1140602001
AIR CONDITIONER (MULTI TYPE)
Owner’s Manual
Outdoor Unit
Model name:
MMY-MUP0721HT6P-UL MMY-MUP0721HT9P-UL
MMY-MUP0961HT6P-UL MMY-MUP0961HT9P-UL
MMY-MUP1201HT6P-UL MMY-MUP1201HT9P-UL
MMY-MUP1441HT6P-UL MMY-MUP1441HT9P-UL
MMY-MUP1681HT6P-UL MMY-MUP1681HT9P-UL
MMY-MUP1921HT6P-UL
MMY-MUP072H1HT6PUL MMY-MUP072H1HT9PUL
MMY-MUP096H1HT6PUL MMY-MUP096H1HT9PUL
MMY-MUP120H1HT6PUL MMY-MUP120H1HT9PUL
<Heat Pump Model>
R410A
For OUTDOOR USE only
Pour une UTILISATION EN EXTÉRIEUR
uniquement
Solo para USO EXTERIOR
Manual del Propietario 41
Owner’s Manual 1
Español
English
Français
Manuel du Propriétaire 21
1140602001_EN FR ES.indb c11140602001_EN FR ES.indb c1 4/22/23 4:50 PM4/22/23 4:50 PM

Thank you very much for purchasing TOSHIBA/Carrier Air Conditioner.
Please read this Owner’s Manual carefully before using your Air Conditioner.
Be sure to obtain the “Owner’s Manual” and “Installation Manual” from constructor (or dealer).
Request to constructor or dealer
Please clearly explain the contents of the Owner’s Manual and hand over it.
ADOPTION OF R410A REFRIGERANT
This Air Conditioner uses R410A an environmentally friendly refrigerant.
Contents
1 Precautions for safety....................................................................................................1
2 Part names ......................................................................................................................6
3 Part names and functions of the remote control......................................................... 8
4 Operation.........................................................................................................................9
5 Timer operation.............................................................................................................11
6 Louver direction............................................................................................................13
7 Installation ....................................................................................................................16
8 Notes on operations and performance.......................................................................16
9 Tips for energy saving and comfortable performance..............................................17
10 Maintenance..................................................................................................................18
11 When the following symptoms are found ..................................................................19
12 Notice code ...................................................................................................................20
After reading these instructions, be sure to keep them in a safe place together with the
Owner’s Manual and Installation Manual supplied with your product.
1Precautions for safety
Installing, starting up, and servicing air conditioning equipment can
be hazardous due to system pressures, electrical components, and
equipment location (roofs, elevated structures, etc.).
Only trained, qualified installers and service mechanics should
install, start up, and service this equipment.
Untrained personnel can perform basic maintenance functions
such as cleaning the heat exchanger. All other operations should
be performed by trained service personnel only.
Before working on the equipment, observe precautions in the
literature and on tags, stickers, and labels attached to the
equipment.
Follow all safety codes. Wear safety glasses and work gloves.
Keep a quenching cloth and fire extinguisher nearby during
brazing. Use care in handling, rigging, and setting bulky equipment.
Read these instructions thoroughly and follow all warnings or
cautions included in the literature and attached to the unit. Consult
the local building codes and National Electrical Code (NEC) for
special requirements. Recognize safety information. This is the
safety alert symbol . When you see this symbol on the unit and
in instructions or manuals, be alert to the potential for personal
injury. Understand these signal words: DANGER, WARNING, and
CAUTION. These words are used with the safety alert symbol.
DANGER identifies the most serious hazards which will result
in severe personal injury or death. WARNING signifies hazards
which could result in personal injury or death. CAUTION is used
to identify unsafe practices which may result in minor personal
injury or product and property damage. NOTE is used to highlight
suggestions which will result in enhanced installation, reliability, or
operation.
The manufacturer shall not assume any liability for the damage
caused by not observing the description of this manual.
– 1 –
1-EN 2-EN
1140602001_EN FR ES.indb 11140602001_EN FR ES.indb 1 4/22/23 4:50 PM4/22/23 4:50 PM

WARNING
General
• Carefully read the Owner’s Manual before starting the air
conditioner. There are a number of important things to keep in
mind for daily operation.
• Ask for the installation to be performed by the dealer or a
professional. Only use a qualified installer to install an air
conditioner. If a non-qualified person installs an air conditioner,
it may result in problems such as fire, electric shock, injury, water
leakage, noise and vibration.
• Do not use any refrigerant different from the one specified for
complement or replacement.
Otherwise, abnormally high pressure may be generated in the
refrigeration cycle, which may result in a failure or explosion of
the product or an injury to your body.
• Places where the operation sound of the outdoor unit may cause
a disturbance. (Especially at the boundary line with a neighbor,
install the air conditioner while considering the noise.)
Transportation and storage
• While transporting the air conditioner, wear shoes with protective
toe caps, protective gloves, and other protective clothing.
• To transport the air conditioner, do not take hold of the bands
around the packing carton. You may injure yourself if the bands
should break.
• Before stacking the packing cartons for storage or transportation,
heed the precautions written on the packing cartons.
Failure to heed the precautions may cause the stack to collapse.
• The air conditioner must be transported in a stable condition.
If any part of the product is broken, contact your dealer.
Installation
• Only a qualified installer or qualified service person is allowed
to carry out the electrical work of the air conditioner. Under no
circumstances should this work be performed by an unqualified
individual since failure to carry out the work properly may result
in electric shocks and/or electrical leaks.
• After the installation work has been completed, have the installer
explain the circuit breaker positions. In the event an electrical
issue occurs with the air conditioner, set the circuit breaker to the
OFF position, and contact a service person.
• If the unit is installed in a small room, take appropriate measures
to prevent the refrigerant from exceeding the limit concentration
even if it leaks. Consult the dealer from whom you purchased the
air conditioner when you implement the measures. Accumulation
of highly concentrated refrigerant may cause an oxygen
deficiency accident.
• Do not install the air conditioner in a location in close proximity
to a combustible gas. If a combustible gas leaks and becomes
concentrated around the unit, a fire may occur.
• If separately sold products are used, use TOSHIBA/Carrier
specified products only. Using unspecified products may cause
fire, electric shock, water leak or other failure.
• Connect the ground wire. Incomplete grounding may cause an
electric shock.
Operation
• Before opening the intake grille of the indoor unit or service panel
of the outdoor unit, set the circuit breaker to the OFF position.
Failure to set the circuit breaker to the OFF position may result
in electric shocks through contact with the interior parts. Only a
qualified installer or qualified service person is allowed to remove
the intake grille of the indoor unit or service panel of the outdoor
unit to perform any type of work on the unit.
• Inside the air conditioner are high-voltage areas and rotating
parts. Due to the danger of electric shocks or of your fingers or
physical objects becoming trapped in the rotating parts, do not
remove the intake grille of the indoor unit or service panel of the
outdoor unit. When work involving the removal of these parts
is required, contact a qualified installer or a qualified service
person.
FR
EN
ES
– 2 –
3-EN 4-EN
1140602001_EN FR ES.indb 21140602001_EN FR ES.indb 2 4/22/23 4:50 PM4/22/23 4:50 PM

• Do not move or repair any unit by yourself. Since there is high
voltage inside the unit, you may get electric shock during removal
of the cover and main unit.
• Use of a stand more than 50 cm high to clean the filter of the
indoor unit or to carry out other such jobs constitutes working at
heights. Due to the danger of falling off the stand and injuring
yourself while working at heights, this kind of work should not be
done by unqualified individuals. When this kind of work must be
carried out, do not do it yourself.
Have a qualified installer or a qualified service person to perform
the work.
• Do not touch the aluminum fin of the outdoor unit. You may injure
yourself if you do so. If the fin must be touched, do not touch
it yourself. Contact a qualified installer or a qualified service
person.
• Do not climb onto or place objects on top of the outdoor unit. You
may fall or the objects may fall off of the outdoor unit and result in
injury.
• Do not place any combustion appliance in a place where it is
directly exposed to the wind of the air conditioner, otherwise it
may cause imperfect combustion.
• When the air conditioner is operated with a combustion appliance
in the same place, ventilate the room adequately.
Poor ventilation may cause an oxygen shortage.
• When the air conditioner is used in a closed room, ventilate the
room. Poor ventilation may cause an oxygen shortage.
• Do not expose your body to cool air directly for a long time and
do not cool yourself excessively.
Doing so may result in a deteriorated physical condition and ill
health.
• Do not insert your finger or a stick into the air intake or outlet.
Doing so may result in injury as the fan is rotating at a high speed
inside the unit.
• Consult the shop where you purchased the unit if air conditioning
(cooling and heating) does not perform properly as a refrigerant
leakage may be the cause. Confirm the repair details with a
qualified service person when the repair includes additional
refrigerant charging.
• Stop running the air conditioner and turn off the breaker before
cleaning.
Otherwise, injury may result as the fan is rotating at a high speed
inside the unit.
Repairs
• If there is any kind of trouble (such as the check code display
appears, there is a burning smell, abnormal sounds are heard,
the air conditioner fails to cool or heat or water is leaking) has
occurred in the air conditioner, do not touch the air conditioner.
Set the circuit breaker to the OFF position and contact a qualified
service person. Take steps to ensure that the power will not be
turned on (by marking “out of service” near the circuit breaker,
for instance) until a qualified service person arrives.
Continuing to use the air conditioner in the trouble status may
cause mechanical problems to escalate or result in electric
shocks or additional mechanical failures.
• If the fan grille is damaged, do not approach the outdoor unit.
Set the circuit breaker to the OFF position and contact a qualified
service person to have the repairs done. Do not set the circuit
breaker to the ON position until the repairs are completed.
• If there is danger of the indoor unit falling, do not approach
the indoor unit. Set the circuit breaker to the OFF position and
contact a qualified installer or a qualified service person to refit
the unit. Do not set the circuit breaker to the ON position until the
unit has been refitted.
• If there is danger of the outdoor unit toppling over, do not
approach the outdoor unit. Set the circuit breaker to the OFF
position and contact a qualified installer or a qualified service
person to correct the issue. Do not set the circuit breaker to the
ON position until the issue is corrected.
• Do not customize the unit. Doing so may result in fire, electric
shock or other failure.
– 3 –
5-EN 6-EN
1140602001_EN FR ES.indb 31140602001_EN FR ES.indb 3 4/22/23 4:50 PM4/22/23 4:50 PM

Relocation
• When the air conditioner is to be relocated, do not relocate
it yourself. Contact a qualified installer or a qualified service
person. Failure to relocate the air conditioner properly may result
in electric shocks and/or a fire.
CAUTION
Cautions about installation
• Lay the drain hose correctly for perfect draining. Bad drainage
may cause flooding in the house and get the furniture wet.
• Use an exclusive power supply circuit for the air conditioner
at the rated voltage. An insufficient power supply capacity or
inappropriate installation may cause fire.
• Confirm that the outdoor unit is securely attached to the base.
Otherwise, the unit may fall and cause damage to the unit,
property, or people.
Cautions about operation
• Do not use this air conditioner for special purposes such as
preserving food, precision instruments, art objects, breeding
animals, car, boats, etc..
• Do not operate the buttons with wet hands. Doing so may cause
electric shock.
• If the air conditioner will not be used for a considerably long time,
turn off the main switch or the circuit breaker, for safety.
• To ensure the air conditioner operates in its original performance,
operate it within the range of the operating temperature specified
in the instructions. Otherwise the unit may malfunction, or leak
fluid.
• Prevent any liquid from falling into the remote control. Do not spill
juice, water or any kind of liquid.
• Do not wash the air conditioner. Doing so may result in electric
shock.
• Check whether the installation base and other equipment have
deteriorated after being used for a long time. Leaving them in
such a condition may result in the unit falling down and causing
injury.
• Do not leave flammable sprays or other flammable materials near
the air conditioner, and do not spray flammable aerosol directly
into the air conditioner. The unit may catch fire.
• Stop running the air conditioner and turn off the breaker before
cleaning.
Otherwise, injury may result as the fan is rotating at a high speed
inside the unit.
• Ask an authorized dealer or qualified service person to clean the
air conditioner.
Cleaning the air conditioner in an improper manner may cause
damage to plastic parts, insulation failure of electric parts, and
result in a malfunction. In worst case, it may result in water
leakage, electric shock, smoke emission and fire.
• Do not put a water container, such as a vase, on the unit.
Water intrusion into the unit may occur and it may cause
deterioration of electric insulation and result in electric shock.
• Do not wash air conditioners with pressure washers. Electric
leaks may cause electric shocks or fires.
FR
EN
ES
– 4 –
7-EN 8-EN
1140602001_EN FR ES.indb 41140602001_EN FR ES.indb 4 4/22/23 4:50 PM4/22/23 4:50 PM

■Warning indications on the air conditioner unit
Warning indication Description
WARNING: RISK OF ELECTRIC
SHOCK. CAN CAUSE INJURY OR
DEATH: DISCONNECT ALL REMOTE
ELECTRIC POWER SUPPLIES
BEFORE SERVICING
ELECTRICAL SHOCK HAZARD
RISQUE D'ÉLECTROCUTION
ATTENTION: RISQUE DE
DÉCHARGE ÉLECTRIQUE
POUVANT CAUSER DES
BLESSURES OU LA MORT.
D
ÉCONNECTER TOUTES LES
ALIMENTATIONS ÉLECTRIQUES
AVANT L'ENTRETIEN
This product may contain chemicals known to the state
of California to cause cancer, or birth defects, or other
reproductive harm.
WARNING
ELECTRICAL SHOCK HAZARD
Disconnect all remote electric power supplies before servicing.
DH79295001
CAUTION
High temperature parts.
You might get burned when removing this panel.
■Connectable indoor units
Model type Model Name
4-Way Cassette MMU-UP✱✱✱✱HP-UL
Compact 4-Way Cassette MMU-UP✱✱✱✱MH-UL
1-Way Cassette MMU-UP✱✱✱✱YHP-UL
Concealed Duct, Standard MMD-UP✱✱✱✱BHP-UL
Concealed Duct, High Static Pressure MMD-UP✱✱✱✱HP-UL
Slim Duct MMD-UP✱✱✱✱SPH-UL
Under Ceiling MMC-UP✱✱✱✱HP-UL
Floor Console Exposed MML-UP✱✱✱✱H-UL
Floor Console Recessed MML-UP✱✱✱✱BH-UL
High-Wall
MMK-UP✱✱✱✱HP-UL
* For details on these models, read the Owner’s Manuals that come with
the indoor units.
High-Wall (HAORI)
MMK-UP✱✱✱✱DHP-UL
* For details on these models, read the Owner’s Manuals that come with
the indoor units.
– 5 –
9-EN 10-EN
1140602001_EN FR ES.indb 51140602001_EN FR ES.indb 5 4/22/23 4:50 PM4/22/23 4:50 PM

2Part names
ŶOutdoor unit
Air discharge
Warm air comes out when cooling,
and cool air when heating.
Refrigerant Conduit Connector
Connecting valve inside.
Air intake
Provided on the three sides
Earth screw
Equipped on the
electrical control box.
NFC tag
NFC : Near Field Communication
Power wire hole
ŶIndoor unit
4-Way Cassette Type
MMU-UPٓٓٓٓHP-UL
Discharge louver
Controls discharge air directions.
Hook
Open/close the return air grille.
Air intake grille
Air in the room is taken in through here.
Earth screw
Equipped on the
electrical control box.
1-way Cassette Type
MMU-UPٓٓٓٓYHP-UL
Air intake grille
Air in the room is taken in
through here.
Discharge louver
Controls discharge air directions.
Earth screw
Equipped on the electrical
control box.
Air filter
Filters out dust.
(Inside the return air grille)
Concealed Duct Standard Type
MMD-UPٓٓٓٓBHP-UL
Air discharge
Connect a discharge duct.
Electrical control box
The earth screw is provided in the electrical control box.
Drain pan
Air intake
Air filter
Compact 4-Way cassette Type
MMU-UPٓٓٓٓMH-UL
Hook
Open / close the return air grille.
Earth screw
Equipped on the electrical control box.
Discharge louver
Controls discharge air directions.
Air intake grille
Air in the room is taken in through here.
FR
EN
ES
– 6 –
11-EN 12-EN
1140602001_EN FR ES.indb 61140602001_EN FR ES.indb 6 4/22/23 4:50 PM4/22/23 4:50 PM

MML-UPٓٓٓٓH-UL
MML-UPٓٓٓٓBH-UL
Air filter
Filters out dust.
(Inside the return air grille)
Discharge louver
Controls discharge air directions.
Ground screw
Equipped on the electrical
control box.
Return air grille
Air in the room enters here.
Ground screw
Equipped on the electrical
control box.
Air intake
Air in the room enters here.
Air discharge
Drain funnel (with strainer)
Accessory to be attached at the site
Air filter
Filters out dust.
(Inside the return air grille)
Front panel (lower)
Floor Console Exposed type
Floor Console Recessed type
Concealed Duct High Static Pressure Type
MMD-UP030ٓHP-UL to MMU-UP054ٓHP-UL
Air discharge
Connect a discharge duct.
Electrical control box
The earth screw is provided in the
electrical control box.
Air intake
Air filter
Drain pan
MMD-UP072ٓHP-UL, MMU-UP096ٓHP-UL
Air discharge
Connect a discharge duct.
Air intake
Connect a suction duct.
Earth screw
Equipped on the electrical control box.
Drain pan
Slim Duct Type
MMD-UPٓٓٓٓSPH-UL
Earth screw
Equipped on the electrical
control box.
Air intake
Air discharge
Under Ceiling Type
MMC-UPٓٓٓٓHP-UL
Horizontal louver / Vertical grille / Air changed.
The air discharge direction can be discharge.
Air intake grille
Air is taken in through here.
Earth screw
Inside the electrical box.
Air filter
Filters out dust.
(Behind the air intake grille)
– 7 –
13-EN 14-EN
1140602001_EN FR ES.indb 71140602001_EN FR ES.indb 7 4/22/23 4:50 PM4/22/23 4:50 PM

3Part names and functions of the remote
control
■Before use
When you use the air conditioner for the first time or change the settings, follow the procedures below. From the
next time, just push [ ON/OFF] to start operating according to the settings.
Preparation
Turn on the power breaker
When the power is turned on, “ ” appears on the remote control display.
* The remote control will not work for about 3 minute after turning on the power. This is not a malfunction.
REQUIREMENT
• Keep the power breaker turned on during use.
• When you resume using the air conditioner after a long period of disuse, turn on the power breaker at least
12 hours before starting operation.
■Part names and functions
1
2
3
6
4
5
Operating LED
Lights while operating.
Temperature sensor
Model name label
For detailed remote control
functions, refer to the Owner’s
Manual for the wired remote control.
* The screens shown here are examples. The content that is displayed may differ, depending on the environment
settings being used.
1[ Menu] button
Shows the “Menu”.
2[ Set/Fix] button
Fixes and applies settings.
Ways to use it are shown on screen.
3[ Return] button
Deletes selections.
Ways to use it are shown on screen.
4[ ] and [ ] buttons
Changes settings and selects items.
5[ ] and [ ] buttons
Selects setting items.
Other ways to use it are shown on screen.
6[ ON/OFF] button
Starts and stops connected devices.
■Main screen
This screen is for confirming or changing settings that are used every day, such as temperature, operating mode,
fan speed and wind direction.
You can check the current state according to the setting items on the bottom of the screen.
You can switch the setting items by pushing [ ] and [ ], and change them by pushing [ ] and [ ].
Setting items
• The currently selected item is highlighted in black.
• You can switch the items by pushing [ ] and [ ].
NOTE
• The temperature setting is changed in the main screen.
• Functions and items that cannot be set are not shown, according to the model.
• While changing settings, if you push [ Return] or if there are no button operations for about 60 seconds, the
main screen returns.
Switching between the detailed display and simple display (Main screen only)
You can change the main screen to the simple display, depending on the “Display mode” setting. For details on
changing “Display mode”, refer to “Display setting” in “Initial setting” in the Installation Manual of wired remote
control.
The detailed display is set as the factory default setting.
Detailed display (Factory default setting)
(*1)
Simple display
*1: “ Preparing to heat”
Displayed when “Heat” operation starts or when
the defrost cycle is operating.
While the icon is displayed, the indoor fan stops or
the “Fan” turns on.
“ Preparing to operate”
This may be displayed on some models.
“ Preparing to operate ventilation”
Displayed while the Heat recovery ventilation unit
is on standby.
While this is being displayed, the Heat recovery
ventilation unit remains stopped.
(*1)
In the simple display, only some icons are shown.
FR
EN
ES
– 8 –
15-EN 16-EN
1140602001_EN FR ES.indb 81140602001_EN FR ES.indb 8 4/22/23 4:50 PM4/22/23 4:50 PM

■Icon list
Displayed when “Energy saving operation”
is “ON”. Displayed when “Timer” is “ON”.
Displayed when remote control sensor is
set. (*1) Displayed when “Louvers lock” is set.
Displayed when “Night operation” is “ON”. !Displayed when it is time for filter
maintenance.
Displayed when operations are locked by
central control. (*1)
Displayed when “Soft Cooling” operation
is “ON”.
Displayed when “Saving operation” is
“ON”.
Displayed for about 3 seconds when the
operation mode is changed in the “Mode”
screen when the operation mode is
restricted.
Displayed when the Bluetooth®function is
“ON”. Refer to the Owner’s Manual of the
Bluetooth®function regarding Bluetooth®
functions.
Displayed when “Air purifier” function is
“ON”.
Displayed when a check code occurs. (*1) Displayed when a notice code occurs. (*1)
For details, contact your dealer.
It reaches the set temperature, and
displayed while the room temperature is
maintained.
It is displayed when a commercially
available ventilation unit connected to the
air conditioner is in operation.
*1: Refer to the Installation Manual of the wired remote control.
4Operation
■Operations
1Push [ ON/OFF] to start operations
The operation LED lights.
2Push [ ] and [ ] to select the item you
want to change
You can change the following items.
Setting temperatures
Operation mode
Fan speed
Wind direction
3To stop operations, push [ ON/OFF]
again
■Changing the set temperature
1Push [ ] and [ ] to switch to the “Set
temp.” screen
2Push [ ] and [ ] to change the
temperature setting
Push [ ] to increase and push [ ] to
decrease the set temperature.
NOTE
• For the range of temperatures that can be set, refer to the Owner's Manual for the wired remote control.
• The temperature setting cannot be changed when “Fan” is set.
• If the operation mode is set to “Auto” and dual set point is set, refer to <Individual temperature settings for “Cool”
and “Heat” in auto operation modes (dual set point)>. Refer to the Owner's Manual for the wired remote control.
– 9 –
17-EN 18-EN
1140602001_EN FR ES.indb 91140602001_EN FR ES.indb 9 4/22/23 4:50 PM4/22/23 4:50 PM

■Changing the operation mode
1Push [ ] and [ ] to switch to the
“Mode” screen
2Push [ ] and [ ] to select an operation
mode
Heat
Fan
Dry
Cool
NOTE
Operation modes that cannot be set are not shown, according to the model of indoor unit.
■Changing the fan speed
1Push [ ] and [ ] to switch to the “Fan
Speed” screen
2Push [ ] and [ ] to select fan speed
Auto
High
Medium +
Medium
Low +
Low
NOTE
• When the operation mode is “Fan”, you cannot select “Auto”.
• The fan speed that can be set varies depending on the indoor unit connected.
• “ ” is displayed when combined with an indoor unit that cannot do “Fan Speed”.
■Changing the wind direction
• If the connected indoor units have louvers, then the horizontal louver icon is displayed on the air conditioner main
screen.
• If the connected indoor units have vertical louvers, then the vertical louver icon is displayed on the air conditioner
main screen.
* For models that have only left-right directional louvers, they are operated as horizontal louvers on the remote
control.
Up / down direction: Horizontal louvers
* Display while swinging
1Push [ ] and [ ] to switch to the “Wind
direction” screen (horizontal louvers)
2Push [ ] and [ ] to select wind
direction
(1) (2) (3) (4) (5) Swing
Operation mode Settable angles
Heat, Fan (1), (2), (3), (4), (5),
Swing
Cool, Dry (1), (2), (3), Swing
Left / right direction: Vertical louvers
* Display while swinging
1Push [ ] and [ ] to switch to the “Wind
direction” screen (vertical louvers)
2Push [ ] and [ ] to select wind
direction
(1) (2) (3) (4)
(7)(6)(5) Swing
FR
EN
ES
– 10 –
19-EN 20-EN
1140602001_EN FR ES.indb 101140602001_EN FR ES.indb 10 4/22/23 4:50 PM4/22/23 4:50 PM

Cancelling swing
* Display when swinging (up / down) is cancelled
“Fan”, “Heat”
* Display when swinging (up / down) is cancelled
“Cool”, “Dry”
* Display when swinging (left / right) is cancelled
1During swing operation, push [ ] and
[ ] to switch to the “Wind direction”
screen
2Push [ ] or [ ]
The louvers stop at the position when [ ] or
[ ] is pushing.
When [ ] is pushing in the display when
swing was cancelled, the louvers go to wind
direction position (1), when [ ] is pushing, the
louvers go to position (3) during “Cool” or “Dry”
operation, and go to position (5) during “Fan”
or “Heat” operation, and vertical louvers go to
position (7).
NOTE
• When the operation mode is “Cool” or “Dry”, the horizontal louvers point downward but do not stop at positions
(4) or (5). If swing is stopped in positions (4) or (5), the louvers move to position (3) and then stop.
• “ ” is displayed when “Louver lock” is set. Refer to “Louver lock (Fixing the angle of the louvers)”
5Timer operation
■Timer (Setting a timer to start or stop operation)
Selecting a timer type
1In “Menu”, select “Timer”, and push
[ Set/Fix]
2Push [ ] and [ ] to select the timer you
want to set
3Push [ Set/Fix]
NOTE
About “Off timer” and “On timer” operations
• “Off timer” and “On timer” are enabled for only 1 time.
• “Off timer” and “On timer” do not operate in the following conditions.
When “Off timer” and “On timer” are disabled, during function settings, during central control (if “ON/OFF” is
prohibited)
• When 2 remote control are connected, settings cannot be done on the “Follower remote control”.
• The setting range of “Off timer” and “On timer” is a minimum of 30 minutes and a maximum of 168 hours (7 days).
• Push [ Return] to not fix the changes, so conditions are as before changes, and return to the “Timer” screen.
• If there is a power outage, the “Off timer” and “On timer” settings are cancelled. (They become “OFF”.)
• When “Off timer” and “On timer” are “ON”, then “ ” is displayed in the detailed display.
For details on setting the “Schedule timer”, refer to the Owner's Manual of the wired
remote control.
– 11 –
21-EN 22-EN
1140602001_EN FR ES.indb 111140602001_EN FR ES.indb 11 4/22/23 4:50 PM4/22/23 4:50 PM

Off timer
You can set the timer to the time at which to stop operation of an air conditioner.
1In the “Off timer” screen, push [ ] and
[ ] to select “Off timer”
2Push [ ]
Pushing [ ] cancels the settings.
3Push [ ] and [ ] to select “Timer”
4Push [ ] and [ ] to change the time
The time can be set in 30 minute intervals for up
to 24 hours, and at 1 hour intervals after that.
5Push [ Set/Fix]
Return to the “Timer” screen.
NOTE
• The air conditioner stops operating after the time set in “Off timer” has elapsed.
• In the period until the air conditioner operation is stopped by the “Off timer”, countdown of the “Off timer”
continues even if the air conditioner is stopped and started.
Countdown of “Off timer”
Set “Off
timer”
Stopped
manually
Operated
manually
No time remaining in
“Off timer”
Operating OperatingStop Stop
On timer
You can set the timer to the time at which to start operation of an air conditioner.
1In the “On timer” screen, push [ ] and
[ ] to select “On timer”
2Push [ ]
Pushing [ ] cancels the settings.
3Push [ ] and [ ] to select “Timer”
4Push [ ] and [ ] to change the time
The time can be set in 30 minute intervals for up
to 24 hours, and at 1 hour intervals after that.
5Push [ Set/Fix]
Return to the “Timer” screen.
NOTE
• The air conditioner starts operating after the time set in “On timer” has elapsed.
• The air conditioner stops operating as soon as a time is set in “On timer”.
• When the air conditioner operation is started during the countdown of “On timer”, the “On timer” becomes “OFF”.
Countdown of “Off timer”
Countdown of “Off timer” Stop countdown of “On timer”
Stopping operation by setting
“On timer”.
Stopping operation by
setting “On timer”.
Stopped
manually
Operated
manually
No time remaining in
“Off timer”
Operating
Operating
Operating
Operating
Stop
Stop Stop
FR
EN
ES
– 12 –
23-EN 24-EN
1140602001_EN FR ES.indb 121140602001_EN FR ES.indb 12 4/22/23 4:50 PM4/22/23 4:50 PM

Off reminder timer
You can set the timer from the air conditioner operation start time to the stop time.
1In the “Off reminder timer” screen, push
[ ] and [ ] to select “Off reminder timer”
2Push [ ]
Pushing [ ] cancels the settings.
3Push [ ] and [ ] to select “Timer”
4Push [ ] and [ ] to change the time
Times can be set in 10 minute intervals.
5Push [ Set/Fix]
Return to the “Timer” screen.
NOTE
• The air conditioner starts operating, and after the set time has elapsed, the air conditioner stops operating.
Countdown of “Off reminder timer”
Starting
operation
No time remaining in
“Off timer”
Operating Stop
• “Off reminder timer” does not operate in the following conditions.
When “Off reminder timer” is disabled, during abnormalities, in test mode, during function settings, while a timer
is set, and during central control (if “ON/OFF” is prohibited)
• When 2 remote control are connected, settings cannot be done on the “Follower remote control”.
• The setting range of “Off reminder timer” is a minimum of 30 minutes and a maximum of 240 minutes.
• Push [ Return] to not fix the changes, so conditions are as before changes, and return to the “Timer” screen.
• When “Off reminder timer” is “ON”, then “ ” is displayed in the detailed display.
6Louver direction
■Individual louver (Select wind direction for each air outlet)
You can set the wind direction for each outlet of indoor units that have 4-way air discharge.
NOTE
• This function may not be available, depending on the model of the indoor unit.
• This function can only be set while the air conditioner is operating.
1In “Menu”, select “Individual louvers”, and
push [ Set/Fix]
2Push [ ] and [ ] to select louvers
Louver 1 Louver 3Louver 2 Louver 4 All louvers
3Push [ ] and [ ] to select wind
direction
 For details, refer to “Changing the wind direction”.
4Push [ Return]
Return to “Menu”.
▼4-way air discharge type
Electrical control
box
Refrigerant
pipe
Drain pipe
Receiver
installation
position
▼Compact 4-way air discharge type
Electrical control
box
Drain pipe Refrigerant pipe
Receiver
installation
position
NOTE
• For models that “Individual louver” is not available, the message “No function” is displayed.
• Push [ ] or [ ] while swinging to stop the louver and cancel swinging, push [ ] or [ ] again to select
an wind direction.
• For group connections, refer to the Owner's Manual for the wired remote control.
• “ ” is displayed when “Louver lock” is set. That louver cannot do “Individual louver”. Refer to “Louver lock
(Fixing the angle of the louvers)”
– 13 –
25-EN 26-EN
1140602001_EN FR ES.indb 131140602001_EN FR ES.indb 13 4/22/23 4:50 PM4/22/23 4:50 PM

■Louver setting
(Selecting the type of swing or fixing the louvers)
NOTE
This function may not be available, depending on the model of the indoor unit.
Swing type
You can select from 3 types of swing operation: “Standard”, “Dual”, or “Cycle”.
1In “Menu”, select “Louver setting”, and
push [ Set/Fix]
2Push [ ] and [ ] to select “Swing
type”, and then push [ Set/Fix]
3In the “Swing type” screen, push [ ] and
[ ] to select a mode
Regarding “Swing type”, refer to the Installation
Manual of the indoor unit.
4Push [ Set/Fix]
Return to the “Louver setting” screen.
5Push [ Return]
“ ” is displayed.
 When doing group connections, the screen for
selecting units is displayed, so push [ Return]
to display “ ”.
NOTE
• For models that “Louver setting” is not available, the message “No function” is displayed.
• Push [ Return] to not fix the changes, so conditions are as before changes, and return to the “Louver setting”
screen.
• For group connections, refer to the Owner's Manual for the wired remote control.
Louver lock (Fixing the angle of the louvers)
You can set and fix the angle of louvers individually for each air outlet.
1In “Menu”, select “Louver setting”, and
push [ Set/Fix]
2Push [ ] and [ ] to select “Louver
lock”, and then push [ Set/Fix]
3Push [ ] and [ ] to select louvers
Louver 1 Louver 3Louver 2 Louver 4 All louvers
 For louver numbers of each indoor unit, refer to
<Individual louver (Select wind direction for each
air outlet)>.
4Push [ ] and [ ] to select a louver
angle (wind direction)
 Push [ ] to raise a louver and push [ ] to
lower a louver.
(1) (2) (3) (4) (5)
Louver not
locked
5Push [ Set/Fix]
 Return to the “Louver setting” screen.
6Push [ Return]
 “ ” is displayed.
 When doing group connections, the screen for
selecting units is displayed, so push [ Return]
to display “ ”.
NOTE
• For models that “Louver setting” is not available, the message “No function” is displayed.
• Push [ Return] to not fix the changes, so conditions are as before changes, and return to the “Louver setting”
screen.
• To cancel “Louver lock”, push [ ] and [ ] to set louver not locked for the louver angle of each louver.
• When the operation mode is “Cool” or “Dry”, performing “Louver lock” at position (4) or (5) may cause
condensation.
• For group connections, refer to the Owner's Manual for the wired remote control.
• “ ” is displayed when “Louver lock” is set.
FR
EN
ES
– 14 –
27-EN 28-EN
1140602001_EN FR ES.indb 141140602001_EN FR ES.indb 14 4/22/23 4:50 PM4/22/23 4:50 PM

Ŷ4-way cassette type
When cooling
When cooling
Point the louver horizontally.
When heating
Point the louver downward.
The louver automatically closes when running is
stopped.
In pre-heating mode, the louver points upward.
The swing indication appears on the remote
control even in pre-heating mode, but the actual
swing starts only after pre-heating is complete.
The louver automatically closes when running is
stopped.
In pre-heating mode, the louver points upward.
The swing indication appears on the remote
control even in pre-heating mode, but the actual
swing starts only after pre-heating is complete.
Ŷ1-way cassette type
When cooling
Point the louver horizontally to send cool air across the
entire room.
When heating
Point the louver downward to send heated air to the
floor.
ŶUnder ceiling type
Vertical adjustment
When cooling
Point the louver horizontally to send cool air across the
entire room.
When heating
Point the louver downward to send heated air to the
floor.
The louver automatically closes when running is
stopped.
In pre-heating mode, the louver points upward.
The swing indication appears on the remote
control even in pre-heating mode, but the actual
swing starts only after pre-heating is complete.
Horizontal air flow adjustment
To change the horizontal air flow direction, point the
vertical louvers inside the horizontal louver in your
preferred direction.
NOTE
When the horizontal louver is pointing downward in
COOL mode, water droplets may form on the surface
of the cabinet or louver and drop down.
When the horizontal louver is pointing horizontally
in HEAT mode, the air may not warm up the room
evenly.
Floor Console Exposed type
Follow the procedure below to change the air
discharge:
1Remove the two fixing screws of the air
discharge. (The fixing screws are to be
reused)
2Insert your hand into the air discharge and
pull it up slightly, then remove the air
discharge from the claw hook at the rear
side.
3Lift up the air discharge and remove it.
4Reverse the air discharge and reattach it to
the main unit.
Make sure that the four claw hooks (2 at the rear
and 2 at the lower sides) are hooked into the
mounting positions.
5Be sure to tighten the air discharge with the
removed fixing screws so that it does not
come off.
Move the louver manually and point it horizontally to
send cool air across the entire room.
Move the louver manually and point it downward to
send heated air to the floor.
When heating
Changing the air discharge
– 15 –
29-EN 30-EN
1140602001_EN FR ES.indb 151140602001_EN FR ES.indb 15 4/22/23 4:50 PM4/22/23 4:50 PM

7Installation
ŶLocation
Avoid installing near machines emitting high frequency waves.
Not suitable for chemical plants such as liquefied carbon dioxide refrigerant plants.
Do not install the air conditioner in locations where iron or other metal dust is present. If iron or other metal dust
adheres to or collects on the interior of the air conditioner, it may spontaneously combust and start a fire.
A failure may occur in certain locations such as the following:
Areas with large amount of oil droplets (including machine oil) or vapors
Salty areas near oceans, etc.
Hot springs emitting sulfidizing gas, etc.
Heavily acidic or alkaline places. ( e.g. place disinfection solution is frequently sprayed at )
Special maintenance or parts are required for use in the above places. For details, contact the dealer where you
purchased the product.
Leave an enough space around the air intake and discharge of the outdoor unit so that the ventilation is not
restricted.
Avoid places where strong wind may blow against the air intake and discharge of the outdoor unit.
Attach a snow stand, snow hood, etc. to the outdoor unit for use in snowfall areas. For details, contact the dealer
where you purchased the product.
Make sure drain water from the outdoor unit is emitted into places with good drainage.
Make sure the air filter is attached to the indoor unit. If not, dust may accumulate on the heat exchanger or other
parts in the air conditioner and cause a water leak.
Keep a distance of at least 3.3 ft (1 m) between the air conditioner / remote control and a TV or radio. Failure to
observe this precaution may cause visual disturbance or noise.
Leave a distance of at least 4.9 ft (1.5 m) between the air discharge and afire a larm. If this precaution is not
observed, the alarm may not work properly or detect fire in case of fire.
ŶBe careful of operation sounds
Locate the unit in a place secure enough so that the sounds and vibrations do not increase.
If something is placed near the air discharge of the outdoor unit, noise may increase.
Be careful not to disturb your neighbors with cool / warm air or noise coming from the air discharge of the
outdoor unit.
8Notes on operations and performance
ŶCheck before operation
Turn on the power switch at least 12 hours before
starting operation.
Make sure the ground wire is securely connected.
Make sure the air filter is attached to the indoor unit.
ŶHeating performance
A heat pump system, which gathers outside heat and
emits it into a room, is used for heating. When the
outside air temperature falls, the heating capacity of
the unit is reduced.
When the outside temperature is low, it is
Heated air may not come out, when the outside
temperature is low (less than -13°F) and the room
temperature is 79°F or higher.
recommended that you also use other heating
equipment.
ŶDefrosting during heating
If frost falls on the outdoor unit during heating,
defrosting is automatically performed
(for approximately 2 - 10 minutes) to increase the
heating effect.
The fan of the indoor unit is stopped during
defrosting.
Ŷ3-minute protection
The outdoor unit will not operate for approximately
3 minutes after the air conditioner has been
immediately restarted after stopping, or the power
switch has been turned on. This is to protect the
system.
ŶPower failure
In the case of a power failure, all operations stop.
To resume operations, push the ON / OFF button.
ŶFan rotation of a stopped
indoor unit
While other indoor units operate, the fans on
indoor units in stand-by mode rotate for several
minutes approximately once per one hour to protect
the machines.
ŶProtective device
(High pressure switch)
The high pressure switch stops the air conditioner
automatically when excessive load is applied to the
air conditioner.
If the protective device activates, the unit’s running
stops and the operation lamp blinks.
When the protective device activates, the indicator
and the check code are displayed on the remote
control.
The protective device may activate in the following
cases:
During cooling
When the air intake or air discharge of the
outdoor unit is blocked.
When strong wind blows continuously against the
air discharge of the outdoor unit.
During heating
When dust or dirt is excessively adhered to the
air filter of the indoor unit.
When the air discharge of the indoor unit is blocked.
NOTE
When the protective device activates, turn off the
power switch, remove the cause, and then restart
running.
FR
EN
ES
– 16 –
31-EN 32-EN
1140602001_EN FR ES.indb 161140602001_EN FR ES.indb 16 4/22/23 4:50 PM4/22/23 4:50 PM

ŶCooling / Heating operations
When the outdoor temperature goes out of the operable range, cooling or heating operation may not be
performed in order to protect the equipment. In this case, “ ” goes on.
If the outside temperature decreases during operation, the fan of the outdoor unit may stop.
ŶCharacteristics of heating
Air does not come out immediately after heating starts. Heated air comes out after 3 to 5 minutes (depending on
the room/outside temperatures), after the indoor heat exchanger warms up.
When the outside temperature increases, the outdoor unit may stop.
While an indoor unit is running in the heating mode, the outdoor unit supplies refrigerant to the other indoor units
which are not running. There, noise may come from the other indoor units or the exterior of them may become
warm.
If the Fan operation is performed while the Heat operation is performed in another room, the fan does not run.
ŶProhibition of NFC function (NFC tag)
NFC communications is enabled at the time of shipping from the factory, but it is possible to disable the test run with
a smart phone.
Please consult dealer from where you purchased it for more details.
9Tips for energy saving and comfortable
performance
To save energy and perform comfortable cooling and heating
Clean the air filter often
A clogged air filter lowers the cooling / heating
performance.
Check
periodically!
Do not cool / heat too much
WARNING
Do not expose your body to cool air directly for a
long time and do not cool yourself excessively.
Doing so may result in deteriorated physical condition
and ill health.
Cooling / Heating too much is bad for your health.
In particular, take care with handicapped / old people
and children.
Do not cool
down too
much!
Close windows and doors
Do not let cooled / heated air escape from the room.
Close.
Cool / Heat the room evenly
Adjust the air direction with the louver.
Exposing yourself to blowing air directly for a long
time is bad for your health.
Air conditioner operating conditions
For proper performance, operate the air conditioner under the following temperature conditions:
Cooling operation
Outdoor temperature : -10°F to 125°F (-23.3°C to 52°C) (Dry-bulb temp.) *1
Room temperature
[CAUTION] Room relative humidity: less than 80%. If the air conditioner operates in excess
of this figure, the surface of the air conditioner may cause dewing.
Heating operation
Room temperature
If air conditioner is used outside of the above conditions, safety protection may operate.
*1 When the outdoor temperature is below 23°F (-5°C), please contact manufacturer’s representative for review.
*2 The temperature is below -13°F (-25°C), please contact manufacturer’s representative for review.
Outdoor temperature : MMY-MUP***1HT*PUL_-22°F to 60°F (-30.0°C to 15.5°C) (Wet-bulb temp.)
MMY-MUP***H1HT*PUL_-30°F to 60°F (-34.4°C to 15.5°C) (Wet-bulb temp.) *2
– 17 –
33-EN 34-EN
1140602001_EN FR ES.indb 171140602001_EN FR ES.indb 17 4/22/23 4:50 PM4/22/23 4:50 PM

10 Maintenance
WARNING
For daily maintenance including Air Filter cleaning, make sure to ask the qualified service person
particularly following models;
 4-way cassette type
 Compact 4-way cassette type
 1-way cassette type
 Under ceiling type
 Concealed duct standard type
 Concealed duct high static type
 Slim duct type
CAUTION
Do not push buttons with wet hands.
'RLQJVRPD\UHVXOWLQHOHFWULFVKRFN
Cleaning the air filters
 :KHQWKHfiOWHUiQGiFDWRUiVGiVSOD\HGRQWKHUHPRWHFRQWUROFOHDQWKHDiUfiOWHUV
 $VNTXDOifiHGVHUYiFHSHUVRQWRFOHDQWKHfiOWHUVfRUWKHPRGHOVOiVWHGiQWKHZDUQiQJRQWKHWRSRfWKiVFKDSWHU
 &ORJJHGfiOWHUVPD\ORZHUWKHFRROiQJDQGKHDWiQJSHUfRUPDQFH
<Daily maintenance>
IfiVGiVSOD\HGonWKHUHPoWHFonWUoOPDinWDinWKH
DiUfiOWHU
BHVXUHWoVWoSWKHDiUFonGiWionHUbHfoUHFOHDninJof
DiUfiOWHUWKHnWXUnoffWKHFiUFXiWbUHDNHU
1Take out the air filter.
)oUGHWDiOVonKoZWoFOHDnWKHDiUfiOWHUUHfHU
WoWKHInVWDOODWion0DnXDOfoUHDFKinGooUXniW
COHDningZiWKZDWHUoUYDFXXPFOHDnHU
IfGiUWiVKHDY\FOHDnWKHDiUfiOWHUb\WHSiG
ZDWHUZiWKnHXWUDOGHWHUgHnWoUZDWHU
$fWHUFOHDningZiWKZDWHUGU\WKHDiUfiOWHU
VXffiFiHnWO\inDVKDGHSODFH
0oXnWWKHDiUfiOWHU
2Turn on the circuit breaker, then push the
ON/OFF button on the remote control to start
the operation.
3After cleaning, perform “Filter Sign Reset”.
CAUTION
DonoWVWDUWWKHDiUFonGiWionHUZKiOHOHDYingDiUfiOWHU
UHPoYHG
Cleaning of air filter
IfWKHDiUFonGiWionHUVDUHoSHUDWHGZKiOH“”iV
GiVSOD\HGWKHn“FiOWHUFKHFN”iVGiVSOD\HG3XVKDn
oSHUDWionbXWWonZKiOHiWiVGiVSOD\HGoUOHDYHiWfoUDW
OHDVW5VHFonGVDnGWKHGiVSOD\ZiOOGiVDSSHDU
When the filter check mark is displayed (filter
check reset)
1In “Menu”, select “Filter sign reset”, and
push [ Set/Fix].
2Push [ Set/Fix].
Filter sign reset
FR
EN
ES
– 18 –
35-EN 36-EN
1140602001_EN FR ES.indb 181140602001_EN FR ES.indb 18 4/22/23 4:50 PM4/22/23 4:50 PM

11 When the following symptoms are found
Check the points described below before asking repair servicing.
esuaCmotpmyS
It is not a failure.
Outdoor unit
White misty cold air or
water is out.
Fan of the outdoor unit stops automatically and performs defrost
operation.
Sometimes, noise of air
leak is heard.
Solenoid valve works when defrost operation starts or finishes.
Indoor unit
“Swish” sound is heard
sometimes.
When the operation has started, during the operation, or immediately
after the operation has stopped, a sound such as water flows may be
heard, and the operation sound may become larger for 2 or 3 minutes
immediately after the operation has started.
They are flowing sound of refrigerant or draining sound of dehumidifier.
Slight clacking sound is
heard.
This is sound generated when heat exchanger, etc. expand and
contract slightly due to change of temperature.
Discharge air smells. Various smell such as one of wall, carpet, clothes, cigarette, or
cosmetics adhere to the air conditioner.
Is outdoor temperature out of operation temperature range?
“ ” indication is lit. When cooling operation cannot be performed because another
indoor unit performs heating operation.
“ ” indication is lit. When the manager of the air conditioner has fixed the operation to
COOL or HEAT, and an operation contrary to the setup operation is
performed.
“ ” indication is lit. When stopping the fan to prevent cool air blow at starting heating.
Sound or cool air is output
from the stand by indoor unit.
Since refrigerant is flowed temporarily to prevent stay of oil or
refrigerant in the stand by indoor unit, sound of flowing refrigerant,
may be heard or white steam when other indoor unit operates in
Heat mode, and cold air in Cool mode may be blow-out.
When power of the air conditioner is turned
on, “Ticktock” sound is heard.
Sound is generated when the expansion valve operates when power
has been turned on.
LCD blurs when it is touched. LCD may temporarily blur by static electricity.
Fan and louvers of the indoor unit moves
when the unit is not operated.
Intermittent operation of the fan with louvers open is sometimes
carried out for the refrigerant recovery control of unoperated unit.
Check again.
?”FFO“remitehtsI.yllacitamotuaspotS
Does not operate.
Is it a power failure?
Is the power switch turned off?
Is the power fuse or breaker blown?
Has the protective device operated? (The operation lamp goes on.)
Is the timer “ON”? (The operation lamp goes on.)
Are Cool and Heat selected simultaneously?
(“ ” indication is lit on the display of the remote control.)
Is outdoor temperature out of operation temperature range?
Air is not cooled or warmed sufficiently.
Is the air intake or air discharge of the outdoor unit obstructed?
Are any door or window open?
Is the air filter clogged with dust?
Is discharge louver of the indoor unit set at appropriate position?
Is air selection set to “Low” “Med”, and is the operation mode set to
“Fan”?
Is the setup temp. the appropriate temperature?
Are Cool and Heat selected simultaneously?
(“ ” indication is lit on the display of the remote control.)
Is outdoor temperature out of operation temperature range?
ŶBefore the cooling season
Ask a qualified service person to clean the drain
pan
CAUTION
Clean the drain pan
Without cleaning, the drain pan may be filled with
waste, and water may overflow onto the ceiling or floor.
If you do not plan to use the unit for more
than 1 month
(1) Operate “Fan” mode.
Run the fan for about half a
day to dry the inside fully.
(2) Stop the air conditioner.
(3) Turn off the main power
switch.
(R410A refrigerant model)
Turn on the main power
switch.
(R32 refrigerant model)
Checks before operation
(1) Check that the air filters are installed.
(2) Check that the air discharge or intake is not
blocked.
(3) Turn on the main power switch.
ŶCleaning the indoor unit and
remote control
Ask qualified service person to clean the indoor units
for the models listed in the warning on the top of this
chapter.
Wipe with a dry, soft cloth.
Do not use acidic or alkaline detergents.
If heavily stained, wipe off dirt with a cloth soaked in
lukewarm water.
(Do not use water to wipe the remote control)
Do not use benzine, thinner, scouring powder,
chemical cloth, etc. as those may cause deformation
or breakage.
ŶIf unused for over a month
Leave the fan on for half a day or so to dry the inside.
Turn off the main power switch.
Clean the air filter and then attach it.
Turn on the power again.
(In case of R32 refrigerant model)
ŶPeriodic inspection
After being used for a long period of time, the parts
may deteriorate or malfunction, or the drainage
may worsen, due to heat, moisture, dust, or general
usage.
In addition to the maintenance, it is recommended
that you have a inspection (charges apply) performed
by the dealer where you purchased the unit, etc.
CAUTION
 Perform high-pressure cleaning for the heat
exchanger.
If commercially available detergent (strong alkaline
or acid cleaning agent) is used, the surface treatment
of the heat exchanger will deteriorate, which may
degrade the self cleaning performance. For details,
contact our sales department or the dealer where
you purchased the unit.
– 19 –
37-EN 38-EN
1140602001_EN FR ES.indb 191140602001_EN FR ES.indb 19 4/22/23 4:50 PM4/22/23 4:50 PM
