Whenpractical,removegas-powered
equipmentfromthetruckortrailerand
refueltheequipmentwithitswheelsonthe
ground.
•Ifthisisnotpossible,refuelsuchequipment
onatruckortrailerfromaportable
container,notfromagasolinedispenser
nozzle.
•Ifyoumustuseagasolinedispenser,keep
thenozzleincontactwiththerimofthefuel
tankorcontaineropeningatalltimesuntil
fuelingiscomplete.
UsingStabilizer/Conditioner
Useafuelstabilizer/conditionerinthetractorto
providethefollowingbenets:
•Itkeepsgasolinefreshduringstorageforupto90
days.Forlongerstorage,drainthefueltank.
•Itcleanstheenginewhileitruns.
•Iteliminatesgum-likevarnishbuildupinthefuel
system,whichcauseshardstarting.
Important:Donotusefueladditivescontaining
methanolorethanol.
Addthecorrectamountoffuelstabilizer/conditioner
tothegasoline.
Note:Afuelstabilizer/conditionerismosteffective
whenitismixedwithfreshgasoline.Tominimizethe
chanceofvarnishdepositsinthefuelsystem,useafuel
stabilizer/conditioneratalltimes.
FillingtheFuelTank
1.Settheparkingbrake.
2.Stoptheengine,removethekey,andwaitforall
movingpartstostopbeforeleavingtheoperating
position.
3.Cleanaroundthefueltankcapandremovethecap.
4.Addunleadedregulargasolinetothefueltankuntil
thelevelis1/4to1/2inch(6to13mm)belowthe
bottomofthellerneck.Donotllthefueltank
completelyfull.
Note:Thisspaceinthetankallowsgasolineto
expand.
5.Installthefueltankcapsecurely.
6.Wipeupanygasolinethatspills.
CheckingtheEngineOilLevel
ServiceInterval:Beforeeachuseordaily
Beforeyoustarttheengineandusethetractor,check
theoillevelintheenginecrankcase;refertoChecking
theOilLevel.
UsingtheParkingBrake
Alwayssettheparkingbrakewheneveryoustopthe
tractororleaveitunattended.
SettingtheParkingBrake
1.Pushthebrakepedal(Figure4)downandholdit.
11

Figure4
1.Brakepedal2.Parkingbrakelever
2.Lifttheparkingbrakelever(Figure4)upand
graduallytakeyourfootoffofthebrakepedal.
Note:Thebrakepedalshouldstayinthedepressed
(locked)position.
ReleasingtheParkingBrake
1.Pushdownonthebrakepedal(Figure4).
Note:Theparkingbrakelevershouldrelease.
2.Graduallyreleasethebrakepedal.
PositioningtheSeat
Theseatcanmoveforwardandbackward.Position
theseatwhereyouhavethebestcontrolofthetractor
andaremostcomfortable.
1.Raisetheseatandloosentheadjustmentknobs
(Figure5).
Figure5
1.Adjustmentknobs
2.Movetheseattothedesiredpositionandtighten
theknobs.
OperatingtheHeadlights
Adash-mountedOn/Offswitch(Figure3)controls
theheadlights.Thelightsonlyshinewhiletheengineis
runningandtheswitchisOn.
OperatingtheBladeControl
(PTO)
Thebladecontrol(PTO)engagesanddisengages
powertotheelectricclutch.
EngagingthePowerTakeOff(PTO)
1.Presstheclutch/brakepedaltostopthetractor.
2.Pullthebladecontrol(PTO)toon(Figure6).
Figure6
1.Off—disengaged2.On—engaged
DisengagingtheBladeControl(PTO)
1.Presstheclutch/brakepedaltostopthetractor.
2.Pushthebladecontrol(PTO)tooff(Figure6).
SettingtheHeight-of-Cut
Usetheheight-of-cutlevertoraiseandlowerthe
mowertothedesiredcuttingheight.Youcanset
theheight-of-cuttooneofsevenpositionsfrom
approximately1-1/2to4-1/2inches(38to116mm).
1.Parkthemachineonalevelsurface.
2.Disengagethebladecontrol(PTO).
3.Settheparkingbrake.
4.Stoptheengine,removethekey,andwaitforall
movingpartstostopbeforeleavingtheoperating
position.
5.Pullontheheight-of-cutleveronthetractorand
moveittothedesiredposition(Figure7).
12

Figure7
1.Height-of-cutlever
6.Adjusteachmowergagewheeltothecorrectheight,
asfollows:
A.Removethehairpincotterandpintochangethe
holelocation(Figure8).
Figure8
1.Wheel3.Hairpincotter
2.Pin
B.Selectaholepositionsothatthegagewheel
is3/8inch(10mm)offofthegroundforthe
height-of-cuttobeused(Figure8).
C.Insertthepinandsecureitwiththehairpin
cotter.
StartingtheEngine
1.Sitdownontheseat.
2.Settheparkingbrake;refertoSettingtheParking
Brake.
Note:Theenginedoesnotstartunlessyousetthe
parkingbrakeorfullydepressthebrakepedal.
3.Pushthebladecontrol(PTO)tooff(Figure6).
4.ShiftthethrottlelevertoChoke(Figure9).
Figure9
1.Choke3.Slow
2.Fast4.Throttlelever
Note:Anenginethathasbeenrunningandis
warmmaynotrequirestep4.
5.Turntheignitionkeyclockwiseandholditinthe
Startposition(Figure10).Whentheenginestarts,
releasethekey.
Figure10
1.Start3.Off
2.On
Important:Iftheenginedoesnotstartafter
30secondsofcontinuouscranking,turnthe
ignitionkeytoOffandletthestartermotor
cool;refertoTroubleshooting.
6.Aftertheenginestarts,slowlyshiftthethrottlelever
toFast(Figure9).Iftheenginestallsorhesitates,
shiftthethrottleleverbacktoChokeforafew
secondsandthenshiftthethrottlelevertoFast.
Repeatthisstepasrequired.
StoppingtheEngine
1.ShiftthethrottlelevertoFast(Figure9).
2.TurntheignitionkeytoOff,waitforallmoving
partstostop,andremovethekeybeforeleavingthe
operatingposition.(Figure10).
13

UsingtheSafetyInterlock
System
ServiceInterval:Beforeeachuseordaily
Ifthesafetyinterlockswitchesaredisconnected
ordamaged,thetractorcouldoperate
unexpectedly,causingpersonalinjury.
•Donottamperwiththeinterlockswitches.
•Checktheoperationoftheinterlock
switchesdailyandreplaceanydamaged
switchesbeforeoperatingthetractor.
UnderstandingtheSafetyInterlock
System
Thesafetyinterlocksystemisdesignedtopreventthe
enginefromstartingunless:
•Youaresittingontheseat.
•Thebrakepedalisdepressed.
•Thebladecontrol(PTO)isintheDisengage
position.
Thesafetyinterlocksystemisdesignedtostopthe
engineifyoudothefollowing:
•Yourisefromtheseatwhenthebrakepedalis
released.
•Yourisefromtheseatwhilethebladecontrol
(PTO)isintheEngageposition.
•Youshiftintoreversewhilethebladecontrol(PTO)
isintheEngageposition.
SettingtheKeyChoiceSwitchto
OperateinReverse
Aninterlockfeatureonthetractorpreventsthepower
take-off(PTO)fromoperatingwhenyoubackupthe
tractor.Ifyoushiftthetractioncontrolswitchinto
Reversewiththebladecontrol(PTO)engaged(i.e.,
withthemowerbladesorotherattachmentrunning),
theenginewillstop.Donotmowinreverseunlessit
isabsolutelynecessary.
Ifyouneedtousethebladecontrol(PTO)while
backingup,turnofftheinterlockfeatureusingthe
KeyChoiceswitchlocatedneartheseatbracket
(Figure11).
1
G006903
Figure11
1.KeyChoiceswitch
Youcouldbackoverachildorbystander
whilethemowerbladesorotherattachmentis
engagedandcauseseriousinjuryordeath.
•Donotmowinreverseunlessitisabsolutely
necessary.
•DonotinserttheKeyChoicekeyunlessitis
absolutelynecessary.
•Alwayslookbackwardanddownbefore
backingup.
•UsetheKeyChoiceswitchonlyifyouare
certainnochildrenorotherbystanderswill
enterthemowingarea.
•Beveryobservantafterdeactivatingthe
interlockbecausethesoundoftheengine
maypreventyoufromnoticingthatachild
orbystanderhasenteredtheworkarea.
•Alwaysremoveboththeignitionand
KeyChoicekeysandputtheminasafeplace
outofthereachofchildrenorunauthorized
userswhenleavingthetractorunattended.
1.Engagethebladecontrol(PTO).
2.InserttheKeyChoicekeyintotheswitch(Figure11).
3.TurntheKeyChoicekey.
Note:Aredlightonthefrontconsole(Figure12)
turnson,indicatingthattheinterlockisdisabled.
14

Figure12
1.Operating-in-reverselight
4.ShiftthetractioncontrolswitchintoReverseand
completeyourtask.
5.Disengagethebladecontrol(PTO)toactivatethe
interlock.
6.RemovetheKeyChoicekeyandputitinasafeplace
outofthereachofchildren.
TestingtheSafetyInterlock
System
Ifsafetyinterlockswitchesaredisconnected
ordamaged,thetractorcouldoperate
unexpectedly,causingpersonalinjury.
•Donottamperwiththeinterlockswitches.
•Checktheoperationoftheinterlock
switchesdailyandreplaceanydamaged
switchesbeforeoperatingthetractor.
•Replaceswitchesevery2yearsregardlessof
whethertheyareoperatingproperlyornot.
Testthesafetysystembeforeyouusethetractoreach
time.Ifthesafetyinterlocksystemdoesnotoperateas
describedbelow,haveanAuthorizedServiceDealer
repairthesafetyinterlocksystemimmediately.While
sittingintheseat,performthefollowingchecks:
1.Settheparkingbrake.Shiftthebladecontrol(PTO)
toEngage,andturntheignitionkeytoStart:The
engineshouldnotcrank.
2.Shiftthebladecontrol(PTO)toDisengageand
releasetheparkingbrake.Turntheignitionkeyto
Start:Theengineshouldnotcrank.
3.WiththegroundspeedinNeutral,settheparking
brake,shiftthebladecontrol(PTO)toDisengage,
andstarttheengine.Whiletheengineisrunning,
releasetheparkingbrakeandriseslightlyfromthe
seat:Theengineshouldstop.
4.Shiftthebladecontrol(PTO)toDisengage,move
thetractioncontrolpedaltoNeutral,settheparking
brake,andstarttheengine.Whiletheengineis
running,shiftthebladecontrol(PTO)switchto
Engageandmovethetractioncontrolpedalto
Reverse:Theengineshouldstop.
5.Shiftthebladecontrol(PTO)toDisengage,
movethetractioncontrolpedaltoNeutral,and
settheparkingbrake.Starttheengine,shift
thebladecontrol(PTO)switchtoEngage,and
turntheKeyChoicekeyandreleaseit:The
operating-in-reversewarninglightshouldilluminate.
6.Shiftthebladecontrol(PTO)toDisengage:The
operating-in-reversewarninglightshouldturnoff.
PushingtheTractorManually
Important:Alwayspushthetractormanually.
Nevertowthetractorbecauseyoumaydamage
thetransaxle.
ToPushtheTractor
1.Disengagethebladecontrol(PTO).
2.Stoptheengine,removethekey,andwaitforall
movingpartstostopbeforeleavingtheoperating
position.
3.PullthedrivecontrolouttothePushposition.
Note:Thisdisengagesthedrivesystemandallows
thewheelstoturnfreely(Figure13).
Figure13
1.Operateposition2.Pushposition
ToOperatetheTractor
PushthedrivecontrolintotheOperateposition.This
engagesthedrivesystem(Figure13).
Note:Thetractorwillnotdriveunlessthedrive
controlisintheOperateposition.
15

DrivingForwardorBackward
Thethrottlecontrolregulatestheenginespeedas
measuredinRPM(revolutionsperminute).Shiftthe
throttlecontrolleverintotheFastpositionforbest
performance.
Togoforwardorbackward:
1.Releasetheparkingbrake;refertoReleasingthe
ParkingBrake.
2.Placeyourfootonthetractioncontrolpedaland
slowlypressonthetopofthetractioncontrolpedal
tomoveforwardoronthebottomofthepedalto
movebackward(Figure14).
Note:Thefartheryoumovethetractioncontrol
pedalineitherdirection,thefasterthetractorwill
moveinthatdirection.
Figure14
1.Tractioncontrolpedal3.Backward
2.Forward
Note:Toslowdown,releasethepressureonthe
tractioncontrolpedal.
Important:Toavoidtransmissiondamage,
alwaysreleasetheparkingbrakebeforemoving
thetractioncontrolpedal.
Note:Toreversethetractorwiththebladecontrol
(PTO)engaged,deactivatetheoperating-in-reverse
interlockusingtheKeyChoiceswitchlocatedin
frontofandbelowtheseat.
StoppingtheTractor
1.Releasethetractioncontrolpedal.
2.Disengagethebladecontrol(PTO).
3.TurntheignitionkeytoOfftostoptheengine.
4.Settheparkingbrakeifyouleavethetractor
unattended;refertoSettingtheParkingBrake.
5.Removetheignitionkeyfromtheswitch.
Childrenorbystandersmaybeinjuredifthey
moveorattempttooperatethetractorwhileit
isunattended.
AlwaysremovetheignitionandKeyChoice
keysandsettheparkingbrakewhenleaving
thetractorunattended,evenifjustforafew
minutes.
OperatingTips
•Forthebestperformance,operatetheengineat
themaximumspeed.Themowerrequiresairto
thoroughlycutgrassclippings,sodonotsetthe
height-of-cuttooloworcompletelysurroundthe
mowerinuncutgrass.Alwaysleaveonesideofthe
mowerfreefromuncutgrasstoallowtheairtobe
drawnintothemower.
•Cutthegrassslightlylongerthannormaltoensure
thatthecuttingheightofthemowerdoesnotscalp
anyunevenground.Whencuttinggrasslongerthan
6inch(15cm)tall,cutthelawntwicetoensurean
acceptableappearance.
•Itisbesttocutonlyabout1/3ofthegrassblade.
Donotcutmorethanthatunlessthegrassissparse
oritislatefallwhengrassgrowsmoreslowly.
•Alternatethemowingdirectiontokeepthegrass
standingstraight.Thisalsohelpsdisperseclippings
andenhancesdecompositionandfertilization.
•Grassgrowsatdifferentratesatdifferenttimesof
theseason.Tomaintainthesamecuttingheight,
whichisagoodpractice,mowmoreofteninearly
spring.Asthegrassgrowthrateslowsinmid
summer,mowlessfrequently.
•Toimprovethequalityofcut,useaslowerground
speed.Forbestoperationonaveragelawns,operate
theengineatfullthrottlewhilecontrollingthe
groundspeed.Youshouldoperatethetractor
between2to3.5mph(3.2to5.6km/h)while
mowing.
•Ifthegrassislongerthannormal,orifitcontains
ahighdegreeofmoisture,raisethecuttingheight
higherthanusual,cutthegrassatthatsetting,and
thencutthegrassagainatthelower,normalsetting.
•Ifyoumuststopthetractorwhilemowing,youmay
leaveaclumpofgrassclippingsonyourlawn.To
avoidthis,dothefollowing:
–Engagethebladeandmovetoapreviouslycut
area.
16

–Dispersetheclippingsevenlybyraisingthe
mower1or2height-of-cutsettingswhiledriving
forwardwiththebladeengaged.
•Usethewashoutporttocleanclippingsanddirt
fromtheundersideofthemoweraftereachuse.If
grassanddirtbuildupinsidethemower,thecutting
qualitywilleventuallybecomeunsatisfactory.
•Maintainasharpbladethroughouttheseason.A
sharpbladecutsgrasscleanlywithouttearingor
shreddingthegrassblades.Tearingandshredding
thegrassturnsitbrownattheedges,whichslows
itsgrowthandincreasesthechanceofdisease.
Every30days,checkthebladeforsharpnessand
ledownanynicks.
17

Maintenance
Note:Determinetheleftandrightsidesofthemachinefromthenormaloperatingposition.
RecommendedMaintenanceSchedule(s)
MaintenanceService
IntervalMaintenanceProcedure
Aftertherst5hours•Changetheengineoil.
Beforeeachuseordaily
•Checktheengineoillevel.
•Checkthesafetysystem.
•Checktheoillevel.
•Checkthebatteryelectrolyte.
•Checktheparkingbrake.
•Washtheundersideofthemower.
Every25hours
•Greaseandlubricatethetractor.Moreoftenindustyordirtyconditions.
•Cleantheaircleanerfoamelement.
•Servicethesparkplug.
•Checkthetirepressure.
Every50hours•Changetheengineoil.Changeitmoreoftenunderaheavyloadorinhigh
temperatures.
Every100hours
•Changetheoillter.
•Replacetheaircleanerpaperelement.
•Replacethesparkplug.
•Replacethefuellter.
•Servicethetransaxleuid.
•Cleanthecoolingsystem.
Beforestorage
•Drainthefueltank.
•Performallthemaintenanceprocedureslistedabove.
•Paintanychippedsurfaces.
•Checkthetirepressure.
•Checkthesafetysystem.
•Checkthebrakes.
•Checkthesparkplug.
•Checkthebatteryelectrolyte.
•Chargethebatteryanddisconnectthecables.
•Checkthebelt(s)forwearandcracks.
Important:Refertoyourengineoperator’smanualforadditionalmaintenanceprocedures.
Ifyouleavethekeyintheignitionswitch,someonecouldaccidentlystarttheengineandseriously
injureyouorotherbystanders.
Removethekeyfromtheignitionanddisconnectthewirefromthesparkplugbeforeyoudoany
maintenance.Setthewireasidesothatitdoesnotaccidentallycontactthesparkplug.
18

Lubrication
GreasingandLubricatingthe
Tractor
ServiceInterval:Every25hours—Greaseandlubricate
thetractor.Moreoftenindustyor
dirtyconditions.
HowtoGreasetheTractor
1.Disengagethebladecontrol(PTO).
2.Settheparkingbrake.
3.Stoptheengine,removethekey,andwaitforall
movingpartstostopbeforeleavingtheoperating
position.
4.Cleanthegreasettingswitharag.
Note:Ensurethatyouscrapeanypaintoffthe
frontofthettings.
5.Connectagreaseguntoeachttingandpump
greaseintoit.
6.Wipeupanyexcessgrease.
WheretoAddGrease
Lubricatethefrontwheelsandsteeringspindlesuntil
greasebeginstooozeoutofthebearings(Figure15).
Figure15
EngineMaintenance
ServicingtheEngineOil
OilType:Detergentoil(APIserviceSF,SG,SH,SJ,or
higher)
CrankcaseCapacity:48oz.or1-1/2qt.(1400ccor1.4
l)whenthelterisnotchanged;56oz.or1-3/4qt.
(1700ccor1.7l)whenthelterischanged.
Viscosity:Seethetablebelow.
Figure16
CheckingtheOilLevel
ServiceInterval:Beforeeachuseordaily
1.Parkthetractoronalevelsurface.
2.Disengagethebladecontrol(PTO).
3.Settheparkingbrake.
4.Stoptheengine,waitforallmovingpartstostop,and
removethekeybeforeleavingtheoperatingposition.
5.Openthehood.
6.Cleanaroundtheoildipstick(Figure17)sothatdirt
cannotfallintothellholeanddamagetheengine.
Figure17
1.Oildipstick/llhole2.Oildrainplug
19

7.Unscrewtheoildipstickandwipethemetalend
clean(Figure18).
Figure18
1.Oildipstick2.Metalend
8.Screwtheoildipstickfullyontothellhole.
9.Unscrewthedipstickagainandlookatthemetal
end.Iftheoillevelislow,slowlypouronlyenough
oilintothellholetoraisetheleveltotheFullmark
onthedipstick.
Important:Donotoverllthecrankcasewith
oilandruntheengine;theenginedamagemay
result.
ChangingtheOil
ServiceInterval:Aftertherst5hours
Every50hoursChangeitmore
oftenunderaheavyloadorinhigh
temperatures.
1.Starttheengineandletitrunfor5minutes.
Note:Thiswarmstheoilsothatitwilldrainmore
easily.
2.Parkthetractorsothattheleftsideisslightlylower
thantherightsidetoensurethattheoildrains
completely.
3.Disengagethebladecontrol(PTO).
4.Settheparkingbrake.
5.Stoptheengine,waitforallmovingpartstostop,and
removethekeybeforeleavingtheoperatingposition.
6.Openthehood.
7.Placeadrainpanbelowtheoildrainplugand
removeit(Figure17).
8.Whentheoilhasdrainedcompletely,installtheoil
drainplug.
Note:Disposeoftheusedoilatacertiedrecycling
center.
9.Changetheoillter,ifnecessary.RefertoChanging
theOilFilter.
10.Slowlypourapproximately80%ofthespecied
amountofoilintothellhole(Figure17).Checkthe
oillevel;referto4and5ofCheckingtheOilLevel.
ChangingtheOilFilter
ServiceInterval:Every100hours
Note:Changetheoilltermorefrequentlywhenthe
operatingconditionsareextremelydustyorsandy.
1.Draintheoilfromtheengine;refertoChangingand
DrainingtheOil.
2.Removetheoldoillterandwipethelteradapter
(Figure19)gasketsurface.
Figure19
1.Oillter3.Filteradapter
2.Gasket
3.Applyathincoatofnewoiltotherubbergasketon
thenewoillter(Figure19).
4.Installthenewoilltertothelteradapter.
5.Turntheoillterclockwiseuntiltherubbergasket
contactsthelteradapter,thentightentheoillter
anadditional1/2to3/4turn(Figure19).
6.Slowlypourabout80%ofthespeciedamountof
oilintothellhole(Figure17).Checktheoillevel;
referto7and8ofCheckingtheOilLevel.
7.Closethehood.
ServicingtheAirCleaner
ServiceInterval:Every25hours—Cleantheaircleaner
foamelement.
Every100hours—Replacetheair
cleanerpaperelement.
Note:Servicetheaircleanermorefrequentlyifthe
operatingconditionsareextremelydustyorsandy.
RemovingtheFoamandPaper
Elements
1.Disengagethebladecontrol(PTO).
20
