SD-R5372V
DVD REWRITEABLE DRIVE
USER MANUAL

CONTENTS
Introduction..............................................................................1
Setup ........................................................................................3
Using the DVD Rewriteable Drive...........................................7
Troubleshooting.....................................................................10
Specifications ........................................................................ 11
Drive Connectors...................................................................15

1
INTRODUCTION – SD-R5372V
General Features
Reads and records digital data on DVD-R/-RW, DVD+R/+RW, DVD±R DL, CD-R/-RW, HS CD-RW and
US CD-RW discs.
Read Write
DVD-R 12X 16X
DVD+R 12X 16X
DVD-RW 6X 6X
DVD+RW 6X 8X
DVD±R DL 8X 6X
DVD-ROM 16X n/a
DVD-RAM 2X n/a
CD-ROM 48X n/a
CD-R 48X 48X
CD-RW 24X 4X
CD-DA 40X n/a
HS CD-RW - 10X
US CD-RW - 24X
3-way Disc Eject (eject button, software, emergency eject hole)
Average Random Access Time
CD 100ms
DVD-RAM 200ms
DVD-ROM 120ms
Horizontal or Vertical Mount
2MByte Buffer
Playback interchangeability for CD-ROM and DVD-ROM discs
Regionalization (RPC2 compliance) (DVD)
BUS Interface - ATAPI
Types of Disc Formats Supported - Write
DVD:
DVD-R, DVD-RW, DVD+R, DVD±R DL, DVD+RW
CD:
CD-R, CD-RW, High Speed CD-RW, Ultra Speed CD-RW

Types of Disc Formats Supported - Read
DVD:
DVD-ROM, DVD-R/RW, DVD+R, DVD±R DL, DVD+RW, DVD-RAM
CD:
CD-DA, CD+G, CD-MIDI, CD-TEXT, CD-ROM, CD-ROM XA, MIXED MODE CD, CD-I, CD-I Bridge
(Photo-CD, Video-CD), Multi-session (Photo-CD, CD-EXTRA, CD-R, CD-RW, Portfolio)
Front Panel
Figure 1.SD-R5372V DVD Writeable Drive Front Panel
Loading
Tray
Load disc using tray.
Busy Light
LED
The LED lights green or amber when the drive is operating (LED is amber when drive is
writing.)
Eject
Button
The Eject button is used to open the disc tray so you can install or remove a disc.
Emergency
Eject Hole
The emergency eject hole is to be used only when the Loading Tray will not open when
Eject button is pressed.
System Requirements
The DVD Writeable kit requires the following (If kit uses Nero6 software):
•Microsoft Windows 98SE, XP, 2000 or ME
•CPU Requirements:
300MHz minimum
800MHz for capturing to hard disc
1.6GHz for capturing to DVD video
•64MB RAM, 128MB RAM (for video editing)
•Hard Drive Space:
500MB minimum
4.8GB for DVD Images
•Screen solution 800 x 600 pixel minimum, 16 bit color depth or higher
•Windows Internet Explorer 4.0 or higher
•PCI sound card, USB audio box or motherboard built-in audio device
•TV tuner or video capture board for analog recording

3
SETUP – SD-R5372V
The following steps must be performed to properly install your drive:
•Set Drive Jumper Settings
•Connect Audio Cable
•Attach IDE BUS Cable
•Attach Power Cable
•Mount Drive
Jumper Settings
The mode select jumpers are 6 straight angle pins located on the rear of the DVD Rewriteable drive.
By placing a jumper on the pins, you can select the following functions:
CS Drive is configured using host interface signal CSEL
SL Configures drive as Slave
MA Configures drive as Master (default mode)
Figure 1.Mode Select Jumper
In most installations, jumper should remain in the MA position (factory default). It is recommended that
you install your DVD Rewriteable drive only on the secondary IDE BUS. If you are installing on primary
IDE BUS, your hard drive would then be the Master, and you should set your DVD Rewriteable drive to
the Slave position (SL)
Figure 2.Jumper Locations
