© Copyright 2005 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Tecra A4-S211 BTS Rev. 1.05 2005-08-25 KK CB V1.40 Page 1 of 4
Tecra A4 Series
Model Name Description Part Number UPC Code
Tecra A4-S211 Intel Pentium® M Processor 730 [1.60GHz, 2MB L2 cache, 533MHz FSB], 60GB (4200) HDD,
15.4” diagonal TFT LCD 1280x800 native resolution, 512MBx1 Memory, CD-RW/DVD-ROM,
6-cell battery, Integrated Intel Pro/Wireless 2200BG (802.11b/g), ATI MOBILITY™ RADEON®
X600 with dedicated 64MB DDR SDRAM, IEEE-1394 port/Media Bridge Adapter slot/Parallel
port/Express Card slot, Integrated Microphone, Microsoft Windows XP Professional, 1-year
standard limited warranty
PTA40U-012009 032017317277
System Characteristics1
Operating System
•Microsoft® Windows® XP Professional
Processor2:
•Intel Pentium® M Processor 730 [1.60GHz, 2MB L2 cache,
533MHz FSB]
Chipset
•Mobile Intel 915GM Express Chipset
Memory3
•512MB (Minimum)/2048MB (Maximum), 2 memory slots using
256MB, 512MB, or 1024MB PC2700 DDR 333MHz SDRAM
2.5V SODIMM memory modules
Mass Storage
Hard Drive4
•60GB (4200 RPM) Enhanced IDE (ATA-6) hard disk drive;
9.5mm height; user removable
Optical Disk Drive
•Fixed Bay DVD/CD-RW drive:
Maximum Speed:
CD-ROM (24x:read), CD-R (24x:write), CD-RW
(10x:write), DVD-ROM (8x:read)
Compatibility:
CD-ROM (read), CD-R (read/write), CD-RW (read/re-
write), DVD-ROM (read), DVD-R (read), DVD-RW (read),
DVD+R (read), DVD-RAM (read)
Display5
•15.4” diagonal widescreen TFT active-matrix LCD display at
1280x800 native resolution; Maximum Brightness 180 Cd/m2
•Brightness Control [keyboard: Fn+F6 (decrease brightness) or
Fn+F7 (increase brightness)]
Graphics
•ATI MOBILITY™ RADEON® X600 with 64MB DDR SDRAM 6
Input Devices
•Keyboard
o85 key US keyboard, 2.7mm key stroke, 6mm keyboard
height, 19.05mm key pitch
oHot Key Functions (FN); please see electronic User’s Guide
for more information
oWindows Key Function
oApplication Key Function
•Mouse:
oTouchPad™ pointing device
oTouchPad Enable/Disable (Fn+F9 or through software)
•Others:
oInternet Browser Launch Function
Expandability
•2 main memory slots. Both slots may be occupied.
•1 PC Card slot; supports 1 Type II, PCMCIA R2.01, PC Card16,
CardBus
•1 Express Card slot
•Bridge Media Adapter slot (Secure Digital®, Memory Stick™,
Memory Stick PRO™, SmartMedia™, Multi Media Card, xD
Picture Card [shared slots])
•240-pin Advanced Port Replicator III docking connector
Communications
•Integrated V.92 modem7
•Marvell® PC Express Network Connection –10Base-T/100Base-
TX Ethernet
•Integrated Intel Pro/Wireless 2200BG (802.11b/g) Wireless-LAN
Network Connection:8
Ports
•RGB (monitor) port
•TV-out (S-Video)
•i.LINK™ IEEE-1394
•3 Universal Serial Bus (USB) ports (v2.0)
•Microphone jack
•Headphone jack
•RJ-45 LAN port
•RJ-11 modem port
•Parallel port
•240-pin docking connector for Advanced Replicator III
Physical Description
•Dimensions (WxDxH Front/H Rear): 14.17'' (360.0mm) x 10.57''
(268.5mm) x 1.14'' (29.0mm)[F]/1.43'' (36.2mm)[R] without feet
•Weight9: Starting at 6.2 lbs. depending upon configuration
•Indicators: Power, DC-IN, Primary HDD/ODD Access, Caps
Lock (keyboard), Arrow Mode (keyboard), Numeric Mode
(keyboard)
•Case material: PC+ABS Plastic; LCD Cover painted Premium
Silver; Premium Black for LCD Mask, Cover, and Base.
Sound
•Analog Devices AD1981B Software Sound
•16-bit stereo; Built-in stereo speakers, Built-in microphone
•Direct3D Sound; DirectSound, Direct Music, MIDI (playback)
Support
•Sound Volume Control Dial
Power Supply
•75W (15V x 5A) Auto sensing external AC Adapter, 100-
240V/50-60Hz frequency (Universal) input.
•Dimensions (WxDxH): 5.35” (136 mm) x 2.09” (53 mm) x 1.18”
(30 mm)
•Weight: starting at 0.88 lbs (400 g)
Battery10
•6-cell (4300mAh) rechargeable, removable Lithium Ion (Li-Ion)
battery pack
oWeight: starting at 0.75 lb. (340 g)
oDimensions (WxDxH): 8.13” (206.6mm) x 0.87” (22.0mm) x
2.12” (53.8mm)
oBattery Life: Up to 3 hours 15 minutes (measured by
MobileMark™)11 (6-cell battery)
oRecharge Time: Main Battery – up to 4.0 hours (system off)
or up to 12 hours (system on)
Security
•Slot for cable lock
•Items protected by a screw: Memory (1 screw), Main HDD (6
screws), Built-in Modem/LAN (3 screws)
•Passwords: User Power-on password, Supervisor Password,
HDD Password
•Other locks: Keyboard Lock (Fn+F1 Hotkey), Screen Blank
(Hotkey), Screen Saver (by Software)
BIOS
•ACPI v1.0b, PNP v1.0a, VESA v2.0, DPMS, DDC, SM BIOS
v2.34, PC BIOS v2.2 support
Software12
Toshiba Software and Utilities
•Toshiba CD/DVD Drive Acoustic Silencer
•Toshiba Common Modules

Toshiba
© Copyright 2005 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Tecra A4-S211 BTS Rev. 1.05 2005-08-25 KK CB V1.40 Page 2 of 4
•Toshiba ConfigFree™
•Toshiba Console
•Toshiba Controls
•Toshiba Custom Utilities
•Toshiba Display Device Change Utility
•Toshiba Express Media Player
•Toshiba Hotkey Utility for Display Devices
•Toshiba MyConnect™ - 45 day free trial offer13
•Toshiba PC Diagnostic Tool
•Toshiba Picture Enhancement Utility
•Toshiba Power Saver
•Toshiba Speech System
•Toshiba Tecra A4 Electronic User’s Guide
•Toshiba Touch and Launch
•Toshiba Touch Pad On/Off Utility
•Toshiba Utilities
•Toshiba Wireless Hotkey
•Toshiba Zooming Utility
Third-party Software14
•Microsoft Office® OneNote™ 2003
•Microsoft Works™ Version 8.0
•Sun® Java™ 2 Runtime Environment
•Adobe® Acrobat® Reader version 5.0
•Software Decoder: InterVideo® (WinDVD™ 5)
•InterVideo WinDVD Creator 2 Platinum
•Sonic™ PrimeTime
•Sonic Solutions RecordNow!™ Basic for Toshiba
•Sonic Solutions Drive Letter Access (DLA)
•Microsoft Windows Media Player version 10
•Napster® Digital Music Service – 30 days trial
•Computer Associates Easy FireWall – 30 days trial
•Norton® AntiVirus™ 2004 – w/3-Month Subscription
•AOL® version 9.0 – 3-Month offer
AOL OFFER DETAILS: Availability may be limited, especially during peak times. TO
AVOID BEING CHARGED A MONTHLY MEMBERSHIP FEE, SIMPLY CANCEL
BEFORE THE THREE-MONTH PROMOTIONAL PERIOD ENDS. Premium services
carry surcharges and communication surcharges may apply, including AK, even
during promotional period. Members may incur telephone charges on their phone bill,
depending on their location and calling plan, even during promotional period.
Available to new AOL members in the United States, age 18 or older; a major credit
card or checking account is required.
•AT&T® Worldnet® Service – 1 Month offer
Telephone access and other charges and other terms and conditions may apply.
Offer available to new customers only,
•Intuit® Quicken® New User Edition 2004
•QuickTime™ Player
•RealOne™ Player 8 Basic
Environmental Specifications
Operating Non-Operating
Temperature 5°to 35°C
(41°to 95°F) -20°to 65°C (-4°to 149°F)
Thermal Gradient 15°C per hour maximum 20°C per hour
maximum
Relative Humidity 20% to 80% 10% to 95%
Altitude (relative to
sea level) -60 to 3000 meters -60 to 10,000 meters
Shock 7G; 1.5G when ODD
device installed 60G
Vibration 0.2G; 0.25G when ODD
device installed 1.0G
Limited Warranty
•1-year standard, limited warranty
Toshiba offers many different warranty extensions and enhanced service
plans such as SystemGuard®, At-Home Repair, and Service Express to
provide additional support to your notebook PC. For a full description and
complete list of programs, please visit
http://www.accessories.toshiba.com
Upgrades and Extensions for Products with a 1-
year Standard, Limited Warranty
Warranty Extension
Extends the standard warranty for up to 4 years from the original
notebook purchase date. See Toshiba Service Plan Agreement for
program terms and conditions at http://www.pcsupport.toshiba.com.
Part Number Description
SWC-PEQQ2V 2nd Year Warranty Extension
SWP-PEQQ3V 2nd/3rd Year Warranty Extension
SystemGuard Accidental Damage Coverage
Provides coverage of accidental damage caused by drops, spills and
even screen breakage. Warranty Extension included except with 1 Year
plan.
Part Number Description
SWC-PSGQ1V 1st Year
SWC-PEGQ2V 1st/2nd Year + Warranty Extension
SWP-PEGQ3V 1st/2nd/3rd Year + Warranty Extension
ServiceExpress
Select your express repair service with either Depot Express or Carry-In
Express. Depot Express: Notebook repaired the same day it is received,
and returned via overnight delivery. Shipping and box provided. Carry-In
Express: Notebook repaired by the next business day at any Premier
Authorized Service Provider. Warranty Extension included except with 1
Year plan.
Part Number Description
SWC-PSQP1V 1st Year
SWC-PEQP2V 1st/2nd Year + Warranty Extension
SWP-PEQP3V 1st/2nd/3rd Year + Warranty Extension
Business On-Site Repair
A technician arrives with parts at the customer’s business location the
next business day and performs the necessary hardware repairs.
Warranty Extension included except with 1 Year plan.
Part Number Description
SWC-PSQN1V 1st Year
SWC-PEQN2V 1st/2nd Year + Warranty Extension
SWP-PEQN3V 1st/2nd/3rd Year + Warranty Extension
SystemGuard1 + ServiceExpress
Combines SystemGuard and ServiceExpress coverage. Warranty
Extension included except with 1 Year plan.
Part Number Description
SWC-PSGP1V 1st Year
SWC-PEGP2V 1st/2nd Year + Warranty Extension
SWP-PEGP3V 1st/2nd/3rd Year + Warranty Extension
SystemGuard1 + Business On-Site Repair
Combines SystemGuard and Business On-Site Repair coverage.
Warranty Extension included except with 1 Year plan.
Part Number Description
SWC-PSGN1V 1st Year
SWC-PEGN2V 1st/2nd Year + Warranty Extension
SWP-PEGN3V 1st/2nd/3rd Year + Warranty Extension
Accessories
Memory
Part Number Description
KTT3311A/512 Kingston PC2100/PC2700, 512MB DDR
KTT3311A/1G Kingston PC2100/PC2700, 1GB DDR
SD Memory Cards
Part Number Description
SD-M5124B3 Toshiba 512MB SD (Secure Digital)
Power
Part Number Description
PA3283U-2ACA Toshiba 75W Global AC Adapter
PA3399U-1BRS Toshiba Primary Li Ion Battery Pack (6 Cell)
PA3400U-1BRS Toshiba Primary High Capacity Li Ion Battery Pack
(12 Cell)
Cases-Security
Part Number Description
PA1335U-1NCS Toshiba Ambassador Leather Case (15.4")
PA1360U-1NCS Toshiba Executive Nylon Case (15.4")
PA1361U-1NCS Toshiba Executive Leather Case (15.4")
PA1362U-1NCS Toshiba BackPack (15.4")
PA1377U-1NCS Toshiba/Brenthaven Deluxe Shoulder Case (15.4")
PA1378U-1NCS Toshiba/Brenthaven Wheeled Case (17")

Toshiba
© Copyright 2005 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Tecra A4-S211 BTS Rev. 1.05 2005-08-25 KK CB V1.40 Page 3 of 4
NWDEFCL Targus-Noteworthy DEFCON CL Cable Lock
Expansion
Part Number Description
PA3314U-1PRP Toshiba Advanced Port Replicator III w/75W AC
Adapter
Input Devices
Part Number Description
PA1336U-1NKB Toshiba USB Keyboard
PA1337U-1NMS Toshiba USB Optical Scroller Mouse
PA1367U-1NMS Toshiba USB Ultra-Mini Retractable Scroller Mouse
PA1368U-1NHB Toshiba USB 2.0 Mini 4-Port Hub (w/AC adapter)
PA1370U-1ETC Toshiba Keyboard Protector (Tecra/Satellite/Qosmio)
Storage and Backup
Part Number Description
PA3404U-1H40 Toshiba USB Mobile Hard Drive 40GB (1.8")
HDD1232CZP41002 Toshiba 5GB Type II PC Card HDD w/Back-up
software
UABS2-60.0 CMS ABSplus 60GB USB 2.0 Auto Backup Syst
UABS2-80.0 CMS ABSplus 80GB USB 2.0 Auto Backup Syst
PA3109U-1FDD Toshiba USB Floppy Disk Drive Kit
Multimedia
Part Number Description
PA3390U-1MPM Toshiba MultiMedia Center/Audio USB Hub
Wireless LAN
Part Number Description
PA3376U-1MPC Wireless LAN Card Kit, Mini-PCI (802.11ag) (Intel)
[Dealer Install Only]
Bluetooth
Part Number Description
PA3370U-1BTM Toshiba Bluetooth SD Card V1.2
PA3405U-1BTM Toshiba Bluetooth USB Adapter
Subject to Change
While Toshiba has made every effort at the time of publication to ensure the accuracy of the information provided herein, product specifications,
configurations, prices, system/component/options availability are all subject to change without notice. For the most up-to-date product information about your
computer, or to stay current with the various computer software or hardware options, visit Toshiba’s Web site at http://pcsupport.toshiba.com. The product
specifications and configuration information are designed for a product Series. Your particular model may not have all the features and specifications listed or
illustrated. For more detailed information about the features and specifications on your particular model, please visit Toshiba's Web site at
http://pcsupport.toshiba.com.
Return Policy
Notwithstanding anything to the contrary in any third party License Agreement or product documentation supplied with your PC, Toshiba America Information
Systems, Inc. (“TAIS”) does not accept the return of component parts, or bundled software, that have been removed from the PC system. Pro-rata refunds on
individual PC components or bundled software, including the operating system, will not be granted. If you wish to return a complete PC system, contact the
TAIS dealer where you purchased the product, and comply with the dealer’s standard return policies and procedures.
Toshiba America Information Systems, Incorporated (“TAIS”)
9740 Irvine Boulevard
Irvine CA 92618
ToshibaDirect website: http://www.toshibadirect.com
TAIS website for resellers: http://sell.toshiba.com
TAIS PC Support website: http://pcsupport.toshiba.com
Portégé, Satellite, Tecra, Slim SelectBay and SystemGuard are registered trademarks and ConfigFree is a trademark of Toshiba America Information
Systems, Inc. and/or Toshiba Corporation. Intel, Celeron, Centrino, Intel Inside, Pentium, the Intel Centrino logo, and the Intel Inside logo are trademarks or
registered trademarks of Intel Corporation or its subsidiaries in the United States and other countries. Microsoft and Windows are registered trademarks and
OneNote is a trademark of Microsoft Corporation in the United States and/or other countries. Winstone® is a registered trademark and BatteryMark™ is a
trademark of Ziff Davis Publishing Holdings Inc. in the U.S. and other countries. MobileMark™ is a trademark of the Business Applications Performance
Corporation. Wi-Fi is a registered certification mark of the Wi-Fi Alliance. The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. and any
use of such marks by Toshiba is under license. NVIDIA and GeForce are registered trademarks or trademarks of NVIDIA Corporation in the United States
and/or other countries. All other trademarks are the property of their respective owners.
1Certain notebook chassis are designed to accommodate all possible configurations for an entire product series. Your select model may not have all the
features and specifications corresponding to all of the icons or switches shown on the notebook chassis, unless you have selected all those features.
2CPU performance in your computer product may vary from specifications under the following conditions:
1. Use of certain external peripheral products
2. Use of battery power instead of AC power
3. Use of certain multimedia, computer generated graphics or video applications
4. Use of standard telephone lines or low speed network connections
5. Use of complex modeling software, such as high end computer aided design applications
6. Use of several applications or functionalities simultaneously
7. Use of computer in areas with low air pressure (high altitude greater than 1,000 meters or greater than 3,280 feet above sea level)
8. Use of computer at temperatures outside the range of 5°C to 30°C (41°F to 86° F) or >25°C (77°F) at high altitude (all temperature references are
approximate and may vary depending on the specific computer model – please refer to your Resource Guide or visit the Toshiba website at
www.pcsupport.toshiba.com for details.)
CPU performance may also vary from specifications due to design configuration.
Under some conditions, your computer product may automatically shut-down. This is a normal protective feature designed to reduce the risk of lost data or
damage to the product when used outside recommended conditions. To avoid risk of lost data, always make back-up copies of data by periodically storing it
on an external storage medium. For optimum performance, use your computer product only under recommended conditions. Read additional restrictions
under “Environmental Conditions” in your product Resource Guide. Contact Toshiba Technical Service and Support for more information.
3The graphics system in your computer may use part of the main system memory for graphics performance and therefore reduce the amount of system
memory available for other computing activities. The amount of system memory allocated to support graphics may vary depending on the graphics system,
applications utilized, system memory size and other factors.
4One (1) Gigabyte (GB) means 1000 x 1000 x 1000 = 1,000,000,000 bytes using powers of 10. The computer operating system, however, reports storage
capacity using powers of 2 for the definition of 1 GB = 1024 x 1024 x 1024 = 1,073,741,824 bytes, and therefore may show less storage capacity. Available
storage capacity will also be less if the product includes one or more pre-installed operating systems, such as Microsoft Operating System and/or pre-
installed software applications, or media content. Actual formatted capacity may vary.
5Small bright dots may appear on your TFT display when you turn on your PC. Your display contains an extremely large number of thin-film transistors (TFT)

Toshiba
© Copyright 2005 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Tecra A4-S211 BTS Rev. 1.05 2005-08-25 KK CB V1.40 Page 4 of 4
and is manufactured using high-precision technology. Any small bright dots that may appear on your display are an intrinsic characteristic of the TFT
manufacturing technology. Over a period of time, and depending on the usage of the computer, the brightness of the LCD Screen will deteriorate. This is an
intrinsic characteristic of LCD technology.
6The revolutionary new ATI RADEON X600 GPU utilizes the additional bandwidth of PCI Express to reach higher levels of graphics performance than
traditional graphics memory solutions. The ATI RADEON X600 GPU shares the capacity and bandwidth of dedicated graphics memory and dynamically
available system memory for turbocharged performance and larger total graphics memory. The system memory capacity indicated in the Microsoft Windows
PROPERTIES display is the maximum possible system memory capacity without adjustment for any system memory which may be dynamically allocated to
the graphics system depending on demand.
7Due to FCC limitations, speeds of 53 kbps are the maximum permissible transmission rates during download. Actual data transmission speeds will vary
depending on line conditions.
8Wireless connectivity is subject to availability of access points. You might have to purchase additional software, hardware and/or services or pay for phone
charges or air time to achieve the functionality as advertised. The transmission speed over the wireless LAN and the distance over which wireless LAN can
reach may vary depending on surrounding electromagnetic environment, obstacles, access point design and configuration, and client design and
software/hardware configurations. The actual transmission speed will be lower than the theoretical maximum speed.
9Weight may vary depending on product configuration, vendor components, manufacturing variability and options selected.
10 Battery life may vary depending on product model, configuration, applications, power management settings and features utilized. Recharge time varies
depending on usage. Battery may not charge while computer is consuming full power. After a period of time, the battery will lose its ability to perform at
maximum capacity and will need to be replaced. This is normal for all batteries. To purchase a new battery pack, see the accessories information that
shipped with your computer or visit the Toshiba web site at http://www.accessories.toshiba.com.
11 MobileMark™ is a registered trademark of Business Applications Performance Corporation.
12 Some software may differ from its retail version (if available), and may not include user manuals or all program functionality.
13 MYCONNECT OFFER DETAILS: 1 Valid in the US only! You must cancel your Access Plan before the end of the trial period to avoid being charged the
$39.95 monthly Access Service fee for the six month plan commitment period. Monthly automatic renewal feature after end of commitment period. Available
to new members in the U.S., age 18 or older, and a major credit card for billing is required. Offer is for unlimited dial-up, wired broadband, or Wi-Fi remote
access connection time in the 50 United States and the District of Columbia within the MyConnect service area for 30 day continuous service periods. Use of
optional 800 telephone number dial-up usage will incur additional fees even during the trial period. Other terms and conditions apply. Offer expires June 30,
2005. Information, prices, and availability subject to change without notice.
14 Some software may differ from its retail version (if available), and may not include user manuals or all program functionality.
